M-Series™ Quantum
User Manual
Models:
M506x-H9, M586x-H1 & M706x-H3
Table of Contents
Getting to Know Your TV. . . . . . . . . . . . . . . . . . . . . . . . . . . |
1 |
Front Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1 |
Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
2. . |
Wall-mounting the TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
.4. |
Using the Remote . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
.5. |
Completing the First-Time Setup . . . . . . . . . . . . . . . . . . . |
6 |
Using the On-Screen Menu . . . . . . . . . . . . . . . . . . . . . . . . . |
7 |
Navigating the On-Screen Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
7. |
Changing the Input Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
7 |
Adjusting the Picture Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
8. |
Adjusting the Color Temperature. . . . . . . . . . . . . . . . . . . . . . . . . . . |
8 |
Changing the Picture Aspect Ratio . . . . . . . . . . . . . . . . . . . . . . . . |
9. |
Adjusting Advanced Picture Settings . . . . . . . . . . . . . . . . . . . . . . |
9. |
Adjusting Picture Input Settings . . . . . . . . . . . . . . . . . . . . . . . . . . |
12. |
Adjusting the Picture Mode Edit Settings. . . . . . . . . . . . . . . . . . . . |
12 |
Adjusting the Audio Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
14. |
Adjusting the Network Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
15. |
Setting Up TV Channels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
16 |
Scanning for TV Channels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
16 |
Skipping Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
16 |
Changing the Analog Audio Language . . . . . . . . . . . . . . . . . . . . . |
17. |
Using Parental Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
18. |
Accessibility Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
19 |
Setting Up Closed Captioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
19. |
Changing the Appearance of Digital Closed Captions . . . . . . . . . |
19 |
Changing the System Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
21 |
Changing the On-Screen Menu Language . . . . . . . . . . . . . . . . . . |
21. |
Setting the Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
21. |
Changing the TV Name . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
22. |
Renaming Devices on the Input Menu. . . . . . . . . . . . . . . . . . . . . . . |
22 |
Adjusting the Power Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
22. |
Using the USB Power Feature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
23 |
Turning the Power Indicator On or Off. . . . . . . . . . . . . . . . . . . . . . . |
23 |
Setting Timers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
.23. |
Setting a System PIN Code. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
24 |
Adjusting the CEC Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
24 |
Managing Mobile Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
24. |
Using the Admin & Privacy Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
25 |
Viewing System Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
25 |
Checking for System Updates . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
25. |
Performing a Soft Power Cycle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
25 |
Restoring the TV to Factory Default Settings. . . . . . . . . . . . . . . . . |
25 |
Store Demo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
25 |
Viewing Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
26 |
Managing Advertising Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . |
26. |
View VIZIO Privacy Policy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
26. |
Using the Info Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
27 |
SmartCast Home™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
28 |
What is SmartCast Home? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
28. |
How to Launch SmartCast Home . . . . . . . . . . . . . . . . . . . . . . . . . |
28. |
What you can do with SmartCast Home . . . . . . . . . . . . . . . . . . . . . |
28 |
Control your TV with the SmartCast Mobile™ App. . . . . . . . . . . . . |
28 |
WatchFree™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
29 |
What is WatchFree? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
29. |
What you can do with WatchFree . . . . . . . . . . . . . . . . . . . . . . . . . . . |
29 |
How to Launch WatchFree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
29. |
Playing USB Media. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
30 |
Preparing Your USB Drive to Play USB Media . . . . . . . . . . . . . . . .30 Displaying USB Media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30. Removing the USB Drive from the TV . . . . . . . . . . . . . . . . . . . . . . 30.
Product Registration and Technical Support. . . . . . . . . . |
34 |
Help Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
35 |
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
37 |
Regulatory Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . |
38 |
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
39 |
Legal Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
41 |
ii
Safety & Certification
THANK YOU FOR CHOOSING VIZIO
And congratulations on your new VIZIO TV!
To get the most out of your new VIZIO product, read these instructions before using your product and retain them for future reference. Be sure to inspect the package contents to ensure there are no missing or damaged parts.
PRODUCT REGISTRATION
To purchase or inquire about accessories and installation services for your VIZIO product, visit our website at vizio.com or call toll free at (877) 698-4946.
We recommend that you register your VIZIO product at vizio.com.
WHEN READING THIS MANUAL
TIP: When you see this symbol, please read the accompanying helpful tip.
WARNING: When you see this symbol, please read the accompanying important warning or notice. It is intended to alert you to the presence of important operating instructions.
