Mindray DIAP User manual

Service Manual

DIAP
Communications Protocol

This publication contains data proprietary to Mindray DS USA, Inc. It is provided solely for use by qualified personnel to interface external
devices with certain Mindray devices. Mindray DS USA, Inc. assumes no responsibility for any adverse interaction resulting from the use of this
protocol, or for any regulatory issues that may be raised by connecting devices. The details of this protocol are subject to change at any time,
without prior notice.

© Mindray DS USA, Inc., 2008. All rights reserved. Contents of this publication may not be reproduced in any form without permission of
Mindray DS USA, Inc.

ii 0070-10-0307 DIAP Communication Protocol Service Manual

Table of Contents

Table of Contents

1

1

1

DIAP....................................................................................................................................... 1

1.1 Introduction..................................................................................................................... 1

1.2 DIAP............................................................................................................................... 1

1.2.1 Connection Type..................................................................................................... 1

1.2.2 Physical Protocol .................................................................................................... 1

1.2.3 Session Protocol......................................................................................................1

1.2.4 Command/Reply Legend........................................................................................ 2

1.3 Commands and Replies................................................................................................... 6

1.4 Error Handling.............................................................................................................. 19

1.4.1 Field Level Errors................................................................................................. 19

1.4.2 Command Level Errors......................................................................................... 19

A

A

A

Appendix A.........................................................................................................................A-1

A.1 CRC Algorithm...........................................................................................................A-1

A.2 CRC Test Program......................................................................................................A-3

B

B

B

Appendix B......................................................................................................................... B-1

B.1 DIAP Modem Support (Optional) .............................................................................. B-1

B.1.1 Overview............................................................................................................. B-1

B.1.2 Physical Implementation..................................................................................... B-1

B.1.3 DIAP Slave Requirements.................................................................................. B-1

B.1.4 DIAP Slave Supported Modems......................................................................... B-1

B.1.5 DIAP Slave Modem Initialization Strings.......................................................... B-1

B.1.6 DIAP Master Requirements................................................................................ B-2

B.1.7 DIAP Master Supported Modems....................................................................... B-2

DIAP Communication Protocol Service Manual 0070-10-0307 iii

Table of Contents

This page intentionally left blank

iv 070-10-0307 DIAP Communication Protocol Service Manual

DIAP

1

1

1

DIAP

1.1 Introduction

This document defines the DIAP for new patient monitor external data communication design.

1.2 DIAP

The DIAP was designed to be simple, yet extensible for new features without compromising programs
written by third parties.

1.2.1 Connection Type

The DIAP is a point-to-point, hierarchical (one or more into one host) protocol. All communications are
initiated by the host. No common access media types, including serial multi-point connections, are
supported.

It is a request/reply, non-continuous protocol. Only numeric data (no waveforms) are supported.

1.2.2 Physical Protocol

The physical interface for the DIAP is asynchronous serial, with a baud rate of 9600 and 19200, 8 bits, 1
stop bit, no parity.

1.2.3 Session Protocol

The messages must be/are encapsulated as follows:

First Character Last Character

Command

HEADER <

DIAP Communication Protocol Service Manual 0070-10-0307 1-1

Reply

% Error

> CRC LF

DIAP

 All Commands are case-insensitive ASCII.

 All Replies are mixed case as indicated in next section.

 Timeout: No reply for 10 seconds.

 Maximum message size for Commands is 255 total bytes.

 Maximum message size for Replies is 511 bytes.

Where:

Item Description Type Length

HEADER DIAPxxx

where: xxx is a channel number from 000 to 999

- it is always 000 for a patient monitor

- it is always 001 to 999 for a central monitor

< , > are delimiter characters literal ASCII string 1, 1

literal ASCII character
+ ASCII decimal numeric

4+3

CRC is a cyclical redundancy check as described in the

section beginning on page 2-1.

LF is an ASCII line feed character. literal ASCII character 1

1.2.4 Command/Reply Legend

This is the legend to the Command/Reply list. It indicates how the arguments for the Commands and
Replies are defined. See “Commands and Replies”(section 1.3).

 Items designated as ‘ASCII decimal numeric’ are padded with leading (left) zeros.

 Items designated as ‘ASCII hex numeric’ are padded with leading (left) zeros.

 Items designated as ‘literal ASCII string’ are padded with trailing (right) spaces.

 Items designated as ‘ASCII string’ are padded with trailing (right) spaces.

 Items designated as ‘ASCII string’ will be truncated by the monitor/central as necessary.

 Items designated as ‘ASCII string’ may contain A-Z, a-z, 0-9, comma, period, dash, space, question

mark.

Item Description Type Length Units

XXX generic ASCII number ASCII decimal numeric 3 -

ASCII hex numeric 4

S numeric sign ASCII ‘+’ or ‘-’ 1 -

productName Accutorr | Passport | Passport ST |

VISA | Passport 2 | Spectrum |
Spectrum OR |Trio| Passport V |
Valiant* | VSeries

* Valiant = Accutorr V

mVersion monitor software version ASCII string 3 -

1-2 070-10-0307 DIAP Communication Protocol Service Manual

literal ASCII string 32 -

DIAP

mRevision monitor software revision ASCII decimal numeric 3 -

pVersion protocol format version=000 ASCII decimal numeric 3 -

pRevision protocol software revision**

** Valiant and
Passport V = 000
VSeries = 000

patRoom1 patient room, line 1 ASCII string 4 -

patRoom2 patient room, line 2 ASCII string 4 -

patName1 patient name, line 1 ASCII string 32 -

patName2 patient name, line 2 ASCII string 32 -

unit Name unit name ASCII string 32 -

co2ins co2 inspired value ASCII decimal numeric 3 torr

co2et co2 end-tidal value ASCII decimal numeric 3 torr

o2ins o2 inspired value (10x) ASCII decimal numeric 4 %

o2et o2 end-tidal value (10x) ASCII decimal numeric 4 %

agtins agent inspired value (100x) ASCII decimal numeric 5 %

ASCII decimal numeric 3 -

agtet agent end-tidal value (100x) ASCII decimal numeric 5 %

n2oins n2o inspired value (10x) ASCII decimal numeric 4 %

n2oet n2o end-tidal value (10x) ASCII decimal numeric 4 %

sys systolic value ASCII decimal numeric 3 + 1

dia diastolic value ASCII decimal numeric 3 + 1

map map value ASCII decimal numeric 3 + 1

status status bits ASCII hex numeric 4 -

heartRate
Source

Respiration
Source

beatType NONE literal ASCII string 16 -

NONE | ECG | SpO2 | NIBP | P1 | P2
| P3 | P4

NONE | ECG | CO2 | PAW | TV literal ASCII string 16 -

literal ASCII string 16 -

sign

sign

sign

mmHg

mmHg

mmHg

DIAP Communication Protocol Service Manual 0070-10-0307 1-3

DIAP

rhythm NONE literal ASCII string 16 -

temp temperature (10x)

