USER´S MANUAL
BEDIENUNGSANLEITUNG
MANUEL D`UTILISATION
MANUAL DE USUARIO
INSTRUKCJA OBSŁUGI
|
|
|
|
|
|
ON |
|
-10 |
-8 |
-12 |
-10 |
-8 |
POWER |
-12 |
-15 |
|
-6 |
OFF |
||
-15 |
|
-6 |
|
|
-4 |
|
|
|
-18 |
|
|
||
|
|
-4 |
|
|
|
|
-18 |
|
|
|
-2 |
|
|
|
|
-27 |
|
|
||
|
|
-2 |
|
0dB |
|
|
-27 |
|
|
|
|
||
|
|
0dB |
|
CHA |
|
|
|
CHA |
|
|
|
|
|
LD DEEP2 SERIES |
|
|||||
DYNAMIC EFFICIENT ENGINEERED POWER AMPS
ENGLISH
LSKFRANCAPOI FRANCAISespañol FRANCAIS DEUTSCH
Thank you for choosing LD-Systems!
We have designed this product to operate reliably over many years. Therefore LD-Systems guarantees for high quality products with its name and many years of experience as a producer.
Please, take a few moments to read these instructions carefully, as we want you to enjoy your new LD-Systems products quickly and to the fullest.
For information about LD-Systems check out our website WWW.LD-SYSTEMS.COM
2
LD DEEP2 SERIES
DYNAMIC EFFICIENT ENGINEERED POWER AMPS
|
|
|
|
ON |
|
-12 -10 -8 |
-12 |
-10 -8 |
POWER |
|
-15 |
-6 |
OFF |
|
-15 |
-6 |
|
-4 |
|
|
-18 |
|
||
|
-4 |
|
|
|
-18 |
|
-27 |
-2 |
|
|
-2 |
0dB |
|
|
-27 |
|
|
||
|
0dB |
|
CHA |
|
CHA
ENGLISH
LSKFRANCAPOI FRANCAISespañol FRANCAIS DEUTSCH
3
ENGLISH
LSKFRANCAPOI FRANCAISespañol FRANCAIS DEUTSCH
PREVENTIVE MEASURES:
1.Please read the attached safety instructions as well as the following instructions carefully.
2.Please keep all the instructions.
3.Please use the device only as intended.
4.Please respect the valid waste management rules. Please deliver the packaging divided into plastic and paper/ cardboard to the recycling management.
5.Please refer all servicing to qualified personel only if the device is damaged, exposed to liquid/rain or if it does not operate normally.
6.Please, do not expose to any kind of heat such as ovens, radiators, or any other devices (incl. amplifiers). Please check for enough distance between amplifiers and walls, racks, etc. to prevent overheating.
7.After connection please check the wiring to prevent any kind of accident or damage. Please never use any kind of damaged cable and wiring.
8.Only use authorized and stable stands, brackets, shelfs, tables etc.. for installations. Please check for adequate stability against collapse.
9.Please check operating voltage before connecting. Wrong voltage will damage your device.
|
CAUTION |
|
RISK OF ELECTRIC SHOCK |
CAUTION: |
DO NOT OPEN |
|
To reduce the risk of electric shock, do not remove cover (or back). No user serviceable parts inside. Refer servicing to qualified personnel.
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product´s enclosure that may be of sufficient magnitude to constitute a risk to persons.
The exclamation mark within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
CAUTION! HIGH VOLUME!
You will operate this system for professional use. Therefore the commercial use of this equipment is liable to the rules and regulations of the Accident Prevention & Insurance Association of your industry sector. Adam Hall as a manufacturer is bound to inform you formally about the existence of eventual sanitary risks.
These speakers are able to induce high acoustic sound pressure levels. 85 db is by law the maximum audio pressure level which your ear can be exposed to during a work day. It was set according to the technical expertise of the occupational medicine as a basis for the noise rating level. Higher sound levels or longer exposition times could damage your ear. The time of exposition by higher sound pressure levels should be shortened in order to prevent from ear damages. Here are a few reliable warning signals which show that you have exposed yourself for a too long period to excessive sound pressure levels:
-You hear bellor whistling sounds!
