Inficon Sensistor ISH2000 HySpeed Operating Instructions Manual
Hydrogen Leak Detector
Sensistor ISH2000 HySpeed
EN
Operating Instructions
Publication: INFICON AB - Part number nind69e1-a (1203) - All information can be modified without prior notice
Hydrogen leak detector Sensistor ISH2000 HySpeed - Operating Instructions
2 OP-Sensistor ISH2000 HySpeed-EN-201203
EN
Welcome to Sensistor ISH2000 HySpeed
Dear customer,
This manual provides user information for installing and operating the Sensistor ISH2000
HySpeed unit. For start-up installation advice please contact the supplier.
The Sensistor ISH2000 HySpeed is a development of the ISH2000 range of hydrogen leak
detectors adapted for rapid automated leak detection in packaging lines. The leak
detection process is built on the Sensistor technology that uses diluted hydrogen as
tracer gas. The tracer gas is a safe and inexpensive standard mix of 5% hydrogen (E949)
and 95% nitrogen (E941). These gases are commonly used as packaging gases, for
example, and have been approved as food additives.
The Sensistor ISH2000 HySpeed comprises a compact, panel-mounted instrument and a
wired sampling probe. For a complete test station, it is normally necessary to install
equipment for handling the packages and for communication with the leak detection
instrument.
In principle, in-line leak testing with the Sensistor ISH2000 HySpeed suits all types of
packaging where it is possible to create over-pressure for the enclosed tracer gas so as to
permit leak testing. All types of flexible plastic packaging, such as bottles, bags for
powders and creams, bag-in-box bags, trays and tubes can be tested.
When reading this manual, please pay particular attention to Warning, Caution and
Notice found throughout the text. The Warning, Caution and Notices are defined in
chapter 1.1.
This product complies with the requirements of European
Directives, listed in the Declaration of Conformity found on
page 49 in this document. These Directives are amended by
Directive 93/68/E.E.C (E.C. Marking).
Copyright/Intellectual property
The use of INFICON AB products are subject to copyright and
intellectual property rights in force in any jurisdiction.
All rights reserved, including copying this document in whole
or in any part without prior written authorization from
INFICON AB.
Though INFICON AB believes reasonable efforts have been
made to ensure the accuracy of the information contained in
the document, it may include inaccuracies or typographical
errors. INFICON AB reserves the right to change the
information inside the document without further notice.
Hydrogen leak detector Sensistor ISH2000 HySpeed - Operating Instructions
OP-Sensistor ISH2000 HySpeed-EN-201203 3
EN
Contents
1 User information.......................................................................................................................... 5
1.1 Notes and safety notices..........................................................................................................5
1.2 Document outline.................................................................................................................... 5
1.3 Conventions used in this book.................................................................................................5
2 Description of equipment............................................................................................................. 6
2.1 Sensistor ISH2000 HySpeed ..................................................................................................... 6
3 Controls and connections............................................................................................................. 7
3.1 Display ....................................................................................................................................7
3.2 Push-buttons ........................................................................................................................... 7
3.3 LEDs ........................................................................................................................................ 7
3.4 Ports and connections .............................................................................................................8
4 Precautions .................................................................................................................................. 10
4.1 When working with gas ........................................................................................................10
4.2 Hydrogen Tracer Gas for leak detection ................................................................................. 11
4.3 Interferences .........................................................................................................................11
5 Working principle........................................................................................................................ 12
5.1 Leak detection methods ........................................................................................................12
5.2 Gas sensor Technology ......................................................................................................... 12
5.3 Condition for leak detection .................................................................................................. 12
5.4 Leak detection modes............................................................................................................ 12
6 Operating the detector............................................................................................................... 15
6.1 To Detect leaks.....................................................................................................................15
6.2 To Locate Leaks .................................................................................................................... 15
6.3 To Quantify Leaks .................................................................................................................16
7 Calibrate the leak detector......................................................................................................... 17
7.1 Introduction ..........................................................................................................................17
7.2 Calibration reference ............................................................................................................. 17
7.3 Calibration procedure............................................................................................................17
7.4 Reference value by gas concentration .................................................................................... 18
8 Reference section........................................................................................................................ 19
8.1 Menu system.........................................................................................................................19
Button functions..............................................................................................................................................................19
8.2 Engineering format................................................................................................................ 19
8.3 Change Test Mode ................................................................................................................ 20
8.4 Calibration ............................................................................................................................20
Calibrate..........................................................................................................................................................................20
Calibration intervals .........................................................................................................................................................20
Sensitivity too low for reject level .....................................................................................................................................20
High signal! Check reference!..........................................................................................................................................20
Sensor condition indicator ...............................................................................................................................................21
Calibration messages .......................................................................................................................................................21
Reference Value...............................................................................................................................................................22
Reference Unit.................................................................................................................................................................22
Calibration Time ..............................................................................................................................................................22
Minimum calibration time................................................................................................................................................23
Password protected calibration ........................................................................................................................................23
8.5 Detection Mode Settings ....................................................................................................... 23
To detect leaks ................................................................................................................................................................23
To locate leaks.................................................................................................................................................................24
Background compensation ..............................................................................................................................................24
Sensitivity ........................................................................................................................................................................24
Auto Range .....................................................................................................................................................................25
Direct Sensitivity Adjustment............................................................................................................................................25
Audio Threshold ..............................................................................................................................................................25
