Pilz PNOZ X7P Data Sheet

E-STOP relays, safety gate monitors

Up to Category 2, EN 954-1

PNOZ X7P

Safety relay for monitoring E-STOP
pushbuttons and safety gates.

Approvals

PNOZ X7P





Unit features

` Positive-guided relay outputs:

– 2 safety contacts (N/O), instanta-

neous

` Connection options for:

– E-STOP pushbutton
– Reset button

` LED indicator for:

– Switch status channel 1/2
– Supply voltage

` Plug-in connection terminals (either

cage clamp terminal or screw termi­nal)

Unit description

The safety relay meets the require­ments of EN 60204-1 and IEC 60204­1 and may be used in applications with

` E-STOP pushbuttons
` Safety gates

The safety relay is not suitable for non­contact barriers because

` a dynamic start is not possible
` the unit can be started during the

delay-on de-energisation time.

Safety features

` The circuit is redundant with built-in

self-monitoring.

` The safety function remains effecti-

ve in the case of a component failu­re.

` The correct opening and closing of

the safety function relays is tested
automatically in each on-off cycle.

Block diagram



The relay conforms to the following
safety criteria:

A1 A2 Y1 Y2

~

Input

Reset/

Start

=

Power

13 23

K1

K2

14 24

Pilz GmbH & Co. KG, Sichere Automation, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

NSG-D-2-340-11/04

E-STOP relays, safety gate monitors

Up to Category 2, EN 954-1

PNOZ X7P

Function description

` Single-channel operation: no red-

undancy in the input circuit, earth
faults in the reset and input circuit
are detected.

Timing diagram

Reset/Start

Power/Input

Output safe

Key

` Power: Supply voltage
` Reset/start: Reset circuit Y1-Y2
` Input: Input circuits A1
` Output safe: Safety contacts 13-14,

23-24

Wiring

` Automatic start: Unit is active once

the input circuit has been closed.

` Manual reset: Unit is active once

the input circuit is closed and then
the reset circuit is closed.

1 2

t1 t2 t1 t2 t2t1t1 t2

` c: Automatic reset
` d: Manual reset
` a: Input circuit closes before reset

circuit

` Increase in the number of available

contacts by connecting contact ex­pander modules or external contac­tors/relays.

ab

` b: Reset circuit closes before input

circuit

: Switch-on delay

` t

1

` t2: Delay-on de-energisation

Please note:

` Information given in the “Technical

details” must be followed.

` Outputs 13-14, 23-24 are safety

contacts.

` To prevent contact welding, a fuse

should be connected before the
output contacts (see technical de­tails).

` Calculation of the max. cable runs

in the input circuit:

l

max

` Use copper wire that can withstand

` Sufficient fuse protection must be

R

lmax

=

I

max

Rl / km

= max. overall cable resi-

R

lmax

stance (see technical details)

/km = cable resistance/km

R

l

60/75 °C.

provided on all output contacts with
capacitive and inductive loads.

Cable capacitance CL depends on the supply voltage U

B

PNOZ X7 AC: The cable runs depend
on the cable capacitance.

` Loop circuit, 1 phase: max. l
` Stub circuit: Cable capacitance C

and therefore the cable runs ls are
dependent on the supply voltage
U

B

UB [V] 24 110 120 230 240
C

[nF] 37.5 37.5 37.5 7.5 7.5

L

Cable runs Loop circuit Stub circuit

l

r

U

B

N

PNOZ X7 AC

A1
A2

l

U

B

N

s

PNOZ X7 AC

A1
A2

= 1 km

r

L

Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

NSG-D-2-340-11/04Pilz GmbH & Co. KG, Sichere Automation, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany

-2

E-STOP relays, safety gate monitors

Up to Category 2, EN 954-1

PNOZ X7P

Preparing for operation

` Supply voltage

Supply voltage AC DC

A1

A2

L1

N

` Input circuit

Input circuit Single-channel Dual-channel
E-STOP

without detection of shorts across

A1

S1

L+/L1

contacts

Safety gate
without detection of shorts across
contacts

S1

L+/L1A1

` Reset circuit

A1

A2

L+

L-

Reset circuit E-STOP wiring (single-channel) E-STOP wiring (dual-channel)
Automatic reset

Manual reset

Y1

Y2

S3

Y1

Y2

` Feedback loop

Feedback loop Automatic reset Monitored reset
Contacts from external contactors

Y1
Y2

13 (23)
14 (24)

K5

K6

K5

K6

L1
N

Y1
Y2

13
14

K5

K6

K5

K6

S3

L1
N

Pilz GmbH & Co. KG, Sichere Automation, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

NSG-D-2-340-11/04

E-STOP relays, safety gate monitors

Up to Category 2, EN 954-1

PNOZ X7P

` Key Terminal configuration

S1 E-STOP pushbutton
S3 Reset button

Switch operated

Gate open

Gate closed

Installation

` The safety relay should be installed

in a control cabinet with a protec­tion type of at least IP54.

