From sr. Nr/ Da Ser. Nr.: ***
SPARE PARTS CATALOGUE
190026
AOS202EBA2
e1
AOS
Level B
2…11
230V 3N 50/60 HZ
236205
FCZ202EKA
q
FCZ
Level K
2…11
STD (400V - 3N)
237205
FCZ202ETA
i
FCZ
Touch
2…11
STD (400V - 3N)
238205
FCZ202EBA2
l
FCZ
Level B
2…11
STD (400V - 3N)
239205
FCZ202ECA2
m
FCZ
Level C
2…11
STD (400V - 3N)
266205
AOS202EKA1
p
AOS
Level K
2… 11
STD (400V - 3N)
266355
AOS202EKR1
a1
AOS
Level K
2…11
400V 3N 50/60 HZ AUS
267205
AOS202ETA1
a
AOS
Touch
2…11
STD (400V - 3N)
267235
AOS202ETC1
e
AOS
Touch
2…11
200V 3N 50/60 HZ JAPAN
267285
AOS202ETM1
b
AOS
Touch
2…11
America (208V - 3)
267305
AOS202ETK1
d
AOS
Touch
2…11
UK (400V - 3N)
267325
AOS202ETV1
n
AOS
Touch
2… 11
USA (480V - 3)
267355
AOS202ETR1
b1
AOS
Touch
2…11
400V 3N 50/60 HZ AUS
268205
AOS202EBA2
f
AOS
Level B
2…11
STD (400V - 3N)
268235
AOS202EBC2
r
AOS
Level B
2…11
200V 3N 50/60 HZ JAPAN
268305
AOS202EBH2
g
AOS
Level B
2…11
UK (400V - 3N)
268355
AOS202EBR2
c1
AOS
Level B
2…11
400V 3N 50/60 HZ AUS
269205
AOS202ECA2
h
AOS
Level C
2…11
STD (400V - 3N)
269305
AOS202ECK2
o
AOS
Level C
2…11
UK (400V - 3N)
269355
AOS202ECR2
d1
AOS
Level C
2…11
400V 3N 50/60 HZ AUS
Pag
Index
Indice
Note
2
Oven cabinet and door.
Cella forno e porta
Brand/Marchio: All
Factory code: 9PDD
CATALOGO PARTI DI RICAMBIO
20 GN 2/1 ELECTRIC CONVECTION / STEAM OVEN
FORNO CONVEZIONE / VAPORE ELETTRICO 20 GN 2/1
PNC Model Ref Group Level Page Notes
3
4
5
6
7...11
From status level / Da scatto: 07 Page: 1 Ed. 2015 12
Water system
Boiler
Electrical components
Accessories
Spare parts list
Impianto idraulico
Boiler
Componenti elettrici
Accessori
Lista ricambi
Doc. Nr.:
875400Y00
From sr. Nr/ Da Ser. Nr.: ***
From status level / Da scatto: 07 Page: 2 Ed. 2015 12
Doc. Nr.:
875400Y00
From sr. Nr/ Da Ser. Nr.: ***
From status level / Da scatto: 07 Page: 3 Ed. 2015 12
Doc. Nr.:
875400Y00
From sr. Nr/ Da Ser. Nr.: ***
From status level / Da scatto: 07 Page: 4 Ed. 2015 12
Doc. Nr.:
875400Y00
From sr. Nr/ Da Ser. Nr.: ***
From status level / Da scatto: 07 Page: 5 Ed. 2015 12
Doc. Nr.:
875400Y00
From sr. Nr/ Da Ser. Nr.: ***
From status level / Da scatto: 07 Page: 6 Ed. 2015 12
Doc. Nr.:
875400Y00
From sr. Nr/ Da Ser. Nr.: ***
Pos
Factory Code
6DGT
Code
Descrizione
Description
Ref./Note
Pagina 2
Page 2
1
0530892000
0C6184
COPERCHIO
COVER
