SPARE PARTS CATALOGUE
CATALOGO PARTI DI RICAMBIO
TUTTAPIASTRA GAS E700XP
GAS SOLID TOP E700XP
PNC Model Ref Brand Version Notes
371008 E7STGH10G0 a ELX GAS OVEN 800 MM
371009 E7STGH30G0 b ELX GAS 2 BURNERS + OVEN 800 MM
371010 E7STGL3010 c ELX GAS 2 BURN. + OVEN + OPEN BURN.1200MM
371012 E7STGL5000 m ELX GAS SOLID TOP + 4 BURNERS 1200 MM
371217 E7STGH10GA j ELX GAS SOLID TOP + OVEN 800 MM AUSTRALIA
371218 E7STGL301A k ELX GAS 2 BURN. + OVEN + OPEN BURN 1200MM
AUSTRALIA
372008 Z7STGH10G0 d ZAN GAS SOLID TOP + OVEN 800 MM
372009 Z7STGH30G0 e ZAN GAS 2 BURNERS + OVEN 800 MM
372010 Z7STGL3010 f ZAN GAS 2 BURN. + OVEN + OPEN BURN.1200MM
372217 Z7STGH10GA l ZAN GAS SOLID TOP + OVEN 800 MM AUSTRALIA
373008 A7STGH10G0 g OEM GAS SOLID TOP + OVEN 800 MM
373009 A7STGH30G0 h OEM GAS 2 BURNERS + OVEN 800 MM
373010 A7STGL3010 i OEM GAS 2 BURN. + OVEN + OPEN BURN.1200MM
Pag Index Indice Note
2,3
5,6
7,8,9
General components
4
Gas components
Pilot / Burner Nozzle
Spare parts list
Componenti struttura
Componenti Gas
Tabelle ugelli
Lista ricambi
Brand/Marchio: All
Factory code: 9PDX
From sr. Nr/ Da Ser. Nr.:016 Page: 1
DATE. 2015 12
Doc. Nr.:
059785DU00
From sr. Nr/ Da Ser. Nr.:016 Page: 2
DATE. 2015 12
Doc. Nr.:
059785DU00
From sr. Nr/ Da Ser. Nr.:016 Page: 3
DATE. 2015 12
Doc. Nr.:
059785DU00
118
94
84
115
110
105
85
112
104
117
105
121
84
107
E
84
71
A
117
H
118
115
112
110
81
D
88
87
104
82
70
120
106
121
79
89
119
76
72
73
93
91
120
121
90
101
81
100
122
95
96
97
98
84
85
99
82
83
123
F
86
84
83
81
74
G
124
106 / 107
139
138
98
135
80
142
C
84
127
86
99
97
132
94
B
103
134
94
From sr. Nr/ Da Ser. Nr.:016 Page: 4
DATE. 2015 12
128
133
131
127
130
84
86
129
140
126
125
Doc. Nr.:
108
059785DU00
A - Ugello bruciatore / Burner nozzle ø60
6DGT Code Ref. / Notes
0C2809 ø1.85 2H/2E+ G20 20mbar
0C2808 ø1.75 2H G20 25mbar
0C2806 ø1.85/2.10 2ELL G25 20mbar
0C2805 ø1.75/2.10 2L G25 25mbar
059314 ø1.15 3+3B/P G30 30mbar
0A2076 ø1.10 3B/P G30 36mbar
0C2807 ø1.10 3B/P G30 50mbar
0C2805 ø1.75/2.10 2S G25.1 25mbar
0C5475 ø3.50 1a G110
0C3658 ø3.30 1b G120
D - Vite di minimo / Min screw ø60
6DGT Code Ref./ Notes
002899 n°80 2H/2E+ G20 20mbar
002899 n°80 2H G20 25mbar
002899 n°80 2ELL G25 20mbar
002899 n°80 2L G25 25mbar
002911 n°55 3+3B/P G30 30mbar
002911 n°55 3B/P G30 36mbar
002925 n°50 3B/P G30 50mbar
002899 n°80 2S G25.1 25mbar
- adj 1a G110
- adj 1b G120
E - Pilota fuochi / Pilot nozzle open burner
6DGT Code Ref./ Notes
053670 n°41 2H/2E+ G20 20mbar
053670 n°41 2H G20 25mbar
053670 n°41 2ELL G25 20mbar
053670 n°41 2L G25 25mbar
