KNIFE SHARPENER
MODEL BE1 ML - 104443
MODEL BE1
EXECUTIVE OFFICES
701 RIDGE AVENUE
TROY, OHIO 45374-0001
FORM 18843 Rev. A (4-94)
Installation, Operation, and Care of
MODEL BE1 KNIFE SHARPENER
SAVE THESE INSTRUCTIONS

GENERAL

The BE1 Knife Sharpener allows you to put a
B
ETTER
E
DGE
on flat-bladed knives by applying the blade
edge against a grit-bearing belt moving at the optimum speed. Excessive pressure during sharpening could overheat the blade resulting in loss of temper and reduction of cutlery life. The unloader wheels prevent over-pressure (and over-heating) by lifting the blade off the belt if too much pressure is applied.

INSTALLATION

UNPACKING
Immediately after unpacking the Knife Sharpener, check for possible shipping damage. If the BE1 is found to be damaged after unpacking, save the packaging material and contact the carrier within 15 days of delivery.
Prior to installation, test the electrical service to assure that it agrees with the specifications on the data plate located on the right side of the housing.
LOCATION
The Model BE1 Knife Sharpener should be placed on a suitable counter, table, or workbench where the
suction-cup
ELECTRICAL CONNECTION WARNING: THE ELECTRICAL CORD IS PROVIDED WITH A THREE-PRONG GROUNDING PLUG.
THE OUTLET TO WHICH THIS PLUG IS CONNECTED MUST BE PROPERLY GROUNDED. IF THE RECEPTACLE IS NOT THE PROPER GROUNDING TYPE, CONTACT AN ELECTRICIAN .
feet will hold the sharpener in place.
ELECTRICAL DATA
Model Volts / Hz / Phase Amps BE1 120 / 60 / 1 0.4

OPERATION

WARNING: DO NOT IMMERSE. UNPLUG BEFORE CLEANING, SERVICING OR REMOVING PARTS.
REPLACE PARTS BEFORE USE. CONTROLS (Fig. 1) On – Off Switch — Turns the sharpener On and Off.
Circuit Breaker — Breaks the circuit if the current exceeds 1
Ampere. Turn off sharpener. Then press Circuit Breaker button to restore circuit.
Adjustment Knob— Centers belt track when sharpener is on.
– 2 –
On/Off Switch
Circuit Breaker
Fig. 1
Adjustment
PL-51362
Knob
