Double-hand foldable set
Applicable for a series gimbal
Guilin Feiyu Technology Incorporated Company
V 1.0E NUser Manual
1.Product Overview
Trigger Button
Indicator
Joystick
Function Button
Shutter Button
Retaining Ring
Fixed Pulley
Tips： 1. The connectors on the foldable set are fitted with 1/4-inch threaded holes.
2. Refer to the a series product manual for functions and operation.
Battery
Compartment
USB Interface
USB Cable
Battery X2
(Type: 18650)
Smart Charger
Cold Shoe
Mount
Basic Accessories
Charging
Indicator
1/4 Inch Screw
1
2.Operation Mode
1
Expansion and closure of folding arm：
①Expand the folding arm and tighten the two fixed pulleys at the interface；②Loosen the two fixed pulleys at the
interface and close the folding arm.
2
Installation and disassembly of a series gimbal：
①Install the a series gimbal, tighten the retaining ring；②Loosen the retaining ring and remove the a series
gimbal gently.
After installation, please tighten
the retaining ring.
①
①
②
②
2
4.Parameters
3.Usage Way
Double-hand foldable set can be used in many ways, such as positive holding and reverse holding. Turn positive
holding to reverse holding as shown in the following, in positive holding, both hands hold the hand grip, began
to rotate, turn to 90 degrees, alternating hands, continue to rotate 90 degrees, to the back of reverse holding.
426.2mm
93mm
171.4mm
128.5mm
211.5mm
3
positive holding 90° reverse holding
D I S C L A I M E R
FeiyuTech reserves the right to amend this manual and the terms and conditions of use the gimbal at
any time.
You can get the latest user manual from the official website: www.feiyu-tech.com.
The Company assumes no liability for any risks related to or resulting from the debug and use of this
product (including the direct, indirect or third-party losses).
Prohibit any user for any illegal purpose. Users will be responsible for all behaviors of purchase and
use products.
For any unknown sources of using, we will not be at any services.
The updating and changes of product firmware and program may cause changes in function
descriptions in this user manual, please read the instructions carefully before upgrading the firmware
and use the corresponding user manual.
Guilin Feiyu Technology Incorporated Company
For more information, please visit our official website
Due to software and hardware improvements, your actual product might differ from the descriptions
and pictures in this user manual. You can get the latest user manual from the official website.
