Operating Manual |
System |
Congratulations on your purchase of an innovative product from Fujitsu.
The latest information about our products, tips, updates etc. can be found on the Internet at: "http://www.fujitsu.com/fts/"
You can find driver updates at: "http://support.ts.fujitsu.com/download" Should you have any technical questions, please contact:
•our Hotline/Service Desk ("http://support.ts.fujitsu.com/contact/servicedesk")
•Your sales partner
•Your sales office
We hope you enjoy working with your new Fujitsu system!
Issued by / EU importer
Fujitsu Technology Solutions GmbH
Mies-van-der-Rohe-Straße 8
80807 Munich, Germany
"http://www.fujitsu.com/fts/"
Copyright
© Fujitsu Technology Solutions GmbH2020. All rights reserved.
Publication Date
06/2020
Order No.: A26391-K504-Z325-1-7619, edition 1
FUJITSU LIFEBOOK U9310
Operating Manual
Innovative technology |
7 |
Ports and controls |
9 |
Important notes |
12 |
First-time setup of your device |
16 |
Working with the notebook |
19 |
Security functions |
45 |
Connecting external devices |
52 |
Removing and installing components |
|
during servicing |
58 |
Settings in BIOS Setup Utility |
59 |
Troubleshooting and tips |
64 |
Technical data |
72 |
Manufacturer’s notes |
75 |
Index |
76 |
Remarks
Information on the product description meets the design specifications of Fujitsu and is provided for comparison purposes. Several factors may cause the actual results to differ. Technical data is subject to change without prior notification. Fujitsu rejects any responsibility with regard to technical or editorial mistakes or omissions.
Trademarks
Fujitsu, the Fujitsu logo and LIFEBOOK are registered trademarks of Fujitsu Limited or its subsidiaries in the USA and other countries.
Microsoft and Windows are trademarks or registered trademarks of Microsoft Corporation in the USA and/or other countries.
The terms HDMI and HDMI High-Definition Multimedia Interface and the HDMI logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries.
Bluetooth® and the Bluetooth logo are registered trademarks of Bluetooth SIG, Inc. Adobe Reader is a trademark of Adobe Systems Incorporated.
USB Type-C™ and USB-C™ are trademarks of the USB Implementers Forum in the USA and other countries.
All other trademarks specified here are the property of their respective owners.
Copyright
No part of this publication may be copied, reproduced or translated without the prior written consent of Fujitsu.
No part of this publication may be saved or transferred by any electronic means without the written approval of Fujitsu.
|
Contents |
Contents |
|
Innovative technology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 7 |
Further information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 7 |
Notational conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 8 |
Ports and controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 9 |
Important notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 12 |
Safety notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 12 |
Additional safety notes for devices with radio components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 13 |
Energy saving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 13 |
Energy saving under Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 13 |
Travelling with your notebook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 14 |
Before you travel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 14 |
Notebook: transporting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 14 |
Cleaning the notebook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 15 |
First-time setup of your device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 16 |
Unpacking and checking the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 16 |
Selecting a location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 17 |
Mains adapter connecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 17 |
Switching on the device for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 18 |
Working with the notebook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 19 |
Status indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 19 |
Switching on the notebook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 21 |
Notebook: switching off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 21 |
Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 22 |
Virtual numeric keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 24 |
Function keys and key combinations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 24 |
F-Lock setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 26 |
Keyboard with backlight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 27 |
Country and keyboard settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 27 |
Touchpad and touchpad buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 28 |
Moving the pointer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 28 |
Selecting an item . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 28 |
Executing commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 28 |
Dragging items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 29 |
Touchscreen/LCD screen without touch function (device-dependent) . . . . . . . . . . . . . . . . . . . |
. . . . . 29 |
Using fingers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 30 |
WebCam and Infrared Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 31 |
Rechargeable battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 32 |
Charging, caring for and maintaining the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 32 |
Switch the battery off and on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 32 |
Using the power-management features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 33 |
Adjusting fan control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 34 |
Memory cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 35 |
Supported formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 35 |
Inserting the memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 35 |
Removing the memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 35 |
Loudspeakers and microphones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 36 |
SIM card (configuration dependent) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 37 |
Inserting the SIM card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 37 |
Fujitsu |
3 |
Contents |
|
Removing a SIM card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
38 |
Wireless components Wireless LAN / Bluetooth / LTE (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
39 |
Switching the wireless components on and off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
39 |
Setting up WLAN access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
39 |
Access via LTE (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
39 |
Ethernet and LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
40 |
Your USB Type-C Port Replicator (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
41 |
Ports on the Port Replicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
41 |
Setting up the port replicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
