ASUS P5SD1-FM2 User Manual

P5SD1-FM2

Motherboard

E1951
First Edition V1

March 2005

Copyright © 2005 ASUSTeK COMPUTER INC. All Rights Reserved.

No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form
or by any means, except documentation kept by the purchaser for backup purposes, without the
express written permission of ASUSTeK COMPUTER INC. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired, modified or
altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the
serial number of the product is defaced or missing.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR
IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS
OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS
HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR
ERROR IN THIS MANUAL OR PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE, AND
SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY
OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL,
INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be registered
trademarks or copyrights of their respective companies, and are used only for identification or
explanation and to the owners’ benefit, without intent to infringe.

ii

Contents

Notices ........................................................................................................ vi

Safety information .................................................................................... vii

P5SD1-FM2 specifications summary ..................................................... viii

Chapter 1: Hardware information

1.1 Before you proceed ................................................................... 1-2

1.2 Motherboard overview ............................................................... 1-3

1.2.1 Placement direction .................................................... 1-3

1.2.2 Screw holes .................................................................. 1-3

1.2.3 Motherboard layout .................................................... 1-4

1.2.4 Layout Contents..........................................................1-5

1 .3 Central Processing Unit (CPU) .................................................. 1-7

1.3.1 Installing the CPU ........................................................1-7

1.3.2 Installing the CPU heatsink and fan ....................... 1-10

1.3.3 Uninstalling the CPU heatsink and fan ................... 1-12

1.4 System memory ...................................................................... 1-14

1.4.1 DIMM sockets location ............................................. 1-14

1.4.2 Memory Configurations ........................................... 1-14

1.4.3 Installing a DIMM ....................................................... 1-17

1.4.4 Removing a DIMM ..................................................... 1-17

1.5 Expansion slots ........................................................................ 1-18

1.5.1 Installing an expansion card .................................... 1-18

1.5.2 Configuring an expansion card ............................... 1-18

1.5.3 Interrupt assignments ............................................. 1-19

1.5.4 PCI slots..................................................................... 1-20

1.5.5 PCI Express x16 slot ................................................ 1-20

1. 6 Jumpers .................................................................................... 1-21

1 .7 Connectors ............................................................................... 1-25

1.7.1 Rear panel connectors ............................................. 1-25

1.7.2 Internal connectors .................................................. 1-27

iii

Contents

Chapter 2: BIOS setup

2 .1 Managing and updating your BIOS ........................................... 2-2

2.1.1 Creating a bootable floppy disk ................................2-2

2.1.2 ASUS EZ Flash utility................................................... 2-3

2.1.3 AFUDOS utility ............................................................. 2-4

2.1.4 ASUS CrashFree BIOS 2 utility ................................... 2 - 6

2 .2 BIOS setup program ................................................................ 2-10

2.2.3 Navigation keys ........................................................ 2-11

2.2.1 BIOS menu screen .................................................... 2-11

2.2.2 Menu bar .................................................................... 2-11

2.2.4 Menu items ................................................................ 2-12

2.2.5 Sub-menu items ....................................................... 2-12

2.2.6 Configuration fields .................................................. 2-12

2.2.7 Pop-up window ......................................................... 2-12

2.2.8 Scroll bar ................................................................... 2-12

2.2.9 General help .............................................................. 2-12

2 .3 Main menu ................................................................................ 2-13

2.3.1 System Time ............................................................. 2-13

2.3.2 System Date ............................................................. 2-13

2.3.3 Legacy Diskette A .................................................... 2-13

2.3.4 Primary, Secondary, Third, and Fourth

IDE Master/Slave ...................................................... 2-14

2.3.5 OnBoard PCI S-ATA Controller ................................ 2-15

2.3.6 System Information.................................................. 2-16

2.4 Advanced menu ....................................................................... 2-17

2.4.1 CPU Configuration .................................................... 2-18

2.4.2 Chipset....................................................................... 2-19

2.4.3 Onboard Devices Configuration .............................. 2-22

2.4.4 PCI PnP ....................................................................... 2-23

2.4.5 USB Configuration .................................................... 2-25

iv

Contents

2 .5 Power menu ............................................................................. 2-26

2.5.1 ACPI Aware O/S ........................................................ 2-26

2.5.2 Suspend Mode .......................................................... 2-26

2.5.3 Repost Video on S3 Resume .................................. 2-26

2.5.4 ACPI 2.0 Support ...................................................... 2-26

2.5.5 ACPI APIC Support .................................................... 2-26

2.5.6 APM Configuration.................................................... 2-27

2.5.7 Hardware Monitor ..................................................... 2-28

2.6 Boot menu ................................................................................ 2-30

2.6.1 Boot Settings Configuration ................................... 2-30

2.6.2 Security ..................................................................... 2-32

2.7 Exit menu .................................................................................. 2-34

v

Notices

Federal Communications Commission Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:

•

This device may not cause harmful interference, and

•

This device must accept any interference received including interference
that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with
manufacturer’s instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:

•

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and receiver.

•

Connect the equipment to an outlet on a circuit different from that to
which the receiver is connected.

•

Consult the dealer or an experienced radio/TV technician for help.

The use of shielded cables for connection of the monitor to the graphics
card is required to assure compliance with FCC regulations. Changes or
modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate
this equipment.

Canadian Department of Communications Statement

This digital apparatus does not exceed the Class B limits for radio noise
emissions from digital apparatus set out in the Radio Interference
Regulations of the Canadian Department of Communications.

This class B digital apparatus complies with Canadian
ICES-003.

vi

Safety information

Electrical safety

•

To prevent electrical shock hazard, disconnect the power cable from
the electrical outlet before relocating the system.

•

When adding or removing devices to or from the system, ensure that
the power cables for the devices are unplugged before the signal cables
are connected. If possible, disconnect all power cables from the existing
system before you add a device.

•

Before connecting or removing signal cables from the motherboard,
ensure that all power cables are unplugged.

•

Seek professional assistance before using an adapter or extension cord.
These devices could interrupt the grounding circuit.

•

Make sure that your power supply is set to the correct voltage in your
area. If you are not sure about the voltage of the electrical outlet you
are using, contact your local power company.

•

If the power supply is broken, do not try to fix it by yourself. Contact a
qualified service technician or your retailer.

Operation safety

•

Before installing the motherboard and adding devices on it, carefully read
all the manuals that came with the package.

•

Before using the product, make sure all cables are correctly connected
and the power cables are not damaged. If you detect any damage,
contact your dealer immediately.

•

To avoid short circuits, keep paper clips, screws, and staples away from
connectors, slots, sockets and circuitry.

•

Avoid dust, humidity, and temperature extremes. Do not place the
product in any area where it may become wet.

•

Place the product on a stable surface.

