Operating and Installation Instructions
Warming Drawer
To prevent accidents and machine damages, read these instructions before installation or use.
en - US, CA |
M.-Nr. 09 800 170 |
Contents
IMPORTANT SAFETY INSTRUCTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Guide to the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Warming drawer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Standard accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Before using for the first time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Operating modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Temperature settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Duration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Keeping food warm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Warming dishes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Capacity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Other uses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Sabbath mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Cleaning and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Frequently asked questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Optional accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
IMPORTANT SAFETY INSTRUCTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Installation dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Installing the front panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Electrical connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Technical Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Help protect our environment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
2
IMPORTANT SAFETY INSTRUCTIONS
WARNINGWhen using your appliance follow basic precautions, including the following:
Read all instructions before installation or use to prevent injury and appliance damage.
This appliance conforms to all uniform safety codes and regulations.
Keep these operating instructions in a safe place and pass them on to any future user.
SAVE THESE INSTRUCTIONS
Proper use
This gourmet warming drawer is intended for domestic use and similar installation conditions. Use only as described in this manual. Any other use is prohibited.
This gourmet warming drawer is not designed for outdoors use.
Persons who lack physical, sensory or mental abilities, or experience with the appliance should not use it without supervision or instruction by a responsible person.
Children
Close supervision is necessary when any appliance is used by or near children.
The appliance becomes hot during use and remains hot for some time after turning off. Keep children away from the warming drawer until it has cooled to a safe temperature.
Ensure that any packing material, is disposed of safely and kept out of the reach of children. Danger of suffocation!
Technical safety
Installation, repair and maintenance work should be performed by a Miele authorized service technician in accordance with local building and safety codes. Work by unqualified persons could be dangerous and may void the warranty.
Before installing the appliance, check for externally visible damage. Do not operate a damaged appliance.
Do not operate any appliance with a damaged cord. Contact Miele’s Technical Service Department.
To guarantee the electrical safety of this appliance, continuity must exist between the appliance and an effective grounding system. It is imperative that this basic safety requirement be met. If there is any doubt, have the electrical system of the house checked by a qualified electrician.
3
IMPORTANT SAFETY INSTRUCTIONS
Before installation, make sure that the voltage and frequency listed on the rating label correspond with the household electrical supply. This data must correspond to prevent injury and appliance damage. Consult a qualified electrician if in doubt.
Proper use
Protect your hands with oven mitts or potholders when using the appliance. Use only dry, heat resistant potholders. Moist or damp potholders used on hot surfaces can result in steam burns.
Power bars and extension cords are not safe for use with this appliance. Risk of fire. Do not use them to connect the gourmet warming drawer to the electrical power supply.
Do not use the appliance until it has been properly installed in the cabinetry.
This gourmet warming drawer must not be operated in mobile installations (boats).
Under no circumstance open the outer casing of the appliance. This is a safety hazard and may damage the appliance.
Defective components should be replaced by Miele original spare parts only. Only with these parts can the manufacturer guarantee the safety of the appliance.
Do not operate any appliance with a damaged cord or plug, or if the appliance has been damaged in any manner. Contact Miele’s Technical Service Department.
Before servicing, turn off the gas valve and disconnect the power supply by either removing the fuse, unplugging the unit or manually "tripping" the circuit breaker.
Do not store plastic containers or flammable objects in the drawer. They can melt or catch fire when the appliance is turned on. Fire hazard!
The use of accessories not recommended by Miele may cause injury.
Make certain that the power cords of small appliances do not come in contact with the appliance. The insulation of the cable could become damaged. Danger of electric shock!
Objects in the vicinity of the activated drawer may burn due to the high temperatures. Never use the appliance to heat rooms.
Do not replace the non-slip mat with kitchen towels or similar objects.
Do not overload the appliance or sit or stand on the opened drawer as this would damage the drawer.
The drawer can be loaded with maximum 55 lbs (25 kg).
If the appliance is installed in a closed kitchen cabinet, only use it when the cabinet door is open.
4
IMPORTANT SAFETY INSTRUCTIONS
Do not heat unopened food containers. Pressure can build up causing an explosion that will damage the cooking compartment. There is also a danger of personal injury and scalding.
Before serving, be sure food is at a safe temperature.
This is particularly important when preparing food for babies and children.
Be aware of loose fitting or hanging clothing while using the warming drawer. They may present a fire hazard.
The floor of the drawer becomes hot during use. Caution, do not touch. Use the handle for opening and closing the appliance.