054593 n°25 3+3B/P G30 30mbar
054593 n°25 3B/P G30 36mbar
054593 n°25 3B/P G30 50mbar
053670 n°41 2S G25 25mbar
053669 n°75 1a G110
053669 n°75 1b G120
From sr. Nr/ Da Ser. Nr.:016 Page: 5
DATE. 2015 12
Doc. Nr.:
059785DU00
B - Ugello FORNO / Burner nozzle OVEN
6DGT Code Ref. / Notes
0C0509 ø1.85 2H/2E+ G20 20mbar
003723 ø1.75 2H G20 25mbar
0A5165 ø2.10 2ELL G25 20mbar
0C2811 ø2 2L G25 25mbar
059804 ø1.25 3+3B/P G30 30mbar
0C2810 ø1.20 3B/P G30 36mbar
054082 ø1.10 3B/P G30 50mbar
0C2811 ø2 2S G25.1 25mbar 059215 n°27 2S G25.1 25mbar
055133 ø3.80 1a G110
054128 ø3.40 1b G120
H - Ugello TuttaPiastra / Burner nozzle
SolidTop 400 mm
6DGT Code Ref. / Notes
0A2082 ø1.40 2H/2E+ G20 20mbar
002393 ø1.30 2H G20 25mbar
0A2103 ø1.55 2ELL G25 20mbar
0A2091 ø1.45 2L G25 25mbar
0A2091 ø1.45 2S G25.1 25mbar
0A2088 ø0.95 3+3B/P G30 30mbar
003397 ø0.90 3B/P G30 36mbar
059357 ø0.85 3B/P G30 50mbar
059383 ø2.80 No CE G110
F - Pilota TuttaPiastra / Pilot nozzle SolidTop
400 mm
6DGT Code Ref./ Notes
059215 n°27 2H/2E+ G20 20mbar
059215 n°27 2H G20 25mbar
059215 n°27 2ELL G25 20mbar
059215 n°27 2L G25 25mbar
059215 n°27 2S G25.1 25mbar
059216 n°14 3+3B/P G30 30mbar
059216 n°14 3B/P G30 36mbar
059216 n°14 3B/P G30 50mbar
059381 n°75 No CE G110
C - Ugello pilota FORNO / Pilot nozzle OVEN
6DGT Code Ref./ Notes
059215 n°27 2H/2E+ G20 20mbar
059215 n°27 2H G20 25mbar
059215 n°27 2ELL G25 20mbar
059215 n°27 2L G25 25mbar
059216 n°14 3+3B/P G30 30mbar
059216 n°14 3B/P G30 36mbar
059216 n°14 3B/P G30 50mbar
059356 n°50 1a G110
059356 n°50 1b G120
H - Ugello TuttaPiastra / Burner nozzle SolidTop
800 mm
6DGT Code Ref. / Notes
0A2301 ø1.95 2H/2E+ G20 20mbar
0A2077 ø1.85 2H G20 25mbar
0A2083 ø2.20 2ELL G25 20mbar
0A2105 ø2.10 2L G25 25mbar
0A2105 ø2.10 2S G25.1 25mbar
0A2533 ø1.35 3+3B/P G30 30mbar
0A2101 ø1.25 3B/P G30 36mbar
059314 ø1.15 3B/P G30 50mbar
0C0703 ø4.20 No CE G110
F - Pilota TuttaPiastra / Pilot nozzle SolidTop
800 mm
6DGT Code Ref./ Notes
059215 n°27 2H/2E+ G20 20mbar
059215 n°27 2H G20 25mbar
059215 n°27 2ELL G25 20mbar
059215 n°27 2L G25 25mbar
059215 n°27 2S G25.1 25mbar
059216 n°14 3+3B/P G30 30mbar
059216 n°14 3B/P G30 36mbar
059216 n°14 3B/P G30 50mbar
059381 n°75 No CE G110
G - Vite di minimo T.P. / Min screw SolidTop
400 mm
6DGT Code Ref./ Notes
002902 n°105 2H/2E+ G20 20mbar
002902 n°105 2H G20 25mbar
002902 n°105 2ELL G25 20mbar
002902 n°105 2L G25 25mbar
002902 n°105 2S G25.1 25mbar
002908 n° 70 3+3B/P G30 30mbar
002908 n° 70 3B/P G30 36mbar
002904 n° 60 3B/P G30 50mbar
- adjust No CE G110
