Introduction
Congratulations on your purchase of the HP LaserJet 9000mfp*
(product number C8523A) or HP La serJet 9000Lmfp (product n umber
Q2622A). The product comes standard with:
•
128 MB random access memory (RAM)
•
copying, digital sending, and wide-format printing capabilities
•
wide-format printing
•
two 500-sheet trays (Tray 2 and Tray 3)
•
a 100-sheet multipurpose tray (Tray 1)
•
a 2000-sheet input tray (Tray 4)
•
an HP Jetdirect print server
•
a duplex printing accessory (for printing on both sides of paper)
The product featur es an in te r a ctive touch screen on the control panel
graphical display. You must choose one of the three paper handling
devices: the 3000-sheet stacker, the 3000-sheet stapler/stacker, or
the multifunction finisher.
Note The product requires an optional tok en ring card to connect to a tok en
ring network.
*Multifunction Peripheral
4 Product Setup
ENWW
Where to look for information
Start guide
This guide contains information about
unpacking and installing your product.
Introduce guide
This guide contains information about
performing basic copying, sending, and
printing tasks. Introduce is available on
the CD-ROM that came with the
product. If you would like a hard copy,
use your product to print the introduce
guide.
English
ENWW
Use guide
This guide contains detailed information
about using and troubleshooting and is
available on the World Wide Web at
http://www.hp .com/support/lj9000. If you
would like a hard copy, use your product
to print the use guide.
Where to look for information 5
Installation checklist
This guide will help you set up and install your new product. For
proper installation, please complete each sectio n in or de r.
•
Unpack the product steps 1 through 5
•
Install the product steps 6 through14
•
Install printing software step 15
•
Verify product setup step 16
WARNING! To avoid injury, do not attempt to lift the product. The prod uct has been
designed to roll on wheels.
6 Product Setup
ENWW
Step 1 Prepare product location
Product size
Prepare a location for the product that allows for these physical and
environmental requirements:
635.0 mm
(25.0 in)
635.0 mm
(25.0 in)
762 mm (30 in)
(20 in)
508 mm
)
n
i
5
.
1
2
(
m
m
1
.
1
3
5
1177.3 mm
(46.0 in)
529.6 mm
(20.5 in)
647.7 mm
(25.5 in)
641.4 mm
(25.3 in)
641.4 mm
(25.3 in)
English
ENWW
1219.2 mm (48.0 in)
HP LaserJet 9000mfp dimensions (top and side views)
Prepare product location 7
Location requirements for the product
•
A level area on the floor.
•
Space allowance around the
product.
•
A well-ventilated room.
•
No exposure to direct
sunlight or chemicals,
including ammonia-based
cleaning solutions.
•
Adequate power supply
(15 A, 110 V, or 220 V circuit
located near the product). A
dedicated 15 A circuit is
recommended.
•
A stable environment—no
abrupt temperature or
humidity changes.
•
Relative humidity 20
percent to 80 percent.
•
Room temperature 10° C to
32.5 ° C (50° F to 91° F).
8 Product Setup
ENWW
Step 2 Check package contents
high speed copy connect cable
control panel overlays
MFP product
standoffs
product software
CD-ROM
English
power cords
ADF output
print cartridge
ENWW
Quick Reference Poster
Package contents
Start guide
Check package contents 9
Step 3 Remove internal packaging
1 To remove the product from the box, follow the instructions
printed on the box.
WARNING! This product weighs appro ximately 143.2 kg (315 lb). HP recommends
that the product be rolled on its wheels rather than be lifted.
2 Remove the or ange shipping loc k from the e xterior of the product,
and remove any cardboard or styrofoam material that is not
orange.
3 Remove the protective film from the control panel graphical
display. (See Step 4, “Identify product parts.”)
4 Open the left door and remove the two packing fuser assembly
spacers. Orange tape connects fuser assembly spacers to the
outside of the left door. Remove the orange tape that runs from
the fuser assembly shipping locks to the outside of the door.
Close the door after removing the fuser assembly spacers and
the tape.
5 Open each tray, remove the orange shipping locks and any other
orange packing material, and then close the trays.
6 Remove all orange packing material and any orange tape from
the automatic document feeder (ADF) door.
7 Remove all orange packing material and any orange tape from
the glass.
Note Save all packing material. You might need it to repack the product at
another time.
10 Product Setup
ENWW
Step 4 Identify product parts
The following illustrations show the location and names of the primary product parts.