1
0873871302
0C4305
COPERCHIO
COVER
For Lev. C,K
2
0538832100
0C6206
FIANCO DX
RIGHT SIDE PANEL
3
0538834100
0C6208
SCHIENALE
BACK PANEL
4
0538834600
0C6210
FIANCO SX
LEFT SIDE PANEL
5
0806871700
0C4824
PIEDE
FOOT
6
0512816003
007086
CERNIERA SUPERIORE
UPPER HINGE
8
0873870202
0C4870
VETRO INTERNO
INNER GLASS
9
0873860410
0C5068
PORTA COMPLETA
COMPLETE DOOR
10
0530873600
0C4970
PROFILO FERMAVETRO DX
RIGHT TRIM
10
0530873700
0C4971
PROFILO FERMAVETRO SX
LEFT TRIM
11
0574400600
0C6562
VETRO ESTERNO
EXTERNAL GLASS
For AOS
11
0574818801
0C4946
VETRO ESTERNO
EXTERNAL GLASS
12
0543828001
006976
AMMORIZZATORE
DAMPER
*
0856808701
0C4119
ASSIEME CHIUSURA
ASS LOCK MECHANISM
13
13a
0853821500
0806873501
003824
0C8627
CORPO CHIUSURA
BOCCOLA
CORE DOOR LOCK MECHANISM
BUSH 14
0806822000
007007
CERNIERA VETRO INTERNO
HINGE, INNER GLASS
15
0853821600
003822
MECCANISMO DI ES T R E MIT A '
HOOK
16
0538804900
0C3802
NASELLO CHIUSURA PORTA
CATCH DOOR CLOSING
18
0513800501
0C4309
ASTA SUPERIORE
SUP. LEVER DOOR LOCK MEC.
20
0214593100
0H6043
SPINA ELASTICA
ELASTIC PIN
21
0513801100
0C4310
ASTA INFERIORE
INF. LEVER DOOR LOCK MEC.
22
0543839700
0C4088
GUARNIZIONE FLANGIA SPILLONE
GASKET
23
0543835100
0C1889
GUARNIZIONE CELLA
CAVITY GASKET
24
0831847304
0C4622
PARETE DI ASPIRAZIONE
SUCTION WALL
26
0518808700
0C2769
FILTRO FONDO
FILTER
27
0654600000
049621
INTERRUTTOR E MA G NETICO
MAGNETIC SWITCH
28
0830400B00
0C6574
SONDA SPILLONE (6 PUNTI)
MEAT PROBE (6 POINTS)
For Level Touch
28
0830400A00
0C6573
SONDA SPILLONE (1 PUNTO)
MEAT PROBE (SINGLE POINT)
For Level B, C,K
29
0527865201
0C1505
SUPPORTO SPILLONE
MEAT PROBE SUPPORT
30
0543838001
0C4131
GUARNIZIONE
GASKET
31
0510815700
002653
POSIZIONATORE
POSITIONER
32
0516855300
006991
DADO SONDA CELLA
NUT, CAVITY PROBE
33
0543842600
0C4872
TAPPO PER SENSORE
STOPPER FOR SENSOR
34
0214105101
020997
CONTRODADO
LOCK NUT
35
0508838701
002700
RONDELLA
WASHER
36
0516809301
002701
TENUTA
GASKET
37
0516809400
002623
RACCORDO SONDA CELLA
CONNECTION, CAVITY PROBE
41
0806857201
0C4244
CONDOTTO SONDA LAMBDA
DUCT, LAMBDA PROBE
42
0543838300
0C4093
GUARNIZIONE
GASKET
43
0538807400
0C4122
DISTANZIALE 20/10
SPACER 20/10
44
0617828000
0C1173
RESISTENZA (8 kW/400V)
HEATING ELEMENT (8 kW/400V)
44
0617829300
0C2241
RESISTENZA (8 kW/208V USA)
