GoPal E4445
Notes on these Operating Instructions
The operating instructions and installation guidelines have been organized so that subject-
related information can be easily found using the contents list.
Note
You will find comprehensive Operating Instructions for navigation on
relevant CDs/DVDs and at the online help of the device.
The section "Frequently Asked Questions" contains answers to questions that are frequent-
ly addressed to our customer service department.
Document Your Navigation Unit
It is important to record the details of your Navigation Unit and the purchase thereof. In
the event you require warranty support you may be asked for this information. The serial
number can be found on the back of the device:
Serial Number ....................................................................................
Password ....................................................................................
Information note ....................................................................................
SuperPIN ....................................................................................
UUID ....................................................................................
Date of Purchase ....................................................................................
Place of Purchase ....................................................................................
Please record the serial number into any appropriate guarantee documents.
You will enter your own password and information note using the Security Function.
The SuperPIN and the UUID will be provided following the activation of the Security Func-
tion. See Page 17.
ii
Quality
The components used have been selected to provide a product that has a high level of
functionality and is user friendly, safe and reliable. A well-balanced hardware and software
design allows us to offer you a technologically advanced navigation system, which is both
practical and enjoyable to use.
Service
Our customer care is there to provide support and assistance whenever you have ques-
tions or are experiencing problems.
This manual contains a section specific to Customer Service starting on page 41.
Copyright © 2010, version 18/05/2010. All rights reserved. Microsoft
®
, MS-DOS
®
, and Windows are
registered trademarks of Microsoft Corporation in the U.S. and other countries. Pentium
®
is a regis-
tered trademark of Intel Corporation. The names of actual companies and products mentioned herein
may be the trademarks of their respective owners. Information in this document is subject to change
without notice
.
iii
Contents
Safety and Maintenance .................................................................................. 1
Safety Instructions ......................................................................................................... 1
Data Security ................................................................................................................. 1
Operating Environment ................................................................................................. 2
Repair ............................................................................................................................ 2
Ambient temperature .................................................................................................... 2
Electromagnetic Compatibility ...................................................................................... 3
Connection ................................................................................................................... 3
Power supply through Car Adapter ............................................................................ 3
Cabling ......................................................................................................................... 3
Information about the Regulatory Compliance according to R&TTE .............................. 4
Battery Operation .......................................................................................................... 4
Maintenance ................................................................................................................. 4
Care of the Display ........................................................................................................ 5
Recycling and Disposal .................................................................................................. 5
Transport ...................................................................................................................... 6
Supplied Items .............................................................................................................. 7
Views ............................................................................................................... 8
Front Components ........................................................................................................ 8
Back Components ......................................................................................................... 9
Top Components .......................................................................................................... 9
Bottom Components ................................................................................................... 10
Left Side ...................................................................................................................... 10
Initial Set up .................................................................................................. 11
I. Charging the Battery ................................................................................................ 11
II. Power Supply .......................................................................................................... 12
Car Adapter .............................................................................................................. 12
Alternative possibility of charging the battery ........................................................... 12
III. Switching on the Device ......................................................................................... 13
IV. Installing the Navigation Software .......................................................................... 14
General Operating Instructions ..................................................................... 15
Switching on/off the device ......................................................................................... 15
Security ......................................................................................................... 16
Storing the password and the information note .......................................................... 16
Making settings ........................................................................................................... 17
iv
SuperPIN and UUID ..................................................................................................... 18
Making subsequent settings ........................................................................................ 19
Password Request ....................................................................................................... 20
Resetting the Navigation System ................................................................... 21
Reset ........................................................................................................................... 21
Switching the Device off Completely / Hard Reset ....................................................... 21
Navigation ..................................................................................................... 22
Safety Instructions for Navigation ................................................................................ 22
General Instructions ................................................................................................. 22
Notes for Use in a Vehicle ......................................................................................... 23
Aerial Orientation ........................................................................................................ 24
I. Mounting the Car Holder ......................................................................................... 24
II. Attaching the Navigation System ............................................................................. 25
III. Connecting the Car Adapter ................................................................................... 26
IV. Starting the Navigation Software ............................................................................ 27
