Panasonic NN-G335WF User Manual

Panasonic Corporation

Web Site: http://panasonic.net

F00036R62KP

IP0110-5

IP2866_36R62KP_Cov_01_100122.indd 1

Operation Guide and Cookbook

ڈيئاگ نشيرپا

ﻯﺰﭙﺷﺁ ﺏﺎﺘﻛﻭ ﺩﺮﺑﺭﺎﻛ ﻯﺎﻤﻨﻫﺍﺭ ﺦﺒﻄﻟﺍ ﺏﺎﺘﻛﻭ ﻞﻴﻐﺸﺘﻟﺍ ﻞﻴﻟﺩ

Microwave / Grill Oven

نووا لرگ/ويووركئام

ﺰﭘ ﺏﺎﺒﻛ/ﻮﻳﻭﻭﺮﻜﻳﺎﻣ ﻕﺎﺟﺍ ﻒﻳﻭﻭﺮﻜﻳﺎﻣ/ﻱﻮﺷ ﻥﺮﻓ

Model NN-G335WF

Before operating this oven, please read these instructions completely and keep for future reference.

<ºЙ +Йд´ЙxЙ EтЙд SЙ±ЙЙxЙд ºЙд {Й½ю±Йд, EЮт{ЙªЙЙ <xЙ КxЙnжщЙЙе EтЙд {ЙЪ®ъТ iЙ®ъ½ю ºЙд {Йgш ±Йе +Йи®ъ ¦ЙК´Й¹ªЙ ¨Йе ºЙЖnщ¦ЙЗ Eдт К±ЙB +{ЙxЙд {ЙЙºЙ ®ъJЙе*

.ںيهكر ےئليك سنيرفير هدنئٓا روا ںيل هڑپ رپ روط لمكم وك تاياده نا مرك هارب ےلهپ ےس ےنرك لامعتسا وك نووا سا

.ﺪﻳﺭﺍﺪﻬﮕﻧ ﺩﻮﺧ ﺩﺰﻧ ﻩﺪﻨﻳﺁ ﺭﺩ ﻪﻌﺟﺍﺮﻣ ﻯﺍ ﺮﺑ ﺍﺭ ﻥﺁ ﻭ ﺪﻴﻧﺍﻮﺨﺑ ﻞﻣﺎﻛ ﺭﻮﻃ ﻪﺑ ﺍﺭ ﻪﭼﺮﺘﻓﺩ ﻦﻳﺍ ﺐﻟﺎﻄﻣ ﺎﻔﻄﻟ ،ﻩﺎﮕﺘﺳﺩ ﻦﻳﺍ ﺯﺍ ﻩﺩﺎﻔﺘﺳﺍ ﺯﺍ ﻞﺒﻗ

.ﻞﺒﻘﺘﺴﻤﻟﺍ ﻲﻓ ﺎﻬﻴﻟﺍ ﻉﻮﺟﺮﻠﻟ ﺎﻬﺑ ﻅﺎﻔﺘﺣﻻﺍﻭ ﻞﻣﺎﻜﻟﺎﺑ ﺕﺎﻤﻴﻠﻌﺘﻟﺍ ﻩﺬﻫ ﺓءﺍﺮﻗ ﻰﺟﺮﻳ ،ﻥﺮﻔﻟﺍ ﺍﺬﻫ ﻞﻴﻐﺸﺗ ﻞﺒﻗ

2010-1-22 13:36:05

English Operating

Instructions

Safety Instructions

Precautions to be taken when using Microwave Ovens for Heating Foodstuffs

Inspection for Damage:

A microwave oven should only be used if an inspection confirms all of the following conditions:

1.The grille is not damaged or broken.

2.The door fits squarely and securely and opens and closes smoothly.

3.The door hinges are in good condition.

4.The metal plates of a metal seal on the door are neither buckled nor deformed.

5.The door seals are neither covered with food nor have large burn marks.

