Preface
Manual Purpose
This manual provides detailed information about the assembling, dissembling, testing and
troubleshooting of the equipment to support effective troubleshooting and repair. It is not
intended to be a comprehensive, in-depth explanation of the product architecture or technical
implementation. Observance of the manual is a prerequisite for proper equipment
maintenance and prevents equipment damage and personnel injury.
This manual is based on the maximum configuration; therefore, some contents may not apply
to your pulse oximeter. If you have any question, please contact our Customer Service
Department.
Intended Audience
This manual is for biomedical engineers, authorized technicians or service representatives
responsible for troubleshooting, repairing and maintaining the pulse oximeter.
Revision History
This manual has a revision number. This revision number changes whenever the manual is
updated due to software or technical specification change. Contents of this manual are subject
to change without prior notice.
Revision number: 2.0
Release time: 2010-04
Password
Maintenance password: 321
III
FOR YOUR NOTES
IV
Contents
1 Safety........... .............................. ... .. ... .............................. ... .. ... .............................. .. .......... 1-1
1.1 Safety Information ..........................................................................................................1-1
1.1.1 Warnings............................................................................................................. 1-2
1.1.2 Cautions ............................................................................................................. 1-2
1.1.3 Notes .................................................................................................................. 1-2
1.2 Equipment Symbols ........................................................................................................ 1-3
2 Theory of Operation ........................................................................................................ 2-1
2.1 Introduction..................................................................................................................... 2-1
2.2 System Connections ........................................................................................................ 2-1
2.2.1 Mounting the Pulse Oximeter ............................................................................ 2-1
2.2.2 Connectors for Peripheral Devices..................................................................... 2-2
2.3 Main Unit ........................................................................................................................ 2-3
2.3.1 Main Control Unit .............................................................................................. 2-3
2.3.2 Power Supply ..................................................................................................... 2-6
2.3.3 Main Board Interfaces........................................................................................ 2-9
2.3.4 SpO
2.3.5 Charger stand ....................................................................................................2-11
Module.................................................................................................... 2-10
2
3 Testing and Maintenance................................................................................................. 3-1
3.1 Introduction..................................................................................................................... 3-1
3.1.1 Recommended Frequency .................................................................................. 3-2
3.2 Visual Test ....................................................................................................................... 3-3
3.3 Power On Test ................................................................................................................. 3-3
3.4 Performance Tests...........................................................................................................3-4
3.4.1 SpO
3.4.2 SpO
3.5 Electrical Safety Tests .....................................................................................................3-5
3.5.1 Enclosure Leakage Current Test......................................................................... 3-6
3.5.2 Patient Leakage Current Test ............................................................................. 3-6
3.6 Output Interface Test.......................................................................................................3-7
3.6.1 RS232 Port test................................................................................................... 3-7
3.6.2 Infrared Output Test ........................................................................................... 3-7
3.7 Program Upgrade ............................................................................................................ 3-8
4 T ro ubleshooting................................................................................................................ 4-1
4.1 Introduction..................................................................................................................... 4-1
4.2 Part Replacement ............................................................................................................4-1
4.3 Software Version Check.................................................................................................. 4-2
Test............................................................................................................ 3-4
2
Test in Motion Mode................................................................................. 3-4
2
1
4.4 Technical Alarm Check ................................................................................................... 4-2
4.5 Troubleshooting Guide.................................................................................................... 4-3
4.5.1 Power On/Off Failures ....................................................................................... 4-3
4.5.2 Display Failures ................................................................................................. 4-3
4.5.3 Alarm Problems.................................................................................................. 4-4
4.5.4 Button Failure..................................................................................................... 4-4
4.5.5 Interface Failures................................................................................................ 4-4
4.5.6 Power Supply Failures ....................................................................................... 4-5
4.5.7 Software Upgrade Problems............................................................................... 4-5
5 Repair and Disassembly .................................................................................................. 5-1
5.1 Tools................................................................................................................................ 5-1
5.2 Preparations for Disassembly.......................................................................................... 5-1
5.3 Disassembly Guide ......................................................................................................... 5-2
5.3.1 Removing the Covers ......................................................................................... 5-2
5.3.2 Removing the Main Board ................................................................................. 5-4
5.3.3 Removing the Speaker and SpO
Communication Cable Socket....................... 5-4
2
5.3.4 Removing the LCD Screen ................................................................................ 5-5
5.3.5 Remove the Screen Mount ................................................................................. 5-6
6 Parts .................................................................................................................................. 6-1
6.1 Introduction..................................................................................................................... 6-1
6.2 Main Unit ........................................................................................................................ 6-2
6.3 Front Panel Assembly ..................................................................................................... 6-3
6.4 Main Board Assembly..................................................................................................... 6-4
6.5 Battery Adjusting Bracket Assembly .............................................................................. 6-5
6.6 Rear Cover Assembly...................................................................................................... 6-6
6.7 Replacement Parts...........................................................................................................6-7
2
1 Safety
1.1 Safety Information
WARNING
z Indicates a potential hazard or unsafe practice that, if not avoided, could result in
death or serious injury.
