the Scraper Mixer
Instruction Booklet
Suits all BEM410 models
CONGRATULATIONS
on the purchase of your new Breville Scraper Mixer
Contents
4 Breville recommends safety first
7 Know your Mixer
10Assembly and operation of your Mixer
14 Care, cleaning and storage
16 Measuring and weighing
18 Cooking information
20 Hints and tips
24 The vital ingredients
32 Recipes
3
Breville recommends safety first
At Breville we are very safety conscious. We design and manufacture consumer products with the safety of you, our valued customer, foremost in mind. In addition we ask that you exercise a degree of care when using any electrical appliance and adhere to the following precautions.
Important safeguards
Read all instructions BEFORE USE AND SAVE FOR FUTURE REFERENCE
•Carefully read all instructions before operating and save for future reference.
•Remove any packaging material and promotional stickers before using the mixer for the first time.
•Do not place the mixer near the edge of a bench or table during operation. Ensure the surface is level, clean and free of water, flour, etc. Vibration during operation may cause the appliance
to move.
•Do not place this appliance on or near a hot gas or electric burner, or where it could touch a heated oven.
•Use only the beater, dough hook or whisk supplied with this mixer.
•Never operate the mixer whilst the mixer head is in the raised position.
•Ensure the speed Control Dial is in the ‘0 – Stand By’ position and the mixer is switched off and unplugged from the power outlet before attaching the beater, dough hook or whisk.
•Do not operate the appliance continuously on heavy loads for more than 3 minutes.
•Handle the mixer and attachments with care. Never place your fingers inside the mixing bowl or near the beater, dough hook or whisk during operation.
•Keep hands, hair, clothing, as well as, spatulas and other utensils away from moving beater, dough hook or whisk during operation.
•Should an object such as a spoon or spatula fall into the bowl while mixing, immediately ensure the speed Control Dial is in the ‘0 – Stand By’ position, turn the Mixer off, unplug at the power outlet and remove the object.
•Do not place hands in the mixing bowl unless the appliance is disconnected from the power outlet. Ensure the speed Control Dial is in the ‘0 – Stand By’ position, the mixer is switched off and unplugged from the power outlet before removing the beater, dough hook or whisk.
•Ensure the motor and beater, dough hook or whisk has completely stopped before disassembling.
•Always remove the beater, dough hook or whisk from the mixer before cleaning.
•Ensure the Mixer motor head is locked into the horizontal (closed) position when not in use and before storing.
•Always ensure the speed control dial is in the ‘0 – Stand By’ position, the power is switched off at the power outlet and the cord is unplugged from the power outlet before attempting to move the appliance, when the mixer is not in use and before cleaning or storing.
•Do not use the mixer on metal surfaces, for example a sink drain board.
•To protect against electric shock do not immerse cord, plug or mixer in water or any other liquid.
4
Breville recommends safety first
•Do not move the mixer whilst in operation.
•Do not leave the mixer unattended when in use.
•Keep the appliance clean. Follow
the cleaning instructions provided in this book.
5
Breville recommends safety first
IMPORTANT SAFEGUARDS FOR ALL ELECTRICAL APPLIANCES
•Fully unwind the power cord before use.
•Do not let the power cord hang over the edge of a bench or table, touch hot surfaces or become knotted.
•To protect against electric shock do not immerse the power cord, power plug or appliance in water or any other liquid.
•The appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
•Children should be supervised to ensure that they do not play with the appliance.
•It is recommended to regularly inspect the appliance. To avoid a hazard do not use the appliance if power cord, power plug or appliance becomes damaged in any way. Return the entire appliance to the nearest authorised Breville Service Centre for examination and/or repair.
•Any maintenance other than cleaning should be performed at an authorised Breville Service Centre.
•This appliance is for household use only. Do not use this appliance for anything other than its intended use. Do not use in moving vehicles or boats. Do not use outdoors. Misuse may cause injury.
•The installation of a residual current device (safety switch) is recommended to provide additional safety protection when using electrical appliances. It
is advisable that a safety switch with a rated residual operating current not exceeding 30mA be installed in the electrical circuit supplying the appliance. See your electrician for professional advice.
IMPORTANT
Ensure the speed control dial is in the ‘0 – stand by’ position, the mixer is switched off at the power outlet and unplugged from the power outlet before attaching the beater, whisk or dough hook.
Never operate the mixer whilst the mixer head is in the raised open position.
SAVE THESE INSTRUCTIONS
6
KNOW
Breville Scraper Mixer
KNOW YOUR BREVILLE Scraper Mixer
D
A
E
B
C
A.Mixer motor head
Powerful 700 watt motor for powerful and thorough mixing results
B.Large 4.7L stainless steel mixing bowl
For mixing your ingredients
C.Die cast metal mixer stand
The heavy duty die cast metal stand keeps the mixer secure and stable during operation
D.Speed control dial with 6 speed settings
E.Tilt back hinge button
The mixer motor head tilts back and locks into position to allow easy removal of the mixing bowl and attachments
F
F.Bowl locking recess
The bowl locking recess allows the bowl to be securely locked into place for safety and stability when the mixer is in operation
G.Scraper beater
Scrapes the sides and bottom of the bowl for exceptionally thorough mixing, of cake and biscuit batter, pastry, frosting and more
H.Wire whisk
Consistently mixes and aerates for egg whites, cream and thin batters
I.Dough hook Effectively kneads heavy dough for bread and pizza
8
KNOW YOUR BREVILLE Scraper Mixer
G
H
I
About your scraper beater
The Breville Scraper Beater folds ingredients and continuously scrapes down the sides and bottom of the bowl for exceptionally thorough mixing. It virtually eliminates
the need to scrape the bowl by hand with a spatula and cuts mixing time up to 60%.