•

If you encounter technical problems with the product, contact a qualified
service technician or your retailer.

vii

P5SD1-FM2 specifications summary

CPU

Chipset

Front Side Bus
Memory

Expansion slots

Storage

Audio

LGA775 socket for Intel® Pentium® 4/Celeron processor

®

Compatible with Intel

Performance Universal FMB

Supports Intel® Hyper-Threading Technology
Northbridge: SiS 649

Southbridge: SiS 965
800/533 MHz
2 x 184-pin DIMM sockets support unbufferred non-ECC

400/333 MHz DDR SDRAM memory modules

1 x PCI Express x16 slot for discrete graphics card
3 x PCI slots

SiS 965 Southbridge supports:

- 4 x Ultra DMA 100/66/33 hard disk drives

- 4 x Serial ATA hard disk drives with RAID 0, RAID 1,
RAID 0+1 (10), and JBOD configuration

ADI AD1888 SoundMax

®

6-channel CODEC

S/PDIF out interface support

LAN
USB
IEEE 1394

BIOS features

Special features

Rear panel

Realtek® RTL 8201CL 10/100 Mbps LAN PHY
Supports up to 8 USB 2.0 ports
VT6307 controller supports:

- 2 x IEEE 1394a ports
4 Mb LPC Flash ROM, AMI BIOS, Green, PnP, DMI2.0,

SM BIOS 2.3, WfM2.0, ACPI 2.0a

ASUS Q-Fan 1.5
ASUS EZ Flash

1 x PS/2 mouse port
1 x PS/2 keyboard port
1 x IEEE 1394a port
1 x Parallel port
1 x LAN (RJ-45) port
4 x USB 2.0 ports
1 x Serial port
1 x Coaxial S/PDIF port
6-channel audio ports

viii

(continued on the next page)

P5SD1-FM2 specifications summary

Internal
connectors

Support CD
contents

Form factor

*Specifications are subject to change without notice.

1 x Floppy disk drive connector
1 x Power LED connector
2 x IDE connectors
4 x Serial ATA connectors
1 x CPU fan connector
1 x Chassis fan connector
1 x Speaker out connector
2 x USB 2.0 connectors
1 x 24-pin ATX power connector
1 x 4-pin ATX 12 V power connector
1 x Internal audio connector
1 x Front panel audio connector
1 x System panel connector

Device drivers

uATX form factor: 9.6 in x 9.0 in (24.4 cm x 23 cm)

ix

x

This chapter lists the hardware setup
procedures that you have to perform
when installing system components.
It includes description of the jumpers
and connectors on the motherboard.

information

Hardware

1

1.1 Before you proceed

Take note of the following precautions before you install motherboard
components or change any motherboard settings.

• Unplug the power cord from the wall socket before touching any
component.

• Use a grounded wrist strap or touch a safely grounded object or a
metal object, such as the power supply case, before handling
components to avoid damaging them due to static electricity

• Hold components by the edges to avoid touching the ICs on them.

• Whenever you uninstall any component, place it on a grounded
antistatic pad or in the bag that came with the component.

• Before you install or remove any component, ensure

that the ATX power supply is switched off or the
power cord is detached from the power supply. Failure

to do so may cause severe damage to the motherboard, peripherals,
and/or components.

1-2 Chapter 1: Hardware information

1.2 Motherboard overview

Before you install the motherboard, study the configuration of your chassis
to ensure that the motherboard fits into it. Refer to the chassis
documentation before installing the motherboard.

Make sure to unplug the power cord before installing or removing the
motherboard. Failure to do so can cause you physical injury and damage
motherboard components.

1.2.1 Placement direction

When installing the motherboard, make sure that you place it into the
chassis in the correct orientation. The edge with external ports goes to the
rear part of the chassis as indicated in the image below.

1.2.2 Screw holes

Place six (6) screws into the holes indicated by circles to secure the
motherboard to the chassis.

Do not overtighten the screws! Doing so can damage the motherboard.

Place this side towards
the rear of the chassis

®

P5SD1-FM2

ASUS P5SD1-FM2 1-3

1.2.3 Motherboard layout

PS/2KBMS

T: Mouse
B: Keyboard

F_USB12

SPDIF_O

PARALLEL PORT

COM1

LAN_USB34

Top:Line In
Center:Line Out
Below:Mic In

VIA

VT6307

AD1888

KBPWR

ATX12V

USBPW12
USBPW34

RTL8201CL

FP_AUDIO

IE1394_2

LGA775

PCIEX16

PCI1

PCI2

PCI3

AUX

USBPW78

SiS

649

CR2032 3V
Lithium Cell

CMOS Power

CPU_FAN

®

USBPW56

USB78USB56

CHA_FAN

I/O

Super

FLOPPY

DDR DIMM1 (64 bit,184-pin module)

DDR DIMM2 (64 bit,184-pin module)

EATXPWR

P5SD1-FM2

PRI_IDE

SEC_IDE

SATA2
SATA4

SiS
965

CLRTC

PLED

SATA1
SATA3

F_PANEL

BIOS

PWDSKP

BIOSREC

4Mb

BUZZER

SPEAKER

1-4 Chapter 1: Hardware information

1.2.4 Layout Contents

Slots Page

1. DDR DIMM slots 1-14

2. PCI slots 1-20

3. PCI Express slot 1-20

Jumpers Page

1. Clear RTC RAM (CLRTC) 1-21

2. USB device wake-up (3-pin USBPW12, USBPW34, USBPW56, USBPW78) 1-22

3. Keyboard power (3-pin KBPWR) 1-23

4. Clear password (3-pin PWSKP) 1-23

5. BIOS Recovery (3-pin BIOSREC) 1-24

Rear panel connectors Page

1. PS/2 mouse port 1-25

2. Parallel port 1-25

3. LAN (RJ-45) port 1-25

4. Rear Speaker Out port 1-25

5. Side Speaker Out port 1-25

6. Line In port 1-25

7. Line Out port 1-25

8. Microphone port 1-25

9. USB 2.0 ports 3 and 4 1-26

10. Serial port 1-26

11. USB 2.0 ports 1 and 2 1-26

12. PS/2 keyboard port 1-26

ASUS P5SD1-FM2 1-5

Internal connectors Page

1. Floppy disk drive connector (34-1 pin FLOPPY) 1-27

2. Power LED connector (3-1 pin PLED) 1-27

3. IDE connectors (40-1 pin PRI_IDE, SEC_IDE) 1-28

4. Serial ATA connectors (7-pin SATA1 [black], SATA2 [black]) 1-29

5. CPU and Chassis fan connectors (4-pin CPU_FAN, 3-pin CHA_FAN) 1-30

6. Speaker out connector (4-pin SPEAKER) 1-30

7. USB connectors (10-1 pin USB56, USB78) 1-31

8. ATX power connector (24-pin EATXPWR) 1-32

9. ATX 12V power connector (4-pin ATX12V) 1-32

10. Internal audio connector (4-pin AUX) 1-33

11. Front panel audio connector (10-1 pin FP_AUDIO) 1-33

12. System panel connector (10-1 pin F_PANEL) 1-34

- System power LED (Green 2-pin PLED)

- Hard disk activity (Red 2-pin HDLED)

- Power/Soft-off button(Black 2-pin PWRSW)

- Reset switch (Blue 2-pin RESET)

1-6 Chapter 1: Hardware information

1.3 Central Processing Unit (CPU)

The motherboard comes with a surface mount LGA775 socket designed for
the Intel® Pentium® 4 processor in the 775-land package.

• Your boxed Intel® Pentium® 4 LGA775 processor package should
come with installation instructions for the CPU, heatsink, and the
retention mechanism. If the instructions in this section do not match
the CPU documentation, follow the latter.

•

Upon purchase of the motherboard, make sure that the PnP cap is
on the socket and the socket contacts are not bent. Contact your
retailer immediately if the PnP cap is missing, or if you see any
damage to the PnP cap/socket contacts/motherboard components.
ASUS will shoulder the cost of repair only if the damage is shipment/
transit-related.

•

Keep the cap after installing the motherboard. ASUS will process
Return Merchandise Authorization (RMA) requests only if the
motherboard comes with the cap on the LGA775 socket.

• The product warranty does not cover damage to the socket
contacts resulting from incorrect CPU installation/removal, or
misplacement/loss/incorrect removal of the PnP cap.

1.3.1 Installing the CPU

To install a CPU:
1 . Locate the CPU socket on the motherboard.