10
1
11
2
12
3
4
5
13
14
6
15
16
17
18
7
19
20
8
21
9
22
English
Product parts (front and back views)
1 ADF output
2 Control panel
3 Front door
4 Power button
5 Tray 2
6 Tray 3
7 Left door
8 Power-cord connector
ENWW
9 Tray 4 power-cord
connector
10 ADF door
11 ADF
12 Tray 1
13 Right door
14 Transfer door
15 Tray 4
16 High speed copy
connect connector
17 Parallel connector
18 Foreign interface
harness connector
(AUX)
19 HP Fast InfraRed
Connect (FIR)
20 HP JetLink connector
(Accessory)
21 EIO slot
22 HP Jetdirect printer
server connector
Identify product parts 11
Step 5 Position the product
1
2
1 Unlock the front wheels of the
product, and roll the product to its
permanent location. Leave space to
walk behind the product.
2 Push the locking tabs on the front
wheels to the lock position. Only the
front wheels lock.
3 Locate the bag with the standoffs,
and then attach them to the product.
Note
The standoffs ensure that your product
cannot be pushed up against the wall.
3
12 Product Setup
ENWW
4
4 Move the scanner carriage shipping
lock to the right.
5 Attach the ADF output.
English
5
ENWW
Position the product 13
Step 6 Install the print cartridge
Note If you get toner on your clothing, wipe it off with a dry cloth and wash
the clothing in cold water. Hot water sets toner into fabric.
1
2
3
1 Before removing the print cartridge
from its packaging, set the print
cartridge on a sturdy surface. Gently
slide the print cartridge out of the
packaging.
CAUTION
To prevent dama ge to the print cartridge,
use two hands when handling the
cartridge.
2 Open the front door of the product.
3 Rotate the green lever downward to
the unlock position.
4 Hold the cartridge so that the arrow
is on the left side of the cartridge.
Position t he cartridge as shown, with
the arrow on the left side pointing
toward the product, and align the
cartridge with the printing guides.
Slide the cartridge into the product
as far as it will go.
4
14 Product Setup
Note
The print cartridge has an internal pull
tab. The product automatically removes
the pull tab after the print cartridge is
installed.
ENWW
5
5 Press the button on the green lever,
and turn the lever clockwise to the
lock position.
6 Close the front door.
English
6
ENWW
Install the print cartridge 15
Step 7 Install accessories
Install the accessories that you purchased. Use the installation
instructions that are packaged with the paper-handling accessories.
See Step 10, “Connect product cables,” for inf ormation on connecting
the HP Fast InfraRed connect.
.
Multifunction finisher
HP Fast InfraRed
3000-sheet stapler/stacker
Accessories
Note See the online use guide for information about ordering accessories.
16 Product Setup
connect (FIR)
3000-sheet stacker
ENWW
Step 8 Load trays 1, 2, 3, and 4
1
2
2
This section describes how to load A4or Letter-size paper. For instructions on
loading and configuring other sizes and
types of media, see the introduce guide
that came on the CD-ROM.
CAUTION
To avoid a jam, never open a tray while
the product is printing from that tray.
English
To load Tray 1
Tray 1 is a multipurpose tray that holds
up to 100 sheets of standard-size paper
or 10 envelopes. The product will pull
paper from Tray 1 first (d efault tray). See
the use guide for information about how
to change this default.
3
Tray 1 provides a con v en ient w a y to print
envelope s, transparencies, custom-size
paper, or other types of media without
having to unload the other trays.
1 Open Tray 1.
ENWW
2 Load A4- or Letter-size paper with
the long edge leading into the
product.
3 Adjust the paper guides so that they
lightly touch the paper stack, but do
not bend the paper.
Note
Make sure the paper fits under the tabs
on the guides and not above the load
level indicators.
Load trays 1, 2, 3, and 4 17
1
2
3
To load Tray 2 and Tray 3
1 Pull Tray 2 open until it stops.
2 Load about 100 sheets of A4- or
Letter-size paper with the short edge
of the paper leading into the produ ct.
Note
For single-sided printing of letterhead or
preprinted paper, the side to be printed
on should be down. For double-sided
printing of letterhead or preprinted
paper, the first side to be printed on
should be up.
3 Adjust the left (Y) paper guide by
squeezing the tab on the guide and
sliding it to the mark for A4- or
Letter-size paper.
18 Product Setup
ENWW
4
6
4 Adjust the front (X) paper guide by
squeezing the tab on the guide and
sliding it to the mark for A4- or
Letter-size paper.
5 Load the remaining paper (up to 500
sheets), if desired.
6 Push the tray in until it stops.
7 Repeat steps 1 through 6 to load
Tray 3.
