QUICK INSTRUCTION MANUAL F-03K
Introduction
Thank you for purchasing "F-03K" mobile terminal. Before using your terminal, or when necessary, read this manual to ensure safe use and handling.
Manuals
" (Kantan operation guide)" (booklet)
This manual provides main functions and operations for the terminal. Operate according to the explanation to use basic function of F-03K.
" me
(Before using Raku raku smartphone me)"
(booklet)
This manual provides important information for using the terminal. For attaching docomo nano UIM card, microSD card, battery pack or charging, refer to this booklet.
" (User's guide)" (installed in the terminal)
This manual provides detailed information and operations of the functions.
<Step>
From the Home screen, [ (User's guide)]e Search method
"Instruction manual" (PDF file)
This manual provides detailed information and operations of the functions.
<From a PC> https://www.nttdocomo.co.jp/support/trouble/manual/ download/index.html
*You can download the latest information.
Viewing this manual
"F-03K" mobile terminal is usually referred to as "the terminal".
The images or illustration used in this manual are examples. They may differ from the actual displays.
"Authenticate" indicates the operating procedure for entering security code or password depending on functions.
In some step descriptions, pressing button is shown by illustration (→p.14).
Main operations are provided. A part of operation steps is simplified in the descriptions.
1 From the Home screen, [ (Mail)]
On the Home screen, touch
.
Touch
.
2 [ (Sent and received logs)]
[ (Recipient)]/[ (Sender)]
Touch [ (Sender)] or [ (Recipient)] according to your purpose.
A log list appears.
To delete all logs, touch [ (Delete received log)]/[ (Delete Sent log)].
Select a log to create mail, register/add to phonebook or delete.
Describes operation result and complemental explanation.
Unauthorized copying of parts of or this entire manual is prohibited.
The contents in this manual, URL and contents are subject to change without prior notice.
Contents |
|
■ Before using the terminal ................................ |
2 |
■ Precautions (Always follow these directions) |
|
.................................................................................. |
3 |
■ Handling precautions ....................................... |
8 |
■ Waterproofness/Dustproofness .................... |
12 |
Before using the terminal ............ |
14 |
Part names and functions....................................... |
14 |
docomo nano UIM card.......................................... |
15 |
microSD card........................................................... |
15 |
Battery pack............................................................. |
16 |
Charging .................................................................. |
16 |
Turning power ON/OFF .......................................... |
18 |
Basic operation........................................................ |
19 |
Initial settings .......................................................... |
20 |
Home screen............................................................ |
20 |
Home screen/Icons.................................................. |
21 |
Calling.......................................... |
24 |
Making a call/video call .......................................... |
24 |
Receiving a call/video call ...................................... |
25 |
One-touch dial......................................................... |
25 |
Phonebook............................................................... |
26 |
Appendix...................................... |
27 |
Specific Absorption Rate (SAR) of Mobile Phones |
|
.................................................................................. |
27 |
Export Administration Regulations ....................... |
30 |
Intellectual Property Right...................................... |
30 |
SIM unlock............................................................... |
32 |
1 |
Contents/Precautions |
Before using the terminal
This terminal supports LTE, W-CDMA, GSM/GPRS, Wireless LAN System.
Because your terminal uses wireless transmission, it may not function in locations where it is difficult for radio waves to penetrate, such as tunnels, underground passages and some buildings, in areas where radio waves are weak, or out of Xi and FOMA service area. Even when you are high up in a tall building or condominium and nothing blocks your view outside, your terminal may not be able to receive or transmit signals. Also, communication may be interrupted even when there are strong radio waves with 4 signal status icons on the terminal and you are not moving (traveling).
Because your terminal uses radio waves to communicate, it is possible that a third party may attempt to tap your calls. However, the LTE, W-CDMA, GSM/GPRS automatically applies a confidential communication function to all calls, so even if a third party could somehow tap a call, they only hear noise.
Your terminal encodes voice communication as digital data. When you are operating your terminal while moving to a location subject to weaker radio wave conditions, the transmitted digital data may not be correctly decoded and as a result the decoded voice may differ somewhat from the actual voice.
Maintain a separate record of the data you saved in the terminal. Note that DOCOMO assumes no responsibility for any loss of saved contents of data resulting from malfunction, repair, changing of the model or other handling of the terminal.
