Installation Instructions
POINTBlock dc 8 Input/8 Relay Output Module
Catalog Numbers 1734D-IB8XOW8, 1734D-IB8XOW8S
Topic Page
Important User Information 2
Environment and Enclosure 3
Prevent Electrostatic Discharge 4
North American Hazardous Location Approval 5
About the Module 6
Install the Module 7
Set Node Address 8
Wire the Module 9
Specifications 15
Publication 1734-IN021C-EN-P - September 2006
2 POINTBlock dc 8 Input/8 Relay Output Module
Important User Information
Solid state equipment has operational characteristics differing from those of electromechanical
equipment. Safety Guidelines for the Application, Installation and Maintenance of Solid State Controls
(publication SGI-1.1 available from your local Rockwell Automation sales office or online at
http://literature.rockwellautomation.com
equipment and hard-wired electromechanical devices. Because of this difference, and also because of
the wide variety of uses for solid state equipment, all persons responsible for applying this equipment
must satisfy themselves that each intended application of this equipment is acceptable.
In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages
resulting from the use or application of this equipment.
The examples and diagrams in this manual are included solely for illustrative purposes. Because of the
many variables and requirements associated with any particular installation, Rockwell Automation, Inc.
cannot assume responsibility or liability for actual use based on the examples and diagrams.
No patent liability is assumed by Rockwell Automation, Inc. with respect to use of information, circuits,
equipment, or software described in this manual.
Reproduction of the contents of this manual, in whole or in part, without written permission of Rockwell
Automation, Inc., is prohibited.
Throughout this manual, when necessary, we use notes to make you aware of safety considerations.
WARNING
Identifies information about practices or circumstances that can cause an explosion in
a hazardous environment, which may lead to personal injury or death, property
damage, or economic loss.
) describes some important differences between solid state
IMPORTANT
ATTENTION
SHOCK HAZARD
BURN HAZARD
Publication
Identifies information that is critical for successful application and understanding of
the product.
Identifies information about practices or circumstances that can lead to personal
injury or death, property damage, or economic loss. Attentions help you to identify a
hazard, avoid a hazard and recognize the consequences.
Labels may be located on or inside the equipment, for example, a drive or motor, to
alert people that dangerous voltage may be present.
Labels may be located on or inside the equipment, for example, a drive or motor, to
alert people that surfaces may be dangerous temperatures.
1734-IN021C-EN-P - September 2006
Environment and Enclosure
POINTBlock dc 8 Input/8 Relay Output Module 3
ATTENTION
This equipment is intended for use in a Pollution Degree 2 industrial
environment, in overvoltage Category II applications (as defined in IEC
publication 60664-1), at altitudes up to 2000 m without derating.
This equipment is considered Group 1, Class A industrial equipment
according to IEC/CISPR Publication 11. Without appropriate
precautions, there may be potential difficulties ensuring
electromagnetic compatibility in other environments due to
conducted as well as radiated disturbance.
This equipment is supplied as open-type equipment. It must be
mounted within an enclosure that is suitably designed for those
specific environmental conditions that will be present and
appropriately designed to prevent personal injury resulting from
accessibility to live parts. The enclosure must have suitable
flame-retardant properties to prevent or minimize the spread of flame,
complying with a flame spread rating of 5VA, V2, V1, V0 (or
equivalent) if non-metallic. The interior of the enclosure must be
accessible only by the use of a tool. Subsequent sections of this
publication may contain additional information regarding specific
enclosure type ratings that are required to comply with certain
product safety certifications.
Besides this publication, see:
• Industrial Automation Wiring and Grounding Guidelines, for additional
installation requirements, Allen-Bradley publication 1770-4.1.
• NEMA Standards publication 250 and IEC publication 60529, as applicable,
for explanations of the degrees of protection provided by different types of
enclosure.
Publication
1734-IN021C-EN-P - September 2006
4 POINTBlock dc 8 Input/8 Relay Output Module
Prevent Electrostatic Discharge
ATTENTION
This equipment is sensitive to electrostatic discharge, which can
cause internal damage and affect normal operation. Follow these
guidelines when you handle this equipment.
