Apricorn Aegis Padlock 3.0 User Manual

Aegis Padlock 3.0

User’s Manual

Remember to memorize / save your authentication and recovery PINs in a safe place.

Data Security at Your Fingertips

Table of Contents

First-Time Use	4
Admin Mode	4
Locking the Drive	5
Unlocking the Drive	5
LED States and Their Meaning	5
Adding a New User PIN (Via Admin Mode)	6
Adding a New User PIN (Via User Forced Enrollment Mode)	6
Deleting the User PIN	7
Changing the User PIN	7
Changing the Admin PIN	7
Setting One-Time-Use Recovery PINs	8
Using One-Time-Use Recovery PINs	8
Setting Read-Only or Read / Write Modes from Admin Mode	9
Setting Read-Only or Read / Write Modes from the User Mode	10
Setting LED Flicker / Button Press Indicator Mode	11
Setting Minimum PIN Length Requirement	11
Setting the Unattended Auto-Lock Feature	11
Setting a Self-Destruct PIN	12
Aegis Padlock 3.0 Brute-Force Protection	13
Performing a Complete Reset	14
Initializing and Formatting After a Complete Reset	15
Hibernating or Logging Off from the Operating System	16
Aegis Padlock 3.0 Setup for Mac OS	16
Diagnostic Mode	17
Lock-Override Mode	18
Troubleshooting / FAQs	19
Quick Reference Guide for Key Command Programming	20
Warranty and RMA information	21

Copyright © Apricorn, Inc 2017. All rights reserved.

Windows is a registered trademark of Microsoft Corporation.

All other trademarks and copyrights referred to are the property of their respective owners.

Distribution of modified versions of this document is prohibited without the explicit permission of the copyright holder.

Distribution of the work or derivative work in any standard (paper) book form for commercial purposes is prohibited unless prior permission is obtained from the copyright holder.

DOCUMENTATION IS PROVIDED AS IS AND ALL EXPRESS OR IMPLIED CONDITIONS, REPRESENTATIONS AND WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT, ARE DISCLAIMED, EXCEPT TO THE EXTENT THAT SUCH DISCLAIMERS ARE HELD TO BE LEGALLY INVALID

(Rev 0) 05/25/2017

First-Time Use

CONFIGURABLE NOTE: if you are using the Aegis Configurator to set up your Aegis Padlock, or any other Apricorn secure drive, you must first ensure that the device to be

configured has the “configurable” logo on the belly label and second, DO NOT perform any of the the following Manual Admin and USER PIN SETUP steps below; The Aegis

Configurator will execute these setup steps and will only recognize devices in their factory “out of box” state or devices that have been completely reset.

Each Aegis padlock 3.0 is shipped without a preset Personal Identification Number (PIN) installed on the key. A 6 to 16-digit Admin PIN must first be established before the drive can be used. This Admin PIN can be used to set any and all of the Admin Mode Features of the drive, as well as to access its data. Note: PINs can’t be repeating or sequential numbers such as 0123456, 987654321, or 1111111, 2222222, etc.

To Set Up the Admin PIN:

1.Plug device into USB Port. Both the BLUE and GREEN LEDs will glow steadily.

2.Press + 9 at the same time. The BLUE LED will glow steadily and the GREEN LED will blink.

3.Enter the series of numbers that you will use for the Admin PIN and press thebutton.*

4.Re-enter that same PIN and press the button again. The GREEN LED will illuminate for one second, then replaced by the BLUE LED glowing steadily.

5.The drive is now in Admin mode where Admin features can be set (e.g., adding a User.)

6.If no further user(s) or functions are to be added, you can exit the Admin mode by pressing the CANCEL button and the drive will return to the locked standby state. If no action is taken within 30 seconds, the drive will return to its locked sleep state.

*GREEN LED will blink if the PIN is accepted; If the PIN is NOT accepted, the RED LED will blink-- see PIN requirements above.

Admin Mode

To set up any of the drive’s Admin functions and features, the Admin mode must first be entered. Once in the Admin mode, each of the drive’s functions can be addressed with the appropriate button commands. Also note that while in the Admin mode, the actual data on the drive will not be accessible.

To return to the Admin mode for future setups, perform the following steps below.

1.Press and hold + 0 for five seconds until the RED LED blinks.

(This indicates that the drive is prepared to accept the correct Admin PIN.)

2.Enter the Admin PIN and press the button.

3.Successfully entering the Admin Mode is indicated by a solid BLUE LED.

4.To exit the Admin Mode, either allow 30 seconds of inactivity or press the CANCEL button.

4

Unlocking the Drive

Enter either a User PIN or Admin PIN and press the button. If the PIN is accepted, the GREEN LED will blink three times, then will rapidly blink for a short time, followed by steady glowing, indicating that it’s now unlocked and ready for use. If the PIN is incorrect, the RED LED will blink.

Locking the Drive

Press the CANCEL button. When successfully locked, The RED LED will glow steadily, indicating that it’s returned to its standby state.

The Aegis Padlock will not be recognized by the operating system while in its standby state.

Note: If data is still being written to the key when the CANCEL button is pressed, the Padlock 3.0 will wait until that operation is completed before the lock command is executed.