Warning function for traffic monitoring points ............................................ 28
Speech commands (optional) ........................................................................ 31
Handsfree Facility by means of Bluetooth (optional) ........................................ 35
Starting the Bluetooth Application............................................................................... 35
Overview of the Main Screen ................................................................................... 36
Pairing the Navigation Device and the Mobile Phone ............................................... 37
Accepting incoming calls ......................................................................................... 38
Making Calls ............................................................................................................ 38
During a Call ............................................................................................................ 39
MP3 Player (optional) ................................................................................... 40
Overview of the Main Screen ....................................................................................... 40
Select a Title and Move it into the List of Favourites ..................................................... 41
List of Favourites ...................................................................................................... 42
List of the established bookmarks ................................................................................ 42
Picture Viewer (optional) .............................................................................. 43
Operating the Picture Viewer ....................................................................................... 43
Main Screen ................................................................................................................ 43
Full Image View........................................................................................................ 44
Travel Guide (optional) ................................................................................. 46
Alarm Clock (waking function) (optional) .................................................... 48
Overview of the main screen ....................................................................................... 48
Description of the Interfaces ........................................................................................ 49
Setting the System Time ........................................................................................... 50
v
Selecting an Alarm Signal ......................................................................................... 51
Setting the Volume .................................................................................................. 52
Snooze Function ...................................................................................................... 53
Ending the Alarm Clock Application ......................................................................... 53
Sudoku (optional) ......................................................................................... 54
Main Screen ................................................................................................................ 54
Description of the switch fields .................................................................................... 55
Overview of the game field.......................................................................................... 56
Description of the control buttons ........................................................................... 56
FAQ ................................................................................................................ 57
Customer Service ........................................................................................... 58
Faults and Possible Causes .......................................................................................... 58
Additional Support ...................................................................................................... 58
Appendix ....................................................................................................... 59
Special CleanUp Function............................................................................................ 59
Synchronisation with the PC ........................................................................................ 62
I. Installing Microsoft
®
ActiveSync
®
............................................................................ 62
II. Connecting with the PC ........................................................................................... 63
Mass Storage mode .................................................................................................. 63
ActiveSync
®
-Mode..................................................................................................... 64
Alternative possibility of charging the battery ........................................................... 64
III. Working with Microsoft
®
ActiveSync
®
.................................................................... 64
GPS (Global Positioning System) ................................................................... 65
TMC (Traffic Message Channel) (optional) .................................................... 66
TMCpro / Trafficmaster (optional) ............................................................................... 66
Trafficmaster (optional) ............................................................................................... 66
Installing the External TMC Receiver / Connecting the TMC Diplole Aerial (optional)67
Working with Memory Cards ......................................................................... 68
Inserting Memory Cards .............................................................................................. 68
Removing Memory Cards ............................................................................................ 68
Accessing Memory Cards ......................................................................................... 68
Data Exchange via Card Reader ................................................................................ 69
Additional Card Material .............................................................................................. 69
Transfer of card material to a memory card .............................................................. 69
Alternate method of installing Navigation Software (using a memory card) ............ 70
Transferring Installation Files and Map Material to the Internal Memory .................. 70
Specifications ................................................................................................ 71
Model Overview ............................................................................................. 72
FCC Compliance Statement ........................................................................................ 73
vi
Conditions of Warranty for the United Kingdom ........................................... 74
Index ............................................................................................................. 80
Safety and Maintenance
Safety Instructions
Please read this section carefully and follow all the instructions provided. This will help
ensure reliable operation and prolong the life of your appliance.
Keep the packaging and the user instructions for future reference or enquiries at a later
date. If you pass the article on to another person, you should pass on these instructions.
Never allow children to play with electrical equipment unsupervised.
Keep the packaging materials, such as plastic bags away from children as there is a
danger of suffocation.
Never open up the housing of the appliance. This contains no user-serviceable
parts. If the housing is opened there is a danger of electric shock.
Please operate your navigation system with an approved power supply only.
Do not place any objects on the appliance and do not exert any pressure on the
display. Otherwise there is a danger that the screen will break.
To avoid damage, do not touch the screen with sharp objects. We recommend us-
ing only the stylus provided or finger when using the touch-screen functionality of
the product.
There is a risk of injury if the display breaks. If this should occur, use protective
gloves to pack the broken parts and contact customer support to arrange for dis-
posal. Then wash your hands with soap, since there is a possibility that chemicals
may have escaped.