Precautions:

Microwave radiation from microwave ovens can cause harmful effects if the following precautions are not taken:

1.Never tamper with or deactive the interlocking devices on the door.

2.Never poke an object, particularly a metal object, through a grille or between the door and the oven while the oven is operating.

3.Never place saucepans, unopened cans or other heavy metal objects in the oven.

4.Do not let other metallic articles, e.g. fast food foil containers, touch the side of the oven.

5.Clean the oven cavity, the door and the seals with water and a mild detergent at regular intervals. Never use any form of abrasive cleaner that may scratch or scour surfaces around the door.

6.Always use the oven with the trays or cookware recommended by the manufacturer.

7.Never operate the oven without a load (i.e. an absorbing material such as food or water) in the oven cavity unless specifically allowed in the manufacturer's literature.

8.For horizontally hinged doors, never rest heavy objects such as food containers on the door while it is open.

9.Do not place sealed containers in the microwave oven. Baby bottles fitted with a screw cap or a teat are considered to be sealed containers.

10.This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

11.Young children should be supervised to ensure that they do not play with the appliance.

Earthing Instructions

This microwave oven must be earthed. In the event of an electrical short circuit, earthing reduces the risk of electric shock by providing an escape wire for the electric current.

This microwave oven is equipped with an earthing plug. The

plug must be plugged into an outlet that is properly installed and earthed.

WARNING—Improper use of the earthing plug can result in electric shock.

Important Instructions

WARNING—To reduce the risk of burns, electric shock, fire, injury to persons or excessive microwave energy:

1.Read all instructions before using microwave oven.

2.Some products such as whole eggs and sealed containers - (for example, closed glass jars and sealed baby bottles with teat) may explode and should not be heated in microwave oven. Refer to cookbook for more detail.

3.Use this microwave oven only for its intended use as described in this manual.

4.As with any appliance, close supervision is necessary when used by children.

5.Do not operate this microwave oven, if it is not working properly, or if it has been damaged or dropped.

6.To reduce the risk of fire in the oven cavity:

(a)Do not overcook food. Carefully attend microwave oven if paper, plastic, or other combustible materials are placed inside the oven to facilitate cooking.

(b)Remove wire twist-ties from bags before placing bag in oven.

(c)If materials inside the oven should ignite, keep oven door closed, turn oven off at the wall switch, or shut off power at the fuse or circuit breaker panel.

7.Do not remove outer panel from oven.

Circuits

Your microwave ovens should be operated on a separate circuit from other appliances. The voltage used must be the same as specified on this microwave oven. Failure to do this may cause the power board fuse to blow. Do not insert higher value fuse in the power board.

Practical Hints:

1.Exterior oven surfaces, including air vents on the cabinet and the oven door will get hot during COMBINATION and GRILL. Use care when opening or closing door and when inserting or removing food and accessories.

2.The oven has a heater situated in the top of the oven. After using the GRILL and COMBINATION functions, the ceiling will be very hot.

N.B. After cooking by GRILL and COMBINATION the accessories will be very hot.

3.The accessible parts may become hot when GRILL or COMBINATION is in use. Children should be kept away.

Warning

(a)The door seals and door seal areas should be cleaned with a damp cloth. The appliance should be inspected for damage to the door seals and door seal areas and if these areas are damaged the appliance should not be operated until it has been repaired by a service technician trained by the manufacturer.

(b)It is dangerous for anyone other than a service technician trained by the manufacturer to perform repair service.

(c)If the supply cord of this appliance is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard.

(d)Before use, the user should check that whether the utensils are suitable for use in microwave ovens.

(e)Liquids or other foods must not be heated in sealed containers since they are liable to explode, at the same time it should avoid the boiling liquids splash.

(f)Only allow children to use the oven without supervision when adequate instructions have been given so that the child is able to use the oven in a safe way and understands the hazards of improper use.

