SAMSUNG GH68 User Manual

P O R T A B L E A L L D I G I T A L

M O B I L E P H O N E

User Manual

Please read this manual before operating your phone and keep it for future reference.

GH68-36252A_Printed in USA

Intellectual Property

All Intellectual Property, as defined below, owned by or which is otherwise the property of Samsung or its respective suppliers relating to the SAMSUNG Phone, including but not limited to, accessories, parts, or software relating there to (the “Phone System”), is proprietary to Samsung and protected under federal laws, state laws, and international treaty provisions. Intellectual Property includes, but is not limited to, inventions (patentable or unpatentable), patents, trade secrets, copyrights, software, computer programs, and related documentation and other works of authorship. You may not infringe or otherwise violate the rights secured by the Intellectual Property. Moreover, you agree that you will not (and will not attempt to) modify, prepare derivative works of, reverse engineer, decompile, disassemble, or otherwise attempt to create source code from the software. No title to or ownership in the Intellectual Property is transferred to you. All applicable rights of the Intellectual Property shall remain with SAMSUNG and its suppliers.

Open Source Software

Some software components of this product incorporate source code covered under GNU General Public License (GPL), GNU Lesser General Public License (LGPL), OpenSSL License, BSD License and other open source licenses. To obtain the source code covered under the open source licenses, please visit:

http://opensource.samsung.com.

Disclaimer of Warranties; Exclusion of Liability,

EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY CONTAINED ON THE WARRANTY PAGE ENCLOSED WITH THE PRODUCT, THE PURCHASER TAKES THE PRODUCT "AS IS", AND SAMSUNG MAKES NO EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT, INCLUDING BUT NOT LIMITED TO THE MERCHANTABILITY OF THE PRODUCT OR ITS FITNESS FOR ANY PARTICULAR PURPOSE OR USE; THE DESIGN, CONDITION OR QUALITY OF THE PRODUCT; THE PERFORMANCE OF THE PRODUCT; THE WORKMANSHIP OF THE PRODUCT OR THE COMPONENTS CONTAINED THEREIN; OR COMPLIANCE OF THE PRODUCT WITH THE REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION OR CONTRACT PERTAINING THERETO. NOTHING CONTAINED IN THE INSTRUCTION MANUAL SHALL BE CONSTRUED TO CREATE AN EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT. IN ADDITION, SAMSUNG SHALL NOT BE LIABLE FOR ANY DAMAGES OF ANY KIND RESULTING FROM THE PURCHASE OR USE OF

VZW_SCH-U380l_UM_English_EK04C_CH_020912_F5

THE PRODUCT OR ARISING FROM THE BREACH OF THE EXPRESS WARRANTY, INCLUDING INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, OR LOSS OF ANTICIPATED PROFITS OR BENEFITS.

SAMSUNG IS NOT LIABLE FOR PERFORMANCE ISSUES OR INCOMPATIBILITIES CAUSED BY YOUR EDITING OF REGISTRY SETTINGS, OR YOUR MODIFICATION OF OPERATING SYSTEM SOFTWARE.

USING CUSTOM OPERATING SYSTEM SOFTWARE MAY CAUSE YOUR DEVICE AND APPLICATIONS TO WORK IMPROPERLY.

Samsung Telecommunications America (STA), LLC

Headquarters:

1301 E. Lookout Drive

Richardson, TX 75082

Customer Care Center:

1000 Klein Rd.

Plano, TX 75074

Toll Free Tel: [phone].HELP (4357)

Internet Address:

http://www samsung com

©2012 Samsung Telecommunications America, LLC. Samsung is a registered trademark of Samsung Electronics Co., Ltd.

Do you have questions about your Samsung Mobile Phone?

For 24 hour information and assistance, we offer a new FAQ/ARS System (Automated Response System) at: www.samsung.com/us/support

Nuance®, VSuite™, T9® Text Input, and the Nuance logo are trademarks or registered trademarks of Nuance Communications, Inc., or its affiliates in the United States and/or other countries.

The Bluetooth® word mark, figure mark (stylized “B Design”), and combination mark (Bluetooth word mark and “B Design”) are registered trademarks and are wholly owned by the Bluetooth SIG.

microSDTM, microSDHCTM and the microSD logo are Trademarks of the SD Card Association.