HEAT. ELEMENT (8 kW/208V USA)
For 208V Version
44
0617400901
0C2242
0C6502
RESISTENZA CELLA(8kw/400V)
HEAT. ELEMENT (8 kW/400V)
For 240V Version
44
0617830000
0C1806
RESISTENZA (8 kW/230V)
HEATING ELEMENT (8
kW/230V)
For e1
45
0806856300
0C4311
CONDOTTO BY-PASS
BY-PASS DUCT
For Level B
46
0543832100
0C1194
GUARNIZIONE CONDOTTO ARIA
GASKET
47
0611810000
0C6563
MOTORE
MOTOR
47 0611400500
0C6704
MOTORE
MOTOR
For 208V,240V 60Hz,
Japan Version
48
0543816700
002873
O RING
O RING
49
0516808902
002699
CUSCINETTO
BEARING
20 GN 2/1 ELECTRIC CONVECTION / STEAMER OVEN
FORNO CONVEZIONE / VAPORE ELETTRICO 20 GN 1/1
7 0806843301 0C2483 CERNIERA INFERIORE LOWER HIGE
For FCZ
44
44
0617829900
0617400C00
0C9858
RESISTENZA (8 kW/240 V USA)
RESISTENZA CELLA(8kw/200V)
HEAT. ELEMENT (8 kW/240V USA)
HEAT. ELEMENT(8 kW/200V)
For Level Touch
For 400V Version
For Japan Version
For a-d-f-g-i-l-p-q
From status level / Da scatto: 07 Page: 7 Ed. 2015 12
Doc. Nr.:
875400Y00
From sr. Nr/ Da Ser. Nr.: ***
20 GN 2/1 ELECTRIC CONVECTION / STEAMER OVEN
Pos
Factory Code
6DGT
Code
Descrizione
Description
Ref./Note
50
0538815401
0C4138
FLANGIA
FLANGE
51
0835400900
0C6464
VENTOLA
FAN
52
0543816501
002689
GUARNIZION E RES IS T ENZE CELLA
GASKET, CAVITY HEAT. ELEMENT
53
0527833700
0C3830
STAFFA
SUPPORT
54
0503891801
006256
STAFFA
SUPPORT
55
0503897402
006253
ANGOLARE
SUPPORT
56
0699603700
049627
MAGNETE
MAGNET
57
0856828500
0C4976
CONDOTTO UMIDIFICATORE
HUMIDIFIER PIPNG
For Level C,K
58
0516887101
0C6228
DADO CONDOTTO
NUT HUMIDIFIER
For Level C,K
0527898900
0C4857
PIASTRA CHIUSURA
FLANGE
61 - 0C6465
KIT SONDA LAMBDA
LAMBDA KIT
for level TOUCH
63
0830400200
0C6568
MANIGLIA COMPLETA
COMPLETE DOOR HANDLE
for AOS Group
64
0830400N00
0C7028
SENSORE TEMPERATURA
TEMP. PROBE
for level TOUCH
For level B-C-K
65
0830899101
0C6539
SENSORE TEMPERATURA
TEMP. PROBE
66
0543400900
0C7016
GUARNIZIONE PER TUBO
PIPE GASKET
68
0543843201
0C4965
GOMMINO CHIUSURA ING.DISIN
GASKET
Pagina 3
Page 3
100
0696808400
0C5517
ELETTROVALVOLA 2 VIE
WATER VALVE 2 WA YS
for Level Touch,B
101
0543840600
0C4096
GUARNIZIONE FILTRO REFLEX
GASKET
for Level Touch,B
102
0549801800
0C2312
VALVOLA NON RITORNO
NOT RE-FLOW VALVE
for Level Touch,B
103
0516879400
0C2313
RACCORDO ENTRATA ACQUA
PIPE FITTING
for Level Touch,B
104
0543840600
0C4096
