RECHARGEABLE HAND-HELD AND UPRIGHT VACUUM
CLEANER SHSS 12 B2
RECHARGEABLE HAND-HELD AND
UPRIGHT VACUUM CLEANER
Operating instructions
IAN 100116
AKKU-HAND- UND
-BODENSTAUBSAUGER
Bedienungsanleitung
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.
GB / IE Operating instructions Page 1
DE / AT / CH Bedienungsanleitung Seite 11
A B C
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Appliance description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Before fi rst use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Charging the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Assembly/disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Connecting the hand element to the handle/removal from handle . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Using the hand element with the handle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Using the hand element . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Cleaning and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Emptying the dirt container . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Cleaning the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Cleaning the rotary brush . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
GB
IE
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Warranty and service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Disposal of the appliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Disposal of (rechargeable) batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Importer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
SHSS 12 B2
1
RECHARGEABLE HAND-HELD
GB
AND UPRIGHT VACUUM
IE
CLEANER SHSS 12 B2
Introduction
Congratulations on the purchase of your new
appliance.
You have selected a high-quality product.
The operating instructions are part of this product.
They contain important information on safety, usage
and disposal. Before using the product, familiarise
yourself with all handling and safety guidelines.
Use the product only as described and for the range
of applications specifi ed. Please also pass these
operating instructions on to any future owner(s).
Intended use
This appliance has been designed exclusively for
vacuum cleaning dry surfaces and dry residues.
This appliance is intended solely for use in private
homes. Do not vacuum people or animals with this
appliance. Any other usage of or modifi cation to
the appliance is deemed to be improper usage
and carries the risk of serious personal injury. The
manufacturer accepts no liability for damages that
result from improper use of the appliance or are
caused by the incorrect operation of it.
The appliance is not intended for commercial use.
Package contents
Handheld vacuum cleaner
Brush nozzle
Crevice tool
Extension handle with fl oor nozzle
Cradle (with charging socket)
Charger
Operating instructions
Appliance description
Figure A:
1 Grip, hand element
2 On/Off switch
3 Charge indicator lamp
4 Hand element
5 Buttons
6 Dust fi lter
7 Coarse fi lter
8 Dirt container
Figure B:
9 On/Off switch
0 Grip
q "Grip" release
w "Hand element" release
e Hand element recess
r Rotary brush
t LED lamp
Figure C:
z Brush nozzle
u Crevice tool
i Charger
o Charger barrel jack
p Holder for brush nozzle
a Holder for crevice tool
s Charging socket
d Cradle (with charging socket)
Check the delivery contents for completeness
immediately after unpacking.
2
SHSS 12 B2
Technical data
Charger
Input: 100–240 V ~50/60 Hz 300 mA Max.
Output: 13.5 V
Type designation: SHSS 12 B2-2
Protection class: II /
Floor nozzle
Nominal power: 5 W
Protection class: III /
Input voltage: 10.8 V 1800 mAh
500 mA
Appliance
Input voltage/current: 13.5 V
Nominal power: 75 W
Protection class: III /
Batteries: 10.8 V/1800 mAh Li-ion battery
Battery Pack: 3 cells each of 3.6 V
Operating time with full battery charge
(depending on fl oor covering): approx. 15 min.
Charging time with empty battery: 5–6 hours
500 mA
Safety guidelines
DANGER – ELECTRIC SHOCK!
► Do not charge or use the appliance outdoors.
► Never use the handheld vacuum cleaner if the cable, plug or casing are
damaged.
► To avoid risks, arrange for damaged power cables and/or plugs to be
replaced as soon as possible by a qualifi ed specialist or by our Customer
Services.
► Arrange for repairs to be carried out only by specialist workshops. Under
no circumstances should you open the appliance yourself. Repairs that are
not carried out by a specialist workshop could lead to physical injuries.
► Before charging the appliance, make sure that the mains voltage corresponds
to the voltage indicated in the technical data for the charger.
► Never touch the mains adapter/charger or the appliance with wet or damp
hands.
► Do not use the mains adapter/charger with an extension cable; connect
the mains adapter directly to a power socket.
GB
IE
SHSS 12 B2
3
GB
IE
WARNING! RISK OF INJURY!
► Do not change any accessories while the appliance is switched on.
► Do not use the handheld vacuum cleaner for vacuuming up water or other
liquids.
► Do not use the handheld vacuum cleaner for vacuuming up sharp objects
or glass shards.
► Never vacuum up burning matches, glowing ashes or cigarette butts.
► Do not use the handheld vacuum cleaner for vacuuming up chemical
products, stone dust, gypsum, cement or similar particles.
► This appliance is not suitable for use with infl ammable and explosive
substances or chemical and aggressive liquids.
► Always store the appliance indoors. To prevent accidents, keep the appli-
ance in a dry location when not in use.
► Under extreme conditions, leaks in the battery cells may occur. In the event
that battery fl uid comes into contact with skin or eyes, the aff ected area
must be rinsed off with water immediately. Contact a physician.
► This appliance may be used by children aged 8 years and above and by
persons with limited physical, sensory or mental capabilities or lack of experience and knowledge, provided that they are under supervision or have
been told how to use the appliance safely and are aware of the potential
risks. Children must not use the appliance as a plaything. Cleaning and
user maintenance tasks may not be carried out by children unless they are
supervised.
4
SHSS 12 B2
WARNING! RISK OF INJURY!
► Use only accessories recommended by the manufacturer.
► The mains adapter may not be used for other purposes.
► Always grip the power plug to disconnect the appliance from the power
supply.
► Always be sure to keep the handheld vacuum cleaner away from heating
elements, ovens or other heated appliances and surfaces.
► Always make certain that the ventilation slits are not obstructed. A blocked
ventilation circuit can result in overheating and damage to the appliance.
► Take special care when using the handheld vacuum cleaner on stairs.
► This product contains rechargeable batteries. Do not throw the appliance
into a fi re and do not subject it to high temperatures. There is a risk of
explosion!
► Always remove the fl oor nozzle from the handle before cleaning the rotary
brush to avoid accidental starting of the rotary brush.
ATTENTION! MATERIAL DAMAGE!
► Do not use the handheld vacuum cleaner without the dust fi lter inserted.
► Do not use the mains adapter for a diff erent product and do not attempt
to charge this appliance with a diff erent charger. Use only the charger
supplied with this appliance.
► Never charge non-rechargeable batteries!
GB
IE
SHSS 12 B2
5