®

P5SD1-FM2

P5SD1-FM2 CPU Socket 775

Before installing the CPU, make sure that the socket box is facing
towards you and the load lever is on your left.

ASUS P5SD1-FM2 1-7

2. Press the load lever with your thumb (A), then move it to the left (B)
until it is released from the retention tab.

Retention tab

A

Load lever

PnP cap

To prevent damage to the socket pins, do not remove the PnP cap
unless you are installing a CPU.

3 . Lift the load lever in the

direction of the arrow to a 135º
angle.

4. Lift the load plate with your
thumb and forefinger to a
100º angle (A), then push
the PnP cap from the load
plate window to remove (B).

B

This side of the
socket box should
face you.

B

A

Load plate

5 . Position the CPU over

the socket, making
sure that the gold
triangle is on the
bottom-left corner of
the socket. The
socket alignment key

Alignment key

should fit into the
CPU notch.

1-8 Chapter 1: Hardware information

Gold triangle mark

6 . Close the load plate (A), then

push the load lever (B) until
it snaps into the retention
tab.

B

The CPU fits in only one correct orientation. DO NOT force the CPU into
the socket to prevent bending the connectors on the socket and
damaging the CPU!

Notes on Intel® Hyper-Threading Technology

• This motherboard supports Intel® Pentium® 4 CPUs in the 775-land
package with Hyper-Threading Technology.

A

• Hyper-Threading T echnology is supported under Windows

2.4.x (kernel) and later versions only . Under Linux, use the Hyper-Threading
compiler to compile the code. If you are using any other operating systems,
disable the Hyper-Threading Technology item in the BIOS to ensure system
stability and performance.

®

• Installing Windows

• Make sure to enable the Hyper-Threading T echnology item in BIOS before
installing a supported operating system.

• For more information on Hyper-Threading T echnology , visit www .intel.com/
info/hyperthreading.

XP Service Pack 2 or later version is recommended.

®

XP and Linux

To use the Hyper-Threading Technology on this motherboard:

®

1 . Install an Intel

Pentium® 4 CPU that supports Hyper-Threading

Technology.

2 . Power up the system and enter the BIOS Setup (see Chapter 2: BIOS

setup). Under the Advanced Menu, make sure that the item
Hyper-Threading Technology is set to Enabled. The item appears only
if you installed a CPU that supports Hyper-Threading Technology.

3. Reboot the computer.

ASUS P5SD1-FM2 1-9

1.3.2 Installing the CPU heatsink and fan

The Intel® Pentium® 4 LGA775 processor requires a specially designed
heatsink and fan assembly to ensure optimum thermal condition and
performance.

•

When you buy a boxed Intel® Pentium® 4 processor, the package
includes the CPU fan and heatsink assembly. If you buy a CPU
separately, make sure that you use only Intel
multi-directional heatsink and fan.

•

Your Intel® Pentium® 4 LGA775 heatsink and fan assembly comes in
a push-pin design and requires no tool to install.

•

If you purchased a separate CPU heatsink and fan assembly, make
sure that you have properly applied Thermal Interface Material to the
CPU heatsink or CPU before you install the heatsink and fan
assembly.

Make sure that you have installed the motherboard to the chassis before
you install the CPU fan and heatsink assembly.

®

-certified

To install the CPU heatsink and fan:
1 . Place the heatsink on top of the

installed CPU, making sure that
the four fasteners match the
holes on the motherboard.

Orient the heatsink and fan
assembly such that the CPU
fan cable is closest to the
CPU fan connector.

Narrow end
of the groove

Motherboard hole

Fastener

Make sure to orient each fastener with the narrow end of the groove
pointing outward. (The photo shows the groove shaded for emphasis.)

1-10 Chapter 1: Hardware information

2. Push down two fasteners at
a time in a diagonal
sequence to secure the
heatsink and fan assembly in
place.

B

A

B

A

A

B

B

A

3 . Connect the CPU fan cable to the connector on the motherboard

labeled CPU_FAN.

CPU_FAN

CPU FAN PWM

CPU FAN IN

®

P5SD1-FM2

CPU FAN PWR

GND

P5SD1-FM2 CPU fan connector

Do not forget to connect the CPU fan connector! Hardware monitoring
errors can occur if you fail to plug this connector.

ASUS P5SD1-FM2 1-11

1.3.3 Uninstalling the CPU heatsink and fan

To uninstall the CPU heatsink and fan:
1 . Disconnect the CPU fan

cable from the connector on
the motherboard.

2. Rotate each fastener
counterclockwise.

3 . Pull up two fasteners at a

time in a diagonal sequence
to disengage the heatsink
and fan assembly from the
motherboard.

A

B

A

B

A

B

B

A

1-12 Chapter 1: Hardware information

4. Carefully remove the
heatsink and fan assembly
from the motherboard.

5. Rotate each fastener
clockwise to ensure correct
orientation when
reinstalling.

Narrow end of the groove

The narrow end of the
groove should point
outward after resetting.
(The photo shows the
groove shaded for
emphasis.)

ASUS P5SD1-FM2 1-13

1.4 System memory

1.4.1 DIMM sockets location

The motherboard comes with two 184-pin Double Data Rate (DDR) Dual
Inline Memory Modules (DIMM) sockets.

The following figure illustrates the location of the sockets:

DIMM1

DIMM2

®

P5SD1-FM2

80 Pins 104 Pins

P5SD1-FM2 184-pin DDR DIMM sockets

1.4.2 Memory Configurations

You may install 256 MB, 512 MB and 1 GB unbuffered non-ECC DDR DIMMs
into the DIMM sockets using the memory configurations in this section.

• Always install DIMMs with the same CAS latency. For optimum
compatibility, we recommend that you obtain memory modules from
the same vendor. Refer to the DDR Qualified Vendors List on the
next page for details.

• Due to chipset resource allocation, the system may detect less than
2 GB system memory when you installed two 1 GB DDR memory
modules.

• This motherboard does not support memory modules made up of
128 Mb chips or double sided x16 memory modules.

1-14 Chapter 1: Hardware information

Recommended memory configurations

Sockets

Mode DIMM_A1 DIMM_A2

(black) (black)

Single-channel (1) Installed —

(2) — Installed
(3)* Installed Installed

* Use only identical DDR DIMM pairs.

ASUS P5SD1-FM2 1-15

1.4.3 Installing a DIMM

Make sure to unplug the power supply before adding or removing DIMMs
or other system components. Failure to do so may cause severe damage
to both the motherboard and the components.

1 . Unlock a DIMM socket by

pressing the retaining clips
outward.

2 . Align a DIMM on the socket such

that the notch on the DIMM
matches the break on the
socket.

A DDR DIMM is keyed with a notch so that it fits in only one direction.
DO NOT force a DIMM into a socket to avoid damaging the DIMM.

2

DDR DIMM notch

1

1

Unlocked retaining clip

3 . Firmly insert the DIMM into the

socket until the retaining clips
snap back in place and the DIMM
is properly seated.

1.4.4 Removing a DIMM

To remove a DIMM:

1 . Simultaneously press the

retaining clips outward to unlock
the DIMM.

Support the DIMM lightly with your fingers when pressing the retaining
clips. The DIMM might get damaged when it flips out with extra force.

Locked Retaining Clip

1

DDR DIMM notch

2

1

2 . Remove the DIMM from the socket.

1-16 Chapter 1: Hardware information

1.5 Expansion slots

In the future, you may need to install expansion cards. The following
sub-sections describe the slots and the expansion cards that they support.

Make sure to unplug the power cord before adding or removing
expansion cards. Failure to do so may cause you physical injury and
damage motherboard components.