ASSIEME FILTRO
FILTER
for Level Touch,B
106
0516896102
0C4198
PORTAGOMMA
CONNECTION
for Level Touch,B
107
0544809000
0C1117
VALVOLA NON RITORNO OF10D
VALVE
for Level Touch,B
108
0516871900
0C1116
RACCORDO PER PO MPA
PUMP CONNECTION
for Level Touch,B
109
0543832300
0C1935
O. RING
OR
for Level Touch,B
110
0680801201
0C2341
POMPA
PUMP
50 Hz
0C5371
KIT POMPA
0C2341+0C1116+0C1935
PUMP KIT
0C2341+0C1116+0C1935
110
0680801301
0C2342
POMPA
PUMP
60 Hz
111
112
113
114
0806871100
0C6031
ASS CONDOTTO BASSO
WASHING PIPING DOWN
115
0806870900
0C6047
ASS.CONDOTTO ALTO
WASHING PIPING UP
116
0805400A00
0C6212
ASS. COLLETORE + TUBI
COLLECTOR+PIPING
Up to 145…
116
0805400A03
0C8185
ASS. COLLETORE + TUBI
COLLECTOR+PIPING
From 146…
118
0543841400
0C4201
ANELLO DI TENUTA
OR
119
0516898301
0C4467
ATTACCO PER GETTO
CONNECTION FOR WASH ARM
120
0516892301
0C4202
DADO
NUT
121
0806873900
0C5503
ASSIEME GETTO RO TA NTE
ROTATING WASHING JET
122
0518807100
007026
MOLLA AGGANCIO GETTO ROTA
SPRING
123
124
0H22982800
007075
TUBO UMIDIFICATORE 57X2/5
PIPING
for Level A,B
124
0856828700
0C4978
TUBO UMIDIFICATORE
PIPING
for Level C,K
125
0831811702
0C1127
GRUPPO COLLEGAMENTO EXT.
EXTERNAL PIPING
126
127
-
-
0C9799
0C9797
TUBO FLESS. 6x8mm rosso
TUBO FLESS.4x6mm rosso
FLEX PIPE 6x8mm red
FLEX PIPE 4x6mm red
127a - 0C9798
TUBO FLESS. 4x6mm blu
FLEX PIPE 4x6mm blue
128
0696808200
0C5515
ELETTROVALVOLA
WATER VALVE
for Level C,K
128
0696808801
0C6170
ELETTROVALVOLA
WATER VALVE
for Level B
129
0696400400
0C6407
GRUPPO VALVOLE CLEANYNG
VALVE GROUP C.S.
for Level C,K
129
0696400200
0C6371
GRUPPO VALVOLE CLEANYNG
VALVE GROUP C.S.
For 60Hz
FORNO CONVEZIONE / VAPORE ELETTRICO 20 GN 1/1
59
63 0806873601 0C8719 MANIGLIA COMPLETA COMPLETE DOOR HANDLE for FCZ Group
64 0830898902 0C6538 SENSORE TEMPERATURA TEMP.PROBE
67 0543816601 002692 TAPPO CARICO DISINCROST. RECHARGE CAP FOR SCALER
For Level C,K
For 50 Hz
126a
From status level / Da scatto: 07 Page: 8 Ed. 2015 12
-
0C9800
TUBO FLESS. 6x8mm blu
FLEX PIPE 6x8mm blue
Doc. Nr.:
875400Y00
From sr. Nr/ Da Ser. Nr.: ***
20 GN 2/1 ELECTRIC CONVECTION / STEAMER OVEN
Pos
Factory Code
6DGT
Code
Descrizione
Description
Ref./Note
129
0696808700
0C6372
GRUPPO VALVOLE CLEANYNG
VALVE GROUP C.S.
130
0831857200
0C6370
ASSIEME COLLETTORE LAVAGGIO
CONNECTION,C.S.