42 |
Connecting the mains adapter to the Port Replicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
42 |
Connect the notebook to the port replicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
43 |
Switching on the notebook via the port replicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
44 |
Switching off notebook via Port Replicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
44 |
Disconnecting the notebook from the Port Replicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
44 |
Security functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
45 |
Configuring the fingerprint sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
45 |
Configuring the palm vein sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
46 |
Using the Security Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
46 |
Configuring password protection in BIOS Setup Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
47 |
Protecting BIOS Setup Utility (supervisor and user password) . . . . . . . . . . . . . . . . . . . . . . . . . . . |
47 |
Password protection for booting of the operating system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
49 |
Password protection for the hard disk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
49 |
Trusted Platform Module (TPM) (device-dependent) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
50 |
Enabling TPM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
50 |
Disabling TPM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
50 |
SmartCard reader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
51 |
Inserting the SmartCard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
51 |
Connecting external devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
HDMI port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52 Connecting an external monitor to the port replicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53 Connecting USB devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54 USB port Intel® ThunderboltTM 3 with charging function and display port (USB Type-C) . . . . 55 USB port with charging function (Anytime USB charge) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56 How to remove USB devices correctly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56 Headset port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Removing and installing components during servicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
58 |
Settings in BIOS Setup Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
59 |
Starting the BIOS Setup Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
59 |
Operating the BIOS Setup Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
60 |
Exiting BIOS Setup Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
61 |
Exit Saving Changes - save changes and exit BIOS Setup Utility . . . . . . . . . . . . . . . . . . . . . . . |
61 |
Exit Discarding Changes – Discard changes and exit BIOS Setup Utility . . . . . . . . . . . . . . . . . |
61 |
Load Setup Defaults – Copy Standard Entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
61 |
Discard Changes – Discard changes without exiting the BIOS Setup Utility . . . . . . . . . . . . . . . |
61 |
Save Changes - save changes without exiting the BIOS Setup Utility . . . . . . . . . . . . . . . . . . . . |
61 |
Save Changes and Power Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
61 |
Erase Disk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
62 |
Troubleshooting and tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
64 |
Help if problems occur . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
64 |
4 |
Fujitsu |
|
Contents |
Reset by switching off the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 65 |
Restore contents of the hard disk from Recovery CD/DVD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 65 |
Restoring the system under Windows 10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 66 |
The notebook’s date or time is incorrect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 66 |
When certain characters are entered on the keyboard, only numerals are written . . . . . . . . |
. . . . . 66 |
The notebook’s LCD screen remains blank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 66 |
The LCD screen is difficult to read . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 66 |
The external monitor remains blank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 67 |
The external monitor is blank or the image is unstable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 67 |
The notebook cannot be started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 68 |
The notebook stops working . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 68 |
The printer does not print . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 68 |
The wireless connection to a network does not work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 69 |
SmartCard reader is not recognised. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 69 |
SmartCard PIN forgotten . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 69 |
SmartCard lost . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 69 |
Error messages on the screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 70 |
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 72 |
LIFEBOOK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 72 |
Rechargeable battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 72 |
Mains adapter (notebook computer) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 73 |
USB Type-C Port Replicator (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 73 |
Mains Adapter USB Type-C Port Replicator (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 74 |
Manufacturer’s notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 75 |
Disposal and recycling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 75 |
TCO Certified . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 75 |
Certification markings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 75 |
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 76 |
Fujitsu |
5 |
Contents
6 |
Fujitsu |
Innovative technology
... and ergonomic design make your device a reliable and convenient companion.
The device boots very quickly, is ready for immediate use and offers a particularly long operating time because of its high capacity battery.
With the user-friendly "BIOS Setup Utility" you can control your notebook’s hardware and better protect your system against unauthorised access by using the powerful password properties.
Information on the connections and user components of your notebook can be found in "Ports and controls", Page 9.
The Windows drivers for your device can be found on our Internet site. The factory installation of your device does not support any other operating system. Fujitsu Technology Solutions accepts no liability whatsoever
if any other operating system is used.
Software oriented components of these instructions refer to Microsoft products, if they come within the scope of the delivery.
If you install other software products, pay attention to the operating instructions of the manufacturer.