©Verizon Wireless. Verizon Wireless and the Verizon Wireless logos are trademarks of Verizon Trademark Services LLC. All company names, trademarks, logos and copyrights not property of Verizon Wireless are the property of their respective owners.

©2012 Samsung Telecommunications America, LLC (“Samsung”). Samsung is a registered trademark of Samsung Electronics Co., Ltd. All product and brand names are trademarks or registered trademarks of their respective companies. Screen images simulated. Appearance of the phone may vary.

©2012 Verizon Wireless. Verizon Wireless, the Verizon Wireless logos, and Brightside are trademarks of Verizon Trademark Services LLC. All company names, trademarks, logos and copyrights not property of Verizon Wireless are the property of their respective owners.

Table of Contents

Section 1: Getting Started ..............................................

4

Understanding this User Manual . . . . . . . . . . . . . . . . . . . . . . . . 4 Activating your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Displaying Your Telephone Number . . . . . . . . . . . . . . . . . . . . . 4 Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Turning Your Phone On and Off . . . . . . . . . . . . . . . . . . . . . . . . . 8 Set-Up Wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Locking and Unlocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Section 2: Understanding Your Phone .........................

12

Features of Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Front View of Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Back View of Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Side View of Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Open View of Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Home Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Event Status Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Section 3: Navigation ...................................................	25
Touch Screen Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . .	25
Keyboard Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	25
Section 4: Call Functions .............................................	26

Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Ending a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Call-In-Progress Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Three-way Calling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Recent Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Voice Recognition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Driving Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Roaming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

TTY Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Section 5: Contacts ......................................................	33
Adding a New Contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	33
Editing a Contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	34
Adding Pauses or Waits . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	35
Sending a Name Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	35
Finding a Contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	35
Deleting a Contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	36
Backup Assistant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	36
Groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	36
Favorites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	38
Speed Dials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	38
Copy To Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	38
Locking a Contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	39
In Case of Emergency (ICE) . . . . . . . . . . . . . . . . . . . . . . . . . .	39

1

Section 6: Entering Text ...............................................	41
Entering Text Using the QWERTY Keyboard . . . . . . . . . . . . . .	41
Entering Text using the Touch Screen . . . . . . . . . . . . . . . . . .	42
Section 7: Messaging ...................................................	45

Types of Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45 Creating and Sending Text Messages . . . . . . . . . . . . . . . . . . . 45 Creating and Sending Multimedia Messages . . . . . . . . . . . . . 46 Receiving Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47 Viewing Text Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48 Viewing Multimedia Messages . . . . . . . . . . . . . . . . . . . . . . . . 48 Erase Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49 Locking and Unlocking a Message . . . . . . . . . . . . . . . . . . . . . 49 Sorting Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49 Drafts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49 Quick Text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 Copy to Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 Quick Reply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 Message Folders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 Email . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52 Message Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53 Emergency Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Section 8: Settings .......................................................	55
Airplane Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	55
Bluetooth Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	55
Sounds Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	57

Display Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Touch Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Phone Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Call Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

USB Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Phone Info . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Easy Set-Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Set-Up Wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Section 9: Media Center ...............................................	73
Apps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	73
Mobile Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	73
Music & Tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	73
Picture & Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	74
Section 10: Music & Tones .........................................	76
Music & Tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	76
Music Player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	76
Song Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	79
Manage My Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	79
Music Only Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	80
Section 11: Pictures and Video ....................................	81

Using the Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

My Pictures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Using the Camcorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

My Videos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

2

Section 12: Applications and Tools .............................

89

My Verizon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Voice Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

Alarm Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Stop Watch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

World Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Notepad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

USB Mass Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

Document Viewer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

Phone Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

VZ Navigator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Section 13: Web and Social Networking Applications 96

Mobile Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

Section 14: Health and Safety Information ...............	100
Exposure to Radio Frequency (RF) Signals . . . . . . . . . . . . . .	100
Specific Absorption Rate (SAR) Certification Information . . . .	104
FCC Part 15 Information to User . . . . . . . . . . . . . . . . . . . . . .	105
Commercial Mobile Alerting System (CMAS) . . . . . . . . . . . . .	106
Smart Practices While Driving . . . . . . . . . . . . . . . . . . . . . . . .	106
Battery Use and Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	107
Samsung Mobile Products and Recycling . . . . . . . . . . . . . . .	109
UL Certified Travel Charger . . . . . . . . . . . . . . . . . . . . . . . . . .	110
Display / Touch-Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . .	110

GPS & AGPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111 Emergency Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112 Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112 Responsible Listening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113 Operating Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115 FCC Hearing Aid Compatibility (HAC) Regulations for Wireless

Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117 Restricting Children's Access to Your Mobile Device . . . . . . . 118 FCC Notice and Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . 119 Other Important Safety Information . . . . . . . . . . . . . . . . . . . . 119

Section 15: Warranty Information .............................	121
Standard Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . .	121
End User License Agreement for Software . . . . . . . . . . . . . .	125
Index ............................................................................	130

3

Section 1: Getting Started

This section allows you to quickly start using your phone by installing and charging the battery, activating your service, setting up your voicemail, contacting customer support.

