Beko WMB 51011 PL F, WMB 50811 PL F Operating Instructions

Washing Machine Pralka automatyczna

WMB 50811 PL F WMB 51011 PL F

Important information or useful hints about usage.

Please read this user manual first!

Dear Customer,

We hope that you get the best results from the product which has been manufactured in state-of-the-art plants and passed through a strict quality control procedure.

Therefore, please read the entire user manual carefully before using the product and keep it as a reference for future use. In case of transferring the product to someone else, give the manual as well.

The user manual will help you use your machine in a fast and safe way.

•Read the user manual before installing and starting your product.

•Always follow the safety instructions.

•Keep this user manual within easy reach for future reference.

•Read also the other documents supplied with the product.

Remember that this user manual is also applicable for several other models. Differences between models will be identified in the manual.

2820522768_EN/090212.1211

Explanation of symbols

Throughout this user manual the following symbols are used:

C

AWarning for hazardous situations with regard to life and property. BWarning for electric shock.

This appliance’s packaging material is recyclable. Help recycle it and protect the environment by dropping it off in the municipal receptacles provided

for this purpose. Your appliance also contains a great amount of recyclable material. It is marked with this label to indicate the used appliances that should not be mixed with other waste. This way, the appliance recycling organised

by your manufacturer will be done under the best possible conditions, in compliance with European Directive 2002/96/EC on Waste Electrical and Electronic Equipment. Contact your town hall or your retailer for the used appliance collection points closest to your home. We thank you doing your part to protect the environment.

2 EN

TABLE OF CONTENTS

1 Your washing machine

4

Overview . . . . . . . . . . . . . . . . . . . . . . . 4 Technical specifications . . . . . . . . . . . . 5

2 Important safety
instructions	6

General safety . . . . . . . . . . . . . . . . . . . 6 Intended use . . . . . . . . . . . . . . . . . . . . 6 Children's safety . . . . . . . . . . . . . . . . . . 7

3 Installation

8

Appropriate installation location . . . . . . 8 Removing packaging reinforcement . . . 8 Removing the transportation locks . . . . 8 Connecting water supply . . . . . . . . . . . 9 Connecting to the drain . . . . . . . . . . . . 9 Adjusting the feet . . . . . . . . . . . . . . . . 10 Electrical connection. . . . . . . . . . . . . . 10 First use . . . . . . . . . . . . . . . . . . . . . . . 11 Disposing of packaging material . . . . . 11 Transportation of the product . . . . . . . 11 Disposing of the old product. . . . . . . . 11

4 Preparation

12

Things to be done for energy saving . . 12 Sorting the laundry . . . . . . . . . . . . . . . 12 Preparing laundry for washing. . . . . . . 12 Correct load capacity . . . . . . . . . . . . . 13 Loading the laundry . . . . . . . . . . . . . . 13 Using detergent and softener . . . . . . . 14 Tips for efficient washing . . . . . . . . . . 16

5 Operating the product

17

Control panel . . . . . . . . . . . . . . . . . . . 17 Preparing the machine . . . . . . . . . . . . 18 Programme selection . . . . . . . . . . . . . 18 Main programmes . . . . . . . . . . . . . . . 18

Additional programmes . . . . . . . . . . . 18 Special programmes. . . . . . . . . . . . . . 19 Temperature selection. . . . . . . . . . . . . 19 Spin speed selection . . . . . . . . . . . . . 19

Programme selection and consumption table . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Auxiliary function selection . . . . . . . . . 21 Starting the programme . . . . . . . . . . . 21 Child Lock . . . . . . . . . . . . . . . . . . . . . 21 Progress of programme . . . . . . . . . . . 22 Loading door lock. . . . . . . . . . . . . . . . 22

Changing the selections after programme has started . . . . . . . . . . . . . . . . . . . . . 22

Canceling the programme . . . . . . . . . 23 End of programme . . . . . . . . . . . . . . . 23

6 Maintenance and cleaning24

Cleaning the detergent drawer . . . . . . 24

Cleaning the loading door and the

drum . . . . . . . . . . . . . . . . . . . . . . . . . 24 Cleaning the body and control panel. . 24 Cleaning the water intake filters . . . . . 24

Draining remaining water and cleaning the pump filter . . . . . . . . . . . . . . . . . . . . . 25

7 Troubleshooting	27
PRODUCT FICHE	33

3 EN

1 Your washing machine

Overview

8	1
	2

3 7

6

4

5

1- Power cable		5- Adjustable feet
2- Top panel		6- Loading door
3- Control panel		7- Detergent drawer
4- Filter cap		8- Drain hose

4 EN

Technical specifications

Models (EN)	WMB 50811 PL F	WMB 51011 PL F
Maximum dry laundry capacity (kg)	5	5
Height (cm)	84	84
Width (cm)	60	60
Depth (cm)	45	45
Net weight (±4 kg.)	59	59
Electrical input (V/Hz)	230 V / 50Hz	230 V / 50Hz
Total current (A)	10	10
Total power (W)	2200	2200
Spin speed (rpm max.)	800	1000
Stand-by mode power (W)	1.00	1.00
Off-mode power (W)	0.25	0.25

C Technical specifications may be changed without prior notice to improve the quality of the product.