1.5.1 Installing an expansion card

To install an expansion card:

1. Before installing the expansion card, read the documentation that
came with it and make the necessary hardware settings for the card.

2. Remove the system unit cover (if your motherboard is already
installed in a chassis).

3. Remove the bracket opposite the slot that you intend to use. Keep
the screw for later use.

4 . Align the card connector with the slot and press firmly until the card is

completely seated on the slot.

5 . Secure the card to the chassis with the screw you removed earlier.
6 . Replace the system cover.

1.5.2 Configuring an expansion card

After installing the expansion card, configure it by adjusting the software
settings.

1 . Turn on the system and change the necessary BIOS settings, if any.

See Chapter 2 for information on BIOS setup.

2 . Assign an IRQ to the card. Refer to the tables on the next page.
3 . Install the software drivers for the expansion card.

ASUS P5SD1-FM2 1-17

1.5.3 Interrupt assignments

Standard interrupt assignments

IRQ Priority Standard Function

0 1 System Timer
1 2 Keyboard Controller
2 - Re-direct to IRQ#9
3 1 1 Communications Port (COM2)*
4 1 2 Communications Port (COM1)*
5 1 3 IRQ holder for PCI steering*
6 1 4 Floppy Disk Controller
7 1 5 Printer Port (LPT)*
8 3 System CMOS/Real Time Clock

9 4 IRQ holder for PCI steering*
1 0 5 IRQ holder for PCI steering*
1 1 6 IRQ holder for PCI steering*
1 2 7 PS/2 Compatible Mouse Port*
1 3 8 Numeric Data Processor
1 4 9 Primary IDE Channel
1 5 1 0 Secondary IDE Channel

* These IRQs are usually available for ISA or PCI devices.

The communications port (COM2) is an optional item.

IRQ assignments for this motherboard

AB CDEFGH

PCI slot 1 shared — — — ————
PCI slot 2 — shared — — ————
PCI slot 3 — — shared — ————
PCI Express x16 slot — — — shared ————
Onboard USB 1.1 controller 0 — — — — used — — —
Onboard USB 1.1 controller 1 — — — — — used — —
Onboard USB 1.1 controller 2 — — — — — — used —
Onboard USB 2.0 controller — — — — — — — us ed
Onboard Audio — — shared — ————
Onboard IDE Controller shared — — — ————
Onboard SATA Controller — shared — — ————
Onboard LAN — — — shared ————
Onboard IEEE 1394a controller — — shared — ————
Onboard modem — — shared — ————

When using PCI cards on shared slots, ensure that the drivers support
“Share IRQ” or that the cards do not need IRQ assignments; otherwise,
conflicts will arise between the two PCI groups, making the system
unstable and the card inoperable.

1-18 Chapter 1: Hardware information

1.5.4 PCI slots

This motherboard has three PCI slots. The PCI slots support cards such as a
LAN card, SCSI card, USB card, and other cards that comply with PCI
specifications. The figure shows a LAN card installed on a PCI slot.

1.5.5 PCI Express x16 slot

This motherboard supports PCI Express x16 graphic cards that comply with
PCI Express specifications. The figure shows a graphics card installed on the
PCI Express x16 slot.

ASUS P5SD1-FM2 1-19

1.6 Jumpers

S

1 . Clear RTC RAM (CLRTC)

This jumper allows you to clear the Real Time Clock (RTC) RAM in
CMOS. You can clear the CMOS memory of date, time, and system
setup parameters by erasing the CMOS RTC RAM data. The onboard
button cell battery powers the RAM data in CMOS, which include
system setup information such as system passwords.

To erase the RTC RAM:
1 . Turn OFF the computer and unplug the power cord.

2. Remove the onboard battery.

3. Move the jumper cap from pins 1-2 (default) to pins 2-3. Keep the
cap on pins 2-3 for about 5~10 seconds, then move the cap back to
pins 1-2.

4. Reinstall the battery.

5 . Plug the power cord and turn ON the computer.
6 . Hold down the <Del> key during the boot process and enter BIOS

setup to re-enter data.

Except when clearing the RTC RAM, never remove the cap on CLRTC
jumper default position. Removing the cap will cause system boot failure!

®

P5SD1-FM2

P5SD1-FM2 Clear RTC RAM

You do not need to clear the RTC when the system hangs due to
overclocking. For system failure due to overclocking, use the C.P.R. (CPU
Parameter Recall) feature. Shut down and reboot the system so the BIOS
can automatically reset parameter settings to default values.

CLRTC

2312

Normal Clear CMO

(Default)

ASUS P5SD1-FM2 1-21

2 . USB device wake-up (3-pin USBPW12, USBPW34,

)

USBPW56, USBPW78)

Set these jumpers to +5V to wake up the computer from S1 sleep
mode (CPU stopped, DRAM refreshed, system running in low power
mode) using the connected USB devices. Set to +5VSB to wake up
from S3 and S4 sleep modes (no power to CPU, DRAM in slow refresh,
power supply in reduced power mode).

The USBPW12 and USBPW34 jumpers are for the rear USB ports. The
USBPW56 and USBPW78 jumpers are for the internal USB connectors
that you can connect to additional USB ports.

USBPW12
USBPW34

3221

®

P5SD1-FM2

+5V

USBPW78

+5V

+5VSB

(Default)

3221

+5VSB

(Default)

USBPW56

+5V

+5VSB

(Default

P5SD1-FM2 USB device wake-up

• The USB device wake-up feature requires a power supply that can
provide 500 mA on the +5VSB lead for each USB port; otherwise,
the system would not power up.

• The total current consumed must NOT exceed the power supply
capability (+5VSB) whether under normal condition or in sleep mode.

3221

1-22 Chapter 1: Hardware information

3 . Keyboard power (3-pin KBPWR)

t)

d

This jumper allows you to enable or disable the keyboard wake-up
feature. Set this jumper to pins 2-3 (+5VSB) to wake up the
computer when you press a key on the keyboard (the default is the
Space Bar). This feature requires an ATX power supply that can supply
at least 1A on the +5VSB lead, and a corresponding setting in the
BIOS.

KBPWR

2312

+5V +5VSB

®

P5SD1-FM2

(Defaul

P5SD1-FM2 Keyboard power setting

4 . Clear password (3-pin PWSKP)

Set this jumper to 1-2 (Default) if you want to enable the password
setting in the BIOS. Set this jumper to 2-3 if you want to skip the
password.

®

PWDSKP

P5SD1-FM2

Normal Clear Passwor

(Default)

2312

P5SD1-FM2 Clear password setting

ASUS P5SD1-FM2 1-23

5 . BIOS Recovery (3-pin BIOSREC)

y

The force BIOS recovery jumper allows you to force recover the BIOS
settings when the BIOS gets corrupted or destroyed.

The jumper block is on pins 1 and 2 during normal operation (default).
To force recover the BIOS, set the jumper block on pins 2 and 3.

To recover the BIOS:
1 . Turn OFF your computer and unplug the power cord.

2. Move the jumper cap from pins 1-2 (default) to pins 2-3.
3 . Insert a floppy disk with the original or updated BIOS file, and

rename the BIOS file name as P5SD1FMF.ROM.
4 . Plug the power cord and turn ON the computer.
5 . The system searches for the BIOS file in the floppy then reflashes

the BIOS.

6. When finished, shut down your computer.
7 . Replace the jumper cap from pins 2-3 to pins 1-2.

8. Reboot your computer.
9 . Hold down the <Del> key during the boot process and enter BIOS

setup to re-enter data.