Under-mixed batters produce poorly baked results, resulting in collapsing, unevenness of crumb, holes, low rising, streaking and course textures. the Scraper Beater will help to ensure a thoroughly mixed batter for your favourite cakes, biscuits, frosting and more.
Many of the recipes provided in your instruction booklet specify the use of the Flat Beater, however, for exceptionally thorough mixing and to save time, you can use your Scraper Beater instead.
9
ASSEMBLY AND OPERATION
of your Breville Scraper Mixer
assembly and operation
Assembling the Mixer
Before using your Breville mixer for the first time, remove any packaging material and promotional labels.
Ensure the speed control dial is in the ‘0 – Stand By’ position, the mixer is switched off at the power outlet and the power cord is unplugged.
Remove the mixing bowl, scraper beater, whisk and dough hook and wash in warm soapy water with a soft cloth. Rinse and dry thoroughly. The bowl and the attachments may be washed in the dishwasher.
NOTE
When first using your Breville mixer, you may notice an odour coming from the motor. This is normal and will dissipate with use.
Attaching the bowl
1.Place the mixer stand on a level, dry surface such as a bench top. The mixer motor head should be in the horizontal (closed) position.
2.Raise the mixer motor head by depressing the tilt back hinge button, then lift the mixer motor head up until it tilts back and locks into the open position.
3.Insert the mixing bowl into the bowl locking recess of the mixer stand and turn clockwise until the bowl locks securely into place.
NOTE
To remove or insert the mixing bowl, the mixer motor head must be raised and locked into the open position.
11
assembly and operation
Attaching the SCRAPER Beater, Dough Hook or Whisk
1.Ensure the mixer motor head is in the raised open position. Align the groove in the top of the scraper beater, dough hook or whisk with the locking pin on the spindle extending down from the mixer motor head.
2.Press the scraper beater, dough hook or whisk upwards and turn clockwise until it locks securely onto the locking pin on the spindle.
3.Lower the mixer motor head by depressing the tilt back hinge button and pushing the mixer motor head down until it locks into the horizontal (closed) position.
NOTE
When ingredients are in the mixing bowl, the scraper beater may make a slight noise as it scrapes the sides and bottom of the bowl. This is normal and should not cause concern.
Do not turn the mixer on with the scraper beater in place if the mixing bowl is empty. This will cause the scraper beater to make a loud noise as it scrapes the bowl.
Operating the Mixer
Planetary Mixing Action
By replicating a similar mixing action used by commercial mixers in bakeries and patisseries, the Breville mixer head rotates around the bowl whilst rotating the beater in the opposite direction. This ensures
a superior and thorough mixing result without the need for a rotating bowl.
1.Ensure the speed control dial is set to the ‘0 – Stand By’ position, plug the cord into a 230/240v power outlet and switch the power ‘ON’ at the power outlet.
2.Add ingredients to the mixing bowl as indicated in the recipe.
3.Always begin mixing by selecting a low
12
assembly and operation
speed setting on the speed control dial. This will prevent ingredients splattering. Increase the speed as suited to the mixing task. The speed setting can be adjusted during operation by moving the dial forward and back. Use the mixing guide as a reference.
4.If necessary, stop the mixer during operation and scrape any food mixture down the sides of the mixing bowl with a spatula.
5.When mixing is complete, turn the speed control dial to the ‘0 – Stand By’ position, switch the appliance off at the power outlet and unplug the cord.
6.Raise the mixer motor head by depressing the tilt back button and lift the mixer motor head up until it tilts back and locks into the open position.
7.Remove the scraper beater/dough hook/ whisk by holding the mixer motor head and pressing the attachment upwards on the spindle. Turn the attachment anticlockwise to release it from the pin on the spindle.
Use a soft plastic spatula to remove mixture from the scraper beater, dough hook or whisk.
NOTE
When lowering or lifting the mixer, always support the motor head with your other hand to prevent from free-falling.
8.Remove the mixing bowl from the indented bowl locking recess of the mixer stand and turn anti-clockwise until the bowl releases. Use a soft plastic spatula to remove mixture from the mixing bowl.
9.Lower the mixer motor head by depressing the tilt back hinge button and pushing the mixer motor head down until it locks into the horizontal (closed) position.
WARNING
Avoid contact with scraper beater/ dough hook/whisk during operation. Keep hands, hair, clothing, spatulas and other utensils away from scraper beater/dough hook/whisk to prevent personal injury or damage to the mixer.
