Index

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Warning symbols used . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Items supplied and transport inspection . . . . . . . . . . . . . . . . . . . . . .4

Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Interaction with batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Appliance description . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Handling and operation . . . . . . . . . . . . . . . . . . . . . . . . .7

Inserting the batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Wall mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Cleaning / Storage / Disposal . . . . . . . . . . . . . . . . . . .10

Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Notes on the Declaration of Conformity . . . . . . . . . . . . . . . . . . . .12

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Importer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

GB
CY

UPA 500 A1

1

Introduction

GB
CY

Congratulations on the purchase of your new appliance!
These operating instructions are a component of the Parking Lamp

UPA 500 A1(hereafter designated as the appliance) and they
provide you with important information about the intended use,
safety, operation and disposal of the appliance.

The operating instructions must be constantly kept available close to the
appliance. They are to be read and applied by everyone assigned to
operate, and eliminate faults in, the appliance. Retain these operating
instructions and pass them on, with the appliance, to any future owner.

Warning symbols used

In these extant operating instructions the following warnings are used:

DANGER

A warning at this risk level indicates a potentially
dang

erous situation.

If the dangerous situation is not avoided, it could lead to
death or serious physical injury.

Pay heed to the instructions in this warning to avoid the ►
death of or serious physical injury to people.

Introduction

2

UPA 500 A1

Introduction

WARNING

A warning at this risk level indicates a potentially
dangerous situation.

If the dangerous situation is not avoided it can lead to physical
injuries.

Pay heed to the instructions in this warning to avoid personal ►
injuries.

TAKE NOTE

A warning at this risk level signifi es
property damage.

If the situation is not avoided it could lead to property damage.

Pay heed to the instructions in this warning to avoid property ►
damage.

NOTICE

A notice signifi es additional information that can assist you in ►
the operation of the appliance.

potential

Intended use

This appliance is intended exclusively for the signaling of distances
between a vehicle and the garage wall and thus facilitates the proc­ess of parking. This appliance is intended only for domestic use, it is
not intended for commercial or industrial applications. This appliance
is intended only as an aid in parking, under no circumstances can
or does it replace the necessary prudence and caution of the driver
during the parking process. Accordingly, no liability can be assumed
for any damage resulting from improper assembly, use, maintenance
or malfunction. The operator alone bears the risk.

GB
CY

UPA 500 A1

3

Introduction/Safety

Items supplied and transport inspection

GB
CY

The appliance is delivered with the following components as standard:

1 x Parking Lamp UPA 500 A1 ▯
4 x Batteries 1.5 V Type AA/LR6/Mignon ▯
4 x Screws M3 x 24 mm ▯
4 x Wallplugs (S6) ▯
3 x Hook and Loop pads ▯
These operating instructions ▯

NOTICE

Check the contents to ensure everything is available and for ►
signs of visible damage.

If the deliv
packaging or through transportation contact the Service
Hotline (see chapter Service).

ery is not complete or is damaged due to defective ►

Safety

In this chapter you will receive important safety information regarding
the handling of the appliance.

This appliance complies with the statutory safety regulations. Incorrect
usage can lead to personal injury and property damage.

Safety instructions

If you are unsure about your current medical condition, obtain ■
advice from your doctor before using the appliance.

4

UPA 500 A1

Safety

WARNING - RISK OF INJURY

Before use check the appliance for visible external damage. ►
Do not put into operation an appliance that is damaged or
has been dr

Use the appliance only for the purposes as described (see ►
chapter Int

This appliance is not intended for use by individuals (including ►
children) with restricted physical, physiological or intellectual
abilities or defi ciences in experience and/or knowledge
unless they are supervised by a person responsible for their
safety or receive from this person instruction in how the appli­ance is to be used.

Children should be supervised to ensure that they do not ►
play with the appliance.

CAUTION - PROPERTY DAMAGE

Avoid any additional heat build up, e.g. direct sunlight, ►
heaters, etc..

Do not e
areas.

opped.

ended use).

xpose the appliance to moisture, use it only in dry ►

GB
CY

UPA 500 A1

5

Interaction with batteries

GB
CY

WARNING

Danger from improper use!

