HCD-GRX80/RXD8/RXD8S
SERVICE MANUAL
Ver 1.1 2001. 06
HCD-GRX80/RXD8/RXD8S is the |
|
tuner, deck, CD and amplifier section |
Photo: HCD-RXD8 (SILVER) |
in MHC-GRX80/RXD8/RXD8S. |
AEP Model
HCD-RXD8/RXD8S
UK Model
HCD-RXD8
E Model
Australian Model
HCD-GRX80
|
|
Model Name Using Similar Mechanism |
HCD-GRX8/R800/RX88/RX99 |
CD |
|
|
|
CD Mechanism Type |
CDM38LH-5BD32L |
||
SECTION |
|
|
|
|
Base Unit Type |
BU-5BD32L |
|
|
|
||
|
|
|
|
|
|
Optical Pick-up Type |
KSS-213D/Q-N |
|
|
|
|
TAPE DECK |
Model Name Using Similar Mechanism |
HCD-GRX8/R800/RX88/RX99 |
|
SECTION |
|
|
|
|
Tape Transport Mechanism Type |
TCM-230AWR1/230PWR1 |
|
|
|
||
|
|
|
|
SPECIFICATIONS
— Continued on next page —
COMPACT DISC DECK RECEIVER
9-928-823-12 |
Sony Corporation |
2001F0200-1 |
Home Audio Company |
© 2001.6 |
Shinagawa Tec Service Manual Production Group |
– 1 –
CAUTION
Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.
Notes on chip component replacement
•Never reuse a disconnected chip component.
•Notice that the minus side of a tantalum capacitor may be damaged by heat.
Flexible Circuit Board Repairing
•Keep the temperature of soldering iron around 270˚C during repairing.
•Do not touch the soldering iron on the same conductor of the circuit board (within 3 times).
•Be careful not to apply force on the conductor when soldering or unsoldering.
Laser component in this product is capable of emitting radiation exceeding the limit for Class 1.
This appliance is classified as a CLASS 1 LASER product. The CLASS 1 LASER PRODUCT MARKING is located on the rear exterior.
This caution label is located inside the unit.
SAFETY-RELATED COMPONENT WARNING !!
COMPONENTS IDENTIFIED BY MARK !OR DOTTED LINE WITH MARK !ON THE SCHEMATIC DIAGRAMS AND IN
THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.
– 2 –
MODEL IDENTIFICATION
— BACK PANEL —
Parts No.
PARTS No. |
MODEL |
PRODUCT |
||
COUNTRY |
||||
|
|
|
||
4-214-451-0¹ |
GRX80: E2, AR |
MALAYSIA |
||
4-214-451-1¹ |
GRX80: EA3 |
MALAYSIA |
||
4-214-451-2¹ |
GRX80: SP |
MALAYSIA |
||
4-214-451-3¹ |
GRX80: MX |
INDONESIA |
||
4-214-451-4¹ |
GRX80: MX |
MALAYSIA |
||
4-214-451-5¹ |
GRX80: AUS |
MALAYSIA |
||
4-214-451-6¹ |
GRX80: TW |
MALAYSIA |
||
4-214-451-7¹ |
GRX80: E2 |
INDONESIA |
||
4-214-451-8¹ |
GRX80: EA4, TH |
THAILAND |
||
4-214-451-9¹ |
GRX80: E3 |
MALAYSIA |
||
4-217-515-2¹ |
GRX80: E3 |
INDONESIA |
||
4-217-515-3¹ |
GRX80: EA3 |
INDONESIA |
||
4-215-165-0¹ |
GRX8: AEP, G, CIS, UK |
INDONESIA |
||
4-215-165-2¹ |
GRX8S: AEP |
INDONESIA |
||
4-215-165-3¹ |
GRX8: AEP |
MALAYSIA |
||
• Abbreviation |
|
|
||
G |
: German model |
|
||
MX |
: Mexican model |
|
||
SP |
: Singapore model |
|
||
TW |
: Taiwan model |
|
||
AUS |
: Australian model |
|
||
TH |
: Thai model |
|
||
EA3 |
: Saudi arabia model |
|
||
EA4 |
: Israel model |
|
||
E2 |
: Without SW tuner E model |
|
||
E3 |
: With SW tuner E model |
|
NOTES ON HANDLING THE OPTICAL PICK-UP BLOCK OR BASE UNIT
The laser diode in the optical pick-up block may suffer electrostatic break-down because of the potential difference generated by the charged electrostatic load, etc. on clothing and the human body.
During repair, pay attention to electrostatic break-down and also use the procedure in the printed matter which is included in the repair parts.
The flexible board is easily damaged and should be handled with care.
NOTES ON LASER DIODE EMISSION CHECK
The laser beam on this model is concentrated so as to be focused on the disc reflective surface by the objective lens in the optical pickup block. Therefore, when checking the laser diode emission, observe from more than 30 cm away from the objective lens.
LASER DIODE AND FOCUS SEARCH OPERATION CHECK
Carry out the “S curve check” in “CD section adjustment” and check that the S curve waveform is output four times.
– 3 –
TABLE OF CONTENTS
1. SERVICING NOTE .......................................................... |
5 |
7-10. Printed Wiring Board – Leaf SW Section – ..................... |
45 |
|
|
|
7-11. Schematic Diagram – Leaf SW Section – ........................ |
46 |
|
2. GENERAL .......................................................................... |
6 |
7-12. Schematic Diagram – Deck Section – .............................. |
47 |
|
|
|
7-13. Printed Wiring Board – Deck Section – ........................... |
49 |
|
3. DISASSEMBLY |
|
7-14. Printed Wiring Board – Panel Section – ........................... |
51 |
|
|
7-15. Schematic Diagram – Panel (1/3) Section – |
53 |
||
3-1. Loading Panel |
8 |
|||
7-16. Schematic Diagram – Panel (2/3) Section – |
55 |
|||
3-2. Front Panel |
8 |
|||
7-17. Schematic Diagram – Panel (3/3) Section – |
57 |
|||
3-3. Cassette Lid and Tape Mechanism |
9 |
|||
7-18. Schematic Diagram – CD Motor Section – |
59 |
|||
3-4. CD SW Board and Panel Board |
9 |
|||
7-19. Printed Wiring Board – CD Motor Section – |
61 |
|||
3-5. Disc Tray |
10 |
|||
7-20. Schematic Diagram – Trans Section – |
63 |
|||
|
|
|||
4. SERVICE MODE |
11 |
7-21. Schematic Diagram – Sub Trans Section – ...................... |
65 |
|
7-22. Printed Wiring Board – Trans Section – |
67 |
|||
|
|
|||
5. MECHANICAL ADJUSTMENTS |
14 |
7-23. Printed Wiring Board – Sub Trans Section – ................... |
68 |
|
7-24. IC Block Diagrams ........................................................... |
69 |
|||
6. ELECTRICAL ADJUSTMENTS |
|
7-25. IC Pin Functions ............................................................... |
70 |
|
14 |
|
|
||
7. DIAGRAMS |
|
8. EXPLODED VIEWS |
|
|
|
8-1. Case Section ........................................................................ |
73 |
||
7-1. Circuit Boards Location ...................................................... |
18 |
8-2. Chassis Section ................................................................... |
74 |
|
7-2. Block Diagrams |
|
8-3. Front Panel Section ............................................................. |
75 |
|
• CD Section ....................................................................... |
19 |
8-4. CD Mechanism Deck Section-1 (CDM38LH-5BD32L) .... |
76 |
|
• Deck Section .................................................................... |
21 |
8-5. CD Mechanism Deck Section-2 (CDM38LH-5BD32L) .... |
77 |
|
• Main Section .................................................................... |
23 |
8-6. Base Unit Section (BU-5BD32L) ....................................... |
78 |
|
• Main Power/Sub Power Section ...................................... |
25 |
8-7. TC Mechanism Section-1 (TCM230AWR1/230PWR1) .... |
79 |
|
• Display Section ................................................................ |
27 |
8-8. TC Mechanism Section-2 (TCM230AWR1/230PWR1) .... |
80 |
|
7-3. Printed Wiring Board – BD (CD) Section – ....................... |
31 |
|
|
|
7-4. Schematic Diagram – BD (CD) Section – .......................... |
33 |
9. ELECTRICAL PARTS LIST ........................................ |
81 |
|
7-5. Printed Wiring Board – Main Section – .............................. |
35 |
|
|
|
7-6. Schematic Diagram – Main (1/4) Section – ........................ |
37 |
|
|
|
7-7. Schematic Diagram – Main (2/4) Section – ........................ |
39 |
|
|
|
7-8. Schematic Diagram – Main (3/4) Section – ........................ |
41 |
|
|
|
7-9. Schematic Diagram – Main (4/4) Section – ........................ |
43 |
|
|
– 4 –
SECTION 1
HOW TO OPEN THE DISC TRAY WHEN POWER SWITCH
TURNS OFF
1 Remove the Case.
3 Pull-out the disc tray.
2 Turn the cam to the direction of arrow.
Note for Installation (ROTARY ENCODER)
BU cam
Note:When attaching the Base unit, Insert the section A into the groove of BU cam.
Section A
Groove
Note:When attaching the BU cam, engage the Rotary encoder switch as shown in the figure.