CAUTION
z Indicates a potential hazard or unsafe practice that, if not avoided, could result in
death or serious injury.
NOTE
z Provides maintenance tips or other useful information.
1-1
1.1.1 Warnings
WARNING
z All installation operations, expansions, changes, modifications and repairs of this
product should be conducted by authorized personnel only.
z Always disconnect the equipment with the charger stand and remove the batteries
before disassembling the equipment.
z Dispose of the packaging material according to local waste control regulations and
your hospital’s waste disposal protocols. Keep the packaging material out of
children’s reach.
1.1.2 Cautions
CAUTION
z Make sure that no electromagnetic radiation interferes with the performance of the
equipment when preparing to carry out performance tests. Mobile phone, X-ray
equipment and MRI devices are possible sources of interference as they may emit
higher levels of electromagnetic radiation.
z Before connecting the charger stand to the AC mai n s, ch eck that the voltage and
frequency ratings of the AC mains meet the specifications indicated on the
equipment’s label or in this manual.
z Protect the equipment from damage caused by drop, impact, strong vibration or
other mechanical force during servicing.
1.1.3 Notes
NOTE
z Refer to Operation Manual for detailed operation and other information.
1-2
1.2 Equipment Symbols
Direct Current (DC)
Attention: Consult this manual before maintenance.
Auxiliary output connector
Audio pause
Battery door locked/unlocked
Power supply connector
Left/Right button
Power button
Up button
Down button
Date of manufacture
Serial number
Safety Class II equipment
Type BF applied part, defibrillation protected
The following definition of the WEEE label applies to EU member states
only.
This symbol indicates that this product should not be treated as household
waste. By ensuring that this product is disposed of correctly, you will help
prevent bringing potential negative consequences to the environment and
human health. For more detailed information with regard to returning and
recycling this product, please consult the distributor from whom you
purchased it.
* For system products, this label may be attached to the main unit only.
1-3
FOR YOUR NOTES
1-4
2 Theory of Operation
2.1 Introduction
This pulse oximeter is designed to monitor or measure the oxygen saturation and pulse rate of
single adult, pediatric and neonatal patient.
The pulse oximeter also:
Presents audible and visual alarms in case of patient or equipment problems.
Enables the real-time displaying, reviewing, storing and exporting of SpO
values.
Supports Pitch Tone, which means the pitch of pulse tone rises as the oxygen saturation
level increases and falls as the oxygen saturation level decreases.
Operates on either alkaline batteries or a lithium-ion battery.
Offers wired or wireless communication with a personal computer.
and PR
2
2.2 System Connections
2.2.1 Mounting the Pulse Oximeter
The pulse oximeter can be mounted on a wall bracket or on a trolley support. The wall
bracket or trolley support can be ordered optionally. Each type of mounting bracket is
delivered with a complete set of mounting hardware and instructions for use. To install the
pulse oximeter, refer to the instrutions for installation.
CAUTION
z Use mounting brackets we supply or approve. If other compatible mounting
bracket is used, be sure it can be safely applied to the pulse oximeter.
z The mounting bracket should be installed by our qualified service personnel, or
mechanical engineers who have adequate knowledge on it.
z If other mounting solution is used, the installation personnel and the customer
should verify if it can be safely applied to the pulse oximeter, and the customer
assume the responsibility for any risk resulting from that.
2-1
2.2.2 Connectors for Peripheral Devices
The connectors for peripheral devices are located at the top, right side and bottom of the
pulse oximeter as shown in the figure.
Multifunctional connector
It is a DB 9 connector which is used to connector a SpO
sensor (including reusable
2
sensor, disposable sensor and veterinary sensor) to measure the oxygen saturation or
connect a personal computer through a PC communication cable to export trend data.
Infrared port
It is a port through which a personal computer is communicated using a infrared adapter
to export data in real time without affecting patient monitoring.
Power supply connector
It is a female power socket which is used to connect the charger stand’s male power
plug . To avoid being mixed with other power supply adapters, it has nonstandard size.
2-2
2.3 Main Unit
The pulse oximeter consists of main board, SpO
charger stand. The main board is composed of a main control unit and a power module.
The following diagram shows the structure of the main unit.
board, display, speaker, batteries and
2
2.3.1 Main Control Unit
The main control unit provides the system with resources and support. It controls the LCD
screen, alarm LED, speaker, button operation and data storage. It also implements
communication with the SpO
The functional block diagram of the main control unit is shown below:
board, power module and external interfaces.
2
2-3
2.3.1.1 Power Supply
The power module provides the main control unit with 3.1 V, 2.5 V and 0.9 V power supple.