®

P5SD1-FM2

P5SD1-FM2 BIOS recovery setting

BIOSREC

Normal

(Default)

2312

Recover

1-24 Chapter 1: Hardware information

1.7 Connectors

1

3 4

5
6
7

2

1.7.1 Rear panel connectors

12 8

1 . PS/2 mouse port (green). This port is for a PS/2 mouse.
2 . Parallel port. This 25-pin port connects a parallel printer, a scanner,

or other devices.

3 . IEEE 1394a port. This 6-pin IEEE 1394a port provides high-speed

connectivity for audio/video devices, storage peripherals, PCs, or
portable devices.

4 . LAN (RJ-45) port. This port allows connection to a Local Area

Network (LAN) through a network hub. Refer to the table below for
the LAN port LED indications.

5 . Line In port (blue). This port connects a tape, CD, DVD player, or

other audio sources. In 6-channel mode, the function of this port
becomes Bass/Center.

6 . Line Out port (green). This port connects a headphone or a

speaker. In 4-channel, and 6-channel the function of this port
becomes Front Speaker Out.

11

10

9

7 . Microphone port (pink). This port connects a microphone. In

6-channel mode, the function of this port becomes Rear Speaker Out.

Refer to the audio configuration table for the function of the audio ports
in stereo, 4-channel, and 5.1/6-channel modes.

Audio configuration

Port Stero mode 4-channel mode 5.1/6-channel mode

Blue Line in Line in Center/LFE*
Green Line out Front speaker out Front speaker out
Pink Mic Rear speaker out Rear speaker out

*Low frequency enhanced output

ASUS P5SD1-FM2 1-25

9 . USB 2.0 ports 3 and 4. These two 4-pin Universal Serial Bus

(USB) ports are available for connecting USB 2.0 devices.

1 0 . Serial port. This 9-pin COM1 port is for pointing devices or other

serial devices.

1 1 . USB 2.0 ports 1 and 2. These two 4-pin Universal Serial Bus

(USB) ports are available for connecting USB 2.0 devices.

1 2 . PS/2 keyboard port (purple). This port is for a PS/2 keyboard.

1-26 Chapter 1: Hardware information

1.7.2 Internal connectors

n

1 . Floppy disk drive connector (34-1 pin FLOPPY)

This connector is for the provided floppy disk drive (FDD) signal cable.
Insert one end of the cable to this connector, then connect the other
end to the signal connector at the back of the floppy disk drive.

Pin 5 on the connector is removed to prevent incorrect cable connection
when using an FDD cable with a covered Pin 5.

FLOPPY

NOTE: Orient the red markings o
the floppy ribbon cable to PIN 1.

®

P5SD1-FM2

PIN 1

P5SD1-FM2 Floppy disk drive connector

2 . Power LED connector (3-1 pin PLED)

This 3-1 pin connector is for the system power LED. Connect the
3-pin power LED cable from the system chassis to this connector. The
LED lights up when you turn on the system power, and blinks when
the system is in sleep mode.

®

P5SD1-FM2

PLED

1

NC

P5SD1-FM2 PLED connector

PLED-

PLED+

ASUS P5SD1-FM2 1-27

3 . IDE connectors (40-1 pin PRI_IDE, SEC_IDE)

s

These connectors are for a Ultra DMA 100/66 signal cable. The Ultra
DMA 100/66 signal cable has three connectors: a blue connector for
the primary IDE connector on the motherboard, a black connector for
an Ultra DMA 100/66 IDE slave device (optical drive/hard disk drive),
and a gray connector for an Ultra DMA 100/66 IDE master device (hard
disk drive). If you install two hard disk drives, you must configure the
second drive as a slave device by setting its jumper accordingly. Refer
to the hard disk documentation for the jumper settings.

• Pin 20 on the IDE connector is removed to match the covered hole
on the Ultra DMA cable connector. This prevents incorrect insertion
when you connect the IDE cable.

• Use the 80-conductor IDE cable for Ultra DMA 100/66 IDE devices.

®

P5SD1-FM2

P5SD1-FM2 IDE connectors

SEC_IDE

PIN 1

NOTE: Orient the red marking
(usually zigzag) on the IDE
ribbon cable to PIN 1.

PRI_IDE

1-28 Chapter 1: Hardware information

4 . Serial ATA connectors

(7-pin SATA1 [blue], SATA2 [blue], SATA3 [black],
SATA4 [black])

These connectors are for the Serial ATA signal cables for Serial ATA
hard disk drives.

These connectors are set to Standard IDE configuration by default. In
Standard IDE mode, you can connect Serial ATA boot/data hard disk
drives to these connectors.

®

P5SD1-FM2

SATA1

GND

RSATA_RXN1

RSATA_RXP1

GND

RSATA_TXP1

RSATA_TXN1

GND

SATA3

GND

GND

GND

RSATA_TXN3

RSATA_RXP3

RSATA_RXN3

RSATA_TXP3

P5SD1-FM2 SATA connectors

Important notes on Serial ATA

•

The Serial ATA RAID feature (RAID 0, RAID 1) is available only if you
are using Windows® XP.

•

Install the Windows® XP Service Pack 1 before using Serial ATA.

• Use only a maximum of two ports for each RAID 0 or RAID 1 set.

•

Plug your Serial ATA boot disk on the master port (SATA1 and
SATA2) to support S3 function. Refer to the table below for details.

Serial ATA Master/Slave connectors

SATA2

SATA4

GND

GND

RSATA_RXP2

RSATA_RXN2

RSATA_RXP4

RSATA_RXN4

GND

GND

RSATA_TXP2

RSATA_TXN2

RSATA_TXN4

RSATA_TXP4

GND

GND

Connector Color Setting Use

SATA1 , SATA2 Blue Master Boot Disk
SATA3, SATA4 Black Slave Data Disk

ASUS P5SD1-FM2 1-29

5 . CPU and Chassis fan connectors

(4-pin CPU_FAN, 3-pin CHA_FAN)

The fan connectors support cooling fans of 350 mA ~ 2000 mA (24 W
max.) or a total of 1 A ~ 3.48 A (41.76 W max.) at +12 V. Connect
the fan cables to the fan connectors on the motherboard, making sure
that the black wire of each cable matches the ground pin of the
connector.

Do not forget to connect the fan cables to the fan connectors.
Insufficient air flow inside the system may damage the motherboard
components. These are not jumpers! DO NOT place jumper caps on the
fan connectors.

CHA_FAN

Rotation

+12V

GND

®

P5SD1-FM2

CPU_FAN

CPU FAN PWM

CPU FAN IN

CPU FAN PWR

GND

P5SD1-FM2 Fan connectors

6 . Speaker out connector (4-pin SPEAKER)

This connector is for the case-mounted speaker and allows you to
hear system beeps and warnings.

®

P5SD1-FM2

P5SD1-FM2 Speaker out connector

SPEAKER

1

+5V

GND

GND

Speak Out

1-30 Chapter 1: Hardware information

7 . USB connectors (10-1 pin USB56, USB78)

These connectors are for USB 2.0 ports. These USB connectors comply with USB 2.0
specification that supports up to 480 Mbps connection speed.

®

P5SD1-FM2

USB+5V

USB_P6-

USB_P6+

GND

NC

USB+5V

USB_P8-

USB_P8+

GND

NC

P5SD1-FM2 USB 2.0 connectors

USB56

USB+5V

USB_P5-

USB78

GND

USB_P5+

Never connect a 1394 cable to the USB connectors. Doing so will
damage the motherboard!

USB+5V

USB_P7-

USB_P7+

GND

ASUS P5SD1-FM2 1-31

8 . ATX power connectors (24-pin EATXPWR, 4-pin ATX12V)

s

These connectors are for an ATX power supply. The plugs from the
power supply are designed to fit these connectors in only one
orientation. Find the proper orientation and push down firmly until the
connectors completely fit.