G - Vite di minimo T.P. / Min screw SolidTop
800 mm
6DGT Code Ref./ Notes
0C1326 n°120 2H/2E+ G20 20mbar
0C1326 n°120 2H G20 25mbar
0C1326 n°120 2ELL G25 20mbar
0C1326 n°120 2L G25 25mbar
0C1326 n°120 2S G25.1 25mbar
002899 n° 80 3+3B/P G30 30mbar
002899 n° 80 3B/P G30 36mbar
002908 n° 70 3B/P G30 50mbar
- adjust No CE G110
From sr. Nr/ Da Ser. Nr.:016 Page: 6
DATE. 2015 12
Doc. Nr.:
059785DU00
TUTTAPIASTRA GAS E700XP
GAS SOLID TOP E700XP
Factory
Pos
Code
1 0835856900 0C0204 PIEDE FOOT
1 0315252601 026806 PIEDE FOOT m
1a 050589CD00 * PIASTRA DI RINFORZO PER PIEDE PLATE FOR FOOT
2 085089FF00 * RIVESTIMENTO LATERALE 800 MM EXTERNAL PANEL 800 MM ELX
2 085089FB00 * RIVESTIMENTO LATERALE 800 MM EXTERNAL PANEL 800 MM ZAN, OEM
2 085089FG01 * RIVESTIMENTO LATERALE 1200 MM EXTERNAL PANEL 1200 MM ELX
2 085089FK00 * RIVESTIMENTO LATERALE 1200 MM EXTERNAL PANEL 1200 MM ZAN, OEM
2 085089F901 *
3 0510814800 002529 SEMIPIASTRA ANTERIORE FRONT HALF PLATE CAST IRON
4 0510814901 002530 SEMIPIASTRA POSTERIORE REAR HALF PLATE CAST IRON
5 0510815000 002531 TAMPONE DISK, PLATE b, e, h, m
6 0530R01701 0C6891 BLOCCHETTO MANIGLIA HANDLE SUPPORT ELX
7 0530R01801 0C6823 TAPPO CHIUSURA MANIGLIA STOPPER FOR HANDLE ELX
8 087089AC00 0C7726
8 087089MH00 0C7927
8 087089A801 0C7722
8 087089MJ00 0C7928
8 087089AB00 0C7725
8 087089MM00 0C7929
8 087089NC01 0C8376 RIPIANO 4B 1200mm WORKTOP 4B 1200mm m
9 085089JQ02 0C8042 CRUSCOTTO TUTTAP. su FORNO CONTR. PANEL SOLID TOP on OVEN ELX 800mm
9 085089JR00 0C8046 CRUSCOTTO TUTTAP. su FORNO CONTR. PANEL SOLID TOP on OVEN ZAN 800mm
9 050389UM00 0C8045 CRUSCOTTO TUTTAP. su FORNO CONTR.PANEL SOLID TOP on OVEN OEM 800mm
9 085089JS00 0C8043 CRUSCOTTO TUTTAP. 2B su FORNO C. PANEL SOLID TOP 2B on OVEN
9 085089JT00 * CRUSCOTTO TUTTAP. 2Bsu FORNO C. PANEL SOLID TOP 2B on OVEN
9 088839K00 * CRUSCOTTO TUTTAP. 2B su FORNO C.PANEL SOLID TOP 2B on OVEN
9 085089J100 0C7892 CRUSCOTTO TUTTAP. 2B su FORNO C. PANEL SOLID TOP 2B on OVEN
9 085589CW00 0C7899 CRUSCOTTO TUTTAP. 2Bsu FORNO C. PANEL SOLID TOP 2B on OVEN
9 0800839Y00 * CRUSCOTTO TUTTAP. 2B su FORNO C.PANEL SOLID TOP 2B on OVEN
9 085089K102 0C8362 CRUSCOTTO 4B C.PANEL 4B m
10 0527850500 0C0156 PIASTRA FISSAGGIO FIANCHI SIDE PANEL JOINTING PLATE
11
12 0510805101 054823 PIASTRA RADIANTE DESTRA RIGHT PLATE CAST IRON
13 0210026714 050803 DISCO RADIANTE DISK, PLATE
13a 0330294200 001158 GANCIO SOLLEVADISCO RINGS HOOK
14 0510805201 054824 PIASTRA RADIANTE SINISTRA LEFT PLATE CAST IRON
15 0511821400 0C2526 GRIGLIA FUOCHI GRID OPEN BURNER
16 050389LP00 0C7333 GRIGLIA CAMINO GRATE FOR CHIMNEY 800mm + m
