Operating Instructions
Vacuum Cleaner
S 2000
To prevent accidents |
|
en, fr - US, CA |
|
||
and machine damage, |
|
|
read these instructions |
HS12 |
|
before |
|
|
installation and use. |
|
M.-Nr. 07 821 160 |
|
|
|
2
Contents
IMPORTANT SAFETY INSTRUCTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Guide to the vacuum cleaner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Before using the vacuum cleaner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Included accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Power cord. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Turning the vacuum On/Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Adjusting the suction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Turning the Powerbrush On/Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Transport and storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Maintenance and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Purchasing new dustbags and filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Which dustbags and filters are the right ones? . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 When to change the dustbag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Replacing the dustbag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 When to change the dust compartment filter (Pre-motor filter) . . . . . . . . . . . . . . . 22 Replacing the dust compartment filter (Pre-motor filter) . . . . . . . . . . . . . . . . . . . . 22 When to replace the Air Clean exhaust filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Replacing the Air Clean filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Exchanging exhaust filters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 When to change the Active HEPA exhaust filter . . . . . . . . . . . . . . . . . . . . . . . . . . 23 Replacing the Active HEPA exhaust filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 When to change the thread catcher on the standard floor brush . . . . . . . . . . . . . 24 Changing the thread catcher. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Cleaning and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Frequently asked questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Optional accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Technical Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Caring for the environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
3
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precautions should always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE
WARNING-
To reduce the risk of fire, electric shock or injury:
Before Using
Check the voltage rating of the vacuum cleaner before connecting the power cord to an electrical outlet. Your power source should correspond with the voltage rating plate located on the underside of the vacuum. Use only household AC outlets. Never use DC power sources. If you are not sure of your home’s voltage supply, consult a qualified electrician. Connecting the vacuum cleaner to a higher voltage may result in damage to the vacuum cleaner or injury.
To reduce the risk of electric shock, this appliance has a polarized plug (one blade is wider than the other.) This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician to install the proper outlet. Do not alter the plug in any way.
A damaged vacuum cleaner can be dangerous. Check the packaging, vacuum cleaner and accessories for any signs of damage. Do not use a damaged appliance.
Do not use with a damaged cord or plug. If the appliance is not working as it should, has been dropped, damaged, left outdoors or submerged in water, bring it to a service center.
The electrical outlet must be fitted with a 15 A fuse.
4
IMPORTANT SAFETY INSTRUCTIONS
Use
Do not use on people or animals.
Do not use outdoors or on wet surfaces. Only dry surfaces should be vacuumed.
Use only as described in this manual. Use only Miele recommended accessories described in this manual.
This appliance is intended strictly for household use only.
Do not allow the vacuum cleaner to be used as a toy. Close attention is necessary when used near children.
Unwind the cord completely to aid the vacuum in dissipating heat.
This vacuum should not be used to entrap or retain any hazardous materials.
Do not use the vacuum cleaner to pick up liquids or damp dirt. This could impair the electrical safety of the vacuum cleaner. Wait for freshly shampooed carpets to dry.
Do not vacuum anything that is burning or smoking such as cigarettes, matches or hot ashes. The vacuum could catch fire.
Never use the vacuum cleaner without the dustbag or filters in place. Otherwise, it could be damaged.
Do not vacuum toner dust. Toner, such as that used in printers and photocopiers can conduct electricity.
If the dustbag is not inserted , the dust compartment lid will not close. Do not force it shut.
Do not leave the vacuum plugged in. Unplug it from the outlet when not in use and before servicing.
On the underside of the vacuum hand piece is a metal insert designed to absorb static electricity. Please make certain that your hand remains around this metal insert when vacuuming.
Persons who lack physical, sensory, or mental capabilities or experience with the machine should not use it without supervision or instruction by a responsible person.
Do not use the vacuum to pick up any flammable or combustible liquids such as gasoline or use in areas where they may be present.
Do not vacuum up items which are heavy, hard or have sharp edges. They could cause a blockage and damage the appliance.