For safe handling of batteries pay heed to the following safety
instructions:

Do not throw batteries into a fi re. ►
Never short-circuit batteries. ►
Do not attempt to recharge batteries. ►
Regularly check the condition of the batteries. Leaking battery ►

acid can cause permanent damage to the appliance. Special
caution should be sho
batteries. Risks from acid burns! Wear protective gloves.

Store batteries in a place inaccessible to children. If a battery ►
is swallowed seek IMMEDIATE medical attention.

Do not use or mix depleted and new batteries together. ►
If you do not intend to use the appliance for an extended ►

period, remove the batteries.

Safety

wn when handling damaged or leaking

6

UPA 500 A1

Appliance Description/Operation ...

Appliance description

Parking Lamp

2

On/Off switch

3

Red LED

4

Yellow LED

5

Green LED

6

Battery compartment

7

Ultrasonic sensor

Handling and operation

Inserting the batteries

Slide the on/off switch ♦
Slide the battery compartment cover in the direction of the arrow ♦

and remove it from the appliance.
Inser

t 4 x 1.5 V batteries of the type AA/LR6/Mignon into the ♦
battery compartment
given in the battery compartment 6.

Replace the battery compartment cover and let it fi rmly engage. ♦

NOTICE

If, during use or in standby mode, the red LED ►
once every 10 seconds, the batteries are too weak and must
be replaced.

2

to the position "OFF".

6

. Pay heed the the polarity markings

3

fl ashes

GB
CY

UPA 500 A1

7

Wall mounting

GB
CY

DANGER

When drilling the holes ensure that any electric cables or ►
other installations in the wall, such as water pipes, are not
damaged.

TAKE NOTE

The supplied plugs are only suitable for a mounting on con- ►
crete or stone. Before starting the installation, please check
y
plugs. If in doubt, call a professional.

NOTICE

Alternatively, you can also use the supplied hook and loop ►
pads for mounting the Parking Lamp
sensor 7.

Handling and operation

our installation location carefully for its suitability for the

Attach the Parking Lamp ♦
the windshield of your vehicle. For this, mark two boreholes with
a vertical spacing of 130 mm.

Attach the ultrasonic sensor on the garage wall at the level of ♦
the bumper of your vehicle. For this, mark two boreholes with a
v

ertical spacing of 45 mm.

Now bore, using an electric or hand drill fi tted with a 6 mm ♦
drill, the four holes to a minimum depth of 30 mm.

Insert the plugs into the holes and screw the screws in. Leave ♦
the screw heads protruding a little.

Now hang the Parking Lamp ♦
on the screws.

on the garage wall at the level of

and the ultrasonic sensor 7

and the ultrasonic

8

UPA 500 A1

Handling and operation

Operation

The appliance has three operating modes:

Standby

The appliance switches automatically into standby mode (energy
saving mode) if no movement has occurred within the monitoring
area for about 30 seconds. In the case of movement occuring, the
appliance automatically detects the entrance or exit, and switches
itself on again.

Entrance

On entrance into the garage the appliance switches itself on with the
light sequence green - yellow - red.

Exit

Should a vehicle remove itself from close to the appliance, the yellow

4

switches on and then the green LED 5.

LED

Switch the appliance on by sliding the on/off switch ♦
position "ON". The LEDs fl ash briefl y (red, yellow, green).
The appliance is now operational and the green LED 5 glows
permanently.

Now test the functionality by moving slowly towards the ultra- ♦
sonic sensor
Parking Lamp .

7

and checking the individual light signals of the

2

to the

GB
CY

Light signal Distance from ultrasonic sensor
green approx. 5 - 1.5 m
yellow approx. 1.5 - 0.5 m
red approx. 0.5 - 0 m

UPA 500 A1

9

Cleaning / Storage / Disposal

GB

NOTICE

CY

Please take note that, in the switchover zones, it is possible ►
to have an alternating of the colours. This is not a defect, it
is an indication that the switcho
identifi ed, such as when the vehicle is not parallel to the
sensor.

ver zone cannot be clearly

Cleaning / Storage / Disposal

Cleaning

IMPORTANT

Possible damage to the appliance.