16 050389LM00 0C7705 GRIGLIA CAMINO GRATE FOR CHIMNEY 1200mm
17 0511850D02 0C7330 MANOPOLA PER RUBINETTO GAS KNOB, GAS COCK ELX up to 2201
054887AV00 0C8645 MANOPOLA+ADATTATORE Ø8 KNOB+ ADAPTER Ø8
17
054887AP00 0C8714 ADATTATORE Ø8 ADAPTER Ø8
17a
17 0548878101 0C7425 MANOPOLA PER RUBINETTO GAS KNOB, GAS COCK ZAN
17 0548865700 0C1380 MANOPOLA PER RUBINETTO GAS KNOB, GAS COCK OEM up to 1361
17 0548865600 0C1007 MANOPOLA PER RUBINETTO GAS KNOB, GAS COCK OEM from 1371
18 0548876S00 0C6671 GHIERA FUOCO ANTERIORE RING KNOB, FRONT BURNER ELX
6DGT
Code
Descrizione Description Ref./Note
RIVESTIMENTO LATERALE TOP
1200
RIPIANO TUTTAPIASTRA su FORNO
800mm
RIPIANO TUTTAPIASTRA su FORNO
800mm
RIPIANO TUTTAPIASTRA 2B su
FORNO 800mm
RIPIANO TUTTAPIASTRA 2B su
FORNO 800mm
RIPIANO TUTTAPIASTRA 2B su
FORNO 1200mm
RIPIANO TUTTAPIASTRA 2B su
FORNO 1200mm
EXTERNAL PANEL TOP 1200 m
b, e, h, m
b, e, h, m
WORKTOP SOLIDTOP on OVEN
800mm
WORKTOP SOLIDTOP on OVEN
800mm
WORKTOP SOLIDTOP 2B on OVEN
800mm
WORKTOP SOLIDTOP 2B on OVEN
800mm
WORKTOP SOLIDTOP 2B on OVEN
1200mm
WORKTOP SOLIDTOP 2B on OVEN
1200mm
ELX
ZAN, OEM
ELX
ZAN, OEM
ELX
ZAN, OEM
ELX - 2 Burner+oven
800mm
ZAN - 2 Burner+oven
800mm
OEM - 2 Burner+oven
800mm
ELX - 2 Burner+oven
1200mm
ZAN-2 Burner+oven
1200mm
OEM-2 Burner+oven
1200mm
ELX from 2211
ELX from 2211
From sr. Nr/ Da Ser. Nr.:016 Page: 7
DATE. 2015 12
Doc. Nr.:
059785DU00
TUTTAPIASTRA GAS E700XP
GAS SOLID TOP E700XP
Factory
Pos
Code
18 0548879F00 0C7243 GHIERA FUOCO ANTERIORE RING KNOB, FRONT BURNER ZAN, OEM
19 0548876T00 0C7332 GHIERA FUOCO POSTERIORE RING KNOB, REAR BURNER ELX
19 0548879G00 0C7244 GHIERA FUOCO POSTERIORE RING KNOB, REAR BURNER ZAN, OEM
20 0218912211 069567 MOLLETTA PER GHIERA RING, RING KNOB
21 0511850D02 0C7330 MANOPOLA TERMOST. VALVOLA KNOB, GAS VALVE THERMOSTAT ELX up to 2201
054887AV00 0C8645 MANOPOLA+ADATTATORE Ø8 KNOB+ ADAPTER Ø8
21
054887AP00 0C8714 ADATTATORE Ø8 ADAPTER Ø8
21a
21 0548877Z01 0C7179 MANOPOLA TERMOST. VALVOLA KNOB, GAS VALVE THERMOSTAT ZAN
21 0548872700 0C5252 MANOPOLA TERMOST. VALVOLA KNOB, GAS VALVE THERMOSTAT OEM
22 0548863303 0C2021 MANOPOLA ACCENDITORE VALV. KNOB. GAS VALVE IGNITER ELX
22 548878303 0C7181 MANOPOLA ACCENDITORE VALV. KNOB. GAS VALVE IGNITER ZAN
22 0548856603 0C0190 MANOPOLA ACCENDITORE VALV. KNOB. GAS VALVE IGNITER OEM
23 0548877401 0C7342 GHIERA PER VALVOLA FORNO KNOB RING. GAS VALVE OVEN ELX
23 0548879700 0C7241 GHIERA PER VALVOLA FORNO KNOB RING. GAS VALVE OVEN ZAN, OEM
24
25 0538831100 0C6445 GRIGLIA PROTEZIONE BULBO GRILL, PROTECTION PROBE