C C

Figures in this manual are schematic and may not match the product exactly.

Values stated on the product labels or in the documentation accompanying it are obtained in laboratory conditions in accordance with the relevant standards.

Depending on operational and environmental conditions of the product, these values may vary.

5 EN

2 Important safety instructions

This section contains safety instructions that will help protect from risk of personal injury or property damage. Failure to follow these instructions shall void any warranty.

General safety

•This product should not be used by persons with physical, sensory or mental disorders or unlearned or inexperienced people (including

children) unless they are attended by a person who will be responsible for their safety or who will instruct them accordingly for use of the product.

•8 years and older children and people with reduced physical, sensory, and mental abilities as well as unskilled

or inexperienced persons can use this appliance provided that they are supervised and instructed on safe use of the appliance as well as to the related dangers. Children should not play or tamper with the appliance.

Cleaning and user maintenance should never be performed by children unless supervised by a responsible adult.

•Never place the product on a carpetcovered floor; otherwise, lack of airflow beneath the machine will cause electrical parts to overheat. This will cause problems with your product.

•Do not operate the product if the power cable / plug is damaged. Call the Authorized Service Agent.

•Have a qualified electrician connect a 16-Ampere fuse to the installation location of the product.

•If the product has a failure, it should not be operated unless it is repaired by the

Authorized Service Agent. There is the risk of electric shock!

•This product is designed to resume operating in the event of powering on after a power interruption. If you wish to cancel the programme, see "Cancelling the programme" section.

•Connect the product to a grounded outlet protected by a fuse complying with the values in the "Technical specifications" table. Do not neglect to have the grounding installation made

by a qualified electrician. Our company shall not be liable for any damages that will arise when the product is used without grounding in accordance with the local regulations.

•The water supply and draining hoses must be securely fastened and remain undamaged. Otherwise, there is the risk of water leakage.

•Never open the loading door or remove the filter while there is still water in the drum. Otherwise, risk of flooding and injury from hot water will occur.

•Do not force open the locked loading door. The loading door will be ready to open just a few minutes after the washing cycle comes to an end.

In case of forcing the loading door to open, the door and the lock mechanism may get damaged.

•Unplug the product when not in use.

•Never wash the product by spreading or pouring water onto it! There is the risk of electric shock!

•Never touch the plug with wet hands!

Never unplug by pulling on the cable, always pull out by grabbing the plug.

•Use detergents, softeners and supplements suitable for automatic washing machines only.

•Follow the instructions on the textile tags and on the detergent package.

•The product must be unplugged during installation, maintenance, cleaning and repairing procedures.

•Always have the installation and repairing procedures carried out by the Authorized Service Agent.

Manufacturer shall not be held liable for damages that may arise from procedures carried out by unauthorized persons.

Intended use

•This product has been designed for domestic use. It is not suitable for commercial use and it must not be used out of its intended use.

•The product must only be used for washing and rinsing of laundry that are marked accordingly.

6 EN

•The manufacturer waives any responsibility arisen from incorrect usage or transportation.

Children's safety

•Electrical products are dangerous for the children. Keep children away from the product when it is in use. Do not let them to tamper with the product. Use child lock to prevent children from intervening with the product.

•Do not forget to close the loading door when leaving the room where the product is located.

•Store all detergents and additives in a safe place away from the reach of the children.

7 EN

3 Installation

Refer to the nearest Authorised Service Agent for installation of the product. To make the product ready for use, review the information in the user manual and make sure that the electricity, tap water supply and water drainage systems are appropriate before calling the Authorized Service Agent. If they are not, call a qualified technician and plumber to have any necessary arrangements carried out.

C Preparation of the location and electrical, tap water and waste water installations at the place of installation is under customer's responsibility.

BInstallation and electrical connections of the product must be carried out by the Authorized Service Agent.

Manufacturer shall not be held liable for damages that may arise from procedures carried out by unauthorized persons.

APrior to installation, visually check if the product has any defects on it. If so, do not have it installed. Damaged products cause risks for your safety.

C Make sure that the water inlet and discharge hoses as well as the power cable are not folded, pinched or crushed while pushing the product into its place after installation or cleaning procedures.