CD-TEXT
This unit is provided with a simple CD-TEXT display function.
The CD-TEXT contents of 20 tracks are displayed on the fluorescent display tube.
Since the function is simple, some special characters may not be displayed, or may be displayed as other characters.
– 5 –
SECTION 2
Front Panel
1 |
2 |
3 |
4 |
5 |
6 |
7 |
62
61
60
59
58
57
56 55 54 53 52
51 50 49 48
47 46 45 44
43 42 41 40
39 38 37
36 35 34
33 32
8
9
10
11
12 13 14
19 15 16 17 18
20 21
22
23
24
25
26
27
28
29
30
31
– 6 –
LOCATION OF PARTS AND CONTROLS
1 |
1/u(Power) button and indicator |
18 |
SYNC BASS button |
40 |
MIC LEVEL knob |
2 |
DEMO (STANDBY) POWER SAVE |
19 |
REC PAUSE/START button and |
41 |
BEAT SPEED button |
|
button (RXD8/RXD8S) |
|
indicator |
42 |
BEAT SELECT button |
|
DEMO button (STANDBY) (GRX80) |
20 |
DBFB button |
43 |
BEAT ON/OFF button and indicator |
3 |
DISC 1 button and indicator |
21 |
SURROUND button |
44 |
P FILE MEMORY button |
4 |
DISC 2 button and indicator |
22 |
HI DUB button |
45 |
GEQ CONTROL button |
5 |
DISC 3 button and indicator |
23 |
CD SYNC button |
46 |
FILE SELECT |
6 |
DISC SKIP/EX–CHANGE button |
24 |
VOLUME knob |
47 |
EFECT button |
7 |
§(Eject) button |
25 |
PHONES jack |
48 |
((B deck) button and indicator |
8 |
Disc tray |
26 |
ENTER/NEXT button and indicator |
49 |
9(B deck) button and indicator |
9 |
EDIT DIRECTION/TUNER MEMORY |
27 |
)+ button and indicator |
50 |
((A deck) button and indicator |
|
button |
28 |
JOG/0x)dial and indicator |
51 |
9(A deck) button and indicator |
10 |
PLAY MODE/DOLBY NR/PTY button |
29 |
GROOVE button and indicator |
52 |
FUNCTION button |
|
(RXD8/RXD8S) |
30 |
–0button and indicator |
53 |
SYNC BASS H indicator |
|
PLAY MODE/DOLBY NR button |
31 |
AUTO BPM button and indicator |
54 |
SYNC BASS L indicator |
|
(GRX80) |
32 |
PAD B button and indicator |
55 |
SYNC EQ indicator |
11 |
REPEAT/STEREO/MONO button |
33 |
PAD A button and indicator |
56 |
EFECT indicator |
12 |
pbutton |
34 |
MIX MIC jack |
57 |
Remote sensor |
13 |
^(CD) button and indicator |
35 |
FLASH button |
58 |
DISPLAY button |
14 |
TUNER/BAND button |
36 |
LOOP button |
59 |
SPECTRUM ANALYZER button |
15 |
NON-STOP button and indicator |
37 |
JAM button and indicator |
60 |
CLOCK/TIME SET button |
16 |
KARAOKE PON/MPX button |
38 |
LEVEL button |
61 |
TIMER SELECT button and indicator |
17 |
SYNC EQ button |
39 |
MIX button |
62 |
Display Window |
This section is extracted from instruction manual.
– 7 –
SECTION 3
Note: Follow the disassembly procedure in the numerical order given.
3-1. LOADING PANEL
Claws
3 Loading panel
1 Turn the cam to the direction
of arrow.
2 Pull-out the disc tray.
3-2. FRONT PANEL
9 Flat type wire (CN303)
8 Flat type wire
2 Screw (BVTT3x6) (CN304) Lead wire
6 Screw (BVTT3x6)
Lead wire
0 Front panel
5 Screw
(BVTT3x6)
1 Screw (BVTT3x6)
7 Flat type wire (CN501)
4 Screw (BVTT3x6)
3 Screw (BVTT3x6)
– 8 –
3-3. CASSETTE LID AND TAPE MECHANISM
Portion A
6 Spring
3Cassette holder (R) assembly
4 Cassette holder (L) assembly
2 Release |
|
(Refer to order No. 1) |
Portion C |
Portion B |
1 Release |
|
|
|
Portion A |
3-4. CD SW BOARD AND PANEL BOARD
3 CD SW board |
1 Three screws |
|
(BVTP2.6x8) |
||
|
4 Knob (Jog)
6 Nut
7 Nut
5 Knob (Vol)
9 Tape mechanism
8Three screws (BVTP2.6x8)
7 Two screws (BVTP2.6x8)
Portion A
5 Spring
Portion C
Portion B
2Three screws (BVTP2.6x8)
8Flat type wire (CN601)
|
9 Four screws |
|
(BVTP2.6x8) |
|
0 Five screws |
|
(BVTP2.6x8) |
|
!¡ Five screws |
!™ Panel board |
(BVTP2.6x8) |
– 9 –
3-5. DISC TRAY
(Perform after removing the front panel.) |
Note:When installing the Disc tray, pull around the flat type wire to |
|
pass through the claw A and claw B, as shown in the figure. |
3 Flat type wire |
(8 core) |
4 Two claws
2 Pull-out the disc tray.
5 Remove the disc tray.
Claw B
Claw A
1Turn the cam the direction of arrow.
– 10 –
SECTION 4
MC Cold Reset
• The cold reset clears all data including preset data stored in the RAM to initial conditions. Execute this mode when returningthe set to the customer.
Procedure:
1. Press three buttons p , ENTER/NEXT , and 1/u simultaneously.
2. “COLD RESET” is displayed on the fluorescent display tube and reset is executed.
CD Delivery Mode
• This mode moves the pick-up to the position durable to vibration. Use this mode when returning the set to the customer after repair.
Procedure:
1. |
Press |
1/u |
button to turn the set ON. |
||||
2. |
Press |
|
|
|
button and |
1/u |
button simultaneously. |
|
LOOP |
||||||
3. |
A message “LOCK” is displayed on the fluorescent indicator tube, and the CD delivery mode is set. |
MC Hot Reset
• This mode resets the set with the preset data kept stored in the memory. The hot reset mode functions same as if the power cord is plugged in and out.
Procedure:
1. |
Press three buttons p , |
ENTER/NEXT |
, and |
DISC 1 |
simultaneously. |
2. |
The fluorescent indicator tube becomes blank instantaneously, and the set is reset. |
Sled Servo Mode
• This mode can run the CD sled motor freely. Use this mode, for instance, when cleaning the pick-up.
Procedure:
1.Press 1/u button to turn the set ON.
2.Press three buttons p , ENTER/NEXT , and § simultaneously.
3.The Sled Servo mode is selected, if “CD” is blanking on the fluorescent indicator tube.
4.With the CD in stop status, When the 0AMS ) knob is rotated in the clockwise direction, the pick-up moves outside. When rotated counterclockwise, it moves inside.
5.To exit from this mode, perform as follows:
1)Move the pick-up to the most inside track.
2)Execute MC cold reset. (Press the three buttons p , ENTER/NEXT , and 1/u button simultaneously.)
Note:
•Always move the pick-up to most inside track when exiting from this mode. Otherwise, a disc will not be unloaded.
•Do not run the sled motor excessively, otherwise the gear can be chipped.
Change-over of AM Tuner Step between 9kHz and 10kHz
• A step of AM channels can be changed over between 9kHz and 10kHz.
Procedure:
1.Press 1/u button to turn the set ON.
2.Select the function “TUNER”, and press TUNER/BAND button to select the BAND “AM”.
3.Press 1/u button to turn the set OFF.
4.Press ENTER/NEXT and 1/u buttons simultaneously, and the display of fluorescent indicator tube changes to “AM 9k STEP” or “AM 10k STEP”, and thus the channel step is changed over.
LED and Fluorescent Indicator Tube All Lit, Key Check Mode
Procedure:
1. Press three buttons p , ENTER/NEXT , and DISC 2 simultaneously.
2.LEDs and fluorescent indicator tube are all turned on. Press DISC 2 button, and the key check mode is activated.
3. |
In the key check mode, the fluorescent indicator tube displays “K 0 V0 J0”. Each time a button is pressed, “K”value increases . However, |
||||
|
once a button is pressed, it is no longer taken into account. |
||||
|
“J” Value increases like 1, 2, 3 ... if rotating |
0AMS ) |
knob in “+” direction, or it decreases like 0, 9, 8 ... if rotating in “-” direction. |
||
|
“V” Value increases like 1, 2, 3 ... if rotating |
|
knob in “+” direction, or it decreases like 0, 9, 8 ... if rotating in “-” direction. |
||
|
VOLUME |
||||
4. |
To exit from this mode, press three buttons in the same manner as step 1, or disconnect the power cord. |
– 11 –
AMS Test Mode
• This mode is used for checking the AMS operations of the tape deck.
JIG
7-819-039-12 Alignment tape, AMS-110A
Procedure:
1.Press the 1/u button to turn the unit ON.
2.Set the tape (AMS-110A).