26
27 050389G501 0C7272 PORTA FORNO DOOR, OVEN
28 050389G600 0C7273 CONTROPORTA INNER DOOR OVEN
29 0560839601 0C0197 ISOLAMENTO PORTA FORNO INSULATION, OVEN DOOR
29a 0560802101 0C2305 ISOLAMENTO CIELO FORNO INSULATION, OVEN TOP
30 051589A500 0C7274 MANIGLIA FORNO HANDLE, OVEN DOOR ELX
30 051589A601 0C7226 MANIGLIA FORNO HANDLE, OVEN DOOR ZAN
30 083089FY00 0C7946 MANIGLIA FORNO HANDLE, OVEN DOOR OEM
* 085589A300 0C7271 ASSIEME PORTA FORNO COMPLETE DOOR ELX
* 085589CH01 0C7276 ASSIEME PORTA FORNO COMPLETE DOOR ZAN
* 085589CQ00 0C7278 ASSIEME PORTA FORNO COMPLETE DOOR OEM
31 0835848100 0C0203 CERNIERA PORTA FORNO HINGE, OVEN DOOR
32 0205075423 052725 COPRICERNIERA HINGE COVER
33 051489AA00 0C6446 GUIDA PER GRIGLIA FORNO GRATE LEADING
33 051489AG00 0C6454 GUIDA PER GRIGLIA FORNO GRATE LEADING AUSTRALIA
34 0330260842 025020 GRIGLIA FORNO GRID; OVEN
34 856814402 0C6455 GRIGLIA FORNO GRID; OVEN AUSTRALIA
35 0500847401 054114 SUOLA SOLE
36 0315280702 050761 COPERTURA FORO PILOTA COVERING, PILOT
39 0522891100 * FONDO VANO 1200 MM BOTTOM CUPBOARD 1200 MM
41 0522891200 * CELLA VANO CELL CUPBOARD
42 0830898200 0C0201 MAGNETE PORTA MAGNET, DOOR
43 050389G300 0C7157 PORTA SINISTRA LEFT DOOR, CUPBOARD
44 050489CQ00 0C7158 CONTROPORTA INNER DOOR
45 051589A700 0C7164 MANIGLIA PORTA SINISTRA HANDLE, LEFT DOOR ELX
45 054887A800 0C8190 MANIGLIA PORTA SINISTRA HANDLE, LEFT DOOR ZAN
45 0854864203 0A5021 MANIGLIA PORTA SINISTRA HANDLE, LEFT DOOR OEM
* 085589CT01 0C7163 ASSIEME PORTA VANO COMPLETE DOOR ELX
* 085589CV00 0C7627 ASSIEME PORTA VANO COMPLETE DOOR OEM
46 0516860801 0C0138 CERNIERA INFERIORE DESTRA BOTTOM HINGE, RIGHT
47 0516860901 0C0139 CERNIERA SUPERIORE DESTRA TOP HINGE, RIGHT
48 0529835402 0C0165 SUPPORTO CERNIERA FORNO SUPPORT FOR HINGE, DOOR OVEN
50 0516860700 0C0137 PIASTRA GIUNZIONE APPARECC. JOINTING REAR PLATE
51 0870838206 0C0218 FACCIATA FORNO 800mm FRONT OVEN 800mm
51 0870838306 0C0219 FACCIATA FORNO 1200mm FRONT OVEN 1200mm
52 0529850500 0C0182 PIASTRINA FACCIATA FIANCO PLATE FRONT OVEN
53 0522882600 * INVOLUCRO FORNO GAS OVEN SHELL
54 0522882700 * SCHIENALE FORNO GAS REAR SIDE PANEL OVEN
56 0522891101 * FONDO VANO BORROM PANEL TOP 800mm
56 05038A2600 * FONDO MONOBLOCCO 800mm BOTTOM PANEL FREEST. 800mm
56 05038A2702 * FONDO MONOBLOCCO 1200mm BOTTOM PANEL FREEST. 1200mm
56 50389WD00 0C7391 FONDO GAS TOP BOTTOM PANEL GAS TOP m
57 0543815000 059293 GUARNIZIONE OR GASKET OR
From sr. Nr/ Da Ser. Nr.:016 Page: 8
DATE. 2015 12
6DGT
Code
Descrizione Description Ref./Note
ELX from 2211