Switch the appliance off immediately, or do not switch it on, and contact Customer Ser-
vice.
If the housing of the appliance becomes damaged or liquid may have leaked into it
the components must be checked by Customer Service in order to avoid damage!
Data Security
Every time your data is updated or modified backup copies should be made on an
external storage medium. The supplier assumes NO liability for data loss or damage
to data storage units, and no claims can be accepted for damages resulting from
the loss of data or for consequential damages.
Safety and Maintenance
2
Operating Environment
Failure to follow these instructions may lead to your appliance being damaged. In cases
where products are damaged as a result of misuse or neglect the associated guarantee will
be considered void.
Keep your navigation System and all connected devices away from moisture and
avoid exposure to dust, heat and direct sunlight, especially in the car.
Make sure you prevent your appliance from getting wet, e.g. from rain and hail, at
all times. Please note that moisture can even build up inside a protective pouch as a
result of condensation.
Avoid heavy vibrations and shaking.
Please note the device should be installed vertically, this will ensure that the device
remains secure within its holder.
Repair
Please contact our Service Centre if you encounter technical problems with your
appliance.
In the event a repair becomes necessary, please use Medion authorised Service
Partners. The address can be found on the back of your guarantee card or online at
www.medion.co.uk
Ambient temperature
The appliance will operate effectively at an ambient temperature of between +32°F
and +95°F (0° C and 35° C) and at a relative humidity of between 10% and 90%
(non-condensing).
In the powered down state the appliance can be stored at between -4°F and
+140°F (-20° C + to 60° C).
Store the appliance in a safe location, away from high temperatures (e.g. when
parking or from direct sunlight).
Safety and Maintenance
3
Electromagnetic Compatibility
When connecting additional or other components the “Electromagnetic Compati-
bility Directive” (EMC) must be adhered to. Please note that only screened cable
(maximum 10ft) should be used with this appliance.
For optimal performance, maintain a distance of at least 10 ft. from sources of high-
frequency and magnetic interference (televisions, loudspeaker systems, mobile
telephones etc.).This will help to avoid malfunctions and loss of data.
Electronic devices emit electromagnetic waves during operation.
These emissions are harmless, but can interfere with other devices operated in close
proximity.
While our devices are tested and optimised for electromagnetic compliance in our
laboratories, interference during operation may still occur in the device itself and
with other devices in its proximity.
Should such interference occur, try to eliminate it by adjusting the positions of and
the distances between the devices.
Before driving, please ensure that the electronic systems of the car are working
properly.
Connection
When connecting your appliance it is important to observe the following instructions:
Power supply through Car Adapter
The car adapter should only be connected to the lighter socket of a car
(car battery = DC 12V , truck battery = DC 24V ). If you are in any doubt about
the power source in your car, please contact your car manufacturer.
Cabling
Arrange cables so that they do not cause unnecessary obstruction or risk entangle-
ment or snaring. E.g. ensure that the cables cannot be trod on, or tripped over.
Do not put any objects on the cable, because it could be damaged if you do so.
Do not use any force and pay attention to the correct orientation of the plug when
connecting the cables and plugs.
Do not permit any great forces to be exerted on the plug connections, from the
side, for example. This will lead to damage in and to your device if you do so.
Avoid short circuiting and broken cable by not crushing or bending it sharply.
Safety and Maintenance
4
Information about the Regulatory Compliance according
to R&TTE
Bluetooth (only for model E4445)
The company declares that this device is in compliance with the essential requirements
and other relevant provisions of Directive 1999/5/EC. Complete declarations of conformity
are available under www.medion.com/conformity
.
Battery Operation
Your appliance is powered by an integrated battery. In order to prolong the life and effi-
ciency of your battery and ensure safe operation, follow the instructions below:
Batteries cannot withstand excessive heat. Take care to avoid overheating of appli-
ance and the integrated battery. Failure to comply with this instruction may lead to
damage to or, even explosion of the battery.
Only use the supplied car adapter to charge the battery.
The batteries are special category waste. When disposing of the appliance en-
sure that this is done correctly. Contact Customer Service for more details.
Maintenance
Warning
There are no user-serviceable parts which require cleaning inside the hous-
ing of the appliance.