Understanding this User Manual

The chapters of this manual generally follow the same order as the menus and sub-menus in your phone. A robust index for quick reference to features begins on page 130.

Also included is important safety information that you should know before using your phone. Most of this information is near the back of the guide, beginning on page 100.

Notes and Tips

Throughout this guide are icons and text that are set apart from the rest. These are intended to point out important information, quick methods for activating features, to define terms, and more. The definitions for these methods are as follows:

•Note: Explains alternative options within the current feature, menu, or sub-menu.

•Tip: Provides quick or innovative methods for performing functions related to the subject at hand.

•Important!: Points out information about the current feature that could affect performance, or even damage your phone.

Note: All screen images in this manual are simulated. Actual displays may vary. Instructions to perform tasks in this manual may change depending on the software version on your phone.

Note: Unless otherwise specified, all instructions to perform tasks in this manual assume that you are starting from a Home screen. To get to a Home screen, you may need to unlock the phone or display. For more information, see “Locking and Unlocking” on page 9.

Activating your Phone

If you purchased your phone at a Verizon Wireless store, it is activated and ready to use. If received a new phone by mail, it may need to be activated before you can use it.

To activate your phone, choose from the following:

•Visit a Verizon Wireless store

•Contact Verizon Wireless customer support.

•Visit www.verizonwireless.com to manage your account online.

Displaying Your Telephone Number

My Number displays the ten-digit telephone number assigned to your phone.

•From a Home screen, touch Settings Phone Info My Number.

Getting Started

4

Battery

Your phone is powered by a rechargeable, standard Li-Ion battery, and comes with a wall charger for charging.

Note: The battery comes partially charged. You must fully charge the battery before using your phone for the first time. A fully discharged battery requires up to 4 hours of charge time.

After the first charge, you can use the phone while charging.

Warning!: Use only Samsung-approved charging devices and batteries. Samsung accessories are designed to maximize battery life. Using other accessories may invalidate your warranty and may cause damage.

Battery Indicator

The battery icon in the upper-right corner of the display shows battery power level, with four bars indicating a full charge. Two to three minutes before the battery becomes too low to operate, a blinking empty battery icon appears and a tone sounds. If you continue to operate the phone without charging, it will shut down.

Battery Cover

Your phone has a removable battery cover, covering the battery and a tab for attaching a strap.

Removing the Cover

Grasp the phone with both hands. Pull up on the slot provided, while lifting the cover up and off the phone.

Installing the Cover

Align the cover and press it firmly into place, being sure it snaps into place at the corners.

5

Installing the Battery

1.Remove the battery cover. For more information, see

“Battery Cover” on page 5.

2.Insert the top end of the battery into the phone housing, aligning the gold contacts on the top of the battery with the gold contacts on the phone. Push down on the bottom of the battery until it snaps into place.

3. Snap the battery cover back into place.

Removing the Battery

1.Remove the battery cover. For more information, refer to

“Battery Cover” on page 5.

2.Grasp the bottom of the battery using the slots provided, then lift the battery up and out of the phone.

3. Snap the battery cover back into place.

Charging the Battery

Note: The battery comes partially charged. You must fully charge the battery before using your phone for the first time. A fully discharged battery requires up to 4 hours of charge time.

After the first charge, you can use the phone while charging.

Getting Started

6

1. Connect the USB cable to the charging head.

Head

USB Cab e

nco ect

Co e t

2.Insert the USB cable into the phone’s power/accessory port.

Incorrect

Correct

3.Plug the charging head into a standard AC power outlet.

4.When the charging is complete, the indicator on the charging head turns green. Unplug the charger from the power outlet and remove the USB cable from the phone.

Warning!: Use only Samsung-approved charging accessories to charge your phone. Improper handling of the power/accessory port, as well as the use of a non-approved charger, may cause damage to your phone and void the warranty.

