SPARE PARTS CATALOGUE
371184
E7FTEDSSI0
ELX
EL. FRY TOP-SMOOTH PLATE 400 MM
400V
a
371185
E7FTEDSRI0
ELX
EL. FRY TOP-RIBBED PLATE 400 MM
400V
b
371186
E7FTEHSSI0
ELX
EL. FRY TOP-SMOOTH PLATE 800 MM
400V
c
371187
E7FTEHSPI0
ELX
EL. FRY TOP-SMOOTH+RIBBED PLATE 800 MM
400V
d
371192
E7FTEDHSI0
ELX
EL. FRY TOP SMOOTH HORIZONTAL PL. 400MM
400V
e
371193
E7FTEDCSI0
ELX
EL. FRY TOP-SMOOTH CHROME PLATE 400 MM
400V
f
371194
E7FTEHCSI0
ELX
EL. FRY TOP-SMOOTH CHROME PLATE 800 MM
400V
g
371197
E7FTEHCPI0
ELX
EL. FRY TOP-SMOOTH+RIBB.CHR.PLATE 800MM
400V
h
371198
E7FTEDSSIN
ELX
EL. FRY TOP-SMOOTH PLATE 400 MM
230V
i
371199
E7FTEHSSIN
ELX
EL. FRY TOP-SMOOTH PLATE 800 MM
230V
j
371200
E7FTEHSPIN
ELX
EL. FRY TOP-SMOOTH+RIBBED PL.800 MM
230V
k
371201
E7FTEHCPIN
ELX
EL. FRY TOP-SMOOTH+RIBB.CHR.PL.800MM
230V
l
371202
E7FTMDSSI5
ELX
EL. FRY TOP-SMOOTH PLATE 400 MM-MAR
400V
m
371203
E7FTMDSSI6
ELX
EL. FRY TOP-SMOOTH PLATE 400 MM-MAR
440V
n
371204
E7FTMDSRI5
ELX
EL. FRY TOP-RIBBED PLATE 400 MM-MAR
400V
o
371205
E7FTMDSRI6
ELX
EL. FRY TOP-RIBBED PLATE 400 MM-MAR
440V
p
371206
E7FTMHSSI5
ELX
EL. FRY TOP-SMOOTH PLATE 800 MM-MAR
400V
q
371207
E7FTMHSSI6
ELX
EL. FRY TOP-SMOOTH PLATE 800 MM-MAR
440V
r
371208
E7FTMHSPI5
ELX
EL.FRYTOP-SMOOTH+RIBBED PL.800MM-MAR
400V
s
371209
E7FTMHSPI6
ELX
EL.FRYTOP-SMOOTH+RIBBED PL.800MM-MAR
440V
t
371262
E7FTEHSRI0
ELX
EL. FRYTOP SMOOTH WITH RIBBED PLATE
440V
s1
372184
Z7FTEDSSI0
ZAN
EL. FRY TOP-SMOOTH PLATE 400 MM
400V
u
372185
Z7FTEDSRI0
ZAN
EL. FRY TOP-RIBBED PLATE 400 MM
400V
v
372186
Z7FTEHSSI0
ZAN
EL. FRY TOP-SMOOTH PLATE 800 MM
400V
w
372187
Z7FTEHSPI0
ZAN
EL. FRY TOP-SMOOTH+RIBBED PLATE 800 MM
400V
x
372192
Z7FTEDHSI0
ZAN
EL. FRY TOP SMOOTH HORIZONTAL PL. 400MM
400V
y
372193
Z7FTEDCSI0
ZAN
EL. FRY TOP-SMOOTH CHROME PLATE 400 MM
400V
z
372194
Z7FTEHCSI0
ZAN
EL. FRY TOP-SMOOTH CHROME PLATE 800 MM
400V
a1
372197
Z7FTEHCPI0
ZAN
EL. FRY TOP-SMOOTH+RIBB.CHR.PLATE 800MM
400V
b1
372198
Z7FTEDSSIN
ZAN
EL. FRY TOP-SMOOTH PLATE 400 MM
230V
c1
372199
Z7FTEHSSIN
ZAN
EL. FRY TOP-SMOOTH PLATE 800 MM
230V
d1
372200
Z7FTEHSPIN
ZAN
EL. FRY TOP-SMOOTH+RIBBED PL.800 MM
230V
e1
372201
Z7FTEHCPIN
ZAN
EL. FRY TOP-SMOOTH+RIBB.CHR.PL.800MM
230V
f1
373184