3.Press the three buttons p , ENTER/NEXT , and DISC 3 button simultaneously.
4.“TEST MODE” is displayed on the fluorescent display tube.
5.Press the FUNCTION button and switch the function to the deck with the tape (AMS-110A).
6.Press the CD SYNC button. “AMS CHECK” is displayed on the fluorescent display tube and the tape is rewound.
7.AMS starts in the normal direction. If the AMS count is 2 at shut down, proceed to step 8. “NG” is displayed at other times, and the deck stops.
8.AMS starts in the opposite direction. If the AMS count is 2 at shut down again, “OK” is displayed.
“NG” is displayed at other times.
Note: The p button of CD section will become effective and the aging of CD section will stop sometime, if the buttons described in step 3 are not pressed simultaneously. In that case, press ^ button and operate the CD section.
Aging Mode
During the aging mode, both the CD player and tape deck are executed together.
• If an error occurs:
Aging stops, and the error state is displayed on the fluorescent display tube.
• If no error occurs:
Aging is repeated.
Procedure:
1.Press the 1/u button to turn the unit ON.
2.Load 10 minute tapes with unbent rec-proof tabs in decks A and B.
3.Set CD on the DISC 1 table.
4.Set the CD mode REPEAT to OFF and PLAY MODE to ALL DISCS.
(Press the PLAY MODE/DOLBY NR and REPEAT/STEREO/MONO buttons to set these modes.)
5.Press the FUNCTION button to switch the function to “CD”.
6. Press the three buttons p , ENTER/NEXT , and DISC SKIP/EX-CHANGE button simultaneously.
7.Aging starts.
8.To end aging, press the 1/u button to turn the unit OFF.
Aging Sequence:
Aging is performed in the following sequence.
• Tape Deck
1.The tape in deck A is rewound. “TAPE A AG-1” is displayed.
2.The FWD side of deck A is played for two minutes. “TAPE A AG-2” is displayed.
3.The tape in deck A is fast forwarded. “TAPE A AG-3” is displayed. Fast forward is carried out for 20 seconds or to the tape e nd.
4.The RVS side of deck A is played for two minutes. “TAPE A AG-4” is displayed.
5.The tape in deck A is rewound. “TAPE A AG-5” is displayed.
6.The FWD side of deck B is played for two minutes. “TAPE B AG-2” is displayed.
7.The tape in deck B is fast forwarded. “TAPE B AG-3” is displayed. Fast forward is carried out for 20 seconds or to the tape e nd.
8.The RVS side of deck B is played for two minutes. “TAPE B AG-4” is displayed.
9.The tape in deck A is rewound. “TAPE A AG-5” is displayed.
10.Repeated from step 2.
• CD
1.The tray rotates.
2.DISC 1 is chucked.
3.The TOC is read.
4.The first track is played for 2 seconds.
5.The last track is played for 2 seconds.
6.Repeated from step 1.
– 12 –
• Display when ended abnormally When the tape deck is abnormal:
The state when ended abnormally is displayed.
The contents of display are the same as that during aging.
When the CD player is abnormal:
A message indicating that errors such as “CD MEC ERR” have occurred.
Check the error contents in the following error history display mode.
Error History Display Mode
Mode which enables the history of error occurring in the CD player to be checked.
Execute this mode after ending the aging mode.
Procedure:
1. Press the 1/u button to turn the unit ON.
2. Press the three buttons p , ENTER/NEXT , and CD SYNC simultaneously.
3.A message such as “EMC@@EDC**” is displayed.
@@ : Number of mechanical errors (Up to three past errors)
**: Number of errors (NO DISC ERROR) which occurs after chucking (Up to three past errors)
4.When checking the history of mechanical errors, press the PLAY MODE/DOLBY NR buttons. When checking errors after chucking, press the REPEAT/STERO/MONO buttons to switch the display.
5.Press the 1/u button to end and turn the unit OFF.
6.To erase the error history, perform COLD reset.
(Press the three buttons p , ENTER/NEXT , and DISC 1 simultaneously.
• Viewing the mechanical error history display |
• Viewing the NO DISC ERROR history display |
||||||||
|
(Switch the history by pressing the |
(Switch the history by pressing the |
|||||||
|
|
PLAY MODE/DOLBY NR |
button.) |
|
REPEAT/STERO/MONO |
buttons.) |
|||
Display |
Display |
|
|
|
|||||
|
E@@M**#*$* |
|
|
E@@D##$$%* |
|
||||
@@ : Error number. 00 is the newest. |
@@ : Error number. 00 is the newest |
||||||||
* |
|
: Invalid |
## |
: Error contents |
|||||
|
|
|
|
|
|
01 : Focus error |
|||
# |
|
: Loading |
|
02 : GFS error |
|||||
|
|
D : Stop that is due to a problem of other than mechanism |
|
03 : Setup error |
|||||
|
|
during CLOSE mode. |
|
|
|
|
|
||
|
|
E : Stop that is due to a problem of other than mechanism |
$$ |
: Retries |
|||||
|
|
during OPEN mode. |
|
00 : NO DISC is determined without attempting chucking |
|||||
|
|
C : Stop that is due to a problem of other than mechanism |
|
|
retry |
||||
|
|
during CHUCK UP mode. |
|
02 : NO DISC is determined after chucking retry. |
|||||
|
|
F : Stop that is due to a problem of other than mechanism |
|
|
|
|
|
||
|
|
during EX OPEN mode. |
% : State when determined as NO DISC |
||||||
|
|
|
|
|
|
1 |
: When stopped |
||
$ |
|
: Emerging |
|
2 |
: At setup |
||||
|
|
1 : Stop during CLOSE mode. |
|
3 |
: At TOC READ |
||||
|
|
2 : Stop during CHUCK DOWN mode. |
|
4 |
: When accessing |
||||
|
|
3 : Time limit of EX OPEN mode. |
|
5 |
: When playing |
||||
|
|
5 : Time limit of EX CLOSE mode. |
|
6 |
: When pausing |
||||
|
|
|
|
|
|
7 |
: When manual searching (during play) |
||
|
|
|
|
|
|
8 |
: When manual searching (during pausing) |
* : Invalid
– 13 –
SECTION 5
Precaution
1.Clean the following parts with a denatured alcohol-moistened swab:
record/playback heads |
pinch rollers |
erase head |
rubber belts |
capstan |
idlers |
2.Demagnetize the record/playback head with a head demagnetizer.
3.Do not use a magnetized screwdriver for the adjustments.
4.After the adjustments, apply suitable locking compound to the parts adjusted.
5.The adjustments should be performed with the rated power supply voltage unless otherwise noted.
Torque Measurement
Mode |
Torque meter |
Meter reading |
||
FWD |
CQ-102C |
31 to 71 g • cm |
||
(0.43 – 0.98 oz • inch) |
||||
|
|
|||
|
|
|
|
|
FWD |
CQ-102C |
2 to 6 g • cm |
||
back tension |
(0.02 – 0.08 oz • inch) |
|||
|
||||
REV |
CQ-102RC |
31 to 71 g • cm |
||
(0.43 – 0.98 oz • inch) |
||||
|
|
|||
|
|
|
|
|
REV |
CQ-102RC |
2 to 6 g • cm |
||
back tension |
(0.02 – 0.08 oz • inch) |
|||
|
||||
FF/REW |
CQ-201B |
71 to 143 g • cm |
||
(0.98 – 1.99 oz • inch) |
||||
|
|
|||
|
|
|
|
|
FWD tension |
CQ-403A |
100 g or more |
||
(3.53 oz or more) |
||||
|
|
|||
|
|
|
||
REV tension |
CQ-403R |
100 g or more |
||
(3.53 oz or more) |
||||
|
|
SECTION 6
DECK SECTION |
|
0 dB=0.775V |
|
|
|
1.Demagnetize the record/playback head with a head damagnetizer.
2.Do not use a magnetized screwdriver for the adjustments.
3.After the adjustments, apply suitable locking compound to the parts adjusted.
4.The adjustments should be performed with the rated power supply voltage unless otherwise noted.
5.The adjustments should be performed in the order given in this service manual. (As a general rule, playback circuit adjustment should be completed before performing recording circuit adjustment.)
6.The adjustments should be performed for both L-CH and R-CH.
7.Switches and controls should be set as follows unless otherwise specified.
Tape |
Signal |
Used for |
|
|
|
P-4-A100 |
10 kHz, –10 dB |
Azimuth Adjustment |
|
|
|
WS-48B |
3 kHz, 0 dB |
Tape Speed Adjustment |
|
|
|
P-4-L300 |
315 Hz, 0 dB |
Level Adjustment |
|
|
|
Record/Playback Head Azimuth Adjustment
(Deck A, Deck B)
Note: Perform this adjustments for both decks.
Procedure:
1. Mode : Playback
test tape |
|
|
P-4-A100 |
|
|
(10kHz, –10dB) |
VIDEO IN |
level meter |
|
set |
+ |
|
– |
2.Turn the adjustment screw and check output peaks. If the peaks do not match for L-CH and R-CH, turn the adjustment screw so that outputs match within 1 dB of peak.
