Vtech CS6114-2, CS6114, CS6114-11 User Manual

Go to www.vtechphones.com to register your product for enhanced warranty support and the latest VTech product news.

CS6114

CS6114-11

CS6114-2

DECT 6.0 cordless telephone

BC

User’s manual

Congratulations

on purchasing your new VTech product. Before using this telephone, please read

Important safety instructions.

This manual has all the feature operations and troubleshooting necessary to install and operate your new VTech telephone. Please review this manual thoroughly to ensure proper installation and operation of this innovative and feature rich VTech product.

For support, shopping, and everything new at VTech, visit our website at www.vtechphones.com. In Canada, please visit www.vtechcanada.com.

Compatible with Hearing Aid T-Coil

T

TIA-1083

Telephones identified with this logo have reduced noise and interference when used with most T-coil equipped hearing aids and cochlear implants. The TIA-1083 Compliant Logo is a trademark of the

Telecommunications Industry Association. Used under license.

The ENERGY STAR® program (www.energystar.gov) recognizes and encourages the use of products that save energy and help protect our environment. We are proud to mark this product with

the ENERGY STAR® label indicating it meets the latest energy efficiency guidelines.

Important safety instructions

When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury, including the following:

1.Read and understand all instructions.

2.Follow all warnings and instructions marked on the product.

3.Unplug this product from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning.

4.Do not use this product near water such as near a bath tub, wash bowl, kitchen sink, laundry tub or a

swimming pool, or in a wet basement or shower.

5.Do not place this product on an unstable table, shelf, stand or other unstable surfaces.

6.Avoid placing the telephone system in places with extreme temperature, direct sunlight, or other electrical devices. Protect your phone from moisture, dust, corrosive liquids and fumes.

7.Slots and openings in the back or bottom of the telephone base and handset are provided for ventilation. To protect them from overheating, these openings must not be blocked by placing the product on a soft surface such as a bed, sofa or rug. This product should never be placed near or over a radiator or heat register. This product should not be placed in any area where proper ventilation is not provided.

8.This product should be operated only from the type of power source indicated on the marking label. If you

are not sure of the type of power supply in your home or office, consult your dealer or local power company.

9.Do not allow anything to rest on the power cord. Do not install this product where the cord may be walked on.

10.Never push objects of any kind into this product through the slots in the telephone base or handset because they may touch dangerous voltage points or create a short circuit. Never spill liquid of any kind on the product.

11.To reduce the risk of electric shock, do not disassemble this product, but take it to an authorized service facility. Opening or removing parts of the telephone base or handset other than specified access doors may

expose you to dangerous voltages or other risks. Incorrect reassembling can cause electric shock when the product is subsequently used.

12.Do not overload wall outlets and extension cords.

13.Unplug this product from the wall outlet and refer servicing to an authorized service facility under the following conditions:

•When the power supply cord or plug is damaged or frayed.

•If liquid has been spilled onto the product.

•If the product has been exposed to rain or water.

•If the product does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operation instructions. Improper adjustment of other controls

may result in damage and often requires extensive work by an authorized technician to restore

the product to normal operation.

•If the product has been dropped and the telephone base and/or handset has been damaged.

•If the product exhibits a distinct change in performance.

14.Avoid using a telephone (other than cordless) during an electrical storm. There is a remote risk of electric shock from lightning.

15.Do not use the telephone to report a gas leak in the vicinity of the leak.

Under certain circumstances, a spark may be created when the adapter

is plugged into the power outlet, or when the handset is replaced in its cradle. This is a common event associated with the closing of any electrical circuit. The user should not plug the phone into a power

outlet, and should not put a charged handset into the cradle, if the phone is located in an environment containing concentrations of flammable or flame-supporting gases, unless there is adequate ventilation. A spark in such an environment could create a fire

or explosion. Such environments might include: medical use of oxygen without adequate ventilation; industrial gases (cleaning solvents; gasoline vapors; etc.); a leak of natural gas; etc.

16.Only put the handset of your telephone next to your ear when it is in normal talk mode.