A7FTEDSSI0
OEM
EL. FRY TOP-SMOOTH PLATE 400 MM
400V
g1
373185
A7FTEDSRI0
OEM
EL. FRY TOP-RIBBED PLATE 400 MM
400V
h1
373186
A7FTEHSSI0
OEM
EL. FRY TOP-SMOOTH PLATE 800 MM
400V
i1
373187
A7FTEHSPI0
OEM
EL. FRY TOP-SMOOTH+RIBBED PLATE 800 MM
400V
j1
373192
A7FTEDHSI0
OEM
EL. FRY TOP SMOOTH HORIZONTAL PL. 400MM
400V
k1
373193
A7FTEDCSI0
OEM
EL. FRY TOP-SMOOTH CHROME PLATE 400 MM
400V
l1
373194
A7FTEHCSI0
OEM
EL. FRY TOP-SMOOTH CHROME PLATE 800 MM
400V
m1
373197
A7FTEHCPI0
OEM
EL. FRY TOP-SMOOTH+RIBB.CHR.PLATE 800MM
400V
n1
373198
A7FTEDSSIN
OEM
EL. FRY TOP-SMOOTH PLATE 400 MM
230V
o1
373199
A7FTEHSSIN
OEM
EL. FRY TOP-SMOOTH PLATE 800 MM
230V
p1
373200
A7FTEHSPIN
OEM
EL. FRY TOP-SMOOTH+RIBBED PL.800 MM
230V
q1
373201
A7FTEHCPIN
OEM
EL. FRY TOP-SMOOTH+RIBB.CHR.PL.800MM
230V
r1
CATALOGO PARTI DI RICAMBIO
FRY TOP ELETTRICO E700XP
ELECTRIC FRYTOP E700XP
PNC Model Brand Description Ref Ref
INDEX
Pagina / Page 2 Vista generale / Main view
Pagina/Page 3/4 Lista ricambi / Spare parts list
Page: 1 Ed. 10 2015
Doc. Nr.: 59785Q300
Page: 2 Ed. 09 2015
Doc. Nr.: 59785Q300
Pos
Spare
Code
1
5038A1U00
*
FONDO 400 mm
BOTTOM PANEL 400mm
1
5038A1V00
*
FONDO 800 mm
BOTTOM PANEL 800mm
2
315252601
026806
PIEDINO CON VITE
FOOT WITH SCREW
3
50489MB00
0C8479
FERMO RESIST ENZ A
HEATING ELEME NT STO PPER
4
638865100
005370
RESISTENZA DI CADUT A
DROPPING RESIS TOR
5
85089F701
0C8544
RIVESTIMENTO LA T E RA L E 40 0mm
EXTERNAL PANEL 400 mm
ELX
5
85089F801
0C7536
RIVESTIMENTO LA T E RA L E 80 0mm
EXTERNAL PANEL 800 mm
ELX
5
85089FA01
0C7268
RIVESTIMENTO LA T E RA L E 40 0mm
EXTERNAL PANEL 40 0 mm
ZAN, OEM
5
85089FB01
0C8464
RIVESTIMENTO LA T E RA L E 80 0mm
EXTERNAL PANEL 800 mm
ZAN, OEM
7
527850500
0C0156
PIASTRA FISSAGGIO FIANCHI
SIDE PANEL JOINTING PLATE
8
87589BW01
0C8480
RIPIANO 400mm FE-LISCIO
TOP 400mm IRON-SMOOTH
ELX
8
87589CZ01
0C8602
RIPIANO 400mm FE-RIGATO
TOP 400mm IRON-RIBBED
ELX
8
87589DC01
0C8613
RIPIANO 400mm CR- LISCIO
TOP 400mm CHROME SMOOTH
ELX
8
87589BZ01
0C8600
RIPIANO 800mm FE- LISCIO
TOP 800mm IRON-SMOOTH
ELX
8
87589D601
0C8608
RIPIANO 800mm FE-1/3 RIGATO
TOP 800mm IRON-1/3 RIBBED
ELX
8
87589DF01
0C8615
RIPIANO 800mm CR 1/3 RIGATO
TOP 800mm CHROME 1/3 RIB.