Label Voltage Applicable parts
DVDD 3.1 V Alarm LEDs, Flash memory, infrared light-emitting IC,
PC communication cable, LCD boost up circuit,
prestage audio optional amplifier.
VDDE 2.5 V DSP peripheral voltage, SDRAM, LCD logic, infrared
logic, buttons and resetting.
VDDINT 0.9 V DSP kernel voltage
2-4
2.3.1.2 Core Control Unit
The Core control unit consists of CPU, SDRAM and Flash memory.
The CPU is ADI’s DSP BF531. Its kernel running frequency is up to 400 MHz and external
frequency up to 133MHz. The kernel voltage is 0.8 V and the current consumed at 50 MHz is
as low as 26mA. The oscillating frequency of the CPU clock is 11.0592 MHz and its
expected frequency is 55MHz, which can be implemented through internal PLL frequency
multiplication. The SDRAM provides space for program running and the Flash memory
provides space for storing program, data, lingual library and configuration information. The
BF531 starts directly from the Flash memory.
2.3.1.3 Man-machine Interfaces
The functions of the buttons are listed below:
Button In measurement mode In menu mode
Audio Pause
button
Up button Increases the beat
Down button Decreases the beat
Left button Enters the main menu Enters a submenu or confirm
Right button Locks/Unlocks buttons. Returns to the previous menu
LCD screen
It is a 2.4” standard QVGA (320×240) TFT LCD with a 36-pin connector. The LCD is
connected with the BF531 through a bus. 4 LEDs in series are used to backlight the
LCD. The maximum current is 15mA and driving voltage 13.2V. The main control
board provides DC power supply for the LCD and the backlight board.
Pauses audible alarms. Pauses audible alarms.
Moves the cursor upwards or
volume.
volume.
increases the value of selected
menu item by one.
Moves the cursor downwards
or decreases the value of selected
menu item by one.
the selection.
or exits the current menu.
Alarm lamp
The alarm lamp gives visual alarm signals which meet applicable requirements. It
consists of 4 LEDs in parallel. The alarm LEDs receive electrical signal sent by the main
board and convert it into optical signal which is then sent to the panel through a light
conducting bar. The alarm LEDs light up in red and yellow.
2-5
Audible indicators
Audio files including alarm tone, button tone and pulse tone are burned in a serial flash
memory in advance. To give out a sound, the CPU reads audio data from the flash
memory and controls the puse-width modulation (PWM) to give out a audible signal.
The pulse oximeter supports pitch tone and multi-level volume. The speaker is
connected with the main board and the audible signal is provided by the main board.
2.3.1.4 Communication Interfaces
RS232 port
The RS232 port implements communication through the CPU’s UART module and the
RS232 drive chip. The RS232 drive chip which is integrated in the PC communication
cable is electrostatically protected. The CPU’s UART module has an external drive IC
to enforce driving and ensure protection.
Infrared port
The BF 531’s UART supports infrared transmission. The transmitted and received
signals are connected directly to the infrared IC.
2.3.2 Power Supply
The power module provides hardware for power supply management. It detects the level
required by all hardware, the priority of power supply type as well as the power supply status.
It is also controls the power indicating lamp and real-time clock, manages battery charging
and communicates with the main control unit.
The block diagram of the power module is shown below:
2-6
2.3.2.1 Input
The pulse oximeter runs on a chargeable lithium-ion battery or three alkaline AA size
batteries.
Lithium-ion battery: voltage 3.7V, capacity 1800mAh;
Alkaline AA size batteries: three batteries in series, the total voltage 4.5V.
Connect the pulse oximeter to the charger stand and then connect the AC mains. The battery
will be charged automatically if a lithium-ion battery is used. However, if alkaline batteries
are used, the batteries will not be charged.
2.3.2.2 Output
1. SpO2 circuit
3.3V 20mA (Peak 120mA)
±2.5V 10mA
2. Main control circuit
3.1V 5mA (Peak 150mA)
2.5V 50mA (Peak 150mA)
0.9V 20mA (Peak 50mA)
3. LCD backlight and speaker are directly run by the power supply.
2.3.2.3 Power Supply Management
1. Shutdown delay
When the battery voltage is too low, an alarm message “Battery Too Low” is presented
and the pulse oximeter will shut down automatically in maximum 10 minutes.
2. Run time
In the case that SpO
brightness is set to minimum, the run time of alkaline batteries is 36 hours and
lithium-ion battery 24 hours, using a new, fully charged battery at ambient temperature
25℃.
is monitored continuously, audio indicators are off and backlight
2
3. The power supply efficiency is not less than 80 percent.
2-7
2.3.2.4 Charging the Lithium-ion Battery
The pulse oximeter is configured with a lithium-ion battery charging circuit which can detect
battery charging status and provide protection against overtime, overcurrent as well as
overtemperature charging. It automatically charges the battery in circle and enters into the
sleeping mode when the battery is fully charged. The system identifies battery type through
BC pole to avoid charging the alkaline batteries. The charge time to 90% capacity is less than
2 hours and to 100% capacity less than 3.5 hours.