17.The power adapter is intended to be correctly oriented in a vertical or floor mount position. The prongs are not designed to hold the plug in place if it is plugged into a ceiling, under-the- table or cabinet outlet.

SAVE THESE INSTRUCTIONS

Battery

•CAUTION: Use Only Supplied Battery.

•Do not dispose of the battery in a fire. Check with local waste management codes for special disposal instructions.

•Do not open or mutilate the battery. Released electrolyte is corrosive and may cause burns or injury to the eyes or skin. The electrolyte may be toxic if swallowed.

•Exercise care in handling batteries in order not to create a short circuit with conductive materials.

•Charge the battery provided with this product only in accordance with the instructions and limitations specified in this manual.

Precautions for users of implanted cardiac pacemakers

Cardiac pacemakers (applies only to digital cordless telephones):

Wireless Technology Research, LLC (WTR), an independent research entity, led a multidisciplinary evaluation of the interference between portable wireless telephones and implanted cardiac pacemakers. Supported by the U.S. Food and Drug Administration, WTR recommends to physicians that:

Pacemaker patients

•Should keep wireless telephones at least six inches from the pacemaker.

•Should NOT place wireless telephones directly over the pacemaker, such as in a breast pocket, when it is turned ON.

•Should use the wireless telephone at the ear opposite the pacemaker.

WTR’s evaluation did not identify any risk to bystanders with pacemakers from other persons using wireless telephones.

About cordless telephones

•Privacy: The same features that make a cordless telephone convenient create some limitations. Telephone calls are transmitted between the telephone base and the cordless handset by radio waves, so there is a possibility that the cordless telephone conversations could be intercepted

by radio receiving equipment within range of the cordless handset. For this reason, you should not think of cordless telephone conversations as being as private as those on corded telephones.

•Electrical power: The telephone base of this cordless telephone must be connected to a working electrical outlet. The electrical outlet should not be controlled by a wall switch. Calls cannot be made from the cordless handset if the telephone base is unplugged, switched off or if the electrical power is interrupted.

•Potential TV interference: Some cordless telephones operate

at frequencies that may cause interference to televisions and VCRs. To minimize or prevent such interference, do not place the telephone base of the cordless telephone near or on top of a TV or

VCR. If interference is experienced, moving the cordless telephone farther away from the TV or VCR often reduces or eliminates the interference.

•Rechargeable batteries: Exercise care in handling batteries in order not to create a short circuit with conducting material such as rings, bracelets and keys. The battery or conductor may overheat and cause harm. Observe proper polarity between the battery and the battery charger.

•Nickel-metal hydride rechargeable batteries: Dispose of these batteries in a safe manner. Do not burn or puncture the battery. Like other batteries of this type, if burned or punctured, they could release caustic material which could cause injury.

Table of contents
What’s in the box.......................................	1
Overview.....................................................	2
Handset overview........................................	2
Telephone base overview............................	3
Charger overview.........................................	3
Display icons overview................................	3
Connect.......................................................	3
Connect the telephone base........................	3
Connect the charger....................................	4
Mount the telephone base...........................	4
Install and charge the battery......................	4
Before use...................................................	5
Set date and time.........................................	5
Check for dial tone.......................................	5
Configure your telephone.........................	6
Use the handset menu.................................	6
Set language................................................	6
Set date and time.........................................	6
Operating range...........................................	6
Home area code..........................................	7
Dial mode.....................................................	7
Temporary tone dialing................................	7
Telephone operations................................	8
Make a call...................................................	8
Predial a call................................................	8
Answer a call................................................	8
End a call:....................................................	8
Volume.........................................................	8
Mute.............................................................	8
Call waiting...................................................	9
Chain dialing................................................	9
Find handset..............................................	10
Redial list..................................................	10
Review a redial list entry............................	10
Dial a redial list entry..................................	10
Delete a redial list entry.............................	10