ELX
8
87589F300
*
RIPIANO 800mm F E - RIGATO
TOP 800mm IRON - RIBBED
s1
8
87589BX01
0C8599
RIPIANO 400mm FE- LISCIO
TOP 400mm IRON-SMOOTH
ZAN, OEM
8
87589D101
0C8604
RIPIANO 400mm FE- RIGATO
TOP 400mm IRON-RIBBED
ZAN, OEM
8
87589DG01
0C8616
RIPIANO 400mm CR- LISCIO
TOP 400mm CHROME SMOOTH
ZAN, OEM
8
87589C001
0C8601
RIPIANO 800mm FE- LISCIO
TOP 800mm IRON-SMOOTH
ZAN, OEM
8
87589D701
0C8609
RIPIANO 800mm FE-1/3 RIGATO
TOP 800mm IRON 1/3 RIBBED
ZAN, OEM
8
87589DJ01
0C8618
RIPIANO 800mm CR- LISCIO
TOP 800mm CHROME SMOOTH
ZAN, OEM
8
87589DL01
0C8620
RIPIANO 800mm CR 1/3 RIGATO
TOP 800mm CHROME 1/3 RIB.
ZAN, OEM
10
541813800
0C6171
RONDELLA SILICONE
SILICONE WASHER
11
543821900
0C2496
GUARNIZIONE CRUSCOTTO
GASKET, CONTROL PANEL
12
85589C903
0C7666
CRUSCOTTO 400mm
CONTROL PANEL 40 0m m
ELX
12
85589C802
0C7665
CRUSCOTTO 800mm
CONTROL PANEL 80 0m m
ELX
12
87089JT03
0C7674
CRUSCOTTO 400mm
CONTROL PANEL 40 0m m
ZAN
12
87089K602
0C7683
CRUSCOTTO 800mm
CONTROL PANEL 80 0m m
ZAN
12
87089HN00
0C7465
CRUSCOTTO 800mm
CONTROL PANEL 80 0mm
i1, j1, m1, n1
12
87089MW03
*
CRUSCOTTO 400mm
CONTROL PANEL 40 0m m
OEM
12
87089MX03
*
CRUSCOTTO 800mm
CONTROL PANEL 80 0m m
p1,q1,r1
13
85089CY00
0C7662
CASSETTO FRYT O P 80 0m m
DRAWER, FRYTO P 80 0m m
15
50489UH00
*
GUIDA CASSETTO
DRAWER RUNNER
400 mm
15
50489UG00
*
GUIDA CASSETTO
DRAWER RUNNER
800 mm
MORSETTIERA DI
ALIMENTAZIONE
18
A05400901
0A2134
INTERRUTTORE
SWITCH
19
646809500
004363
TERMOSTATO FERRO
THERMOSTAT IRON
IRON
20
A05414500
0A2205
STAFFA FISSAGGIO
FASTENING PLATE
21
876800002
005010
LAMPADA VERDE
GREEN LAMP
22
876800102
005011
LAMPADA ARANCIO
ORANGE LAMP
23
544802300
0C0068
PRESSACAVO
TIGHTNER, CORD
24
548877V00
0C7345
ADATTATORE MANOPOLA
KNOB ADAPTER
ELX
25
548877P00
0C7626
GHIERA
KNOB RING
ELX
25
548879Z00
0C7430
GHIERA
KNOB RING
ZAN, OEM
Factory
Code
8 87589DD01 0C8614 RIPIANO 800mm CR- LISCIO TOP 800mm CHROME SMOOTH ELX
Part
Description Description Note
9 806860102 0C6237 TUBO DI SCARICO DRAIN PIPE
13 85089CW00 0C7868 C A S SET TO FR YTO P 40 0m m DRAWER, FRYTO P 40 0m m