-En-1 -

Installation and General Instructions

General Use

1.In order to maintain high quality, do not operate the oven when empty. The microwave energy will reflect continuously throughout the oven if no food or water is present to absorb energy.

2.If smoke is observed, press the STOP/RESET Pad and leave door closed. Disconnect the power cord, or shut off power at the fuse or circuit breaker panel.

3.Do not dry clothes, newspapers or other materials in oven. They may catch on fire.

4.Do not use recycled paper products, as they may contain impurities which may cause sparks and/or fires when used.

5.Do not use newspapers or paper bags for cooking.

6.Do not hit or strike control panel. Damage to controls may occur.

7.POT HOLDERS may be needed as heat from food is transferred to the cooking container and from the container to the glass tray. The glass tray can be very hot after removing the cooking container from the oven.

8.Do not store flammable materials next to, on top of, or in the oven. It could be a fire hazard.

9.Do not cook food directly on glass tray unless indicated in recipes. (Food should be placed in a suitable cooking utensil.)

10.DO NOT use this oven to heat chemicals or other nonfood products. DO NOT clean this oven with any product that is labeled as containing corrosive chemicals. The heating of corrosive chemicals in this oven may cause microwave radiation leaks.

11.If glass tray is hot, allow to cool before cleaning or placing in water.

Placement of Oven

1.The oven must be placed on a flat, stable surface, it shall not be placed in a cabinet. For correct operation, the oven must have sufficient air flow. Allow 15 cm of space on the top of the oven, 10 cm at back and 5 cm on both sides. If one side of the oven is placed flush to a wall, the other side or top must not be blocked. Do not remove feet.

15cm

5cm

10cm

OPEN

Counter-top

(a)Do not block air vents. If they are blocked during operation, the oven may overheat. If the oven overheats, a thermal safety device will turn the oven off. The oven will remain inoperable until it has cooled.

(b)Do not place oven near a hot or damp surface such as a gas stove, electric range or sink etc.

(c)Do not operate oven when room humidity is too high.

2.This oven was manufactured for household use only.

Food

1.Do not use your oven for home canning or the heating of any closed jar. Pressure will build up and the jar may explode. In addition, the microwave oven cannot maintain the food at the correct canning temperature. Improperly canned food may spoil and be dangerous to consume.

2.Do not attempt to deep fat fry in your microwave oven.

3.Do not boil eggs in their shell (unless otherwise stated in cookbook). Pressure will build up and the eggs will explode.

4.Potatoes, apples, egg yolks, whole squash and sausages are examples of foods with nonporous skins. This type of food must be pierced before cooking, to prevent bursting.

5.When heating liquids, e.g. soup. sauces and beverages in your microwave oven, overheating the liquid beyond boiling point can occur without evidence of bubbling.

This could result in a sudden boil over the hot liquid. To prevent this possibility the following steps should be taken.

(a)Avoid using straight-sided containers with narrow necks.

(b)Do not overheat.

(c)Stir the liquid before placing the container in the oven and again halfway through cooking time.

(d)After heating, allow to stand in the oven for a short time, stirring again before carefully removing the container.

6.DO NOT USE A CONVENTIONAL MEAT THERMOMETER IN THE MICROWAVE OVEN. To check the degree of cooking of roasts and poultry use a MICROWAVE THERMOMETER. Alternatively, a conventional meat thermometer may be used after the food is removed from the oven. If undercooked, return meat or poultry to the oven and cook for a few more minutes at the recommended power level. It is important to ensure that meat and poultry are thoroughly cooked.

7.COOKING TIMES given in the cookbook are APPROXIMATE. Factors that may affect cooking time are preferred degree of moisture content, starting temperature, altitude, volume, size, shape of food and utensils used. As you become familiar with the oven, you will be able to adjust for these factors.

8.It is better to UNDERCOOK RATHER THAN OVERCOOK foods. If food is undercooked, it can always be returned to the oven for further cooking. If food is overcooked, nothing can be done. Always start with minimum cooking times recommended.

