From sr. Nr/ Da Ser. Nr.: 338
From status level / Da scatto: 00 Page: 1 Ed. 01 2016
Doc. Nr.: 59785FF00
SPARE PARTS CATALOGUE
CATALOGO PARTI DI RICAMBIO
CUOCI PASTA E700 XP
PASTA COOKER E700 XP
FROM SERIAL 3 38 / DA MATRICOLA 3 38
PNC
Model
Ref
Brand
Version
Notes
371090
E7PCGD1KF0
a
ELX
GAS
1X40 LT WELL 400MM
371091
E7PCGH2KF0
b
ELX
GAS
2X40 LT WELLS 800MM
371098
E7PCED1KF0
c
ELX
EL
1X40 LT WELL 400MM
371099
E7PCEH2KF0
d
ELX
EL
2X40 LT WELLS 800MM
372090
Z7PCGD1KF0
e
ZAN
GAS
1X40 LT WELL 400MM
372091
Z7PCGH2KF0
f
ZAN
GAS
2X40 LT WELLS 800MM
372098
Z7PCED1KF0
g
ZAN
EL
1X40 LT WELL 400MM
372099
Z7PCEH2KF0
h
ZAN
EL
2X40 LT WELLS 800MM
373090
A7PCGD1KF0
i
OEM
GAS
1X40 LT WELL 400MM
373091
A7PCGH2KF0
l
OEM
GAS
2X40 LT WELLS 800MM
373098
A7PCED1KF0
m
OEM
EL
1X40 LT WELL 400MM
373099
A7PCEH2KF0
n
OEM
EL
2X40 LT WELLS 800MM
373232
A7PCGD1KFK
o
KIP
GAS
1X40 LT WELL 400MM
373233
A7PCGH2KFK
p
KIP
GAS
2X40 LT WELLS 800MM
373234
A7PCED1KFK
q
KIP
EL
1X40 LT WELL 400MM
Pag
Index
Indice
Note
2
3
4
5
6
7
8,9,10
General view
Idraulic circuit (water)
FROM S/N 3 38 (2013) -
Gas components
Electric components
Pasta baskets
Ugelli
Spare parts list
Vista Generale
Componenti imp.idraulico (acqua)
DA MATRICOLA S/N 3 38 (2013)
Componenti Gas
Componenti elettrici
Cestelli pasta
Nozzels
Lista ricambi
Brand/Marchio: All
From sr. Nr/ Da Ser. Nr.: 338
From status level / Da scatto: 00 Page: 2 Ed. 01 2016
Doc. Nr.: 59785FF00
General view / Vista generale
From sr. Nr/ Da Ser. Nr.: 338
From status level / Da scatto: 00 Page: 3 Ed. 01 2016
Doc. Nr.: 59785FF00
FROM S/N 3 38 (2013) - DA MATRICOLA S/N 3 38 (2013)
Idraulic circuit (water) / Componenti impianto idraulico (acqua)
From sr. Nr/ Da Ser. Nr.: 338
From status level / Da scatto: 00 Page: 4 Ed. 01 2016
Doc. Nr.: 59785FF00
Gas components / Componenti gas
Electric Components / Componenti Elettrici
From sr. Nr/ Da Ser. Nr.: 338
From status level / Da scatto: 00 Page: 5 Ed. 01 2016
Doc. Nr.: 59785FF00
From sr. Nr/ Da Ser. Nr.: 338
From status level / Da scatto: 00 Page: 6 Ed. 01 2016
Doc. Nr.: 59785FF00
From sr. Nr/ Da Ser. Nr.: 338
From status level / Da scatto: 00 Page: 7 Ed. 01 2016
Doc. Nr.: 59785FF00
Gas nozzles / Ugelli per gas
A - Ugello bruciatore / Burner nozzle
Code
Spare
Code
Reference
-
002267
ø2.45
2H/2E+
G20 20mbar
-
002865
ø2.30
2H
G20 25mbar
-
003371
ø2.75
2ELL
G25 20mbar
-
002268
ø2.60
2L
G25 25mbar
-
002268
ø2.60
2S
G25.1 25mbar
-
002905
ø1.60
3+3B/P
G30 30mbar
-
003722
ø1.55
3B/P
G30 36mbar
-
004488
ø1.40
3B/P
G30 50mbar
-
0C0551
ø2.85
No CE
G20 10mbar
0C3079
Ø6.25
No CE
G110 8mbar