• Touch a grounded object to discharge potential static.
• Wear an approved grounding wriststrap.
• Do not touch connectors or pins on component boards.
• Do not touch circuit components inside the equipment.
• Use a static-safe workstation, if available.
• Store the equipment in appropriate static-safe packaging when not in use.
Publication
1734-IN021C-EN-P - September 2006
POINTBlock dc 8 Input/8 Relay Output Module 5
North American Hazardous Location Approval
The following information applies when
operating this equipment in hazardous
locations
Products marked CL I, DIV 2, GP A, B, C, D are
suitable for use in Class I Division 2 Groups A, B,
C, D, Hazardous Locations and nonhazardous
locations only. Each product is supplied with
markings on the rating nameplate indicating the
hazardous location temperature code. When
combining products within a system, the most
adverse temperature code (lowest “T” number)
may be used to help determine the overall
temperature code of the system. Combinations of
equipment in your system are subject to
investigation by the local Authority Having
Jurisdiction at the time of installation.
EXPLOSION HAZARD -
WARNING AVERTISSEMENT
• Do not disconnect equipment unless
power has been removed or the area
is known to be nonhazardous.
• Do not disconnect connections to
this equipment unless power has
been removed or the area is known
to be nonhazardous. Secure any
external connections that mate to
this equipment by using screws,
sliding latches, threaded
connectors, or other means provided
with this product.
• Substitution of components may
impair suitability for Class I,
Division 2.
• If this product contains batteries,
they must only be changed in an
area known to be nonhazardous.
Informations sur l’utilisation de cet équipement
en environnements dangereux
Les produits marqués “CL I, DIV 2, GP A, B, C, D” ne
conviennent qu’à une utilisation en environnements
de Classe I Division 2 Groupes A, B, C, D dangereux et
non dangereux. Chaque produit est livré avec des
marquages sur sa plaque d’identification qui
indiquent le code de température pour les
environnements dangereux. Lorsque plusieurs
produits sont combinés dans un système, le code de
température le plus défavorable (code de température
le plus faible) peut être utilisé pour déterminer le
code de température global du système. Les
combinaisons d’équipements dans le système sont
sujettes à inspection par les autorités locales
qualifiées au moment de l’installation.
RISQUE D’EXPLOSION –
• Couper le courant ou s’assurer que
• Couper le courant ou s'assur er que
• La substitution de composants peut
• S’assurer que l’environnement e st
l’environnement est classé non
dangereux avant de débrancher
l'équipement.
l’environnement est classé non
dangereux avant de débrancher les
connecteurs. Fixer tous les connecteurs
externes reliés à cet équipement à
l'aide de vis, loquets coulissants,
connecteurs filetés ou autres moyens
fournis avec ce produit.
rendre cet équipement inadapté à une
utilisation en environnement de Classe
1, Division 2.
classé non dangereux avant de changer
les piles.
Publication
1734-IN021C-EN-P - September 2006
6 POINTBlock dc 8 Input/8 Relay Output Module
About the Module
This 1734D input/output module is a DIN-rail mounted device with
an integrated DeviceNet communication interface, 8 inputs, 8 relay
outputs, removable terminations, and a POINTBus expansion port.
Use the expansion port to add a maximum of 12 additional POINT
I/O modules.
The module includes a non-isolated DeviceNet communication
interface. The 24V dc from the DeviceNet connection powers a
non-isolated dc/dc converter that generates +5V dc that powers the
POINTBlock electronics and connects to the POINTBus port to power
the expansion I/O electronics.
The 1734D-IB8XOW8 module uses cage-clamp termination and the
1734D-IB8XOW8S module uses spring-clamp termination.