131
0546825100
0C6222
FORCELLA SICUREZZA
CLIP
132
0646817200
0C6217
PRESSOSTATO ATTACCO RAPID
CONNECTION FOR WASH
137 - 0C6375
KIT RIDUTTORI
FLOW REDUCER KIT
138 - 061303
KIT O-RING +BUSSOLA
O-RING +BUSH KIT
139
0219035015
0C6421
ANELLO ELASTICO
ELASTIC RING
141
0544400C01
0C8348
VITE TTL
TTL SCREW
Up to 5151…
141
0544400C02
0CA348
VITE TTL
TTL SCREW
From 5161…
142
0543400R00
0C7925
PASSACAVO
WIRING BUSH
144
0246530100
005382
GOMMINO
GASKET
145
0544819400
0C5829
TUBO EPDM BLU
EPDM PIPE
Up to 4441…
146
0686400201
0CA112
POMPA CEME
CEME PUMP
From 4451…
147
0835400L00
0C8683
GRUPPO ENTRATA ACQUA
GROUP WATER INLET
148
0805400A02
0C8185
ASS. COLLETORE + TUBI
COLLECTOR+PIPING
Pagina 4
Page 4
200
0878401600
0C9665
KIT ASSIEME BOILER
BOILER ASS.Y KIT
201
0569807100
0C5838
KITISOLAMENT O BO ILER EL.
KIT ISOLATION
202
0543816601
002692
TAPPO
STOPPER
203
0543817500
0C7016
GOMMINO CHIUSURA
GASKET
203
0543843200
0C4965
GOMMINO INGRESSO DISINCR.
GASKET
For Lev. C,K
204
0831858600
0C7128
SONDA DI LIVELLO
LEVEL PROBE
205
0516809501
007117
RACCORDO PER VA L VO L A
CONNECTION
206
0696804201
0C0882
VALV.SFERA MOTORIZZATA
DRAIN VALVE
206
0696808500
0C5518
VALV.SFERA MOTORIZZATA
DRAIN VALVE
For 60 Hz Version
207
0511817600
007040
MANICOTTO RIDOTTO
CONNECTION
version
208
0560845602
0C4141
KIT ISOLAMENTO AIR BREAK
KIT ISOLATION
209
0543832400
0C4133
GUARNIZIONE AIR BREAK
AIR BREAK GASKET
210
0543842600
0C4872
TAPPO PER SENSORE
STOPPER FOR SENSOR
211
0527899100
0C4858
FLANGIA CHIUSURA FORO BOILER
FLANGE
212
0543843100
0C4964
GUARN. CHIUSURA FORO BOILER
GASKET
For Lev. C,K
213
0538806601
0C4142
FLANGIA TENUTA BOILER
FLANGE, BOILER
214
0543832500
0C3128
ORTENUTA BOILER
OR BOILER
215
054384480
0C5834
GUARNIZIONE
GASKET
216
0617837200
0C5822
RESIST. BOILER (24 kW/208V USA)
HEATING ELEM. BOIL. 24 kW/208V
For 208V Version
216
216
0617837800
0617839502
0C5825
0C6027
RESIST. BOILER (24 kW/240V USA)
RESIST. BOILER (20kw/200V)
HEATING ELEM. BOIL. 24 kW/240V
HEATING ELEM. BO IL . (2 0k w/ 2 00V)
For 240V Version
For Japan Version
216
0617837502
0C5844
RESIST. BOILER (20kw/230V)
HEATING ELEM.