Reject Indicator................................................................................................................................................................25
Audio Ready Pulse ...........................................................................................................................................................25
8.6 Analysis mode ....................................................................................................................... 25
To analyse leaks...............................................................................................................................................................25
Reject level ......................................................................................................................................................................25
Correlation Value.............................................................................................................................................................26
Analysis Unit....................................................................................................................................................................26
Min Presentation Time .....................................................................................................................................................26
Display Threshold.............................................................................................................................................................26
Audio Threshold ..............................................................................................................................................................26
Reject Indications.............................................................................................................................................................26
Show Reject Level ............................................................................................................................................................26
Audio Ready Pulse ...........................................................................................................................................................26
Hydrogen leak detector Sensistor ISH2000 HySpeed - Operating Instructions
4 OP-Sensistor ISH2000 HySpeed-EN-201203
EN
8.7 APC Settings .........................................................................................................................26
Probe Type ......................................................................................................................................................................27
APC Time A-D .................................................................................................................................................................27
Purge Level ......................................................................................................................................................................27
8.8 Display Settings ..................................................................................................................... 27
Contrast ..........................................................................................................................................................................27
Brightness........................................................................................................................................................................27
Invert Colors ....................................................................................................................................................................27
Screen Save Timeout........................................................................................................................................................27
8.9 General settings ....................................................................................................................28
Language ........................................................................................................................................................................28
Probe Button ...................................................................................................................................................................28
Probe Lamp .....................................................................................................................................................................28
Change Password ............................................................................................................................................................28
Audio Base Frequency......................................................................................................................................................28
Set Clock .........................................................................................................................................................................28
Set Date ..........................................................................................................................................................................29
Printer Port ......................................................................................................................................................................29
Info .................................................................................................................................................................................29
8.10 Service Settings .....................................................................................................................29
Show Password ...............................................................................................................................................................29
Instrument system Reset ..................................................................................................................................................29
Probe System Reset..........................................................................................................................................................29
Detector Signal Level .......................................................................................................................................................29
HySpeed Parameters ........................................................................................................................................................30
Minimum Calibration Time ..............................................................................................................................................30
Calibration Tolerance.......................................................................................................................................................30
Number of Significant Digits ............................................................................................................................................30
Debug Mode ...................................................................................................................................................................30
Service Mode...................................................................................................................................................................30
8.11 Combined Mode ................................................................................................................... 30
8.12 Probe ....................................................................................................................................30
8.13 Probe Control Port................................................................................................................. 31
Probe Control Port Connector..........................................................................................................................................31
Status signal patterns.......................................................................................................................................................32
8.14 Printer port............................................................................................................................33
Connector pin configuration............................................................................................................................................33
Selectable printer types....................................................................................................................................................34
RS232 serial communication ............................................................................................................................................36
APC driver installation......................................................................................................................................................38
8.15 Sensistor ISH2000 HySpeed installation.................................................................................. 39
Installation process ..........................................................................................................................................................39
8.16 Default parameters................................................................................................................40
9 Trouble-shooting......................................................................................................................... 42
10 Sensistor ISH2000 HySpeed specifications................................................................................ 43
11 Spare parts and accessories........................................................................................................ 46
12 Support by INFICON.................................................................................................................... 48
12.1 How To Contact INFICON ......................................................................................................48
12.2 Returning your instrument to INFICON................................................................................... 48
13 Declaration of conformity .......................................................................................................... 49
Hydrogen leak detector Sensistor ISH2000 HySpeed - Operating Instructions
OP-Sensistor ISH2000 HySpeed-EN-201203 5
EN
1 User information
Read this user manual carefully before using the Sensistor ISH2000 HySpeed.