L-CH |
output |
|
|
|
peak |
within |
|
|
|
level |
|
|
||
|
|
|
||
|
|
1 dB |
|
within 1dB |
|
R-CH |
|
|
|
screw |
peak |
|
|
|
|
|
|
|
|
position |
|
|
|
screw |
|
|
L-CH |
R-CH |
|
|
|
position |
||
|
|
peak |
peak |
|
– 14 –
3. Mode: Playback
test tape P-4-A100 (10kHz, –10dB)
oscilloscope
MD OUT
set
Waveform of oscilloscope
in phase 45° |
90° |
135° 180° |
good |
|
wrong |
4.After the adjustments, apply suitable locking compound to the parts adjusted.
Adjustment Location: Playback Head (Deck A)
Record/Playback/Erase Head (Deck B)
Reverse Foward
Tape Speed Adjustment (Deck A)
Note: Set the test mode using the following method and begin tape speed adjustment.
In the test mode, the speed will switch to double speed or normal speed each time the HI DUB button is pressed.
Procedure:
With the power turned ON, press the p button, ENTER/NEXT button, and DISC 3 button simultaneously.
(The “CD TYPE INDICATOR” on the fluorescent display tube will blink while in the test mode.)
To exit the test mode, press the 1/u button.
1.Insert the WS-48B into deck B.
2.Press the ( button of deck B.
3.Press the HI DUB button and play the tape at double speed.
4.Adjust RV1001 of the LEAF SW board so that the reading of the frequency counter becomes 6000 ± 180 Hz.
5.Press the HI DUB button and play the tape at normal speed.
6.Adjust RV1002 of the LEAF SW board so that the reading of the frequency counter becomes 3000 ± 90 Hz.
Adjustment Location: LEAF SW board
Sample Value of Wow and flutter
W.RMS (JIS) less than 0.3% (test tape: WS-48B)
Playback Level Adjustment (Deck A, Deck B)
Procedure:
Mode: Playback
test tape
P-4-L300 level meter (315Hz, 0dB)
set
MD OUT
Deck A is RV311 (L-CH) and RV411 (R-CH), deck B is RV301 (L-CH) and RV401 (R-CH)
so that adjustment within the following adjustment level.
Adjustment level:
CN301 playback level: 301.5 to 338.3 mV (–8.2 to –7.2 dB) level difference between the channels: within ± 0.5 dB
Adjustment Location: AUDIO board
Adjustment Location
[LEAF SW BOARD]
RV1001(High Speed)
RV1002(Normal Speed)
RV1002 RV1001
– 15 –
Record Bias Adjustment (Deck B)
Procedure:
INTRODUCTION
When set to the test mode performed in Tape Speed Adjustment, when the tape is rewound after recording, the “REC memory mode” which rewinds only the recorded portion and playback is set.
This “REC memory mode” is convenient for performing this adjustment. During recording, the input signal FUNCTION will automatically switch to VIDEO.
(After recording, press the –0 button without stopping will return to the position where recording was started.)
1.Press FUNCTION button to select VIDEO. (This step is not necessary if the above test mode has already been set.)
2.Insert a tape into deck B, press the r REC button, and then press the ( button to start recording.
3.Mode: Record
VIDEO (AUDIO) IN
1)315 Hz } 50 mV (–23.8 dB)
2)10 kHz
AF OSC |
blank tape |
|
|
600 Ω |
CS-123 |
attenuator |
|
|
set |
4. Mode: Playback
recorded |
level meter |
||||
position |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
set
MD OUT
Record Level Adjustment (Deck B)
Procedure:
INTRODUCTION
When set to the test mode performed in Tape Speed Adjustment, when the tape is rewound after recording, the “REC memory mode” which rewinds only the recorded portion and playback is set.
This “REC memory mode” is convenient for performing this adjustment. During recording, the input signal FUNCTION will automatically switch to VIDEO.
(After recording, press the –0 button without stopping will return to the position where recording was started.)
1.Press FUNCTION button to select VIDEO 1. (This step is not necessary if the above test mode has already been set.)
2.Insert a tape into deck B, press the r REC button, and then press the ( button to start recording.
3.Mode: Record
VIDEO (AUDIO) IN 315Hz 50 mV (–23.8 dB)
AF OSC |
blank tape |
|
|
600 Ω |
CS-123 |
attenuator |
|
|
set |
4. Mode: Playback
recorded |
level meter |
||||
position |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
set
MD OUT
5.Confirm playback the signal recorded in step 2 become adjustment level as follows.
If these levels do not adjustment level, adjust the RV341 (L-CH) and RV441 (R-CH) on the AUDIO board to repeat steps 3 and 4.
Adjustment level: The playback output of 10 kHz level difference against 315 Hz reference should be ± 1.0 dB.
Adjustment Location: AUDIO board
5.Confirm playback the signal recorded in step 2 become adjustment level as follows.
If these levels do not adjustment level, adjust the RV301 (L-CH) and RV351 (R-CH) on the MAIN board to repeat steps 3 and 4.
Adjustment level:
CN403 playback level: 47.2 to 53.0 mV (–24.3 to –23.3 dB)
Adjustment Location: MAIN board
Adjustment Location: |
|
|
[MAIN BOARD] (Conductor Side) |
|
|
|
Record Level (L CH) |
||
[AUDIO BOARD] (Conductor Side) |
|
|
||
|
|
RV301 |
|
|
|
|
|
|
|
RV341(Lch),RV441(Rch) |
RV311(Lch),RV411(Rch) |
43 42 |
||
Record Bias |
Playback Level (Deck A) |
56 |
29 |
|
|
|
|
1 |
28 IC301 |
|
|
|
14 |
15 |
|
|
|
CN303 |
|
RV301 RV401 |
|
|
RV351 |
|
|
|
Record Level (R CH) |
||
|
|
RV411 |
||
RV441 RV341 |
RV311 |
|
|
RV301(Lch),RV401(Rch)
Playback Level (Deck B)
– 16 –
CD SECTION
Note:
1.CD Block is basically constructed to operate without adjustment. Therefore, check each item in order given.
2.Use YEDS-18 disc (3-702-101-01) unless otherwise indicated.
3.Use an oscilloscope with more than 10MΩ impedance.
4.Clean the object lens by an applicator with neutral detergent when the signal level is low than specified value with the following checks.
S Curve Check
|
oscilloscope |
BD board |
|
TP (FE) |
+ |
TP (VC) |
– |
Procedure :
1.Connect the oscilloscope to test points TP (FE) and TP (VC).
2.Connect TP (FEI) and GND, and TP (AGCCON) and GND of the BD board with lead wires.
3.Press the 1/u button to turn the set ON.
4.With the disc (YEDS-18) loaded, press the ^ button and perform focus search. (Focus search will be performed in the same way even while the disc table is pushed in and out.)
5.Check the symmetry and peak to peak level of the oscilloscope waveform (S curve) at this time.
S-curve waveform
symmetry
A
Within 4 ± 1 Vp-p
B
6. After check, remove the lead wire connected in step 2.
Note: • Try to measure several times to make sure than the ratio of A : B or B : A is more than 10 : 7.
• Take sweep time as long as possible and light up the brightness to obtain best waveform.
RF Level Check
|
oscilloscope |
BD board |
|
TP (RF) |
+ |
TP (VC) |
– |
Procedure :
1.Connect oscilloscope to test point TP (RF) and TP (VC) on BD board.
2.Connect TP (AGCCON) and GND of the BD board with lead wires.
3.Press the 1/u button to turn the set ON.
4.Put disc (YEDS-18) in and playback 5track.
5.Confirm that oscilloscope waveform is clear and check RF signal level is correct or not.
6.After check, remove the lead wire connected in step 2.
HCD-GRX80/RXD8/RXD8S
SECTION 7
Note: Clear RF signal waveform means that the shape “ ◊” can be |
7-1. CIRCUIT BOARDS LOCATION |
clearly distinguished at the center of the waveform. |
|
RF signal waveform
VOLT/DIV : 200mV
TIME/DIV : 500ns
SUB TRANS board (RXD8/RXD8)
level : 1.45 ± 3 Vp-p
CD SW board
E-F Balance (1 Track Jump) check
oscilloscope
BD board |
|
|
ENCAPSULATED COMPONENT |
|
|
(GRX80:E2.E3,EA3,AR,SP,TW,MX,AUS) |
|
|
|
PANEL board |
|
|
|
TUNER unit |
|
TP (TE) |
+ |
|
|
|
(GRX80:EA4,TH/RXD8/RXD8S) |
||
TP (VC) |
– |
|
|
Procedure:
1.Connect oscilloscope to test point TP (TE) on BD board.
2.Press the 1/u button to turn the unit ON.
3.Put disc (YEDS-18) in to play the number five track.
4.Press the ^button.
5.Check the level B of the oscilloscope's waveform and the A (DC voltage) of the center of the Traverse waveform.
