WIRELESS

HEADPHONES

USER

GUIDE

ENGLISH . . . . . . . . . . . . . . . . . . . 4

. . . . . . . . . . . . . . . . . . . 16

POWER UP.

Turn on the UE 9000

Wireless Headphones.

Turn on your Ultimate Ears 9000 Wireless Headphones.

The Bluetooth® LED should blink blue rapidly, indicating that the headphones are discoverable.

SYNC

UP.

Pair your headphones with your Bluetooth-enabled device.

Apple iOS®

Go to Settings > General > Bluetooth.

Turn on Bluetooth.

Select “UE 9000” from “Devices.”

PRESS

PLAY.

Press play on your media device.

Optional: Pair additional Bluetooth-enabled devices.

You can pair your headphones with up to eight devices. To do so:

1.Move the slider to the “Bluetooth” position and hold it there until the Bluetooth LED blinks rapidly blue, indicating that the headphones are discoverable.

2.Complete pairing according to the instructions on the previous page.

3.Press play on the device you’ve just paired.

When you’ve successfully paired a device, the Bluetooth LED will turn solid blue. If pairing times out (the LED will blink slowly), move the slider to the “Bluetooth” position and hold it there until the LED starts rapidly blinking again.

WHAT’S IN

THE BOX:

UE 9000 Wireless Headphones

Molded travel case

Optional audio cable with on-cord mic and controls

USB charging cable

AC adapter

¼-inch (6.35 mm) adapter

Microfiber polishing cloth

GET TO KNOW YOUR UE 9000 WIRELESS HEADPHONES.

On/Off/Bluetooth connection slider

Bluetooth LED

Battery level LED

Music/Calling





On-ear controls

On-cord controls



Volume up

Click, or press and hold



Play/Pause

Single click



Call answer/hang up

Single click to answer/





press and hold to hang up



Next track

Double click



Previous track

Triple click



Volume down

Click, or press and hold



Listen Through button





Micro USB charging port









3.5 mm input (Interrupts Bluetooth connection when connected)

FEATURES:

FEATURES:

LED BEHAVIOR.

CHARGING.

Bluetooth LED

Off

Headphones off or connected to an audio source via the 3.5 mm jack

Blue (blinking rapidly):

Discoverable/pairing mode

Blue (blinking slowly): Connecting

Blue (solid): Connected

Battery Level LED

Off

Headphone off

Green (pulsing slowly): Charging

Green (solid): Power on; fully charged

Computer USB port

Red: Low battery

or

Micro USB charging port

USB charging cable

AC power adapter

When in wireless mode, all LEDs turn off automatically. However, the LEDs will illuminate when there is a pairing change or a control is activated.

To use the “listen through” feature, press the Listen Through button once. Your music will be muted and environmental sounds will be amplified into your headphones. To resume listening to music, simply press the Listen Through button again.

The “listen through” feature is only available in wireless mode while listening to music. It is not available in wired mode or during phone calls.

Typically a three-hour charge through an AC outlet provides up to 10 hours of power, and you can use your headphones while they’re charging.

When the battery level LED turns red, you should recharge your headphones. To do so:

1.Charge the headphones via the supplied AC adapter or USB. The battery level LED will pulse green.

2.When your headphones are fully charged, the battery level LED will glow

solid green.

ENGLISH - 9

FEATURES: TRAVEL STORAGE.

To safely store your headphones while you’re on the go:

1.Swivel the ear cups until they “click”.

2.Place the headphones flat in their case.

3.Place the AC adapter in the top pocket.

4.Place all cables and accessories in the bottom pocket.

PRODUCT CENTRAL.

There’s more information and support available for your product online.

Visit Product Central, where you can:

Browse online articles and tutorials.

Find tips about usage and information about additional features.

Get help troubleshooting a problem.

Download the latest software for your product.

Find online documentation and warranty information.

Connect with other users in our Community Forums to get advice, ask questions and share solutions.

Order spare parts (when available).

Go to www.logitech.com/support/ue9000

ENGLISH - 11

TROUBLESHOOTING.

If your headphones are not working or pairing/connecting properly, try the following:

Move closer. The range of the Bluetooth wireless connection is up to 10 meters or 30 feet.

Recharge, particularly if the battery level LED is red. See “Charging.”

Try increasing the volume on the headphones, on your device or in your media application. And if you’re connected to a computer, check the volume settings for your operating system.

Enable Bluetooth on your device, and then select “UE 9000” from the Bluetooth device list.

To fix a Bluetooth connection by repairing:

1.On your device: Delete “UE 9000” from the Bluetooth device list

2.On the headphones: Move the slider to “Bluetooth” and hold until the Bluetooth LED blinks blue

3.On your device: Select “UE 9000” from the Bluetooth device list

4.From the media player on your Bluetooth device: Select “UE 9000”

For computers, you may need to specify the headphone as the input/output device for your operating system.

For help, go to www.logitech.com/support/ue9000

WHAT DO YOU THINK?

Please take a minute to tell us.

www.logitech.com/ithink

PRODUCT SUPPORT.

www.logitech.com/support/ue9000

ENGLISH - 13

BATTERY REMOVAL

HEADPHONE

AND RECYCLING

DISASSEMBLY

Remove screws

1.Peel and remove the ear pad from the left ear cup.

2.Remove screws to disassemble the speaker chamber.

3.Unplug the old battery.

4.Dispose of old battery at an authorized

battery recycling center.

Unplug battery

Peel and remove earpad

LEFT EAR CUP

ENGLISH - 15

UE 9000







Ultimate Ears 9000

iOS®



“ ”>“ ”>“ ”

® LED





“ ” “UE 9000”

1.LED

LED

LED LED

内容

UE 9000

USB

¼ 6.35

UE 9000

/ /

LED LED

/











/



/

/

















Listen Through ( )

USB

3.5

LED

LED

LED





3.5







/















充电

USB

USB

USB

LEDLED

“ ” Listen ThroughListen Through

“ ”

10LED

1.USB LED

2.LED

- 21















“ ”













• “ ”





www.logitech.com/support/ue9000

1.“ ”

- 23





/



10 30



LED “ ”







“UE 9000”









1.

“UE 9000”





2.

LED





3.

“UE 9000”





4.

“UE 9000”



/



www.logitech.com/ithink

www.logitech.com/support/ue9000

www.logitech.com/support/ue9000

- 25









4. 电池回收中心对旧电池进行弃置。

- 27

© 2012 Logitech. Logitech, the Logitech logo, the Logitech UE logo, and other Logitech marks are owned by Logitech and may be registered. All other trademarks are the property of their respective owners. Logitech assumes no responsibility for any errors that may appear in this manual. Information contained herein is subject to change without notice.

©2012 UE

www.logitechUE.com

620-004372.004