Directory...................................................	11
Add a directory entry...................................	11
Review a directory entry.............................	11
Alphabetical search...................................	12
Delete a directory entry..............................	12
Edit a directory entry..................................	12
Dial a directory entry..................................	12
Caller ID.....................................................	13
Review a caller ID log entry.......................	13
Memory match...........................................	13
Missed call indicator..................................	13
View dialing options...................................	14
Dial a caller ID log entry.............................	14
Save a caller ID log entry to the
directory.................................................	14
Delete the caller ID log entries...................	15
Sound settings.........................................	15
Key tone.....................................................	15
Ringer tone................................................	15
Ringer volume............................................	16
Temporary ringer silencing.........................	16
Retrieve voicemail from telephone
service..................................................	16
Retrieve voicemail.....................................	16
Turn off the new voicemail indicators........	16
Register a handset...................................	17
Other information.....................................	17
Website......................................................	17
Screen messages.....................................	18
General product care...............................	19
Frequently asked questions....................	19
The RBRC® seal........................................	22
FCC, ACTA and IC regulations...............	22
California Energy Commission
battery charging testing
instructions..........................................	25
For C-UL compliance only.......................	25
Limited warranty......................................	29
Technical specifications..........................	31

i

What’s in the box

Your telephone package contains the following items. Save your sales receipt and original packaging in the event warranty service is necessary.

NOTE

•To purchase a replacement battery or power adapter, visit our website at www.vtechphones.com or call

1 [phone]. In Canada, go to www.vtechcanada.com or call

1 [phone].

1 set for CS6114/CS6114-11/ CS6114-2

1 set for CS6114/CS6114-11;

2 sets for CS6114-2

1 set for CS6114-2

Abridged		Important
user’s		safety
manual		instructions

1 set for CS6114/CS6114-11/ CS6114-2

1

Overview

Handset overview

1 – Handset earpiece

2 – LCD display

3 – CID/VOL-

•Review the caller ID log when the telephone is not in use.

•Scroll down while in a menu, or in the directory, caller ID log or redial list.

•Move the cursor to the left when entering numbers or names.

•Decrease the listening volume during a call.

4 – /FLASH

•Make or answer a call.

•Answer an incoming call when you receive a call waiting alert.

5 – 1

•Press repeatedly to add or remove 1 in front of the caller ID log entry before dialing or saving it to the directory.

6 – TONE

•Switch to tone dialing temporarily during a call.

7 – MUTE/DELETE

• Mute the microphone during a call.

•Silence the handset ringer temporarily while the phone is ringing.

•Delete the displayed entry while reviewing the directory, caller ID log or redial list.

•Delete digits or characters when entering numbers or names.

8 – Microphone

9 – Charging pole

10 – MENU/SELECT

•Show the menu.

•While in a menu, press to select an item, or save an entry or setting.

11 – /VOL+

•Review the directory when the phone is not in use.

•Scroll up while in a menu, or in the directory, caller ID log or redial list.

•Move the cursor to the right when entering numbers or names.

•Increase the listening volume during a call.

12 – OFF/CANCEL

•Hang up a call.

•Return to the previous menu or idle mode without making changes.

•Delete digits while predialing.

•Silence the handset ringer temporarily while the phone is ringing.

•Erase the missed call indicator while the handset is not in use.

13 – 0/OPER

•Enter space character during text editing.

14 – #

•Show other dialing options when reviewing a caller ID log entry.

15 – REDIAL/PAUSE

•Review the redial list.

•Insert a dialing pause while dialing or entering numbers into the directory.

16 – Battery compartment cover

2

Telephone base overview

1 – /FIND HANDSET

• Page all system handsets.

2 – Charging pole

Charger overview

Connect

You can choose to connect the telephone base for desktop usage or wall mounting.

NOTES

•Use only the adapters provided.

•Make sure the electrical outlets are not controlled by wall switches.

•The adapters are intended to be correctly oriented in a vertical or floor mount position. The prongs are not designed to hold the plug in place if it is plugged into a ceiling, under-the-table or cabinet outlet.

TIP

•If you subscribe to digital subscriber line (DSL) high-speed Internet service through your telephone line, make sure you install a DSL filter (not included) between the telephone line cord and telephone wall jack. Contact your DSL service provider for more information.