` Use the notch on the rear of the unit

to attach it to a DIN rail.

` Ensure the unit is mounted securely

on a vertical DIN rail (35 mm) by
using a fixing element (e.g. retaining
bracket or an end angle).

Dimensions

* with cage clamp terminals

94 (3.70")

* 101 (3.98")

121 (4.76")

22,5

(0.88")

Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

NSG-D-2-340-11/04Pilz GmbH & Co. KG, Sichere Automation, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany

-4

E-STOP relays, safety gate monitors

Up to Category 2, EN 954-1

PNOZ X7P

Notice

Service life graph

This data sheet is only intended for use
during configuration. For installation
and operation, please refer to the ope­rating instructions supplied with the

10

AC15: 230 V

unit.

DC13: 24 V

1

D Nennbetriebstrom (A)

GB Nominal operating current (A)

F Courant coupé (A)

Technical details

Electrical data

Supply voltage UB AC
Supply voltage U

AC/DC

B

Voltage tolerance -15 % / 10 %
Power consumption at U

Power consumption at U

AC

B

DC

B

Frequency range AC 50 - 60 Hz
Residual ripple DC 160 %
Voltage and current at
input circuit:

110.0 - 120.0 V Order no.: 777053, 787053

230.0 - 240.0 V Order no.: 777056, 787056

24.0 V Order no.: 777059, 787059

reset circuit: 24 VDC

feedback loop: 24 VDC

Output contacts in accordance with EN 954-1, Category 2 Safety contacts (N/O): 2
Utilisation category in accordance with EN 60947-4-1
AC1: 240 V

DC1: 24 V

Utilisation category in accordance with EN 60947-5-1
AC15: 230 V

DC13 (6 cycles/min): 24 V

Contact material AgSnO

0.1

E Corriente nominal de servicio (A)

I Corrente di esercizio nominale (A)

NL Nominale bedrijfsstroom (A)

10 100 1000 10000

D Schaltspielzahl x 10
GB Cycles x 10
F Nombre de manvres x 10

110 - 120 V, 230 - 240 V
24 V

2.0 VA Order no.: 777053, 777056, 787053, 787056

3.0 VA Order no.: 777059, 787059

1.5 W Order no.: 777059, 787059

17 mA Order no.: 777053, 787053
8 mA Order no.: 777056, 787056
50 mA Order no.: 777059, 787059

210.0 mA Order no.: 777059, 787059

40.0 mA Order no.: 777053, 777056, 787053, 787056

210.0 mA Order no.: 777059, 787059

40.0 mA Order no.: 777053, 777056, 787053, 787056

I

: 0.01 A,

min

I

: 4.00 A Order no.: 777053, 777056, 787053, 787056

max

6.00 A Order no.: 777059, 787059
P

: 1,000 VA Order no.: 777053, 777056, 787053, 787056

max

1,500 VA Order no.: 777059, 787059
I

: 0.01 A,

min

I

: 4.0 A Order no.: 777053, 777056, 787053, 787056

max

6.0 A Order no.: 777059, 787059
P

: 100 W Order no.: 777053, 777056, 787053, 787056

max

150 W Order no.: 777059, 787059

: 4.0 A Order no.: 777053, 777056, 787053, 787056

I

max

5.0 A Order no.: 777059, 787059
I

: 4.0 A Order no.: 777053, 777056, 787053, 787056

max

6.0 A Order no.: 777059, 787059

3

3

+ 0.2 µm Au

2

DC1: 24 V

AC1: 230 V

E Número de ciclos x 10
I Numero dei cicli di commutazione x 10

3

NL Aantal schakelingen x 10

3

3

3

Pilz GmbH & Co. KG, Sichere Automation, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

NSG-D-2-340-11/04

E-STOP relays, safety gate monitors

Up to Category 2, EN 954-1

PNOZ X7P

Electrical data

External contact fuse protection (EN 60947-5-1)
Blow-out fuse, quick

Blow-out fuse, slow
Circuit breaker
Max. overall cable resistance R
reset circuits
Single-channel at U
Single-channel at U

Times

Switch-on delay
with automatic reset typ.

with automatic reset max.

with automatic reset after power on typ.

with automatic reset after power on max.

with manual reset typ.

with manual reset max.