-You have the impression that you can’t hear high tones anymore!
4
FRONT PANEL:
2 3
4 |
5 |
1 |
1POWER SWITCH
Press to toggle the power on or off.
2PROTECT
By overheat or when DC is occured at power amp blocks, Protection cirquit is activated and „Protect“ -LED turns red. The protection cirquit and LED is always activated for 3 seconds after you turn the amplifier on.
3LIMIT
Lights up orange when the limiter ist working, because the signal level is too high. In this case lower the Gain.
4SIGNAL LED
Normal indication: The Signal indicator illuminates when the input signal exceeds -35dB, the -15dB indicator illuminates when the signal exceeds -15dB, the -10dB indicator illuminates when the signal exceeds -10dB, the -5dB indicator illuminates when the when the signal exceeds -5dB.
If no indication: check gain settings and increase gain if necessary. Check input connections and audio source for signal.
Abnormal indication: if -20dB, -15dB, -10dB, -5dB LED illuminates with no signal input, there may be system oscillations or some other malfunction. Disconnect the load and fully reduce the gain. If the LED remains on , the amp may need servicing.
5Gain Controls
Turn the gain controls clockwise to increase gain and counter clockwise to decrease gain.
ENGLISH
LSKFRANCAPOI FRANCAISespañol FRANCAIS DEUTSCH
5
ENGLISH
FRANCAIS DEUTSCH
BACK PANEL:
DP4950 |
1 |
|
Bridge |
Bridge |
|
INPUT |
INPUT |
|
INPUT |
INPUT |
3 4 2 5
DP600, DP1600, DP2100 |
3 |
|
3 |
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
5 |
|
B |
|
|
|
|
|
CH A / BRIDGE |
1 |
3 |
2 |
4 |
DP2400X |
3 |
3 |
6 |
7 |
|
7 |
6 |
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
FRANCAISespañol |
|
|
|
5 |
|
1 |
3 |
2 |
4 |
||
|
FRANCAPOLSKI
KANAL A |
|
|
|
KANAL B |
|
|
AMP OUTPUTS |
1+ |
|
AMP OUTPUTS |
1+ |
||
|
|
|
||||
A.C |
B.C |
|
|
A.C |
B.C |
|
1+ |
1- |
|
|
1+ |
1- |
|
SPEAKON CONNECTOR |
1- |
|
2- |
SPEAKON CONNECTOR |
1- |
2- |
SCHEMATIC DIAGRAM |
|
|
|
SCHEMATIC DIAGRAM |
|
|
BRIDGE MODE 1+ 2+ |
|
|
2+ |
2- |
|
|
2+ |
|
NOT CONNECTED |
2+ |
|||
|
|
|
||||
6
BACK PANEL:
1MAIN SOcKET
Please, make sure that the mains voltage of the amplifier matches the local mains supply. An appropriate mains cord is included.
2INPUT
The XLR/TRS COMBI-type connector inputs INPUT A, B, (C, D on DP4950) are connect to mixing console or other source. The XLR-type connectors LINK A, B, (NOT excisting on DP4950) are prepared for through-
connecting input signals to additional external power amps. The input signal is directly routed to these output connectors, even if power is switched off.
audio Connection cables
Choosing high-quality balanced cables (two conductors for the audio + and - signal plus sepearate shielding screen) with XLR-type connectors is recommended. Although connecting unbalanced cables to the power amplifier inputs is possible as well, using balanced cables is always preferable. A great number of today´s audio applications uses balanced outputs. With balanced cables, the shield connects all metal chassis parts and therefore efficiently eliminates the external interference -mostly noise and hum.
3 OUTPUTS
Speakon and Binding post -type loudspeaker connectors. The Speakon connector is designed specially for highpower speaker connections. It locks in place, prevents shock hazard, and assures the correct polarity.
SPEAKER CABLING
Larger wire sizes and shorter lengths minimize both loss of power and degradation of damping factor. Do not place speaker cables next to input wiring. Please take care when binding posts are used, that there comes no possibility to short cirquit from loosen cables.