Do not pull or carry by the cord, use the cord as a handle, close a door on the cord, or pull the cord around sharp edges or corners. Do not run the appliance over the cord. Keep the cord away from heated surfaces.
Do not unplug by pulling the cord. To unplug grasp the plug, not the cord.
Do not handle the plug or vacuum with wet hands.
5
IMPORTANT SAFETY INSTRUCTIONS
Keep hair, loose clothing, fingers, and all parts of body away from openings and moving parts.
To avoid risk of injury while vacuuming, do not reach into the moving beater bar of the Powerbrush. Danger of injury.
Do not place anything into the openings of the vacuum. Do not use if any openings are blocked; keep them free of dust, lint, hair or anything that may reduce air flow.
This appliance is equipped with a power cord reel. Hold the plug when rewinding onto cord reel. Do not allow plug to whip when rewinding.
Turn off all controls before unplugging.
Use caution when vacuuming on stairs.
Floor attachments, accessories and wands must not be used at head level to avoid injuries to the eyes and ears.
Using accessories
The hose and telescopic wand contain electrical wires. Do not use the vacuum cleaner if these parts are damaged, cut or punctured. Avoid picking up sharp objects. There is the risk of electric shock.
Unplug the vacuum when changing accessories, especially when using the Powerbrush.
The socket on the vacuum cleaner is only to be used for the Miele Powerbrush.
The Miele Powerbrush is a
motor-driven accessory for use only with Miele vacuum cleaners. The vacuum must not be used with another manufacturer's Powerbrush.
Do not use the vacuum without an accessory attached. The rim could be damaged and injuries could result from sharp edges.
Miele dustbags are disposable and intended to be used only once. Do not attempt to reuse them. An over stuffed dustbag will reduce the efficiency of the vacuum cleaner.
Only use genuine Miele dustbags with the Miele quality signet and original Miele filters and accessories. Only then will the manufacturer guarantee its safety.
Always turn off this appliance before connecting or disconnecting either hose or motorized nozzle.
6
IMPORTANT SAFETY INSTRUCTIONS
Cleaning, maintenance and repairs
Turn the vacuum cleaner off after each use and before every cleaning / maintenance. Pull the plug from the outlet.
Disposing of an old appliance
Before discarding an old vacuum cleaner, please cut off the power cord, and render the plug useless. Ensure the appliance presents no danger to children while being stored for disposal
Never submerge the vacuum cleaner in water. Clean only with a dry cloth or slightly damp cloth when disconnected from the mains supply. If moisture gets into the appliance there is a risk of electrical shock.
Monitor the dustbag change indicator and inspect all filters regularly. For best performance, the dustbag and filters should be replaced when necessary. A full bag or blocked filter will reduce the vacuum cleaners' suction power. A temperature limiter automatically switches the vacuum cleaner off if it gets too hot, see "Frequently asked questions".
The hose and telescopic wand contain electrical wires. They should not come in contact with water. These items may only be cleaned with a dry cloth. Danger of electric shock.
Repairs during the warranty period should only be performed by an authorized service agent in accordance with national and local safety regulations. Unauthorized repairs could cause injury or machine damage and may void the warranty.
SAVE THESE
INSTRUCTIONS
7
Guide to the vacuum cleaner
8
Guide to the vacuum cleaner
Hand piece
On/Off switch for the Powerbrush
Lock release button
Electro Telescopic wand SET 220
Elbow
Plug for Electro-accessories
Electro Telescopic wand release button
Dust compartment lid release
Suction power selector
Powerbrush SEB 217-3/EB02 (not shown in these Operating Instructions) / SEB 228/EB03
A separate Operating manual for the respective accessory is supplied with the vacuum.
Carrying handle
Socket for Electro-accessories
Dustbag
Dust compartment filter (pre-motor filter)
Exhaust filter
On/Off foot switch
Park-system
Power cord
Cord rewind switch
Airflow indicator
Accessory clip with three tools
Suction hose SES 116
Optional accessories are available from your Miele dealer or Miele.com
9
Before using the vacuum cleaner
Connecting the Electro hose
Insert the elbow into the suction socket until it clicks into place.