1734D-IB8XOW8, 1734D-IB8XOW8S Modules
DeviceNet
Connector
Node Address
Setting Switches
Publication
Module
Status
Network
Status
4
Inputs
0
1
2
9
-
0
3
-6
0
1
1734-IN021C-EN-P - September 2006
I/O Status
Indicators
4
Outputs
5
0
6
1
7
2
5
3
6
7
3
Removable
Terminal Blocks
44201
POINTBlock dc 8 Input/8 Relay Output Module 7
Install the Module
For information about how to install the module, read this and the
sections on how to set the node address and wire the module.
ATTENTION
ATTENTION
This product is grounded through the DIN rail to chassis ground.
Use zinc-plated, yellow-chromated steel DIN rail to assure proper
grounding. Using other DIN rail materials, for example, aluminum
and plastic, which can corrode, oxidize or are poor conductors, can
result in improper or intermittent platform grounding.
Secure DIN rail to mounting surface approximately every 200 mm
(7.8 in.) and use end-anchors appropriately.
Whatever field power you supply is connected to the internal
field-power bus. For example, if 120V ac is applied to the power
connections, 120V ac is applied to the modules through the
internal field-power bus.
POINT I/O modules to the right of the module also have that
internal power bus voltage applied, unless you use a 1734-FPD
module to interrupt and change the field power-bus voltage.
Publication
1734-IN021C-EN-P - September 2006
8 POINTBlock dc 8 Input/8 Relay Output Module
Set Node Address
Read this for information about how to set the node address.
To set the node address, set the combination of ones and tens
switches to correspond to the required address.
For example, for 61, set the tens switch to six and the ones switch to
one.
Node Address Switches and Status Indicators
Module
Status
Tens Node
Address Rotary
Switch
Ones Node
Address
Rotary
Switch
Publication
Inputs
0
1
10-60
0-9
2
3
1734-IN021C-EN-P - September 2006
Network
Status
Outputs
4
0
4
5
1
5
I/O
6
2
7
3
Status
6
7
POINTBlock dc 8 Input/8 Relay Output Module 9
Wire the Module
Refer to the figures that show how to wire the module.
WARNING
WARNING
ATTENTION
WARNING
When you connect or disconnect the Removable Terminal Block
(RTB) with field-side power applied, an electrical arc can occur.
This could cause an explosion in hazardous location installations.
Be sure that power is removed or the area is nonhazardous before
proceeding.
If you connect or disconnect the communications cable with power
applied to this module or any device on the network, an electrical
arc can occur. This could cause an explosion in hazardous location
installations.
To comply with the CE low voltage directive (LVD), this equipment
must be powered from a source compliant with the following: safety
extra-low voltage (SELV) or protected extra-low voltage (PELV).
If you connect or disconnect wiring while the field-side power is on,
an electrical arc can occur. This could cause an explosion in hazardous
location installations. Be sure that power is removed or the area is
nonhazardous before proceeding.
Publication
1734-IN021C-EN-P - September 2006
10 POINTBlock dc 8 Input/8 Relay Output Module
Connectors and POINTBus Expansion Ports
DeviceNet
Connector
Power Connections
12/24V dc
24
CH
SH
CL
RT
I/O Connections
24V
to 5V
Microprocessor
I/O Circuits
En
POINTBus Expansion
CH
CL
Port (allows
5V
GND
expansion of up to
12 POINT I/O
modules)
Field Bus
Connector
41971
Publication
1734-IN021C-EN-P - September 2006
Wire the Module
POINTBlock dc 8 Input/8 Relay Output Module 11
V dc
12/24V dc
Power
Input Wiring
Sink Input
2-wire
Prox
Field Power
01
NC
NC
23
NC
NC
45
C
C
67
V
V
RTB 0 RTB 1 RTB 2 RTB 3 RTB 4
This supply is to be connected to the internal power bus.