4SElecting GROUND SWITCH
Ground lift means breaking a connection between chassis earth and electrical earth. Use this feature only when 50Hz hum is excisting from loudspeakers.
5Selecting stereo / Bridge mode
Stereo mode
Each channel within the pair remains independent, and each may be used for a different signal.
Bridge mode
This setting combines both channels of a pair into a single channel with twice the output voltage. Use only the input and gain control channel A. Set the channel B gain control at minimum.
ENGLISH
LSKFRANCAPOI FRANCAISespañol FRANCAIS DEUTSCH
7
BACK PANEL / CONNECTION:
ENGLISH
LSKFRANCAPOI FRANCAISespañol FRANCAIS DEUTSCH
FREQUENCY FILTER FUNCTION (DP2400X)
6FILTER FREQUENCY 25-150 hz
7Filter switch
OFF: Filter off
Low Pass: For use as variable Low-Pass Filter. Frequencies higher than the adjusted frequency will be cut off. Low Cut: For use as variable Low-Cut Filter. Frequencies lower than the adjusted frequency will be cut off.
To use the DP2400X as an active 2-Way amplifier, combine both filters as a crossover.
CONNECTION
LF - CONNECTION CORDS
For best result please choose high quality balanced XLR cables.
Integrated XLR / 6,3 mm Phone jack combo input connectors offer the opportunity to connect also unbalanced mixing consoles by using 6,3 mm phone jack cables.
XLR-type connector pin-assignment
XLR (male) |
XLR (female) |
|
|
|
|
|
|
|
|
|
|
8
SPECIFICATIONS:
MODEL |
DP600 |
|
DP1600 |
|
DP2100 |
DP4950 |
DP2400X |
Output Power @1 |
|
|
|
|
|
|
|
kHz |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
2 Ω |
2 x 300 W |
|
2 x 800 W |
|
2 x 1050 W |
- |
2 x 1200W |
|
|
|
|
|
|
|
|
4 Ω |
2 x 400 W |
|
2 x 650 W |
|
2 x 810 W |
4 x 810 W |
2 x 950 W |
|
|
|
|
|
|
|
|
8 Ω |
2 x 300 W |
|
2 x 450 W |
|
2 x 560 W |
4 x 490 W |
2 x 600 W |
|
|
|
|
|
|
|
|
Bridge 4 Ω |
600 W |
|
1600 W |
|
2100 W |
- |
2200 W |
|
|
|
|
|
|
|
|
Bridge 8 Ω |
800 W |
|
1300 W |
|
1620 W |
2 x 1600 W |
1800 W |
|
|
|
|
|
|
|
|
Output Circuity: |
Class H |
|
Class H |
|
Class H |
Class H |
Class H |
|
|
|
|
|
|
|
|
Frequenzy Range: |
20 Hz - 20 kHz |
|
20 Hz - 20 kHz |
|
20 Hz - 20 kHz |
20 Hz - 20 kHz |
20 Hz - 20 kHz |
|
|
|
|
|
|
|
|
THD: |
< 0.1 % |
|
< 0.1 % |
|
< 0.1 % |
< 0.1 % |
< 0.1 % |
|
|
|
|
|
|
|
|
S/N Ratio: |
105 dB |
|
106 dB |
|
106 dB |
105 dB |
106 dB |
|
|
|
|
|
|
|
|
Damping Factor: |
> 400 |
|
> 400 |
|
> 450 |
> 400 |
> 450 |
|
|
|
|
|
|
|
|
Crosstalk: |
> 80 dB |
|
> 80 dB |
|
> 80 dB |
> 70 dB |
> 76 dB |
|
|
|
|
|
|
|
|
Voltage Gain: |
35 dB |
|
38 dB |
|
39 dB |
38 dB |
39 dB |
|
|
|
|
|
|
|
|
Input Sensitivity: |
0.775 V |
|
0.775 V |
|
0.775 V |
0.775 V |
0.775 V |
|
|
|
|
|
|
|
|
Input Impedance: |
>20 kOhm |
|
>20 kOhm |
|
>20 kOhm |
>20 kOhm |
>20 kOhm |
|
|
|
|
|
|
||
Protection: |
DC, Temp, Short circuit, Over current |
|
|
||||
|
|
|
|
||||
Controls: |
On/Off, 2x (4x) Volume, Ground lift, Bridge/Stereo |
|
|
||||
|
|
|
|
|
|||
Indicators: |
Power, Signal, Level, Limit, Protect |
|
|
+ Frequency |
|||
|
|
|
|
|
|
|
Filter 12 db/oct |
|
|
|
|||||
Connectors: |
Input: XLR-6,3mm-Combi jack/Link output: XLR/Output: SPKn-Binding post/AC Input: |
||||||
|
Volex power plug |
|
|
|
|
|
|
|
|
|
|
|
|||
Cooling System: |
High efficiency, two speed fan |
|
|
|
|||
|
|
|
|
|
|||
Power Supply: |