(100 X for Accutorr Plus)

sec seconds ASCII decimal numeric 2 -

min minutes ASCII decimal numeric 2 -

hour hours ASCII decimal numeric 2 -

day day of month ASCII decimal numeric 2 -

month month of year ASCII decimal numeric 2 -

year year ASCII decimal numeric 4 -

weekday Mon | Tue | Wed | Thu | Fri | Sat |

Sun

timeInSecs elapsed time (since midnight, 01-

Jan-1990)

Lo low alarm value or “OFF” ASCII decimal numeric or

ASCII decimal numeric 4 + 1

literal ASCII string 3 -

ASCII decimal numeric 10 -

literal ASCII string

sign

3 + 1
sign or 1
space

°C

-

Hi high alarm value or “OFF” ASCII decimal numeric or

pawpValue pulmonary artery wedge pressure ASCII decimal numeric 3 + 1

coValue cardiac output value (100x) ASCII decimal numeric 4 liters/min

ciValue cardiac index value (10x) ASCII decimal numeric 3 liters/min/m

agentName ISO | ENF | HAL | DES | SEV literal ASCII string 3 -

stValue ECG s-t value (10x) ASCII decimal numeric 2 + 1

timeInMins time in minutes ASCII decimal numeric 3 minutes

apneaAlarm alarm delay for Apnea or “OFF” ASCII decimal numeric or

histString1 Item#,Date,Time,Call

(001,XX/XX/XX,24:00,Text)

literal ASCII string

literal ASCII string

ASCII String 4+9+6+13 -

3 + 1
sign or 1
space

sign

sign

3 seconds

-

mmHg

2

mm

1-4 070-10-0307 DIAP Communication Protocol Service Manual

DIAP

histString100 Item#,Date,time,Call

(100,XX/XX/XX,24:00,Text)

height Height in centimeters (10x) ASCII decimal numeric 4 cm

weight Weight in kilograms (100x) ASCII decimal numeric 5 kg

bsa Body Surface Area using Dubois

Algorithm BSA = height(cm)0.725 x
weight(kg)0.425 x 0.007184 (1000x)

cpp Cerebral Perfusion Pressure

calculated as the difference between
the Art Mean and the ICP Mean
pressure

mode Monitor mode of “Standby”, “Demo”

or “Normal” is returned

vtValue insp/exp Tidal Volume ASCII decimal numeric 4 ml

mvValue insp/exp Minute Volume (10x) ASCII decimal numeric 3 ml

ASCII String 4+9+6+13 -

ASCII decimal numeric 5 Dubois

ASCII decimal numeric 3 + 1

sign

ASCII string 8 -

Algorithm

mmHg

ieRatio Ratio of insp time to exp time ASCII string 5 -

pValue Spirometry pressure ASCII decimal numeric 3 + 1

complValue Dynamic Airway compliance value ASCII decimal numeric 3 ml/ cmH2O

macValue Minimum Alveolar Concentration

(10x)

vtLo low alarm value or "OFF" of Tidal

Volume

vtHi low alarm value or "OFF" of Tidal

Volume

mvLo low alarm value or "OFF" of Flow

Minute Volume (10x)

mvHi high alarm value or "OFF" of Flow

Minute Volume (10x)

spSensorSize Spirometry Sensor Size Adult | Ped |

-----

ASCII decimal numeric 2 -

ASCII decimal numeric or
literal ACSII string

ASCII decimal numeric or
literal ACSII string

ASCII decimal numeric or
literal ACSII string

ASCII decimal numeric or
literal ACSII string

Literal ACSII string 5 -

sign or 1
space

4 ml

4 ml

3 + 1
sign or 1
space

3 + 1
sign or 1
space

cmH2O

ml

ml

rawValue Dynamic Airway Resistance ASCII decimal numeric 2 cmH2O/l/s

DIAP Communication Protocol Service Manual 0070-10-0307 1-5

DIAP

bissef BIS Spectral Edge Frequency (10x) ASCII decimal numeric 3 Hz

sbis Standard Deviation of BIS (10x) ASCII decimal numeric 3 N/A

semg Standard Deviation of EMG (10x) ASCII decimal numeric 3 dB

svi Stroke Volume Index (10x) ASCII decimal numeric 4 ml/m2

edvi End Diastolic Volume Index (10x) ASCII decimal numeric 4 ml/m2

esvi End Systolic Volume Index (10x) ASCII decimal numeric 4 ml/m2

o2eii Oxygen Extraction Index (10x) ASCII decimal numeric 3 %

1.3 Commands and Replies

The following is a list of alternating Commands and Replies. They are encapsulated in the format
above. There are no space characters within the Commands or Replies - they are indicated in the

table for clarity only.

 Multiple Commands may be sent in one message; they must be separated by semi-colons (‘;’); the

Replies will be returned in a single message separated by semi-colons. Having replies returned as

a single message insures that the information in the replies are all synchronized with respect to one
another (atomic transaction).

Example:

Command:

DIAPØØØ<t1;t2;deltaT>

Reply:

DIAPØØØ<t1=42;t2=39;deltaT=3>

The value for deltaT will reflect what the values were for t1 and t2 at the time the message was
received.