Do not use plastic containers or plastic wrap in the warming drawer. These items may melt and cause damage to the warming drawer or injury.
Never add water to food in a hot drawer. The steam created could cause serious burns or scalds.
Liquids entering the appliance interior through the air vents may cause a short-circuit.
Open and close the loaded drawer carefully to prevent liquids from spilling.
The "Keep food warm" operating mode must be only used for keeping hot food warm, but not for heating cold food. Ensure that the food is sufficiently heated before you place it in the appliance.
It is possible that some bacterial growth may occur in foods kept for lengthy period of time at low temperature levels.
Do not use a steam cleaner to clean the drawer. Steam could penetrate electrical components and cause a short circuit.
Never warm undiluted alcohol in the warming drawer, this can easily ignite.
Exercise caution when warming food with a high sugar content. If heated for too long the sugar may caramelize or ignite.
Be sure that the vents are not covered. Food and tableware may not warm evenly otherwise.
Do not leave the warming drawer unattended while in use.
Do not use water on grease fires! A violent steam explosion may result. Smother the fire with a dry chemical or foam fire extinguisher.
SAVE THESE INSTRUCTIONS AND REVIEW THEM PERIODICALLY
5
Guide to the appliance
Warming drawer
Non-slip mat
Control panel
Vents
Rack
6
Guide to the appliance
Control panel
Sensors
|
Turns the warming drawer on and off |
Menu |
Selects the operating mode |
Temperature |
Sets the temperature |
Duration |
Sets the duration |
Indicators
Operating modes:
For warming cups and glasses
For warming plates and dishes
For keeping food warm
For low temperatures
Temperature:
Duration:
1h 1 hour
2h 2 hours
3h 3 hours
4h 4 hours
7
Guide to the appliance
Standard accessories
All standard and additional accessories can be reordered if necessary (see "Optional accessories") from Miele.
Rack
For increasing the loading area
Non-slip mat
Provides a secure base for your dishes
8
Before using for the first time
Clean and heat the appliance
Remove any protective wrapping.
Remove the non-slip mat and the rack, if provided, from the appliance and clean both with a sponge cloth, warm water and liquid dish soap. Then dry with a cloth.
Wipe your appliance inside and outside with a damp cloth and then dry.
Reinsert the non-slip mat and the rack, if provided.
Heat the empty drawer for at least 2 hours.
Touch the ON/OFF sensor to turn the appliance on.
Tap "Menu" until the symbol is illuminated.
Tap "Temperature" until the LED on the far right is illuminated.
Tap "Duration" until 2h is illuminated.
Close the drawer.
The heater and the fan of the appliance will only turn on when the drawer is closed.
The appliance will turn off automatically after two hours.
Metal components have a protective coating which may give off a slight odor the first time your new appliance is heated. The smell will dissipate after a short time and does not indicate a faulty connection.
Ensure proper ventilation of the area during this time.
9
Operation
Operating modes
Touch the "Menu" sensor to select the operating mode; the corresponding symbol will be illuminated:
Warming cups and glasses
Warming dishes and plates
Keeping food warm
Low temperature
The last selected operating mode is automatically set when the appliance is turned on the next time and will be displayed on the control panel.
The appliance is fitted with a fan distributing the warmed air within the drawer. The fan runs continuously in the "Cups/glasses" and "Warming dishes/plates" modes. It works intermittently in the "Keeping food warm" and "Low temperature" modes.
The appliance lets you keep food warm while simultaneously warming dishes. For this purpose, use the "Keeping food warm" operating mode.
Caution! The dishes need more time to warm up but may become very hot!
10
Operation
Temperature settings
Every operating mode has its own temperature range. The factory settings for recommended temperatures are shown in bold. By touching the sensor, you can change the temperature in 5 degree increments.
The last selected temperature is automatically set when the appliance is turned on the next time and will be displayed on the control panel (Exception: Low temperature).
Temperature |
|
Temperature °F / °C * |
|
||
Display |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
104 / 40 |
|
140 / 60 |
150 / 65 |
150 / 65 |
|
|
|
|
|
|
|
113 / 45 |
|
150 / 65 |
158 / 70 |
158 / 70 |
|
|
|
|
|
|
|
122 / 50 |
|
158 / 70 |
167 / 75 |
167 / 75 |
|
|
|
|
|
|
|
131 / 55 |
|
167 / 75 |
176 / 80 |
176 / 80 |
|
|
|
|
|
|
|
140 / 60 |
|
176 / 80 |
185 / 85 |
185 / 85 |
|
|
|
|
|
|
*Approximate temperatures, measured in the center of an empty drawer