Color Text — This is the TV menu feature you should be selecting.
Grey Text — This is an action for you to complete, such as entering in a name.
>— The arrow sign shows the flow of the steps you should take.
1.Lists additional steps you can take for each setting.
•Bullets give more detailed information about each feature.
IMPORTANT SAFETY INSTRUCTIONS
Your TV is designed and manufactured to operate within defined design limits. Misuse may result in electric shock or fire. To prevent your TV from being damaged, the following instructions should be observed for the installation, use, and maintenance of your TV. Read the following safety instructions before operating your TV. Keep these instructions in a safe place for future reference.
•To reduce the risk of electric shock or component damage, switch off the power before connecting other components to your TV.
•Read these instructions.
•Keep these instructions.
•Heed all warnings.
•Follow all instructions.
•Do not use this apparatus near water.
•Clean only with dry cloth.
•Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
•Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
•Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
•Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
•Only use attachments/accessories specified by the manufacturer.
•Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
•Unplug the power cord before cleaning your TV.
•Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
•Unplug this apparatus during lightning storms or when unused for long periods of time.
•When moving your TV from an area of low temperature to an area of high temperature, condensation may form in the housing. Wait before turning on your TV to avoid causing fire, electric shock, or component damage.
•A distance of at least three feet should be maintained between your TV and any heat source, such as a radiator, heater, oven, amplifier etc. Do not install your TV close to smoke. Operating your TV close to smoke or moisture may cause fire or electric shock.
•Slots and openings in the back and bottom of the cabinet are provided for ventilation. To ensure reliable operation of your TV and to protect it from overheating, be sure these openings are not blocked or covered. Do not place your TV in a bookcase or cabinet unless proper ventilation is provided.
•Never push any object into the slots and openings on your TV cabinet. Do not place any objects on the top of your TV. Doing so could short circuit parts causing a fire or electric shock. Never spill liquids on your TV.
•Your TV should be operated only from the type of power source indicated on the label. If you are not sure of the type of power supplied to your home, consult your dealer or local power company.
•Do not apply pressure or throw objects at your TV. This may compromise the integrity of the TV. The manufacturer’s warranty does not cover user abuse or improper installations.
•The power cord must be replaced when using different voltage than the voltage specified. For more information, contact your dealer.
•When connected to a power outlet, power is always flowing into your TV. To totally disconnect power, unplug the power cord.
•The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of un-isolated, dangerous voltage within the inside of your TV that may be of sufficient magnitude to constitute a risk of electric shock to persons.
iii
•Do not overload power strips and extension cords. Overloading can result in fire or electric shock.
•The wall socket should be installed near your TV and easily accessible.
•Only power of the marked voltage can be used for your TV. Any other voltage than the specified voltage may cause fire or electric shock.
•Do not touch the power cord during lightning. To avoid electric shock, avoid handling the power cord during electrical storms.
•Unplug your TV during a lightning storm or when it will not be used for long period of time. This will protect your TV from damage due to power surges.
•Do not attempt to repair or service your TV yourself. Opening or removing the back cover may expose you to high voltages, electric shock, and other hazards. If repair is required, contact your dealer and refer all servicing to qualified service personnel.
•WARNING: Keep your TV away from moisture. Do not expose your TV to rain or moisture. If water penetrates into your TV, unplug the power cord and contact your dealer. Continuous use in this case may result in fire or electric shock.
•Do not use your TV if any abnormality occurs. If any smoke or odor becomes apparent, unplug the power cord and contact your dealer immediately. Do not try to repair your TV yourself.
•Avoid using dropped or damaged appliances. If your TV is dropped and the housing is damaged, the internal components may function abnormally. Unplug the power cord immediately and contact your dealer for repair. Continued use of your TV may cause fire or electric shock.
•Do not install your TV in an area with heavy dust or high humidity. Operating your TV in environments with heavy dust or high humidity may cause fire or electric shock.
•Follow instructions for moving your TV. Ensure that the power cord and any other cables are unplugged before moving your TV.
•To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation instructions.
•Insert batteries in accordance with instructions. Incorrect polarities may cause the batteries to leak which can damage the remote control or injure the operator. Do not expose batteries to excessive heat such as sunshine, fire or the like.
•When unplugging your TV,grab the head of the power plug, not the cord. Pulling on the power cord may damage the wires inside the cord and cause fire or
electric shock. When your TV will not be used for an extended period of time, unplug the power cord.
