EcoSense® ORP15A ORP/Temperature Pen

Operations Manual

EcoSense ORP15A OVERVIEW

A. Description

2. Graphic LCD screen

3. Keypad

4. Belt clip (Do not remove screw.)

5. Electrode collar

6. Electrode & ATC assembly – outside o-ring on
electrode is yellow and inside o-ring is black.
(Electrode cap shown covering electrode.)

B. EcoSense ORP15A Keypad Layout

1. Battery cap

Hold – On/Off key

Store/Save key

Calibration/Mode key

Scroll key

INITIAL INSPECTION AND ASSEMBLY

Carefully unpack the instrument and accessories, and inspect for shipping damages. Notify your
local dealer or YSI immediately ([phone] or [e-mail]) of any damages
or missing parts. Save packing materials until satisfactory operation is confirmed.

BEFORE USING

A. Insert the Batteries

1. Remove the battery cap at the top of the unit.

2. Insert the set of batteries (included) ensuring correct polarities.

3. Securely replace battery cap.

B. Soak the Electrode

1. Remove the electrode cap covering the ORP15A meter electrode.

2. Soak electrode in pH 4 buffer for 10 minutes before first use or after storage.

OPERATION

A. Power ON/OFF

Press “HOLD – On/Off” key for 3 seconds. The unit will turn on and enter the “Measure
Mode”. Repeat process to turn off. There is a 10 minute automatic shutoff feature if no keys are
pressed.

B. Set Date and Time

1. Press and hold “CAL” key until it enters “Date/Time Set Mode”.

2. Press “HOLD” key to select date or time parameters.

3. Press “CAL”

4. Press “STORE”

key to increase or “SCROLL” keys to decrease values.

key for 2 seconds to return to “Measure Mode”.

C. Offset Calibration

1. Press “CAL” key for 3 seconds and release to enter “Calibration” mode.

2. Immerse meter into YSI Zobell solution or other known solution.

3. Press “HOLD” key to select the ability to change the offset values.

4. Press “CAL” key to increase or “SCROLL” keys to decrease values.

5. Press “STORE” key for 2 seconds to return to “Measure Mode” displaying absolute
ORP values.

6. Press “CAL” key to display relative ORP values.

Note: For accuracy, it is recommended the ORP electrode is kept clean. Calibrations may only
be needed occasionally.

D. Measure

Dip the electrode into the test solution while in the “Measure Mode”. “CAL” will enable toggling
between absolute (direct reading) and relative (corrected based on calibration) ORP values.
ABS or REL will appear on the display based on the mode selected.

E. Hold Data

1. When the ORP is stable, press “HOLD” key once to lock the reading on the display.

2. Press “HOLD” key again to unlock reading and the unit will return to “Measure Mode”.

Note: The unit cannot be powered off in “Hold Mode”.

The unit is now ready for another measurement.

F. Save Data

Either in the “Hold Mode” or the “Measure Mode”, press “STORE” key for 2 seconds. “SAVE”
and “M-XX” will appear indicating the reading has been saved and stored in memory location
XX. The unit automatically returns to “Measure Mode”.
Note: The non-volatile memory stores up to 50 sets of data (ABSolute and RELative mV,
Temperature, Date, Time) even if power is lost. If memory is full, the next set of data will
overwrite the first data set stored, then the second set of data, etc.

G. Recall Data

1. In “Measure Mode”, press “SCROLL” key 3 seconds and release. the most recent set
of saved data will appear.

2. Press the “SCROLL” key to view previous saved data.

3. Press “STORE” key for 2 seconds to return to “Measure Mode”.

H. Erase Data

1. Press “SCROLL” key 10 seconds to enter erase mode.

2. Press “STORE” key to erase
the ORP15A will return automatically to “Measure Mode”.

3. Press “SCROLL” key to escape to “Measure Mode” without clearing data.

all saved data. “Data Clear” will appear at the top and

ONGOING MAINTENANCE

A. Electrode Storage

1. Electrodes attached to the instrument should be kept in a moist environment. Keep
the sponge in the chamber moist, tap water is acceptable. The single-junction
electrode needs to be kept clean; check periodically for cleanliness.