14 617839H00 0C8476 RESISTEN ZA 42 0 0W HEATING ELEME NT 42 00W
14 617839J00 0C8477 RESISTENZ A 39 0 0W HEATING ELEMENT 3900W
14 617839K00 0C8478 RESIST ENZ A 42 0 0W HEATING ELEMENT 4200W 440V;n,p,r,t
17 A05714000 058613
MAIN TERMINAL BLO C K
400V;a,b,c,d,e,f,h,m,o,q,s,u,v
,w,x,y,z,a1,b1,g1,h1,j1,k1,l1,
m1,n1
230V;i,j,k,l,c1,d1,e1,f1,o1,p1,
q1,r1
19 646817400 0C6234 TERMOSTATO CROMO THERMOSTAT CROME CHROME
Page: 3 Ed. 10 2015
Doc. Nr.: 59785Q300
Pos
Spare
Code
26
511850G01
0C6670
MANOPOLA
KNOB
ELX
26
548878201
0C7232
MANOPOLA
KNOB
ZAN
26
548865500
0A5621
MANOPOLA
KNOB
OEM
27
218912211
069567
MOLLETTA PER GHIERA
SPRING, KNOB RING
28
543821000
053816
GUARNIZIONE MANOPOLA
GASKET, KNOB
29
214590701
025245
MOLLETTA PER MANOPOLA
SPRING, KNOB
30
50389LP00
0C7333
GRIGLIA CAMINO
CHIMNEY GRID
31
532806904
0C2964
PARASPRUZZI 400mm
SPLASHBACK
400 mm up to ser 524
31a
50089B000
0CA412
PARASPRUZZI POST 400 mm
SPLASHBACK REAR
400 mm from ser 525
31a
50089B100
0CA413
PARASPRUZZI POST 800 mm
SPLASHBACK REAR
800 mm from ser 525
31b
50089B200
0CA414
PARASPRUZZI SX
SPLASHBACK LEFT
From ser 525
31c
50089B300
0CA415
PARASPRUZZI DX
SPLASHBACK RIGHT
From ser 525
31d
85089NA00
0CA420
ASSIEME PARASPRUZZI 400 mm
SPLASHBACK ASSEMBLY
400 mm from ser 525
31d
85089NB00
0CA421
ASSIEME PARASPRUZZI 800 mm
SPLASHBACK ASSEMBLY
800 mm from ser 525
32
805848202
055995
RASCHIETTO PIASTRA LISCIA
SCRAPER FOR SMOOTH TOP
32a * 0C2519
LAMA PER RASCHI E TT O
SCRAPER BLADE
(10pcs per code)
LAMA PER RASCHIETTO (angoli
smussati)
33
646817800
0C8686
LIMITATORE TEMPERATURA
SAFETY THERMOSTAT
CHROME
34
516860700
0C0137
PIASTRINA GIUNZIONE
JOINTING REAR PL ATE
35
830851300
056940
SPATOLA PIASTRA RIGATA
SCRAPER FOR RIBBED TOP
36 * 0S0990
SGRASSANTE
GREASE CUTTER
1pcs = 6 x 0,75lt bottles
36 * 0S0841
SGRASSANTE
GREASE CUTTER
1pcs = 4 x 5lt bottles
Factory
Code
31 532807104 0C2965 PARASPRUZZI 800mm SPLASHBACK 800 mm up to ser 524
Part
Description Description Note
32a * 056340
SCRAPER BLADE (rounded corners) (2pcs per code)
Page: 4 Ed. 09 2015
Doc. Nr.: 59785Q300
