Instructions for Installation and Use
Electric Hob
Model E604
|
CONTENTS |
|
|
|
|
Introduction |
3 |
|
For Your Safety |
4 |
|
Know your Hob |
5 |
|
How to use your Hob |
5 |
|
Practical Advice |
6 |
|
Care and Cleaning |
7 |
|
Troubleshooting |
7 |
|
Installation |
8 |
|
Electrical Connection |
9 |
|
After Sales Service |
10 |
|
Hotpoint Guarantee |
11 |
|
Key Contacts |
Back Cover |
|
Retention of this Instruction Book
This Instruction Book must be kept handy for reference as it contains important details on the safe and proper use of the appliance.
If you sell or pass the appliance to someone else, or move house and leave it behind, make sure this Book is also provided so the new owner can become familiar with the appliance and safety warnings.
If the Book is lost or damaged a copy may be obtained from:
GDA LTD., Morley Way, Peterborough, PE2 9JB
2
Introduction
Your new hob is guaranteed* and will give lasting service. This guarantee is only applicable if the appliance has been installed in accordance with the installation instructions detailed in this booklet.
To help make best use of your cooking equipment, please read this booklet carefully.
The hob is designed specifically for domestic use and responsibility will not be accepted for use in any other installation.
When first using the hob, ensure that the room is well ventilated (eg. open a window or use an extractor fan) and that persons who may be sensitive to the odour avoid any fumes. it is suggested that any pets be removed from the room until the odour has ceased. This odour is due to temporary finish on elements.
Before using the hotplates for the first time, we recommend you heat them at maximum temperature for approximately 4 minutes (without pans). During this initial stage, their protective coating hardens and reaches its maximum resistance.
* The guarantee is subject to the provisions that the appliance:
(a)Has been used solely in accordance with this booklet.
(b)Has been properly connected to a suitable supply voltage as stated on the rating plate, attached to the appliance.
(c)Has not been subjected to misuse or accident or been modified or repaired by any person other than the manufacturers authorised employee or agent.
(d)Has been correctly installed.
This appliance conforms with the following European Economic Community directives
-73/23/EEC of 19/02/73 (Low Voltage) and subsequent modifications.
-89/336/EEC of 03/05/89 (Electromagnetic Compatibility) and subsequent modifications.
-93/68/EEC of 22/07/93 and subsequent modifications.
3
For Your Safety
When used properly your appliance is completely safe but as with any electrical product there are certain precautions that must be observed.
PLEASE READ THE BELOW PRECAUTIONS BEFORE USING YOUR APPLIANCE.
To maintain the efficiency and safety of this appliance, we recommend you do the following:
-only call the Service Centres authorised by the manufacturer.
-always use genuine spare parts.
ALWAYS:
-make sure you remove all packaging and dispose of safely.
-check the soundness of the appliance after it has been unpacked.
-make sure you understand the controls before using the appliance.
-keep children away from the appliance during use.
-take care to avoid heat/steam burns when operating the controls.
-make sure the controls are turned off when you have finished cooking and when not in use.
-disconnect from the power supply, and allow to cool, before cleaning or performing maintenance.
-refer servicing to a qualified appliance service engineer.
-keep the hob clean as a build up of grease or fat from cooking can cause a fire.
-follow the basic principles of food handling and hygiene to prevent the possibility of bacterial growth.
-dry food thoroughly before frying and lower it slowly into the hot oil or fat. Frozen food in particular, will cause frothing and spitting if added too quickly.
-keep outside of pans clean and free from streaks of oil or fat.
-place pans centrally over the hotplates making sure handles are kept away from the edge of the hob and cannot be heated by other hotplates/pans.
-keep any ventilation slots clear of obstructions.
SAFETY ADVICE
NEVER:
-attempt to install or repair the appliance without the assistance of qualified personnel.
-store items above the appliance that children may attempt to reach.
-heat up unopened food containers, as pressure can build up causing the container to burst.
-use the appliance to heat up anything other than food.
-use the appliance as a room heater.
-dry any items on the hob.
-install the appliance next to curtains or other soft furnishings.
-allow children to play with or tamper with the controls.
-leave children unsupervised where cooking appliances are installed as all the cooking surfaces get hot during and after use.
-store chemicals, foodstuffs or pressurised containers in or on the appliance, or in cabinets immediately above or next to the appliance.
-use flammable or plastic items on or near the hob.
-use adapters, multiple sockets and/or extension leads.
-fill a deep fat frying pan more than 1/3 full of oil, or use a lid. DO NOT LEAVE UNATTENDED WHILE COOKING.
-fry too much food at a time, especially frozen food. This only lowers the temperature or the oil or fat too much, resulting in greasy food.
-pull on the appliance or the supply cable to unplug it from the electrical outlet.
-allow power cables of other appliances to come into contact with hot parts of this appliance.
-expose the appliance to atmospheric agents, such as rain or sunlight.
-operate the appliance with wet hands.
-operate the appliance when barefoot.
-allow anyone to sit or stand on any part of the appliance.
-use misshapen pans which may be unstable.
-use fish kettles or large preserving pans across two hotplates.
-leave anything on the hob surface when unattended and not in use.
IMPORTANT - As with any cooking appliance there could be some fire risk attached to the heating of oil, particularly for deep fat frying. Cooking utensils containing oil must not be left unattended (eg. to answer the telephone) on or in close proximity to the cooking areas.
IN THE EVENT OF A CHIP PAN OR ANY OTHER PAN FIRE:
1.Turn off the hotplates.
2.Cover the pan with a fire blanket or damp cloth, this will smother the flames and extinguish the fire.
3.Leave the pan to cool for at least 60 minutes before moving it. Injuries are often caused by picking up a hot pan and rushing outside with it.
NEVER USE A FIRE EXTINGUISHER TO PUT OUT A PAN FIRE as the force of the extinguisher is likely to tip the pan over. Never use water to extinguish oil or fat fires.
4