Non-Supported Batteries

Samsung handsets do not support the use of a non-approved battery.

Important!: Using a non-supported battery may damage your phone.

When using a non-supported battery, you will hear a series of beeps and you will see a warning message that indicates:

“NON-SUPPORTED BATTERY. SEE USER GUIDE.”

If you receive this warning, battery charging has been disabled.

Samsung charging accessories, such as the travel adapter and cigarette lighter adapter, will only charge a Samsung-approved battery.

7

Note: When using a non-supported battery the phone can only be used for the duration of the life of the battery. The non-supported battery cannot be charged.

Turning Your Phone On and Off

Press and hold the End/Power key to turn the phone’s power on or off.

While powering on, the phone connects with the home network, then displays the Home screen and active alerts.

Set-Up Wizard

The Set-Up Wizard helps you set 7 basic parameters to get started using your phone quickly.

1.From a Home screen, touch Settings Easy Set-Up

Set-Up Wizard.

2.Follow instructions on the screen to set preferences:

• Tone Level: Touch the plus sign to increase the tone volume, or press the minus sign to decrease the tone volume.

• Call Sounds: Choose how incoming calls are announced.

• Wallpaper: Choose an image for the home screen.

• Display Theme: Select either the Orange or the Green background theme.

• Menu Layout: Choose how the Menu displays, either as a Grid Menu or a Shortcut Menu.

• Menu Font: Set the font type used on menus.

• Clock Format: Choose a style for the main clock. Options: Digital 12, Analog, Large Analog, Digital 24, Dual Clock, or OFF.

3.Touch Skip to skip any setting.

4.Touch Done when finished.

5.Touch or Exit to return to the menu.

Getting Started

8

Locking and Unlocking

Your phone offers two lock functions: locking the display, or locking the phone. Because this is a touch screen phone, the display prevents unintentional key presses and can minimize unnecessary battery drainage. Locking the phone can prevent unauthorized access to the information on your phone, while allowing access to the Keypad for call functions.

Locking and unlocking the phone

You can lock the phone to prevent unauthorized access to information on the phone, but allow dialing with the Keypad. Locking and unlocking requires the Lock Code.

Locking the phone:

1.From a Home screen, touch Settings Phone Settings Security.

Enter the lock code when prompted.

Tip: The default lock code is the last four digits of your telephone number.

2. Touch Lock Phone Now. The Home screen displays.

Unlocking the phone:

Enter the lock code at the prompt.

Note: You may choose to lock the phone automatically when powered on. For more information, see “Phone Lock Setting” on page 65.

Locking and unlocking the display

By default, the display locks when the backlight goes off. To change this setting, see “Touch Settings” on page 62.

Locking the display:

Press the Lock key on the right side of the phone.

Unlocking the display

1. Press the Lock key once to wake up the display.

Note: You can change the settings to allow you to press any key to activate the backlight. For more information, see “Touch Settings” on page 62.

9

2.Starting at the edge of the display, drag your finger upward and across the display in any direction. The lock screen animates and clears from the display.

Voicemail

All unanswered calls to your phone are sent to voicemail, even if your phone is turned off, so you’ll want to set up your voicemail and personal greeting as soon as you activate your phone.

Setting up Voicemail

1.From a Home screen, touch .

– or –

Touch Keypad. and touch and hold .

– or –

Touch	Keypad and touch	,
then press	CALL CALL.

2.Follow the automated instructions to set up your new password and record a greeting.

Checking Voicemail

1.From a Home screen, touch .

– or –

Touch Keypad, then touch and hold .

– or –

Touch	Keypad and touch	,
then press	CALL CALL.

2.Enter your password, then touch .

3.Follow the recorded prompts to listen to messages and manage your voicemail.

Getting Started

10

Tip: You can also access voice mail by dialing your phone number from any touch-tone phone.

Memory Card

Your phone supports the use of an optional, removable microSD™ memory card of up to 32GB capacity. You can store music or pictures you download or transfer to your phone, and other files, on the memory card.

Note: You can only store music files that you own (from a CD or purchased) to the memory card.

Installing the Memory Card

1.Pull the microSD card cover out and turn it to expose the card slot.

Incorrect

Correct

2. Push the microSD card into the slot until it locks into place.

Removing the Memory Card

1.Pull the microSD card cover out and turn to expose the card slot.

2.Push in on the memory card to release the lock and remove memory card from the memory card slot.