You can prolong the life of the appliance by taking the following simple steps:
Always remove the power plug and all connecting cables before cleaning.
Clean the appliance only with a damp, lint-free cloth.
Do not use solvents, caustic or gaseous cleaners.
Safety and Maintenance
5
Care of the Display
Avoid scratching the display surface as this may be easily damaged. We recommend
using a display protection film (mylar) to prevent scratching of the screen. Please
contact your nearest dealer for this accessory.
The plastic on the display at delivery is purely for protection during transportation!
Ensure that no traces of water remain on the screen. Water can cause irreversible
discoloration.
Use only a soft, lint-free cloth to clean the screen.
Do not expose the screen to strong sunlight or ultraviolet radiation.
Recycling and Disposal
The device and its packaging are recyclable.
Device
At the end of its life, the appliance must not be disposed of in household rubbish. Consult
your local waste disposal company to enquire about environmentally-friendly options for
disposal.
Packaging
To avoid damage during transport, the appliance was supplied in protective packaging.
The majority of packaging is manufactured from materials which can be disposed of in an
environmentally friendly manner and be recycled professionally.
Safety and Maintenance
6
Transport
When transporting the appliance please follow the instructions below:
After transporting the appliance wait until the unit has acclimatised and adjust to
surrounding conditions (e.g. room temperature and humidity) prior to use. In the
event of large fluctuations in temperature or humidity, condensation or moisture
may form inside the appliance. This can cause an electrical short-circuit.
In order to protect the appliance from dirt, knocks and scratching, please use an
appropriate protective case.
Before travelling ensure that you are aware of the power and communications pro-
visions at your destination. Before travelling obtain any power or communications
adapters that may be required for the operation of your device.
When shipping your appliance we recommend using the original packaging. If the
original packaging isn’t available please contact customer service for advice.
When passing through baggage control at airports, it is recommended that you
pass the appliance and all magnetic storage media (external hard drives) through
the X-ray system (the machine on which your bags are placed). Avoid the magnetic
detector (the structure through which you yourself pass) or the magnetic wand
(the hand device that the security staff use), since this may corrupt your data.
Safety and Maintenance
7
Supplied Items
Please check the condition of items supplied and check for missing items using the list
below. If you find your package to be incomplete, please forward to us all claims for miss-
ing items within 14 days from the date of purchase.
The package should include the following:
Navigation system
Power cable for cigarette lighter
Car holder and cradle
USB cable
CDs/DVDs with navigation software, digital maps, ActiveSync®,
PC application for restoring data quickly
Instruction manual and warranty card
Optional
Memory card
TMC dipole antenna
External TMC receiver
Earphones
Protective case
Views
8
Views
Front Components
Ref Component Description
Microphone (only for models E4245 and E4445)
Battery Charge
Indicator
The LED will flash orange during the charging
process. It will shine constant green when the
accumulator is fully charged.
Bluetooth indicator This LED will blink at different speeds, according
to the connection status, if Bluetooth has been
activated (only for model E4445)
Touch Screen Displays the output of your appliance. Tap on
the screen with your finger, a stylus or a "blunt"
tip to select menu commands or enter data.
Views
9
Back Components
Ref Component Description
Loudspeaker Plays back music, language statements and
warnings.
Top Components
Ref Component Description
On-/ Off button
Turn the device on or off by pressing and holding
the On/Off button. You will switch to the stand-by
mode or reactivate the device by quickly pressing
the button.
Memory card
insertion slot
Accepts an optional memory card for removable
storage.
GPS
Antenna
Views
10
Bottom Components
Ref Component Description
Mini-USB-
Connector
Connection to external power supply as well as
connection for connecting to a PC by means of the
USB cable (for data matching)
You also have the possibility to connect an external
TMC receiver here (only for the model E4145)
Left Side
Ref Component Description
Earphones Connects to a pair of stereo earphones
Using this appliance at full
volume for extended periods
of time may cause damage to
the hearing capacity of the
listener.
W
m
e
w
H
v
You also have the possibility to connect a TMC
dipole antenna here (only for the models E4245
and E4445).
Initial Set up
11
Initial Set up
The following is a step by step guide to assist in the initial Set-up of the navigation system.
Start by removing the protective plastic from the display.