Insert the plug into the socket on the inside of the carrying handle.
Disconnecting the Electro hose
Remove the plug from the socket.
Press the two release buttons at the sides of the elbow and lift the hose from the socket.
Connecting the hand piece and the Electro Telescopic wand
Insert the hand piece into the electro telescopic wand until it clicks into place. Use the inlet guides to direct insertion.
To release the hand piece from the telescopic wand press the locking button (see arrow) and pull the hand piece away from the telescopic wand.
10
Before using the vacuum cleaner
Using the Powerbrush
Observe the cleaning instructions of the floor manufacturer.
The Powerbrush is particularly suitable for cleaning and restoring crushed carpet pile of wall to wall carpeting and floor coverings subject to hard wear, especially in high traffic areas.
The Powerbrush can also be used on smooth floor surfaces.
Do not use the powerbrush on:
–(SEB 217-3/EB02 only) Floors with a variable or uneven surface. The brush could come into contact with the floor and cause damage.
–High quality, hand knotted rugs, for example Berber or Persian rugs, as well as extremely long piled area rugs and carpets. There is a danger of the threads being pulled out. Turn the Powerbrush off to vacuum these types of floor coverings and use only suction.
Connecting the Powerbrush to the Electro Telescopic wand
Insert the Electro Telescopic wand into the Powerbrush until it clicks into place.
To release the parts, press the lock release button and pull the wand up and out .
For more information on use and care please refer to the instructions supplied with the Powerbrush.
11 |
Before using the vacuum cleaner
Using the standard floor brush
(depending on model)
Observe the cleaning instructions of the floor manufacturer.
The floor brush is suitable for cleaning carpets, rugs, carpeted stairs and hard surfaces that are not susceptible to scratching.
Connecting the floor brush
Place the floor brush into the suction hose and twist until it clicks into place.
To separate the parts , press the locking button.
Adjusting the floor brush
For vacuuming carpets and rugs, lower the tool by:
pressing the foot switch marked .
For cleaning smooth floors, raise the tool by:
pressing the foot switch marked .
For safety, when vacuuming stairs it is best to start at the bottom and move upwards.
12
Included accessories
The following accessories are included:
Dust brush with natural bristles
Upholstery tool
Crevice nozzle
Accessory clip for the included accessories
Position the accessories as indicated.
Accessory clip
Press onto the elbow until it clicks into place.
Floor brush Parquet-3
(depending on model)
Special brush with natural bristles intended for cleaning parquet and laminate floors, especially those susceptible to scratching.
The parquet floor brush can be cleaned with the vacuum cleaner using the crevice nozzle if necessary.
13 |
Use
Power cord
Unwind the cord completely to aid the vacuum in dissipating heat.
Do not pull or carry by the cord, use the cord as a handle, close a door on the cord, or pull the cord around sharp edges or corners. Do not run the appliance over the cord. Keep the cord away from heated surfaces.
Do not unplug by pulling the cord. To unplug grasp the plug, not the cord.
This appliance is equipped with a power cord reel. Hold the plug when rewinding onto cord reel. Do not allow plug to whip when rewinding.
Unwinding
Hold the plug and pull out the power cord.
To reduce the risk of electric shock, the vacuum has a polarized plug (one blade is wider than the other). This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, contact a qualified electrician. Do not alter the plug in any way.
Danger of overheating and damage.
Rewinding
Unplug the vacuum from the outlet.
Press the rewind switch - the power cord will rewind automatically . Hold the plug so that it does not whip around when rewinding.
14
Use
Adjusting the Electro
Telescopic suction wand
One part of the electro telescopic wand is fitted inside the other and can be adjusted to your height for comfortable vacuum cleaning.
Press the telescopic wand release button to release the tubes and adjust to the desired height.
15
Use
Turning the vacuum On/Off
Press the On/Off foot switch .
Adjusting the suction
You can adjust the suction power to suit the type of flooring. By reducing the suction power the floor brush can be pushed easier.