Connect the telephone base

1 – Charging pole

Display icons overview

											The battery icon flashes
											when the battery is low and
											needs charging.
											The battery icon animates
											when the battery is charging.
											The battery icon becomes
											solid when the battery is fully
											charged.
											There are new voicemail
											received from your telephone
											service provider.
	NEW										There are new caller ID log
											entries.

3

Connect the charger

Mount the telephone base

THIS SIDE UP

Install and charge the battery

Install the battery

Install the battery as shown below.

NOTES

•Use only supplied battery.

•Charge the battery provided with this product only in accordance with the instructions and limitations specified in this manual.

•If the handset will not be used for a long time, disconnect and remove the battery to prevent possible leakage.

Charge the battery

Place the handset in the telephone base or the charger to charge.

Once you have installed the battery, the handset LCD display indicates the battery status (see the following table).

NOTES

•For best performance, keep the handset in the telephone base or charger when not in use.

•The battery is fully charged after 16 hours of continuous charging.

•If you place the handset in the telephone base or the charger without plugging in the battery, the screen displays No battery.

4

	Battery					Battery	Action
	indicators					status
	The screen					The battery	Charge
	is blank, or					has no or	without
	displays Put					very little	interruption
	in charger					charge. The	(at least 30
	and				flashes.	handset	minutes).
						cannot be
						used.
	The screen					The battery	Charge
	displays					has enough	without
	Low battery					charge to	interruption
	and				flashes.	be used for	(about 30
						a short time.	minutes).
	The screen					The battery	To keep
	displays					is charged.	the battery
	HANDSET X.						charged,
							place it in the
							telephone
							base or
							charger when
							not in use.

When the battery is fully charged, you can expect the following performance:

	Operation	Operating
		time
	While in use (talking*)	Seven hours
	While not in use (standby**)	Five days

*Operating times vary depending on your actual use and the age of the battery.

**Handset is not charging nor in use.

Before use

After you install your telephone or power returns following a power outage, the handset will prompt you to set the date and time.

Set date and time

1.Use the dialing keys (0-9) to enter the month (MM), date (DD) and year (YY). Then press SELECT.

2.Use the dialing keys (0-9) to enter the hour (HH) and minute (MM). Then press q or p to choose AM or

PM.

3.Press SELECT to save.

Check for dial tone

Press . If you hear a dial tone, the installation is successful.

If you do not hear a dial tone:

•Make sure the installation procedures described above are properly done.

•It may be a wiring problem. If you have changed your telephone service to digital service from a cable company or a VoIP service provider, the telephone line may need to be rewired to allow all existing telephone jacks to work. Contact your cable/VoIP service provider for more information.

5

Operating range

This cordless telephone operates with the maximum power allowed by the Federal Communications Commission (FCC). Even so, this handset and telephone base can communicate over only a certain distance - which can vary with the locations of the telephone base and handset, the weather, and the layout of your home or office.

When the handset is out of range, the handset displays Out of range or no pwr at base.

If there is a call while the handset is out of range, it may not ring, or if it does ring, the call may not connect well when you press . Move closer to the telephone base, then press to answer the call.

If the handset moves out of range during a telephone conversation, there may be interference. To improve reception, move closer to the telephone base.

Configure your telephone

Use the handset menu

1.Press MENU when the phone is not in use.

2.Press or until the screen displays the desired feature menu.

3.Press SELECT.

•To return to the previous menu, press

CANCEL.

•To return to idle mode, press and hold

CANCEL.

Set language

The LCD language is preset to English. You can select English, French or Spanish to be used in all screen displays.

1.Press MENU when the handset is not in use.

2.Press q or p to choose Settings and then press SELECT twice.

3.Press q or p to choose English,

Français or Español.

4.Press SELECT twice to save your setting. You hear a confirmation tone.

Set date and time

1.Press MENU on the handset when not in use.

2.Press q or p to choose Set date/time and then press SELECT.

3.Use the dialing keys (0-9) to enter the month (MM), date (DD) and year (YY). Then press SELECT.

4.Use the dialing keys (0-9) to enter the hour (HH) and minute (MM). Then press q or p to choose AM or

PM.

5.Press SELECT to save your setting. Your hear a confirmation tone.

6