BOIL.(20kw/230V)
For e1
217
0515857001
055347
DISTANZIALE
SPACER
218
0510828000
0C5564
RESCA D12 FILETT 1/4' GAS
PIPE CONNECTION
219
0516889400
0C3797
UGELLO 'ELPIS'1/4'FD3.5-3/8'M
NOZZLE
220
0543400000
0C7033
GUARNIZIONE PORTELLO
GASKET
for level TOUCH
221
0J89061403
0C3443
PORTELLO ISPEZIONE
INSPECTION COVER
222
Pagina 5
Page 5
300
0806874001
MANOPOLA
HANDLE
FORNO CONVEZIONE / VAPORE ELETTRICO 20 GN 1/1
For level TOUCH,B
140 0505401R00 0C7924 PIASTRINA FISSAGGIO POMPE FIXING PLAQUE
141a 0546400J00 0C9538 CAPPUCCIO DI PROT. PROTECTION CAP
143 0805402400 0C8328 TUBO EXT EXT. PIPE
146 0686400100 0C8347 POMPA DEFOND PHOENIX PHOENIX DEFOND PUMP
147 0835400M00 0C8684 GRUPPO ENTRATA ACQUA GROUP WATER INLET For level C,K
207a
216 0617836500 0C5841 RESISTENZA BOILER (24 kW/400V) HEAT. ELEM. BOILER (24 kW/400V)
0543816800
002874
O-RING
SEALING RING
For Touch, Level B
For Lev. C,K
For 400V Version
0830899101 0C6539 SONDA BYPASS 1100 BIANCO BYPASS PROBE 1100mm WHITE for Level TOUCH e B
From status level / Da scatto: 07 Page: 9 Ed. 2015 12
0C5600
Doc. Nr.:
875400Y00
From sr. Nr/ Da Ser. Nr.: ***
20 GN 2/1 ELECTRIC CONVECTION / STEAMER OVEN
Pos
Factory Code
6DGT
Code
Descrizione
Description
Ref./Note
301
0214114900
CONTRODADO
LOCK NUT
302
0508836400
002727
RONDELLA
DISK
303
0516807301
002662
BOCCOLA
BUSH
304
0548400B00
0C6551
MEMBRANA LIV.TOUCH
LAYER LEV. TOUC H
FCZ Ver.
304
0548400G00
0C6554
MEMBRANA LIV.B
LAYER LEV. B
for Level B AOS Ver.
304
0548400K00
0C6557
MEMBRANA LIV.C
LAYER LEV. C
for Level C AOS Ver.
304
0675855102
0C4949
MEMBRANA LIV.C
LAYER LEV. C
for Level C FCZ Ver.
For level touch “K”
AOS ver.
CRUSCOTTO TOUCH (NO
CONTROL PANEL TOUCH (NO
305
0870400C00
0C6589
CRUSCOTTO LIV. B (NO MEMBR.)
CONT.PANEL LEV. B (NO LAYER)
for Level B AOS Ver.
305
0873896902
0C4911
CRUSCOTTO LIV. B (NO MEMBR.)
CONT.PANEL LEV. B (NO LAYER)
for Level B FCZ Ver.
0870400R00
0C6599
305
0873897002
0C4912
CRUSCOTTO LIV. C (NO MEMBR.)
CONT.PANEL LEV. C (NO LAYER)
for Level C FCZ Ver.
CRUSCOTTO LIV. TOUCH “K” CON
MEMBRANA
CONT.PANEL TOUCH “k” WITH
LAYER
For level Tocuh “K”
AOS vers.