I. Charging the Battery
The battery of your navigation system can be charged in the following ways:
Using the supplied car adapter or
using a suitable USB cable.
Attention!
It may be necessary to initially charge the battery for a considerable period
of time prior to commencing and running through the initial installation,
this is dependent on the level of charge held at the time by the internal
battery.
Please observe the following notes relating to the battery:
The charging status display LED will flash orange until the navigation system is
charged. If possible, do not interrupt the charging process until the
battery is fully charged. This may take a few hours. The charging status LED will
shine constant green if the battery has a high level of charge. Leave the device
charging for 20 further minutes, to ensure the battery is fully charged.
The navigation system can be used during the charging process, but the power
supply must not be interrupted during initial set-up.
Leave the external power supply connected to the navigation system for around 24
hours, so that the backup battery also charges-up fully.
The external power supply can remain connected; this is recommended for conti-
nuous operation. However, the mains adapter (optional) must remain switched on
whenever it is connected to the navigation system.
Even after a power source has been connected to the device it may take several mi-
nutes until the device is once again ready to operate again, this occurs if the charg-
ing state of the battery is exceptionally low. The battery will continue to be charged
if the power supply is connected and the device is switched off.
The battery can be charged while the device is switched off completely.
Initial Set up
12
II. Power Supply
Car Adapter
(similar picture)
1. Plug the jack () of the connection cable into the corresponding receptor at the
bottom of your navigation system.
2. Insert the power adapter () into the cigar lighter socket ensuring, that it will not
lose contact while driving. This could cause a malfunction.
Alternative possibility of charging the battery
The battery will charge as soon as you connect your navigation device to a switched-on PC
or notebook by means of a USB cable. No additional software or updates is required for
your PC to perform this function. Do not interrupt the charging process if possible during
the initial charge.
Note
The brightness will be adjusted downwards, if necessary, if a USB connec-
tion is being set up when the device is switched on.
It is recommended to set the device to the stand-by mode, in order to
shorten the charging time by USB.
Initial Set up
13
III. Switching on the Device
You will switch your navigation device on or off again completely by pressing the On/Off
key for a long time (> 3 sec.).
The navigation system will start the first setting up automatically. Select the language that
you require first. The brand logo will appear and your device will display the entry screen
after a few seconds.
Button Description Main Screen
Menu
Viewing maps
Navigation menu
Other applications
Settings
Initial Set up
14
Note
You will not be able to select the Navigation menu or the settings if the
navigation software does not find any map files in the device or on a
memory device. Then the ‘Other applications’ menu will appear auto-
matically.
Note
Brief pressure on the on/off button will be enough to switch the device
on or off, provided that your navigation system is connected to an external
source of electricity or is running in battery operation (standby mode).
You can adjust the period of operation to suit your needs using the
Settings button on the main screen of your device. Your device is deliv-
ered in a status in which it will not switch off independently.
Press and hold the On/Off key (> 3 sec.), to completely switch off the
device.
No data will be lost as data is stored in the internal memory. The starting
process will only last slightly longer.
Your navigation system will use a low amount of electricity and the batteries will be dis-
charged, even when in standby mode.
IV. Installing the Navigation Software
The final installation of the navigation software will take place automatically from the in-
ternal memory, during the initial set up, if your device has already been equipped with the
basic data of the navigation software at the factory. Follow the instructions on the screen.
An optional memory card must always be inserted in the device while the navigation sys-
tem is being used.
It will be necessary to carry out a Reset to restart the navigation system if the memory card
has been removed (see page 21).
Please also read the chapter Navigation starting on page 22.
General Operating Instructions
15
General Operating Instructions
Switching on/off the device
Your device will be in its normal operating state after the initial set up. You can activate
and deactivate your device with the On-/Off switch.
1. To start your navigation system press briefly the On-/Off switch .
Note
Your device is delivered in a status in which it will not switch off independ-
ently. You can adjust the period of operation to suit your needs using the
Settings button on the main screen of your device.
Your navigation system will use a low amount of electricity and the batter-
ies will be discharged, even when it is in the standby mode.
2. To switch off your navigation system briefly press the On-/Off switch .
The following screen will appear:
You have three possible choices:
Button Description
Cancel/Back
Return to previous view with this key, if you have accidently called
up this screen.
Standby Mode (Energy saving mode)
The device will go into Standby Mode if this key is clicked.