9.Extreme care should be taken when cooking popcorn in a microwave oven. Cook for minimum time as recommended by manufacturer. Use the directions suitable for the wattage of your microwave oven. NEVER leave oven unattended when popping popcorn.

10.When heating food in plastic or paper containers, check the oven frequently due to the possibility of ignition.

11.The contents of feeding bottles and baby food jars are to be stirred or shaken and the temperature is to be checked before consumption, in order to avoid burns.

Instructions

Operating English

- En-2 -

English Operating

Instructions

Feature Diagram

7

8

9 5

1 Oven Window

2 Door Safety Lock System

3 Pull Door Handle

Pull to open the door. Opening the door during cooking

will stop the cooking process without cancelling the

program. Cook resumes as soon as the door is closed

and Start Pad is pressed. It is quite safe to open the

door at any time during a cooking program and there is

1

4

no risk of Microwave exposure.

4 Control Panel

5 Cover (do not remove)

6 Roller Ring

a. Roller Ring should be cleaned regularly to avoid

6

excessive noise.

2

b. Roller Ring and Glass Tray should be used at the

same time.

7 Identification Plate

8 Oven Air Vent

9 Glass Tray

a. DO NOT operate the oven without the Roller Ring

and Glass Tray in place.

b. Only use the Glass Tray specifically designed for this

oven. Do not substitute any other Glass Tray.

c. If the Glass Tray is hot, allow to cool before cleaning

or placing in water.

d. DO NOT cook directly on the Glass Tray. Always

place food on a microwave-safe dish, or on a rack set

in a microwave-safe dish.

3

e. If food or utensil on the Glass Tray touches oven

walls, causing the tray to stop moving, the tray will

automatically rotate in the opposite direction. This is

0normal.

f.Glass Tray can rotate in either direction.

0 Wire Rack

a. A Wire Rack is included with the oven in order to facilitate browning of small dishes.

b. Wire Rack should be cleaned regularly.

c. When using Wire Rack in the manual GRILL or COMBINATION cooking modes, be careful to choose heat-proof containers; containers made of plastic or paper may melt or burn when exposed to the heat radiating from the grill.

d. When using the COMBINATION mode, never place any aluminum or metal container directly on Wire Rack. Always insert a glass plate or dish between Wire Rack and the aluminum container. This will prevent sparking that may damage the oven.

e. It is not recommended to use Wire Rack when cooking in the MICROWAVE mode only.

- En-3 -

Control Panel

		(1)	Display Window
		(2)	Auto Cook Pads
		(3)	Micro Power Pad
		(4)	Grill Pad
		(5)	Combination Pad
(1)		(6)	Time Pads
		(7)	Turbo Defrost Pad
		(8)	Stop/Reset Pad
			Before cooking: One tap clears your instruction.
			During cooking: One tap temporarily stops the cooking
			process. Another tap cancels all your instructions and
	(2)		colon appears on the Display Window.
		(9)	Start Pad
			One tap allows oven to begin functioning. If door is
(3)	(5)		opened or Stop/Reset Pad is pressed once during oven
			operation, Start Pad must be pressed again to restart
(4)			oven.
	(6)	Beep Sound:
		When a pad is pressed correctly, a beep will be heard.
(7)		If a pad is pressed and no beep is heard, the unit did not or
		cannot accept the instruction. The oven will beep twice
(8)	(9)	between programmed stages. At the end of any complete
		program, the oven will beep 5 times.

Instructions

Operating English

- En-4 -

Operation

Setting Power and Time

English Operating

Instructions

1.Put the food into the oven

2.Press to select power

(see chart below)

3.Set Cooking Time

(HIGH	up to	30 minutes
	or 29 minutes 90 seconds
Others	up to	99 minutes 90 seconds)

4.Press

The time on the Display Window will count down.