T

o avoid irreparable damage, when you are cleaning the ►

appliance ensure that no moisture can penetrate inside it.
Do not use abr

the surface.

Clean the appliance with a soft, dry cloth. For stubborn soiling ♦
you may also moisten the cloth slightly.

Storage

Should you intend to not use the appliance for an extended period,
remove the batteries and store it in a clean and dry place away from
direct sunlight.

asive cleaners or solvents. They could damage ►

10

UPA 500 A1

Cleaning / Storage / Disposal

Disposal

Disposal of the appliance

Do not dispose of this appliance in your

normal domestic waste. This appliance is
subject to the provisions of European
Directive 2002/96/EC-WEEE (Waste Electrical
and Electronic Equipment).

Dispose of the appliance through an approved

disposal centre or at your community waste facility.
Observe the currently applicable regulations. In case
of doubt, please contact your waste disposal centre.

Dispose of all packaging materials in an environmen-

tally friendly manner.

Disposing of the batteries

Batteries must not be disposed of in the household waste. Every
consumer is statutorily obliged to dispose of batteries at a collecting
point in their town/district or at a retail company. This obligation
is intended to ensure that batteries are disposed of in an environ­mentally safe manner. Only dispose of batteries when they are fully
discharged.

GB
CY

UPA 500 A1

11

Appendix

GB
CY

Technical data

Detectable range 15 cm - 500 cm

Power supply

Operating temperature range + 5 to + 40°C

Humidity 5 - 90% (no condensation)
Dimensions (W x H x D)

Parking Lamp
Ultrasonic sensor

Weight

4 x 1.5 V-Batteries

Type AA/LR6/Mignon

approx. 5.5 x 16.5 x 4.8 cm

approx. 5.6 x 8 x 3.4 cm

approx. 165 g

(without batteries)

Notes on the Declaration of Conformity

In regard to compliance with fundamental requirements
and other relevant provisions, this appliance complies
with the requirements of the European Electromagnetic
Compatibility Directive 2004/108/EC.

The complete original declaration of conformity can be
obtained from the importer.

Appendix

12

UPA 500 A1

Appendix

Warranty

You receive a 3-year warranty for this appliance as of the purchase
date. This appliance has been manufactured with care and meticu­lously examined before delivery.

Please retain your receipt as proof of purchase. In the case of a
warranty claim, please make contact by telephone with our service
department. Only in this way can a post-free despatch for your
goods be assured.

NOTICE

The warranty covers only claims for material and manufac- ►
turing defects, not for transport damages, wearing parts or
for damage to fr

This appliance is intended solely for domestic, not commercial, use.
In the event of misuse and improper handling, use of force and
interference not carried out by our authorised service branch, the
warranty will become void.

Your statutory rights are not restricted in any way by this warranty.
The warranty period is not extended by repairs eff ected under
warranty. This applies also to replaced and repaired parts.

Any damages or defi ciencies found on purchase must be reported
as soon as possible after unpacking, at the latest by two days after
purchase.

On expiry of the warranty, all repairs carried out are subject to
charges.

agile components, e.g. buttons or batteries.

GB
CY

UPA 500 A1

13

Service

GB
CY

Service Great Britain

Tel.: [phone] (£ 0.10/Min.)
E-Mail: [e-mail]

IAN 70429

Service Ireland

Tel.: [phone]
(0,08 EUR/Min., (peak))

(0,06 EUR/Min., (off peak))
E-Mail: [e-mail]

IAN 70429

CY

Service Cyprus

Tel.: [phone]
E-Mail: [e-mail]

IAN 70429

Importer

KOMPERNASS GMBH
BURGSTRASSE 21
44867 BOCHUM, GERMANY
www.kompernass.com

Appendix

14

UPA 500 A1

Sadržaj

Uvod . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Korištene upozoravajuće napomene . . . . . . . . . . . . . . . . . . . . . . .16

Uporaba u skladu sa namjenom . . . . . . . . . . . . . . . . . . . . . . . . . .17

Obim isporuke i transportna inspekcija . . . . . . . . . . . . . . . . . . . . .18