Delay-on de-energisation
with E-STOP typ.

with E-STOP max.

with power failure typ.

with power failure max.

Recovery time at max. switching frequency 1/s
after E-STOP

after power failure

Supply interruption before de-energisation 20 ms

Environmental data

EMC EN 60947-5-1, EN 61000-6-2
Vibration in accordance with EN 60068-2-6
Frequency

Amplitude
Climatic suitability EN 60068-2-78
Airgap creepage EN 60947-1
Ambient temperature -10 - 55 °C
Storage temperature -40 – 85 °C
Protection type

Mounting (e.g. cabinet)
Housing
Terminals

Mechanical data

Housing material
Housing
Front

Max. cross section of external conductors with screw terminals
1 core flexible
2 core, same cross section, flexible:
with crimp connectors, without insulating sleeve
without crimp connectors or with TWIN crimp connectors
Torque setting with screw terminals 0.50 Nm

B
B

DC
AC

input circuits,

lmax

4 A Order no.: 777053, 777056, 787053, 787056
6 A Order no.: 777059, 787059
4 A
4 A, 24 VAC/DC, characteristic B/C

15 Ohm Order no.: 777059, 787059
15 Ohm Order no.: 777059, 787059

230 ms Order no.: 777053, 777056, 787053, 787056
50 ms Order no.: 777059, 787059
700 ms Order no.: 777053, 777056, 787053, 787056
150 ms Order no.: 777059, 787059
230 ms Order no.: 777053, 777056, 787053, 787056
50 ms Order no.: 777059, 787059
700 ms Order no.: 777053, 777056, 787053, 787056
150 ms Order no.: 777059, 787059
140 ms Order no.: 777053, 777056, 787053, 787056
35 ms Order no.: 777059, 787059
700 ms Order no.: 777053, 777056, 787053, 787056
150 ms Order no.: 777059, 787059

70 ms Order no.: 777053, 777056, 787053, 787056
45 ms Order no.: 777059, 787059
100 ms Order no.: 777053, 777056, 787053, 787056
70 ms Order no.: 777059, 787059
70 ms Order no.: 777053, 777056, 787053, 787056
45 ms Order no.: 777059, 787059
100 ms Order no.: 777053, 777056, 787053, 787056
70 ms Order no.: 777059, 787059

120 ms Order no.: 777053, 777056, 787053, 787056
50 ms Order no.: 777059, 787059
120 ms Order no.: 777053, 777056, 787053, 787056
150 ms Order no.: 777059, 787059

10 - 55 Hz

0.35 mm

IP54
IP40
IP20

PPO UL 94 V0
ABS UL 94 V0

0.25 - 2.50 mm

0.25 - 1.00 mm

0.20 - 1.50 mm

2

2
2

Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

NSG-D-2-340-11/04Pilz GmbH & Co. KG, Sichere Automation, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany

-6

E-STOP relays, safety gate monitors

Up to Category 2, EN 954-1

PNOZ X7P

Mechanical data

Max. cross section of external conductors with cage clamp termi­nals: Flexible without crimp connectors 0.20 - 1.50 mm
Cage clamp terminals
Terminal points per connection
Stripping length

Dimensions (H x W x D)
with screw terminals
with cage clamp terminals

Weight 190 g

The standards current on 09/04 apply.

Max. continuous current

2
8 mm

94.0 mm x 22.5 mm x 121.0 mm

101.0 mm x 22.5 mm x 121.0 mm

2

Number of contacts I
1 4 A Order no.: 777059, 787059 4 A Order no.: 777053, 777056, 787053, 787056
2 4 A Order no.: 777059, 787059 3 A Order no.: 777053, 777056, 787053, 787056

Order reference

Type Features Terminals Order no.

PNOZ X7P C 24 VAC/DC Cage clamp terminals 787 059
PNOZ X7P 24 VAC/DC Screw terminals 777 059
PNOZ X7P C 110 - 120 VAC Cage clamp terminals 787 053
PNOZ X7P 110 - 120 VAC Screw terminals 777 053
PNOZ X7P C 230 - 240 VAC Cage clamp terminals 787 056
PNOZ X7P 230 - 240 VAC Screw terminals 777 056

(A) at UBAC/DC I

max

(A) at UBAC

max

Pilz GmbH & Co. KG, Sichere Automation, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

NSG-D-2-340-11/04
