From sr. Nr/ Da Ser. Nr.: 116
Page: 1 Ed. 2015 12
Doc. Nr.: 59785GA00
SPARE PARTS CATALOGUE
CATALOGO PARTI DI RICAMBIO
FRIGGITRICI ELETTRICHE 18L E900XP
ELECTRIC FRYERS 18L E900XP
PNC
Model
Ref
Pag.
Brand
Version
Notes
391094
E9FRED1HF0
a
2,3
ELX
1 WELL
2 ½ BASKETS – 400V
391095
E9FREH2HF0
b
2,3
ELX
2 WELLS
4 ½ BASKETS – 400V
391178
E9FRED1HFN
c
2,3
ELX
1 WELL
2 ½ BASKETS - 230V
391179
E9FREH2HFN
d
2,3
ELX
2 WELLS
4 ½ BASKETS - 230V
391190
E9FRMD1HF5
e
2,3
ELX
1 WELL
2 ½ BASKETS MARINE 400V
391191
E9FRMD1HF6
n
2,3
ELX
1 WELL
2 ½ BASKETS MARINE 440V
391311
E9FRED1HFG
o
2,3
ELX
1 WELL
2 ½ BASKETS – 400V
392094
Z9FRED1HF0
f
2,3
ZAN
1 WELL
2 ½ BASKETS – 400V
392095
Z9FREH2HF0
g
2,3
ZAN
2 WELLS
4 ½ BASKETS – 400V
392178
Z9FRED1HFN
h
2,3
ZAN
1 WELL
2 ½ BASKETS - 230V
392179
Z9FREH2HFN
i
2,3
ZAN
2 WELLS
4 ½ BASKETS - 230V
393094
A9FRED1HF0
l
2,3
OEM
1 WELL
2 ½ BASKETS – 400V
393095
A9FREH2HF0
m
2,3
OEM
2 WELLS
4 ½ BASKETS – 400V
Pag
Index
Indice
Note
2
3
4,5
General componets
Electric Components
Spare parts list
Componenti struttura
Componenti elettrici
Lista ricambi
Brand/Marchio: All
Factory code: 9PDX
From sr. Nr/ Da Ser. Nr.: 116
Page: 2 Ed. 2015 12
Doc. Nr.: 59785GA00
From sr. Nr/ Da Ser. Nr.: 116
Page: 3 Ed. 2015 12
Doc. Nr.: 59785GA00
From sr. Nr/ Da Ser. Nr.: 116
Page: 4 Ed. 2015 12
Doc. Nr.: 59785GA00
FRIGGITRICI ELETTRICHE 18L E900XP
ELECTRIC FRYERS 18L E900XP
Pos
Spare
Part
Code
Factory Code
Descrizione
Description
Ref./Note
1
0C0204
835856900
PIEDE
FOOT
1
0C3324
806844600
PIEDE
FOOT
MARINE
2
3
4
5
0C6171
541813800
RONDELLA SILCONE
SILICONE WASHER
6 * 147018088
ADESIVO STRUTTURALE
STRUCTURAL ADHESIVE
7
0CA526
85089DY00
FASCIA 400mm
EXTERNAL PANEL 400mm
ELX
7 * 85089DZ00
FASCIA 800mm
EXTERNAL PANEL 800mm
ELX 7 *
85089F300
FASCIA 400mm
EXTERNAL PANEL 400mm
ZAN, OEM
7 * 85089F400
FASCIA 800mm
EXTERNAL PANEL 800mm
ZAN, OEM
8
0C7497
87089AU00
RIPIANO / VASCA 400mm (18Lt)
WORKTOP / TANK 400mm (18Lt)
ELX
8
0C7498
87089AV00
RIPIANO / VASCA 800mm
(18+18Lt)
WORKTOP / TANK 800mm
(18+18Lt)
ELX
8
0C7508
87089CB00
RIPIANO / VASCA 400mm (18Lt)
WORKTOP / TANK 400mm (18Lt)
ZAN, OEM
8
0C7509
87089CC00
RIPIANO / VASCA 800mm
(18+18Lt)
WORKTOP / TANK 800mm
(18+18Lt)
ZAN, OEM
9
0C0156
527850500
PIASTRA FISSAGGIO FIANCHI
SIDE PANEL JOINTING PLATE
10
0A5439
835841201
VALVOLA SCARICO
DRAIN VALVE
11
0C0763
525885100
PROTEZIONE LEVA SCARICO
PROTECTION, DRAIN LEVER
12
0C0764
508883202
SUPPORTO PROTEZIONE LEVA
SUPPORT, PROTECTION DRAIN
14
0C7740
85589AK00
CRUSCOTTO 400mm
CONTROL PANEL 400mm
ELX
14
0C7749
85589B600
CRUSCOTTO 400mm
CONTROL PANEL 400mm
ELX MARINE
14
0C7741
85589AL00