AC ~ 230V / 50-60 Hz |
|
|
|
|||
|
|
|
|
|
|
||
Power Consump- |
6.0 A |
|
11.0 A |
|
15.0 A |
19.0 A |
16.0 A |
tion @ Full Load: |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Dimension |
483 x 88 x 350 |
|
483 x 88 x 350 |
|
483 x 88 x 350 |
483 x 88 x 350 |
483 x 88 x 350 |
W x H x D (mm): |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Weight (kg): |
14,5 |
|
14,5 |
|
16,5 |
19,5 |
17,6 |
|
|
|
|
|
|
|
|
Since all our products are constantly controlled and improved, technical changes are possible without prior notice.
ENGLISH
LSKFRANCAPOI FRANCAISespañol FRANCAIS DEUTSCH
9
ENGLISH
LSKFRANCAPOI FRANCAISespañol FRANCAIS DEUTSCH
MANUFACTURER´S DECLARATIONS:
LIMITED warranty
This Limited Warranty applies to the Adam Hall, LD Systems, Defender, Palmer and Eminence branded products.
The statutory warranty rights towards the seller are not affected by this guarantee. In fact, it justifies, additional independent warranty claims towards Adam Hall.
Adam Hall warrants that the Adam Hall product you have purchased from Adam Hall or from an Adam Hall authorized reseller is free from defects in materials or workmanship under normal use for a period of 2 or 5 years from the date of purchase.
The Limited Warranty Period starts on the date of purchase. In order to receive warranty services you are required to provide proof of the purchase date. Your dated sales or delivery receipt, showing the date of purchase, is your proof of the purchase date. Should products of the brands named above be in need of repair within the limited warranty period, you are entitled to warranty services according to the terms and conditions stated in this document.
This Limited Warranty extends only to the original purchaser of this Adam Hall branded product and is not transferable to anyone who obtains ownership of the Adam Hall branded product from the original purchaser. During the Limited Warranty Period, Adam Hall will repair or replace the defective component parts or the product. All component parts or hardware products removed under this Limited Warranty become the property of Adam Hall.
In the unlikely event that your Adam Hall product has a recurring failure, Adam Hall, at its discretion, may elect to provide you with a replacement unit of Adam Hall´s choice that is at least equivalent to your Adam Hall branded product in hardware performance.
Adam Hall does not warrant that the operation of this product will be uninterrupted or error-free. Adam Hall is not responsible for damage that occurs as a result of your failure to follow the instructions included with the Adam Hall branded product.
This Limited Warranty does not apply,
-to wear parts (e.g. accumulator)
-to any product from which the serial number has been removed or that has been damaged or rendered defec tive as the result of an accident
-in case of, misuse, abuse, or other external causes
-by operation outside the usage parameters stated in the user´s documentation shipped with the product
-by use of spare parts not manufactured or sold by Adam Hall
-by modification or service by anyone other than Adam Hall
These terms and conditions constitute the complete and exclusive warranty agreement between you and Adam Hall regarding the Adam Hall branded product you have purchased.