1.1 Notes and safety notices
This manual contains warnings and cautions concerning the safe use of the product.
See definitions below.
Note: A Note is used to indicate information that is important for trouble-free and
optimal use of the Sensistor ISH2000 HySpeed.
1.2 Document outline
The document is devided in two main parts:
• Getting started
• Reference section
The Getting started part consists of step by step case examples, explaining how to
use the Sensistor ISH2000 HySpeed in a variety common situations. The Reference
section consists of in depth explanation and additional information, which
completes the user manual with all relevant information.
1.3 Conventions used in this book
In this user manual the following text style (hardware command) is used for
references to hardware commands or button labels, while this text style (
software
command) is used for references to software commands and menu choices.
WARNING!
Warning indicates a hazardous situation which, if not
avoided, could result in death or serious injury. It is
important not to proceed until all stated conditions
are met and clearly understood.
CAUTION!
Caution indicates a hazardous situation which, if not
avoided, could result in minor or moderate injury. It is
important not to proceed until all stated conditions
are met and clearly understood.
NOTICE!
Notice indicates instructions that must be
followed to avoid damage to the Sensistor
ISH2000 HySpeed or other equipment.
Hydrogen leak detector Sensistor ISH2000 HySpeed - Operating Instructions
6 OP-Sensistor ISH2000 HySpeed-EN-201203
EN
2 Description of equipment
2.1 Sensistor ISH2000 HySpeed
Sensistor ISH2000 HySpeed is a leak test detector optimized for high speed leak
testing. The model is particularly aimed at testing packages, but possible to use for
other applications as well where the time allowed for a LEAK/NO LEAK decision is
extremely limited. The testing speed can be up to four tests per second. The
detector is designed for integrating in a packaging machine or similar applications.
If you intend to make the leak test using accumulation, shell damps, scanning or by
hand sniffing we recommend the standard model of Sensistor ISH2000.
Sensistor ISH2000 HySpeed is equipped with a number of powerful functions
making it very easy to integrate in a semi or fully automatic test system. The
functions range from output of all necessary status signals and printer/
communication port to an advanced Active Probe Control system (APC). This makes
the detector capable of controlling advanced sample collecting devices down to
simple test fixtures.
The model consists of one part apart from the manual, etc:
Fig 2-1. Sensistor ISH2000 HySpeed
Item Description
1
Detector unit
7
User manual (not shown)
8
Product return form (not shown)
Hydrogen leak detector Sensistor ISH2000 HySpeed - Operating Instructions
OP-Sensistor ISH2000 HySpeed-EN-201203 7
EN
3 Controls and connections
The controls and connections are discussed and shown in this chapter.
Fig 3-1. Sensistor ISH2000 HySpeed controls and indicators.
3.1 Display
The display shows:
• indicator bar in Detection Mode and the figures in Analysis Mode.
• seven main menus. Their positions are indicated on a horizontal scale. Change from
one menu to another using the < and > buttons.
• main menus have submenus, which are also indicated by horizontal scales and can
be selected using the < and > buttons.
• scales for setting numeric values, languages, etc.
• messages.
3.2 Push-buttons
The functions of the push-buttons are shown at the lower edge of the display. In this
manual the buttons are numbered, from left to right, 1, 2, 3, and 4. The push-buttons
are used to:
• Change from one menu item to another using the < and > buttons.
• Press Enter to move down to the nearest submenu.
• Press Save to save the set value.
• Press Undo to restore the previously set value.
• Press Esc to move up to the nearest higher level(s).
3.3 LEDs
The two LEDs indicate the status of the instrument as follows:
• Green flashing slowly, during warming up phase.
• Green fixed light indicates that instrument is ready and hydrogen signal is below
Item Description
1 Display
2 Loudspeaker
3 Control push-buttons
4 Earphone socket
5 Probe connector
6 LEDs
1
1
2
3 3 3 3
45
6
Hydrogen leak detector Sensistor ISH2000 HySpeed - Operating Instructions
8 OP-Sensistor ISH2000 HySpeed-EN-201203
EN
Reject Level limit.
• Red fixed light together with Reject on display means the instrument has detected a
leak larger than the set Reject Level limit.
• Red flashing rapidly, check message on screen. (See “Trouble-shooting” on
page 42.)
3.4 Ports and connections
Sensistor ISH2000 HySpeed
Fig 3-2. Sensistor ISH2000 HySpeed ports and connections.