Formatting the memory card

Formatting erases any content on the memory card, and prepares it for use with your phone.

Warning!: Repeated formatting will shorten the life of the memory card.

1.From a Home screen, touch Settings Memory Card Memory.

2.Touch Format Card. At the Format Card? prompt, touch Yes.

11

Section 2: Understanding Your Phone

This section outlines key features of your phone. It also displays the screen and the icons that are displayed on the phone.

Features of Your Phone

•Full color 3.1” QVGA Touch Screen

•Slide-out QWERTY keyboard

•High Speed Data (1x-EVDO REV 0 Capable Technology)

•Global Positioning (GPS) Technology with VZ Navigator®

•V CAST Videos

•Social Networking through the Social Networks application

•Messaging Services

–Standard and Enhanced Text Messaging

–Picture Messaging

–Video Messaging

–Threaded message display, by contact

–Voicemail

–Email Messaging, including mobile and corporate Email

•Personal Tools, including Calculator, Calendar, Alarm Clock, Stop Watch, World Clock, and Notepad

•3.2 Megapixel CMOS Camera and Camcorder

•Advanced Nuance® Voice Recognition technology, for no-training voice commands for dialing and other features

•Speakerphone

•microSD™ Memory Card Slot (up to 32GB capacity)

•Advanced photo features and functionalities (photo editor, panoramic photos)

•Phone Search

•Document Viewer

•Bluetooth® 2.1 + EDR Wireless Technology. For more information, see

“Bluetooth Menu” on page 55.

•USB Mass Storage

•Driving Mode

Understanding Your Phone

12

Front View of Your Phone												Functions
							1.						LCD Touch Screen: Displays all the information needed to
													operate your phone.
							2.						Send key: Press to answer an incoming call or to dial a
											4		number. From the Home screen, press to open the KEYPAD
										5			screen.
													Clear key: Press to return to the previous screen. Press and
							3.
													hold to return to the Home screen.
1							4.						Earpiece: Allows you to hear callers.
							5.						Proximity and Light Sensors: Detects the presence of
													nearby objects to control screen display, such as when you
													hold the phone to your ear during a phone call. Detects
													ambient light to determine screen brightness when the
													Automatic brightness setting is enabled, and when taking
													pictures.
2							6.						End/Power key: Press and hold to power the phone On or
												6	Off. Press to end a call or to end any application from any
3
													menu, sub-menu or options menu.
7							7.						Microphone: Allows the other caller to hear you clearly

when you are speaking to them.

13

Back View of Your Phone		Features
		1. 3.5mm Headset Jack: Plug in standard music headphones
1		(for listening to music only) or an optional headset for safe
		and convenient conversations.

2. Camera/Camcorder Lens: The lens of the built-in camera/

2

3

camcorder.

3. Speaker: Music, ringtones, speakerphone, and sounds play through the speaker.

Understanding Your Phone

14

Side View of Your Phone				1.				Strap attachment: Attach a strap (not included).
1				2.				Volume key: In idle mode, press to adjust master volume,
								or press and hold to activate Sound Off/Normal mode.
								Press to adjust voice volume during calls, adjust audio
							3	volume, or mute an incoming call ringer. When browsing
2								web with music playing, press to bring up Music Player.
				3.				Lock key: Locks/unlocks display. Press to lock display.
								When backlight is off, press once to activate backlight, or
								press and hold to unlock the display in one step.
				4.				Camera/Camcorder key: Press to activate the camera.
						4

15

Open View of Your Phone

This touch screen phone also offers the convenience of a slideout QWERTY keyboard. To access the keyboard, rotate the phone and slide the phone open.

	1	10
		9
	2
		8
	3
		7
	4

56

When you slide the phone open, the display automatically rotates from portrait mode to landscape mode.

QWERTY Keyboard Features

1.Favorites key: From a Home screen, press to view the Favorites screen. You can add up to 12 contacts or groups.

2.Message key: From a Home screen, press to open a new Text Message composer.

3.Shift key: Toggles the case for alphabet characters, between mixed case, uppercase and lowercase.

4.Function key: Press to toggle access to the orange symbols on the QWERTY keyboard. From the Home screen, press the Function key and Z key to access Smiley symbols.

5.Space key: Add spaces between words and characters. Press to choose Smileys.

6.Directional keys: Navigate through phone menus and screens.