2.3.2.5 Man-machine Interfaces
Button
To avoid pressing the Power button by accident, you have to press and hold it for 2
seconds when you need to turn off the pulse oximeter. However, to turn on the pulse
oximeter, just press it momentarily.
LED indicator
The Power Indicating lamp is a LED that lights green and yellow. It is located on the
main board. The status of the LED is specified as follows:
Green: when the pulse oximeter is plugged in the charger stand, and the AC
mains is connected, or when the battery is fully charged if a lithium
battery is used.
Yellow: when a lithium ion battery is used and is being charged.
Off: When the AC mains is not connected.
2-8
2.3.3 Main Board Interfaces
The main board implements connection and communication with other parts and peripheral
devices. The interfaces located on the main board are listed below:
No. Description What to connect
J1 LCD connector LCD screen
SpO
board, providing power supply and
J2 SpO2 board connector
J3 SpO2 sensor connector
J4
Multifunctional
connector
2
communicating the SpO
SpO
board, connecting the SpO2 sensor to the
2
SpO
board
2
board
2
SpO2 sensor or personal computer
J5
DSP simulator
connector
DSP simulator
J6 Speaker connector Speaker
J7 DC connector Charger stand
J8
J9
J10 BC connector
J11 NTC connector
J12
Battery positive pole
connector
Common earthing
connector
Power supply program
downloading connector
Battery positive pole
Charger stand or battery negative pole
Lithium-ion battery BC pole, detecting battery
type
Lithium-ion battery NTC pole, detecting battery
temperature
Power supply MCU programmer
2-9
2.3.4 SpO2 Module
The SpO
perfusion strength. It also offers motion and poor perfusion proof, detects status and fault,
and communicates with the main control unit.
The SpO
module measures oxygen saturation and pulse rate and offers Pleth wave and
2
module block diagram is shown below:
2
2-10
2.3.4.1 Analog Circuit
The SpO
module analog circuit adopts low power consumption design. The voltage of signal
2
amplifying part is ±2.5V. The first stage amplifying multiple is adjustable. The sensor's
driving voltage is 3.3V.
2.3.4.2 Digital Circuit
The digital circuit part mainly consists of microprocessor circuit and watchdog circuit.
The ADuC7024 microprocessor used on the SpO
8kb SRAM and a 62kb Flash/EE memory, a 10-channel 12-bit ADC, a dual-channel 12-bit
DAC and a 12-bit data acquisition system. The processor kernel is ARM7TDMI which
supports 16/32-bit RISC command. The system frequency is up to 40MIPS. The ADuC7024
microprocessor supports downloading through UART and JTAG interfaces. The chip’s
operating voltage is 2.7 to 3.6V and operating temperature is -40 to 125℃.
The chip adopted in the watchdog circuit is TPS3823-30.
module is AD’s 16/32-bit MCU. It has an
2
2.3.5 Charger stand
The DC terminal of the charger stand is a round male power plug which is used to connect
the pulse oximeter’s DC power supply connector. The AC terminal of the charger stand varies
to match AC power lines of different areas.
The charger stand meets the following specifications:
Input voltage 100 to 240V AC
Input frequency 50 to 60Hz
Output voltage 5V DC
Output current 1.2A
2-11
FOR YOUR NOTES
2-12
3 Testing and Maintenance
3.1 Introduction
To ensure the pulse oximeter always functions normally, qualified service personnel should
perform regular inspection, maintenance and test. This chapter provides testing procedures
for the pulse oximeter with recommended test equipment and frequency. The service
personnel should perform the testing and maintenance procedures as required and use
appropriate test equipment.
The testing procedures provided in this chapter are intended to verify that the pulse oximeter
meets the performance and safety specifications. If the pulse oximeter fails to perform as
specified in any test, repairs or replacement must be done to correct the problem. If the
problem persists, contact our Customer Service Department.
The service personnel may ask the manufacturer for circuit diagrams, parts and components
list, operation manual, instructions for calibration and other documents needed for repairing
if necessary.
CAUTION
z All tests should be performed by qualified service personnel only.
z Care should be taken to change the settings in the [Maintenance] menus to avoid
loss of data.
z Service personnel should acquaint themselves with the test tools and make sure
that test tools and cables are applicable.
3-1
3.1.1 Recommended Frequency
Check/Maintenance Item Frequency
Visual test When first used or not used for a prolonged time.
Power on test 1. When first used or not used for a prolonged time.
2. Following each repair or replacement of main unit
part.