Command:

DIAPØØØ<t1>

Reply:

DIAPØØØ<t1=42>

Command:

DIAPØØØ<t2>

Reply:

DIAPØØØ<t2=39>

Command:

DIAPØØØ<deltaT> (meanwhile, t1 changed from 42 to 40)

Reply:

DIAPØØØ<deltaT=1>

1-6 070-10-0307 DIAP Communication Protocol Service Manual

DIAP

The value of deltaT reflects the most current temperature values and not necessarily those from
previous commands.

 If a particular imbedded Command is invalid, the particular Reply will be “UNSUPPORTED

FEATURE”.

Example

Command:

DIAPØØØ<ecgHR;p3>

Reply:

DIAPØØØ<ecgHR=Ø81;p3=UNSUPPORTED FEATURE>

 Command keywords ending with a colon (:) will control the DIAP slave.

Example

Command:

DIAPØØ1<patient:A1Ø ,ICU3,John Doe ,>

Reply:

DIAPØØ1<patient=A1Ø ,ICU3,John Doe ,>

-Indicating that the controlling Command has been accepted by the DIAP Slave.

NOTE: There are 24 trailing spaces after the name “John Doe”, for a

total of 32 characters.

 The commands that are supported by a product are indicated by a checkmark () in the product’s

column(s). All other commands will receive the UNSUPPORTED FEATURE reply.

 Protocol changes that affect Command or Reply or Message formats will cause pVersion to be

changed; changes that affect whether a feature is supported on a given product will cause

pRevision to change for that product.

DIAP Communication Protocol Service Manual 0070-10-0307 1-7

DIAP

This page intentionally left blank.