Reset
You can carry out a reset by clicking this key.
The device will go into the Standby mode automatically after a few seconds if you do not
want to select any of these three possibilities.
For further settings within the Standby mode also see the chapter on “Special CleanUp
Function”, page 59, point 8.
Security
16
This display will also appear after the delay period of a few seconds has expired, if you
have activated the DC AutoSuspend Comfort Function.
Security
You have the possibility of protecting your device against external access by means of this
function. Some one-off settings will have to be made before you will be able to use this
function. Proceed as follows to do this:
Storing the password and the information note
1. Go to Settings and then to Device settings by means of the main display.
2. Click on Security, in order to start the respective function. The following display
will appear:
3. Click on
, in order to enter a password.
4. A keyboard will appear. Enter a password with it.
Note
The password must consist of at least 4 symbols. Use a combination of
letters (A – Z) and numbers (0 - 9). Keep the password in a safe place.
5. Confirm the password with the symbol after you have entered it.
6. Enter the password in the second field to reconfirm it and in order to avoid poten-
tial careless mistakes.
Note
The password will be displayed in the form of small stars (****).
7. An additional text field will appear after you have entered the password. Enter an
information note here that will serve as a support for remembering your password.
You will be able to call up this information if you have forgotten or mislaid the
password.
Security
17
Making settings
The following selection window, through which you will make the settings for the Security
Function, will appear after you have entered the password and the information note
successfully.
Button Description
Set here whether the device should request the password
after a hard reset.
Set here whether the device should request the password
after a restart.
Set here whether the device should request the password
after the device has been switched on from the Standby
mode.
Confirm your settings with during the set-up. The following screen will appear:
Security
18
SuperPIN and UUID
The SuperPIN and the UUID (Universally Unique IDentifier = definite device identification)
will appear on the display after you have confirmed the settings.
Note
Record this data in your Operating Instructions (see Page 1) and keep
them in a safe place.
You will need this information if you have entered the password incor-
rectly 3 times. The navigation device can then only be released with this
information.
Security
19
Making subsequent settings
Start the Security Function if you have already entered a password and would like to make
a subsequent setting or to change the password. The following display will appear:
Button Description
Change the password or the information text
Authentication settings(see Page 17, Making settings)
Display SuperPIN and UUID (see Page 18)
Reverses the complete security function. All security set-
tings and passwords will have been deleted after this func-
tion has been carried out. You will have to enter and con-
firm your password again to be able to carry out the secu-
rity function.
Security
20
Password Request
A password request will appear at the restarting of the device, according to the setting, if
you have established a password by means of the Security Function.
1. Enter the password stored by you by means of the keyboard.
Note
The password will be displayed in the form of small stars (****).
2. Click on the question symbol to have the information note displayed, if you have
forgotten the password and need the Help setting.
3. Click on
to confirm the entry.
Note
You will have to enter the SuperPIN if you have entered the password
incorrectly 3 times. Contact your Service Center, giving the UUID, if you
have also mislaid it. The UUID will be faded out in the lower display.
Resetting the Navigation System
21
Resetting the Navigation System
You can reset your navigation system if it is no longer reacting or working properly.
This option restarts the navigation system, without reinstallation being necessary. A reset is
often used in order to reorganise the memory. In doing so all programs that are running
are interrupted and the working memory is reinitialised.
You can carry out two different Reset procedures with your device.
Reset
The following screen will appear if you press the On/Off switch for a short time:
If you want to carry out a Reset, tap on .
You will find further information in the chapter “Switching on/off the device”, page 15.
Switching the Device off Completely / Hard Reset
Attention!
A hard reset will delete all data in the temporary memory.
Your navigation system will normally be in the Standby Mode, if you have switched it off
by pressing the on/off button briefly. In addition, the system can be switched off com-
pletely; the consumption of energy can be kept as low as possible through this. All the
data in the temporary memory will be lost if the device is switched off completely (hard reset).
To switch your navigation system off completely:
1. Press and hold the On/Off key (> 3 sec.), to switch off the device.
2. Press and hold the On/Off key (> 3 sec.), to switch the device on again.
A reinstallation will not be necessary after a hard reset if your device has already been
equipped with the basic data of the navigation software in the permanent memory.
Loading...