B - Ugello Pilota / Burner nozzle
Code
Spare
Code
Reference
-
054037
n°25
2H/2E+
G20 20mbar
-
054037
n°25
2H
G20 25mbar
-
054037
n°25
2ELL
G25 20mbar
-
054037
n°25
2L
G25 25mbar
-
054037
n°25
2S
G25.1 25mbar
-
054286
n°24
3+3B/P
G30 30mbar
-
054286
n°24
3B/P
G30 36mbar
-
054286
n°24
3B/P
G30 50mbar
-
054037
n°25
No CE
G20 10mbar
054038
No CE
G110 8mbar
C – Vite Minimo / Min Screw
Code
Spare
Code
Reference
-
003182
140
2H/2E+
G20 20mbar
-
003182
140
2H
G20 25mbar
-
003182
140
2ELL
G25 20mbar
-
003182
140
2L
G25 25mbar
-
003182
140
2S
G25.1 25mbar
-
002770
85
3+3B/P
G30 30mbar
-
002770
85
3B/P
G30 36mbar
-
002769
75
3B/P
G30 50mbar
-
003182
140
No CE
G20 10mbar
From sr. Nr/ Da Ser. Nr.: 338
From status level / Da scatto: 00 Page: 8 Ed. 01 2016
Doc. Nr.: 59785FF00
COUOCI PASTA E700 XP
PASTA COOKER E700 XP
Pos
Factory
Code
Spare Part
Code
Descrizione
Description
Ref./Note
1
835856900
0C0204
PIEDE
FOOT
2
85089FD01
*
ASSIEME FASCIA 400
SIDE PANEL 400
a,c
2
85089FF01
*
ASSIEME FASCIA 800
SIDE PANEL 800
b,d
2
85089FH01
*
ASSIEME FASCIA 400
SIDE PANEL 400
e,g,i,m, O,Q
2
85089FJ01
*
ASSIEME FASCIA 800
SIDE PANEL 800
f, h, l, n,P
3
87089BK01
0C7218
RIPIANO / VASCA 400 MM
WORKTOP / TANK 400mm
a 3 87089BL01
*
RIPIANO / VASCA 800 MM
WORKTOP / TANK 800mm
b
3
87089BM01
0C7628
RIPIANO / VASCA 400 MM
WORKTOP / TANK 400mm
c
3
87089BN01
0C7629
RIPIANO / VASCA 800 MM
WORKTOP / TANK 800mm
d
3
87089MC01
0C7632
RIPIANO / VASCA 400 MM
WORKTOP / TANK 400mm
e, i, o
3
87089MD01
0C7633
RIPIANO / VASCA 800 MM
WORKTOP / TANK 800mm
f, l, p
3
87089BR00
*
RIPIANO / VASCA 400 MM
WORKTOP / TANK 400mm
g, m, q
3
87089BS00
*
RIPIANO / VASCA 800 MM
WORKTOP / TANK 800mm
h, n
4
85089BF00
0C7620
CRUSCOTTO 400mm
CONTROL PANEL 400mm
c
4
85089AF00
0C7136
CRUSCOTTO 800mm
CONTROL PANEL 800mm
d
4
85089AB00
0C7135
CRUSCOTTO 400mm
CONTROL PANEL 400mm
a
4
85089BD00
0C7138
CRUSCOTTO 800mm
CONTROL PANEL 800mm
b 4 85089FN00
0C7389
CRUSCOTTO 400mm
CONTROL PANEL 400mm
g
4
85089FP00
0C7390
CRUSCOTTO 800mm
CONTROL PANEL 800mm
h
4
87089GY00
0C7222
CRUSCOTTO 400mm
CONTROL PANEL 400mm
e
4
85089FM00
0C7388
CRUSCOTTO 800mm
CONTROL PANEL 800mm
f
4
502899K00
0C8024
CRUSCOTTO 400mm
CONTROL PANEL 400mm
i,O
4
502899Y00
0C8025
CRUSCOTTO 800mm
CONTROL PANEL 800mm
l,P
4
502899Z00
0C8026
CRUSCOTTO 400mm
CONTROL PANEL 400mm
m,Q 4 502899N00
0C8027
CRUSCOTTO 800mm
CONTROL PANEL 800mm
n
5
527850500
0C0156
PIASTRA FISSAGGIO FIANCHI
SIDE PANEL JOINTING PLATE
6
51589A700
0C7164
MANIGLIA
HANDLE
a,b,c,d
6
54887A800
0C8190
MANIGLIA
HANDLE
e,f,g,h
6
854864203
0A5021
MANIGLIA
HANDLE
i,l,m,n,O,P,Q
7
516860901
0C0139
CERNIERA SUP.