•To reduce risk of electric shock, do not touch the connector with wet hands.
•This apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the apparatus.
•The mains plug or appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable.
•If any of the following occurs, contact the dealer:
−The power cord fails or frays.
−Liquid sprays or any object drops into your TV.
−Your TV is exposed to rain or other moisture.
−Your TV is dropped or damaged in any way.
−The performance of your TV changes substantially.
•CAUTION: These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock, do not perform any servicing other than that contained in the operating instructions unless you are qualified to do so.
•The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated DANGEROUS VOLTAGE within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electrical shock to persons.
•WARNING: Exposure to loud sounds can damage your hearing causing hearing loss and tinnitus (ringing or buzzing in the ears). With continued exposure to loud noises, ears may become accustomed to the sound level, which may result in permanent damage to hearing without any noticeable discomfort.
•Install the TV where it cannot be pulled, pushed or knocked over.
•Do not allow children to hang onto the product.
•Store the accessories (remote, batteries, etc.) in a location safely out of the reach of children.
•The American Academy of Pediatrics discourages television viewing for children younger than two years of age.
•WARNING — Stability Hazard: A television set may fall, causing serious personal injury or death. Many injuries, particularly to children, can be avoided by taking simple precautions such as:
•ALWAYS use cabinets or stands or mounting methods recommended by the manufacturer of the television set.
•ALWAYS use furniture that can safely support the television set.
•ALWAYS ensure the television set is not overhanging the edge of the supporting furniture.
•ALWAYS educate children about the dangers of climbing on furniture to reach the television set or its controls.
•ALWAYS route cords and cables connected to your television so they cannot be tripped over, pulled or grabbed.
•NEVER place a television set in an unstable location.
•NEVER place the television set on tall furniture (for example, cupboards or bookcases) without anchoring both the furniture and the television set to a suitable support.
•NEVER place the television set on cloth or other materials that may be located between the television set and supporting furniture.
•NEVER place items that might tempt children to climb, such as toys and remote controls, on the top of the television or furniture on which the television is placed.
•If the existing television set is going to be retained and relocated, the same considerations as above should be applied.
•Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery, that can result in an explosion;
•Leaving a battery in an extremely high temperature surrounding environment that can result in an explosion or the leakage of flammable liquid or gas;
•A battery subjected to extremely low air pressure that my result in an explosion or the leakage of flammable liquid or gas.
•WARNING: To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation instructions.
iv
TELEVISION ANTENNA CONNECTION PROTECTION
The TV shall be installed in accordance with the applicable provisions of Article 810 and Article 820.
If an outside antenna/satellite dish or cable system is to be connected to the TV, make sure that the antenna or cable system is electrically grounded to provide some protection against voltage surges and static charges.
Article 810 of the National Electrical Code, ANSI/NFPSA 70, provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of the grounding conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements of the grounding electrode.
Lightning Protection
For added protection of the TV during a lightning storm or when it is left unattended or unused for long periods of time, unplug the TV from the wall outlet and disconnect the antenna or cable system.
Power Lines
Do not locate the antenna near overhead light or power circuits, or where it could fall into such power lines or circuits. Remember, the screen of the coaxial cable is intended to be connected to earth in the building installation.
Installation of CATV
The installation instructions states the cable distribution system should be grounded (earthed) in accordance with ANSI/NFPA 70. the National Electrical Code (NEC), in particular Section 820.93, Grounding of Outer Conductive Shield of a Coaxial Cable.
Installation of Antenna
The installation instructions states the cable distribution system used for connection to antennas and dishes should be grounded (earthed) in accordance with ANSI/ NFPA 70. the National Electrical Code (NEC), in particular Section 810.21, Bonding Conductors and Grounding Electrode Conductors — Receiving Stations.
Ground Clamp
Antenna Lead In Wire
Antenna Discharge Unit
(NEC Section 810-20)
Grounding Conductors
(NEC Section 810-21)
Ground Clamps
Electric Service Equipment |
Power Service Grounding Electrode System |
|
(NEC ART 250, part H) |
v
Dolby, Dolby Vision, Dolby Audio, and the double-D symbol are trademarks of Dolby Laboratories Licensing Corporation. Manufactured under license from Dolby Laboratories. Confidential unpublished works. Copyright © 1992-2020 Dolby Laboratories. All rights reserved.
For DTS patents, see http://patents.dts.com.