Appropriate installation location

•Place the machine on a rigid floor. Do not place it on a long pile rug or similar surfaces.

•Total weight of the washing machine and the dryer -with full loadwhen they are placed on top of each other reaches to approx. 180 kilograms. Place the product on a solid and flat floor that has sufficient load carrying capacity!

•Do not place the product on the power cable.

•Do not install the product at places where temperature may fall below 0ºC.

•Place the product at least 1 cm away from the edges of other furniture.

Removing packaging reinforcement

Tilt the machine backwards to remove the packaging reinforcement. Remove the packaging reinforcement by pulling the ribbon.

Removing the transportation locks

ADo not remove the transportation locks before taking out the packaging reinforcement.

ARemove the transportation safety bolts before operating the washing machine, otherwise, the product will be damaged.

1.Loosen all the bolts with a spanner until they rotate freely (C).

2.Remove transportation safety bolts by turning them gently.

8 EN

3.Attach the plastic covers supplied in the User Manual bag into the holes on the rear panel. (P)

C Keep the transportation safety bolts in a safe place to reuse when the washing machine needs to be moved again in the future.

C Never move the product without the transportation safety bolts properly fixed in place!

Connecting water supply

C The water supply pressure required to run the product is between 1 to 10 bars (0.1 – 10 MPa). It is necessary to have 10 – 80 liters of water flowing from the fully open tap in one minute to have your machine run smoothly.

Attach a pressure reducing valve if water pressure is higher.

C If you are going to use the double water-inlet product as a single (cold) water-inlet unit, you must install the supplied stopper to the hot water valve before operating the product. (Applies for the products supplied with a blind stopper group.)

C If you want to use both water inlets of the product, connect the hot water hose after removing the stopper and

gasket group from the hot water valve.

(Applies for the products supplied with a blind stopper group.)

AModels with a single water inlet should not be connected to the hot water tap. In such a case the laundry will get damaged or the product will switch to protection mode and will not operate.

ADo not use old or used water inlet hoses on the new product. It may cause stains on your laundry.

1.Connect the special hoses supplied with the product to the water inlets on the product. Red hose (left) (max.

90 ºC) is for hot water inlet, blue hose (right) (max. 25 ºC) is for cold water inlet.

AEnsure that the cold and hot water connections are made correctly when installing the product. Otherwise, your laundry will come out hot at the end of the washing process and wear out.

2.Tighten all hose nuts by hand. Never use a wrench when tightening the nuts.

3.Open the taps completely after making the hose connection to check for water leaks at the connection points. If any leaks occur, turn off the tap and remove the nut. Retighten the nut carefully after checking the seal. To prevent water leakages and damages caused by them, keep the taps closed when the machine is not in use.

Connecting to the drain

•The end of the drain hose must be directly connected to the wastewater drain or to the washbasin.

AYour house will be flooded if the hose comes out of its housing during water discharge. Moreover, there is risk of scalding due to high washing temperatures! To prevent such

situations and to ensure smooth water intake and discharge of the machine, fix the end of the discharge hose tightly so that it cannot come out.

•The hose should be attached to a height of at least 40 cm, and 100 cm at most.

9 EN

•In case the hose is elevated after laying it on the floor level or close to the ground (less than 40 cm above the ground), water discharge becomes more difficult and the laundry may come out excessively wet. Therefore, follow the heights described in the figure.

•To prevent flowing of dirty water back into the machine and to allow for easy discharge, do not immerse the hose end into the dirty water or drive it in the drain more than 15 cm. If it is too long, cut it short.

•The end of the hose should not be bent, it should not be stepped on and the hose must not be pinched between the drain and the machine.

•If the length of the hose is too short, use it by adding an original extension hose. Length of the hose may not be longer than 3.2 m. To avoid water leak failures, the connection between the extension hose and the drain hose of the product must be fitted well with an appropriate clamp as not to come off and leak.

Adjusting the feet

AIn order to ensure that the product operates more silent and vibration-free, it must stand level and balanced on its feet. Balance the machine by adjusting the feet. Otherwise, the product

may move from its place and cause crushing and vibration problems.

1.Loosen the lock nuts on the feet by hand.

2.Adjust the feet until the product stands level and balanced.

3.Tighten all lock nuts again by hand.

ADo not use any tools to loosen the lock nuts. Otherwise, they will get damaged.

Electrical connection

Connect the product to a grounded outlet protected by a fuse complying with the values in the "Technical specifications" table. Our company shall not be liable

for any damages that will arise when the product is used without grounding in accordance with the local regulations.

•Connection must comply with national regulations.

•Power cable plug must be within easy reach after installation.