1-8 070-10-0307 DIAP Communication Protocol Service Manual

DIAP

Passport

Type Command Reply

Alarm alarmHR alarmHR=lo, hi √ √ √ √ √ √ √ √ √ √ √ √

Alarm alarmSpo2 alarmSpo2=lo, hi √ √ √ √ √ √ √ √ √ √ √

Rev. 009

VISA/

Ambulatory

VISA/

Passport

Accutorr

Plus REV. G Passport 2 Spectrum Spectrum OR Trio

Passport V

Ver 1.03

Passport V

Ver 1.04 Accutorr V

VSeries Notes

Alarm alarmP1Sys alarmP1Sys=lo, hi √ √ √ √ √ √ √ √

Alarm alarmP1Dia alarmP1Dia=lo, hi √ √ √ √ √ √ √ √ √

Alarm alarmP1Map alarmP1Map=lo, hi √ √ √ √ √ √ √

Alarm alarmP2Sys alarmP2Sys=lo, hi √ √ √ √ √ √ √

Alarm alarmP2Dia alarmP2Dia=lo, hi √ √ √ √ √ √ √

Alarm alarmP2Map alarmP2Map=lo, hi √ √ √ √ √ √ √ √

Alarm alarmP3Sys alarmP3Sys=lo, hi √ √ √

Alarm alarmP3Dia alarmP3Dia=lo, hi √ √ √

Alarm alarmP3Map alarmP3Map=lo, hi √ √ √

Alarm alarmP4Sys alarmP4Sys=lo, hi √ √ √

Alarm alarmP4Dia alarmP4Dia=lo, hi √ √ √

Alarm alarmP4Map alarmP4Map=lo, hi √ √ √

Alarm alarmP5Sys alarmP5Sys=lo, hi

Alarm alarmP5Dia alarmP5Dia=lo, hi

Alarm alarmP5Map alarmP5Map=lo, hi

Alarm alarmP6Sys alarmP6Sys=lo, hi

√

√

√

√

√

Alarm alarmP6Dia alarmP6Dia=lo, hi

Alarm alarmP6Map alarmP6Map=lo, hi

Alarm alarmP7Sys alarmP7Sys=lo, hi

Alarm alarmP7Dia alarmP7Dia=lo, hi

Alarm alarmP7Map alarmP7Map=lo, hi

Alarm alarmP8Sys alarmP8Sys=lo, hi

Alarm alarmP8Dia alarmP8Dia=lo, hi

Alarm alarmP8Map alarmP8Map=lo, hi

Alarm alarmICPxSys alarmICPxSys=lo, hi

Alarm alarmICPxDia alarmICPxDia=lo, hi

Alarm alarmICPxMap alarmICPxMap=lo, hi

Alarm alarmNibpSys alarmNibpSys=lo, hi √ √ √ √ √ √ √ √ √ √ √

Alarm alarmNibpDia alarmNibpDia=lo, hi √ √ √ √ √ √ √ √ √ √ √

DIAP Communication Protocol Service Manual 0070-10-0307 1-9

√

√

√

√

√

√

√

√

DIAP

Passport

Type Command Reply

Alarm alarmNibpMap alarmNibpMap=lo, hi √ √ √ √ √ √ √ √ √

Alarm alarmT1 alarmT1=lo, hi √ √ √ √ √ √ √

Alarm alarmT2 alarmT2=lo, hi √ √ √ √

Rev. 009

VISA/

Ambulatory

VISA/

Passport

Accutorr

Plus REV. G

Passport 2 Spectrum Spectrum OR Trio

Passport V

Ver 1.03

Passport V

Ver 1.04

Accutorr V

VSeries Notes

Alarm alarmT3 alarmT3=lo, hi

Alarm alarmICT alarmICT=lo, hi

Alarm alarmDeltaT alarmDeltaT=lo, hi √ √ √

Alarm alarmResp alarmResp=lo, hi √ √ √ √ √ √ √ √ √

Alarm alarmCo2 alarmCo2=lo, hi √ √ √

Alarm alarmCo2Et alarmCo2Et=lo, hi √3 √3 √3 √ √4 √

Alarm alarmCo2Ins alarmCo2Ins=lo, hi √3 √3 √3 √ √4 √

Alarm alarm02 alarm02=lo, hi √

Alarm alarm02Et alarm02Et=lo, hi √ √ √ √ √ √

Alarm alarm02Ins alarm02Ins=lo, hi √ √ √ √ √ √

Alarm alarmAgent alarmAgent=lo, hi √

Alarm alarmHalIIns alarmHalIns=lo, hi √ √ √ √ √4 √

Alarm alarmHalEt alarmHalEt=lo, hi √ √ √ √ √4 √

Alarm alarmIsoIns alarmIsoIns=lo, hi √ √ √ √ √4 √

Alarm alarmIsoEt alarmIsoEt=lo, hi √ √ √ √ √4 √

√

Alarm alarmEnflIns alarmEnflIns=lo, hi √ √ √ √ √4 √

Alarm alarmEnflEt alarmEnflEt=lo, hi √ √ √ √ √4 √

Alarm alarmSevoIns alarmSevoIns=lo, hi √ √ √ √ √4 √

Alarm alarmSevoEt alarmSevoEt=lo, hi √ √ √ √ √4 √

Alarm alarmDesIns alarmDesIns=lo, hi √ √ √ √ √4 √

Alarm alarmDesEt alarmDesEt=lo, hi √ √ √ √ √4 √

Alarm alarmN2o alarmN2o=lo, hi √ √ √ √ √ √

Alarm alarmApnea alarmApnea=apneaAlarm √ √ √ √ √ √ √ √ √

Alarm alarmTblood alarmTblood=lo, hi √ √ √

Alarm Baud Rate 9600 √ √ √ √ √ √ √ √ √ √

Alarm Baud Rate 19200 √ √ √ √ √

Alarm alarmvtinsp alarmvtinsp=vtLo,vtHi √

Alarm alarmvtexp alarmvtexp=vtLo,vtHi √

1-10 0070-10-0307 DIAP Communication Protocol Service Manual

DIAP

Passport

Type Command Reply

Alarm alarmmvinsp alarmmvinsp=mvLo,mvHi √

Alarm alarmmvexp alarmmvexp=mvLo,mvHi √

Alarm alarmpplat alarmpplat=lo,hi √

Alarm alarmpeep alarmpeep=lo,hi √

Alarm alarmpip alarmpip=lo,hi √

Alarm alarmpmean alarmpmean=lo,hi √

Alarm alarmbis alarmbis=lo,hi √ √

Alarm alarmartsys alarmartsys=lo,hi √ √ √ √

Alarm alarmartdia alarmartdia=lo,hi √ √ √ √

Alarm alarmartmap alarmartmap=lo,hi √ √ √ √

Alarm alarmpasys alarmpasys=lo,hi √ √ √ √

Rev. 009

VISA/

Ambulatory

VISA/

Passport

Accutorr

Plus REV. G

Passport 2 Spectrum Spectrum OR Trio

Passport V

Ver 1.03

Passport V

Ver 1.04

Accutorr V

VSeries Notes

Alarm alarmpadia alarmpadia=lo,hi √ √ √ √

Alarm alarmpamap alarmpamap=lo,hi √ √ √ √

Alarm alarmcvpsys alarmcvpsys=lo,hi √ √ √ √

Alarm alarmcvpdia alarmcvpdia=lo,hi √ √ √ √

Alarm alarmcvpmap alarmcvpmap=lo,hi √ √ √ √

Alarm alarmuasys alarmuasys=lo,hi √ √ √ √

Alarm alarmuadia alarmuadia=lo,hi √ √ √ √

Alarm alarmuamap alarmuamap=lo,hi √ √ √ √

Alarm alarmlvsys alarmlvsys=lo,hi √ √ √ √

Alarm alarmlvdia alarmlvdia=lo,hi √ √ √ √

Alarm alarmlvmap alarmlvmap=lo,hi √ √ √ √

Alarm alarmlasys alarmlasys=lo,hi √ √ √ √