Fujitsu |
7 |
Innovative technology
|
|
|
Pay particular attention to text marked with this symbol. Failure to observe |
||
|
|
|
these warnings could pose a risk to health, damage the device or lead |
||
|
|
|
to loss of data. The warranty will be invalidated if the device becomes |
||
|
|
|
defective through failure to observe these warnings. |
||
|
|
|
Indicates important information for the proper use of the device. |
||
|
|
|
|
|
|
|
► |
Indicates an activity that must be performed |
|||
|
|
Indicates a result |
|||
|
|
|
|
||
|
|
|
|
|
|
|
This font |
indicates data entered using the keyboard in a program dialogue or at |
|||
|
|
|
the command line, e.g. your password (Name123) or a command used to |
||
|
|
|
start a program (start.exe) |
||
|
This font |
indicates information that is displayed on the screen by a program, e.g.: |
|||
|
|
|
Installation is complete. |
||
|
|
|
|
|
|
|
This font |
indicates |
|||
|
|
|
• terms and texts used in a software interface, e.g.: Click on Save |
||
|
|
|
• names of programs or files, e.g. Windows or setup.exe. |
||
|
"This font" |
indicates |
|||
|
|
|
• cross-references to another section, e.g. "Safety information" |
||
|
|
|
• cross-references to an external source, e.g. a web address: For more |
||
|
|
|
information, go to "http://www.fujitsu.com/fts/" |
||
|
|
|
• Names of CDs, DVDs and titles or designations for other materials, |
||
|
|
|
e.g.: "CD/DVD Drivers & Utilities" or "Safety/Regulations" manual |
||
|
Key |
|
indicates a key on the keyboard, e.g: |
F10 |
|
|
|
|
|||
|
This font |
indicates terms and texts that are emphasised or highlighted, e.g.: Do |
|||
|
|
|
not switch off the device |
8 |
Fujitsu |
Ports and controls
This chapter presents the individual hardware components of your device. It gives an overview of the indicators and ports of the device. Please familiarise yourself with these components before you start to work with the device.
1 |
23 |
2 |
|
|
41 |
9 |
5 |
6 |
|
8 |
|
|
|
5 |
|
7 |
1 |
= Microphone (optional) |
6 |
= ON/OFF button |
2 |
= Infrared camera sensors (optional) |
7 |
= Fingerprint sensor (optional) or palm |
3 |
= WebCam (optional) |
|
sensor (optional) |
4 |
= WebCam LED (optional) |
8 |
= Touchpad buttons |
5 |
= Status indicators |
9 |
= Touchpad |
Fujitsu |
9 |
Ports and controls
Left |
side |
|
|
|
|
|
|
|
1 |
2 |
3 |
4 |
5 |
6 |
7 |
1 |
= DC input connector (DC IN) |
5 |
= USB 3.2 Gen1 port with charging function |
|
2+3= USB port Intel® ThunderboltTM 3 |
|
|
(USB Type-A, Anytime USB charge) |
|
|
with charging function and display |
6 |
= |
Headset jack |
|
port (USB Type-C) |
7 |
= SmartCard reader |
|
4 |
= HDMI port |
|
|
|
The descriptions in this document show the standard product configuration with Intel® ThunderboltTM 3.
Alternative USB configurations without Intel® ThunderboltTM 3 are also available for projects:
•Pos. 2 = USB 3.2 Gen2 port with charging function and DisplayPort (USB Type-C™)
•Pos. 3 = USB port 3.2 Gen1 (USB Type-C)
Right |
side |
|
|
|
|
|
1 |
2 |
3 |
4 |
5 |
1 |
= Slot for SIM cards (optional) |
4 |
= |
LAN connector (removable) |
|
2 |
= |
Slot for memory cards |
5 |
= |
Security lock device |
3 |
= |
USB port 3.2 Gen1 (USB Type-A) |
|
|
|
10 |
Fujitsu |
Ports and controls
1 |
1 |
2
1 = Loudspeaker |
2 = Off button for the battery (recessed) |
Fujitsu |
11 |
Important notes
This chapter contains essential safety information which must be followed when working with your notebook. Other notes also provide useful information which will help you with your notebook.
Please follow the safety notes provided in the "Safety/Regulations" manual as well as the safety notes given below.
Please pay special attention to the sections in the manual marked with the symbol on the left.
When connecting and disconnecting cables, observe the relevant notes in this operating manual.
In order to prevent burn injury or the device from overheating, do not lay the device directly on your lap and make sure that the ventilation openings are not obstructed.
Read the information on the ambient conditions in the "Technical data", Page 72 and "First-time setup of your device", Page 16 before preparing your notebook for use and switching it on for the first time.