NC = No Connection Chas Gnd = Chassis Ground
C = CommonV = Supply
Inputs Outputs
0
1
3
C
V
01
4
5
23
6
7
45
C
C
67
V
V
1
01
0
23
2
45
C
67
V
01
0A
1A
23
OB
1B
45
2A
3A
67
2B
3B
In 0 In 1
C
In 3
3
5
7
3-wire
Prox
3-wire
2
In 2
Prox Prox
4
C
6
VV
01
4A
5A
23
4B
5B
45
6A
7A
67
6B
7B
42064
2-wire
V = 12/24V dc
C = Common
Wiring for RTB1 and RTB2
Publication
41966B
1734-IN021C-EN-P - September 2006
12 POINTBlock dc 8 Input/8 Relay Output Module
Channel, Input Terminal, Common, and Voltage for Terminal Blocks
Channel Input Terminal Common Voltage
Removable Terminal Block 0
0…3 No Connection No Connection
4, 5 Common
6, 7 Vin
Removable Terminal Block 1
Channel Input Terminal Common Voltage
00 4 6
11 5 7
22 4 6
33 5 7
Removable Terminal Block 2
Channel Input Terminal Common Voltage
40 4 6
51 5 7
62 4 6
73 5 7
Connect common on 3-wire proximity switches.
12/24V dc is supplied through the internal power bus.
IMPORTANT
Publication
When connecting more than one wire in a termination point,
make sure that both wires are the same gauge and type.
1734-IN021C-EN-P - September 2006
POINTBlock dc 8 Input/8 Relay Output Module 13
Relay Output Wiring (Load Powered by External Power)
Field Power
Inputs Outputs
NC
NC
C
V
01
0
1
23
2
3
45
C
C
67
V
V
V dc
12/24V dc
Power
01
NC
23
NC
45
C
67
V
RTB 0 RTB 1 RTB 2 RTB 3 RTB 4
This supply will be connected to the internal power bus.
NC = No Connection Chas Gnd = Chassis Ground
C = Common V = Supply
Relay Output Wiring
Power
Supply
Load
Out = Output channel relay contacts
Power Supply = can range from +5V dc…240V ac
C = Common
0
Out 0A
2
Out 0B
4
Out 2A
6
Out 2B
Out 1A
Out 1B
Out 3A
Out 3B
5
7
C
V
01
0A
1A
23
OB
1B
45
2A
3A
67
2B
3B
Power
01
4
23
6
45
C
67
V
1
Supply
3
5
Load
7
Wiring for RTB3 is shown.
RTB4 is identical except outputs are
numbered Out 4…7.
01
4A
5A
23
4B
5B
45
6A
7A
67
6B
7B
42064
Publication
1734-IN021C-EN-P - September 2006
14 POINTBlock dc 8 Input/8 Relay Output Module
Terminal, Output, Common, and Supply for Terminal Blocks
Terminal Common Voltage
Removable Terminal Block 0
0…3 No connection No Connection
4, 5 Common
6, 7 Vin
Removable Terminal Block 4
Channel Output Common Supply
0A 0
0B 2
1A 1
1B 3
2A 4
2B 6
3A 5
3B 7
Removable Terminal Block 4
Channel Output Common Supply
4A 0
4B 2
5A 1
5B 3
6A 4
6B 6
7A 5
7B 7
Supply voltage can range from +5V dc…240V ac, depending on relay load.
12/24V dc power for the module is provided by the internal power bus.
Publication
1734-IN021C-EN-P - September 2006
DeviceNet Connector Wiring
POINTBlock dc 8 Input/8 Relay Output Module 15
+V
CAN - High
Shield
CAN - Low
-V
42132
DeviceNet
Connection
IMPORTANT
Red
White
Bare
Blue
Black
When connecting more than one wire in a termination point,
make sure that both wires are the same gauge and type.
Specifications
POINTBlock dc 8 Input/8 Relay Output Module - 1734D-IB8XOW8,
1734D-IB8XOW8S
Attribute Value
POINTBus Output Current 1 A max @ 5V dc output
(1)
DeviceNet Current
Number of POINT I/O
Expansion Modules
Isolation Voltage 120V (continuous), Reinforced Insulation Type
Indicators 1 red/green module status indicator
Power Dissipation 2.0 W max @ 24V dc
Power Consumption 8.2 W max @ 24V dc
95 mA max for POINTBlock
12 max at expansion port
1250V rms or 2121V dc for 1 s between ac circuits and
DeviceNet network
1 red/green network status indicator
16 I/O status indicators (8 input/8 relay output)
Publication
1734-IN021C-EN-P - September 2006
16 POINTBlock dc 8 Input/8 Relay Output Module
POINTBlock dc 8 Input/8 Relay Output Module - 1734D-IB8XOW8,
1734D-IB8XOW8S
Attribute Value
Field Power Bus
Supply Voltage, Nom
Voltage Range
Supply Current, Max
Communication Rate 125 Kbps (500 m max)
Dimensions (HxWxD),
Approx.