SpO2 test
PR test
Real-time data exporting test
Trend data exporting test
Electrical safety
tests
Enclosure leakage
current test
Patient leakage
current test
1. When you suspect that the measurement is inaccurate.
2. Following each repair or replacement of the SpO
2
module.
3. At least once every two years.
When you suspect that data exporting does not work
properly.
At least once every two years.
3-2
3.2 Visual Test
Inspect the equipment for obvious signs of damage. The test is passed if the equipment has no
obvious signs of damage. Follow these guidelines when inspecting the equipment:
Carefully inspect the case, the display screen and the buttons for physical damage.
Inspect all external connections for loose connectors, bent pins or frayed cables.
Inspect all connectors on the equipment for loose connectors or bent pins.
Make sure that safety labels and name plates on the equipment are clearly legible.
3.3 Power On Test
This test is to verify that the pulse oximeter powers up correctly. The test is passed if the
pulse oximeter starts up following this procedure:
In the case that the alkaline AA size batteries are used,
1. Install 3 alkaline AA batteries in the pulse oximeter and press the Power button;
2. The alarm indicating lamp flashes, and then goes out; the system gives a beep and
displays the startup screen;
3. The startup screen disappears and the pulse oximeter enters the main screen.By now, the
pulse oximeter starts up properly.
In the case that a lithium-ion battery,
1. Remove the battery adjusting bracket and install the lithium-ion battery in the pulse
oximeter;
2. Press the Power button. The alarm indicating lamp flashes, and then goes out; the
system gives a beep and displays the startup screen;
3. The startup screen disappears and the pulse oximeter enters the main screen. By now,
the pulse oximeter starts up properly.
4. Connect the pulse oximeter to the charger stand and then connect the AC mains. If the
battery is full, the Power indicating lamp will light green. Otherwise, the battery will be
charged automatically and the Power indicating lamp will light yellow. When the battery
is fully charged, the Power indicating lamp turns to be green.
3-3
3.4 Performance Tests
3.4.1 SpO2 Test
Required tool: SpO
simulator
2
1. Connect the pulse oximeter with the SpO
2. Connect the SpO
sensor with the SpO2 simulator.
2
3. Select the model and manufacturer of the SpO
sensor.
2
module under test; set SpO2 to 96% and
2
PR to 80 bmp.
4. The SpO
and PR readings should be within the ranges listed below.
2
SpO2 (%) PR (bmp)
96%±2% 80±3
3.4.2 SpO2 Test in Motion Mode
Required tool: SpO
1. Connect the pulse oximeter with the SpO
2. Connect the SpO
3. Select the model and manufacturer of the SpO
the motion mode preset by the SpO
simulator.
2
sensor with the SpO2 simulator.
2
simulator.
2
sensor.
2
module under test; take measurement in
2
4. The SpO
and PR readings should be within the ranges listed below.
2
SpO2 (%) PR (bmp)
±3% ±5
NOTE
z The SpO
properly. It cannot be used to verify the accuracy of the pulse oximeter or the SpO
sensor. To verify the accuracy, clinical tests are required.
simulator can only be used to verify that the pulse oximeter operates
2
3-4
2
3.5 Electrical Safety Tests
WARNING
z Electrical safety tests are a proven means of verifying the electrical safety of the
equipment. They are intended for determining potential electrical hazards. Fai l ure
to find out these hazards timely may cause personnel injury.
z Commercially available test equipment such as safety analyzer, etc. can be used for
electrical safety tests. Be sure that the test equipment can be safely and reliably
used with the pulse oximeter before use. The service personnel should acquaint
themselves with the use of the test equipment.
z Electrical safety tests should meet the requirements of the latest edition of
standards EN 60601-1 and UL60601.
z These electrical safety tests do not supersede local requirements.
z All devices using the AC mains and connected to medical equipment within patient
environments must meet the requirements of the IEC 60601-1 and should be put
under electrical safety tests at the frequency recommended for the pulse oximeter.
Electrical safety tests are intended to check if there are potential electrical hazards to the
patient, operator or service personnel of the equipment. Electrical safety test should be
performed under normal ambient conditions of temperature, humidity and pressure.
The electrical safety test plan described hereafter takes 601 safety analyzer as an example.
Different safety analyzers may be used in different areas. Be sure to choose applicable test
plan.
Connection of the equipment is shown below:
3-5
A: AC mains (programmable and frequency adjustable)
B: Isolation transformer on the leakage current testing apparatus
C: Safety analyzer
D: Unit under test
Tools required:
Safety analyzer
Isolation transformer
3.5.1 Enclosure Leakage Current Test
1. Connect the 601 safety analyzer to an AC power supply (264 V, 60 Hz).
2. Connect the SpO
sensor to the RA terminal of the 601 safety analyzer.
2
3. Connect the pulse oximeter’s charger stand to the auxiliary power outlet of the 601
safety analyzer using a power cord.