ELX from 2211
Doc. Nr.:
059785DU00
TUTTAPIASTRA GAS E700XP
GAS SOLID TOP E700XP
Factory
Pos
Code
70 0533825302 * ANTERIORE CAMINO FORNO FRONT CHIMNEY OVEN
71 0533825401 * POSTERIORE CAMINO FORNO REAR CHIMNEY OVEN
71 0533828100 * CAMINO TUTTA PIASTRA CHIMNEY SOLID TOP
72 0533828001 * CAMERA COMBUSTIONE COMBUSTION CHAMBER
72 0533828500 * CAMERA COMBUSTIONE SS 800 COMBUSTION CHAMBER SS800
73 0533828200 * ANTERIORE CAMINO FRONT PANEL CHIMNEY
74 0543844000 0C6971 GUARNIZIONE GASKET
79 0853864402 0C0793 RIBALTA TUTTAPIASTRA MANIFOLD SOLID
79 0853864402 0C0793 RIBALTA TUTTAPIASTRA SU FORNO MANIFOLD SOLIDTOP on OVEN
79 0853864502 0C0794 RIBALTA SIMPLESERVICE SU FORNO MANIFOLD SIMPLE SERV. ON OVEN
79 0853883400 0C2977 RIBALTA TUTTAP. SIMPLE SERVICE MANIFOLD SOLIDTOP SIMPLE SERV.
79 085589DP00 0C7589 RIBALTA 4B MANIFOLD 4B m
80 0516863900 0C0140 FILTRO FILTER
81 0835857201 0C0205 RUBINETTO GAS GAS TAP
82 0853898400 0C2978 CONDUTTURA GAS BRUCIATORE GAS PIPE, BURNER
82 0853895100 0C2979
83 0517898601 0C3633 CONDUTTURA PI LOTA GAS PIPE, PILOT
83 0517898701 0C3639 CONDUTTURA PILOTA 1200MM GAS PIPE, PILOT 1200MM b, e, h, m
84 0214164400 052125 RACCORDO PILOTA PIPE FITTING PILOT PIPE
85 0215199700 052127 BICONO RUBINETTO DOUBLE CONE, GAS TAP
86 0517808700 059161 BICONO PILOTA DOUBLE CONE, PILOT
87 0511805801 059375 PORTAUGELLO INJECTOR HOLDER
88 0214105101 020997 CONTRODADO PORTAUGELLO LOCK NUT, INJECTOR HOLDER
89 510817900 004279 BRUCIATORE BURNER a, c, d, f, g, i, j, k
89 510817900 005502 BRUCIATORE BURNER b, e, h, m
90 0510818001 004280 SPARTIFIAMMA FLAME SPREADER
91 0506841000 054536 DISCO PER BRUCIATORE DISK, BURNER
93 0206993401 052116 BOCCOLA BUSH
94 0830884101 005503 PILOTA PILOT BURNER
95 0528866100 0C6442 SUPPORTO PILOTA HOLDER PILOT
96 0831800500 0C0202 TERMOCOPPIA THERMOCOUPLE
96 0830853101 051119 TERMOCOPPIA THERMOCOUPLE b, e, h, m
97 0214162000 0C0121 RACCORDO TERMOCOPPIA PIPE FITTING, THERMOCOUPLE
98 0830863300 059380 ELETTRODO ELECTRODE
99 0214164101 057960 RACCORDO ELETTRODO PIPE FITTING, ELECTRODE
100 0835834900 002605 ACCENDITORE PIEZO PIEZOELECTRIC IGNITER
101 0638883500 006514 CAVO IGNITION CABLE
102 0541809000 002816 COPERTURA PULSANTE PIEZO COVER, PIEZO
103 0506833401 054029 GUARNIZIONE UGELLO GASKET, INJECTOR
104 0835868100 0C2799 CONDUTTURA ANTERIORE FUOCHI PIPE, FRONTAL OPEN BURNER
105 0835868202 0C2800 CONDUTTURA POSTERIORE FUOCHI PIPE, REAR OPEN BURNER
106 0544821000 0C4192
106 051589BJ00 0C9553
106 0544820900 0C4193
106 051589BH00 0C9552
107 0510823900 0C3643 RACCORDO INFERIORE PILOTA INFERIOR PILOT JUNCTION