•The voltage and allowed fuse or breaker protection are specified in the “Technical specifications” section. If the current value of the fuse or breaker in the house is less than 16 Amps, have a qualified electrician install a 16 Amp

10 EN

fuse.

•The specified voltage must be equal to your mains voltage.

•Do not make connections via extension cables or multi-plugs.

BDamaged power cables must be replaced by the Authorized Service Agents.

First use

Before starting to use the product, make sure that all preparations are made in accordance with the instructions in sections "Important safety instructions" and "Installation".

To prepare the product for washing laundry, perform first operation in Drum Cleaning programme. If your machine is not featured with Drum Cleaning programme, use Cottons-90 programme and select

Additional Water or Extra Rinse auxiliary functions as well. Before starting the programme, put max. 100 g of powder anti-limescale into the main wash detergent compartment (compartment nr. II). If the anti-limescale is in tablet form, put only one tablet into compartment nr. II. Dry the inside of the bellow with a clean piece of cloth after the programme has come to an end.

C Use an anti-limescale suitable for the washing machines.

C Some water might have remained in the product due to the quality control processes in the production. It is not harmful for the product.

Disposing of packaging material

Packaging materials are dangerous to children. Keep packaging materials in a safe place away from reach of the children.

Packaging materials of the product are manufactured from recyclable materials. Dispose of them properly and sort

in accordance with recycled waste

instructions. Do not dispose of them with normal domestic waste.

Transportation of the product

1.Unplug the product before transporting it.

2.Remove water drain and water supply connections.

3.Drain the remaining water in the product completely; see, "Draining remaining water and cleaning the pump filter".

4.Install transportation safety bolts in the reverse order of removal procedure; see, "Removing the transportation locks".

C Never move the product without the transportation safety bolts properly fixed in place!

Disposing of the old product

Dispose of the old product in an environmentally friendly manner.

Refer to your local dealer or solid waste collection centre in your area to learn how to dispose of your product.

For children's safety, cut the power cable and break the locking mechanism of the loading door so that it will be nonfunctional before disposing of the product.

11 EN

4 Preparation

Things to be done for energy saving

Following information will help you use the product in an ecological and energyefficient manner.

•Operate the product in the highest capacity allowed by the programme you have selected, but do not overload; see, “Programme and consumption table”.

•Always follow the instructions on the detergent packaging.

•Wash slightly soiled laundry at low temperatures.

•Use faster programmes for small quantities of lightly soiled laundry.

•Do not use prewash and high temperatures for laundry that is not heavily soiled or stained.

•If you plan to dry your laundry in a dryer, select the highest spin speed recommended during washing process.

•Do not use detergent in excess of the amount recommended on the detergent package.

Sorting the laundry

•Sort laundry according to type of fabric, colour, and degree of soiling and allowable water temperature.

•Always obey the instructions given on the garment tags.

Washing water	Wash with sensitive,
temperature	.short programmes
Bleach can be	Do not use bleach
used
Suitable for drier	Do not dry with drier

Hang without	Can be ironed with
spinning	hot iron
Non machine-washable	Do not wash
Dry-cleanable	Do not dry-clean
Dry horizontally	Dry on a hanger

Can be ironed			Do not iron
with warm iron

Preparing laundry for washing

•Laundry items with metal attachments such as, underwired bras, belt buckles or metal buttons will damage the machine. Remove the metal pieces or wash the clothes by putting them in a laundry bag or pillow case.

12 EN

•Take out all substances in the pockets such as coins, pens and paper clips, and turn pockets inside out and brush.

Such objects may damage the product or cause noise problem.

•Put small size clothes such as infant’s socks and nylon stockings in a laundry bag or pillow case.

•Place curtains in without compressing them. Remove curtain attachment items.

•Fasten zippers, sew loose buttons and mend rips and tears.

•Wash “machine washable” or “hand washable” labeled products only with an appropriate programme.

•Do not wash colours and whites together. New, dark coloured cottons release a lot of dye. Wash them separately.

•Tough stains must be treated properly before washing. If unsure, check with a dry cleaner.

•Use only dyes/colour changers and limescale removers suitable for machine wash. Always follow the instructions on the package.

•Wash trousers and delicate laundry turned inside out.

•Keep laundry items made of Angora wool in the freezer for a few hours before washing. This will reduce pilling.

•Laundry that are subjected to materials such as flour, lime dust, milk powder, etc. intensely must be shaken off before placing into the machine. Such dusts and powders on the laundry may build up on the inner parts of

the machine in time and can cause damage.

Correct load capacity

The maximum load capacity depends on the type of laundry, the degree of soiling

and the washing programme desired.

