Item # _____________________________________
Quantity ___________________________________
C.S.I. Section 11400
HS9N-HV
701 S Ridge Avenue, Troy, OH 45374
1-888-4HOBART • www.hobartcorp.com
STANDARD FEATURES
KNIFE
■ 13" CleanCut™ Knife
■ Removable Ring Guard Cover
■ Zero Knife Exposure
■ Heavy-Gauge Stainless Steel Knife Cover
■ Top-Mounted Borazon Stone Sharpener
OPERATION
■ 1⁄2 H.P. Knife Drive Motor
■ Timing Belt for Automatic Drive System
■ Variable Four-Speed Automatic Carriage with
Front Mounted Controls
■ Three Stroke Lengths
INTERLOCKS
■ Home-Start Position
■ Close-to-Stop
■ Gauge-Plate Interlock
■ Carriage-System Interlock
■ No-Volt Release
■ 30-Second Shut Off
SLICER
MODELS
❑ HS9N-HV50CP – Automatic Slicer/Anodized
Finish with Non-Removable Knife Feature,
220-240 volts, 50 Hz with 240 volt power cord
& plug
❑ HS9N-HV60CP – Automatic Slicer/Anodized
Finish with Non-Removable Knife Feature,
220-240 volts, 60 Hz with 240 volt power cord
& plug
❑ HS9N-HV50C – Automatic Slicer/Anodized
Finish with Non-Removable Knife Feature,
220-240 volts, 50 Hz with 240 volt power cord
& no plug
❑ HS9N-HV60C – Automatic Slicer/Anodized
Finish with Non-Removable Knife Feature,
220-240 volts, 60 Hz with 240 volt power cord
& no plug
Specications, Details and Dimensions on Inside and Back.
HOUSING AND BASE
■ Sanitary Anodized Aluminum Base
■ Machined Grooves on Gauge Plate and Knife
Cover
■ Exclusive Tilting, Removable Carriage System
■ Electroless Nickel Plated Single Slide Rod with
Reservoir Wick in Transport
■ Double-Action Indexing Cam
■ Manual Lift Handle
■ Ergonomic-Style Handle
■ Rear-Mounted, Removable Meat/Vegetable Grip
Arm
ACCESSORIES
❑ Full Fence
❑ Food Chute
❑ Slaw Tray
❑ Debris Deector
HS9N-HV SLICER
F40364 – HS9N-HV Slicer Page 1 of 4
HS9N-HV
SLICER
SOLUTIONS / BENEFITS
PRECISION SLICING
13" CleanCut™ Knife
■ Super alloy edge stays sharp longer
■ Lasts two to three times longer than carbon coated
or stainless steel knives
Top Mounted Borazon Stone Sharpener
■ Single-action sharpens and hones in just ve
seconds
■ Removable and warewasher safe for easy cleaning
and sanitation – can be used wet or dry
■ Lifetime guaranteed Borazon sharpening stones
provide maximum performance with reduced
maintenance costs
Machined Grooves on Gauge Plate and Knife Cover
■ Reduces drag for smoother slicing motion
Double-Action Indexing Cam
■ The rst full revolution of the indexing knob provides
precise control of shaving, chipping and thin slicing
■ The second revolution opens the gauge plate quickly
for thicker slicing
■ Gauge plate holds position for consistent, precision
slicing
EASY TO USE
1
⁄2 H.P. Knife Drive Motor
■ Reserve power runs at 430 rpm for optimum results
Timing Belt Automatic Drive System
■ Extends belt life while producing optimum slicing
results
■ Quieter operating slicer
■ Four carriage speeds including 28, 38, 48 and 58
strokes per minute
Three Stroke Lengths
■ Three stroke lengths ideal for a variety of products
Electroless Nickel Plated Single Slide Rod with
Reservoir Wick in Transport
■ Smooth operation with continous lubrication of
carriage rod
Zero Knife Exposure*
■ Knife edge is covered when sharpener is both
mounted and removed, making cleaning easier
■ Gauge plate remains closed during operation of
sharpener
701 S Ridge Avenue, Troy, OH 45374
1-888-4HOBART • www.hobartcorp.com
Home Start Position
■ Carriage must be in ‘home position’ before the slicer
will start
Close to Stop
■ Closing of the gauge plate turns off the slicer
Gauge Plate Interlock
■ Gauge plate must be closed to remove carriage for
cleaning and cannot be opened when removed
Carriage System Interlock
■ Will not tilt away or remove if gauge plate is not
closed
No Volt Release
■ Slicer must be restarted if power fails or slicer is
unplugged
Automatic Shutoff
■ Knife shuts off after 30 seconds of inactivity
EASY TO CLEAN
Removable Ring Guard Cover*
■ Catches product debris around the knife for easy
removal during cleaning
■ Reduces time to ‘oss’ during cleaning
Exclusive Tilting, Removable Carriage System*
■ Tilt design allows for ease of mid-day cleaning
■ Removable for complete cleaning and sanitation
Rear-Mounted, Removable Meat Grip
■ Opens up front of product tray for unobstructed
loading
■ Removable meat grip allows for easy cleaning
Manual Lift Handle
■ Props machine for easy cleaning underneath slicer
Sanitary Anodized Aluminum Base
■ Limited cracks/crevices or bolt holes where product
can lodge and bacteria may grow
■ Easy clean up and durable nish
*Feature unique to Hobart
Page 2 of 4 F40364 – HS9N-HV Slicer
HS9N-HV
701 S Ridge Avenue, Troy, OH 45374
1-888-4HOBART • www.hobartcorp.com
SPECIFICATIONS
KNIFE
13" CleanCut Knife: The knife is approximately 13 inches,
constructed of 304L stainless steel and high performance
Stellite alloy. Knife cover is retained magnetically, and is
quickly removed by pulling straight back on the top cover
knob.