Alarm alarmladia alarmladia=lo,hi √ √ √ √

Alarm alarmlamap alarmlamap=lo,hi √ √ √ √

Alarm alarmrasys alarmrasys=lo,hi √ √ √ √

Alarm alarmradia alarmradia=lo,hi √ √ √ √

Alarm alarmramap alarmramap=lo,hi √ √ √ √

Alarm alarmicpsys alarmicpsys=lo,hi √ √ √ √

Alarm alarmicpdia alarmicpdia=lo,hi √ √ √ √

Alarm alarmicpmap alarmicpmap=lo,hi √ √ √ √

DIAP Communication Protocol Service Manual 0070-10-0307 1-11

DIAP

Passport

Type Command Reply

Alarm alarmicpxsys alarmicpxsys=lo,hi

Rev. 009

VISA/

Ambulatory

VISA/

Passport

Accutorr

Plus REV. G

Passport 2 Spectrum Spectrum OR Trio

Passport V

Ver 1.03

Passport V

Ver 1.04

Accutorr V

VSeries Notes

Alarm alarmicpxdia alarmicpxdia=lo,hi

Alarm alarmicpxmap alarmicpxmap=lo,hi

Alarm alarmsvo2 alarmsvo2=lo,hi

Alarm alarmcco alarmcco=lo,hi

Alarm alarmcci alarmcci=lo,hi

Alarm alarmrso2c1 alarmrso2c1=lo,hi

Alarm alarmrso2c2 alarmrso2c2=lo,hi

Alarm alarmrso2c3 alarmrso2c3=lo,hi

Alarm alarmrso2c4 alarmrso2c4=lo,hi

Control patient:patRoom1,

patRoom2,
part Name1,
partName2

Control unit:unitName unit=unitName √ √

Informational htcm htcm=XXXX √ √ √ √ √

Informational wtkg wtkg=XXXXX √ √ √

Informational bsa bsa=XXXXX Dubois √ √ √

patient=patRoom1,patRoom2,
part Name1,partName2

√

√ Not Supported available only

√

√

√

√

√

√

√

when patient is

discharged

Informational connect connect=productName,

pVersion,pRevision

Informational disconnect disconnect= √ √ √ √ √ √ √ √ √ √ √ √

Informational product product=productName,

mVersion,mRevision

Informational patient patient=patRoom1,patRoom2,

patName1,patName2

Informational unit unit=unitName √ √

Informational Mode Mode Currently not

Informational spsensorsize spsensorsize=spSenorSize √

Physiological ecgResp ecgResp=XXX √ √

Physiological ecgSt1 ecgSt1=stValue √1 √1 √1 √ √

Physiological ecgSt2 ecgSt2=stValue √1 √1 √1 √ √

Physiological ecgST3 ecgST3=stValue √1 √1 √1 √ √

Physiological ecgHR ecgHR=XXX √ √

√ √ √ √ √ √ √ √ √ √ √ √

√ √

√ √ √ √ √ √ √ √ √ √ √

implemented

1-12 0070-10-0307 DIAP Communication Protocol Service Manual

DIAP

Passport

Type Command Reply

Physiological ecgBeatType ecgBeatType=beatTime √

Physiological ecgRhythm ecgRhythm=rhythm √

Rev. 009

VISA/

Ambulatory

VISA/

Passport

Accutorr

Plus REV. G

Passport 2 Spectrum Spectrum OR Trio

Passport V

Ver 1.03

Passport V

Ver 1.04

Accutorr V

VSeries Notes

Physiological co co=coValue,ciValue,

timeInSeconds

Physiological p1 p1=sys,dia,map √ √ √ √ √ √ √ √ √

Physiological p1HR p1HR=XXX √

Physiological p2 p2=sys,dia,map √ √ √ √ √ √ √ √

Physiological p2HR p2HR=XXX

Physiological p3 p3=sys,dia,map √ √ √

Physiological p3HR p3HR=XXX √

Physiological p4 p4=sys,dia,map √ √ √

Physiological p4HR p4HR=XXX √

Physiological p5 p5=sys,dia,map

Physiological p5HR p5HR=XXX √

Physiological p6 p6=sys,dia,map

Physiological p6HR p6HR=XXX √

Physiological p7 p7=sys,dia,map

Physiological p7HR p7HR=XXX √

√ √ √

√

√

√

√

Physiological p8 p8=sys,dia,map

Physiological p8HR p8HR=XXX √

Physiological icpx icpx=sys,dia,map

Physiological icpxHR icpxHR=XXX

Physiological historyLine historyLine=histStringX √ √ most current

Physiological historyFile historyFile=histString1,

histString2, ...histString100

Physiological pawp Pawp=pawpValue,

timeInSeconds

Physiological t1 t1=temp √ √ √ √ √ √ √ √ √ √ √

Physiological t2 t2=temp √ √ √ √

Physiological t3 t3=temp

Physiological ict ict=temp

Physiological deltaT2 deltaT=temp √ √ √

DIAP Communication Protocol Service Manual 0070-10-0307 1-13

√ √ All available

√ √ √ √ √

√

line number

lines

√

DIAP

Passport

Type Command Reply

Physiological tBlood tBlood=temp √ √ √

Physiological hr hr=XXX √ √ √ √ √ √ √ √ √ √ √ √

Physiological hrSource hrSource=heartRateSource √ √ √ √ √ √ √ √ √ √ √ √

Physiological hrBeatType hrBeatType=beatType √

Physiological hrRythm hrRythm=rhythm √

Physiological nibp nibp=sys, dia, map √ √ √ √ √ √ √ √ √ √ √

Physiological nibpStatus nibpStatus=status √ √

Physiological nibpHr nibpHr=XXX √ √ √ √

Physiological nibpElapsedTime nibpElapsedTime=timeInMins √ √ √ √ √ √ √ √ √

Rev. 009

VISA/

Ambulatory

VISA/

Passport

Accutorr

Plus REV. G

Passport 2 Spectrum Spectrum OR Trio

Passport V

Ver 1.03

Passport V

Ver 1.04

Accutorr V

VSeries Notes

Physiological nibpStartTime nibpStartTime=timeInSecs

Physiological nibpStopTime nibpStopTime=timeInSecs √

Physiological resp resp=XXX √ √ √ √ √ √ √ √ √

Physiological respSource respSource=respirationSourc

e

Physiological co2 co2=co2Ins,co2Et √ √ √ √ √ √ √4 √ co2Ins="- - -"