When cleaning the device, please observe the relevant notes in the section "Cleaning the notebook", Page 15.
Pay attention to the additional safety notes for devices with wireless components provided in the "Safety/Regulations" manual.
Please refer to the notes in the chapter "Removing and installing components during servicing", Page 58.
This notebook complies with the relevant safety regulations for data processing equipment. If you have questions about using your notebook in a particular area, please contact your sales outlet or our Hotline/Service Desk.
Please open the LCD screen carefully until you feel resistance. Do not try to open it further with force!
12 |
Fujitsu |
Important notes
If a radio component (Wireless LAN, Bluetooth, LTE) is integrated in your notebook, you must be sure to observe the following safety notes when using your notebook:
•Switch off the radio components when you are in an aircraft or driving in a car.
•Switch off the radio components when you are in a hospital, an operating room or near a medical electronics system. The transmitted radio waves can impair the operation of medical devices.
•Switch off the radio components when you let the device get near flammable gases or into hazardous environments (e.g. petrol station, paintshops), as the transmitted radio waves can cause an explosion or a fire.
For information on how to switch radio components on and off, see chapter "Switching the wireless components on and off", Page 39.
Switch the notebook off when it is not in use. Switch off external, connected devices if you are not using them. If you use the energy saving functions, the notebook uses less energy. You will then be able to work for longer before having to recharge the battery.
Energy efficiency is increased and the environmental impact is reduced.
You save money while protecting the environment.
►Make use of the power management features (see ""Using the power-management features", Page 33").
Fujitsu |
13 |
Important notes
Please observe the points listed below when travelling with your notebook.
►Back up important data stored on your hard disk.
►Switch off the wireless component for data security reasons. With data traffic via a wireless connection, it is also possible for unauthorised third parties to receive data.
Information on activating data encryption is provided in the documentation for your wireless component.
►If you wish to use your notebook during a flight, first check with the flight attendants if it is OK to do so.
When travelling in other countries
►If you are travelling abroad, check that the mains adapter can be operated with the local mains voltage. If this is not the case, obtain the appropriate mains adapter for your notebook. Do not use any other voltage converter!
►Check whether the local mains voltage and the power cable are compatible. If this is not the case, buy a power cable that matches the local conditions.
►Contact the relevant authorities of the country you will be travelling in as to whether you may operate the radio component integrated into your notebook computer. Please observe the additional safety instructions for devices with radio components, found in the handbook “Safety/formalities”.
Protect the notebook from severe shocks and extreme temperatures (e.g. direct sunlight in a car).
►Switch the notebook off.
►Unplug the mains adapter and all external devices from the power socket.
►Disconnect the mains adapter cable and the data cables for all external devices.
►Close the LCD screen.
►To protect against damaging jolts and bumps, use a notebook carrying case to transport your notebook.
14 |
Fujitsu |
Important notes
Do not clean any interior parts yourself; leave this job to a service technician.
Only use cleaning products designed for computers. Normal household cleaners and polishes can damage the markings on the keyboard and the device, the paintwork or the notebook itself.
Ensure that no liquid enters the notebook.
The LCD screen very sensitive to scratches. Only clean the display surface with a very soft, slightly damp cloth.
►Switch the notebook off.
►To prevent accidental activation of the device, remove the power plug of the mains adapter from the power socket.
The surface may be cleaned with a dry cloth. If particularly dirty, use a damp cloth that has been dipped in water mixed with mild domestic detergent and then carefully wrung out.
To clean the keyboard and the Touchpad, if available, you can use disinfectant wipes. Ensure that no liquid enters the device.
Fujitsu |
15 |
First-time setup of your device
Please read the chapter "Important notes", Page 12.
If your device is equipped with a Windows operating system, the necessary hardware drivers and supplied software are already pre-installed.
Before you switch on the device for the first time, connect it to the mains voltage using the mains adapter, see "Mains adapter connecting", Page 17. The mains adapter must be connected during the entire installation process.
A system test is performed when your device is first switched on. Various messages can appear. The display may remain dark for a short time or may flicker.
Please follow the instructions on the screen.
NEVER switch off your device during the first-time setup process.
The battery must be charged if you want to operate your device using the battery.
When used on the move, the built-in battery provides the device with the necessary power. You can increase the operating time by using the available energy-saving functions.
For instructions on how to connect external devices (e.g. mouse, printer) to your device, please refer to the operating manual for your device.
Should you discover any damage that occurred during transportation, notify your local sales outlet immediately!
►Unpack all the individual parts.