10
MANUFACTURER´S DECLARATIONS:
LIMITATION OF LIABILITY
If your Adam Hall branded hardware product fails to work as warranted above, your sole and exclusive remedy shall be repair or replacement. Adam Halls’ maximum liability under this limited warranty is expressly limited to the lesser of the price you have paid for the product or the cost of repair or replacement of any hardware components that malfunction in conditions of normal use.
Adam Hall is not liable for any damages caused by the product or the failure of the product, including any lost profits or savings or special, incidental, or consequential damages. Adam Hall is not liable for any claim made by a third party or made by you for a third party.
This limitation of liability applies whether damages are sought, or claims are made, under this Limited Warranty or as a tort claim (including negligence and strict product liability), a contract claim, or any other claim. This limitation of liability cannot be waived or amended by any person. This limitation of liability will be effective even if you have advised Adam Hall of an authorized representative of Adam Hall of the possibility of any such damages. This limitation of liability however, will not apply to claims for personal injury.
This Limited Warranty gives you specific legal rights. You may also have other rights that may vary from state to state or from country to country. You are advised to consult applicable state or country laws for a full determination of your rights.
REQUESTING WARRANTY-SERVICE
To request warranty service for the product, contact Adam Hall or the Adam Hall authorized reseller from which you purchased the product.
EC DECLARATION OF CONFORMITY
These devices meet the essential requirements and further relevant specifications of Directives 2004/108/EC (EMC) and 2006/95/EC (LVD). For more information, see www.adamhall.com.
Correct Disposal OF THIS PRODUCT (ELECTRICAL WASTE)
(Applicable in the European Union and other European countries with separate collection systems)
This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government office, for details on where and how they can recycle this item in an enviromentally friendly manner.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This product should not be mixed with other commercial wastes for disposal.
ENGLISH
LSKFRANCAPOI FRANCAISespañol FRANCAIS DEUTSCH
11
ENGLISH
LSKFRANCAPOI FRANCAISespañol FRANCAIS DEUTSCH
MANUFACTURER´S DECLARATIONS:
WEEE-DECLARATION
Your LD-Systems product was developed and manufactured with high quality materials and components wich can be recycled and/or reused. This symbol indicates that electrical and electronic equipment must be disposed of separately from normal waste at the end of its operational lifetime.
Please dispose of this product by bringing it to your local collection point or recycling centre for such equipment. This will help to protect the environment in which we all live.
BatteriES and ACCUMULATORS
The supplied batteries or rechargeable batteries can be recycled. Please dispose of them as special waste or return them to your specialist dealer. In order to protect the environment, only dispose exhausted batteries.
Adam Hall GmbH, all rights reserved. The technical data and the functional product characteristics can be subject to modifications. The photocopying, the translation, and all other forms of copying of fragments or of the integrality of this user’s manual is prohibited.
12
13
:NOTES
LSKFRANCAPOI |
FRANCAISespañol |
FRANCAIS |
DEUTSCH |
ENGLISH |
ENGLISH
LSKFRANCAPOI FRANCAISespañol FRANCAIS DEUTSCH
Mit einem Produkt von LD Systems haben Sie die richtige Wahl getroffen!
Dieses Gerät wurde unter hohen Qualitätsanforderungen entwickelt und gefertigt, um viele Jahre einen reibungslosen Betrieb zu gewährleisten. Dafür steht LD Systems mit seinem Namen und der langjährigen Erfahrung als Hersteller hochwertiger Audioprodukte.
Bitte lesen Sie diese Bedienungsanleitung sorgfältig, damit Sie Ihren neuen Verstärker von LD Systems schnell optimal einsetzen können.
Weitere Informationen zu Produkten von LD Systems erhalten Sie auf unserer Internet-Seite WWW.LD-SYSTEMS. COM.
