Ecovacs WINBOT2 (W730) User Manual

The window cleaner robot

WINBOT2(W730)

www.ecovacs.cz	• Unique product, worldwide innovation
	•Winbot2 ensures automatic window cleaning
Automaticcleaning	•Winbot2 is unique; suitable for cleaning windows
	with or without a frame
	• 3-stagecleaning:
	1/The front micro-pad sprayed with cleaning solution,
	moisten, loosen and absorbs dirt
	2/The squeegee collects any fines and dampness
	3/ Another micro-pad brighten up the area
Winbot´ssuctiontothe	•The vacuum pump system assuresWinbot2 stays
windowisabletobear	on the window
theweightof12kg	• Motion ensured by anti-slip driving treads
	• Rectangular shape allows cleaning up the corners
	of windows
	• Double safety system from falling in case of power
	supply: battery backup and safety pod
	• Using of remote control option
	• Beeper power interruptions

Suitablefor cleaning windows with or without

aframe (mirrors)

Automatic

cleaning

Also for frameless windows

Silence cleaning < 55 dB (A)

Detailedspecification

–Systematic motion to cover whole widow area

–Innovation: anti-fall sensors for frameless windows

–Anti-fall sensors for frameless windows

–3-stage cleaning:

1/The front micro-pad sprayed with cleaning solution, moisten, loosen and absorbs dirt

2/The squeegee collects any fines and dampness 3/ Another micro-pad brighten up the area

–The vacuum pump system assuresWinbot stays on the window

–Rectangular shape allows cleaning up the corners of windows

–Double safety system from falling in case of power supply: battery backup and safety pod

–Beeper power interruptions

–Possibility to use ordinary cleaning solution

–Easy and user-friendly control and set, optionally using by remote control

–Smallest window size for proper operation 60 x 45 cm

–Suitable for vertical windows

–Noise level < 55 dB;Voltage 230V / 50 Hz

Accessories:	main unit; safety suction cup; remote control + batteries;
	cleaning solution; cleaning pad; power adapter; manual;
	cleaning pads 3x
Youcan also buy:	ECOPADWIN710 - cleaning pads 3x
	ECOSPWIN710 - anti-slip driving tread 1x
	ECOCSWIN710 - cleaning solution
	ECORCWIN710 - remote control
	ECOADWIN710 - power adapter
	ECOCEWIN710 - extending cable
	ECOSUWIN710 - safety suction cups 2x
Size (H xW x D):	22,4 x 23,2 x 10 cm
Weight (product):	2,9 kg
EAN:	8592417045931

The window cleaner robot

WINBOT2 (W730)

www.ecovacs.cz

Noscratching

You can stop worrying about damaged windows. The body ofWinbot 7 is surrounded by extremely soft material which will not scratch the window frame.

Alsosuitableforframelesswindows

New system of anti-fall sensors provides cleaning for frameless areas. Except of widows,Winbot2 can be used for mirrors, banisters or tables with glass desk.

3-stage cleaning

Step2

The squeegee draws the remaining waterborne dirt off the window.

Step1

The front micro-pad sprayed with cleaning solution, moisten, loosen and absorbs dirt.

Step3

The rear cleaning pad wipes window to

a dry, spotless shine.