•

We recommend that you use an ATX 12 V Specification

2.0-compliant power supply unit (PSU) with a minimum of 350 W
power rating. This PSU type has 24-pin and 4-pin power plugs.

•

If you intend to use a PSU with 20-pin and 4-pin power plugs, make
sure that the 20-pin power plug can provide at least 15A on +12V
and that the PSU has a minimum power rating of 350 W. The system
may become unstable or may not boot up if the power is
inadequate.

•

Do not forget to connect the 4-pin ATX +12 V power plug;
otherwise, the system will not boot up.

• We recommend that you use a PSU with higher power output when
configuring a system with more power-consuming devices. The
system may become unstable or may not boot up if the power is
inadequate.

®

P5SD1-FM2

P5SD1-FM2 ATX power connectors

GND

GND

+12V DC

+12V DC

+3 Volts
+12 Volts
+12 Volts

+5V Standby

Power OK

Ground

+5 Volts

Ground

+5 Volts

Ground
+3 Volts
+3 Volts

EATXPWRATX12V

Ground
+5 Volts
+5 Volts
+5 Volts

-5 Volts
Ground
Ground
Ground
PSON#
Ground

-12 Volt
+3 Volts

1-32 Chapter 1: Hardware information

9 . Internal audio connector (4-pin AUX)

l

This connector allows you to receive stereo audio input from sound
sources such as a CD-ROM, TV tuner, or MPEG card.

®

P5SD1-FM2

AUX (White)

Left Audio Channel
Ground
Right Audio Channe

P5SD1-FM2 Internal audio connector

1 0 . Front panel audio connector (10-1 pin FP_AUDIO)

This connector is for a chassis-mounted front panel audio I/O module
that supports AC ‘97 audio standard. Connect one end of the front
panel audio I/O module cable to this connector.

®

+5VA

BLINE_OUT_L

BLINE_OUT_R

P5SD1-FM2

FP_AUDIO

P5SD1-FM2 System panel connector

AGND

MIC2

MICPWR

NC

Line out_L

Line out_R

ASUS P5SD1-FM2 1-33

1 1 . System panel connector (10-1 pin F_PANEL)

This connector supports several chassis-mounted functions.

PLED PWRBTN

®

PLED-

PWR

PLED+

HDLED-

HDLED+

GNDReset

Ground

P5SD1-FM2

F_PANEL

HDLED RESET

P5SD1-FM2 System panel connector

The sytem panel connector is color-coded for easy connection. Refer to
the connector description below for details.

•

System power LED (Green 2-pin PLED)

This 3-pin connector is for the system power LED. Connect the
chassis power LED cable to this connector. The system power LED
lights up when you turn on the system power, and blinks when the
system is in sleep mode.

•

Hard disk drive activity (Red 2-pin HDLED)

This 2-pin connector is for the HDD Activity LED. Connect the HDD
Activity LED cable to this connector. This LED lights up or flashes
when data is read from or written to the HDD.

•

Power/Soft-off button (Black 2-pin PWRSW)

This connector is for the system power button. Pressing the power
button turns the system ON or puts the system in SLEEP or SOFT-OFF
mode depending on the BIOS settings. Pressing the power switch for
more than four seconds while the system is ON turns the system OFF.

•

Reset button (Blue 2-pin RESET)

This 2-pin connector is for the chassis-mounted reset button for
system reboot without turning off the system power.

1-34 Chapter 1: Hardware information

This chapter tells how to change
the system settings through the BIOS
Setup menus. Detailed descriptions
of the BIOS parameters are also
provided.

BIOS setup

2

2.1 Managing and updating your BIOS

The following utilities allow you to manage and update the motherboard Basic Input/Output
System (BIOS) setup.

1. ASUS EZ Flash (Updates the BIOS using a floppy disk during POST .)

2. ASUS AFUDOS (Updates the BIOS in DOS mode using a bootable floppy disk.)

Refer to the corresponding sections for details on these utilities.

Save a copy of the original motherboard BIOS file to a bootable floppy
disk in case you need to restore the BIOS in the future. Copy the original
motherboard BIOS using the ASUS Update or AFUDOS utilities.

2.1.1 Creating a bootable floppy disk

1 . Do either one of the following to create a bootable floppy disk.

DOS environment

a. Insert a 1.44 MB floppy disk into the drive.
b. At the DOS prompt, type format A:/S then press <Enter>.

Windows® XP environment

a. Insert a 1.44 MB floppy disk to the floppy disk drive.

®

b. Click Start from the Windows

desktop, then select My

Computer.
c. Select the 3 1/2 Floppy Drive icon.
d. Click File from the menu, then select Format. A Format 3 1/2

Floppy Disk window appears.
e. Select Create an MS-DOS startup disk from the format

options field, then click Start.

2-2 Chapter 2: BIOS setup

2.1.2 ASUS EZ Flash utility

The ASUS EZ Flash feature allows you to update the BIOS without having to
go through the long process of booting from a floppy disk and using a
DOS-based utility. The EZ Flash utility is built into the BIOS chip so it is
accessible by pressing <Alt> + <F2> during the Power-On Self Tests
(POST).

To update the BIOS using EZ Flash:
1 . Visit the system builder’s website to download the latest BIOS file for

the motherboard and rename the same to P5SD1FMF.ROM.
2 . Save the BIOS file to a floppy disk, then restart the system.
3 . Press <Alt> + <F2> during POST to display the following.

EZFlash starting BIOS update
Checking for floppy...

4 . Insert the floppy disk that contains the BIOS file to the floppy disk

drive. When the correct BIOS file is found, EZ Flash performs the BIOS

update process and automatically reboots the system when done.

EZFlash starting BIOS update
Checking for floppy...
Floppy found!
Reading file “P5SD1FMF.ROM”. Completed.

Start erasing.......|

Start programming...|
Flashed successfully. Rebooting.

• Do not shut down or reset the system while updating the BIOS to
prevent system boot failure!

• A “Floppy not found!” error message appears if there is no floppy
disk in the drive. A “P5SD1FMF.ROM not found!” error message
appears if the correct BIOS file is not found in the floppy disk. Make
sure that you rename the BIOS file to P5SD1FMF.ROM.

ASUS P5SD1-FM2 2-3

2.1.3 AFUDOS utility

The AFUDOS utility allows you to update the BIOS file in DOS environment
using a bootable floppy disk with the updated BIOS file. This utility also
allows you to copy the current BIOS file that you can use as backup when
the BIOS fails or gets corrupted during the updating process.

Copying the current BIOS

To copy the current BIOS file using the AFUDOS utility:

• Make sure that the floppy disk is not write-protected and has at
least 600 KB free space to save the file.

• The succeeding BIOS screens are for reference only. The actual BIOS
screen displays may not be exactly the same as shown.

1. Copy the AFUDOS utility (afudos.exe) from the motherboard support
CD to the bootable floppy disk you created earlier.

2. Boot the system in DOS mode, then at the prompt type:

afudos /o[filename]

where the [filename] is any user-assigned filename not more than
eight alphanumeric characters for the main filename and three
alphanumeric characters for the extension name.

A:\>afudos /oOLDBIOS1.ROM

Main filename Extension name

3 . Press <Enter>. The utility copies the current BIOS file to the floppy

disk.

A:\>afudos /oOLDBIOS1.ROM
AMI Firmware Update Utility - Version 1.10
Copyright (C) 2002 American Megatrends, Inc. All rights reserved.

Reading flash ..... done

A:\>

The utility returns to the DOS prompt after copying the current BIOS
file.