13
CARE, CLEANING AND STORAGE
of your new Breville Scraper Mixer
CARE AND CLEANING
Cleaning after use
1.Always ensure the speed control dial is in the ‘0 – Stand By’ position, the mixer is switched off at the power outlet and the power cord is unplugged.
2.Remove the scraper beater, dough hook or whisk and mixing bowl from the mixer. Follow instructions in ‘Assembly and Operation' of your mixer. Wipe the mixer motor head and mixer stand with a soft, damp cloth then dry thoroughly.
3.Wipe any excess food particles from the power cord.
4.Wash the bowl, scraper beater, dough hook, and whisk in warm soapy water with a soft cloth or they can be washed in the dishwasher. Rinse and dry thoroughly.
A small bottle brush can be used to clean inside the neck of the attachments if needed.
NOTE
Do not use abrasive scouring pads or cleaners when cleaning the mixing bowl, scraper beater, dough hook or whisk as these may scratch the surface. Also ensure that the attachments are not soaked in water for extended periods of time, for example several hours or overnight, as this may damage the finish.
NOTE
Do not wash or immerse the mixer motor head and mixer stand in water or any other liquid. Clean with a soft, damp cloth and dry thoroughly. Do not allow water or any liquid to enter the gear system as damage may result.
Storage
Your mixer should be kept in a convenient position on your kitchen bench top or in an accessible cupboard.
Always ensure the speed control dial is in the ‘0 – Stand By’ position, the mixer is switched off at the power point and the power cord is unplugged.
Store the mixing bowl in the bowl locking recess in the mixer stand.
Place the attachments inside the mixing bowl and lower the mixer motor head into the horizontal (closed) position.
NOTE
The motor head cannot be taken off the base for any purpose.
WARNING
Never immerse the mixer, power cord or plug in water or any other liquid.
15
MEASURING AND
WEIGHING
with your new Breville Scraper Mixer
MEASURING AND WEIGHING
Care should be taken when weighing and measuring ingredients to achieve accuracy and consistency. Recipes in this instruction book have been developed using Australian metric weights and measurements.
Australian metric |
|
measurements |
ml |
|
|
1 teaspoon |
5 |
1 tablespoon |
20 |
1 cup |
250 |
|
|
|
|
For New Zealand |
|
customers — New Zealand |
|
metric measurements |
ml |
1 teaspoon |
5 |
1 tablespoon |
15 |
1 cup |
250 |
|
|
The New Zealand tablespoon is 5ml less than the Australian tablespoon, so care should
be taken when measuring ingredients to compensate for the variance. For example, 1 Australian tablespoon = 1 New Zealand tablespoon + 1 New Zealand teaspoon.
It is important to note that New Zealand ingredients, especially flour and yeast, can differ from Australian equivalents. Suitable New Zealand Products have been listed in the 'Vital Ingredients' section of this booklet.
We suggest these New Zealand products be substituted for the Australian products in the Recipe Section.
For further New Zealand bread making assistanceTelephone: 0800 273 845.
Metric weighing scales
For consistent results it is recommended that a set of metric weighing scales be used to weigh larger quantities as they provide greater accuracy than measuring cups.
Tare (zero) the scales with the container in position then spoon or pour ingredients in until the desired weight is achieved.
NOTE
In general, water weighs the same in grams as it measures in millilitres.
Metric measuring cups and spoons
If using graduated metric measuring cups, it is important to spoon the dry ingredients loosely into the required cup. Do not tap the cup on the bench or pack the ingredients into the cup unless otherwise directed. Level the top of the cup with a knife. When using graduated metric measuring spoons, level the top of the spoon with a straight edged knife or spatula.
Metric liquid measuring jugs
If using a graduated, metric measuring jug, place jug on a flat surface and check for
accuracy at eye level.
IMPORTANT
Do not use tableware cups or spoons. Do not use tableware jugs or measuring cups.
17
COOKING
INFORMATION
for your new Breville Scraper Mixer
COOKING INFORMATION
The following oven temperature settings are included as a guide. These settings may need to be adjusted to suit the individual oven.
NOTE
If using fan forced ovens be sure to turn the temperature down by 1520°C. Also check recipes at the back of this book.
Thermostat Settings |
|
|
|
|
|
|
Description of oven |
Electric |
|
Gas |
|
Gas |
|
temperatures |
°C |
°F |
°C |
°F |
Mark |
|
Very slow |
120 |
|
250 |
120 |
250 |
1 |
|
|
|
|
|
|
|
Slow |
150 |
|
300 |
150 |
300 |
2 |
|
|
|
|
|
|
|
Moderately slow |
170 |
|
325 |
160 |
325 |
3 |
|
|
|
|
|
|
|
Moderate |
180 |
|
350 |
180 |
350 |
4 |
|
|
|
|
|
|
|
Moderately hot |
200 |
|
400 |
190 |
375 |
5 |
|
|
|
|
|
|
|
Hot |
220 |
|
425 |
200 |
400 |
6 |
|
|
|
|
|
|
|
Very hot |
230 |
|
450 |
230 |
450 |
7 |
|
|
|
|
|
|
|
19
HINTS AND TIPS
for your new Breville Scraper Mixer