4. Attach one end of the red lead to the “Red input terminal” of the analyzer, and the other
end to the tinsel over the enclosure of the EUT.
5. Power on the 601 safety analyzer and then press the “5-Enclosure leakage” button on the
analyzer’s panel to enter the enclosure leakage test screen.
6. Under normal condition, the enclosure leakage current should be no greater than 100 µA.
Under single fault condition, it should be no greater than 300 µA.
3.5.2 Patient Leakage Current Test
1. Connect the 601 safety analyzer to an AC power supply (264 V, 60 Hz).
2. Connect the SpO
3. Connect the pulse oximeter under test to the auxiliary power outlet of the 601 safety
analyzer using a power cord.
sensor to the RA terminal of the 601 safety analyzer.
2
4. Power on the 601 safety analyzer and then press the “6-Patient leakage” button on the
analyzer’s panel to enter the Patient leakage test screen.
5. Repeatedly press the “Applied Part” button to measure AC and DC leakage alternatively.
DC leakage reading is following by “DC”.
6. Under normal status, the patient leakage current should be no greater than 10 µA. Under
single fault condition, it should be no greater than 50 µA.
3-6
3.6 Output Interface Test
3.6.1 RS232 Port test
1. Use a PC communication cable to connect the multifunctional connector of the pulse
oximeter under test with the RS232 port of a personal computer.
2. Select [Menu]→[Trend] to enter the trend window.
3. Press the Left button to enter the [Trend Setup] menu.
4. Set [Export Port] to [Wire].
5. Select [Export Trend] to enter the trend window; verify that trend data is exported
correctly.
3.6.2 Infrared Output Test
1. Connect a personal computer with the infrared adapter and align the infrared adapter
with the pulse oximeter’s infrared port.
2. Select [Menu]→[System] to enter the system menu.
3. Select [RT Export] and press the Left button to enable the infrared port.
4. Run the software on the personal computer to verify that real-time data is exported
correctly.
NOTE
z A communication protocol is developed and the interface is opened for infrared
transmission. A third party software is required to test this item.
3-7
3.7 Program Upgrade
You can upgrade the pulse oximeter software by downloading the upgrade software through a
serial port. The upgrade software can run directly on a personal computer. You can upgrade
the following programs by connecting the pulse oximeter with the personal computer through
a PC communication cable:
Bootstrap program
System program
Multilingual library
BMP resource files (including screen icons, startup screen and standby screen)
General configurations (including password and company name)
System function configurations
SpO
For details, refer to help and instructions for program upgrade.
module program
2
Caution
z Disconnect the pulse oximeter from the patient and make sure the important data
are saved before upgrade.
z Do not shut down or power off the equipment when upgrading the bootstrap
program. It may cause the equipment to break down.
z Program upgrade should be performed by qualified service personnel only.
NOTE
z After upgrading the bootstrap program, re-upgrade the system program and other
programs to ensure compatibility.
z Make sure the version of the upgrade package is what you desire. If you want t o
obtain the latest upgrade package, contact our Customer Service Department.
3-8
4 Troubleshooting
4.1 Introduction
In this chapter, problems are listed along with possible causes and recommended corrective
actions. Refer to the tables to check the pulse oximeter, identify and eliminate the troubles.
The troubles we list here are frequently arisen difficulties and the actions we recommend can
correct most problems, but not all of them. For more information on troubleshooting, contact
our Customer Service Department.
4.2 Part Replacement
Printed circuit board (PCB) assemblies, major parts and components of the pulse oximeter
are replaceable. Once you isolate a suspected PCB, follow the instructions in 5 Repair and
Disassembly to replace the PCB with a known good one. Check that the trouble symptom
disappears or the pulse oximeter passes all performance tests. Defective PCB assembly can
be sent to us for repair. If the trouble symptom persists, swap the replacement PCB and the
suspected malfunctioning PCB (the original PCB that was installed when you start
troubleshooting) and continue troubleshooting as directed in this chapter.
To obtain information on replacement parts or order them, refer to parts by the part names
and part number listed in 6 Parts.
4-1
4.3 Software Version Check
Some troubleshooting tasks may require you to identify the configuration and software
version of your pulse oximeter for software compatibility. For detailed information on
version compatibility, contact our Customer Service Department.
To check the version information,
1. Select [Menu]→[System]→[Maintenance >>]→enter required password→[Version
>>]. In the [Version] menu, you can view PCBA version and copyright information.
2. Select [Menu]→[System]→[Maintenance >>]→enter required password→[Version
>>]→[Software version >>]. In the [Software version] menu, you can view system
software version and module version.
4.4 Technical Alarm Check
Before troubleshooting the pulse oximeter, check for technical alarm message. If an alarm
message is presented, eliminate the technical alarm first. For detailed information on
technical alarm message, possible cause and corrective action, refer to the pulse oximeter’s
Operation Manual.