7.OK key: When navigating through a menu or screen, press to accept the highlighted choice, or to select Go when surfing the web.

8.Return key: Press to go to the next line when entering text.

Understanding Your Phone

16

9.Backspace key: Delete characters from the display when entering text, or go back when surfing the web or viewing pictures.

10.Search key: From a Home screen, press to search the phone.

Home Screen

The Home screen is your starting point for using the features of your phone. The Home screen displays menus in either a grid or shortcut format. You can customize home screens by placing Applications. You can also customize the Lock screens wallpaper.

1

2

3	4	7
	5	6

Understanding the Lock and Home Screen

1.Annunciator Line: Icons indicate network status, battery power, signal strength, connection type and more. You can view a list of all icons used on your phone in the Icon Glossary; for more information see “Phone Info” on

page 71.

2.ERI banner: Displayed on the Lock screen (shown) indicates current network, if ERI Banner is enabled. For more information, see “ERI Banner” on page 61.

3.Event Status Bar: Icons light up to indicate recent events or status changes. Touch icons to access the Event Manager screen. See “Event Status Bar” on page 22.

4.Voicemail button: Dials the voicemail inbox.

5.Recent button: Displays All, Missed, Received, and Dialed calls.

6.Keypad button: Opens the Keypad dialer.

7.Contacts button: Opens Contacts.

17

Customizing the Lock and Home Screen

The lock Screen has a fixed menu selection, however, you can customize the screen by changing the wallpaper, personal banner, and ERI banner. You can also cahnge the layout of the Main menu, themes, and fonts. You can also choose to display a clock on the screen.

Touch an item to open the application, feature or menu.

Customizing the Main Menu

You can customize the Main Menu by adding or rearranging icons to your favorite applications.

1.From a Home screen, touch Settings Display Settings Main Menu Settings.

2.To Position Menu Items, touch and drag an item to a new grid position.

3.To Replace Menu Items, touch the item, then choose another item to replace it.

4.To Change Menu Layout, Select Grid Menu or Shortcut Menu.

5.Touch Reset Menu Settings, then select the item to reset to default:

•Menu items and Position: resets the menu items to the default items and positions them in the default position.

•Menu Layout: repositions the items in the menu to the default layout.

•All: resets all menu items, position, and layout to the default settings.

6.Touch Yes to confirm your selection and perform the reset.

Menu Items

Default

These items appear on the Menu by default.

My Verizon: Launches a Verizon Wireless mobile web site, to check your account details and status.

Tools: Opens the Tools menu. See “Applications and Tools” on page 89.

Settings: Opens Settings. For more information, see

“Settings” on page 55.

Email: Opens the Email menu. For more information, see “Email” on page 52.

Messaging: Opens the Messaging menu. For more information, see “Messaging” on page 45.

Understanding Your Phone

18

Mobile Web: Launches the Browser. For more information, see “Mobile Web” on page 96.

Media Center: Opens the Media Center menu. For more information, see “Media Center” on page 73.

Social Networks: Sets up your phone to access Facebook, and Twitter feeds. See “Social Networks” on page 98.

VZ Navigator: Launches VZ Navigator®. For more information, see “VZ Navigator” on page 95.

Apps: Allows you to download and display purchased or preloaded applications.

Alarm: Launches an Alarm. see “Alarm Clock” on page 91.

My Pictures: Launches My Pictures. For more information, see “My Pictures” on page 84.

Voicemail: Launches voicemail to configure the mailbox, or retrieve messages. For more information, refer to “Voicemail” on page 10.

Recent: Opens the Recent Calls menu. For more information, see “Recent Calls” on page 29.

Keypad: Opens the dialpad to enter the digits of the telephone or speed dial number.

Contacts: Opens the Contacts menu. For more information, see “Contacts” on page 33.

Optional

You can customize the Menu to include these optional items: For more information on how to Replace Menu Items with one of the following, see “Customizing the Lock and Home Screen” on page 18.

Backup Assistant Is a wireless service that saves a copy of your phone's address book to a secure web site. For more information, refer to “Backup Assistant” on page 36.

BluetoothMenu: Opens the Bluetooth Menu. For more information, see “Bluetooth Menu” on page 55.

Bluetooth On/Off: Turns Bluetooth On or Off. See

“Turning Bluetooth On or Off” on page 56.

19

Calculator: Launches the Calculator. For more information, see “Calculator” on page 89.