108 0835859300 0C0209 VALVOLA GAS MERTIK GAS VALVE MERTIK Up to 814
108 0835859302 0C5247 VALVOLA GAS MERTIK GAS VALVE MERTIK From 815
108 0835865602 0C5250 VALVOLA GAS MERTIK GAS VALVE MERTIK AUSTRALIA
109 0515827401 053665 BICONO DOUBLE CONE
110 0510819003 0C0124 SUPPORTO VENTURI SUPPORT, VENTURI
112 0510819103 0C0125 VENTURI 6 KW VENTURI, 6 KW
115 0510819303 0C0127 CORPO BRUCIATORE 6KW BURNER 6KW
117 0510819501 0C0129 SPARTIFIAMMA 6kW FLAME SPREADER 6kW
118 0830884101 0C7102 PILOTA PILOT BURNER
6DGT
Code
Descrizione Description Ref./Note
CONDUTTURA GAS SIMPLE
SERVICE
CONDUTTURA ANTERIORE
PILOTA
CONDUTTURA ANTERIORE
PILOTA
CONDUTTURA POSTERIORE
PILOTA
CONDUTTURA POSTERIORE
PILOTA
GAS PIPE, SIMPLE SERVICE b, e, h, m
PIPE, FRONTAL PILOT Up to 3281
PIPE, FRONTAL PILOT From 3291
PIPE, REAR PILOT Up to 3281
PIPE, REAR PILOT From 3291
From sr. Nr/ Da Ser. Nr.:016 Page: 9
DATE. 2015 12
Doc. Nr.:
059785DU00
TUTTAPIASTRA GAS E700XP
GAS SOLID TOP E700XP
Factory
Pos
Code
119 0831800500 0C0202 TERMOCOPPIA THERMOCOUPLE
120 0514862501 051950 RACCORDO VALVOLA - RIBALTA PIPE FITT. MAINFOLD - GAS VALVE
121 0215170716 050682 OGIVA VALVOLA - RIBALTA RING , MAINFOLD - GAS VALVE
122 0835857602 0C0208 CONDUTTURA FORNO PIPE, OVEN
123 0516869500 0C0149 RACCORDO VALVOLA - COND.FORNO PIPE FITTING, GAS VALVE - OVEN
124 0516869600 0C0150 BICONO VALVOLA - COND.FORNO DOUBLE CONE, GAS VALVE - OVEN
125 0514829301 0A2125 DADO, CONDUTTURA FORNO NUT, OVEN PIPE
126 0215073101 060325 BICONO, CONDUTTURA FORNO DOUBLE CONE, OVEN PIPE
127 0544820800 0C0153 CONDUTTURA PILOTA PIPE, PILOT
128 0831823400 0C3584 BRUCIATORE FORNO OVEN BURNER
129 0511805401 059250 PORTAUGELLO INJECTOR HOLDER
130 0214105101 020997 CONTRODADO LOCK NUT
131 0830827102 054085 AREATORE AREATOR
132 0830852501 020094 TERMOCOPPIA FORNO THERMOCOUPLE OVEN
133 0529836201 0C0171 SQUADRETTA PILOTA BRACKET, PILOT
134 0529836300 0C0172 PROTEZIONE PILOTA PROTECTION, PILOT
135
0533819600 0C3472
138 0533814300 0C2823 CONVOGLIATORE BRUCIATORE PROTECTION, BURNER
139 0529836000 0C0169 CHIUSURA PER CONVOGLIATORE PROTECTION TIGHTENER
140 0529836101 0C0170 CHIUSURA PER BRUCIATORE OVEN BURNER TIGHTENER
0525867300 0A5415
141
142 0246519800 0C2356 TAPPO PER RIBALTA MANIFOLD STOPPER
143 0533828400 * PARETE SUP. CAMINO UPPER PANEL, CHIMNEY b, m, e, h
6DGT
Code
Descrizione Description Ref./Note
PARAFIAMMA BRUCIATORE FORNO FLAME SPREADER, OVEN
PARAFIAMMA CAMERA COMB. FIREPROOF COMBUSTION CHAMBER
From sr. Nr/ Da Ser. Nr.:016 Page: 10
DATE. 2015 12
Doc. Nr.:
059785DU00
Loading...