14
LD DEEP2 SERIE
DYNAMIC EFFICIENT ENGINEERED POWER AMPS
|
|
|
|
ON |
|
-12 -10 -8 |
-12 |
-10 -8 |
POWER |
|
-15 |
-6 |
OFF |
|
-15 |
-6 |
|
-4 |
|
|
-18 |
|
||
|
-4 |
|
|
|
-18 |
|
-27 |
-2 |
|
|
-2 |
0dB |
|
|
-27 |
|
|
||
|
0dB |
|
CHA |
|
CHA
ENGLISH
LSKFRANCAPOI FRANCAISespañol FRANCAIS DEUTSCH
15
ENGLISH
LSKFRANCAPOI FRANCAISespañol FRANCAIS DEUTSCH
SICHERHEITSHINWEISE:
1.Bitte lesen Sie die folgenden Sicherheitshinweise sowie die beigefügten Richtlinien sorgfältig.
2.Bewahren Sie alle zugehörigen Unterlagen für spätere Referenzzwecke auf.
3.Nutzen Sie das Gerät ausschließlich für den bestimmungsgemäßen Zweck.
4.Beachten Sie die jeweils geltenden Vorschriften zur Abfallentsorgung, und geben Sie die Verpackung nach Materialien (Plastik und Papier/Kartonagen) getrennt in die Entsorgung.
5.Lassen Sie Reparaturen ausschließlich von qualifiziertem Servicepersonal durchführen, wenn das Gerät beschädigt ist, Regen oder anderer Feuchtigkeit ausgesetzt war oder Fehlfunktionen aufweist.
6.Achten Sie auf ausreichenden Abstand zu Wärmequellen wie Heizkörper, Öfen etc. (einschließlich anderer Verstärker). Sorgen Sie zur Vermeidung von Überhitzung auf ausreichenden Abstand zu Wänden, innerhalb von Racks etc.
7.Prüfen Sie die Verkabelung sorgfältig, um Unfälle und Schäden zu vermeiden, und verwenden Sie niemals beschädigte Kabel und andere Komponenten.
8.Verwenden Sie bei der Installation/Aufstellung ausschließlich zugelassene, stabile Stative, Halterungen, Regale, Tische etc. und prüfen die Stabilität sorgfältig.
9.Achten Sie vor Anschluss des Geräts auf die korrekte Betriebsspannung, da das Gerät ansonsten beschädigt wird.
|
CAUTION |
|
RISK OF ELECTRIC SHOCK |
ACHTUNG: |
DO NOT OPEN |
|
Entfernen Sie niemals die Abdeckung, da sonst das Risiko eines elektrischen Schlages besteht. Im Inneren des Geräts befinden sich keine Teile, die vom Bediener repariert oder gewartet werden können. Lassen Sie Repara-
turen ausschließlich von qualifiziertem Servicepersonal durchführen.
Das gleichschenkelige Dreieck mit Blitzsymbol warnt vor nichtisolierten, gefährlichen Spannungen im Geräteinneren, die einen elektrischen Schlag verursachen können.
Das gleichschenkelige Dreieck mit Ausrufungszeichen kennzeichnet wichtige Bedienungsund Wartungshinweise.
ACHTUNG! HOHE LAUTSTÄRKEN!
Dieses Gerät ist für den professionellen Einsatz vorgesehen. Der kommerzielle Betrieb dieses Geräts unterliegt den jeweils gültigen nationalen Vorschriften und Richtlinien zur Unfallverhütung. Als Hersteller ist Adam Hall gesetzlich verpflichtet, Sie ausdrücklich auf mögliche Gesundheitsrisiken hinzuweisen.
16
FRONT:
1NETZSCHALTER
Hier schalten Sie den Verstärker ein und aus.
2PROTECT
Die "Protect"-LED leuchtet rot, wenn die Schutzschaltung aufgrund von Überhitzung oder Gleichspannung im Signal aktiviert wird. Außerdem ist die Schutzschaltung nach dem Einschalten des Verstärkers 3 Sekunden lang aktiv ("Protect"-LED leuchtet).
3LIMIT
Die "LIMIT"-LED leuchtet orange, wenn der Signalpegel zu hoch eingestellt ist und die Verzerrung des Ausgangssignals im entsprechenden Kanal über 1% liegt ("Clipping"). Reduzieren Sie in diesem Fall die Verstärkung ("Gain").