307
675400A00
0C6571
SCHEDA USER INTERFACE
LIV.TOUCH
USER INTERF. BOARD, LEV. TOUCH
for Level TOUCH,K
up to 2441…
307
675400P01
0C8805
SCHEDA USER INTERFACE
USER INTERF. BOARD, LEV. TOUCH
for Level TOUCH,K
up to 4481…
307
675400P03
0CA070
SCHEDA USER INTERFACE
LIV.TOUCH
USER INTERF. BOARD, LEV. TOUCH
for Level TOUCH,K
from4491…
307
0675838802
0C0041
SCHEDA USER INTERFACE LIV. B
USER INTERF. BOARD, LEV. B
for Level B
308
0675400801
0C6570
SCHEDA POWER
MAIN POWER
for Level TOUCH,K
for Level B
308
0675854501
0C4890
SCHEDA POWER
MAIN POWER
for Level C
309
0546824600
0C5833
PROLUNGA PULSANTE
PROLONG
311
0652802200
005136
FUSIBILE 16 A
FUSE 16 A
311
0652803900
0C2301
FUSIBILE 800 mA
FUSE T 630 mA
311
0652803300
0C1480
FUSIBILE 5X20 6,3A T
FUSE 5X20 6,3A T
312
0652802100
0F0031
PORTAFUSIBILE
FUSE HOLDER
313
0646810802
006314
LIMITATORE, CELLA
LIMITER, CAVITY
For 208V
314
0508840801
002628
FLANGIA
FLANGE
315
0574804900
002627
VETRO
GLASS
316
0543817202
002626
GUARNIZIONE
GASKET
317
0660808300
0C4396
LAMPADA ALOGENA
HALOGEN LAMP
Up to 4361…
317
0660400100
0C9877
LAMPADA ALOGENA
HALOGEN LAMP
From 4371…
318
0660806800
007105
PORTALAMPADA
LAMP HOLDER
319
0538804000
0C1169
FARFALLA CAMINO CELLA LW
CLOSER
320
0680802300
0C5501
MOTORIDUTTORE FIBER
MOTOREDUCER
320
0680802400
0C5502
MOTORIDUTTORE FIBER
MOTOREDUCER
For 60Hz
321
0646814900
0C2983
LIMITATORE, BOILER
LIMITER, BOILER
322
0543832200
0C1168
GUARNIZIONE
GASKET
323
0831806402
0C1219
CONDOTTO ARIA
DUCT, AIR
324
0624811000
0C4106
VENTILATORE
FAN
325
0694605400
049303
FILTRO
FILTER
326
0639805401
058707
MORSETTIERA
TERMINAL BOARD
326
0639811600
0C2673
MORSETTIERA
TERMINAL BOARD
For 208V
FORNO CONVEZIONE / VAPORE ELETTRICO 20 GN 1/1
051263
304 0548400600 0C6550 MEMBRANA LIV.TOUCH LAYER LEV. TOUC H AOS Ver.
304 0675855001 0C4948 MEMBRANA LIV.B LAYER LEV. B for Level B FCZ Ver.
304 0548401H00 0C8707 MEMBRANA LIV.TOUC “K” LAYER LEV, TOUCH “K”
305 0875401B01
305 0870400Q00 0C6598
305
305 0875401R00 0C8708
0C7032
CRUSC. + MEMBRANA TOUCH
MEMBRANA)
CRUSCOTTO LIV. C (NO MEMBR.) CONT.PANEL LEV. C (NO LAYER) for Level C AOS Ver.
LIV.TOUCH
CONTROL PANEL+LAYERTOUCH
LAYER)
for TOUCH AOS group
for TOUCH FCZ Group
from 2451…
307 0675854600 0C4891 SCHEDA USER INTERFACE LIV. C USER INTERF. BOARD, LEV. C for Level C
307
308 0675400200 0C0042 SCHEDA POWER MAIN POWER
313 0646812200 007042 LIMITATORE, CELLA LIMITER, CAVITY
0675854602
0C7350
SCHEDA USER INT.BOARD
LEV.C(1/2SPEED)
USER INT.BOARD LEV.C(1/2
SPEED)
For level c(start
sn120…)
For 208V-240V
From status level / Da scatto: 07 Page: 10 Ed. 2015 12
Doc. Nr.:
875400Y00
From sr. Nr/ Da Ser. Nr.: ***
20 GN 2/1 ELECTRIC CONVECTION / STEAMER OVEN
Pos
Factory Code
6DGT
Code
Descrizione
Description
Ref./Note
326
326
0639810900
0639400900
0C2243
0C9704
MORSETTIERA
MORSETTIERA
TERMINAL BOARD
TERMINAL BOARD
For 240V
For Japan Version
327
0694802700
0C1187
CONDENSATO RE 1 5 Mf
CAPACITOR
327
0694800700
0C1186
CONDENSATO RE 3 1, 5 MF
CAPACITOR
328
328
0624400100
0624400B00
0C6400
0C9857
TRASFORMATO R E 23 0V -12/24V
TRASFORMATORE
TRANSFORMER 230V-12/24V
TRANSFORMER
Up to 329100..