Item Description
1 Probe connection
2 Ground screw
3 Power connector
4 Probe control port
5 Printer port
NOTICE!
Always connect all four wires to the Power connector to
24VDC in order to operate.
Sensistor ISH2000 HySpeed Rear View
1
2
3
4
5
Hydrogen leak detector Sensistor ISH2000 HySpeed - Operating Instructions
OP-Sensistor ISH2000 HySpeed-EN-201203 9
EN
This Page Intentionally Left Blank
Hydrogen leak detector Sensistor ISH2000 HySpeed - Operating Instructions
10 OP-Sensistor ISH2000 HySpeed-EN-201203
EN
4 Precautions
Read this user manual carefully before using the instrument. Hydrogen Leak
Detector Sensistor ISH2000 HySpeed is extremely selective. Only Hydrogen Sulphide
(extremely toxic) gives a comparable response to hydrogen.
4.1 When working with gas
The normal risks associated with working with all compressed gases must be
considered.
Before connecting tracer gas: confirm that the connectors or test object is designed
for working at the test pressure.
Note: INFICON AB can not take any responsibility for the consequences arising from the
inappropriate use of certain test pressures.
WARNING!
Pure hydrogen is a flammable gas. Only use
ready-made Hydrogen Tracer Gas of 5%
Hydrogen in Nitrogen. This is a standard
industrial gas mixture used in various industrial
applications.
Note: Whenever the word Hydrogen is used in this
manual it implies that the hydrogen gas is safely
mixed with Nitrogen in the proportions 5% H2 95% N2.
WARNING!
Since the tracer gas mix contains no oxygen,
releasing large amounts of gas in a confined
space may lead to asphyxiation.
WARNING!
Compressed gases contain a great deal of stored
energy. Always carefully secure gas bottles
before connecting pressure regulator. Never
transport gas bottle with the pressure regulator
fitted.
WARNING!
Pressurising objects at too high pressures can
result in a burst object. This in turn can result in
serious injury or even death.
Never pressurise objects that have not
previously been burst tested or otherwise
approved for the chosen test pressure.
Hydrogen leak detector Sensistor ISH2000 HySpeed - Operating Instructions
OP-Sensistor ISH2000 HySpeed-EN-201203 11
EN
Pressure shocks might cause strong sounds which can cause impairment of hearing.
Check that all relevant legislation and safety standards are complied with before
putting Sensistor ISH2000 HySpeed into service.
4.2 Hydrogen Tracer Gas for leak detection
When pure hydrogen gas is released in air its flammability range spans from 4% to
75% of hydrogen in air. Below 4% there is insufficient chemical energy available for
a flame to occur. Above 75% hydrogen there is not enough oxygen left to support a
flame.
When, for example, a mixture of less than 5.5 % hydrogen in nitrogen mixes with air
there is not sufficient energy to support a flame, irrespective of the ratio of air-togas.
When a mixture of more than 5.5 % hydrogen in nitrogen is released into air there
is a region of ratios of air-to-gas where the mixture is flammable. When, for
example, a mixture of 10% hydrogen in nitrogen mixes with air there is still very
little energy available. Only in exceptional circumstances can a flame be selfsupporting. However, such mixtures cannot detonate.
4.3 Interferences
Most tracer gas methods suffer from some sort of interference. Either the detector is
sensitive to other gases or vapors, or there are other sources of the gas present to
which the detector is sensitive.
Some examples of possible hydrogen sources:
• Engine exhaust
• Battery charging stations
• Cigarette smoke
• Breathing air
• Human flatulence
• Scratching on aluminum surfaces
WARNING!
Hydrogen/nitrogen mixtures containing
approximately more than 15% hydrogen can
detonate when mixed in certain proportions
with air.
NOTICE!
Never make your own mixtures. Only use readymade mixtures or use a certified hydrogen/
nitrogen mixture mixer installed by your gas
supplier.
Hydrogen leak detector Sensistor ISH2000 HySpeed - Operating Instructions
12 OP-Sensistor ISH2000 HySpeed-EN-201203
EN
5 Working principle
5.1 Leak detection methods
Leak detection or leak testing can easily be done with help of Sensistor ISH2000
HySpeed.
By pressurizing the test object with a tracer gas, consist a mix of 5% hydrogen and
95% nitrogen, all hole and capillaries will be filled up with the tracer gas.
The tracer gas penetrates through leaks and out on the outside. On the outside the
leaks position will be able to detect and the size of the leak be able to measure by
the leak detector instrument with a tracer gas-sensitive probe.