The symbols on the controls indicate the type of use the settings are suitable for.
curtains, lightweight fabrics
upholstery, cushions
thick pile carpets, rugs and runners
energy saving, daily vacuuming with low noise level
lightly soiled textured carpets
textured hard flooring, and for
intensive cleaning of carpets
Turn the suction power selector to the desired setting.
To prevent static electricity your hand must touch the metal inlay on the underside of the vacuum hand piece. Be certain to continuously touch this inlay when vacuuming fine dust, flour or sawdust as these materials are more likely to create a static discharge. To further prevent static discharge while vacuuming, pull the vacuum along by the hose with one hand while continuing to hold the hand piece in the other hand.
16
Use
Turning the Powerbrush
On/Off
The Powerbrush is turned on and off separately from the vacuum using the hand piece.
The button allows you to turn off the Powerbrush, e.g. when moving from wall-to-wall carpeting to a persian rug.
17
Transport and storage
Park system
(unable to be used with the Powerbrush SEB 228/EB03)
The Park system allows you to conveniently park the telescopic wand on the vacuum cleaner during brief pauses.
A special parking attachment is fitted to all floor brushes. Insert the lower clip on the floor brush into the slot on the end of the vacuum cleaner from above.
Transport and storage
For easier transportation and storage stand the vacuum cleaner vertically.
Insert the parking clip attachment on the floor tool or floor brush into the parking slot from above (does not apply to Powerbrush SEB 228/EB03).
To save space, completely collapse the tubes in the telescopic wand.
18
Maintenance and care
Turn off and unplug the vacuum cleaner before performing any maintenance work.
The Miele filter system consists of the following three components.
–Dustbag
–Exhaust filter
–Dust compartment filter
Each of these components must be changed periodically to maintain the vacuum cleaner’s efficiency.
Only use Miele dustbags, filters and accessories with the "Original Miele" logo. Only then can the suction power of the vacuum cleaner reach its optimum potential creating the best possible cleaning results.
Purchasing new dustbags and filters
Original Miele dustbags and filters can be purchased from an authorized Miele vacuum dealer or by visiting the Miele store at http://store.miele.com.
Which dustbags and filters are the right ones?
This vacuum cleaner uses Original Miele dustbags Type G/N and an Original Miele filters, the "Original Miele" Logo will appear on the packaging or directly on the dustbag.
The use of dustbags made of paper or a similar material, or dustbags with a cardboard retaining plate can lead to serious damage to the vacuum cleaner and possibly voiding the warranty, just as with the use of dustbags without the "Original Miele" logo.
An "Air clean" exhaust filter and a dust compartment filter are supplied with every box of Miele dustbags.
If you would like to purchase additional Miele filters separately, contact your vacuum dealer or Miele, please quote the model number of your Miele vacuum cleaner to ensure correct parts are ordered. These parts are also available to order from the online Miele store.
The exhaust filter supplied with the vacuum cleaner can be exchanged with another type of Original Miele filter (see "Exchanging exhaust filters").
19
Maintenance and care
When to change the dustbag
Change the dustbag when the colored marker in the airflow indicator fills the display.
Miele dustbags are disposable and made to be used only once. Do not attempt to reuse.
Checking the airflow indicator
Attach the standard floor brush (depending on model) to the vacuum cleaner. Perform this test with the floor brush only, other attachments can affect the function of the airflow indicator.
Turn the vacuum cleaner on and select the highest power setting.
Lift the floor brush slightly off the floor. If the marker completely fills the indicator window, the dustbag needs to be changed.
How the airflow indicator works
The airflow indicator is designed to show when the bag is full of common household dust and measures the amount of air flow through the dustbag. Normal household dust is a mixture of dust, hair, carpet fluff, threads, sand, etc.
However, if fine dust, such as drill dust, sand, plaster or flour is vacuumed, the pores of the dustbag may become blocked. The marker will indicate that the bag is "full" even when it is not. The dustbag should be changed as the suction power is greatly reduced.
If the bag is bulging with pet fur, hair, carpet fluff, etc. the indicator may not register "full". This is because the air flow of the dustbag may still be high enough not to activate the marker to show maximum. The dustbag should still be changed.
20
Loading...