Manufactured under license from DTS, Inc. DTS, the Symbol, DTS and the Symbol together, Virtual:X, and the DTS Virtual:X logo are registered trademarks or trademarks of DTS, Inc. in the United States and/or other countries. © DTS, Inc. All Rights Reserved.
The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
For DTS patents, see http://patents.dts.com.
Manufactured under license from DTS, Inc. DTS, the Symbol, DTS and the Symbol together, DTS-HD, and the DTS-HD logo are registered trademarks or trademarks of DTS, Inc. in the United States and/or other countries. © DTS, Inc. All Rights Reserved.
vi
Getting to Know Your TV |
1 |
|
|
FRONT PANEL
Remote Sensor and Power Indicator
When using the remote, aim it directly at this sensor. |
|
The power indicator flashes on when the TV turns on, then goes out after several seconds. |
|
To keep the power indicator on, see Turning the Power Indicator On or Off on page 23. |
1 |
1
REAR PANEL
Power
Press to turn on the TV.
Press and hold to turn the TV off.
Volume
Press to increase or decrease the TV volume level.
Input
Press to access the input menu.
VOL
INPUT
Note: The image shown here is for illustrative purposes only and may be subject to change.
The actual number of ports and their locations may vary, depending on the model.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
HDMI |
|
Composite |
Audio Out |
Coaxial |
|
USB |
Optical Audio Out |
Ethernet |
||||||||||||
Connect an HDMI device |
Connect a composite |
Connect to an RCA device, |
Connect to a coaxial |
Connect a USB thumb drive to |
Connect to an optical/SPDIF |
Connect an Ethernet cable |
||||||||||||||
|
|
|
|
|
|
|
|
such as sound bar |
cable from cable, |
play photo, music, or video |
audio device, such as home |
to modem/router |
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
satellite, or antenna |
|
|
|
audio receiver |
|
||
2
1
Connecting a device — AUDIO & VIDEO CABLE TYPES
Your TV can be used to display output from most devices.
1.Verify that your device has a video port that matches an available port on the TV (HDMI, Composite, etc.).
2.Connect the appropriate cable (not included) to the TV and the device.
3.Turn the TV and your device on.
4.Set the TV’s input to match the connection you used (HDMI-1, HDMI-2, etc.).
HDMI CABLE |
|
COAXIAL CABLE |
|
HDMI |
Coaxial |
|
|
COMPOSITE (AV) CABLE
Y
L
R
Connecting a device — AUDIO CABLE TYPES
Your TV can be output sound to an audio device, such as a receiver or sound bar.
1.Verify that your device has an audio port that matches an available port on the TV (optical, RCA, etc).
2.Connect the appropriate cable (not included) to the TV and the device.
3.Turn the TV and your device on.
HDMI CABLE
HDMI
COMPONENT AND/OR COMPOSITE CABLE
R
L
OPTICAL/SPDIF CABLE
Optical
Note: The actual ports and their locations may vary, depending on the TV model.
3
1
WALL-MOUNTING THE TV
First you will need a wall mount. Consult the provided table below to find the appropriate mount for your TV.
Be sure the mount you choose is capable of supporting the weight of the TV.
To install your TV on a wall:
1.Disconnect any cables connected to your TV.
2.Place the TV face-down on a clean, flat, stable surface. Be sure the surface is clear of debris that can scratch or damage the TV.
3.If attached, remove the stands by loosening and removing the screws.
4.Attach your TV and wall mount to the wall by carefully following the instructions that came with your mount. Use only with a UL-listed wall mount bracket rated for the weight/load of your TV.
TIP: Installing a TV on a wall requires lifting. To prevent injury or damage to the TV, ask someone to help you.
WARNING: Do not use the screws that are included inside the wall mount holes to mount TV.
Note: The image shown here is for illustrative purposes only and may be subject to change. The actual number of ports and their locations may vary, depending on the model.