The machine automatically adjusts the amount of water according to the weight of the loaded laundry.

AFollow the information in the “Programme and consumption table”. When overloaded, machine’s washing performance will drop. Moreover, noise and vibration problems may occur.

Laundry types and their average weights in the following table are given as examples.

Laundry type	Weight (g)
Bathrobe	1200
Napkin	100
Duvet cover	700
Bed Sheet	500
Pillowcase	200
Tablecloth	250
Towel	200
Hand towel	100
Evening gown	200
Underclothing	100
Men’s overalls	600
Men’s shirt	200
Men’s pajamas	500
Blouses	100

Loading the laundry

•Open the loading door.

•Place laundry items loosely into the machine.

•Push the loading door to close until you hear a locking sound. Ensure that no items are caught in the door.

C The loading door is locked while a programme is running. The door can only be opened a while after the programme comes to an end.

AIn case of misplacing the laundry, noise and vibration problems may occur in the machine.

13 EN

Using detergent and softener

Detergent Drawer

The detergent drawer is composed of three compartments:

-(1) for prewash

-(2) for main wash

– (3) for softener

– (*) in addition, there is siphon piece in the softener compartment.

2 3 1

C The detergent dispenser may be in two different types according to the model of your machine as seen above.

Detergent, softener and other cleaning agents

•Add detergent and softener before starting the washing programme.

•Never open the detergent drawer while the washing programme is running!

•When using a programme without prewash, do not put any detergent into the prewash compartment (compartment nr. 1).

•In a programme with prewash, do not put liquid detergent into the prewash compartment (compartment nr. 1).

•Do not select a programme with prewash if you are using a detergent bag or dispensing ball. Place the detergent bag or the dispensing ball directly among the laundry in the machine.

•If you are using liquid detergent, do not forget to place the liquid detergent cup into the main wash compartment (compartment nr. 2).

Choosing the detergent type

The type of detergent to be used depends on the type and colour of the fabric.

•Use different detergents for coloured and white laundry.

•Wash your delicate clothes only with special detergents (liquid detergent, wool shampoo, etc.) used solely for delicate clothes.

•When washing dark coloured clothes and quilts, it is recommended to use liquid detergent.

•Wash woolens with special detergent made specifically for woolens.

AUse only detergents manufactured specifically for washing machines.

ADo not use soap powder.

Adjusting detergent amount

The amount of washing detergent to be used depends on the amount of laundry, the degree of soiling and water hardness.

Read the manufacturer’s instructions on the detergent package carefully and follow the dosage values.

•Do not use amounts exceeding the dosage quantities recommended on the detergent package to avoid problems of excessive foam, poor rinsing, financial savings and finally, environmental protection.

•Use lesser detergent for small amounts or lightly soiled clothes.

•Use concentrated detergents in the recommended dosage.

Using softeners

Pour the softener into the softener compartment of the detergent drawer.

•Use the dosages recommended on the package.

•Do not exceed the (>max<) level marking in the softener compartment.

•If the softener has lost its fluidity, dilute it with water before putting it in the detergent drawer.

Using liquid detergents

If the product contains a liquid detergent cup:

•Make sure that you have placed the liquid detergent cup in compartment nr. “2”.

•Use the detergent manufacturer’s measuring cup and follow the instructions on the package.

•Use the dosages recommended on the package.

•If the liquid detergent has lost its fluidity, dilute it with water before putting in the detergent cup.

14 EN

If the product does not contain a liquid detergent cup:

•Do not use liquid detergent for the prewash in a programme with prewash.

•Use the detergent manufacturer’s measuring cup and follow the instructions on the package.

•Liquid detergent stains your clothes when used with Delayed Start function. If you are going to use the Delayed Start function, do not use liquid detergent.

Using gel and tablet detergent

When using tablet, gel, etc. detergents, read the manufacturer’s instructions on the detergent package carefully and follow the dosage values. If there is not any instruction on the package, apply the following.

•If the gel detergent thickness is fluidal and your machine does not contain a special liquid detergent cup, put the gel detergent into the main wash detergent compartment during first

water intake. If your machine contains a liquid detergent cup, fill the detergent into this cup before starting the programme.

•If the gel detergent thickness is not fluidal or in the shape of capsule liquid tablet, put it directly into the drum before washing.

•Put tablet detergents into the main wash compartment (compartment nr. II) or directly into the drum before washing.

C Tablet detergents may leave residues in the detergent compartment. If you encounter such a case, place the tablet

detergent between the laundry, close to the lower part of the drum in future washings.

C Use the tablet or gel detergent without selecting the prewash function.

Using starch

•Add liquid starch, powder starch or the dyestuff into the softener compartment as instructed on the package.