Conductors Wire Size
Category
Terminal Base Screw
Torque
North American Temp
Code
Field Wiring Terminations
DeviceNet
Field Power Supply 0 - No Connection 1 - No Connection
Weight, Approx. 0.40 kg (0.86 lb)
(1)
350 mA for max with expansion of 12 POINT I/O modules
(2)
Use this conductor category information for planning conductor routing. Refer to Industrial
Automation Wiring and Grounding Guidelines, publication 1770-IN041.
24V dc
10…28.8V dc
10 A
250 Kbps (250 m max)
500 Kbps (100 m max)
76.2 x 60.0 x 33.4 mm (3.00 x 2.36 x 5.25 in.)
0.25…2.5 mm
2
(22…14 AWG), solid or stranded copper
rated @ 75 °C (167 °F) or higher
1.2 mm (3/64 in.) insulation max
2 - on all ports
(2)
0.5…0.6 Nm (5…7 lb-in)
T5
1 - Black Wire-V
2 - Blue WireCAN Low
3 - Bare WireDrain
4 - White WireCAN High
5 - Red Wire+V
2 - No Connection 3 - No Connection
4 - Common 5 - Common
6 - Supply 7 - Supply
Publication
1734-IN021C-EN-P - September 2006
POINTBlock dc 8 Input/8 Relay Output Module 17
Environmental Specifications
Attribute Value
Operational Temperature IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
-20…55 °C (-4…131 °F)
Storage Temperature IEC 60068-2-1 (Test Ab, Unpackaged Non-operating Cold)
IEC 60068-2-2 (Test Bb, Unpackaged Non-operating Dry Heat)
IEC 60068-2-14 (Test Na, Unpackaged Non-operating Thermal
Shock) -40…85 °C (-40…185 °F)
Relative Humidity IEC 60068-2-30 (Test Db, Unpackaged Damp Heat):
Shock Operating
Nonoperating
Vibration IEC 60068-2-6 (Test Fc, Operating): 5 g @ 10…500 Hz
Conducted RF Immunity IEC 61000-4-6: 10V rms with 1 kHz sine-wave 80% AM from
EFT/B Immunity IEC 61000-4-4: ±2 kV at 5 kHz on power ports
ESD Immunity IEC 61000-4-2: 4 kV contact discharges
Enclosure Type Rating None (open-style)
Emissions CISPR 11:
Radiated RF Immunity IEC 61000-4-3: 10V/m with 1 kHz sine-wave 80%AM from
Surge Transient
Immunity
5…95% noncondensing
IEC 60068-2-27 (Test Ea, Unpackaged Shock): 30 g
IEC 60068-2-27 (Test Ea, Unpackaged Shock): 50 g
150 kHz…80 MHz
±2 kV at 5 kHz on signal ports
±1 kV at 5 kHz on communication ports
8 kV air discharges
Group 1, Class A
30…2000 MHz
10V/m with 200 Hz 50% Pulse 100%AM at 900 MHz
1 V/m with 1 kHz sine-wave 80%AM from 2000…2700 MHz
IEC 61000-4-5:
±2 kV line-earth(CM) on power ports
±1 kV line-line(DM) and ±2 kV line-earth(CM) on signal ports
±2 kV line-earth(CM) on communication ports
Publication
1734-IN021C-EN-P - September 2006
18 POINTBlock dc 8 Input/8 Relay Output Module
Input Specifications - IEC 3 24V dc Input Compliant
Attribute Value
On-state Voltage Range,
Min
On-state Voltage Range,
Nom
On-state Voltage Range,
Max
On-state Current, Min 2.5 mA
On-state Current, Nom 6.3 mA @ 24V dc
On-state Current, Max 7.6 mA
Off-state Voltage, Max 5V dc
Off-state Current, Max 1.5 mA
Input Impedance, Max 5.3 KΩ
Input Delay Time
OFF to ON
ON to OFF
(1)
IEC denotes the International Electrotechnical Commission.