4-2
4.5 Troubleshooting Guide
4.5.1 Power On/Off Failures
Symptom Possible Causes Corrective Actions
The pulse oximeter
fails to start.
Batteries are not
installed;
The pulse oximeter is
turned on when being
connected with the
charger stand.
Batteries discharged. Replace the alkaline batteries or charge the
Batteries make
improper electrical
contact
Power supply
protection
Main board defective Replace the main board.
4.5.2 Display Failures
Install batteries and then check if the pulse
oximeter can be powered on.
lithium-ion battery.
Check that batteries contact the pulse oximeter
properly.
Check that power supply voltage meets the
requirement.
Symptoms Possible Causes Corrective Actions
LCD displays
incorrectly
Cables defective Check that LCD cable and connector are
undamaged and properly connected.
LCD defective Replace the LCD.
Main board defective Replace the main board.
4-3
4.5.3 Alarm Problems
Symptoms Possible Causes Corrective Actions
Alarm lamp does
not light or
extinguish but
alarm sound is
issued.
No alarm sound is
issued but alarm
lamp lights up
properly
Main board defective Replace the main board.
Alarm volume is set to
zero.
Speaker failure Replace the speaker.
Main board defective Replace the main board.
Select [Menu]→[Normal Setup]; adjust [Alm
Vol].
4.5.4 Button Failure
Symptoms Possible Causes Corrective Actions
Buttons do not
work.
Main board defective Replace the main board.
4.5.5 Interface Failures
Symptoms Possible Causes Corrective Actions
Infrared port does
not work.
SpO2 measurement
fails
Battery charging
fails and Power
indicating lamp
does not light up.
Real-time export
disabled.
Infrared adapter
defective.
Main board defective. Replace the main board.
SpO2 sensor fails. Replace the SpO2 sensor.
SpO2/communication
socket fails.
Main board defective Replace the main board.
Charger stand or main
board fails
Select [Menu]→[System], set [RT Expor t] to
[Start].
Replace the infrared adapter.
Replace the SpO2/communication socket.
Replace the charger stand or main board.
4-4
4.5.6 Power Supply Failures
Symptoms Possible Causes Corrective Actions
Battery defective Replace the battery Battery cannot be
fully charged.
Main board defective Replace the main board.
Battery cannot be
charged.
Battery defective Replace the battery
Charger stand fails Replace the charger stand.
Main board defective Replace the main board.
NOTE
z When the power module has a failure, it may cause problems to other components,
e.g. the pulse oximeter suddenly breaks down during startup, which may be caused
by power supply protection of the power module. In this case, remove the power
supply protection problem as per the procedure described in the table above.
4.5.7 Software Upgrade Problems
Symptoms Possi ble Cause s Corrective Actions
Bootstrap program
upgrade fails.
Power failure or
unintended power off
during bootstrap
upgrade.
Return the main board to factory for repair if
you cannot start up the pulse oximeter.
Programs cannot be
upgraded.
Incorrect connection. Check that the PC communication cable
properly connects the pulse oximeter and the
personal computer.
Check that correct serial port on the personal
computer is selected and the port is not used
by other unit.
Wrong upgrade package
downloaded.
Upgrade package shall be .pkg files. Select
package according to programs to be
upgraded.
4-5
FOR YOUR NOTES
4-6
5 Repair and Disassembly
5.1 Tools
The following tools may be required for disassembly and repair:
Small screwdriver
Sharp-nose pliers
Tweezers
5.2 Preparations for Disassembly
Before disassembling the pulse oximeter, stop monitoring the patient, turn off the pulse
oximeter and disconnect all the accessories and peripheral devices.
CAUTION
z Before disassembling the pulse oximeter, be sure to eliminate the static charges
first. When disassembling the parts labeled with static-sensitive symbols, make
sure to wear electrostatic discharge protection such as an antistatic wristband or
gloves to avoid damaging the equipment.
z Put the cables or wires in place when reassemble the pulse oximeter to avoid short
circuit.
z When assembling the pulse oximeter, be sure to select proper screws. If an unfit
screw is tightened by force, the pulse oximeter may be damaged and the screw or
the part may fall off during use, resulting in unpredictable damage or human
injury
z Be sure to follow correct sequence to disassembly the pulse oximeter. Otherwise,
the pulse oximeter may be damaged permanently.
z Be sure to disconnect all the cables before disassembling any parts. Be sure not to
damage any cables or connectors.
z Be sure to place the removed screws and parts properly for convenient reassembly.
Protect them from dropping, contaminating or losing.
5-1
5.3 Disassembly Guide
5.3.1 Removing the Covers
1. As shown in the figure, rotate the battery door key for 90° to loose the lock pin that
secures the battery door. Open the battery door and remove the batteries.