•Do not use softener and starch together in a washing cycle.

•Wipe the inside of the machine with a damp and clean cloth after using starch.

Using bleaches

•Select a programme with prewash and add the bleaching agent at the beginning of the prewash. Do not put detergent in the prewash compartment.

As an alternative application, select a programme with extra rinse and add the bleaching agent while the machine is taking water from the detergent compartment during first rinsing step.

•Do not use bleaching agent and detergent by mixing them.

•Use just a little amount (approx. 50 ml) of bleaching agent and rinse the clothes very well as it causes skin irritation. Do not pour the bleaching agent onto the clothes and do not use it for coloured clothes.

•When using oxygen based bleaches, follow the instructions on the package and select a programme that washes at a lower temperature.

•Oxygen based bleaches can be used together with detergents; however,

if its thickness is not the same with the detergent, put the detergent first into the compartment nr. “II” in the detergent drawer and wait until the detergent flows while the machine is taking in water. Add the bleaching agent from the same compartment

while the machine is still taking in water.

Using limescale remover

•When required, use limescale removers manufactured specifically for washing machines only.

•Always follow instructions on the package.

15 EN

Tips for efficient washing

Soiling Level

			Clothes
		Light colours and	Colors	Dark colors	Delicates/
		whites			Woolens/Silks
		(Recommended	(Recommended	(Recommended	(Recommended
				temperature	temperature
		temperature range	temperature range
				range based	range based
		based on soiling	based on soiling level:
				on soiling level:	on soiling level:
		level: 40-90C)	cold-40C)	cold-40C)	cold-30C)
		It may be
		necessary to pre-
		treat the stains of	Powder and
		perform prewash.	liquid detergents
		Powder and	recommended for
		liquid detergents	colours can be	Liquid	Prefer liquid
	Heavily Soiled	recommended	used at dosages	detergents	detergents
		for whites can be	recommended for	suitable for	produced for
	(difficult stains	used at dosages	heavily soiled clothes.	colours and dark	delicate clothes.
		recommended	It is recommended	colours can be	Woollen and silk
	such as grass,	for heavily soiled	to use powder	used at dosages	clothes must
	coffee, fruits	clothes. It is	detergents to clean	recommended	be washed with
	and blood.)	recommended	clay and soil stains	for heavily soiled	special woollen
		to use powder	and the stains that are	clothes.	detergents.
		detergents to clean	sensitive to bleaches.
		clay and soil stains	Use detergents
		and the stains that	without bleach.
		are sensitive to
		bleaches.
			Powder and	Liquid	Prefer liquid
	Normally Soiled	Powder and	liquid detergents
				detergents	detergents
		liquid detergents	recommended for	suitable for	produced for
		recommended	colours can be
	(For example,			colours and dark	delicate clothes.
		for whites can be	used at dosages
	stains caused	used at dosages	recommended for	colours can be	Woollen and silk
	by body on	recommended for	normally soiled	used at dosages	clothes must
	collars and	normally soiled	clothes. Use	recommended	be washed with
				for normally	special woollen
	cuffs)	clothes.	detergents without
				soiled clothes.	detergents.
			bleach.
			Powder and	Liquid	Prefer liquid
		Powder and	liquid detergents	detergents	detergents
	Lightly Soiled	liquid detergents	recommended for	suitable for	produced for
		recommended	colours can be	colours and dark	delicate clothes.
	(No visible	for whites can be	used at dosages	colours can be	Woollen and silk
		used at dosages	recommended for	used at dosages	clothes must
	stains exist.)	recommended for	lightly soiled clothes.	recommended	be washed with
		lightly soiled clothes.	Use detergents	for lightly soiled	special woollen
			without bleach.	clothes.	detergents.

16 EN

5 Operating the product

Control panel

6		8		7		2		1

4 5

1 - Programme Selection knob

2 - Spin Speed Adjustment button*

3 - Temperature Adjustment button*

4 - Start / Pause / Cancel button

5 - Auxiliary Function buttons

6 - On / Off button

7 - Programme Follow-up indicator

8 - Loading Door light*

* Varies depending on the model of your machine.

17 EN

Preparing the machine

1.Make sure that the hoses are connected tightly.

2.Plug in your machine.

3.Turn the tap on completely.

4.Place the laundry in the machine.

5.Add detergent and fabric softener.

Programme selection

1.Select the programme suitable for the type, quantity and soiling degree of the laundry in accordance with the "Programme and consumption table" and the temperature table below.