In the terminal, as it is for a PC, some applications that you install may give instability of the operation, or may send your location information or personal information registered to the terminal to outside via the Internet and the information may be used improperly. Please thoroughly check a provider and operation status of the application etc. which you want to use beforehand and then use it.
You are recommended to save important data to microSD card. or a PC.
This terminal supports FOMA Plus-Area and FOMA HIGH-SPEED Area.
The terminal does not support i-mode sites (programs) or i-αppli.
You can use the terminal only with docomo nano UIM card. If you have a UIM or FOMA card, bring it to a docomo Shop to replace.
Even in Manner mode, shutter sound, auto focus lock sound for camera shooting, and count down sound for self timer are emitted.
To check your own phone number, touch
[ (My own phone number)] on the Home screen.
The terminal automatically performs communication for some functions, for example, to synchronize data, check the latest software or maintain connection with the server. If you transmit a large amount of data such as downloading applications or watching video, a packet communication charge becomes high. Subscription of packet flat-rate service is highly recommended.
Depending on the applications or service you use, packet communication charge may be applied even in Wi-Fi communication.
The software on the terminal can be updated with the latest information.
Improving the terminals quality may be included in the software update.
Display is manufactured by taking advantage of highly advanced technology but some dots may be always or never lit. Note that, this shows characteristics of liquid crystal displays and not defects in the terminals.
When the memory of the microSD card or the terminal is almost full, running application may not operate normally. In this case, delete saved data.
In the terminal, only specified applications such as spmode mail, i-channel, etc. are available. Downloading applications from Google Play and using them are not available.
If your terminal is lost, change your password or disable your PC mail accounts using a PC to prevent other persons from using them.
Set the screen lock to ensure the security of your terminal for its loss.
The terminal supports only sp-mode, mopera U and Business mopera Internet. Other providers are not supported.
For details on usage fee, refer to https:// www.nttdocomo.co.jp/english/.
2 |
Contents/Precautions |
Precautions (Always follow these directions)
Before using your terminal, or when necessary, read the precautions below to ensure safe use and handling. After reading this manual, keep it carefully.
These precautions are intended to protect you and others around you. Read and follow them carefully to avoid injury, damage to the product or damage to property.
The signs below differentiate between the levels of danger that can occur if the product is not used within the specified guidelines.
|
|
This sign denotes that death or |
|
|
|
serious injury may directly result |
|
DANGER |
from improper use. |
|
|
|
|
This sign denotes that death or |
|
|
|
serious injury may result from |
|
WARNING |
improper use. |
|
|
|
|
This sign denotes that minor injury |
|
|
|
or damage to property may result |
|
CAUTION |
from improper use. |
|
|
The symbols below show specific directions. |
|
||
|
This symbol denotes that the action is |
|
|
|
prohibited. |
|
|
Don’t |
|
|
|
|
This symbol denotes that disassembling the |
|
|
|
phone or its components is not allowed. |
|
|
No disassembly |
|
|
|
|
This symbol denotes that using the phone or |
|
|
|
its components in a bathroom or other highly |
|
|
No liquids |
|
|
|
|
humid area is not allowed. |
|
|
|
This symbol denotes that using the phone or |
|
|
|
its components with wet hands is not allowed. |
|
|
No wet hands |
|
|
|
|
This symbol denotes that an instruction must |
|
|
|
be obeyed at all times. |
|
|
Do |
|
|
|
|
This symbol denotes that the equipment |
|
|
|
should be unplugged. |
|
|
Unplug |
|
|
|
■ Precautions contain the description below. |
|
||
Handling the terminal, battery pack, adapter, desktop holder |
|||
and docomo nano UIM card (common)............................ |
3 |
||
Handling the terminal |
............................................................. |
4 |
|
Handling battery pack |
............................................................. |
5 |
|
Handling adapter and desktop ....................................holder |
6 |
||
Handling docomo nano ..........................................UIM card |
7 |
||
Handling mobile phones near electronic medical equipment |
|||
............................................................................................... |
|
|
7 |
Material list.............................................................................. |
|
|
7 |
Handling the terminal, battery pack, adapter, desktop holder and docomo nano UIM card (common)
DANGER
Do not use, store or leave the terminal in hot
places (e.g. by the fire, near a heater, under a Don’t kotatsu, in direct sunlight, in a car in the hot
sun).