CRUSCOTTO 800mm
CONTROL PANEL 800mm
ELX
14
0C7517
87089J600
CRUSCOTTO 400mm
CONTROL PANEL 400mm
ZAN
14
0C7516
87089J100
CRUSCOTTO 800mm
CONTROL PANEL 800mm
ZAN
14 * 50389N800
CRUSCOTTO 400mm
CONTROL PANEL 400mm
OEM
14 * 50389N900
CRUSCOTTO 800mm
CONTROL PANEL 800mm
OEM
15
0L0113
543821900
GUARNIZIONE X CRUSCOTTO
GASKET, CONTROL PANEL
16
0C7164
51589A700
MANIGLIA
HANDLE
ELX
16
0C8190
054887A800
MANIGLIA
HANDLE
ZAN
16
0A5021
854864203
MANIGLIA
HANDLE
OEM
17
0C0138
516860801
CERNIERA
HINGE, DOOR
18
0C0139
516860901
CERNIERA
HINGE, DOOR
19
0C7157
50389G300
PORTA
DOOR
ELX, ZAN
19 * 50389MB01
PORTA
DOOR
OEM
20
0C7158
50489CQ00
CONTROPORTA
INNER DOOR
21
0C0201
830898200
MAGNETE PER PORTA
MAGNET, DOOR
*
0C7163
085589CT01
ASSIEME PORTA
COMPLETE DOOR
ELX
*
0C7165
085589CU02
ASSIEME PORTA
COMPLETE DOOR
ZAN
*
0C7627
085589CV00
ASSIEME PORTA
COMPLETE DOOR
OEM
22
006573
830889001
GRIGLIA DI FONDO
GRATE FOR BOTTOM
23
0C0611
522854700
BACINELLA PER OLIO
BASIN FOR OIL
24
0C0612
528822801
SUPPORTO MANIGLIA BACINELLA
SUPPORT FOR HANDLE, BASIN
25
006131
516849501
MANIGLIA BACINELLA
HANDLE, BASIN
26
0C0765
529890200
COPERCHIO
LID
27
0C0614
511819000
MANIGLIA COPERCHIO
HANDLE, LID
28
006133
850894500
CESTELLO, 1/2
BASKET, 1/2
330 x 137 H 142
29
006539
878824600
CESTELLO INTERA VASCA
FULL WELL SIZE BASKET
330 x 285 H 142
31
0C7345
548877V00
ADATTATORE MANOPOLA
KNOB ADAPTER
ELX
32
0C7481
548877L00
GHIERA
RING, KNOB
ELX
32
0C7485
548879W00
GHIERA
RING, KNOB
ZAN, OEM
33
069567
218912211
MOLLA PER GHIERA
SPRING, RING KNOB
34
0C6670
511850G01
MANOPOLA
KNOB
ELX
34
0C7232
548878201
MANOPOLA
KNOB
ZAN
34
0A5621
548865500
MANOPOLA
KNOB
OEM
35
0C0137
516860700
PIASTRA GIUNZIONE APPARECC.
JOINTING REAR PLATE
From sr. Nr/ Da Ser. Nr.: 116
Page: 5 Ed. 2015 12
Doc. Nr.: 59785GA00
FRIGGITRICI ELETTRICHE 18L E900XP
ELECTRIC FRYERS 18L E900XP
Pos
Spare
Part
Code
Factory Code
Descrizione
Description
Ref./Note
51
006567
516851400
SUPPORTO CESTELLI
SUPPORT, BASKET
52
0C0766
522838400
COPERCHIO SCATOLA RESISTENZE
COVER, HEATING ELEMENTS BOX
53
0C0767
524886300
COPERTURA SINISTRA
LEFT END COVER
54
0C0768
524886500
COPERTURA CENTRALE
CENTRAL COVER
230 V
55
0C0769
524886200
COPERTURA DESTRA
RIGHT END COVER
56
0C0770
528826400
SUPPORTO SINISTRO RESISTENZE
LEFT SUPPORT, HEAT.ELEMENT
57
053671
640800800
MICROINTERRUTTORE
MICROSWITCH
57a
045404
246214023
PIASTRINA ISOLANTE
INS. PLAQUE
58
0C0771
853849902
SCATOLA RESISTENZE
HEATING ELEMENTS BOX
59
0C0772
516853101
PERNO DESTRO
RIGHT HINGE
60
0C0773
528826300
SUPPORTO DESTRO RESISTENZE
RIGHT SUPPORT, HEAT.ELEMENT
61
052330
446578713
INTERRUTTORE CON TERMOSTATO