Sigurnost . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Sigurnosne upute . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Rukovanje sa baterijama . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Opis uređaja . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Posluživanje i rad . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Umetanje baterija . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Zidna montaža . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Pogon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Čišćenje/Skladištenje/Zbrinjavanje . . . . . . . . . . . . . .24

Čišćenje . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Čuvanje . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Zbrinjavanje . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Prilog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Tehnički podaci . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Napomene u vezi sa EU-izjavom o konformitetu . . . . . . . . . . . . . .26

Jamstvo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Servis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Uvoznik . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

HR

UPA 500 A1

15

Uvod

Čestitamo na kupnji Vašeg novog uređaja!
Ove upute za rukovanje predstavljaju sastavni dio parkirnog semafora

HR

UPA 500 A1 (u nastavku označenog kao uređaj) i daje Vam važne
napomene za namjensku uporabu, sigurnost, posluživanje i zbrinjavanje
uređaja.

Upute za rukovanje moraju stalno stajati u pripravnosti na raspola­ganju u blizini uređaja. Mora ih pročitati i primijeniti svaka osoba,
koja je zadužena za rukovanje uređaja i otklanjanje grešaka na
njemu. Ove upute za rukovanje sačuvajte i predajte ih zajedno sa
uređajem slijedećem vlasniku.

Korištene upozoravajuće napomene

U ovim uputama za rukovanje su korištene slijedeće upozoravajuće
napomene:

OPASNOST

Upozoravajuća napomena ovog stupnja opasnosti
označa

Ukoliko ne izbjegnete opasnu situaciju, to može dovesti do
smrti ili do teških ozljeda osoba.

va prijetnju nastanka opasne situacije.

Slijedite naputke navedene u ovoj upozoravajućoj napo- ►
meni, da biste izbjegli opasnost nastupanja smrti ili teških
ozljeda osoba.

Uvod

16

UPA 500 A1

Uvod

UPOZORENJE

Upozoravajuća napomena ovog stupnja opasnosti
označava moguću opasnu situaciju.

Ukoliko ne izbjegnete opasnu situaciju, to može dovesti do
ozljeda.

Slijedite naputke navedene u ovoj upozoravajućoj napomeni, ►
da biste izbjegli ozljede osoba.

PAŽNJA

Upozoravajuća napomena ovog stupnja opasnosti
označa

Ukoliko ne izbjegnete dotičnu situaciju, to može dovesti do
predmetne štete.

NAPOMENA

va moguću predmetnu štetu.

Slijedite naputke navedene u ovoj upozoravajućoj napomeni, ►
da biste izbjegli nastanak predmetne štete.

Napomena označava dodatne informacije za jednostavnije ►
rukovanje uređajem.

Uporaba u skladu sa namjenom

Uređaj služi isključivo za signaliziranje rastojanja između vozila i
garažnog zida i na taj način olakšava uparkiravanje. Ovaj uređaj
je namijenjen isključivo za uporabu u privatnim domaćinstvima, a
nije predviđen za obrtne ili industrijske namjene. Uređaj predstavlja
pomoć za uparkiravanje, koja niukom slučaju ne zamjenjuje potrebnu
pažnju i potreban oprez vozača za vrijeme ove radnje. Stoga
proizvođač za eventualne štete nastale uslijed nestručne montaže,
uporabe, nestručnog održavanja ili funkcionalnih smetnji ne preuzi­ma nikakvu odgovornost. Rizik nosi isključivo korisnik.

HR

UPA 500 A1

17

Uvod/Sigurnost

Obim isporuke i transportna inspekcija

Uređaj se standardno isporučuje sa slijedećim komponentama:

HR

1 x parkirni semafor UPA 500 A1 ▯
4 x baterije 1,5 V tipa AA/LR6/Mignon ▯
4 x vijci M3 x 24 mm ▯
4 x tiple (S6) ▯
3 x ljepljive trakice na čičak ▯
Ove upute za uporabu ▯

NAPOMENA

Prekontrolirajte cjelovitost obima isporuka i ustanovite, da li ►
postoje vidljiva oštećenja.

