Pilz PNOZ x1 Data Sheet

E-STOP relays

up to Category 2, EN 954-1

PNOZ X1

Safety relay for monitoring E-STOP
pushbuttons.

Approvals

PNOZ X1







Unit features

` Positive-guided relay outputs:

– 3 safety contacts (N/O), instanta-

neous

– 1 auxiliary contact (N/C), instan-

taneous

` Safe separation of safety contacts

13-14, 23-24, 33-34 from input cir­cuits A1-A2, feedback loop Y1-Y2
and auxiliary contact 41-42.

` Connection options for:

– E-STOP pushbutton
– Reset button

` LED indicator for:

– Switch status channel 1/2
– Supply voltage

Unit description

The safety relay meets the require­ments of EN 60204-1 and IEC 60204­1 and may be used in applications with

` E-STOP pushbuttons

The safety relay is not suitable for non­contact barriers because

` a dynamic start is not possible
` the unit can be started during the

delay-on de-energisation time.

Safety features

The relay meets the following safety
requirements:

` The circuit is redundant with built-in

self-monitoring.

` The safety function remains effec-

tive in the case of a component fail­ure.

` The correct opening and closing of

the safety function relays is tested
automatically in each on-off cycle.

Block diagram

* Safe separation in accordance with EN 60947-1, 6 kV (see unit features)

A1 A2

A1 A2

~

~

Power

Power

=

=

Input

Input

Y1 Y2

Y1 Y2

Reset/

Reset/

Start

Start

K1

K1

K2

K2

*

*

13 23 33 41

13 23 33 41

14 24 34 42

14 24 34 42

Pilz GmbH & Co. KG, Sichere Automation, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

NSG-D-2-069-2006-09

E-STOP relays

up to Category 2, EN 954-1

PNOZ X1

Function description

` Single-channel operation: no re-

dundancy in the input circuit, earth
faults in the reset circuit are detect­ed.

Timing diagram

POWER

Reset/Start

Input

Output safe

Output aux.

Key

` Power: Supply voltage
` Reset/start: Reset circuit Y1-Y2
` Input: Input circuits A1-L+
` Output safe: Safety contacts 13-14,

23-24, 33-34

` Automatic start: Unit is active once

the input circuit has been closed.

` Manual reset: Unit is active once

the input circuit is closed and then
the reset circuit is closed.

1 2

t1 t2

t1 t2

` Output aux: Auxiliary contacts 41-

42

` c: Automatic reset
` d: Manual reset
` a: Input circuit closes before reset

circuit

` Increase in the number of available

contacts by connecting contact ex­pander modules or external contac­tors/relays.

ab

t1

t1

t2

t2

` b: Reset circuit closes before input

circuit

: Switch-on delay

` t

1

: Delay-on de-energisation

` t

2

Wiring

Please note:

` Information given in the “Technical

details” must be followed.

` Outputs 13-14, 23-24, 33-34 are

safety contacts, output 41-42 is an
auxiliary contact (e.g. for display).

` To prevent contact welding, a fuse

should be connected before the
output contacts (see technical de­tails).

` Calculation of the max. cable runs

in the input circuit:

l

max

R

lmax

=

I

max

Rl / km

R

= max. overall cable resist-

lmax

ance (see technical details)

/km = cable resistance/km

R

l

` Use copper wire that can withstand

60/75 °C.

` Sufficient fuse protection must be

provided on all output contacts with
capacitive and inductive loads.

Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

NSG-D-2-069-2006-09Pilz GmbH & Co. KG, Sichere Automation, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany

-2

E-STOP relays

up to Category 2, EN 954-1

PNOZ X1

Preparing for operation

` Supply voltage

Supply voltage AC DC

A1

S1

L1

A1

S1

L+

A2

N

A2

` Input circuit

Input circuit Single-channel Dual-channel
E-STOP

without detection of shorts across con-

A1

S1

L+

tacts

` Reset circuit

Reset circuit E-STOP wiring (single-channel) E-STOP wiring (dual-channel)
Automatic reset

Manual reset

Y1

Y2

S3

Y1

L-

Y2

` Feedback loop

Feedback loop Automatic reset Manual reset
Contacts from external contactors

13 (23, 33)
14 (24, 34)

Y1
Y2

K5

K6

K5

K6

L1
N

` Key

S1 E-STOP pushbutton
S3 Reset button

Pilz GmbH & Co. KG, Sichere Automation, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

Y1

Y2
13 (23, 33)
14 (24 ,34)

NSG-D-2-069-2006-09

K5

K6

K5

K6

S3

L1
N

E-STOP relays

up to Category 2, EN 954-1

PNOZ X1

Terminal configuration

A113Y1

13

19068

144124

23

PNOZ X1

POWER
CH.1
CH.2

23

33

42

33

Y2

41

42342414

A2

34

Installation

` The safety relay should be installed

in a control cabinet with a protec­tion type of at least IP54.

` Use the notch on the rear of the unit

to attach it to a DIN rail.

` Ensure the unit is mounted securely

on a vertical DIN rail (35 mm) by us­ing a fixing element (e.g. retaining
bracket or an end angle).

Dimensions

75 (2.95")

87 (3.42")

121 (4.8")

22,5
(0,89")

Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

NSG-D-2-069-2006-09Pilz GmbH & Co. KG, Sichere Automation, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany

-4

E-STOP relays

up to Category 2, EN 954-1

PNOZ X1

Notice

Service life graph

This data sheet is only intended for use
during configuration. For installation
and operation, please refer to the op-

10

erating instructions supplied with the
unit.