►Check your device for any visible damage which may have occurred during transportation.
You may need the packaging in the future, if you need to transport your device.
16 |
Fujitsu |
First-time setup of your device
Select a suitable location for the device before setting it up. Follow the instructions below when doing so:
•Never place the device or the mains adapter on a heat-sensitive surface. The surface could be damaged as a result.
•Never place the device on a soft surface (e.g. carpeting, upholstered furniture, bed). This can block the air vents and cause overheating and damage.
•The underside of the device heats up during normal operation. Prolonged contact with the skin may become unpleasant or even result in burns.
•Place the device on a stable, flat, non-slippery surface. Please note that the rubber feet of the device may mark certain types of delicate surfaces.
•Keep other objects at least 100 mm / 3.94 inches away from the device and its mains adapter to ensure adequate ventilation.
•Never cover the ventilation slots of the device.
•Do not expose the device to extreme environmental conditions. Protect the device from dust, humidity, and heat.
Observe the safety notes in the enclosed "Safety/Regulations" manual.
The supplied power cable conforms to the requirements of the country in which you purchased your device. Make sure that the power cable is approved for use in the country in which you intend to use it.
3 |
2 |
1 |
►Connect the power cable (1) to the power adapter provided for the device, see chapter "Technical data", Page 72.
►Plug the mains cable (2) into a mains outlet.
►Connect the mains adapter cable (3) to the DC jack (DC IN) of the device.
Fujitsu |
17 |
First-time setup of your device
Switching on the device for the first time
When you switch on the device for the first time, the supplied software is installed and configured. Because this procedure must not be interrupted, you should set aside enough time for it to be fully completed and connect the device to the mains using the mains adapter.
During the installation process, DO NOT restart the device unless you are requested to do so!
To make it easier to use your device for the first time, the operating system is pre-installed on the hard disk.
► Switch on your device.
► During installation, follow the instructions on screen.
If a Windows operating system is installed on your device, you will find more information on the system and drivers, help programmes, updates, manuals etc. on the device or on the Internet under "http://www.fujitsu.com/fts/support/".
You can find information and help on the Windows operating system functions on the Internet at "http://windows.microsoft.com".
18 |
Fujitsu |
Working with the notebook
This chapter describes the basics for operating your notebook. Please read the chapter entitled "Connecting external devices", Page 52 for instructions on how to connect devices such as a mouse and a printer to the notebook.
Please refer to the notes in "Important notes", Page 12.
The status indicators provide information about the status of the power supply, the hard disk and the keyboard functions.
F
Fujitsu |
19 |
Working with the notebook
Indicator Description
Power-on indicator/Standby
•Indicator is illuminated: The notebook is switched on.
•Indicator flashes: The notebook is in standby mode.
•Indicator is off: The notebook is switched off.
Battery status indicator/mains connection
The state of charge of the battery is shown by the battery indicator.
1.With AC adapter connected:
•The indicator lights up orange: The battery is charging.
•The indicator is off: Charging is completed.
•The indicator flashes orange: The battery cannot be charged as the battery is too hot or cold for charging. The charging process is continued as soon as the battery reaches a permissible temperature again.
2.Running on battery (without AC adapter):
•The indicator is off: Battery level is 100-21%.
•The indicator lights up red: Battery level is 20-0%.
3.Battery abnormality/error: The indicator flashes red.
F Lock indicator
F
The indicator lights up: The key combination Fn + F has been pressed. Instead of the imprinted standard functions of the function keys, the Fn functions can be executed by pressing the keys directly (see chapter "Function keys and key combinations", Page 24).
Num Lock indicator
Indicator is illuminated: The Num key has been pressed. The virtual numerical keypad is activated. You can output the characters indicated on the upper right of the keys.
Caps Lock indicator
Indicator is illuminated: The Caps Lock key has been pressed. All the characters you type will appear in upper case. In the case of overlay keys, the character printed on the upper left of the key will appear when that key is pressed.
Scroll Lock indicator
Indicator is illuminated: the key combination Fn + Scr has been pressed. The effect that this key has varies between applications.
20 |
Fujitsu |
Working with the notebook
► Open the LCD screen.
► Press the ON/OFF button for about 1 second to switch the notebook on.
The power-on indicator is lit.
Back up your data and close all applications before you switch off your device. Otherwise data might be lost.
► Shut down the operating system correctly.
► If the notebook does not switch itself off automatically, press the ON/OFF button for about 5-10 seconds.
► Close the LCD screen.
Fujitsu |
21 |