For Japan Version
328
0624807901
0C0886
TRASFORMATORE
TRANSFORMER
329
0648803001
058857
RELE
RELE 329
0648802601
056466
RELE
RELE
For 208V-240V
329
0648722900
088267
RELE
RELE
330
0624807002
007047
ALIMENTATORE SWITCHING
SWITCHING FEED ER
331 0648807300
088477
CONTATTORE K3-10°
CONTACTOR K3-10A
For Lev A,B
Japan version
331
0648807800
007104
CONTATTORE K3-40A
CONTACTOR K3-40A
331 0648807700
007080
CONTATTORE K3-32°
CONTACTOR K3-32°
For 208V, Japan version
331 0648807400
006879
CONTATTORE K3-18°
CONTACTOR K3-18°
For 208V,
331
0648613200
0L0355
CONTATTORE K3-24A
CONTACTOR K3-24A
331
0648808400
0C2244
CONTATTORE K3-50A
CONTACTOR K3-50A
For 208V,
331
0648809100
0L0430
CONTATTORE K3-18A10
CONTACTOR K3-18A10
For e1
331
0648809200
0C5051
CONTATTORE K3-32A00
CONTACTOR K3-32A00
For e1
331
0648809300
0C5052
CONTATTORE K3-40A00
CONTACTOR K3-40A00
For e1
332
0509803900
0C4459
RIFLETTORE
REFLECTOR
333
334
335
0624400000
0C6945
TRASFORMATORE
TRANSFORMER
For 208V,240V
336
0652803400
0C1487
PORTAFUSIBILE
FUSE HOLDER
For 208V,240V
337
0652803500
0C1488
FUSIB.OMEGA 22X58 80A
FUSEOMEGA 22X58 80A
For 208V,240V
339
0541400A00
0C6546
COPERTURA USB
USB COVER
for TOUCH level
340
0543843500
0C5451
GUARNIZIONE
GASKET
341
343
0675858601
0638400Y00
0C8033
0C6566
TASTO ON-OFF
PROLUNGA USB
ON-OFF (MAIN SWITCH)
USB CABLE
For TOUCH level
For Touch level
345
0549400K00
0C9992
FILTRO CRUSCOTTO
FILTER CONTROL PANEL
Pagina 6
Page 6
400
0853861303
0C1197
CARRELLO PORTA TEGLIE (P63)
TROLLEY (P63)
401
0835865000
0C1631
RUOTA CON FRENO
WHEEL WITH BRAKE
402
0835865800
0C2216
RUOTA
WHEEL
403
0517878001
0C4682
MANIGLIA
HANDLE
404
0H21503300
006309
PILETTA DI SCARICO
DRAIN
0830400N00
0C7028
SONDA CELLA 500mm ROSSA
CAVITY PROBE 5 00m m R ED
0830899001
0C0325
SONDA BOILER 800mm AZZURRA
BOILER PROBE 800mm BLUE
for Level TOUCH e B
FORNO CONVEZIONE / VAPORE ELETTRICO 20 GN 1/1
328
338 0546400200 0C6547 VASCHETTA USB USB PLUG for TOUCH level
0624400900
0C9557
TRASFORMATORE 230/10-24V
TRANSFORMER 230/10-24V
From to 330100..
For 208V Version
For 208V-240V
For Lev A,B
Japan version
Japan version
342
344 0831851301 0C4937 ASSIEME FILTRO CRUSCOTTO ASS. FILTER CONTROL PANEL
0648722900
SONDE DI TEMPERATURA TEMPERATURE PROBES
0830899101 0C6539 SONDA BYPASS 1100 BIANCO BYPASS PROBE 1100mm WHITE for Level TOUCH e B
088267
RELE’ SICUREZZA
(INTER.PRINCIPALE)
SECURITY RELE
From status level / Da scatto: 07 Page: 11 Ed. 2015 12
Doc. Nr.:
875400Y00
Loading...