|
M506x-H9 |
M586x-H1 |
M706x-H3 |
|
|
|
|
Screw Size: |
M6 |
M6 |
M6 |
|
|
|
|
Hole Depth: |
14 mm |
14 mm |
12 mm |
|
|
|
|
Hole Pattern: |
200 mm x 200 mm |
300 mm x 200 mm |
400 mm x 400 mm |
|
|
|
|
Weight w/o Stand: |
27.62 lb (12.53 kg) |
31.53 lb (14.3 kg) |
57 lb (24.2 kg) |
|
|
|
|
4
USING THE REMOTE
Input
Change the currently displayed input
App Launcher
Quickly launch the pictured app
Menu
Display the settings menu
WatchFreeTM
Access WatchFree channels
(not available in Canada)
Navigation Buttons — Left / Right
Navigate the on-screen menus
Navigation Buttons — Up / Down
Navigate the on-screen menus
Back
Go to the previous on-screen menu
Volume Up/Down
Increase or decrease the loudness of the audio
Number Pad
Manually enter a channel
Pic
Cycle through the different picture setting modes
Long press to enabled/disable talk back feature
INPUT
MENU |
|
INFO |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
OK
|
|
BACK |
|
|
|
CC |
|
|
|
||||||
|
|
|
|
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
+ |
PREV |
+ |
|
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
VOL |
|
|
|
CH |
|||||||||
|
|
|
|
|
|||||||||||
_ |
|
|
|
_ |
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
1 |
2 |
|
3 |
|
|
|
|
|
|
||||||
4 |
5 |
|
6 |
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|||||||||
|
|
|
8 |
|
9 |
|
|
|
|
|
|
||||
|
7 |
|
|
|
|
|
|
|
|||||||
|
|
PIC |
0 |
— |
|
|
|
|
|||||||
|
|
|
|
|
|
||||||||||
|
|
|
|||||||||||||
Power
Turn television on or off
Info
Display the info window
OK/Play/Pause
Select the highlighted menu option and play or pause content
Home Button
Launch SmartCast Home™/Return to
SmartCast Home Screen
Closed Caption
Enable or disable close captions
Long press to open Accessibility menu featuring captions, talk back, speech rate, and zoom mode
Channel Up/Down
Change the channel
Last
Return to the channel last viewed
Mute
Turn the audio on or off
Dash
Use with number pad to manually enter a digital subchannel (for example, 18-4 or 18-5)
1
Replacing the Batteries
1.Push the bottom of the battery compartment and lift battery cover to open.
2.Insert two batteries into the remote control. Make sure that the (+) and (-) symbols on the batteries match the (+) and (-) symbols inside the battery compartment.
3.Replace the battery cover and click to close.
Lift
+
In many places batteries cannot be thrown away or discarded with household waste. Please ensure you properly dispose of your batteries consistent with the laws and/or regulations where you live. For more information please visit: www.vizio.com/environment
WARNING: Keep the remote control batteries away from children. It may cause choking and/or lead to a fire or chemical burn if mishandled. Do not dispose of batteries in fire. Replace only with batteries of the correct type.
TIP: When needed, VIZIO recommends replacing the batteries that came with this remote with two, new Duracell ‘AAA’ alkaline batteries.
5
Completing the First-Time Setup
Before you begin the first-time setup:
•Your TV should be installed and the power cord should be connected to an electrical outlet.
•If you have a wireless network, have the network password ready.
•If you are connecting to your network with an Ethernet cable, connect it to the Ethernet port on the TV.
The first time you turn on the TV, the on-screen instructions will guide you through each of the steps necessary to get your TV ready for use:
Choose a language for your TV.
English |
|
|
|
|
|
Español |
|
Français |
|
|
|
|
|
|
|
|
|
|
|
1.Choose your language. Pressing the CC button will enable TTS (text-to-speech) functionality.
How are you using your TV?
How are you using your TV?
Home Use |
|
Store Demo |
|
Home Use |
|||
|
Store Demo |
||
|
|
|
|
|
|
|
2.Choose home use.
Where is you VIZIO TV located?
USA |
|
|
|
|
|
Mexico |
|
Canada |
|
|
|
|
|
|
|
|
|
|
|
3.Choose your country.
Choose a Wi-Fi Network.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Home Network |
|
|
Public Wi-Fi |
|
|
John’s Network |
|
|
Ana’s Network |
|
Encrypted |
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
|
Rescan Networks |
|
|
Hidden Netwok |
|
Help |
|
|
Skip |
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
4.Choose your Wi-Fi network and enter the password.
Which room is your VIZIO TV Located?
Which room is your VIZIO TV Located?
Family Room |
Living Room |
Master |
|
Bedroom |
|
Game Room |
||
Family Room |
Living Room |
Master |
|
Bedroom |
|
Game Room |
||
|
|
|
Add Custom Location |
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
Add Custom Location |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
5.Name your TV.
2
Let’s set up local channels.
To search for local broadcast channels, make sure the cable from the antenna, wall or cable box is properly connected to your VIZIO TV.