NOTE:

1. For 2 or 3 stage cooking, repeat steps 2 and 3 above before pressing Start pad.

2. When selecting High power on the first stage, you can skip step 2.

3.You can refer to the Suggested Cooking Guide when cooking , of course you can use other power levels as desired.

	No. of taps	Power Level	Power	Example of Use
	1	HIGH	100%	Boil water. Cook fresh fruit, vegetables, rice, desserts, pasta
				and noodles.
	2	DEFROST	30%	Thaw foods.
	3	MEDIUM	55%	Cook pot roasts, casseroles and meat loaves, melt chocolate.
				Cook eggs and cheeses. Cook fish, poultry, meat, cakes, heat
				milk.
	4	LOW	10%	Keep cooked foods warm, simmer slowly.

Suggested Cooking Guide

Potatoes

•Potatoes should be trimmed or prepared and cut into evenly sliced pieces.

•Add 1 tablespoon to 1/4 cup of water to vegetables, if dehydrated or softer texture is desired.

•Place in a appropriate size dish and cover with plastic wrap or well fitting lid.

•Halfway through the cooking time, stir potatoes. This will assist in even cooking.

•Use the following as a guide:

Weight	Power	Cooking Time
200 g	HIGH	5 - 6 mins
500 g	HIGH	8 - 9 mins

Rice

•Place rice with water in a suitable sized dish. Use the following as a guide:

	Rice	*Water	Dish Size	Cooking Time
	200 g	500 ml	3 litre	HIGH 6 mins
	(1 cup)	(2 cups)		LOW 18 mins

*(It may be necessary to adjust the amount of water to your personal preference.)

•Rice will boil over if the dish used is too small.

•Cook rice covered with lid or plastic wrap.

•Do not cook in plastic containers unless suitable for high temperature cooking.

•Stand rice for 5 to 10 minutes after cooking, if necessary.

- En-5 -

Operation

Turbo Defrost / Child Safety Lock

To Use Turbo Defrost (0.1~2.0 kg):

1.Put the food into the oven

2.Select the weight of food

Example: To defrost 1.5 kg of meat.

once 5 times

	Food	Maximum
		Weight
	Minced meat, Chicken Pieces,	2 kg
	Chops
	Beef roast, lamb, whole	2 kg
	chickens
	Whole fish, scallops, prawns,	1 kg
	fish fillets

3.Press

Defrosting time appears on the Display Window and beginning to count down.

NOTE:

1.Turbo Defrost can be used to defrost many cuts of meat, poultry and fish by weight. To use, simply program Turbo Defrost and the weight of the food in kg (1.0) and tenths of a kg (0.1). The oven will determine the defrosting time and power levels. Once the oven is programmed, the defrosting time will appear in the display. For best results the minimum recommended weight is 0.2 kg.

2.BONE-IN ROASTS, such as a Beef Rib Roast have a smaller muscle than a boneless roast of the same weight. Therefore, for bone-in roasts weighing over 2 kg reduce weight by 500 g. For bone-in roasts weighing less than 2 kg, reduce weight by 250 g.

3.Turn over or remove or shield food when buzzer rings in the middle of cooking.

To Use Child Safety Lock:

To set:

Instructions

Operating English

Colon is displayed

Press 3 times

Display Window

To cancel:

Display Window

Press 3 times

Colon is displayed

NOTE:

1.Child Lock can be set when colon is displayed.

2.This feature allows you to prevent operation of the oven by a young child; however, the door will open.

-En-6 -

Operation

Grill / Combination

English Operating

Instructions

1.Put the food into the oven

2.Select Grill/Combiantion

setting

Pads	1 tap	2 taps	3 taps	3.Set cooking time
Grill	Grill 1	Grill 2		up to 99 minutes 90 seconds
Combination Combi 1		Combi 2	Combi 3

4.Press

Directions for Grilling

When grilling, heat is radiated from the two elements at the top of the oven. The oven door must be kept closed to prevent cooking odours from spreading in the kitchen and so as not to waste energy. The grill elements do not require preheating. The grill is particularly useful for thin slices of meat, steaks chops, kebabs, sausages or pieces of chicken. It is also suitable for hot sandwiches and all gratin dishes.