Confirm the following:
•A/B x 100 = less then ± 22 (%)
•B = 1.3 ± 0.6 Vp-p
TRANS board
MAIN board |
ENCAPSU LATED COMPONENT/TUNER |
|
unit is supplied as the assembled block. |
||
|
1 track jump waveform |
Center of the waveform |
|
B |
|
A (DC voitage) |
MOTOR (TURN) board |
0V |
CONNECTOR board |
|
|
Symmetry |
BD board |
|
|
level : 1.3 ± 0.6 Vp-p |
|
Adjustment Location :
SENSOR board
[ BD BOARD ] — SIDE A —
MOTOR (SLIDE) board
TP
(VC) |
LEAF SW board |
|
TP (RF)
AUDIO board
TP (AGCCON)
TP (FE)
TP
(TE) TP (FE1)
– 17 – |
– 18 – |
HCD-GRX80/RXD8/RXD8S |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
7-2. BLOCK DIAGRAMS |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
– CD SECTION – |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
IC381 |
IC381 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
1 |
D.OUT |
CD DIGITAL |
|
|
|
|
|
X101 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
OUT |
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
OPTICAL PICK-UP BLOCK |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
OPTICAL |
|
|
|
|
|
16.9344MHz |
|
|
||
|
|
|
FOCUS/TRACKING SERVO. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
RF AMP |
|
|
|
|
|
71 |
|
|
|
|
|
|
|
|
89 • 90 |
|
|
|
|
|
|
|
|
|
|
IC101 (1/2) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
B+ |
|
|
|
|
|
|
|
|
DOUT |
|
|
|
|
|
|
|
|
XTAI • XTAO |
|
|
|||
DETECTOR |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
K |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
E |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
A |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
4 |
|
38 |
PD1 |
RF O 33 |
44 |
RF |
|
|
|
|
|
|
|
|
|
|
|
LOUT1 86 |
L-CH |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||
|
A |
D |
D |
2 |
|
39 |
PD2 |
|
|
|
|
|
|
|
|
|
DIGITAL SIGNAL PROCESSOR |
|
|
|
|
|
|
|
|
|
5 |
|
|
|
LOCK |
19 |
29 |
LOCK |
|
|
|
|
|
|
|
|
|
LOUT2 93 |
R-CH |
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
IC103 |
|
|
|
|
|
|
|||||||
|
B |
C |
C |
10 |
|
41 |
F |
C.OUT |
24 |
14 |
CNIN |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
6 |
|
42 |
E |
SENS1 |
25 |
15 |
SEIN |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||
|
|
|
B |
|
|
|
|
|
|
|
DATAO |
XLTO |
CLKO |
|
|
SPOD |
DATA XLAT CLOK |
SCOR |
SQSO |
SQCK |
SENS |
XRST |
|
|
|
|
|
F |
|
|
|
|
|
SENS2 |
26 |
|
MDP |
FOK |
|
|
|
||||||||||
|
|
|
|
|
|
|
|
|
15 16 17 |
27 23 |
21 |
10 11 12 |
75 |
8 |
7 |
9 |
100 |
|
|
|
|||||
|
|
|
|
|
|
2 |
FEI |
|
|
|
|
|
|
||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
1 |
FEO |
FE O |
6 |
|
|
|
|
|
|
|
S101 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
FE M |
7 |
|
|
|
|
|
|
|
LIMIT |
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
45 |
TEO |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
CD CLK |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
47 |
TEI |
TA M 12 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
TA O 13 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
CD DATA |
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
DATA |
22 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
SENS2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
XLT |
21 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
CLK 20 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
SCOR |
|
|
|
|
|
|
|
LD DRIVE |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
SQ DATA |
|
|
|
|
|
|
36 LD |
FOK |
27 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
SQ CLK |
|
||
|
|
|
|
|
Q101 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
SENS |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
LASER |
|
|
|
|
|
37 |
PD |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
DIODE |
|
|
|
|
|
|
|
XRST |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
23 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
XRST |
|
|
|
|
|
TRACKING |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
XLAT |
C |
|
|
|
FOCUS |
|
|
|
9 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
COIL |
COIL |
|
|
|
MUTE |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
T+ |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
TABLE |
|
MAIN |
|
|
|
|
|
|
15 |
TRACKING |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
27 |
|
|
|
|
|
|
|
|
|
|
|
|
|
SECTION |
||||
|
|
|
|
|
|
16 |
COIL DRIVE |
|
|
|
|
|
|
|
|
|
|
|
|
|
SENSOR |
TRAY SENS |
|||
|
|
|
|
|
T– |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
IC702 |
(Page 23) |
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
FOCUS/TRACKING |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
2-AXIS |
|
|
COIL DRIVE |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
DISC |
|
|
|
|
|
|
|
|
|
IC102 (1/2) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
DEVICE |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
SENSOR |
DISC SENS |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
F – |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
IC703 |
|
|
|
|
|
|
|
18 |
FOCUS |
|
26 |
|
|
|
|
|
|
|
|
|
|
|
|
Q701 |
|
|
||
|
|
|
|
|
F+ |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
17 |
COIL DRIVE |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
ROTARY |
ENC 1 |
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
ENCODER |
ENC 2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
S811 |
ENC 3 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
SLED/SPINDLE |
|
|
|
SLED |
|
|
|
|
|
|
|
|
|
|
|
|
TURN |
|
S801 |
|
|
|
|
|
|
MOTOR DRIVE |
|
|
SERVO |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
MOTOR DRIVER |
OPEN/CLOSE |
OUT-OPEN |
|
||||
|
|
|
|
IC102 (2/2) |
|
|
IC101 (2/2) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
IC701 |
|
DET |
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
M102 |
M |
11 |
|
SLED MOTOR |
6 |
16 SL O |
SL P 14 |
|
|
|
|
|
|
|
M701 |
M |
|
7 |
OUT1 |
IN1 |
3 |
TBL.L |
|
||
• |
|
DRIVE |
|
|
|
|
|
|
|
TURN |
|
2 |
OUT2 |
IN2 |
6 |
TBL.R |
|
||||||||
SLED MOTOR |
|
12 |
|
|
|
|
|
|
|
|
|
|
|
|
|
MOTOR |
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
SLIDE |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
MOTOR DRIVER |
|
|
• R CH: Same as L ch |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
IC801 |
|
|
|
|
M101 |
|
13 |
SPINDLE MOTOR |
|
|
|
|
|
|
|
|
|
|
|
|
M801 |
|
|
|
|
|
|
|
• SIGNAL PATH |
|
M |
3 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
: CD |
|||||
SPINDLE |
• |
|
DRIVE |
|
|
|
|
|
|
|
|
|
|
|
|
|
4 |
OUT2 |
RIN |
2 |
LD IN |
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
SLIDE |
M |
|
|||||||||
MOTOR |
|
14 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
7 |
|
FIN |
10 |
LD OUT |
: Digital out |
||
09 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
MOTOR |
|
|
OUT1 |
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
– 19 – |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
– 20 – |
|
|
– DECK SECTION – |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