10V dc
24V dc
28.8V dc
0.5 ms hardware + (0…65 ms selectable)
0.5 ms hardware + (0…65 ms selectable)
(1)
Publication
1734-IN021C-EN-P - September 2006
POINTBlock dc 8 Input/8 Relay Output Module 19
Output Specifications
Attribute Value
Relay Type Form A, normally open, Single Pole, Single Throw
Output Voltage Range,
Resistive
Relay Output Current
Rating, Inductive
Relay Output Current
Rating, Resistive
Power Rating, Max,
For Resistive Loads
Power Rating, Max,
For Inductive Loads
Load 10 mA per point min
Initial Contact Resistance 30 mΩ
Switching Frequency 1 operation/3 s at rated load
Bounce Time 1.2 ms mean
5…28.8V dc @ 2.0 A
48V dc @ 0.5 A
125V dc @ 0.25 A
125V ac @ 2.0 A
240V ac @ 2.0 A
2.0 A steady state @ 5…28.8V dc, L/R - 7 ms
0.5 A steady state @ 48V dc, L/R = 7 ms
0.25 A steady state @ 125V dc, L/R = 7 ms
2.0 A steady state, 15 A make @ 125V ac, PF = cos θ = 0.4
2.0 A steady state, 15 A make @ 240V ac, PF = cos θ = 0.4
2 A @ 5…30V dc
0.5 A @ 48V dc
0.25 A @ 125V dc
2 A @ 125V ac
2 A @ 240V ac
250 W for 125V ac
480 W for 240V ac
60 W for 28.8V dc
24 W for 48V dc
31 W for 125V dc
250 VA for 125V ac
480 VA for 240V ac
60 VA for 28.8V dc
24 VA for 48V dc
31 VA for 125V dc
Publication
1734-IN021C-EN-P - September 2006
Output Specifications
Attribute Value
Expected Contact Life 300 Kcycles resistive; 100 Kcycles inductive
Off-state Leakage, Max 1.5 mA
Output Delay Time 10 ms max ON/OFF
Certifications
Attribute Value
Certifications
(when product is marked)
(1)
See the Product Certification link at http://www.ab.com for Declarations of Conformit y, Certificates, and other
certification details.
C-UL-US UL Listed Industrial Control Equipment, certified
for US and Canada. See UL File E65584.
(1)
UL Listed for Class I, Division 2 Group A,B,C,D
Hazardous Locations, certified for U.S. and Canada.
See UL File E194810.
CE European Union 89/336/EEC EMC Directive,
compliant with:
EN 50082-2; Industrial Immunity
EN 61326; Meas./Control/Lab., Industrial Requirements
EN 61000-6-2; Industrial Immunity
EN 61000-6-4; Industrial Emissions
EN 61131-2; Programmable Controllers
(Clause 8, Zone A & B)
European Union 73/23/EEC LVD, compliant with
EN 61131-2; Programmable Controllers
Australian Radiocommunications Act, compliant
C-Tick
with: AS/NZS CISPR 11; Industrial Emissions
DeviceNet
ODVA conformance tested to DeviceNet specifications
Allen-Bradley and POINTBlock are trademarks of Rockwell Automation, Inc. Trademarks not belonging
to Rockwell Automation are property of their respective companies.
Publication 1734-IN021C-EN-P - September 2006 PN 953030-11
Supersedes Publication 1734-IN021B-EN-P - July 2001 Copy right © 2006 Rockwell Automation, Inc. All rights reserved. Printed in the U.S.A.
Loading...