2. For long-term storage, store in pH 4 buffer.

B. Battery Disposal

This instrument is powered by alkaline batteries, which the user must remove and dispose of
when the batteries no longer power the instrument. Disposal requirements vary by country and
region, and users are expected to understand and follow the battery disposal requirements for
their specific locale.

The circuit board in this instrument may contain a manganese dioxide lithium "coin cell" battery
that must be in place for continuity of power to memory devices on the board. This battery is not
user serviceable or replaceable. When appropriate, an authorized YSI service center will
remove this battery and properly dispose of it, per service and repair policies.

ERROR DISPLAYS AND TROUBLESHOOTING

ORP LCD
Display

Any Value

"OVER" or
“UNDR”

ATC
Display

"OVER"
or
“UNDR”

-10 to

100.0°C

DISPLAY
Mode

Measure

Measure

Possible cause(s)
[Action(s)]

a. Temperature outside -10 to 100.0°C range.
[Bring solution to a lower/higher temp.]
b. Bad sensor. [Replace electrode.]
ORP value outside -1100 to +1100 ORP range .
[Recalibrate, Clean or Replace electrode.]

SPECIFICATIONS

Range Resolution Accuracy

ORP -1100 to +1100 mV 1 mV 1 mV ± 1 LSD

Temp. -10.0 to 100.0 °C Temp. 0.1 °C Temp. ±0.3 °C

Temp. 14.0 to 212 °F Temp. 0.2 °F Temp. ±0.6 °F

ORP

Offset Range User programmable from -999 to 999 mV
Input impedance >10

Temperature

Temperature sensor Thermistor, 10 kΩ at 25°C

General

12

Ω

Battery life Meter: >200 Hours (low battery indicator)
Ambient temperature range 0.0 to 50.0 °C (32.0 to 122.0 °F)
Display 98x64 graphic LCD
Case IP67 water-tight case
Weight 105 g (3.7 ounces)

REPLACEMENT PARTS

Item Number Description

605122 REF Instruction Manual

606112
606116 Sensor Cap

606118 Battery Compartment Kit (Includes battery cover and battery gasket)
605118 Battery Kit (Includes 4 batteries)

ORP15A Electrode Replacement Kit (Includes electrode, electrode collar,

3 o-rings, and sensor cap)

WARRANTY

The EcoSense ORP15A Instrument is warranted for one year from date of purchase by the end user against
defects in materials and workmanship. EcoSense ORP15A electrodes are warranted for six months from date
of purchase by the end user against defects in material and workmanship. Within the warranty period, YSI will
repair or replace, at its sole discretion, free of charge, any product that YSI determines to be covered by this
warranty.

To exercise this warranty, write or call your local YSI representative, or contact YSI Customer Service in
Yellow Springs, Ohio. Send the product and proof of purchase, transportation prepaid, to the Authorized
Service Center selected by YSI. Repair or replacement will be made and the product returned, transportation
prepaid. Repaired or replaced products are warranted for the balance of the original warranty period, or at
least 90 days from date of repair or replacement.

Limitation of Warranty

This Warranty does not apply to any YSI product damage or failure caused by: (i) failure to install, operate or
use the product in accordance with YSI's written instructions; (ii) abuse or misuse of the product; (iii) failure to
maintain the product in accordance with YSI's written instructions or standard industry procedure; (iv) any
improper repairs to the product; (v) use by you of defective or improper components or parts in servicing or
repairing the product; or (vi) modification of the product in any way not expressly authorized by YSI.

THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING ANY WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. YSI's LIABILITY UNDER THIS WARRANTY IS LIMITED
TO REPAIR OR REPLACEMENT OF THE PRODUCT, AND THIS SHALL BE YOUR SOLE AND EXCLUSIVE REMEDY FOR
ANY DEFECTIVE PRODUCT COVERED BY THIS WARRANTY. IN NO EVENT SHALL YSI BE LIABLE FOR ANY SPECIAL,
INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM ANY DEFECTIVE PRODUCT COVERED BY
THIS WARRANTY.