Calendar: Launches the Calendar. For more information, see “Calendar” on page 90.

Call Settings: Allows you to select options related to call functions. For more information, refer to “Call Settings” on page 67.

CityID: Displays the city and state of incoming calls.

Daily Scoop: Provides free content, discounts and offers from restaurants and retailers in your area. You receive exclusive discounts on products and services that are useful to you at the most useful time and location.

Display Settings: Customizes the phone’s display screens. For more information, refer to “Display Settings” on page 60.

Driving Mode: Enables your phone to use sounds to alert you to notifications, regardless of other phone or call settings. For more information, refer to “Driving Mode” on page 31.

MessagingInbox: Allows you to view all the messages by time received, or by contact (also known as a threaded view). For more information, refer to

“Message Folders” on page 51.

Music & Tones: Allows you to access the music and other tones. For more information, refer to “Music & Tones” on page 73.

My Music: Launches Music Player. For more information, see “Music Player” on page 76.

My Ringtones: Launches My Ringtones. For more information, see “My Ringtones” on page 73.

My Sounds: Accesses sounds downloaded, recorded using your phone, or saved from a Picture message with Sound attached. For more information, refer to

“My Sounds” on page 74.

My Videos: Accesses video Clips saved from a Video message, downloaded via “Media Center”, or taken using Camcorder. For more information, refer to “My Videos” on page 88.

Understanding Your Phone

20

New Contact: Creates a new contact entry. For more information, refer to “Adding a New Contact” on page 33.

New message: Creates a new text message. See

“Creating and Sending Text Messages” on page 45.

Notepad: Allows you to create, read, edit and erase text notes. For more information, refer to “Notepad” on page 92.

Online Album: Store pictures and videos to your VerizonWireless Online Album.Formore information, refer to “Online Album” on page 75.

Phone Search: Launches Device Search. For more information, see “Phone Search” on page 94.

Phone Settings: Choose settings for Voice Commands, Language, and Location, for phone operation. Secure the phone, set data roaming access an d restrictions. Also set the primary NAM, andchooseQWERTYkeyboard preferences.Formore information, refer to “Phone Settings” on page 63.

Picture & Video: phone to create, download and manage your image and video files. For more information, refer to “Pictures and Video” on page 81.

Play All Songs: Uses the music player to play all songs in the music library. For more information, refer to

“Playing Music” on page 76.

SoundsSettings: Customizes your phone’s sounds for incoming calls and messages, alerts, and other phone features. For more information, refer to

“Sounds Settings” on page 57.

StopWatch: Measurelap times and total elapsed time. For more information, refer to “Stop Watch” on page 92.

Tetris: Play this popular mobile game.

Uno: Play this popular mobile card game.

Update Status: Updates your social networking sites and media. For more information, refer to “Social Networks” on page 98.

21

USB Mass Storage: Connect your phone to a PC with a USB cable to transfer files, such as music or pictures, to your phone. For more information, refer to

“USB Mass Storage” on page 93.

VCAST Tones: Downloads ringtones and ringback tones.

VCAST Video: Provides access to vibrant, full-color video-on-demand. For more information, refer to

“VCAST Video” on page 74.

Voice Commands: Use Voice Commands to operate your phone by speaking commands. For more information, refer to “Voice Commands” on page 89.

World Clock: World Clock allows you to view the current time in your location, and anywhere in the world. For more information, refer to “World Clock” on page 92.

Event Status Bar

The Event Status Bar appears on the Home screen to alert you to calendar events, missed calls, new messages, or special Master Volume modes. The Event Status Bar does not display when there are no active alerts.

Touch an event in the Event Status bar to launch the Event Manager.

Event Status Bar

The Event Status bar appears near the bottom of the Home screen.

An icon illuminated in color indicates an alert. Touching an icon on the bar opens the Event Manager menu.

Shortcuts

Touch an empty space within the status bar to display the following list of shortcuts:

•Master Volume: Adjust the Master Volume settings.

•New Message: View new messages.

•Voicemail: Call Voicemail or Clear the Counter.

•Email: View Mobile Email.

•Missed Call: View all Missed calls and view the Timers.

•Calendar Event: View calendar events.

•Speaker Phone: Activate the speakerphone by touching ON, or touch OFF to deactivate this feature.

•Alarm: View a list of alarms or Add a new alarm.

Understanding Your Phone

22

Event Status Icons

Alarm: An alarm is set.