	90˚C	Heavily soiled white cottons
		and linens. (coffee table
		covers, tableclothes, towels,
		bed sheets, etc.)
		Normally soiled, coloured,
	60˚C	fade proof cottons or
		synthetic clothes (shirt,
		nightgown, pajamas, etc.)
		and lightly soiled white
		linens (underwear, etc.)
	40˚C-	Blended laundry including
		delicate textile (veil curtains,
	30˚C-
		etc.), synthetics and
	Cold
		woolens.

2.Select the desired programme with the Programme Selection button.

C Programmes are limited with the highest spin speed appropriate for that particular type of fabric.

C When selecting a programme, always consider the type of fabric, colour, degree of soiling and permissible water temperature.

C Always select the lowest required temperature. Higher temperature means higher power consumption.

C For further programme details, see "Programme and consumption table".

Main programmes

Depending on the type of fabric, use the following main programmes.

• Bawełna (Cottons)

You may wash your normally soiled durable cotton and linen laundry in this programme with the highest energy and water saving compared to all other wash programmes suitable for cottons. Actual

water temperature may differ from the declared cycle temperature. Programme duration may automatically be shortened during later stages of the programme if you wash less amount (e.g. ½ capacity or less) of laundry. In this case energy and water consumption will be further decreased giving you the opportunity for a more economical wash. This feature is available for certain models having remaining time display.

• Syntetyki (Synthetics)

Use this programme to wash your synthetic clothes (shirts, blouses, synthetic/cotton blends, etc.). It washes with a gentle action and has a shorter washing cycle compared to the Cottons programme.

For curtains and tulle, use the Synthetic 40˚C programme with prewash function selected. As their meshed texture causes excessive foaming, wash the veils/tulle by putting little amount of detergent into the main wash compartment. Do not put detergent in the prewash compartment.

• Wełna (Woollens)

Use this programme to wash your woolen clothes. Select the appropriate temperature complying with the tags of your clothes. Use appropriate detergents for woolens.

Additional programmes

For special cases, additional programmes are available in the machine.

C Additional programmes may differ according to the model of the machine.

• Delikatne (Delicate)

Use this programme to wash your delicate clothes. It washes with a gentle action without any interim spin compared to the Synthetics programme.

• Pranie ręczne (Hand wash)

Use this programme to wash your woolen/ delicate clothes that bear “not machinewashable” tags and for which hand wash is recommended. It washes laundry with a very gentle washing action to not to damage clothes.

• Mini 30

Use this programme to wash your little amount of lightly soiled cotton clothes in a short time (30 minutes).

18 EN

• Super 40

Use this programme to wash your laundry for which you cannot use Cottons 60 °C programme. It gives the same result with the Cottons 60 °C programme by washing for a longer time at 40 °C, thus enabling energy saving.

Special programmes

For specific applications, select any of the following programmes.

• Płukanie (Rinse)

Use this programme when you want to rinse or starch separately.

• Wirowanie + Odpompowanie (Spin + Drain)

Use this programme to apply an additional spin cycle for your laundry or to drain the water in the machine.

Before selecting this programme, select the desired spin speed and press Start / Pause / Cancel button. First, the machine will drain the water inside of it. Then, it will spin the laundry with the set spin speed and drain the water coming out of them.

If you wish to drain water only without spinning your laundry, select the Pump+Spin programme and then select the "No Spin" function with the help of Spin

Speed Adjustment button depending on the model of your machine and press Start / Pause button.

C If your machine is not equipped with Spin Speed Adjustment button and

No Spin auxiliary function and if you wish to drain the water only without spinning your laundry, select the Pump+Spin programme and press Start / Pause button. Machine will switch to spin step once it completes pump step. Press Start / Pause / Cancel button to stop the machine as soon as you see the drum rotating.

C Use a lower spin speed for delicate laundries.

Temperature selection

In models equipped with Temperature

Adjustment button, you can wash your clothes at the desired temperature by using this button.

ATo prevent damage on your laundry, do not select a temperature that exceeds the one recommended for your laundry in the “Programme and consumption table".

Spin speed selection

In models equipped with Spin Speed

Adjustment button, you can spin your laundry at the desired speed by using this button.

In models not equipped with Spin Speed

Adjustment button, spin will be performed at the recommended speed for the selected programme.

C If you wish to take out your laundry without spinning, switch the Spin

Speed Adjustment button to No Spin position.