UPPER. HINGE, DOOR
8
516860801
0C0138
CERNIERA INF.
BOTTOM HINGE, DOOR
9
50389G300
0C7156
PORTA (SENZA MANIGLIA)
DOOR (WITHOUT HANDLE)
a,b,c,d, e,f,g,h
9
50389MB01
*
PORTA (SENZA MANIGLIA)
DOOR (WITHOUT HANDLE)
i,l,m,n, O,P,Q
10
50489CQ00
0C7158
CONTROPORTA
INNER DOOR OVEN
11
565819900
0C4433
DISTANZIALE PORTA
DOOR SPACER
*
85089AA02
0C7156
ASSIEME PORTA (SENZA MANIGLIA)
COMPLETE DOOR (NO HANLE)
a,b,c,d, e,f,g,h
12
541813800
0C6171
RONDELLA IN SILICONE
SILICONE WASHER
14
830898200
0C0201
MAGNETE
MAGNET, DOOR
15
548877Y00
0C7134
GHIERA COMMUTATORE ELETTRICO
RING, KNOB SWITCH ELECTRIC
Electric, ELX
15
548876G01
0C6802
GHIERA RUBINETTO ACQUA
RING, KNOB WATER REGULATION
Water ELX
15
548877X00
0C7178
GHIERA RUBINETTO GAS
RING, KNOB GAS REGULATION
Gas, ELX
15
54887A400
0C7386
GHIERA COMMUTATORE ELETTRICO
RING, KNOB SWITCH ELECTRIC
Electric,ZAN, OEM, KIP
15
54887A300
0C7938
GHIERA RUBINETTO GAS
RING, KNOB GAS REGULATION
GAS,ZAN, OEM,KIP
15
548879H00
0C7385
GHIERA RUBINETTO ACQUA
RING, KNOB WATER REGULATION
Water,ZAN, OEM, KIP
16
543821000
053816
GUARNIZIONE X MANOPOLA
GASKET, KNOB
18
54887AW00
0C8646
MANOPOLA GAS ED ACQUA
KNOB GAS AND WATER TAP
a,b,c,d,
18
548878001
0C7180
MANOPOLA RUBINETTO ACQUA
KNOB WATER TAP
e,f,g,h
18
548878201
0C7232
MANOPOLA GAS E COMMUTATORE
KNOB, GAS AND REGULATOR
e,f,g,h
18
548865700
0C1380
MANOPOLA RUBINETTO ACQUA
KNOB WATER TAP
i,l,m,n
18
548865500
0A5621
MANOPOLA GAS E COMMUTATORE
KNOB, GAS AND REGULATOR
i,l,m,n
18
548876V00
0C8295
MANOPOLA
KNOB
O,P,Q
18
548876X00
0C6747
MANOPOLA GAS E COMMUTATORE
KNOB, GAS AND REGULATOR
O,P,Q
19
218912211
069567
MOLLETTA PER GHIERA
RING, RING KNOB
20
50489CR03
0CA416
PANNELLO FRONTALE 400mm
FRONTAL PANEL 400mm
a,c,e,g,I,m,o,q
20
50489D403
PANNELLO FRONTALE 800mm
FRONTAL PANEL 800mm
b,d,f,h,l,n,p
20* * 0CA417
KIT pos. 20 (0CA416) + pos. 41
(0C9410)
KIT pos. 20 (0CA416) + pos. 41
(0C9410)
a,c,e,g,I,m,o,q
21
506864501
004836
FILTRO FONDO
BOTTOM FILTER
From sr. Nr/ Da Ser. Nr.: 338
From status level / Da scatto: 00 Page: 9 Ed. 01 2016
Doc. Nr.: 59785FF00
COUOCI PASTA E700 XP
PASTA COOKER E700 XP
Pos
Factory
Code
Spare Part
Code
Descrizione
Description
Ref./Note
22
514848300
054905
MOLLA PER FILTRO FONDO
SPRING, FILTER
23
214105101
020997
CONTRODADO GETTO
WATER TAP NUT
24
511832001
0C5935
GETTO ACQUA
WATER TAP
25
50389LP00
0C7333
GRIGLIA CAMINO
CHIMNEY GRID
26
F921618
