Logitech UE Air Speaker Quick Start Manual
Air Speaker
Getting started with
Première utilisation
Logitech UE™ Air Speaker
Wireless speaker with AirPlay
for iPad, iPhone, iPod touch and iTunes
Logitech UE Air Speaker
Air Speaker
Getting started with
Première utilisation
Logitech UE™ Air Speaker
Wireless speaker with AirPlay
for iPad, iPhone, iPod touch and iTunes
2
Contents
Logitech UE Air Speaker
English. . . . . . . . . . . . . . . . . . . 4
Français . . . . . . . . . . . . . . . . . . 9
www.logitech.com/support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Español . . . . . . . . . . . . . . . . . . 14
3
Logitech UE Air Speaker
Features
1
Front
2 3 4 5
Back
6 7 8
Top
1. Status indicator
Green: Normal operation
Orange: Network or firmware issue
2. Ethernet port Connector
for direct connection to a network.
Visit www.logitech.com/support/
airspeaker for setup instructions using
an Ethernet cable
3. Wi-Fi Connect button For use with
computer setup (optional)
4. Auxiliary input 3.5mm audio input
for other music devices (optional)
5. AC power input
6. Mute Press to mute and unmute.
7. Volume Turn clockwise to increase
volume and counterclockwise
to decrease volume.
8. Power Press to turn on the speaker.
While the speaker is on, press to sleep.
Press again to wake. Press and hold
for 5 seconds to turn o the speaker.
(Power-on takes 35 seconds.)
44 English
Set up AirPlay using an iOS device (preferred)
Logitech UE Air Speaker
1
1. Connect the AC power supply and turn
on the speaker. The speaker powers up
in 35 seconds.
2. Press to open the device dock.
Do not dock your iOS device while
the speaker is powering up.
3. Make sure your iOS device is connected to
the same Wi-Fi network on which you want
to operate the speaker.
2 3 4 5
4. Dock your iOS device after the speaker
powers up. A notification will appear
on your screen. Select Yes to install
the Logitech UE Air app.
5. Keep your iOS device docked,
launch the APP, and then follow
the on-screen instructions. Be ready
to enter your Wi-Fi network password.
When the Status indicator turns solid green,
the Wi-Fi network connection is made.
5English 5
Logitech UE Air Speaker
Set up AirPlay using
acomputer (optional)
1. Connect the AC power supply.
Turn on the speaker. Wait until power-
on finishes before proceeding.
(Power-on takes 35 seconds.)
2. Press and hold the Wi-Fi Connect button
for more than 5 seconds. After 35 seconds
the Status indicator changes from slow
blinking green to fast blinking green to
indicate that setup mode is ready.
3. Open Wi-Fi network settings on
your computer. Select the network called
“Air Speaker Setup”. (For Wi-Fi help refer
to your computer documentation.)
4. Launch an Internet browser.
Enter http://192.168.1.12 in the address bar.
A configuration page launches.
5. Follow the on-screen instructions. Be ready
to select your Wi-Fi network and to enter
your password. The speaker will restart.
The Status indicator will turn solid green
after the Wi-Fi connection is made.
Your computer should automatically
reconnect to your Wi-Fi network.
If not, you will need to reconnect it
manually.
Note: If the Status indicator changes to
slow blinking orange, the speaker did not
connect to your Wi-Fi network. Please visit
www.logitech.com/support/airspeaker
for help and try again.
Playing music
The speaker plays music from only one device
at a time. To switch devices, stop the
current device before playing music on
another device.
AirPlay with iOS device (wireless)
1. Make sure Wi-Fi is turned on for your iOS
device and your iOS device is connected
to the same network as the Air Speaker
2. Tap the iPod app or a music app.
3. Find the AirPlay icon and tap it.
4. Choose the Air Speaker from the list
of speakers.
5. Select a song or track to play it.
1
You can also dock your iOS device.
1