19 EN

Programme selection and consumption table

EN

Programme		(kg)LoadMax.	DurationProgramme(~min)	ConsumptionWater (l)	ConsumptionEnergy (kWh)	wstępnePranie	PłukanieDodatkowe	płukaniaZatrzymanie	reductionspeedSpin	SpinNo	HeatNo
Bawełna	90	5	133	45	1.65	•	•	•	•	•	•
Bawełna	60**	5	150	50	0.87	•	•	•	•	•	•
Bawełna	60**	2.5	150	45	0.72	•	•	•	•	•	•
Bawełna	40**	2.5	135	45	0.54	•	•	•	•	•	•
Bawełna	40	5	142	49	0.69	•	•	•	•	•	•
Bawełna	Zimna woda (Cold)	5	120	45	0.16	•	•	•	•	•	•
Super 40	40	5	165	45	0.78				•	•	•
Syntetyki	60	2.5	113	52	0.92	•	•	•	•	•	•
Syntetyki	40	2.5	125	52	0.56	•	•	•	•	•	•
Syntetyki	30	2.5	95	52	0.3	•	•	•	•	•	•
Syntetyki	Zimna woda (Cold)	2.5	90	52	0.15	•	•	•	•	•	•
Delikatne	30	2	65	45	0.36		•	•	•	•	•
Wełna	40	1.5	60	45	0.36		•	•	•	•	•
Wełna	Zimna woda (Cold)	1.5	50	45	0.02		•	•	•	•
Pranie ręczne	30	1	45	32	0.21				•	•	•
Mini 30	30	2.5	30	43	0.17				•	•	•

** “Cotton 40°C and Cotton 60°C are the standard programmes.” These programmes are referred to as ‘standard 40°C cotton programme’ and ‘standard 60°C cotton programme’

• : Selectable

* : Automatically selected, no canceling.

**: Energy Label programme (EN 60456 Ed.3)

- : See the programme description for maximum load.

C Water and power consumption may vary subject to the changes in water pressure, water hardness and temperature, ambient temperature, type and amount of laundry, selection of auxiliary functions and spin speed, and changes in electric voltage.

C The auxiliary functions in the table may vary according to the model of your machine.

20 EN

Auxiliary function selection

Select the desired auxiliary functions before starting the programme. Furthermore, you can also select or cancel auxiliary functions that are suitable to the running programme without pressing the Start / Pause / Cancel button when the machine is operating. For this, the machine must be in a step before the auxiliary function you are going to select or cancel.

If the auxiliary function cannot be selected or canceled, light of the relevant auxiliary function will blink 3 times to warn the user.

C Some functions cannot be selected together. If a second auxiliary function conflicting with the first one is selected before starting the machine, the function selected first will be canceled and the second auxiliary function selection will remain active.

C An auxiliary function that is not compatible with the programme cannot be selected. (See "Programme and consumption table")

C Auxiliary Function buttons may vary according to the model of the machine.

• Pranie wstępne (Prewash)

A Prewash is only worthwhile for heavily soiled laundry. Not using the Prewash will save energy, water, detergent and time.

C As their meshed texture causes excessive foaming, wash the veils/tulle by putting little amount of detergent into the main wash compartment.

Do not put detergent in the prewash compartment.

•Dodatkowe Płukanie (Rinse Plus)

This function enables the machine to make another rinsing in addition to the one already made after the main wash. Thus, the risk for sensitive skins (babies, allergic skins, etc.) to be effected by the minimal detergent remnants on the laundry can be reduced.

•Zatrzymanie płukania (Rinse Hold)

If you are not going to unload your clothes immediately after the programme

completes, you can use rinse hold function to keep your laundry in the final rinsing water in order to prevent them from getting wrinkled when there is no water in the machine.

In models equipped with Spin Speed

Adjustment button, select the Spin Speed and press Start / Pause / Cancel button if you want to spin the laundry held in water.

In models not equipped with Spin Speed

Adjustment button, select Spin+Pump programme if you want to spin your laundry held in water.

C In these models, you need to stop the machine by pressing Start / Pause / Cancel button before switching to spin step and after pump step is completed and the water in the machine is drained. Thus, water inside the machine is drained and your laundry is not spun.

• Bez podgrzewania (No Heat)

Use this function if you want to wash your laundry in cold water.

• Bez wirowania (No Spin)

Use this function if you do not want your clothes be spun at the end of the programme.

• Ograniczenie prędkości wirowania (Spin speed reduction)

This function allows spinning of laundry at a speed lower than the maximum spin speed of the machine.

When Spin Reduction button is pressed, spin speed will be limited to the minimum speed specified on the control panel.

Starting the programme

1.Press Start / Pause / Cancel button to start the programme.

2.Start / Pause / Cancel button lights up to indicate that the programme has started.

3.Loading door is locked and Loading Door light turns off.

Child Lock

Use Child Lock function to prevent children from tampering with the machine. Thus you can avoid any changes in a running programme.

C You can switch on and off the machine with On / Off button when the Child Lock is active. When you switch on the machine again, programme will resume from where it has stopped with the child lock enabled.

To activate the Child Lock:

21 EN