Physiological co2Resp co2Resp=XXX √ √

Physiological spo2 spo2=XXX √ √ √ √ √ √ √ √ √ √ √

Physiological spo2HR spo2HR=XXX √ √ √ √ √ √ √ √ √

Physiological o2 o2=o2Ins, o2Et √ √ √ √ √ √ √

Physiological agent agent=agtIns, agtEt √ √ √ √ √ √ √

Physiological agentType agentType=agentName √ √ √ √ √ √ √

Physiological n2o n2o=n2oIns, n2oEt √ √ √ √ √ √ √

Physiological art art=sys,dia,map √ √ √ √

Physiological arthr arthr=XXX √ √ √ √ √

Physiological pa pa=sys,dia,map √ √ √ √

√ √ √ √ √ √ √ √ √

√

Physiological pahr pahr=XXX √ √ √ √ √

Physiological cvp cvp=sys,dia,map √ √ √ √

Physiological cvphr cvphr=XXX √ √ √ √ √

Physiological ua ua=sys,dia,map √ √ √ √

Physiological uahr uahr=XXX √ √ √ √ √

Physiological lv lv=sys,dia,map √ √ √ √

Physiological lvhr lvhr=XXX √ √ √ √ √

1-14 0070-10-0307 DIAP Communication Protocol Service Manual

DIAP

Passport

Type Command Reply

Physiological la la=sys,dia,map √ √ √ √

Physiological lahr lahr=XXX √ √ √

Physiological ra ra=sys,dia,map √ √ √ √

Physiological rahr rahr=XXX √ √ √

Physiological icp icp=sys,dia,map √ √ √ √

Physiological icphr icphr=XXX √ √ √

Physiological cpp cpp=XXX √ √ √ √

Physiological ci ci=ciValue √ √ √

Physiological vtinsp vtinsp=vtValue √

Physiological vtexp vtexp=vtValue √

Physiological mvinsp mvinsp=mvValue √

Rev. 009

VISA/

Ambulatory

VISA/

Passport

Accutorr

Plus REV. G

Passport 2 Spectrum Spectrum OR Trio

Passport V

Ver 1.03

Passport V

Ver 1.04

Accutorr V

VSeries Notes

Physiological mvexp mvexp=mvValue √

Physiological ieratio ieratio=ieRatio √

Physiological pplat pplat=pValue √

Physiological peep peep=pValue √

Physiological compl compl=complValue √

Physiological pip pip=pValue √

Physiological pmean pmean=pValue √

Physiological mac mac=macValue √ √

Physiological bis bis=XX √ √ BIS Left

Physiological sqi sqi=XX √ √ BIS Left

Physiological emg emg=XX √ √ BIS Left

Physiological bislsr bislsr=XX √

Physiological bislbc bislbc=XX √

Physiological bislsef bislsef=bissef √

Physiological bisltp bisltp=XX √

Channel

Channel

Channel

Physiological sbisl sbisl=sbis √

Physiological semgl semgl=semg √

Physiological bisr bisr=XX

Physiological sqir sqir=XX

DIAP Communication Protocol Service Manual 0070-10-0307 1-15

√

√

DIAP

Passport

Type Command Reply

Physiological emgr emgr=XX

Physiological bislsr bislsr=XX √

Physiological bisrbc bisrbc=XX √

Physiological bisrsef bisrsef=bissef √

Physiological bisrtp bisrtp=XX √

Physiological sbisr sbisr=sbis √

Physiological semgr semgr=semg √

Physiological bisasym bisasym=XX √

Physiological cco cco=coValue √

Physiological cci cci=ciValue √

Physiological svo2 svo2=XX √

Rev. 009

VISA/

Ambulatory

VISA/

Passport

Accutorr

Plus REV. G

Passport 2 Spectrum Spectrum OR Trio

√

Passport V

Ver 1.03

Passport V

Ver 1.04

Accutorr V

VSeries Notes

Physiological sv sv=XXXX √

Physiological svi svi=svi √

Physiological edv edv=XXX √

Physiological edvi edvi=XXXX √

Physiological ccostat ccostat=coValue √

Physiological ccistat ccistat=ciValue √

Physiological svr svr=XXXX √

Physiological svri svrI=XXXX √

Physiological ccosnr ccosnr=XX √

Physiological svv svv=XX √

Physiological rvef rvef=XX √

Physiological rvefstat rvefstat=XX √

Physiological edvstat edvstat=XXX √

Physiological edvistat edvistat=XXXX √

Physiological esv esv=XXX √

Physiological esvi esvi=XXXX √

Physiological svstat svstat=XXXX √

Physiological svistat svistat=svi √

Physiological rso2c1 rso2c1=XX √

Physiological rso2bc1 rso2bc1=XX √

1-16 0070-10-0307 DIAP Communication Protocol Service Manual

DIAP

Passport

Type Command Reply

Physiological rso2aucc1 rso2auc1=XX √

Physiological rso2c2 rso2c2=XX √

Physiological rso2bc2 rso2bc2=XX √

Physiological rso2aucc2 rso2auc2=XX √

Physiological rso2c3 rso2c3=XX √

Physiological rso2bc3 rso2bc3=XX √

Physiological rso2aucc3 rso2auc3=XX √

Physiological rso2c4 rso2c4=XX √

Physiological rso2bc4 rso2bc4=XX √

Physiological rso2aucc4 rso2auc4=XX √

Physiological pvcpermin pvcpermin=XX √

Rev. 009

VISA/

Ambulatory

VISA/

Passport

Accutorr

Plus REV. G

Passport 2 Spectrum Spectrum OR Trio

Passport V

Ver 1.03

Passport V

Ver 1.04

Accutorr V

VSeries Notes

Physiological satseconds satseconds=XX √

Physiological perfusionindex perfusionindex=XX √

Physiological pausespermin pausespermin=XX √

Physiological app app=XX √

Physiological cepp cepp=XX √

Physiological stLeadI stLeadI=stValue √

Physiological stLeadII stLeadII= stValue √

Physiological stLeadIII stLeadIII= stValue √

Physiological stLeadAVR stLeadAVR= stValue √

Physiological stLeadAVF stLeadAVF= stValue √

Physiological stLeadAVL stLeadAVL= stValue √

Physiological stLeadV1 stLeadV1= stValue √

Physiological stLeadV2 stLeadV2= stValue √

Physiological stLeadV3 stLeadV3= stValue √

Physiological stLeadV4 stLeadV4= stValue √

Physiological stLeadV5 stLeadV5= stValue √

Physiological stLeadV6 stLeadV6= stValue √

Physiological stRefLeadI stRefLeadI= stValue √

Physiological stRefLeadII stRefLeadII= stValue √

Physiological stRefLeadIII stRefLeadIII= stValue √

DIAP Communication Protocol Service Manual 0070-10-0307 1-17

DIAP

Passport

Type Command Reply

Physiological stRefLeadAVR stRefLeadAVR= stValue √

Physiological stRefLeadAVF stRefLeadAVF= stValue √

Physiological stRefLeadAVL stRefLeadAVL= stValue √

Physiological stRefLeadV1 stRefLeadV1= stValue √

Physiological stRefLeadV2 stRefLeadV2= stValue √

Physiological stRefLeadV3 stRefLeadV3= stValue √

Physiological stRefLeadV4 stRefLeadV4= stValue √

Physiological stRefLeadV5 stRefLeadV5= stValue √

Physiological stRefLeadV6 stRefLeadV6= stValue √

Physiological do2 do2=XXXX

Physiological vo2 vo2=XX

Rev. 009

VISA/

Ambulatory

VISA/

Passport

Accutorr

Plus REV. G

Passport 2 Spectrum Spectrum OR Trio

Passport V

Ver 1.03

Passport V

Ver 1.04

Accutorr V

VSeries Notes

Physiological scvo2 scvo2=XX √

Physiological o2ei o2ei=o2ei

Physiological raw raw=rawValue √

1 In 12-Lead mode this is the absolute value otherwise this the delta value.

2 deltaT is defined as the abolute value of t1 - t2.
3 Not supported when using the Gas Module II.
4 Depends upon type of CO2 gas module installed

1-18 0070-10-0307 DIAP Communication Protocol Service Manual

DIAP

1.4 Error Handling

1.4.1 Field Level Errors

Invalid data fields in replies are represented by two, three, or more dashes (— or —-, etc.), based on
the expected value length.