5.2 Gas sensor Technology
The Sensistor ISH2000 HySpeed leak detector is using an extremely sensitive
hydrogen gas sensor based on a microelectronic field effect transistor (MOS-FET).
The gas sensitivity appears when hydrogen absorbs into the sensor through a metal
alloy (metal hydride) layer.
Only hydrogen can diffuse into the metal and this makes the sensors practically
insensitive to other substances that do not contain free hydrogen molecules.
The signals from the sensors are processed by a microprocessor which also controls
the sensor temperature with high accuracy, and other sensor diagnostics in order to
ensure perfect functionality. It also automatically compensates for background gas.
5.3 Condition for leak detection
To use the leak detector the test object must be filled and pressurized by tracer gas
(95% N
2
/ 5% H2) to get a gas flow through the leak. The tracer gas is a standard
welding gas of industry quality, easy to obtain at low cost. The generic name is
Forming Gas. Appropriate gas filling equipment can be obtained from the leak
detector supplier.
Be careful of how tracer gases are handled after use. Released tracer gas
contaminates the surrounding air with hydrogen and can complicate the following
measurements for a time. Ensure that the tracer gas is ventilated away from the
target area, preferably to the outside of the building.
5.4 Leak detection modes
The detector operates in three modes:
• The leak locating mode (Detection Mode), mainly used for detecting and locating
leaks but not quantifying them.
• The hydrogen measurement mode (Analysis Mode) measures the concentration of
hydrogen.
• The Combined Mode, (default mode) which is a combination of Detection and
Analysis mode.
The Detection Mode operates continuously while the Analysis Mode determines the
hydrogen concentration (and calculates a corresponding leak rate) in a step
measurement. Detection Mode gives no numbers. It therefore needs no actual
Hydrogen leak detector Sensistor ISH2000 HySpeed - Operating Instructions
OP-Sensistor ISH2000 HySpeed-EN-201203 13
EN
calibration. The sensitivity of the sound signal and the moving bar on the display is
set manually or automatically, see below.
When using the instrument in Analysis Mode, it must be calibrated as described. See
“Calibrate the leak detector” on page 17 in order to give correct figures.
Hydrogen leak detector Sensistor ISH2000 HySpeed - Operating Instructions
14 OP-Sensistor ISH2000 HySpeed-EN-201203
EN
Hydrogen leak detector Sensistor ISH2000 HySpeed - Operating Instructions
OP-Sensistor ISH2000 HySpeed-EN-201203 15
EN
6 Operating the detector
6.1 To Detect leaks
If all you wish to do is to detect the presence of a leak, that is, find out whether
there is a leak or not, then use the Detection Mode (or use the detection bar in
Combined Mode). The definition of Leak/No Leak will then simply be ”A leak is a
leak when it can be detected by the detector, set to a specific sensitivity”.
To set up:
The operation in Detection Mode is not quantitative. The audio and visual signal
will increase and decrease with the gas concentration. Therefore, there is no actual
calibration to be done, but rather a setting of the sensitivity to a desired level.
A typical set-up procedure for Detection Mode is:
• Set up a reference leak which corresponds to the smallest leak you wish to detect.
• Put the probe close to the reference leak and note approximately what reaction you
get (no reaction, small, medium, high, full scale) within the first few seconds.
• Set the sensitivity. This can be done permanently under the menu Detection Mode
Settings or temporarily as a Direct Sensitivity Adjustment on the display (unless
you have set this function to OFF under the Detection Mode Settings menu).
There is also an Auto ranging function which can be selected under the Detection
Mode Settings menu.
Note: If the Detection Mode is used and the alarm function is required to be
activated at a particular calibrated level, then the unit must be calibrated in
accordance with the instructions, see “Calibrate the leak detector” on
page 17. The reason for this is that the alarm is based on the Analysis Mode
when the Detection Mode is displayed.
6.2 To Locate Leaks
Note: The Detection Mode (or use the detection bar in Combined Mode) is used
to locate leaks. This mode is semi-quantitative, that is, it gives an audio and
visual signal which increases as a leak is approached (a higher gas
concentration) and decreases as you move the probe away from the leak. It
does not display figures. In this mode of operation leaks can easily be detected
using a sensitivity which can be preset. See “To locate leaks” on page 24 and
“Direct Sensitivity Adjustment” on page 25.