U slučaju nepotpune isporuk
pakiranja ili transportne štete obratite se dežurnoj servisnoj
telefonskoj liniji (vidi poglavlje Servis).

e ili štete uslijed oskudnog ►

Sigurnost

U ovom poglavlju možete pronaći važne sigurnosne napomene
u vezi rukovanja sa uređajem.

Ovaj uređaj odgovara propisanim sigurnosnim odredbama. Nestručna
uporaba može dovesti do oštećenja osoba i do predmetne štete.

Sigurnosne upute

Ukoliko postoje dvojbe u pogledu Vašeg zdravstvenog stanja, ■
prije uporabe uređaja potražite liječnički savjet.

18

UPA 500 A1

Sigurnost

UPOZORENJE - OPASNOST OD OZLJEĐIVANJA

Uređaj prije uporabe kontrolirajte i ustanovite, da li postoje ►
vidljiva vanjska oštećenja. Oštećen uređaj ili uređaj koji je
pao ne pustite u r

Uređaj koristite isključivo za ovdje navedenu namjensku svrhu ►
(vidi poglavlje Upor

Ovaj uređaj nije namijenjen da bude korišten od strane osoba ►
(uključujući djecu) sa ograničenim fi zičkim, senzoričnim i
mentalnim osobinama i nedostatkom iskustva ili znanja, osim
ako ove osobe stoje pod nadzorom druge osobe zadužene
za njihovu sigurnost, ili ako su od nje primili upute za ispravno
korištenje uređaja.

Djeca bi trebala biti pod nadzorom, čime treba biti osigurano ►
da se ne mogu igrati ovim uređajem.

PAŽNJA - PREDMETNA ŠTETA

Izbjegavajte dodatni dovod topline, na primjer uslijed nepo- ►
srednog izlaganja sunčevoj svjetlosti, grijaćih tijela itd..

eđaj ne izložite vlazi i koristite ga samo u suhim prostorijama. ►

Ur

ad.

aba u skladu sa namjenom).

HR

UPA 500 A1

19

Rukovanje sa baterijama

UPOZORENJE

HR

Opasnost uslijed nenamjenske uporabe!

Za sigurno rukovanje baterijama uvažite slijedeće sigurnosne
napomene:

Baterije ne bacajte u vatru. ►
Ne izazovite kratak spoj baterija. ►
Ne pokušajte baterije ponovo napuniti. ►
U redovnim vremenskim razmacima kontrolirajte baterije. ►

Iscurjele baterije mogu prouzrokovati trajna oštećenja uređaja.
Prilik

om rukovanja sa oštećenim ili iscurjelim baterijama budite
posebno pažljivi. Opasnost od nagrizanja kože! Nosite zaštitne
rukavice.

Baterije čuvajte na mjestu nedostupnom za djecu. Ako dođe ►
do gutanja, neizostavno zatražite liječničku pomoć.

Ne koristite istovremeno rabljene i nove baterije zajedno. ►
Izvadite baterije, ako uređaj duže vrijeme ne koristite. ►

Sigurnost

20

UPA 500 A1

Opis uređaja/Posluživanje i rad

Opis uređaja

Parkirni semafor

2

Prekidač Uklj/Isklj

3

Crveni LED

4

Žuti LED

5

Zeleni LED

6

Pretinac za baterije

7

Ultrazvučni senzor

Posluživanje i rad

Umetanje baterija

Gurnite prekidač Uklj/Isklj ♦
Gurnite poklopac pretinca za baterije u smjeru strelice i skinite ♦

ga sa uređaja.
Umenite 4 x 1,5 V-baterije tipa AA/LR6/Mignon u pr

za baterije
u pretincu za baterije 6.

Ponovo vratite poklopac pretinca za baterije na svoje mjesto ♦
i pustite ga da ulegne u predviđeno ležište.

6

. Pritom obratite pažnju na polaritet označen

2

u poziciju „OFF“.

HR

etinac ♦

NAPOMENA

Ako za vrijeme uporabe ili u standby-pogonu crvena ►

3

LED-lampica
baterije preslabe i moraju biti zamijenjene.