0C9225
KIT CESTELLO 105X160
KIT BASKET 105X160
KIT OF 2 LEFT + 2
RIGHT BASKET
26* * 0C9226
KIT CESTELLO 105X160
KIT BASKET 105X160
2 RIGHT BASKET
26* * 0C9227
KIT CESTELLO 105X160
KIT BASKET 105X160
2 LEFT BASKET
27
F921619
004873
CESTELLO 105X350
BASKET 105X350
28
F921611
004874
CESTELLO 220X350
BASKET 220X350
28a
F921610
004875
CESTELLO 220X170
BASKET 220X170
29
F921606
004876
GRIGLIA DI FONDO
FALSE BOTTOM, PASTA COOKER
30 * 0C9655
KIT PIASTRA GIUNZIONE
KIT JOINTING REAR PLATE
Screws and bracket
36
50689DY00
0C9743
DOMA FORATURA
DRILL JIG
TB PDX2013-03
37
855899X02
0C6953
ASSIEME RACCORDO DI SCARICO
COMPLETE DRAIN JUNCTION
Up to 5481…
37
855899X04
0CA490
ASSIEME RACCORDO DI SCARICO
COMPLETE DRAIN JUNCTION
From 5491…
38
544825Q00
0C9199
TUBO SCARICO
DRAIN PIPE
Up to 5201 LENGTH
160MM
38
544826000
0CA374
TUBO SCARICO
DRAIN PIPE
From 5211 LENGTH
160MM
39
544825H00
*
TUBO TROPPO PIENO
TOO FULL PIPE
LENGTH 510MM
40
543827500
0C6800
OR
OR 41
50689DG00
0C9410
MANIGLIA SCARICO
HANDLE , WATER DISCHARGE
42
83089JZ00
0C9633
RIBALTA ACQUA AISI
WATER PIPE STAINLESS STEEL
1x40 WELL a,c,e,g,i,m
42
83089KF00
0C9740
KIT COMPLETO RIBALTA AISI
KIT WATER INLET PIPE
TB PDX2013-03
1x40 WELL a,c,e,g,i,m
42
83089K000
0C9634
RIBALTA ACQUA AISI
WATER PIPE STAINLESS STEEL
2x40 WELL b,d,f,h,l,n
42
83089KG00
0C9741
KIT COMPLETO RIBALTA AISI
KIT WATER INLET PIPE
TB PDX2013-03
2x40 WELL b,d,f,h,l,n
43
548877V00
0C7345
ADATTATORE MANOPOLA
KNOB, ADAPTER
a,b,c,d
44
516875100
0C8993
DADO FISSAGGIO
FIXING NUT
45
835877Z00
0C9635
RUBINETTO+PROLUNGA , CARICO
WATER TAP + EXTENSION, INLET
46
518613100
049888
FASCETTA GETTO ACQUA
CLAMP BAND WATER NOZZLE
46a
518825C00
0C9201
FASCETTA SCARICO ACQUA
CLAMP BAND DISCHARGE WATER
46b
518613300
0L2728
FASCETTA TROPPOPIENO
CLAMP BAND OVERFLOW WATER
47
511851900
0C9205
MANICOTTO
EXTENSION
48
511851800
0C9204
NIPPLO 1” 7/1
GAS CONNECTION 1” 7/1
49
518803100
0C7118
INSERTO FILETTATO M5
THREADED RIVET M5
FIXING OF POS.42
50
505899T03
0TTA07
PIASTRINA SCARICO
DRAIN PLATELET INDICATOR
Except for KIP
100
83089D301
0C6795
BRUCIATORE
BURNER
101
514829700
054118
PORTAUGELLO
INJECTOR HOLDER
102
214105101
020997
CONTRODADO
LOCK NUT
103
506833401
054029
GUARNIZIONE
GASKET
104
830828001
054039
AERATORE
AERATOR
105
835875R01
0C8647
RUBINETTO GAS
GAS TAP
106
80589AN00
0C8029
CONDOTTA GAS
GAS PIPE
107
80589BY00
0C9198