Next Skip
6.Scan for channels.
Terms & Conditions.
Your use of this device and software functionality are covered by VIZIO and Google ‘s respective Terms of Service and Privacy Policies.
By pressing “Accept All”, you agree to be bound by the (i) VIZIO Terms of Service and Privacy Policy and (ii) the Google Terms of Service and
Privacy Policy. NOTE: Accepting the terms and policiesis a condition of using the Cast functionality of this device.
VIZIO Terms & |
|
VIZIO Privacy |
|
Google Privacy |
|
Google Terms & |
Conditions |
|
Policy |
|
Policy |
|
Conditons |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Skip For Now |
|
Accept All |
|
|
|
|
|
|
|
|
|
7.Accept the Terms & Conditions.
Viewing Data
This unit is equipped with Automated Content Recognition (”ARC”) Technology also known as Viewing Data.
WHAT DATA DOES ACR TECHNOLOGY COLLECT? |
|
DO WE DO WITH VIEWING DATA? |
When enabled, ACR technology will collect information about the audio and video |
VIZIO or its authorized data partners may combine Viewing Data with household |
|
|
Viewing Data |
|
programing content playing on this internet-connected display unit including |
|
demogr phic data, or other data about your digital actions, like smartphone |
broadcast television, advertisements and other commercially available content. We |
location, web histories or offline purchases, in order to determine the effectiveness |
|
associate this Viewing Data with the IPThisaddressunit isforequippedthe unit,withand aAutomatedniquedeviceContent Recognitionofa (”ARC”)particularTechnad, orlogychoosealsowhichknownads ViarewinglikelyDatato be. useful or timely, including
number we assign. You may change your Viewing Data settings at any time within |
|
during broadcast, cable, satellite, or internet based television programming. VIZIO |
||||||
WHATthe SettingsDATAMenuDOESofACRyourTECHNOLOGYTV. DecliningCOLLECT?Viewing Data collection will not change the |
|
WHATand itsDOauthorizedWE DO WITHdata partnersVIEWINGalsoDATA?use the information to generate summary |
||||||
Whenfunctionalityenabled,ofACRyourtechnologydevice. |
will collect information about the audio and video |
|
VIZIOanalysisor itsandauthreporizedts ofdatahow partnersusers engagemay combinewith contentViewingon theirDataTVswithandhouseholdother |
|||||
programing content playing on this internet-connected display unit including |
|
devicesmographic. |
data, or other data about your digital actions, like smartphone |
|||||
broadcastWHO DO WEtelevision,SHARE VIEWINGadvertisementsDATA WITH?and other commercially available content. We |
|
location, web histories or offline purchases, in order to determine the effectiveness |
||||||
associateWhen enabled,this Viewingwe shareDataViewingwith theDataIPwithaddressauthorizedfor thedataunit,partnersandunique. We licensedevice |
|
ofWHATa particularELSE DOESad, orVIEWINGchoose DATAwhichSHARINGads are likelyMEANto beFORusefulYOU?or timely, including |
||||||
numberViewing weDataassignto analytics. You maycompanies,change yourmediaViewingcompanies,Data settingsadvertisers,at anyadtimeagencies,within |
|
duringViewingbroadcast,D ta is alsocable,usedsatellite,to help orcontentinternetpubalishers,ed televisionbroadcastersprogrammior congtent. VIZIO |
||||||
theandSettingsother adMenutech companiesof your TV. whoDecliningmeasureViewingad effectivenessData collectionr aidwillpersonnot changelizationthe |
|
anddistributionits authorizedservicesdatacreatepartnersor recommendalso use themoreinformationrelevant entertainmentto generate summarybased on |
||||||
functionalityof ads. Our authorizedof your devicecloud. service providers may also store this data on and |
|
analysissummaryandinsightsreports. Forofexample,how usersif devicesengage withsharingcontentyour onIP addresstheir TVssuggestand otheran |
||||||
solely on our behalf, and for no other purposes. |
|
devicesinterest.in music, fitness, or sports related topics, advertisers might deliver tailored |
||||||
WHO DO WE SHARE VIEWING DATA WITH? |
|
|
|
|
|
|
||
When enabled, we share Viewing Data with authorized data partners. We license |
|
WHAT ELSE DOES VIEWING DATA SHARING MEAN FOR YOU? |
||||||
Viewing Data to analytics companies, media companies, advertisers, ad agencies, |
|
Viewing Data is also used to help content publishers, broadcasters or content |
||||||
and other ad tech companies who measure ad effectivenessViewingor aidDatapersonalizationPolicy |
|
distributionDeclineservices create orAcceptrecommend more relevant entertainment based on |
||||||
of ads. Our authorized cloud service providers may also store this data on and |
|
summary insights. For example, if devices sharing your IP address suggest an |
||||||
solely on our behalf, and for no other purposes. |
|
interest in music, fitness, or sports related topics, advertisers might deliver tailored |
||||||
|
|
|
|
|
|
|
|
|
|
|
Viewing Data Policy |
|
Decline |
|
|
Accept |
|
|
|
|
|
|
|
|
|
|
8.View and accept VIZIO Viewing Data Policy.