2-4 Chapter 2: BIOS setup

Updating the BIOS file

To update the BIOS file using the AFUDOS utility:
1 . Visit the system builder’s website and download the latest BIOS file

for the motherboard. Save the BIOS file to a bootable floppy disk.

Write the BIOS filename on a piece of paper. You need to type the exact
BIOS filename at the DOS prompt.

2. Copy the AFUDOS utility (afudos.exe) from the motherboard support
CD to the bootable floppy disk you created earlier.

3. Boot the system in DOS mode, then at the prompt type:

afudos /i[filename]

where [filename] is the latest or the original BIOS file on the bootable
floppy disk.

A:\>afudos /iP5SD1FMF.ROM

4 . The utility verifies the file and starts updating the BIOS.

A:\>afudos /iP5SD1FMF.ROM
AMI Firmware Update Utility - Version 1.19(ASUS V2.07(03.11.24BB))
Copyright (C) 2003 American Megatrends, Inc. All rights reserved.

WARNING!! Do not turn off power during flash BIOS

Reading file ..... done

Reading flash .... done

Advance Check........

Erasing flash .... done

Writing flash .... 0x0008CC00 (9%)

Do not shut down or reset the system while updating the BIOS to
prevent system boot failure!

ASUS P5SD1-FM2 2-5

5 . The utility returns to the DOS prompt after the BIOS update process is

completed. Reboot the system from the hard disk drive.

A:\>afudos /iP5SD1FMF.ROM
AMI Firmware Update Utility - Version 1.19(ASUS V2.07(03.11.24BB))
Copyright (C) 2003 American Megatrends, Inc. All rights reserved.

WARNING!! Do not turn off power during flash BIOS

Reading file ..... done

Reading flash .... done

Advance Check.........

Erasing flash ..... done

Writing flash ..... done

Verifying flash ... done

Please restart your computer

A:\>

2-6 Chapter 2: BIOS setup

2.2 BIOS setup program

This motherboard supports a programmable firmware chip that you can
update using the provided utility described in section “2.1 Managing and
updating your BIOS.”

Use the BIOS Setup program when you are installing a motherboard,
reconfiguring your system, or prompted to “Run Setup.” This section
explains how to configure your system using this utility.

Even if you are not prompted to use the Setup program, you can change
the configuration of your computer in the future. For example, you can
enable the security password feature or change the power management
settings. This requires you to reconfigure your system using the BIOS
Setup program so that the computer can recognize these changes and
record them in the CMOS RAM of the firmware hub.

The firmware hub on the motherboard stores the Setup utility. When you
start up the computer, the system provides you with the opportunity to
run this program. Press <Del> during the Power-On-Self-Test (POST) to
enter the Setup utility; otherwise, POST continues with its test routines.

If you wish to enter Setup after POST, restart the system by pressing
<Ctrl+Alt+Delete>, or by pressing the reset button on the system chassis.
You can also restart by turning the system off and then back on. Do this
last option only if the first two failed.

The Setup program is designed to make it as easy to use as possible. Being
a menu-driven program, it lets you scroll through the various sub-menus
and make your selections from the available options using the navigation
keys.

• The default BIOS settings for this motherboard apply for most
conditions to ensure optimum performance. If the system becomes
unstable after changing any BIOS settings, load the default settings
to ensure system compatibility and stability. Select the Load
Default Settings item under the Exit Menu. See section “2.7 Exit
Menu.”

• The BIOS setup screens shown in this section are for reference
purposes only, and may not exactly match what you see on your
screen.

• Visit the system builder’s website to download the latest BIOS file
for this motherboard.

ASUS P5SD1-FM2 2-7

2.2.1 BIOS menu screen

Menu items

System Time [10:55:25]
System Date [Thu,02/24/2005]
Legacy Diskette A [1.44M, 3.5 in]

Primary IDE Master [ST320410A]
Primary IDE Slave [ASUS CD-S520/A]
Secondary IDE Master [Not Detected]
Secondary IDE Slave [Not Detected]
Third IDE Master [Not Detected]
Third IDE Slave [Not Detected]
Fourth IDE Master [Not Detected]
Fourth IDE Slave [Not Detected]

OnBoard PCI S-ATA Controller [Native]

System Information

Sub-menu items

Menu bar

Configuration fields

General help

Use [ENTER], [TAB] or
[SHIFT-TAB] to select
a field.

Use [+] or [-] to
configure the System
Time.

Navigation keys

2.2.2 Menu bar

The menu bar on top of the screen has the following main items:

Main For changing the basic system configuration
Advanced For changing the advanced system settings
Power For changing the advanced power management (APM)

configuration

Boot For changing the system boot configuration
Exit For selecting the exit options and loading default

settings

To select an item on the menu bar, press the right or left arrow key on the
keyboard until the desired item is highlighted.

2.2.3 Navigation keys

At the bottom right corner of a menu screen are the navigation keys for
that particular menu. Use the navigation keys to select items in the menu
and change the settings.

Some of the navigation keys differ from one screen to another.

2-8 Chapter 2: BIOS setup

2.2.4 Menu items

The highlighted item on the menu
bar displays the specific items for
that menu. For example, selecting
Main shows the Main menu items.

The other items (Advanced, Power,
Boot, and Exit) on the menu bar
have their respective menu items.

System Time [10:5 5:25]
System Date [Thu 01/27/2005 ]
Legacy Diskette A [1.44M, 3.5 in]

Primary IDE Master : [ST320410A]
Primary IDE Slave : [ASUS CD-S520/A]
Secondary IDE Master : [Not Detected]
Secondary IDE Slave : [Not Detected]
Third IDE Master : [Not Detected]
Third IDE Slave : [Not Detected]
Fourth IDE Master : [Not Detected]
Fourth IDE Slave : [Not Detected]

OnBoard PCI S-ATA Controller [Native]

System Information

Main menu items

Use [ENTER], [TAB] or
[SHIFT-TAB] to select
a field.

Use [+] or [-] to
configure the System
Time.

2.2.5 Sub-menu items

A solid triangle before each item on any menu screen means that the item
has a sub-menu. To display the sub-menu, select the item and press
<Enter>.

2.2.6 Configuration fields

These fields show the values for the menu items. If an item is
user-configurable, you can change the value of the field opposite the item.
You cannot select an item that is not user-configurable.

A configurable field is enclosed in brackets, and is highlighted when
selected. To change the value of a field, select it then press <Enter> to
display a list of options. Refer to “2.2.7 Pop-up window.”

2.2.7 Pop-up window

Select a menu item then press <Enter> to display a pop-up window with
the configuration options for that item.

2.2.8 Scroll bar

A scroll bar appears on the right side
of a menu screen when there are
items that do not fit on the screen.
Press the Up/Down arrow keys or
<Page Up> /<Page Down> keys to
display the other items on the
screen.

2.2.9 General help

Advanced PCI/PnP Settings

WARNING: Setting wrong values in
below sections may cause system to
malfunction.

Plug And Play O/S [No]
PCI Latency Timer [64]
Allocate IRQ to PCI VGA [Yes]
Palette Snooping [Disabled]
PCI IDE BusMaster [Enabled]

Pop-up window

At the top right corner of the menu
screen is a brief description of the

Scroll bar

selected item.

ASUS P5SD1-FM2 2-9

2.3 Main menu

When you enter the BIOS Setup program, the Main menu screen appears,
giving you an overview of the basic system information.

Refer to section “2.2.1 BIOS menu screen” for information on the menu
screen items and how to navigate through them.