Place food to be grilled on Wire Rack on Glass Tray. Select Grill setting, set the time and start the oven. The food being grilled should normally be turned over after half the grilling time. When the oven door is opened the program is interrupted. Turn the food over, place it back the oven, close the door and restart oven. While grilling, the oven door can be opened at any time to check the food.

No. of	Heater	Types of food
Grill 1	HIGH	Meat, poultry, pieces
Grill 2	LOW	Seafood, Garlic bread, Toast

Suggested Cooking Guide

Meat Skewers

•Allows you to grill or barbecue your favourite meat and poultry pieces or seafood.

•Place food on Wire Rack on Glass Tray.

•Turnover halfway during cooking time. Use the following as a guide:

Weight	Power	Cooking Time
200 g	Combi 1	15 - 16 mins
400 g	Combi 2	25 - 30 mins

Directions of Combination

The combination means that it is possible to combine the microwave and grill function for thawing, cooking, and heating foods. There is a special program to keep the crispness of certain foods.

Wire Rack can be used for better browning result.

	No. of	Heater	Micro Power	Types of food
	Combination 1	HIGH	LOW	Baked potatoes,
				Whole poultry
	Combination 2	MEDIUM	MEDIUM	Beef, Lamb
	Combination 3	LOW	HIGH	Sea food, Puddings

- En-7 -

Operation

Auto Cook Pads

1.Put the food into the oven

2.Select pads

Press the desired food category pad until the desired number of Weight appears on the Display Window.

Pads	1 tap	2 taps	3 taps
Auto Reheat	1 serve	2 serves	3 serves
Vegetables	100 g	200 g	300 g
Chicken Pieces	200 g	400 g	—

3.Press

The time on the Display Window will count down.

Instructions

Operating English

Auto Reheat

Pre-cooked foods are reheated automatically by setting the food's serving. You need not select power level or reheating time. The foods should be at refrigerator or room temperature. Use suitable sized dish and cover with a lid or microwave safe plastic.

Note: When reheating items such as soups, stews, and casseroles, it is recommended that they are stirred at half of reheating time and at completion of reheating.

Average serving size

1 serve	200 g
2 serves	400 g
3 serves	600 g

Vegetables

It is suitable steaming leafy vegetables only. Arrange vegetables on a plate or casserole dish, stem on outer ring of plate and leafy in the center. Cover with a lid or microwave safe plastic wrap.

Chicken Pieces

It is suitable for grilling meat pieces, poultry pieces, etc. Place prepared food to be grilled on Wire Rack.

- En-8 -

English Operating

Instructions

Before Requesting Service

ALL THESE THINGS ARE NORMAL:

The oven causes interference	Some radio and TV interference might occur when you cook with the
with my TV.	microwave oven. This interference is similar to the interference caused by
	small appliances such as mixers, vacuums, hair dryers, etc. It does not
	indicate a problem with your oven.
The oven lights dim.	When cooking with a power other than HIGH, the oven must cycle to obtain
	the lower power levels. The oven light will dim and clicking noises can be
	heard when the oven cycles.

Steam accumulates on the oven door and warm air comes from the oven vents.

I accidentally operate my microwave oven without any food in it.

During cooking, steam and warm air are given off from the food. Most of the steam and warm air are removed from the oven by the air which circulates in the oven cavity. However, some steam will condense on cooler surfaces such as the oven door. This is normal.

Operating the oven empty for a short time will not damage the oven. However, we do not recommend this to be done.