May cause fire, burns or injuries.
Do not put the terminal into heating cooking
device such as microwave oven or high-pressure Don’t container.
May cause fire, burns, injuries, electric shock.
Do not disassemble or remodel the equipment.
May cause fire, burns, injuries, electric shock.
No disassembly
Do not let the terminal get wet with water,
drinking water, urine of pet animals, etc.
No liquids May cause fire, burns, injuries, electric shock. For waterproofness, refer to "Waterproofness/ Dustproofness"
Use the battery pack and adapter specified by NTT DOCOMO for your terminal.
Do
May cause fire, burns, injuries, electric shock.
|
WARNING |
|
|
Do not throw the equipment or give a strong |
|
Don’t |
force or hard shock to it. |
|
May cause fire, burns, injuries, electric shock. |
||
|
|
|
|
Keep conductive materials (metal pieces, pencil |
|
Don’t |
lead, etc.) from coming in contact with the |
|
charging jack, external connection jack, or stereo |
||
|
earphone jack. Do not put those materials inside |
|
|
the terminal. |
|
|
May cause fire, burns, injuries, electric shock. |
|
|
|
|
|
Do not cover or wrap the terminal with a |
|
Don’t |
blanket, etc while using or charging. |
|
May cause fire or burns. |
||
|
|
|
|
Turn the terminal OFF and stop charging before |
|
Do |
entering a place such as a gas station where |
|
flammable gases are generated. |
||
|
||
|
The gas may catch fire. |
|
|
When using Osaifu-Keitai in a place as a gas station, |
|
|
turn OFF the terminal before using it. |
|
|
(When Osaifu-Keitai lock is activated, deactivate it |
|
|
before turning OFF the terminal.) |
3 |
Contents/Precautions |
If the equipment starts giving off a strange smell, overheats, becomes discolored or deformed
Do
during use, charging or in storage, immediately perform the following operations.
Remove the power plug from the wall outlet or cigarette lighter socket.
Turn the terminal OFF.
Remove the battery pack from the terminal.
May cause fire, burns, injuries, electric shock.
CAUTION
Do not leave the equipment on unstable or
sloping surfaces.
Don’t May cause injuries.
Do not store the equipment in extremely humid,
dusty or hot areas.
Don’t May cause fire, burns, electric shock.
Children using the equipment should be instructed in proper operation by an adult. Do
Do
not allow them to use the equipment without adult supervision.
May cause injuries.
Store the equipment out of reach of small children.
Do
May be accidentally swallowed or cause injuries.
Be careful especially when using the terminal connected to the adapter continuously for a long
Do
time.
If you use applications, call or watch 1Seg while charging the battery for a long time, the terminal, battery pack and adapter may be heated.
Directly touching a hot part for a long time, you may have redness, itching or rash on your skin, or it may result in low-temperature burns depending on your constitution and/or health condition.
Handling the terminal
WARNING
Do not turn on the light by getting the lighting
part closer to other person's eyes. When
Don’t shooting infants, keep at least 1 m away from the object.
May impair eyesight. And may cause accidents like injury etc., by dazzling or astounding other people.
Do not put foreign objects such as liquid like
water, metal pieces or burnable things into Don’t docomo nano UIM card slot or microSD card slot.
May cause fire, burns, injuries, electric shock.
Do not turn on the light aiming directly at the
driver of the car etc.
Don’t May disturb driving and cause an accident.
Turn the terminal OFF in areas where use is prohibited, such as in airplanes and hospitals.
Do
May cause electronic equipment or electronic medical equipment to fail or malfunction.
When using the phone in a medical facility, be sure to observe the regulations of the facility.
If you do prohibited act such as using the phone in an airplane, you will be punished according to law. If usage of the terminal in an aircraft is admitted by setting airplane mode, etc., use the terminal under the direction of the airline.
When you talk by setting handsfree or ring alert is sounding, keep the terminal away from your
Do
ear.
And, when connecting the earphone/ microphone etc. to the terminal and play a game or music, adjust the volume moderately.
Too loud volume may cause a hearing loss. And, if you cannot hear the sound around you clearly, it may cause an accident.