LED States and Their Meaning

	No LEDs	Drive locked, power switch is off, device unplugged
	Blinking RED	Error / incorrect button entry; Mode Not Available;
		User PIN Change
	Solid RED	Locked / Standby state; Awaiting PIN entry
	Blinking GREEN	Button-entry accepted
	Solid BLUE /	Waiting for New User or Admin PIN to be
	Blinking GREEN	established
	Solid BLUE	Admin Mode
	Solid GREEN	Drive unlocked
	Slow Blinking BLUE	Drive unlocked in Lock-Override Mode
	Solid GREEN /	Drive unlocked in Read-Only Mode
	Slow Blinking RED
	Alternating	Indicates a mode has been entered that can result
	RED / BLUE	in the deletion of a User or the data on the drive
		(depending on the mode chosen.)
		Also used when setting Auto-lock feature
	One second of RED	Self-test mode to ensure all components are ready
	followed by one	and working properly
	second of GREEN
	followed by one
	second of BLUE
	Three Seconds of	During Reset Process, indicates successful
	Solid RED / GREEN	resetting of cryptographic security parameters

5

Establishing a User PIN

If no additional Users beyond the Admin will be permitted to access the drive’s data, disregard this page’s contents as it relates only to the “User” PINs.

The Aegis Padlock 3.0 can have one Admin and four addtional Users, making a total of five working PINs.

Adding a User is a perfect way to securely share the drive or deploy it for use where the Users do not require access to the drive’s Admin features. While the Users have limited functionality and no Admin rights to the drive, they can still access all of its data, change their own User PINs, and set the drive to Read Only or Read / Write mode.

There are two ways to establish a User PIN: Admin-generated while in Admin Mode, or Usergenerated while in User Forced Enrollment State.

A.) ADMIN-GENERATED USER PIN

1.Enter the Admin Mode by holding + 0 for five seconds; WithRED LED blinking, enter the Admin PIN and press the button. The BLUE LED will glow steadily.

2.Press the + 1 buttons together until the BLUE LED glows steadily and the GREEN LED starts blinking.

3.Enter the User PIN* and press . The GREEN LED will blink three times by itself, then the BLUE LED will glow steadily as the GREEN LED continues blinking.

4.Enter that same User PIN again and press to verify. The GREEN LED will glow steadily for three seconds verifying that the User PIN was successfully added, and then will be replaced by the BLUE LED glowing steadily, indicating that the drive has returned to the Admin mode.

CREATING FORCED ENROLLMENT STATE ALLOWING USER TO GENERATE USER PIN B.) USER-GENERATED USER PIN (USER FORCED ENROLLMENT)

Note: User Forced Enrollment state can only be implemented where there is no Admin-generated User PINs set up as described in the process above.

User Forced Enrollment Security Warning:

When a drive is in the User Forced Enrollment state, it is essentially unlocked until a User PIN is established. Therefore, DO NOT load sensitive data onto the drive if User Forced Enrollment is to be implemented.

1.Enter the Admin Mode by holding + 0 for five seconds; WithRED LED blinking, enter the Admin PIN and press the button. The BLUE LED will glow steadily.

2.Press 0 + 1 and the GREEN LED will blink three times, then will be replaced by BLUE LED glowing steadily. Press the CANCEL button to return the drive to its locked state. The drive is now in User Forced Enrollment State, allowing the first User to establish his own

User PIN.

USER-GENERATED USER PIN IN FORCED ENROLLMENT STATE

1.Press and ensure that the BLUE and the GREEN LEDs are glowing steadily.

2.Press + 1 and ensure that the BLUE LED continues glowing steadily while the GREEN LED blinks. Enter the new User PIN and press the button. The GREEN LED will blink three times by itself and then will be joined by the BLUE LED glowing steadily.

3.Within 30 seconds, enter that same User PIN once more, and press the button again. This time, the GREEN LED will glow steadily for a few seconds, then the drive will return to its locked state, indicated by the RED LED glowing steadily. The drive’s data can now be accessed using either a User PIN or the Admin PIN.

	* Note: Default setting for minimum PIN length is 6 characters,	6
	and a maximum of 16.

Deleting the User PIN

You can delete the User PIN by doing the following:

1.Enter the Admin mode. (Hold+ 0 for five seconds. With theRED LED blinking, enter the Admin PIN and press thebutton.) The BLUE LED will now glow steadily.

2.Press the 7 + 8 buttons together for five seconds. TheGREEN LED will blink three times and then will be followed by the RED and BLUE LEDs blinking alternately.

3.Press the 7 + 8 buttons together again for five seconds. The GREEN LED will glow steadily for two seconds.

4.The drive will return to Admin mode indicated by the BLUE LED glowing steadily.

NOTE: Deleting the User PIN will also delete the Self-Destruct PIN and all recovery PINs (if any have been set.)

Changing the User PIN

The User PIN can be changed within the User mode (drive unlocked, GREEN LED blinking)

*Note: The Admin PIN cannot be changed while in the User mode.

The Admin PIN can only be changed from within the Admin mode-- See below. You can change the User PIN by doing the following:

1.Unlock the Aegis Padlock 3.0 with the User PIN. (The GREEN LED will blink)

2.Press the + 1 buttons together for five seconds (the RED LED will blink)

3.Enter the current User PIN and press the button. (The BLUE LED will glow steadily and the GREEN LED will blink.)

4.Enter the new User PIN and press the button (the GREEN LED will blink three times, followed by the BLUE LED glowing steadily and the GREEN LED blinking.)

5.Re-enter the new User PIN and press the button (the GREEN LED will glow steadily for two seconds, then will return to the User mode, indicated by the GREEN LED blinking.)

Changing the Admin PIN

Changes to the Admin PIN can only be made while the drive is in the Admin mode.

1.Enter the Admin mode. (Hold + 0 for five seconds – with the RED LED blinking, enter the Admin PIN and press the button.) The BLUE LED will glow steadily.

2.Press UNLOCK + 9. The BLUE LED will glow steadily and the GREEN LED will blink.

3.Enter the new Admin PIN and press the button. The GREEN LED will blink three times.

4.Re-enter the new Admin PIN and press the button. The GREEN LED will glow steadily for two seconds and then return to the Admin mode, indicated by the BLUE LED glowing steadily.

7