There are humming and clicking	These noise occur as the oven automatically switches from microwave
noises from my oven when I	power to Grill, to create the Combination setting. This is normal.
cook by Combination.
The oven has an odor and	It is essential that your oven is wiped out regularly particularly after cooking
generates smoke when using	by Combination or Grill. Any fat and grease that builds up on the roof and
Combination and Grill function.	walls of the oven will begin to smoke if not cleaned.

PROBLEM

POSSIBLE CAUSE

REMEDY

Oven will not turn on.

Oven will not start cooking.

When the oven is turning on, there is noise coming from Glass Tray.

The word "Child" appears in the Display Window.

The oven is not plugged in	Remove plug from outlet, wait 10
securely.	seconds and re-insert.
Circuit breaker or fuse is tripped	Reset circuit breaker or
or blown.	replace fuse.

There is a problem with the outlet. Plug another appliance into the outlet to check if the outlet is working.

The door is not closed completely. Close the oven door securely.

Start Pad was not pressed after	Press Start Pad.
programming.
Another program has already	Press Stop/Reset Pad to cancel
been entered into the oven.	the previous program and program
	again.
The program has not been	Program again according to the
entered correctly.	Operating Instructions.
Stop/Reset Pad has been	Program oven again.
pressed accidentally.
The roller ring and oven bottom	Clean these parts according
are dirty.	to care of your oven (See
	next page).
The Child Lock was activated by	Deactivate Lock by pressing
pressing Start Pad 3 times.	Stop/Reset Pad 3 times.

If it seems there is a problem with the oven, contact an authorized Service Centre.

- En-9 -

Care of your Microwave Oven

1.Turn the oven off and remove the power plug from the wall socket before cleaning.

2.Keep the inside of the oven clean. When food splatters or spilled liquids adhere to oven walls, wipe with a damp cloth. Mild detergent may be used if the oven gets very dirty. The use of harsh detergent or abrasives is not recommended.

3.The outside oven surfaces should be cleaned with a damp cloth. To prevent damage to the operating parts inside the oven, water should not be allowed to seep into the ventilation openings.

4.Do not allow the Control Panel to become wet. Clean with a soft, damp cloth. Do not use detergents, abrasives or spray-on cleaners on the Control Panel.

When cleaning the Control Panel, leave oven door open to prevent oven from accidentally turning on. After cleaning press STOP/RESET Pad to clear display window.

5.If steam accumulates inside or around the outside of the oven door, wipe with a soft cloth. This may occur when the microwave oven is operated under high humidity conditions and in no way indicates malfunction of the unit.

6.It is occasionally necessary to remove the glass tray for cleaning. Wash the tray in warm sudsy water or in a dishwasher.

7.The roller ring and oven cavity floor should be cleaned regularly to avoid excessive noise. Simply wipe the bottom surface of the oven with mild detergent, water or window cleaner and dry. The roller ring may be washed in mild sudsy

water or dish washer. Cooking vapors collect during repeated use but in no way affect the bottom surface or roller ring wheels. When removing the roller ring from cavity floor for cleaning, be sure to replace in the proper position.

8.When using the GRILL or cooking in the COMBINATION mode, some foods may inevitably splatter grease on to the oven walls. If the oven is not cleaned, occasionally it may start to "smoke" during use. These marks will be more difficult to clean later.

9.After GRILL or COMBINATION cooking the ceiling and walls of the oven should be cleaned with a soft cloth squeezed in soapy water. Particular care should be taken to keep the window area clean particularly after cooking by GRILL or COMBINATION. Stubborn spots inside the oven can be removed by using a small amount of microwave oven cleaner sprayed onto a soft damp cloth. Wipe onto problem spots, leave for recommended time and then wipe off. Avoid cleaning oven door and the microwave feed guide area situated on the right hand side of the cavity wall.

DO NOT SPRAY DIRECTLY INSIDE THE OVEN.

10.When it becomes necessary to replace the oven light, please consult a dealer to have it replaced.