If you have weak heart, be careful when setting the Vibrate alert (vibration) or alert volume
Do
setting.
May cause harmful effect on heart.
When you use electronic medical equipment, check with the equipment manufacturer to
Do
determine how the device is affected by radio waves before using.
May cause harmful effect on electronic medical equipment etc.
Turn the terminal OFF near high-precision electronic control equipment or electronic
Do
equipment using low-power signals.
May cause the equipment to fail or malfunction.
*Examples of electronic equipment to avoid.
Hearing aids, implanted pacemakers or defibrillators, other electronic medical equipment, fire alarms, automatic doors and other automatic control equipment.
Users wearing implanted pacemakers or defibrillators or other electronic medical equipment should check with the manufacturer or sales outlet about the effect of radio frequencies on the equipment.
4 |
Contents/Precautions |
When the display or camera lens is accidentally broken, be careful of fragments of broken glass
Do
or exposed internal parts of the terminal.
Surface of display and camera lens are made of plastic panel so as not to be shattered, however, if you mistakenly touch broken or exposed parts, you may be injured.
CAUTION
Do not swing the terminal by the antenna, strap,
etc.
Don’t May cause accident such as injury to yourself or others by hitting.
Do not use the damaged terminal.
May cause fire, burns, injuries, electric shock.
Don’t
When using the motion sensor, check the safety
around you, hold the terminal firmly, and do not Don’t shake it unnecessarily.
May cause accident such as injuries.
If the display part is accidentally broken and the
liquid crystal leaks out, do not make the Don’t substance contact with your skin of face or
hands.
May cause loss of sight or skin problems.
If the liquid crystal gets into your eyes or mouth, rinse it with clean water and see a doctor immediately.
And, if the liquid adheres to skin or clothing, use alcohol etc. to wipe it off, then wash with soap.
To use the terminal in car, check with automobile manufacturer or dealer to determine
Do
how the device is affected by radio waves before using.
In rare cases, using the phone in some vehicle models can cause the vehicle's electronic equipment to malfunction. In that case, stop using the terminal immediately.
The use of the terminal may cause itching, rashes, eczema, or other symptoms depending
Do
on the user's physical condition. If you develop skin problems, immediately stop using the phone, and see a doctor.
When watching the display, take a certain distance from the display in a fully bright place.
Do
May reduce visual acuity.
Handling battery pack
■Check that the battery type matches the type displayed on the battery pack label.
Display |
Battery type |
|
|
Li-ion 00 |
Li-ion battery |
|
|
|
DANGER |
|
|
Do not connect a wire or other metal objects to |
|
Don’t |
the jack. And, do not carry or store the terminal |
|
with objects like a metal necklace. |
||
|
May cause battery pack to ignite, burst, heat or leak. |
|
|
|
|
|
Check the orientation of the battery pack to |
|
Don’t |
attach to the terminal, and do not try to force the |
|
battery pack onto the terminal if you are having |
||
|
trouble attaching it. |
|
|
May cause battery pack to ignite, burst, heat or leak. |
|
|
|
|
|
Do not throw the battery pack into the fire. |
|
Don’t |
May cause battery pack to ignite, burst, heat or leak. |
|
|
||
|
|
|
|
Do not nail the battery pack, hit with a hammer |
|
Don’t |
or step on it. |
|
May cause battery pack to ignite, burst, heat or leak. |
||
|
|
|
|
If the battery pack's fluid etc. contacts eyes, |
|
Do |
immediately flush the eyes with clean water and |
|
see a doctor right away. Do not rub the eyes. |
||
|
||
|
May cause loss of sight. |
|
|
WARNING |
|
|
If the battery pack seems to have abnormalities |
|
Don’t |
such as deformation or scratches due to falling, |
|
never use it. |
||
|
May cause battery pack to ignite, burst, heat or leak. |
|
|
|
|
|
If the battery pack leaks or gives off a strange |
|
Do |
smell, immediately remove it from the vicinity of |
|
open flames. |
||
|
||
|
The vapors from leaking battery pack fluid may |
|
|
ignite or explode. |
|
|
|
|
|
Be careful not to let your pet bite the battery |
|
Do |
pack. |
|
May cause battery pack to ignite, burst, heat or leak. |
||
|
5 |
Contents/Precautions |
Loading...