4SIGNAL-LEDs
Normale Anzeige: Die Signal-LED leuchtet, wenn das Eingangssignal -35 dB überschreitet; die "-15 dB"-LED leuchtet, wenn das Signal -15 dB überschreitet; die "-10 dB"-LED leuchtet, wenn das Signal -10 dB überschreitet; und die "-5 dB"-LED leuchtet, wenn das Signal -5 dB überschreitet.
Keine Anzeige: Prüfen Sie die Gain-Einstellungen und erhöhen Sie ggf. die Verstärkung. Prüfen Sie die Eingangsverbindungen und die Audioquelle, ob überhaupt ein Signal anliegt. Wenn die Clip-LED leuchtet, jedoch kein oder nur ein schwaches Signal erkannt wird, prüfen Sie bitte die Ausgangsverkabelung auf Kurzschlüsse.
Anzeige Fehlfunktion: Wenn die "-20 dB"-, "-15 dB"-, "-10 dB" und "-5 dB"-LEDs leuchten, ohne dass ein Signal anliegt, kann dies auf Schwankungen im System oder andere Fehlfunktionen zurückzuführen sein. Trennen Sie in diesem Fall die Lastverbindung, und drehen Sie die Verstärkung (Gain) auf Minimum. Leuchtet die LED weiterhin, lassen Sie den Verstärker bitte auf einen Defekt überprüfen.
5Gain-Regler
Drehen Sie die Gain-Regler nach rechts, um die Verstärkung zu erhöhen, und nach links, um die Verstärkung zu reduzieren.
ENGLISH
LSKFRANCAPOI FRANCAISespañol FRANCAIS DEUTSCH
17
ENGLISH
FRANCAIS DEUTSCH
RÜCKSEITE:
DP4950 |
1 |
|
Bridge |
Bridge |
|
INPUT |
INPUT |
|
INPUT |
INPUT |
3 4 2 5
DP600, DP1600, DP2100 |
3 |
|
3 |
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
5 |
|
B |
|
|
|
|
|
CH A / BRIDGE |
1 |
3 |
2 |
4 |
DP2400X |
3 |
3 |
6 |
7 |
|
7 |
6 |
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
FRANCAISespañol |
|
|
|
5 |
|
1 |
3 |
2 |
4 |
||
|
FRANCAPOLSKI
KANAL A |
|
|
|
KANAL B |
|
|
AMP OUTPUTS |
1+ |
|
AMP OUTPUTS |
1+ |
||
|
|
|
||||
A.C |
B.C |
|
|
A.C |
B.C |
|
1+ |
1- |
|
|
1+ |
1- |
|
SPEAKON CONNECTOR |
1- |
|
2- |
SPEAKON CONNECTOR |
1- |
2- |
SCHEMATIC DIAGRAM |
|
|
|
SCHEMATIC DIAGRAM |
|
|
BRIDGE MODE 1+ 2+ |
|
|
2+ |
2- |
|
|
2+ |
|
NOT CONNECTED |
2+ |
|||
|
|
|
||||
18
RÜCKSEITE:
1NETZBUCHSE
Vergewissern Sie sich stets, dass die Betriebsspannung des Verstärkers der in Ihrer Region geltenden Netzspannung entspricht. Ein geeignetes Netzkabel ist im Lieferumfang enthalten.
2EINGÄNGE
Die XLR/TRS-Kombibuchsen (XLR/Stereoklinke; INPUT A, B bzw. INPUT A, B, C, D beim DP4950) dienen der Verbindung mit einem Mischpult oder einer anderen Signalquelle. Die XLR-Anschlüsse LINK A, B (NICHT bei Modell DP4950) sind für das Durchschleifen des Signals zu weiteren Leistungsverstärkern vorgesehen, wobei das Eingangssignal direkt auf diese Ausgänge geroutet wird, selbst wenn der Verstärker ausgeschaltet ist.