6
Using the On-Screen Menu
Your TV features an easy-to-use on-screen menu .
To open the on-screen menu, press the MENU button on the remote.
From this menu, you can: |
|
|
• Adjust the picture settings |
TV Settings |
|
• Adjust the audio settings |
Picture |
|
• Adjust the network settings |
Audio |
|
|
||
|
Network |
|
• Adjust the TV channel settings |
TV Channels |
|
|
||
• Adjust accessibility settings |
Accessibility |
|
• Adjust TV system settings |
System |
|
Admin & Privacy |
||
|
||
• Access admin and privacy settings |
User Manual |
|
• View the user manual |
|
|
|
|
3
NAVIGATING THE ON-SCREEN MENU
To open the on-screen menu:
1.Press the MENU button on the remote.
2.Use the Navigation buttons to highlight a menu option, and press the OK button to select that option.
TIP: While navigating the on-screen menu, you can press the BACK button at any time to return to the previous menu screen.
CHANGING THE INPUT SOURCE
External devices, such as DVD players, Blu-ray players, and video game consoles, can be connected to your TV. To use one of these devices with your TV, you must first change the input source using the input menu.
To change the input sources:
1.Press the INPUT button on the remote. The input menu is displayed.
2.Use the Navigation buttons or the INPUT button on the remote to highlight the input you wish to view. The corresponding inputs are named on the back of your TV.
3.Press OK or release the INPUT button. The selected input is displayed.
Change Input
SMARTCAST |
WatchFree |
HDMI-1 |
HDMI-2 |
HDMI-3 |
HDMI-4 |
COMP |
TV |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Input Name
The underlined input on the left is the current input selected. Inputs may vary by TV.
TIP: You can change the input names that appear on the Input menu to make your devices easy to recognize. See Renaming Devices on the Input Menu on page 22.
7
3
ADJUSTING THE PICTURE SETTINGS
Your TV can be adjusted to suit your preferences and viewing conditions.
To adjust the picture mode settings:
Menu > Picture > Picture Mode
1.Use the Navigation buttons on the remote to highlight Picture Mode, then use the Left/Right Navigation buttons to change the picture mode:
•Vivid — Sets the picture settings to values that produce a brighter, more vivid picture.
•Bright — Great for viewing everyday TV, such as news and TV shows, that requires a brighter image with motion enhancements.
•Calibrated — Accurate colors intended for cinema content viewing in a bright room.
•Calibrated Dark — Accurate colors intended for cinema content viewing in a dark room or at nighttime.
•Game — Reduces throughput delays and optimizes the picture settings for displaying game console output. Also the preferred picture mode for computer mode.
•Sports — Sets the picture settings to values ideal for watching sport events with motion control setting.
TIP: If you save changes to the setting for a picture mode, an asterick will appear after its name. See Saving a Custom Picture Mode on page 12.
2.To manually change each of the picture settings, use the Up/Down Navigation buttons on the remote to highlight that picture setting, then use the Left/Right Navigation buttons to adjust the setting:
•Backlight (SDR content) or Tone Mapping (HDR content) — Adjusts the LED brightness to affect the overall brilliance of the picture.
•Brightness — Adjusts the black level of the picture. When this setting is too low, the picture may be too dark to distinguish details. When this setting is too high, the picture may appear faded or washed out.
•Contrast — Adjusts the white level of the picture. When this setting is too low, the picture may appear dark. When this setting is too high, the picture may appear faded or washed out. If the setting is too high or too low, detail may be difficult to distinguish in dark or bright areas of the picture.
•Color — Adjusts the intensity of the picture colors.
•Tint — Adjusts the hue of the picture. This setting is useful in adjusting the flesh tones in the picture. If flesh appears too orange, reduce the level of color before adjusting tint.