UPA 500 A1

svakih 10 sekundi trepti jednom, onda su

21

Zidna montaža

OPASNOST

HR

Obratite pažnju na to, da prilikom bušenja ne oštetite elek- ►
trične vodove ili druge instalacije, kao na primjer vodovodne
cije

PAŽNJA

Priložene tiple su prikladne samo za učvršćavanje u betonu ili ►
kamenu. Molimo da obavezno prije radova mjesto montaže
p
U slučaju dvojbe zatražite savjet stručnjaka.

Pričvrstite parkirni semafor ♦
Vašeg vozila. U tu svrhu označite dva mjesta za otvore sa
okomitim razmakom od 130 mm.

Pričvrstite ultrazvučni senzor na zidu garaže u visini branika ♦
Vašeg vozila. U tu svrhu označite dva mjesta za otvore sa
ok

Sada sa bušilicom i svrdlom pormjera 6 mm izbušite četiri ♦
otvora dubine najmanje 30 mm.

Umetnite tiple u otvore i okretanjem umetnite vijke. Glave vijaka ♦
trebaju malo viriti.

Zatim objesite parkirni semafor ♦

NAPOMENA

Alternativno možete koristiti priložene trakice na čičak ►
za pričvršćavanje parkirnog semafora
senzora 7.

Posluživanje i rad

vi u zidu.

rovjerite i ustanovite, da li je prikladno za ovu vrstu tipli.

na zidu garaže u visini vjetrobrana

omitim razmakom od 45 mm.

i ultrazvučni senzor 7 na vijke.

i ultrazvučnog

22

UPA 500 A1

Posluživanje i rad

Pogon

Uređaj raspolaže sa 3 načina rada:

Standby (pripravnost)
Uređaj automatski prelazi u standby-pogon (modus za štednju struje),

nakon što u nadzornom području ca. 30 sekundi nije došlo do kreta­nja. U slučaju kretanja uređaj automatski prepoznaje ulaz ili izlaz i
samostalno se uključuje.

Ulaz

Prilikom ulaza vozila u garažu uređaj se uključuje redosljedom
svjetala zeleno-žuto-crveno.

Izlaz

4

Kada se vozilo udaljava od uređaja, žuti LED
zatim zeleni LED 5.

Uključite uređaj tako, što ćete prekidač Uklj/Isklj ♦
poziciju „ON“. LED-lampice će nakratko zasvijetliti (crveno, žuto,
zeleno). Uređaj je sada spreman za pogon i zeleni LED 5 trajno
svijetli.

Sada provjerite funkcionalnost tako, što ćete se polako približa- ♦

7

vati ultrazvučnom senzoru
svjetlosne znakove parkirnog semafora .

Svjetlosni
znakovi

zeleno ca. 5 - 1,5 m
žuto ca. 1,5 - 0,5 m
crveno ca. 0,5 - 0 m

Rastojanje prema ultrazvučnom
senzoru

i pritom kontrolirati odgovarajuće

se uključuje, a

2

gurnuti u

HR

UPA 500 A1

23

Čišćenje/Skladištenje/Zbrinjavanje

NAPOMENA

Molimo vodite računa o tome, da u graničnim područjima ►

HR

eventualno nije moguće preskakanje boje. To nije defekt

eđaja, nego granično područje, koje ne može biti jasno

ur
razgraničeno, jer primjerice vozilo ne stoji paralelno u
odnosu na senzor.

Čišćenje/Skladištenje/Zbrinjavanje

Čišćenje

PAŽNJA

Moguće oštećenje uređaja.

Osigur

ajte, da prilikom čišćenja ne može doći do prodiranja ►
vlage u uređaj, kako biste izbjegli nastanak nepopravljivog
oštećenja ur

Ne koristite agresivna sredstva za čišćenje, odnosno otapala. ►
Takva sredstva mogu oštetiti površinu uređaja.

Očistite uređaj mekanom i suhom krpom. U slučaju tvrdokornih ♦
onečišćenja možete blago navlažiti krpu.

Čuvanje

Ukoliko duže vrijeme ne koristite uređaj, izvadite baterije i uređaj
čuvajte na čistom i suhom mjestu koje nije izloženo neposrednom
utjecaju sunčeve svjetlosti.

eđaja.

24

UPA 500 A1