S1004 |
S1008 |
|
|
|
|
|
PB A/B |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
MS OUT |
|||
|
|
|
|
|
|
|
|
A CrO2 |
B CrO2 |
|
|
|
|
|
||
|
|
|
|
RV311 |
16 |
|
|
17 |
19 |
28 |
27 |
26 |
|
|
MAIN SECTION |
|
|
|
|
IC611 |
PLAYBACK |
|
|
|
|
|
|||||||
|
|
|
PB-A/B |
|
|
A 120/70 |
B 120/70 |
|
|
|
|
|
|
|||
|
|
|
LEVEL |
|
|
|
|
MS |
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
||||||
|
L |
|
|
DECK A |
|
|
|
70 |
|
|
|
|
|
|
|
|
|
|
|
|
A IN |
|
|
|
PAS |
|
|
|
|
|
|
||
|
|
|
48 |
|
|
|
|
|
|
PB OUT |
|
|
|
|||
HP101 |
|
|
|
|
|
|
|
|
|
|
40 |
|
PB L |
|||
|
|
|
46 |
B IN |
|
|
120 |
|
|
|
|
|
|
|||
PB HEAD |
|
R CH |
|
|
|
|
|
DOL |
|
LM ON/ 25 |
|
LM ON/OFF |
||||
|
|
|
|
|
|
|
|
|
|
|||||||
(DECK A) |
R |
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
DOLBY NR |
|
|
OFF |
|
|
|
|||
|
|
|
|
|
|
|
|
DOLBY NR |
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
NORM/ |
|
|
|
|
|
|
|
|
RV301 |
|
|
|
IC301 |
|
|
|
|
|
|
NORM/HIGH |
|
|
|
|
|
|
|
|
|
|
|
|
HIGH |
18 |
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
IC601 |
PLAYBACK |
|
|
|
|
|
|
|
|
NR ON/ |
23 |
|
NR ON/OFF |
|
|
|
|
LEVEL |
|
|
|
|
|
|
|
|
OFF |
|
|
|
|
L |
|
|
DECK B |
|
|
|
RV301 |
|
|
|
|
|
24 |
|
REC/PB/PASS |
|
|
|
|
|
|
|
|
|
|
|
PB |
|
||||
REC/PB HEAD |
|
|
|
|
|
|
|
REC LEVEL |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
RECOUT |
DOLBY |
|
|
|
|
|
|||
(DECK B) |
|
|
|
|
|
|
|
39 |
|
RIN |
|
|
|
|||
|
R |
R CH |
|
|
|
|
|
|
|
TYPE B |
|
44 |
|
REC L |
||
|
|
|
|
36 |
EQOUT |
EQIN |
38 |
|
|
BIAS SW |
|
|
BIAS ON/OFF |
20 |
|
BIAS ON/OFF |
|
|
|
|
|
|
|
|
|
|
|
|
|
RM ON/OFF |
22 |
|
RM ON/OFF |
|
|
3 |
1 |
|
|
|
|
|
C |
M |
|
|
ALC ON/OFF |
15 |
|
ALC ON/OFF |
|
|
|
|
|
|
|
32 33 |
|
|
|
|
|
|
|||
|
|
|
IC602 |
|
|
|
|
|
|
|
|
|
|
|
||
|
|
P |
R |
|
|
|
|
|
|
|
|
|
|
|
|
RELAY |
HRPE101 |
|
|
4 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
REC/PB |
|
|
|
|
|
|
|
|
|
CAP MOTOR |
|
CAPM CNT1 |
||
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
RV341 |
|
|
|
|
|
|
|
|
|
CAPM CNT2 |
||
|
|
|
|
|
|
|
|
|
|
|
|
CONTROL |
|
|||
|
|
|
|
REC |
+7.5V |
|
|
|
|
|
|
|
Q336-343 |
|
|
|
|
|
|
|
BIAS |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Q623 |
|
|
|
|
M1 |
|
SPEED |
SWITCH |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
CAPSTAN |
M |
CONTROL |
CAP M H / L |
|||
|
|
|
|
|
|
|
|
|
|
Q335 |
||||||
|
|
|
|
|
|
|
|
|
|
MOTOR |
|
Q1001 |
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
REC BIAS |
|
|
|
|
ERASE BIAS |
BIAS OSC |
|
|
|
|
T621, Q621, 622 |
|
|
|
|
|
ERASE HEAD X |
|
|
|
|
|
|
|
|
|
|
|
|
RV1002 |
RV1001 |
|
REEL |
|
|
NORMAL |
HIGH |
|
|
|
|
|
DETECT |
A SHUT |
||
|
SPEED |
SPEED |
|
||
|
|
IC1001 |
|
||
|
|
|
|
|
|
|
|
|
|
REEL |
|
|
|
|
|
DETECT |
B SHUT |
|
|
|
|
IC1002 |
|
|
• R CH : Same as L ch |
|
|
S1001 (A PLAY) |
|
|
|
+5V |
|
A PLAY |
|
|
• SIGNAL PATH |
|
|
S1002 (B PLAY) |
B PLAY |
|
: PB (DECK A) |
|
|
|
|
|
|
|
|
|
|
|
: PB (DECK B) |
|
S1003 |
|
A HALF |
|
: REC (DECK B) |
|
(A HALF) |
+5V |
|
|
|
|
|
||
|
|
|
|
+5V |
|
|
|
|
S1005 |
|
|
|
|
|
(REC A) |
|
|
09 |
|
|
S1006 |
|
B HALF/REC A/REC B |
|
|
|
(B HALF) |
|
|
|
|
S1009 |
|
|
|
(REC B) |
|
• PLUNGER SOLENOID is supplied |
MAIN SECTION |
|
|
as the MECHANICAL BLOCK ASSY. |
|
||
|
|
||
A DECK/ |
TRIGGER |
B TRIG |
|
MOTOR |
|||
B DECK |
|
||
CONTROL |
|
||
PLUNGER |
A TRIG |
||
Q331-334 |
|||
|
|
HCD-GRX80/RXD8/RXD8S
B
MAIN
SECTION
(Page 23)
– 21 – |
– 22 – |
HCD-GRX80/RXD8/RXD8S |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
GRX80:EA3 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
ECHO PROCESSOR |
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
– MAIN SECTION – |
|
|
IC711 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
2 |
LPF 1 IN |
|
LPF 2 OUT |
9 |
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||
|
|
RV712 |
|
|
|
|
ECHO |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
MIC |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
J711 |
|
|
|
|
LEVEL |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
LEVEL |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
MIX |
|
|
|
|
|
|
|
R-CH |
|
|
|
|
|
|
|
|
|
|
|
|
MIC |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
(Page 28) |
|
IC712(1/2) |
|
IC712(2/2) |
|
|
|
|
|
|
|
|
|
|
|
|
SPE SIG |
E |
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
DISPLAY |
|
IC181(1/2) |
|
|
|
IC181(2/2) |
|
|
|
|
|
|
|
|
|
|
WAKE UP |
|||
SECTION |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
STANDBY LED |
|||||
|
|
|
MUTE |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
F |
DJ-SIG |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
IIC DATA |
DISPLAY |
||
|
|
Q181 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
IIC CLK |
SECTION |
|
DJ-MUTE |
|
|
|
|
|
|
|
EQ |
|
|
|
|
VOLUME |
|
|
|
|
(Page 27) |
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
TIMER LED |
|||||
|
|
GRX80:EA3 |
|
|
|
|
2 |
IC101(1/2) |
|
|
|
|
IC101(2/2) |
|
|
|
|
RESET |
|
|
|
J101 |
|
|
|
|
|
|
30 |
|
|
|
|
|
|
|
|
|
|
|
|
VIDEO/IN |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
EQ |
42 |
Lch |
|
41 |
|
36 Lch |
|
|
|
|
||
(AUDIO) |
|
|
68 |
V |
|
|
|
|
AMP |
|
|
|
|
|
FRONT |
|
||||
L |
|
|
69 |
MD |
|
|
|
|
|
|
|
|
|
|
|
|
|
MUTE |
|
|
|
|
|
SELECT |
|
|
|
|
|
|
|
|
|
|
|
|
|||||
MD IN L |
|
|
66 |
TC |
|
|
|
|
|
|
|
|
|
|
Q113 |
|
|
|||
|
|
SWITCH |
|
58 |
|
|
|
|
|
|
|
|
J191 |
|
||||||
|
|
|
67 |
TU |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
65 |
CD |
|
|
|
R-CH |
57 |
|
|
|
|
|
72 |
|
|
MUTE |
SUPER |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Q191 |
WOOFER |
|
||
MD/VIDEO |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
(AUDIO) |
|
|
|
|
MICON |
|
|
|
|
|
|
38 39 |
37 |
|
|
|
|
|
||
OUT L |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
|
|
INTERFACE |
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
34 33 |
32 |
|
|
|
|
|
|
|
Q201 |
|
|
|
|
|
||
|
|
|
|
|
1 |
2 |
3 |
|
|
|
|
|
|
DBFB |
|
|
|
|
|
|
|
PB L |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
DBFB |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
SWITCH |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
REC L |
|
|
|
|
|
|
|
|
|
|
|
|
Q111,112 |
|
|
|
|
|
|
|
RELAY |
|
|
|
|
|
|
|
|
|
|
100 |
TC RELAY |
|
BASS FRQ. |
44 |
|
|
|
|
|
A SHUT |
|
|
|
|
|
|
|
|
|
|
91 |
A SHUT |
|
|
|
|
|
|
|
|
B SHUT |
|
|
|
|
|
|
|
|
|
|
90 |
B SHUT |
|
DBFB H/L |
7 |
MUTE SW |
|
MUTE |
|
B HALF/REC A/REC B |
|
|
|
|
|
|
|
|
|
|
89 |
B HALF |
|
LINE MUTE |
6 |
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
Q509 |
|
Q192 |
|
||||||
|
A HALF |
|
|
|
|
|
|
|
|
|
|
88 |
A HALF |
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
F RELAY |
|
|||
B |
A PLAY |
|
|
|
|
|
|
|
|
|
|
87 |
A PLAY SW |
|
F RELAY |
3 |
|
|
|
|
B PLAY |
|
|
|
|
|
|
|
|
|
|
86 |
B PLAY SW |
|
|
|
|
|
|
|
|
PB A / B |
|
|
|
|
|
|
|
|
|
|
84 |
PB A/B |
|
WAKE UP |
18 |
|
|
|
|
|
NORM/HIGH |
|
|
|
|