CAVETTO ACCENSIONE CON GUAINA
SPARK PLUG CABLE (sheathed)
LENGTH 700MM
108
646809901
005295
TERMOSTATO SIC. LIMITATORE
SAFETY THERMOSTAT
109
835834901
0C9240
KIT ACCENDITORE
(ACCEND+TAPPO+RONDEL)
KIT IGNITER
(IGNITER+BUTTON+WASHER)
109
835829600
059251
ACCENDITORE
IGNITER
109
541809001
0C9407
TAPPO DI GOMMA
RUBBER BUTTON
109
516814601
0C9408
RONDELLA
WASHER
110 * 0C9409
TAPPO DI GOMMA + RONDELLA
RUBBER BUTTON + WASHER
111
83089DD00
0C8030
RIBALTA GAS
INLET GAS PIPE
1x40 WELL
a,c,e,g,i,m,o,q
111
83089DA00
0C8031
RIBALTA GAS
INLET GAS PIPE
2x40 WELL b,d,f,h,l,n,p
From sr. Nr/ Da Ser. Nr.: 338
From status level / Da scatto: 00 Page: 10 Ed. 01 2016
Doc. Nr.: 59785FF00
COUOCI PASTA E700 XP
PASTA COOKER E700 XP
Pos
Factory
Code
Spare Part
Code
Descrizione
Description
Ref./Note
112
830828100
054032
BRUCIATORE PILOTA
PILOT BURNER
113
330272401
052610
ELETTRODO ACCENSIONE
SPARK CANDLE
114
214164400
052125
RACCORDO
PIPE FITTING
115
831818901
0C3162
TERMOCOPPIA INTERROTTA
THERMOCOUPLE
116
515827401
053665
BICONO
DOUBLE CONE
117
51589A901
0C8032
CONDUTTURA PILOTA
PIPE, PILOT
118
214164400
052125
RACCORDO
PIPE FITTING
119
206260400
057382
VETRO SPIA
GLASS
120
275290025
057400
CORNICE VETRO
FRAME
200
617839900
0C7625
RESISTENZA
HEATING ELEMENT
201
505899G00
0CA572
SUPPORTO RESISTENZA
HEATING E. SUPPORT
202
538831803
*
SUPPORTO RESISTENZA FRONTALE
FRONT HEATING E. SUPPORT
203
569807501
0C8182
BACCHETTA IN STEATITE
CERAMIC ROD
204
511833002
0C5964
ASTA AZIONAMENTO MICRO
SLIDE BAR
205
514828600
053819
MOLLA
SPRING
206
246214023
045404
PIASTRINA ISOLANTE MICRO
MICRO INSULATION
207
640800800
053671
MICRO-INTERRUTTORE
MICROSWITCH
208
538831903
0CA537
SICUREZZA MECCANICA
SECURITY SUPPORT
209
641805101
0C7353
COMMUTATORE
SWITCH
210
648807900
0C7622
CONTATTORE
CONTACTOR
211
H58194500
0C4704
CONTATTO AUSILIARIO
AUXILIARY CONTACT
212
639806600
006854
MOSETTIERA (completa)
TERMINAL BOARD (assembly)
like picture 212
213
652806400
0C1884
FUSIBILE
FUSE
10a
214
544802300
0C0068
PASSACAVO
TOGHTENER CORD
215
653800000
0C6155
PROTEZIONE TERMICA
THERMIC SECURITY
c,d,g,h,m,n,Q
216
560857403
0C9888
ISOLAMENTO
INSULATION
c,d,g,h,m,n,Q
217
876800002
005010
LAMPADA VERDE
GREEN LAMP
218
652603200
075737
PORTAFUSIBILE
FUSE HOLDER TERMINAL
219
638899T02
0C9678
CABLAGGIO ELETTRICO
WIRING HARNESS
c,g,m,Q
219
638899U02
0CA119
CABLAGGIO ELETTRICO
WIRING HARNESS
d,h,n
Loading...