English
ENWW
Load trays 1, 2, 3, and 4 19
1
2
3
To load Tray 4
1 Pull Tray 4 open until it stops.
2 Load about 100 sheets of A4- or
Letter-size paper with the short edge
of the paper leading into the produ ct.
Note
For single-sided printing of letterhead or
preprinted paper, the side to be printed
on should be down. For double-sided
printing of letterhead or preprinted
paper, the first side to be printed on
should be up.
3 Adjust the left (Y) paper guide by
squeezing the tab on the guide and
sliding it to the mark for A4- or
Letter-size paper.
20 Product Setup
ENWW
4
5
4 Adjust the front (X) paper guide by
squeezing the tab on the guide and
sliding it to the mark for A4- or
Letter-size paper.
5 Load the remaining paper (up to
2000 sheets), if desired.
6 Press down on all four corners of
the paper stack to ensure the
paper rests flat in the tray,
without bending.
CAUTION
Never store paper or other items in the
area to the left of the paper guides.
Doing so can permanently damage the
tray.
English
6
7 Push the tray in until it stops.
7
ENWW
Load trays 1, 2, 3, and 4 21
Step 9 Change the control panel overlays
1
2
The control panel comes either with
English overlays installed or with no
overlays. If necessary, use the procedure
below to change the control panel
overlays.
1 Locate the two control panel
overlays.
2 Insert a small, flat-bladed
screwdriver or other thin, narrow
device in the slot at the top edge of
one of the overlays.
3 Lift the overlay up and backward to
move it away from the product.
3
22 Product Setup
ENWW
4
4 Position the new overlay over the
control panel. Align the ends of the
overlay with the holes on the control
panel and slide the overlay in.
5 Snap the overlay firmly onto the
control panel. Ensure that the
overlay is flat against the control
panel.
English
5
6 Repeat steps 2 through 5 to change
the second overlay.
ENWW
Change the control panel overlays 23
Step 10 Connect product cables
r
The product can connect to a computer using a parallel cable, or to
the network using the HP Jetdirect print server. Connection to a token
ring network is available through an optional token ring card.
Parall el connector
(Parallel)
High speed copy
connect connector
Foreign interface
harness (AUX)
(optional)
HP Fast InfraRed
Connect (FIR)
(optional)
HP JetLink connecto
(Accessory) (for
accessories)
Location of interface ports
24 Product Setup
HP Jetdirect print
server RJ-45
connector
ENWW
Connecting to Ethernet 10/100Base-TX
network
Use the RJ-45 connector to connect the product to an Ethernet 10/
100Base-TX network. HP Jetdirect print servers are available for
many different network connections.
English
1
2
1 Locate the power button on the front
of the product. Make sure the
product is turned off (button out).
2 Connect a twisted-pair network
cable to the RJ-45 connector on the
HP Jetdirect print server installed in
the product.
3 Connect the other end of the cable
to the network.
3
ENWW
Connect product cables 25
Step 11 Connect power cords
This section describes how to connect the power cord. HP
recommends connecting the power cord to a surge protector.
1
2
3
1 Locate the power button on the front
of the product. Make sure the
product is turned off (button out).
CAUTION
Do not connect the product power cord
to the power-cord connector on
Tray 4. That connector is designed t o
connect paper output devices such as
the multifunction finisher to Tray 4.
2 Connect the power cords to the
product power cord connector and to
the Tray 4 connector. Then connect
the power cords to an adequate AC
outlet.
Note
For best performance, a dedicated 15 A
outlet is recommended.
3 Connect the high speed copy
connect cable to the copy processor
board. Be sure to run the cable
under the standoff.
4
26 Product Setup
4 Press the power button to turn the
product on (button in). Afte r the
product warms up, a prompt will
appear asking you to configure your
control panel display languag e. (See
Step 12, “Configure the control panel
display language.”)
ENWW
5
5 Check that the light on the output
device is solid green. Also make
sure that the light on Tray 4 is solid
green. If the light is amber, flashing,
or off, see the use guide that can be
downloaded from
http://www.hp.com/support/lj9000.
English
ENWW
Connect power cords 27
Step 12 Configure the control panel display
language
By default, the control panel on the product displays messages in
English. If necessary, set the product to display messages and print
configuration pages in another supported language.
Note When the product is turned on for the fi rst time, y ou ha v e the option to
set the language to display messages in many different languages.
To configure the control panel language
On the touch screen of the graphical display:
1 Touch Menu.
2 Touch Configure Device.
3 Touch System Setup.
4 Touch Language.
.
5 Touch your language, and then touch S
TART
28 Product Setup
ENWW
Loading...