Removable Ring Guard Cover: Fits on top of ring guard
to catch food debris. When removed, reveals a 0.12"
space between knife and guard for easier ossing. Ring
guard is made with Zytel™ plastic and can be washed in
warewasher or three compartment sink.
Zero Knife Exposure: Knife edge is not exposed during
cleaning or sharpening procedures.
Top Mounted Borazon Stone Sharpener: Single action
operation utilizing two Borazon stones to sharpen and
hone in ve seconds. Removable, top mounted and
warewasher safe. When sharpener is removed for cleaning,
knife edge is completely shielded. Borazon stones have a
lifetime guarantee.
MOTOR
Poly V-Belt Knife Drive System: Knife is driven by
a Hobart Poly V belt and runs at 430 rpm for optimal
performance.
Four Stroke Speeds: Stroke speed can be set to 28, 38,
48 and 58 strokes per minute.
1
⁄2 H.P. Knife Drive Motor: 1⁄2 H.P. permanently lubricated
ball bearings. Single phase capacitor-start, induction run.
INTERLOCKS
Home Start Position: Home-start ensures carriage is in a
convenient position before starting the slicer.
Close to Stop: After slicing, a quick turn of the index knob
to the closed position turns off the slicer.
Gauge Plate Interlock: Gauge plate interlock protects
knife edge when indicator is at zero.
Carriage System Interlock: Carriage will not tilt away or
remove if gauge plate indicator is not closed.
No Volt Release: In the event of a power loss, slicer must
be restarted before operation can continue.
Automatic Shut Off: Knife shuts off after 30 seconds of
inactivity to extend motor life and save energy.
SLICER
HOUSING AND BASE
Sanitary Anodized Aluminum Base: One-piece base has
fewer places to harbor soil and is easier to clean. Limits
holes or crevices in which food can lodge.
Finish: Stainless steel top cover, anodized aluminum
product tray and gauge plate.
Exclusive Tilting, Removable Carriage System:
Aluminum product tray tilts easily for mid-day cleaning
and is removable for thorough cleaning and sanitation
procedures. The carriage has 12.5" manual travel.
Electroless Nickel Plated Single Slide Rod with
Reservoir Wick in Transport: Transport slide rod is
E-Nickel electroless plated. Slide rod bearings feature an
oil reservoir/oil wick.
Double-Action Indexing Cam: A solid construction index
knob moves the gauge plate via a barrel cam ensuring
consistent slice thickness across machine and over time.
First revolution of index cam for precision slicing; second
revolution for thicker slicing selection.
Manual Lift Lever: Helps hold slicer in tilted position for
cleaning beneath the machine.
Ergonomic Style Handle: Specially shaped and
positioned for ease of use during manual operation.
Rear Mounted, Removable Meat Grip Arm: Rear
mounted grip is high strength thermoplastic. Swings out
of way when not in use.
Electrical Specification: Available in 220-240/50/1;
2.8 Amps and 220-240/60/1; 2.8 Amps - Not submitted for
ETL Listing.
Switch: Moisture protected push button switch.
Cord & Plug: 6-foot, three-wire power supply cord and
plug on the HS9N-HV50CP and HS9N-HV60CP. Plug not
furnished on HS9N-HV50C or HS9N-HV60C machines.
Capacity: The carriage will take food up to 12" in width or
7.5" in diameter.
Gauge Plate: Gauge plate is a heavy aluminum extrusion
with machined grooves for smooth feeding. Adjustable to
cut any thickness of slice up to 1".
Warranty: All parts and service coverage for one year
including knife. Lifetime guarantee on Borazon stones
in the sharpening system. This warranty is valid in the
U.S. and Canada. However, warranty may vary in other
countries.
Shipping Weight: 142 l bs.
F40364 – HS9N-HV Slicer Page 3 of 4
HS9N-HV
SLICER
DETAILS AND DIMENSIONS
701 S Ridge Avenue, Troy, OH 45374
1-888-4HOBART • www.hobartcorp.com
As continued product improvement is a policy of Hobart, specications are subject to change without notice.
Page 4 of 4 F40364 – HS9N-HV Slicer
F40364 (02/15) LITHO IN U.S.A. (H-01)