5-2
2. Remove the adjusting bracket.
3. Unscrew 2 M2X6 crosshead screws and 3 PT2X8 tapping screws. Separate the front
panel from the rear cover with your hands.
NOTE
z Carefully separate the covers to avoid damage the wires and connectors.
5-3
5.3.2 Removing the Main Board
To remove the main board, disconnect the speaker cable and the SpO
communication.
2
5.3.3 Removing the Speaker and SpO2 Communication Cable
Socket
1. Unscrew 3 PT2X8 tapping screws and remove the speaker.
5-4
2. Thrust the end of the SpO
communication cable socket and push it out.
2
5.3.4 Removing the LCD Screen
Pry the LCD screen at the top right corner with tweezers, disconnect the flexible cable socket
and remove the LCD screen.
5-5
CAUTION
z Do not touch the LCD screen.
z Disassemble the LCD screen in an environment as dust-free as possible.
5.3.5 Remove the Screen Mount
Use sharp-nose pliers to straighten the three clips that secure the screen mount to the main
board. Remove the screen mount.
5-6
6 Parts
6.1 Introduction
This chapter contains the exploded views and parts lists of the pulse oximeter. It helps the
service personnel to identify the parts during disassembling the pulse oximeter and replacing
the parts.
The architecture of the pulse oximeter main unit is shown below:
Front panel
assembly
Main board
assembly
Main unit
Battery adjusting
bracket assembly
Rear cover
assembly
6-1
6.2 Main Unit
Exploded View
Parts List
SN P/N Description Qty
1 047-000211-00 Screen lens 1
2 115-001546-00 Front panel assembly 1
3 0852-30-77450 Main board assembly 1
4 0852-20-77409 IR lens 1
5 0852-20-77452 Rear Cover assembly 1
6 M04-002405--- Crosshead screw M2X6 2
7 M04-051060--- Tapping screw PT2X8 3
8 0852-30-77451
9 0852-20-77411-51 Battery door 1
Battery adjusting bracket assembly (for AA size
batteries)
6-2
1
6.3 Front Panel Assembly
Exploded View
Parts List
SN P/N Description Qty
1 043-000086-00 Front panel 1
2 0852-20-77417 DC-IN waterproof pad 1
3 0852-20-77404 DC-IN lens 1
4 0852-20-77414 Screen fixture 1 1
5 0852-20-77406 Waterproof frame 1
6 0852-20-77405 Button 1
7 0852-20-77403 Alarm LED cover 1
6-3
6.4 Main Board Assembly
Exploded View
Parts List
SN P/N Description Qty
1 0852-30-77551 LCD assembly kit(TRULY) 1
2 0852-20-77423 LCD mount 1
3 0852-30-77428 Main board 1
6-4
6.5 Battery Adjusting Bracket Assembly
Exploded View
Parts List
SN P/N Description Qty
1 0852-20-77422 Leaf 5 1
2 0852-20-77421 Leaf 4 1
3 0852-20-77408 Battery adjusting bracket 1
6-5
6.6 Rear Cover Assembly
Exploded View
Parts List
SN P/N Description Qty
1 0000-10-43076 Speaker 1
2 0850-20-30708 Socket fixture 2
3 M04-051060--- Tapping screw M2X8 4
4 0852-20-77425 Waterproof seal 2 2
5 M04-021000--- Flat washer 1
6 0852-2077432 Spring 1
7 0852-20-77407-51 Rear cover 1
8 0852-20-77410 Lock pin 1
9 0852-20-77420 Leaf 3 1
10 0852-20-77419 Leaf 2 1
11 0852-20-77418 Leaf 1 1
12 0850-20-30704 SpO2/Communication cable socket 1
6-6
6.7 Replacement Parts
To replace the parts, refer to 5 Repair and Disassembly and the exploded views in this
chapter.
NOTE
z In the list below, we list most of the replacement parts. Contact our Customer
Service Department for more replacement parts.
P/N Description Qty
0852-20-77409 IR lens 1
0852-20-77411-51 Battery door 1
0852-20-77427 Battery door key 1
115-001546-00 Front Panel assembly 1
0852-20-77405 Button 1
0852-30-77431
801-0852-00005-00
801-0852-00004-00 Main board 1
0852-20-77415 Screen fixture 2 1
0852-30-77452 Rear cover assembly 1
0852-30-77451 Battery adjusting bracket assembly 1
0850-20-30704 SpO2/Communication cable socket 1
0852-20-77407-51 Rear cover 1
0852-20-77410 Lock pin 1
047-000211-00 Screen lens 1
M05-010003-08 Lithium-ion battery 1
0000-10-43076 Speaker 1
0850-20-30708 Socket fixture 2
LCD assembly kit (CTL)
LCD assembly kit (TRULY)
1
1
6-7
P/N: 046-000177-00 (2.0)
Loading...