Audiokabel
Wir empfehlen den Einsatz hochwertiger, symmetrischer Audiokabel – mit zwei Leitern für das Audiosignal (+ und -) plus separater Abschirmung – mit XLR-Steckverbindern. Es ist zwar auch möglich, unsymmetrische Kabel an den Verstärker anzuschließen, grundsätzlich sollte jedoch der Verwendung symmetrischer Kabel der Vorzug gegeben werden. Heutige Audio-Hardware wird meist über symmetrische Verbindungen angeschlossen, da die Abschirmung alle metallenen Gehäuseteile miteinander verbindet und Störeinflüsse von außen, in erster Linie Rauschen und Brummen, auf diese Weise effektiv verhindert werden.
3AUSGÄNGE
Die Lautsprecherausgänge sind als Speakon-Anschlüsse und Klemmleisten ausgeführt. Speakon-Steckverbin- der wurden speziell für Hochleistungs-Lautsprecherverbindungen entwickelt. Sie lassen sich verriegeln, vermeiden Risiken durch elektrischen Schlag und gewährleisten stets die richtige Polarität.
LAUTSPRECHERKABEL
Je größer der Kabelquerschnitt und kürzer die Kabellängen sind, desto geringer sind die Leitungsverluste und Dämpfung des Signals. Verlegen Sie Lautsprecherkabel nicht direkt neben den Eingangssignalkabeln. Bitte beachten Sie bei der Belegung von Klemmanschlüssen, dass es nicht durch Kurzschlüsse durch lose Leitungsenden kommt.
4GROUND-LIFT-SCHALTER
Mit dem Ground-Lift-Schalter unterbrechen Sie die Verbindung zwischen der Gehäusemasse des Geräts und dem eigentlichen Erdanschluss. Nutzen Sie diese Funktion nur, wenn aus den Lautsprechern 50-Hz-Netz- brummen zu hören ist.
5Stereo- / Bridge-Betrieb
Stereo-Betrieb
Beide Stereokanäle sind unabhängig und können unterschiedliche Signale übertragen.
Bridge-Betrieb
In diesem Modus werden beide Eingänge eines Stereopaars zu einem Kanal mit der doppelten Ausgangsspannung verkoppelt. In diesem Fall verwenden Sie lediglich Eingang und Gain-Regler Kanal A und stellen den GainRegler des Kanals B auf Minimum.
ENGLISH
LSKFRANCAPOI FRANCAISespañol FRANCAIS DEUTSCH
19
ENGLISH
LSKFRANCAPOI FRANCAISespañol FRANCAIS DEUTSCH
RÜCKSEITE / VERKABELUNG:
Frequenzfilterfunktion (DP2400X)
6Filterfrequenz 25-150 hz
7Filter switch
OFF: Filter ausgeschaltet
Low Pass: Benutzung als variabler Low-Pass Filter. Frequenzen über der eingestellten Frequenz werden rausgefiltert.
Low Cut: Benutzung als variabler Low-Cut Filter. Frequenzen unter der eingestellten Frequenz werden rausgefiltert.
Die DP2400X kann als aktive 2-Wege Endstufe verwendet werden , in dem beide Filter kombiniert als Crossover verwendet werden.
VERKABELUNG
NF-Kabel
Wir empfehlen den Einsatz hochwertiger, symmetrischer NF-Kabel (mit zwei Leitern für das Audiosignal plus separater Abschirmung) mit XLR-Steckverbindern. Es ist zwar auch möglich, unsymmetrische Kabel an den Verstärker anzuschließen, grundsätzlich sollte jedoch der Verwendung symmetrischer Kabel der Vorzug gegeben werden. Heutige Audio-Hardware wird meist über symmetrische Verbindungen angeschlossen, da die Abschirmung alle metallenen Gehäuseteile miteinander verbindet und Störeinflüsse von außen, in erster Linie Rauschen und Brummen, auf diese Weise effektiv verhindert werden.
Belegung XLR-Stecker
XLR (male) |
XLR (female) |
|
|
|
|
|
|
|
|
|
|
|
|
|
20
Loading...