Leaks can be located very accurately, even when there are other leaks nearby. If, for
example, you are trying to locate a leak on a product and the product has a major
leak, then you will get an audio signal as soon as the probe is placed close to the
product. When the probe is moved around and over the product, the signal will
increase as the probe approaches the leak. If the signal goes out of scale, simply
reduce the sensitivity setting to bring the signal within the scale. Working with the
sensitivity setting this way you will be able to locate multiple leaks that are in close
proximity to each other.
Note: Working inside a confined space such as, for example, a cabinet or a narrow
passage on a combustion engine there is a risk that the background
concentration accumulates to levels close to the upper detection limit of the
detector. In such case it will not be possible to locate leaks as easily as in open
spaces.
Hydrogen leak detector Sensistor ISH2000 HySpeed - Operating Instructions
16 OP-Sensistor ISH2000 HySpeed-EN-201203
EN
Hint: It is good practice to detect a leak, locate it, and immediately remove the probe
to avoid saturation. The probe is not damaged by the exposure but it will recover more
slowly. After excessive exposure it will be less sensitive for a short period of time.
6.3 To Quantify Leaks
The Analysis Mode (or use the analysis figures in Combined Mode) is used for
measuring the size of a leak (or the concentration of a gas sample). To be able to do
this measurement and obtain correct values, the instrument must first be calibrated
using the calibration function.
In the Analysis Mode the detector determines the gas concentration from the
change, as the probe goes from being exposed to background to being exposed to a
certain gas concentration. The detector does not continuously monitor the gas
concentration but takes just one reading instead. Another suitable alternative name
for this mode could be Sampling Mode. It is important to keep this in mind when using
the detector in this mode.
In Analysis Mode the probe should be moved directly from a background situation to
the test point. The size of the leak in PPM, or any other selected units, is shown on the
display. The probe can and should be removed from the measuring point as the
measured value steadies and remains on the display. The period during which the
measured value is displayed can be adjusted in the Analysis Mode Settings menu.
The leak detector operates in the range 20 - 50000 ppm (0,002-5%) H2.
CAUTION!
• Do not open detector! Service of this equipment may only be carried out by service organisations authorised therefore by INFICON, Sweden.
• If the detector gets outer damage it must be controlled and repaired by service
organisation authorised by INFICON.
• Do not expose the probe to a hydrogen concentration higher than 0.1 % when
the instrument is not put into operation, this might damage or destroy the probe
sensor.
Note:• When the instrument is put into operation the sensor withstands
temporary exposure to hydrogen concentration up to 100%. Avoid long exposures
to high concentrations.
Hydrogen leak detector Sensistor ISH2000 HySpeed - Operating Instructions
OP-Sensistor ISH2000 HySpeed-EN-201203 17
EN
7 Calibrate the leak detector
7.1 Introduction
The leak detector is the instrument and the probe together.
This section of the user manual consists of step by step examples about how to
calibrate the detector in the most common cases. For more about the calibration
routine see the reference section.
The instrument must be calibrated by using the integrated calibration function to
make sure it displays the correct values in Analysis Mode. After calibration the
instrument will show the correct measured values on the display in
Analysis Mode.
The calibration parameters will be stored into the probe or in the Combox.
7.2 Calibration reference
There is a possibility to calibrate the detector by Reference Gas concentration.
A Reference contains a well-defined concentration of Hydrogen gas in ppm mixed
by air or some inert gas. If you use premixed Reference gas a Certificate will
normally follow the gas bottles. Reference Gas can be ordered from local gas
suppliers.
Choose a calibration reference size, as follows recommendations:
• Same or higher than the Reject Level (but maximum 10 times higher)
• in the following range: 500-5000 ppm H2
Please contact the provider of the detector for help to select optimal calibration
reference for your application.
7.3 Calibration procedure
Before calibration, the Reference Value in the Calibration Menu must be set. See “With
reference gas concentration”.
When calibrating, expose the probe to the background air then do the following
steps:
1. First Menu then Calibration/Calibrate/Enter.
2. Push the
Start button or push the probe button.
3. Expose the probe to the reference gas/leak
The probe does not have to be exposed to the to the calibration gas during the
whole
Calibration Time (the time set in the Calibration menu while the bar is moving).
The instrument only measures the change as the probe goes from the background
air to calibration gas.
While the calibration time bar is moving, the probe should be exposed to the
calibration gas or reference leak. Then the display shows
Detecting Gas and gives
sound signals. Repeat the calibration routine until you can save the calibration. If
the calibration is not saved, the instrument will revert to the previous value after
one minute.