|
|
|
|
|
|
83 |
EQ H//N |
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
ST-BY LED/CLOCK OUT |
39 |
|
|
|
|
||||
DECK |
BIAS ON/OFF |
|
|
|
|
|
|
|
|
|
|
82 |
BIAS |
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
SECTION |
RM ON/OFF |
|
|
|
|
|
|
|
|
|
|
81 |
REC MUTE |
|
IIC DATA |
30 |
|
|
|
|
(Page 22) |
NR ON/OFF |
|
|
|
|
|
|
|
|
|
|
80 |
NR ON/OFF |
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
IIC CLK |
29 |
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
REC/PB PASS |
|
|
|
|
|
|
|
|
|
|
79 |
R/PB PASS |
|
|
|
|
|
|
|
|
CAPM CNT1 |
|
|
|
|
|
|
|
|
|
|
75 |
CAPM CNT1 |
|
TIMER LED |
26 |
|
|
|
|
|
CAPM CNT2 |
|
|
|
|
|
|
|
|
|
|
74 |
CAPM CNT2 |
|
RESET |
12 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
85 |
|
|
|
|
|
|
||
|
ALC ON/OFF |
|
|
|
|
|
|
|
|
|
|
ALC |
|
|
|
RESET |
|
|
|
|
|
LM ON/OFF |
|
|
|
|
|
|
|
|
|
|
78 |
TC MUTE |
|
|
|
MUTE SW |
|
D |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
SWITCH |
|
|||||
|
CAP M H/L |
|
|
|
|
|
|
|
|
|
|
76 |
CAP M H/L |
|
|
|
Q508 |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Q501 |
|
|||||
|
A TRG |
|
|
|
|
|
|
|
|
|
|
73 |
A TRG |
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
AC CUT |
|
|
|
|
||||
|
B TRG |
|
|
|
|
|
|
|
|
|
|
72 |
B TRG |
|
22 |
|
|
|
POWER |
|
|
MS OUT |
|
|
|
|
|
|
|
|
|
|
77 |
AMS IN |
MASTER CONTROL |
(CHECK) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
1 |
|
3 |
|
|
SECTION |
|||||
|
ST L |
|
|
|
|
|
|
|
|
|
38 |
493-LAT |
IC501 |
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
2 |
|
|
RESET |
|
|
(Page 25) |
||||
|
RDS DATA |
|
|
|
|
|
|
|
|
|
47 |
493-DATA |
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
3 |
|
|
|
IC502 |
|
|
|
|||
|
RDS INT |
|
|
|
|
|
|
|
|
|
48 |
493-CLK |
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
1 |
|
|
|
|||
FM/AM TUNER |
ST-DOUT |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
54 |
ST DIN |
|
|
|
|
|
|
|
||
ST-DIN |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
TUNER UNIT IS |
|
|
|
|
|
|
|
|
|
|
|
|
|
D503 |
|
|
|
|||
SUPPLED AS THE |
STEREO |
|
|
|
|
|
|
|
|
|
|
50 |
STEREO |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
ASSEMBLED |
TUNED |
|
|
|
|
|
|
|
|
|
|
51 |
TUNED |
|
|
|
|
|
|
|
BLOCK |
|
|
|
|
|
|
|
|
|
|
|
|
|
+5.6V |
|
|
|
|||
ST CE |
|
|
|
|
|
|
|
|
|
|
52 |
ST CE |
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
X-OUT |
13 |
|
|
|
|
|||
|
ST-MUTE |
|
|
|
|
|
|
|
|
|
|
49 |
ST MUTE |
|
X613 |
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
ST-CLK |
|
|
|
|
|
|
|
|
|
|
53 |
ST DOUT |
|
X-IN |
15 |
16MHz |
|
|
|
|
L CH |
|
|
|
|
|
|
|
|
|
|
55 |
ST CLK |
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
TBL. L |
|
|
|
|
|
|
|
|
|
|
63 |
TBL L |
|
|
|
|
|
|
|
|
TBL. R |
|
|
|
|
|
|
|
|
|
|
65 |
TBL R |
|
XC-IN |
10 |
X601 |
|
|
|
|
SCOR |
|
|
|
|
|
|
|
|
|
|
19 |
SCOR |
|
|
|
|
|
|
|
|
TRAY SENS |
|
|
|
|
|
|
|
|
|
|
61 |
T SENS |
|
XC-OUT |
11 |
32.768KHz |
|
|
• R CH: Same as L ch |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||
|
HOLD |
|
|
|
|
|
|
|
|
|
|
57 |
HOLD |
|
|
|
|
|
|
• SIGNAL PATH |
|
SENS |
|
|
|
|
|
|
|
|
|
|
56 |
SENS |
|
|
|
|
|
|
|
C |
|
|
|
|
|
|
|
|
|
|
|
RY-SW |
36 |
|
|
RY-SW |
: FM |
|||
X RST |
|
|
|
|
|
|
|
|
|
|
59 |
XRST |
|
|
|
|||||
CD CLK |
|
|
|
|
|
|
|
|
|
|
37 |
CD CLK |
|
|
|
|
|
|
: CD |
|
CD DATA |
|
|
|
|
|
|
|
|
|
|
35 |
CD DATA |
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
POWER |
2 |
|
|
POWER ON/OFF |
: PB |
|||
CD |
DISC SENS |
|
|
|
|
|
|
|
|
|
|
60 |
DISC SENS |
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
SECTION |
SQ CLK |
|
|
|
|
|
|
|
|
|
|
33 |
SQ CLK |
|
CD POWER |
5 |
|
|
CD POWER |
: REC |
(Page 20) |
SQ DATA |
|
|
|
|
|
|
|
|
|
|
32 |
SQ DATA |
|
|
|
: VIDEO/MD |
|||
X LAT |
|
|
|
|
|
|
|
|
|
|
58 |
XLT |
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
• Abbreviation |
|||
|
OUT-OPEN |
|
|
|
|
|
|
|
|
|
|
71 |
OUT OPEN |
|
FL SW |
42 |
|
|
FL SW ON/OFF |
|
|
ENC-1 |
|
|
|
|
|
|
|
|
|
|
70 |
ENC1 |
|
STBY RELAY |
43 |
|
|
STANDBY RELAY |
EA3 : Saudi Arabia model. |
|
ENC-2 |
|
|
|
|
|
|
|
|
|
|
69 |
ENC2/DISC-LED |
|
|
|
|
ON/OFF |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
ENC-3 |
|
|
|
|
|
|
|
|
|
|
68 |
ENC3/UP-SW |
|
STK MUTE |
1 |
|
|
STK MUTE |
|
|
LD IN |
|
|
|
|
|
|
|
|
|
|
67 |
LOAD IN |
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
LD OUT |
|
|
|
|
|
|
|
|
|
|
66 |
LOAD OUT |
|
|
|
|
|
|
|
09 |
|
|
|
|
|
|
|
|
|
|
|
22 |
RDS DATA |
RXD8, |
PROTECTOR |
27 |
|
|
PROTECTOR |
|
|
|
|
|
|
|
|
|
|
|
|
21 |
RDS INT |
RXD8S |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
– 23 – |
– 24 – |
HCD-GRX80/RXD8/RXD8S
– MAIN POWER/SUB POWER SECTION –
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
TM402 |
|
|
|
F RELAY |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
SURROUND |
• R CH : Same as L ch |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
SPEAKER |
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
• SIGNAL PATH |
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
THERMAL |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
: FM |
|
|
|
|
|
|
DET |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
• Abbreviation |
||
|
|
|
|
POWER AMP |
|
Q831, 832 |
|
|
|
|
|
|
|
|
|
|
|
RXD8,RXD8S |
|||
|
|
|
|
IC801 |
|
THP831 |
|
|
|
|
|
|
|
|
|
|
|
|
|
E2 : Without SW tuner E model. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
FAN MOTOR |
|
|
M901 |
|||
|
|
|
|
|
|
Lch |
|
|
|
RY401 |
|
|
|
|
|
M |
E3 |
: Without SW tuner E model. |
|||
|
FRONT |
|
|
18 |
14 |
|
|
|
|
|
|
|
DRIVER |
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
UNREG |
FAN |
EA3 |
: Saudi Arabia model. |
||||||
|
|
|
|
16 |
|
|
|
|
|
|
RELAY |
|
|
|
Q401, 402 |
|
MOTOR |
||||
|
|
|
|
|
|
|
|
VH+ |
|
|
|
|
–7V |
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
Rch |
|
|
|
|
SP |
: Singapore model. |
||||
|
|
|
|
|
|
|
|
|
|
DRIVE |
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
Q435, 436, 431 |
|
|
|
|
|
|
|
MY |
: Malaysia model. |
|
|
|
VH+ SUPP |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
VH+ |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
HK |
: Hong Kong model. |
||
|
Q803, 881 |
|
|
OVER LOAD |
|
|
|
|
|
|
|
|
FRONT |
|
|
TM401 |
|||||
|
|
|
|
|
|
|
|
|
|
SWITCH |
|
|
|
|
TW |
: Taiwan model. |
|||||
|
|
|
|
|
|
DET |
|
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
FRONT |
|||||
|
|
|
|
|
|
Q801 |
|
|
|
|
Q437 |
|
|
|
|
|
|
|
AR |
:Argentine model. |
|
|
|
|
|
MUTE |
|
|
|
|
|
|
|
|
|
|
|
|
|
SPEAKER |
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
SWITCH |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Q804 |
|
Rch |
|
Rch |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
J701 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
PHONES |
|
|
|
|
DBFB |
|
|
|
|
|
|
|
PROTECT |
|
|
MUTE |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
CONTROL |
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