1

DC13: 24 V

D Nennbetriebstrom (A)

GB Nominal operating current (A)

F Courant coupé (A)

Technical details

Electrical data

Supply voltage
Supply voltage U

AC/DC 24 V

B

Voltage tolerance -15 %/+10 %
Power consumption at U
Power consumption at U

AC 4.0 VA

B

DC 2.0 W

B

Frequency range AC 50 - 60 Hz
Residual ripple DC 160 %
Voltage and current at
Input circuit DC: 24.0 V 65.0 mA
Reset circuit DC: 24.0 V 40.0 mA
Feedback loop DC: 24.0 V 40.0 mA
Number of output contacts
Safety contacts (S) instantaneous: 3
Auxiliary contacts (N/C): 1
Category of output contacts in accordance with EN 954-1
Safety contacts (S) instantaneous: 2
Utilisation category in accordance with EN 60947-4-1
Safety contacts: AC1 at 240 V I

Safety contacts: DC1 at 24 V I

Auxiliary contacts: AC1 at 240 V I

Auxiliary contacts: DC1 at 24 V I

Utilisation category in accordance with EN 60947-5-1
Safety contacts: AC15 at 230 V I
Safety contacts: DC13 at24 V (6 cycles/min) I
Auxiliary contacts: AC15 at 230 V I
Auxiliary contacts: DC13 at24 V (6 cycles/min) I
Contact material AgCuNi + 0.2 µm Au

0.1

E Corriente nominal de servicio (A)

I Corrente di esercizio nominale (A)

NL Nominale bedrijfsstroom (A)

100

D Schaltspielzahl x 10
GB Cycles x 10
F Nombre de manvres x 10

: 0.01 A , I

min

: 2000 VA

P

max

: 0.01 A , I

min

P

: 200 W

max

: 0.01 A , I

min

P

: 2000 VA

max

: 0.01 A , I

min

: 200 W

P

max

: 6.0 A

max

: 5.0 A

max

: 6.0 A

max

: 5.0 A

max

3

3

max

max

max

max

1000

: 8.0 A

: 8.0 A

: 8.0 A

: 8.0 A

DC1: 24 V

AC15: 230 V

E Número de ciclos x 10
I Numero dei cicli di commutazione x 10

3

NL Aantal schakelingen x 10

AC1: 230 V

10000

3

3

100000

3

Pilz GmbH & Co. KG, Sichere Automation, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

NSG-D-2-069-2006-09

E-STOP relays

up to Category 2, EN 954-1

PNOZ X1

Electrical data

External contact fuse protection (IK = 1 kA) to EN 60947-5-1
Blow-out fuse, quick
Safety contacts: 10 A
Auxiliary contacts: 10 A
Blow-out fuse, slow
Safety contacts: 6 A
Auxiliary contacts: 6 A
Circuit breaker 24 VAC/DC, characteristic B/C
Safety contacts: 6 A
Auxiliary contacts: 6 A
Max. overall cable resistance R
input circuits, reset circuits
single-channel at U
single-channel at U

Times

Switch-on delay
with automatic reset typ. 60 ms
with automatic reset max. 120 ms
with manual reset typ. 50 ms
with manual reset max. 120 ms
Delay-on de-energisation
with E-STOP typ. 55 ms
with E-STOP max. 90 ms
with power failure typ. 55 ms
with power failure max. 90 ms
Recovery time at max. switching frequency 1/s
after E-STOP 100 ms
after power failure 100 ms
Supply interruption before de-energisation 20 ms

Environmental data

EMC EN 60947-5-1, EN 61000-6-2
Vibration to EN 60068-2-6
Frequency 10 - 55 Hz
Amplitude 0.35 mm
Climatic suitability EN 60068-2-78
Airgap creepage EN 60947-1
Rated insulation voltage 250 V
Rated impulse withstand voltage 6.0 kV
Ambient temperature -10 - 55 °C
Storage temperature -40 - 85 °C
Protection type
Mounting (e.g. cabinet) IP54
Housing IP40
Terminals IP20

Mechanical data

Housing material
Housing PPO UL 94 V0
Front ABS UL 94 V0
Max. cross section of external conductors with screw terminals
1 core flexible 0.20 - 4.00 mm² , 24 - 10 AWG
2 core, same cross section, flexible:
with crimp connectors, without insulating sleeve 0.20 - 2.50 mm² , 24 - 14 AWG
without crimp connectors or with TWIN crimp connectors 0.20 - 2.50 mm² , 24 - 14 AWG
Torque setting with screw terminals 0.60 Nm

DC 30 Ohm

B

AC 30 Ohm

B

lmax

Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

NSG-D-2-069-2006-09Pilz GmbH & Co. KG, Sichere Automation, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany

-6

E-STOP relays

up to Category 2, EN 954-1

PNOZ X1

Mechanical data

Dimensions
Height 87.0 mm
Width 22.5 mm
Depth 121.0 mm
Weight 180 g

The standards current on 2004-09 apply.

Conventional thermal current

Number of contacts I
1 8.00 A 8.00 A
2 7.00 A 7.00 A
3 6.00 A 6.00 A

Order reference

Type Features Terminals Order no.

PNOZ X1 24 VAC 24 VDC Screw terminals 774 300

(A) at UBDC Ith(A) at UBAC

th

Pilz GmbH & Co. KG, Sichere Automation, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: [phone], Telefax: [phone], E-Mail: [e-mail]

NSG-D-2-069-2006-09