•Sharpness — Adjusts the edge sharpness of picture elements. It can be used to sharpen non-HD (high definition) content; however, it will not produce detail that does not otherwise exist.
Picture Mode |
|
|
Calibrated |
|||
Backlight |
|
|
|
|
|
|
|
|
|
|
|
||
Brightness |
|
|
|
|
|
|
|
|
|
|
|
||
Contrast |
|
|
|
|
|
|
|
|
|
|
|
||
Color |
|
|
|
|
|
|
|
|
|
|
|
||
Tint |
|
|
|
|
|
|
|
|
|
|
|
||
Sharpness |
|
|
|
|
|
|
|
|
|
|
|
|
|
Color Temperature |
|
|
|
Normal |
||
Picture Aspect |
|
|
|
Normal |
||
Advanced Picture |
|
|
|
|
|
|
Input Settings |
|
|
|
|
|
|
Adjusting the Color Temperature
Adjusting the color temperature changes the white balance of the picture.
To adjust the color temperature:
Menu > Picture > Color Temperature
Use the Navigation buttons on the remote to highlight a color temperature preset and then press OK.
•Warm — Produces an orange-hued picture.
•Cool — Produces a blue-hued picture.
•Normal — Optimized for television viewing.
Color Temperature
Warm
Cool
Normal
8
3
Changing the Picture Aspect Ratio
To change the screen aspect ratio:
Menu > Picture > Picture Aspect
Use the Navigation buttons to highlight the aspect ratio you wish to view.
Your TV can display images in different modes:
•Normal (default) — No change to aspect ratio.
•Panoramic* — Stretches a 4:3 image to fill 16:9 screen with an algorithm so the center doesn’t look stretched.
•Wide — Stretches a 4:3 aspect ratio to fill 16:9 screen. If a 16:9 image, adds black bars to top and bottom.
•Zoom — Expands image both horizontally and vertically by 14%.
•Stretch* — When the 16:9 signal is a 4:3 image with black bars left and right, stretches to fill the screen.
Some programs have black bars on the top or sides of the screen so that the picture keeps its original shape. Examples include widescreen movies and older TV programs.
Normal |
Stretch |
Wide |
Zoom |
|
|
|
|
TIP: The aspect ratio cannot be changed for Ultra
HD content or HDR content.
Adjusting Advanced Picture Settings
To adjust advanced picture settings:
Menu > Picture > Advanced Picture
Use the Navigation buttons to highlight the setting you wish to adjust, then press the Left/Right Navigation buttons to change the setting:
•Black Detail — Adjusts the average brightness of the picture to compensate for large areas of brightness.
•Super Resolution — Configures the resolution to enhance dim and blurred pictures resulting in a sharper image.
•Edge Enhancement — Increases the smoothness of edges.
•Local Contrast — Adjust the contrast of the picture locally.
•Backlight Control — Dynamically improves the constrast ratio of the picture by adjusting the backlight.
Advanced Picture
Black Detail |
Off |
Super Resolution |
Medium |
Edge Enhancement |
Low |
Local Contrast |
Low |
Backlight Control |
Off |
Reduce Noise |
|
V-Gaming Engine™ |
|
Film Mode |
On |
Gamma |
2.1 - Normal |
Color Calibration |
Off |
•Reduce Noise:
−Signal Noise: Reduces background picture noise when viewing analog sources. This function helps to correct "speckle" noise with a slight reduction in sharpness.
−Block Noise: Reduces the side effects of digital compression such as "blocking" and noise on sharp edges. The High setting will cause a slight reduction in sharpness.
−Contour Smoothing: Removes visible contour noise without loss of the complex detail.
•V-Gaming Engine™:
−Game Low Latency: Reduces video delay (lag) when gaming. When set to Auto and Automatic Low Latecy Mode (ALLM) is detected, ALLM will apply for the duration of the game.
−Game HDR: Optimizes picture quality for HDR game.
•Film Mode — Optimizes the picture for watching films. Select On or Off.
•Gamma — Set the shape of the Gamma curve. Use lower Gamma values for bright room conditions, and higher values when it’s dark.
•Color Calibration — Calibrate colors using HSB, gain, offset and 20 point white balance and test or reset colors to defaults.
*Available aspect ratio settings may vary by input source. Panoramic mode is only available for standard |
9 |
definition TV (480i/480p) and Stretch mode is only available for high definition TV (720p/1080i/1080p). |