Alarm Only: Master Volume is set to Alarm Only. Your phone will only ring when the set alarm sounds.

Vibrate Only: Master Volume is set to Vibrate Only. Your phone vibrates upon receiving a call, a new message or voicemail, or when an alarm has been set.

All Sounds Off: Master Volume is set to All Sounds Off. No sounds will play.

Email: Illuminates when you receive a new Email message.

New Message: Illuminates when you receive a new message.

New Voicemail: Illuminates when you receive a voicemail message. (Available on the Verizon Wireless Network.)

Missed Call: Illuminates when you have one or more missed calls.

Calendar Event: Illuminates when events are scheduled in the next 24 hours.

Speaker: Illuminates when Speakerphone is on.

Event Manager

The Event Manager offers easy access to common events and features.

1.Touch the Event Status bar on the Home screen.

2.Touch any Event to launch the associated feature.

23

Section 3: Navigation

This section explains navigation for your phone. It also includes an outline of all menus available on your phone.

Note: Instructions in this User Manual apply to Touch Screen Navigation, except where noted.

Touch Screen Navigation

Warning!: If your handset has a touch screen display, please note that a touch screen responds best to a light touch from the pad of your finger or a non-metallic stylus. Using excessive force or a metallic object when pressing on the touch screen may damage the tempered glass surface and void the warranty. For more information, see “Warranty Information” on page 121.

Touch

Touch icons or menu items onscreen to select or launch them. Examples of touch actions include:

•Entering characters with the Keypad.

•Selecting an item from a menu or list

•Launching an application from the main Menu.

Keyboard Navigation

To access menus and options using the slide-out QWERTY keyboard:

Press the corresponding number key:

.

Press the directional keys Left, Right, Up and Down to scroll in a menu or long text screen.

To accept the highlighted option or launch the selected application, press .

Lock Key

Press the Lock key at any time to lock the display.

Clear/CLR Key

Press the Clear key when navigating a menu, to return to the previous screen. Press and hold the Clear key at any time to return to the Home screen.

25

Section 4: Call Functions

This section describes how to make, answer and end a call. It also includes information about the Recent Calls log and voice dialing with Voice Commands.

Making a Call

Your phone offers multiple ways to make calls:

•Use the touchscreen Keypad to enter a telephone or speed dial number.

•Use the QWERTY keyboard to enter a telephone or speed dial number.

• Call a contact from Contacts, or from the Favorites .

•Return a call, or call a recent caller via Recent.

•Voice dial using Voice Commands.

Touch Screen Keypad

To access the Keypad:

From a Home screen, touch Keypad.

–or –

From a Home screen press Send.

Making a Call using the Keypad

1. From a Home screen, touch				Keypad.

2.Touch the digits of the telephone or speed dial number.

• Touch CALL to call a contact.

•Touch More to send a message, add a 2-second pause, add a wait, or for Assisted Dialing.

•Touch Save to save the entered number to add a new contact, update an existing contact, or save the number to the Notepad.

•Touch to delete digits if you enter an incorrect number.

3.Press CALL Call or Send to dial the call.

Tip: As you touch numbers, matching contacts display on screen. You can continue dialing, or touch the contact to dial their default number.

Call Functions

26

Making a Call using the QWERTY keyboard

1.Slide open the phone.

2.From a Home screen, touch Keypad.

3.Press the digits of the telephone or speed dial number on the QWERTY keypad.

• Touch CALL to call a contact.

•Touch More to send a message, add a 2-second pause, add a wait, or for Assisted Dialing.

•Touch Save to save the entered number to add a new contact, update an existing contact, or save the number to the Notepad.

•Touch to delete digits if you enter an incorrect number.

Tip: As you press numbers, matching contacts display on screen, with the number of potential matches (4, in the example above). You can continue dialing, touch the contact to dial their number, or touch the number to display all potential matches.

4. Press CALL Call or Send to dial the call.

Note: When using the QWERTY keyboard, calls are automatically made in Speakerphone mode.

Making a Call using Contacts

A contact is an entry that you have created to store the name, numbers, and other information for people or groups of interest. For more information, refer to “Contacts” on page 33.

1.From a Home screen, touch Contacts.

2.Find the contact and touch Call on the entry to dial the default number for the Contact.

– or –

Touch the Contact to open the entry, then touch any

number to dial the number.

Ending a Call

Press the End/Power key.

27