SWITCH WITH THERMOSTAT
62
005010
876800002
LAMPADA SPIA VERDE
PILOT LAMP; GREEN
63
005011
876800102
LAMPADA SPIA GIALLA
PILOT LAMP; YELLOW
63
0C0687
876800201
LAMPADA SPIA ROSSA
PILOT LAMP; RED
MARINE
64
0A5153
508806002
RONDELLA SUPPORTO CESTELLI
WASHER, BASKET SUPPORT
65
058613
A05714000
MORSETTIERA
TERMINAL BOARD
e,n all serials /
a,o,f,l, up to 6041
66
058608
639805301
MORSETTIERA 2,5/16mm²
TERMINAL BOARD 2,5/16mm²
c,h all serial /
a,o,f,l from 6051
66
006854
639806600
MORSETTIERA 1,5/16mm²
TERMINAL BOARD 1,5/16mm²
b,g,m
66
002277
639805500
MORSETTIERA 2,5/35mm²
TERMINAL BOARD 2,5/35mm²
d,i
67
057783
452140500
FUSIBILE
FUSE
All pnc
68
059078
694502400
FILTRO LC
LC STRAINER
69
049303
694605400
FILTRO TRIFASE
RADIO INTERFERENCE FILTER
70
004472
646808800
TERMOSTATO DI SICUREZZA
SAFETY THERMOSTAT
71
007080
648807700
CONTATTORE
CONTACTOR
72
056582
652800401
PORTAFUSIBILE
FUSE HOLDER
c,h,a,o,f,l,b,g,m,d,i
Up to 6041
72a
0C0774
527815701
SUPPORTO FUSIBILI
SUPPORT, FUSE
c,h,a,o,f,l,b,g,m,d,i
Up to 6041
73
052262
214582200
MOLLETTA FISSAGGIO CAPILLARI
SPRING, FIX CAPILLARY
74
006571
617822101
RESISTENZA 5,5kW 400V
HEATING ELEMENT 5,5kW 400V
a,b,e,f,g,l,m
74
006698
617823900
RESISTENZA 5,5kW 230V
HEATING ELEMENT 5,5kW 230V
c,d,h,i
74
006711
617824300
RESISTENZA 5,5kW 440V
HEATING ELEMENT 5,5kW 440V
n
75
056330
506879501
FASCETTA FISS. BULBO
LIMITATORE
HOSE CLAMP, FIX SAF.THERM.
BULB
76
0C0775
528809100
TRAVERSINO
CROSSBAR
77
0C0776
522838801
GUIDA ANTERIORE RESISTENZE
FRONTAL RUNNER, HEAT.ELEM.
78
0C0777
522851900
GUIDA POSTERIORE RESISTENZE
REAR RUNNER, HEAT.ELEM.
79
066823
214584201
MOLLA PER BULBO TERMOSTATO
SPRING, THERMOSTAT BULB
80 * 206434901
PIASTRINA
PLATE
81
0C0778
527842900
SUPPORTO STAFFA
SUPPORT, HOLDER
82
006083
147098044
ADESIVO SILICONICO gr.100
ADHESIVE PIPE gr.100
84
0C0779
516864500
STAFFA PER RESISTENZE 18Lt
HOLDER FOR HEAT.ELEM. 18Lt
85
0C0780
853858200
ENTRATA CAVO 400m
PIPE FOR CABLE 400mm
1 WELL
85 * 85589C200
ENTRATA CAVO 800mm
PIPE FOR CABLE 800mm
2 WELLS
85 * 835878900
ENTRATA CAVO 400m
PIPE FOR CABLE 400mm
o
86
0H6043
214593100
SPINA PER STAFFA
SPRING, HOLDER
87 * 528826603
SUPPORTO CENTRALE RESISTENZE
CENTRAL SUPPORT,
HEAT.ELEMENT
2 WELLS
88
006710
624806700
AUTOTRASFORMATORE
TRASFORMER
MARINE
89
055368
675800503
BUZZER
BUZZER
MARINE
up to 5461…
From sr. Nr/ Da Ser. Nr.: 116
Page: 6 Ed. 2015 12
Doc. Nr.: 59785GA00
FRIGGITRICI ELETTRICHE 18L E900XP
ELECTRIC FRYERS 18L E900XP
Pos
Spare
Part
Code
Factory Code
Descrizione
Description
Ref./Note
89
0CA485
675401000
BUZZER
BUZZER
1 WELL
90
006610
648806900
RELÉ
RELAY
MARINE
