Electrolux Professional E9FRG02QF0 Parts Manual

SPARE PARTS CATALOGUE
CATALOGO PARTI DI RICAMBIO
GAS FRYER WITH SLIDING BASKET
FRIGGITRICE GAS A CESTO TRASLABILE
PNC
Ref
NOTE
391085
c
Elux. 1680mm 110LT GAS
391086
b
Elux. 2480mm 2 x 110LT GAS
Pag
Indice
Note
2 3 4
Componenti struttura Componenti gas Lista ricambi
Document review . 2015 / 06; Edition 2015 / 06
PAGE 1
Doc. 59785G500
Document review . 2015 / 06; Edition 2015 / 06
PAGE 2
Doc. 59785G500
Document review . 2015 / 06; Edition 2015 / 06
PAGE 3
Doc. 59785G500
Art
Spare
Part
Code
Factory
Code
Descrizione
Description
Ref / Notes
2
002438
*
Griglia camino
Flue grate
3 054722
*
Ruota post. cestello
Rear basket wheel
4 054652
*
Pomolo
Pommel
M6/20
5
003617
*
Cuscinetti a sfera
Ball bearing
Rs - Fag 61800
6
054721
*
Ruota ant. cestello
Front basket wheel
7 003651
*
Anello seeger inox
Inox c -clamp
E10 8 054654
*
Pomello
Pommel
M8/25
9
053342
*
Molla
Spring
10
003615
*
Calamita porta
Door magnet
Rpv 30xh6
11
*
0020549700
Maniglia porta
Door handle
12
*
0030147001
Assieme porta
Door assembly
13
003652
*
Cerniera porta
Door hinge
14
003618
*
Valvola scarico olio
Oil drain valve
15
059218
*
Piede
Foot
ø 50
16
005461
*
Guarnizione,valvola scarico olio
Gasket, oil drain valve
22
002075
*
Guarnizione bulbo
Bulb gasket
23
053808
*
Termometro
Thermometer
24
003616
*
Termostato di sicurezza
Safety thermostat
Ego 55325
25
002602
*
Termostato lavoro
Work thermostat
Ego
26
0C8716
*
Adattatore per manopola
Knob adapter
27
*
0020548900
Manopola termostato
Thermostat knob
27A
*
0020549800
Ghiera
Knob ring
28
059251
*
Accenditore piezo
Piezo lighter
See T.B. N°02005
29
002606
*
Valvola gas
Gas valve
820 Sit
30
029321
*
Bicono
Ring 31
029322
*
Dado con collare
Nut
32
003400
*
Tegolo superiore
Upper sheath
33
003401
*
Tegolo inferiore
Lower sheath
34
052256
*
Staffa pilota
Pilot support
35
059301
*
Cannello pilota
Pilot tube burner
36
052610
*
Elettrodo accenditore
Spark plug
37
057960
*
Raccordo fiss. elettrodo
Nipple sparkplug fixing
39
054055
*
Termocoppia interrotta
Interrupted thermocouple
40
003327
*
Portaugello + ugello
Nozzle holder + nozzle
L.P.G., 0,40
40
003614
*
Ugello pilota
Pilot nozzle
ø 0,40 LPG
40
058525
*
Portaugello + ugello
Nozzle holder + nozzle
Natural Gas, 0,30
40
003613
*
Ugello pilota
Pilot nozzle
ø 0,30 N.G.
41
059297
*
Bruciatore
Burner
42
058302
*
Boccola aeratore
Air Bush
43
025953
*
Ugello ø 1,90 G.N.(G25)
Ø 1,90 N.G.(G25) Nozzle
43
059314
*
Ugello ø 1,15 G.P.L. 30 mbar
Ø 1,15 L.P.G. 30 mbar Nozzle
43
059342
*
Ugello ø 1,00 G.P.L. 50 mbar
Ø 1,00 L.P.G. 50 mbar Nozzle
43
059315
*
Ugello ø 1,75g.n.(G20)
Ø 1,75 N.G.(G20) Nozzle
44
002077
*
Rondella
Washer
44
020997
*
Controdado
Lock nut
Document review . 2015 / 06; Edition 2015 / 06
PAGE 4
Doc. 59785G500
Art
Spare
Part
Code
Factory
Code
Descrizione
Description
Ref / Notes
45
002027
*
Rondella ugello bruc.
Nozzle burner washer
46
003399
*
Diffusore
Diffuser
47
052246
*
Controstaffa
Counter support
48
002607
*
Termopila
Thermopile
49
052263
*
Distanziale
Spacer
50
059296
*
Convogliatore fiamma
Flame conveyor
51
002544
*
Cavo acenditore
Ignitor cable
52
052833
*
Raccordo con bicono
Nipple with bicone
53
002816
*
Copertura accenditore
Igniter covering
54
059293
*
Guarnizione bulbo term.
Therm.bulb gasket
55
059295
*
Raccordo fiss. bulbo
Bulb fix. connection
56
003653
*
Raccordo per bulbo
Bulb nipple
57 * 0025512800
Assieme cestello ambidestro
Basket assembly
Document review . 2015 / 06; Edition 2015 / 06
PAGE 5
Doc. 59785G500