1.4.2 Command Level Errors

If an error occurs, an error reply is returned to the host in place of the normal reply.

These Command Level Errors are indicated below (literal ASCII string, prefaced with a %):

Error Description

UNABLE TO CONNECT The monitor cannot respond.

NO OPEN DELIMITER The monitor could not find the character ‘<‘ (open delimiter) in the message

NO CLOSE DELIMITER The monitor could not find the character ‘>’ (close delimiter) in the message

NO LINE FEED The monitor could not find the linefeed character in the message received,

INVALID CRC CHAR The monitor detected a non-hexadecimal CRC character (syntax error).

UNDEFINED ERROR The monitor detected an undefinable syntax error.

RESPONSE TOO LARGE In a multiple command message, the response is greater than the maximum

REQUEST CORRUPT The monitor detected an invalid CRC.

CHANNEL OUT OF RANGE The central monitor could not reply because the channel number requested is

BAD MSG HEADER The message header did not contain ‘‘DIAP’’ as the first four characters

COMMAND TO LARGE The message size exceeded the maximum of 255

IBP LABEL NOT APPLIED The monitor cannot return a value because the requested IBP label has not

received, making the message not interpretable (syntax error).

received, making the message not interpretable (syntax error).

making the message not interpretable (syntax error).

size response buffer. (Separate the multiple command message into two or
more messages).

invalid.

been applied to IBP1, IBP2, IBP3 or IBP4.

IBP LABEL NOT CURRENT
HR SOURCE

The monitor cannot return a value because the request IBP label has not been
set as the current heart rate source.

DIAP Communication Protocol Service Manual 0070-10-0307 1-19

DIAP

This page intentionally left blank.

1-20 0070-10-0307 DIAP Communication Protocol Service Manual

Appendix A

A

A

A

A.1 CRC Algorithm

Appendix A

The algorithm used to create the CRC follows:

const unsigned short crcTable[256] = {

0x0000, 0x0108, 0x0210, 0x0318, 0x0420, 0x0528, 0x0630, 0x0738,

0x0840, 0x0948, 0x0A50, 0x0B58, 0x0C60, 0x0D68, 0x0E70, 0x0F78,

0x1081, 0x1189, 0x1291, 0x1399, 0x14A1, 0x15A9, 0x16B1, 0x17B9,

0x18C1, 0x19C9, 0x1AD1, 0x1BD9, 0x1CE1, 0x1DE9, 0x1EF1, 0x1FF9,

0x2102, 0x200A, 0x2312, 0x221A, 0x2522, 0x242A, 0x2732, 0x263A,

0x2942, 0x284A, 0x2B52, 0x2A5A, 0x2D62, 0x2C6A, 0x2F72, 0x2E7A,

0x3183, 0x308B, 0x3393, 0x329B, 0x35A3, 0x34AB, 0x37B3, 0x36BB,

0x39C3, 0x38CB, 0x3BD3, 0x3ADB, 0x3DE3, 0x3CEB, 0x3FF3, 0x3EFB,

0x4204, 0x430C, 0x4014, 0x411C, 0x4624, 0x472C, 0x4434, 0x453C,

0x4A44, 0x4B4C, 0x4854, 0x495C, 0x4E64, 0x4F6C, 0x4C74, 0x4D7C,

0x5285, 0x538D, 0x5095, 0x519D, 0x56A5, 0x57AD, 0x54B5, 0x55BD,

0x5AC5, 0x5BCD, 0x58D5, 0x59DD, 0x5EE5, 0x5FED, 0x5CF5, 0x5DFD,

0x6306, 0x620E, 0x6116, 0x601E, 0x6726, 0x662E, 0x6536, 0x643E,

0x6B46, 0x6A4E, 0x6956, 0x685E, 0x6F66, 0x6E6E, 0x6D76, 0x6C7E,

DIAP Communication Protocol Service Manual 0070-10-0307 A-1

Appendix A

0x7387, 0x728F, 0x7197, 0x709F, 0x77A7, 0x76AF, 0x75B7, 0x74BF,

0x7BC7, 0x7ACF, 0x79D7, 0x78DF, 0x7FE7, 0x7EEF, 0x7DF7, 0x7CFF,

0x8408, 0x8500, 0x8618, 0x8710, 0x8028, 0x8120, 0x8238, 0x8330,

0x8C48, 0x8D40, 0x8E58, 0x8F50, 0x8868, 0x8960, 0x8A78, 0x8B70,

0x9489, 0x9581, 0x9699, 0x9791, 0x90A9, 0x91A1, 0x92B9, 0x93B1,

0x9CC9, 0x9DC1, 0x9ED9, 0x9FD1, 0x98E9, 0x99E1, 0x9AF9, 0x9BF1,

0xA50A, 0xA402, 0xA71A, 0xA612, 0xA12A, 0xA022, 0xA33A, 0xA232,

0xAD4A, 0xAC42, 0xAF5A, 0xAE52, 0xA96A, 0xA862, 0xAB7A, 0xAA72,

0xB58B, 0xB483, 0xB79B, 0xB693, 0xB1AB, 0xB0A3, 0xB3BB, 0xB2B3,

0xBDCB, 0xBCC3, 0xBFDB, 0xBED3, 0xB9EB, 0xB8E3, 0xBBFB, 0xBAF3,

0xC60C, 0xC704, 0xC41C, 0xC514, 0xC22C, 0xC324, 0xC03C, 0xC134,

0xCE4C, 0xCF44, 0xCC5C, 0xCD54, 0xCA6C, 0xCB64, 0xC87C, 0xC974,

0xD68D, 0xD785, 0xD49D, 0xD595, 0xD2AD, 0xD3A5, 0xD0BD, 0xD1B5,

0xDECD, 0xDFC5, 0xDCDD, 0xDDD5, 0xDAED, 0xDBE5, 0xD8FD, 0xD9F5,

0xE70E, 0xE606, 0xE51E, 0xE416, 0xE32E, 0xE226, 0xE13E, 0xE036,

0xEF4E, 0xEE46, 0xED5E, 0xEC56, 0xEB6E, 0xEA66, 0xE97E, 0xE876,

0xF78F, 0xF687, 0xF59F, 0xF497, 0xF3AF, 0xF2A7, 0xF1BF, 0xF0B7,

0xFFCF, 0xFEC7, 0xFDDF, 0xFCD7, 0xFBEF, 0xFAE7, 0xF9FF, 0xF8F7,

};
unsigned short Crc (unsigned short lastCrc, unsigned long sizeOfBuffer,
unsigned char *buffer) {
unsigned long i;
unsigned char index;
for (i = 0L; i < sizeOfBuffer; i++) {
index = buffer[i] ^ ((unsigned char)(lastCrc & 0x00FF));
lastCrc = ((lastCrc >> 8) & 0x00FF) ^ (crcTable[index]);
}
return (lastCrc);
}

A-2 0070-10-0307 DIAP Communication Protocol Service Manual

Appendix A

A.2 CRC Test Program

The following program can be used to test the above:

#include <stdio.h>
int main(void) {
unsigned char buffer [] = {0, 0, 0, 0, 0, 0x77, 0xCF};
printf(“CRC(Expected 0x73F3) = 0x%04X\n”, Crc(0x0, 7, buffer));
return(0);
}

NOTE: For the example above, the value for the last CRC parameter

should be initalized to zero (0).

DIAP Communication Protocol Service Manual 0070-10-0307 A-3

Appendix A

This page intentionally left blank.

A-4 0070-10-0307 DIAP Communication Protocol Service Manual

Appendix B

B

B

B

B.1 DIAP Modem Support (Optional)

B.1.1 Overview

B.1.2 Physical Implementation

Appendix B

Optional support for a modem attached to a DIAP Slave is described here.

A standard external modem is connected to the DIAP Slave, such as a Passport, Point of View, VISA,
etc. The same modem type is connected to a DIAP Master, such as a personal computer, workstation,
minicomputer, etc. A public telephone switching system connects the modems.

B.1.3 DIAP Slave Requirements

The Mindray equipment must have the following additions made to implement DIAP Modem Support:

 Configuration Dialog for Modem Connected (yes/no choice, default no)

 Configuration Dialog for Modem Speaker On (yes/no choice, default no)

 User Dialog for Reset Modem (button)

Upon initialization, the DIAP Slave UART is set per section 1.2. The modem initialization string is them

sent (section Error! Reference source not found.). The modem initialization string is re-sent anytime

the Reset Modem button is depressed.

B.1.4 DIAP Slave Supported Modems

The DIAP Slave shall support the following V.32-compliant or higher modems:

 Hayes Accura 144

B.1.5 DIAP Slave Modem Initialization Strings

The DIAP Slave communicates with the modem as follows:

DIAP Communication Protocol Service Manual 0070-10-0307 B-1

Appendix B

Modem

Slave Control ASCII Strings Sent

configuration set to
Modem Connected (yes)

Modem Speaker On (no)

and/or

Reset Modem active

(>1 sec pause) +++
(>1 sec pause)

ATZ (carriage return) OK “Reset Modem”

AT&F (carriage return) OK “Recall Factory Configuration”

AT&K4 (carriage return) OK “Enable XON/XOFF Local Flow

ATM0 (carriage return) OK “Speaker Off”

ATS0 = 1 (carriage return) OK “Answer in 1 Ring”

Returns Description

(nothing) “Force Command Mode” (Hayes

standard for modem attention)

Control”

NOTE: The above assumes that the modem is new or reset to default

factory configuration.

NOTE: If the configuration Modem Speaker On = ‘yes’, then do not send

the ATM0 command above.

B.1.6 DIAP Master Requirements

The Master computer must initialize the local serial port (setting communications parameters per
section 2.2) and initialize the locally- attached modem (including modem reset, setting up off-hook and
telephone dialing to the DIAP Slave modem). It also configures the modem in a manner similar to the
DIAP Slave modem (XON/XOFF flow control).

B.1.7 DIAP Master Supported Modems

The DIAP Master shall support any V.32-complaint or higher modem.

B-2 0070-10-0307 DIAP Communication Protocol Service Manual

Appendix B

Mindray DS USA, Inc. • 800 MacArthur Boulevard • Mahwah, NJ 07430 • USA •
Dom. Customer Service: 1.800.288.2121 • Intl. Customer Service: +1.201.995.8000 •
Dom. Fax: [phone] • Intl. Fax: [phone] • www.mindray.com

Mindray Medical Netherlands B.V.• Drs. W. van Royenstraat 8 • P.O. Box 26 • 3870 CA Hoevelaken • The
Netherlands • Tel: [phone] • Fax: [phone]

Mindray (UK) Limited • 3 Percy Road • St. John’s Park • Huntingdon • Cambridgeshire PE 29 6SZ • United Kingdom •
Tel: [phone] • Fax: [phone]

Mindray Medical France SARL • Europarc Créteil •123, Chemin des Bassins •
94035 Créteil Cedex • France • Tel: [phone] • Fax: [phone]

Mindray Medical Germany GmbH • Zwischen den Bächen 4 • 64625 Bensheim • Deutschland •
Tel: [phone] • Fax: [phone]

Mindray Medical International Ltd. • 2813 Office Tower, Convention Plaza • No 1 Harbour Road • Wanchai • Hong
Kong • Tel: [phone] • Fax: [phone]

Medstar Importação e Exportação Ltda • Av. Vereador José Diniz, 3300 • São Paulo, SP • CEP 04804- 000 • Brazil •
Tel: [phone] • Fax: [phone]

DIAP Communication Protocol Service Manual 0070-10-0307 B-3

0070-10-0307 / 0070-00-0307 Rev T November 11, 2011