11.Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could adversely affect the life of the appliance and possibly result in a hazardous situation.

Instructions

Operating English

Technical Specifications

		220 V
Power Source		50 Hz
Power Consumption		5.9 A 1,200 W
Cooking Power	Microwave*	800 W
	Grill	1,100 W
Outside Dimensions (H x W x D)		284 mm x 482 mm x 364 mm
Oven Cavity Dimensions (H x W x D)		191 mm x 325 mm x 330 mm
Operating Frequency		2,450 MHz
Net Weight		Approx. 11.5 kg

* IEC Test Procedure

Specifications subject to change without notice.

As for the voltage requirement, the production month, country and serial number, please refer to the identification plate on the microwave oven.

- En-10 -

English Cookbook

Introduction

Cooking with Microwave Energy

Microwaves are a form of high frequency electromagnetic waves (approx 12cm wavelength) similar to those used by a radio. Electricity is converted into microwave energy by the magnetron tube. The microwaves travel from the magnetron tube to the oven cavity where they are reflected, transmitted or absorbed.

Reflection

Microwaves are reflected by metal just as a ball is bounced off a wall. A combination of stationary (interior walls) and rotating metal (turntable or stirrer fan) helps assure that the microwaves are well distributed within the oven cavity to produce even cooking.

Transmission

Microwaves pass through some materials such as paper, glass and plastic much like sunlight shining through a window. Because these substances do not absorb or reflect the microwave energy, they are ideal materials for microwave oven cooking containers.

Absorption

Microwaves are absorbed by food. They penetrate to a depth of about 2 to 4cm. Microwave energy excites the molecules in the food (especially water, fat and sugar molecules), and causes them to vibrate very quickly. The vibration causes friction and heat is produced. In large foods, the heat which is produced by friction is conducted to the center to finish cooking.

Combination

Combination cooking is ideal for roasting meats and poultry. Combination cooking automatically alternates between convection and microwave heating. The advantage to combination cooking is that it gives the browning of convection and often shortens the convectional cooking time.

Grilling

Grilling is done at high temperatures with the food close to the heat. This gives meat a rich brown appearance. Only use high-quality, well-marbled meats for grilling since the high temperatures can dry out the less choice meats.

Cookware and Utensil Guide

	Microwave Oven		Combination		Grill
Aluminuim Foil	For Shielding		For Shielding		Yes
Glass Tray	No		No		Yes
Browning Dish	Yes		No		No
Browning Paper Bags	No		No		No
Dinnerware: Oven/Microwave Safe	Yes		Yes		No
Non Oven/Microwave Safe	No		No		No
Disposable Polyeser	Yes	*	check manufacturers'		No
Paperboard Dishes			recommendation, must
			withstand heat
Glassware: Oven Glassware & Ceramic	Yes		Yes		Yes for short
					term top browning
Non-heat Resistant	No		No		No
Metal Cookware	No		No		Yes
Metal Twist-ties	No		No		No
Oven Cooking Bag	Yes		Yes		No
Oven Rack	No		No		Yes
Paper Towels and Napkins	Yes	*	No		No
Plastic Dishes: Microwave Safe	Yes	*	check manufacturers'		No
Non-microwave Safe	No		recommendation, must		No
			withstand heat
Plastic Wrap	Yes	*	No		No
Straw, Wicker, Wood	Yes	*	No		No
Thermometers: Microwave Safe	Yes		No		No
Conventional	No		No		Yes
Wax Paper	Yes		No		No

*Caution

• Plastics: Plastic dishes, cups and some freezer containers should be used with care in a microwave oven. Choose plastic containers carefully, as some plastic containers may become soft, melt and scorch.

•Paper Products and Freezer Wrap: Waxed paper, paper plates, cups and napkins should not be used for heating or cooking food by Combination and Grill. Freezer wrap should not be used as it is not heat resistant and bake paper may be safely used for short periods of time for covering or lining.

- En-11 -