Rch |
|
|
|
SWITCH |
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
Q432 - 434 |
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
Q439 |
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Rch |
|
|
|
|
|
|
|
|
|
|
|
|
MUTE |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
STK MUTE |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
SWITCH |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Q412, 411 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
RY-SW |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
PROTECTOR |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
RXD8,RXD8S |
|
D |
|
|
|
|
|
|
|
|
|
|
|
|
T951 |
|
|
|
|
|
T11 |
|
|
|
|
|
|
|
|
|
|
|
|
|
POWER TRANSFORMER |
|
|
|
|
|
SUB TRANSFORMER |
|
|||
D+5V UNSW |
RECTIFIER |
|
|
JW51 |
|
|
+VH |
RECT |
|
SUB TRANS. D+5.6V |
3 |
IC11 |
1 |
RECT |
|
|
|
||||
|
|
|
|
|
AC1 |
|
|
|
|||||||||||||
|
|
D507 |
|
|
|
|
|
|
–VH |
D831 |
|
|
|
5.6V REG |
|
D12-15 |
|
|
|
||
MAIN |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
AC2 |
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
RECTIFIER |
|
|
|
|
|
|
|
|
|
|
|
|
|
||
SECTION |
|
+5.6V (STBY) |
|
|
RDS D+5V UN SW |
|
+VL |
RECT |
|
|
|
|
|
|
|
|
|
||||
(Page 24) |
|
|
|
D922 |
|
|
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
AC2 |
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
–VL |
D832 |
|
|
|
-26V REG |
|
RECT |
|
|
|
|||
|
|
|
|
|
|
|
RECTIFIER |
|
|
AC1 |
|
VG |
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
|
+5V (STBY) |
|
|
|
+5V (LED) |
|
|
|
|
|
|
Q12, 13 |
|
D17-20 |
|
|
|
|||
|
|
|
|
|
D924 |
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
(DISPLAY) |
D509 |
|
|
(DISPLAY) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
DISPLAY |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
+5V OUT |
|
IC902 |
|
|
|
VF |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
D+5V |
3 |
1 |
|
|
(VIA POWER) |
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
Q905 |
|
REG |
|
|
|
|
COM MON |
|
|
|
|
|
|
AC |
|
|
|
|
|
|
SWITCH |
|
|
|
|
|
|
|
VF |
|
|
|
VF BUFF |
|
|
|
|
|
|
|
|
|
Q904 |
A+7V |
|
+7V REG |
|
|
|
|
|
|
|
Q14, 15 |
|
|
IN |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
Q901,902,913 |
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
POWER ON/OFF |
|
|
|
|
SWITCH |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Q923, 903 |
|
|
|
|
|
|
GRX80:E2,E3,EA3,SP,AR,TW |
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
AC3 |
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
CD D+5V (SW) |
+5V REG |
|
RECTIFIER |
|
|
|
|
|
|
RECT |
|
VOLTAGE |
|
|
SWITCH |
|
RELAY DRIVE |
|
|
|
|
|
Q907 |
|
D925 |
|
|
|
|
–7V REG |
|
D901-904 |
|
SELECTOR |
|
|
|
|
Q11 |
|
||
|
CD A+5V (SW) |
|
|
|
A–7V |
|
|
AC3 |
|
|
Q16, 17 |
|
Q11 |
|
|
||||||
|
|
|
|
|
|
|
|
|
S951 |
|
|
|
RY11 |
|
|
||||||
|
|
|
|
+5V OUT |
|
IC904 1 |
|
Q951,952,914 |
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
3 |
|
|
|
|
|
AC4 |
|
|
|
|
|
|
|
|
|
||
|
|
|
|
Q911 |
|
REG |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
SWITCH |
|
SWITCH |
|
CD MOTOR +7V |
3 |
IC901 |
1 |
RECT |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
D907-910 |
AC4 |
|
|
|
|
|
|
|
|
|
|||||||
|
|
Q908 |
|
Q912 |
|
|
|
|
+7V REG |
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
TC MOTOR +12V |
|
|
|
|
|
|
|
|
|
|
|
|
|
AC |
|||
|
CD POWER |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
+10V REG |
|
|
|
VF |
|
|
|
|
|
|
|
|
|
IN |
|
|
|
|
|
|
|
|
3 |
IC903 |
1 |
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
ST+10V |
|
|
|
|
|
|
|
|
GRX80 |
|
|
||||
|
|
|
|
|
|
|
Q909 |
+12V REG |
|
VF |
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
FL SW ON/OFF |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
STANDBY RELAY ON/OFF |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
09 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
– 25 – |
– 26 – |
HCD-GRX80/RXD8/RXD8S
– DISPLAY SECTION – |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
D637 |
RIGHT |
|
|
|
|
|
|
|
|
|
|
LED SWITCH |
+5V (LED) |
|
|
|
|
|
|
|
|
|
|
Q607 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
GRADATION L |
15 |
|
|
|
LED SWITCH |
|
|
|
|
|
|
|
|
|
Q608 |
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
D638 |
LEFT |
|
|
|
|
|
|
|
|
IC604 |
|
|
|
|
|
|
|
|
|
|
|
|
1 |
|
|
|
|
|
|
|
|
|
|
|
| |
|
|
|
|
|
|
|
|
|
|
|
5 |
|
|
|
|
|
|
|
|
|
|
|
• |
|
|
|
|
|
|
|
L/P SCK |
3 |
13 |
|
7 |
|
Q601,602 |
|
|
|
|
|
LED |
| |
|
|
||||
|
|
|
|
LED LA |
4 |
|
11 |
PANEL LED |
+5V (LED) |
|
|
|
|
|
|
|
SWITCH |
|
|||||
|
|
|
|
L/P DAT |
5 |
15 |
• |
|
|
||
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
17 |
|
|
|
IIC DATA |
78 |
I2C DATA |
|
|
|
|
|
• |
|
|
|
IIC CLK |
79 |
I2C CLK |
|
|
|
|
|
19 |
|
|
|
|
|
|
|
|
| |
|
|
|
|||
|
|
|
|
|
|
|
|
23 |
|
|
|
|
|
|
|
|
|
|
|
|
LED |
|
|
|
|
|
|
L SEL |
7 |
|
|
|
CONTROL |
|
|
|
|
|
|
|
|
|
|
|
Q603 |
|
|
|
|
|
|
SIRCS |
1 |
|
|
|
REMOTE |
|
|
|
|
|
DISPLAY CONTROL |
S LOW (F01) |
16 |
|
|
|
CONTROL |
|
|
RESET |
73 |
RESET |
IC601 |
|
|
|
RECEIVER |
|
|
||
BPF1 (F02) |
17 |
|
|
|
|
|
|||||
|
|
|
|
IC602 |
|
|
|||||
|
|
|
|
BPF2 |
18 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
BPF3 |
19 |
|
|
|
|
|
|
|
|
|
|
BPF4 |
20 |
|
|
|
S601 |
|
|
|
|
|
|
ALL B (L+R) |
21 |
|
|
|
(JOG) |
|
|
|
|
|
|
JOG A |
2 |
|
|
|
ROTARY |
|
|
|
|
|
|
JOG B |
8 |
|
|
|
ENCODER |
|
|
|
72 XOUT |
|
KEY 0 |
11 |
|
|
|
KEY |
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
MATRIX |
|
|
||
|
X601 |
|
|
KEY 3 |
14 |
|
|
|
|
|
|
|
12.5MHz |
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
70 XIN |
|
|
|
|
|
|
|
|
MUTE |
|
|
|
|
|
|
75 |
|
|
|
|
|
|
|
|
|
|
Busy for PAD |
|
|
|
|
|
SWITCH |
|
|
|
|
|
|
|
|
|
|
|
|
Q851 |
WAKE UP |
22 |
GRADATION R/WAKE UP |
PAD LA |
6 |
|
|
|
|
SOUND MIX |
||
|
|
|
|
CH for PAD |
74 |
|
|
|
|
|
IC605 |
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
VOL A |
9 |
|
|
|
|
15 SD |
|
|
|
|
|
|
ROTARY |
|
|
14 SI |
|
||
E |
|
|
|
VOL B |
10 |
|
ENCODER |
|
|
8 ST |
A.OUT 23 |
|
|
|
|
|
|
S602 |
|
|
16 CH |
||
|
SEG1-SEG22 |
GR2-GR12 |
GR1, GR13-GR18 |
|
|
|
|
|
|||
|
|
|
VOLUME |
|
|
|
|
||||
MAIN |
|
46 - 67 |
33 - 40, 42 - 44 |
27 - 32, 45 |
|
|
|
|
|
20 BUSY |
|
|
|
|
|
|
|
|
|
|
|||
SECTION |
|
|
|
|
|
|
|
|
|
XT |
XT |
(Page 24) |
|
|
|
IND BUFF |
|
|
|
|
|
2 |
3 |
|
|
|
Q610-616 |
|
|
|
|
|
|
|
|
|
|
|
|
|
X602 |
|
|
|
FL601 |
|
|
4.09MHz |
|
VF |
|
|
|
VF |
|
|
|
FLUORESCENT INDICATOR TUBE |
||||
|
|
|
|
|||
|
|
|
SPEANA BPF FILTER |
|
|
|
|
|
|
IC603 |
|
|
|
|
|
|
F01 |
17 |
S LOW |
|
|
|
|
F02 |
16 |
BPF1 |
|
SPE SIG |
4 |
LINE IN |
F04 |
14 |
BPF2 |
|
|
6 |
REC IN |
F05 |
13 |
BPF3 |
|
|
F06 |
12 |
BPF4 |
|
||
|
|
|
|
|||
|
|
|
L+R |
11 |
ALLB |
|
STANDBY LED
D804
ECO
TIMER LED |
|
LED SWITCH |
|
+5V (LED) |
|
Q605 |
|
||
|
|
|
|
|
|
|
|
|
|
D635
TIMER SELECT
09
DJ MUTE
F
|
MAIN |
DJ SIG |
SECTION |
|
(Page 23)
– 27 – |
– 28 – |