System Time [10:55:25]
System Date [Thu,02/24/2005]
Legacy Diskette A [Disabled]

Primary IDE Master : [ST320410A]
Primary IDE Slave : [ASUS CD-S520/A]
Secondary IDE Master : [Not Detected]
Secondary IDE Slave : [Not Detected]
Third IDE Master : [Not Detected]
Third IDE Slave : [Not Detected]
Fourth IDE Master : [Not Detected]
Fourth IDE Slave : [Not Detected]

OnBoard PCI S-ATA Controller: [Native]

System Information

Use [ENTER], [TAB] or
[SHIFT-TAB] to select
a field.

Use [+] or [-] to
configure the System
time.

2.3.1 System Time [xx:xx:xx]

Allows you to set the system time.

2.3.2 System Date [Day xx/xx/xxxx]

Allows you to set the system date.

2.3.3 Legacy Diskette A [Disabled]

Sets the type of floppy drive installed. Configuration options: [Disabled]
[360K, 5.25 in.] [1.2M , 5.25 in.] [720K , 3.5 in.] [1.44M, 3.5 in.]
[2.88M, 3.5 in.]

2-10 Chapter 2: BIOS setup

2.3.4 Primary, Secondary, Third, and Fourth
IDE Master/Slave

While entering Setup, the BIOS automatically detects the presence of IDE
devices. There is a separate sub-menu for each IDE device. Select a device
item then press <Enter> to display the IDE device information.

Primary IDE Master

Device : Hard Disk
Vendor : ST320410A
Size : 20.0GB
LBA Mode : Supported
Block Mode : 16 Sectors
PIO Mode : 4
Async DMA : MultiWord DMA-2
Ultra DMA : Ultra DMA-2
SMART Monitoring : Supported

Type [Auto]
LBA/Large Mode [Auto]
Block(Multi-sector Transfer) M [Auto]
PIO Mode [Auto]
DMA Mode [Auto]
Smart Monitoring [Auto]
32Bit Data Transfer [Disabled]

Select the type of
device connected to
the system.

The BIOS automatically detects the values opposite the dimmed items
(Device, Vendor, Size, LBA Mode, Block Mode, PIO Mode, Async DMA, Ultra
DMA, and SMART monitoring). These values are not user-configurable.
These items show N/A if no IDE device is installed in the system.

Type [Auto]

Selects the type of IDE drive. Setting to Auto allows automatic selection of
the appropriate IDE device type. Select CDROM if you are specifically
configuring a CD-ROM drive. Select ARMD (ATAPI Removable Media Device)
if your device is either a ZIP, LS-120, or MO drive.
Configuration options: [Not Installed] [Auto] [CDROM] [ARMD]

LBA/Large Mode [Auto]

Enables or disables the LBA mode. Setting to Auto enables the LBA mode if
the device supports this mode, and if the device was not previously
formatted with LBA mode disabled. Configuration options: [Disabled] [Auto]

Block (Multi-sector Transfer) [Auto]

Enables or disables data multi-sectors transfers. When set to Auto, the
data transfer from and to the device occurs multiple sectors at a time if
the device supports multi-sector transfer feature. When set to [Disabled],
the data transfer from and to the device occurs one sector at a time.
Configuration options: [Disabled] [Auto]

ASUS P5SD1-FM2 2-11

PIO Mode [Auto]

Selects the PIO mode.
Configuration options: [Auto] [0] [1] [2] [3] [4]

DMA Mode [Auto]

Automatically sets the DMA mode.

SMART Monitoring [Auto]

Sets the Self-Monitoring, Analysis, and Reporting Technology.
Configuration options: [Auto] [Disabled] [Enabled]

32Bit Data Transfer [Disabled]

Enables or disables 32-bit data transfer.
Configuration options: [Disabled] [Enabled]

2.3.5 OnBoard PCI S-ATA Controller [Native]

Enables or disables the onboard PCI Serial ATA controller .
Configuration options: [Disabled] [RAID] [Native]

2-12 Chapter 2: BIOS setup

2.3.6 System Information

This menu gives you an overview of the general system specifications. The
BIOS automatically detects the items in this menu.

AMIBIOS

Version : 08.00.10
Build Date : 02/23/05
ID : A0231000

Processor

Type : Genuine Intel(R) CPU 3.06 GHz
Speed : 3066 MHz
Count : 1

System Memory

Size : 256 MB

AMI BIOS

Displays the auto-detected BIOS information.

Processor

Displays the auto-detected CPU specification.

System Memory

Displays the auto-detected system memory.

ASUS P5SD1-FM2 2-13

2.4 Advanced menu

The Advanced menu items allow you to change the settings for the CPU
and other system devices.

Take caution when changing the settings of the Advanced menu items.
Incorrect field values can cause the system to malfunction.

CPU Configuration
Chipset
Onboard Devices Configuration
PCI PnP
USB Configuration

Configure CPU.

2-14 Chapter 2: BIOS setup

2.4.1 CPU Configuration

The items in this menu show the CPU-related information that the BIOS
automatically detects.

Configure advanced CPU Settings

Manufacturer : Intel
Brand String : Genuined Intel (R) CPU 3.06 GHz
Frequency : 3066 MHz
FSB Speed : 533 MHz

Cache L1 : 16 KB
Cache L2 : 256 KB
Cache L3 : 0 KB

Ratio Status: Unlocked
Ratio Actual Value : 23

Ratio CMOS Setting: [ 8]
VID CMOS Setting: [ 62]
Microcode Updation: [Enabled]
Max CPUID Value Limit: [Disabled]
NX Technology [Disabled]
Enhanced C1 Control [Auto]
CPU Internal Thermal Control [Auto]

Sets the ratio between
CPU Core Clock and the
FSB Frequency.
NOTE: If an invalid
ratio is set in CMOS
then actual and
setpoint values may
differ.

Ratio CMOS Setting [18]

Sets the ratio between the CPU Core Clock and the Front Side Bus
frequency. The default value of this item is auto-detected by BIOS. Use the
<+> or <-> keys to adjust the values.

VID CMOS Setting [ 62]

Allows you to set the VID CMOS setting at which the processor is to run.
The default value of this item is auto-detected by BIOS. Use the <+> or
<-> keys to adjust the values.

You can only adjust the Ratio CMOS and the VID CMOS setting if
you installed an unlocked CPU. Refer to the CPU documentation for
details.

Microcode Updation [Enabled]

Enables or disables microcode updation.
Configuration options: [Disabled] [Enabled]

Max CPUID Value Limit [Disabled]

Enable this item to boot legacy operating systems that cannot support
CPUs with extended CPUID functions. Configuration options: [Disabled]
[Enabled]

ASUS P5SD1-FM2 2-15

NX Technology [Disabled]

Allows you to enable or disable the No-Execution page protection
technology feature. Configuration options: [Disabled] [Enabled]

Enhanced C1 Control [Auto]

When set to [Auto], the BIOS will automatically check the CPU’s capability
to enable the C1E support. In C1E mode, the CPU power consumption is
lower when idle. Configuration options: [Auto] [Disabled]

CPU Internal Thermal Control [Auto]

Disables or sets the CPU internal thermal control.
Configuration options: [Auto] [Disabled]

2.4.2 Chipset

The Chipset menu allows you to change the advanced chipset settings.
Select an item then press <Enter> to display the sub-menu.

NorthBridge SIS649 Configuration
SouthBridge SiS965/SiS965L Configuration

Options for NB

2-16 Chapter 2: BIOS setup

NorthBridge SIS649 Chipset Configuration

Primary Graphics Adapter [PCI Express]

CPU FSB Set To Chipset Timing [FSB: 533MHz]

Auto Detect DRAM Frequency [Enabled]

CPU:DRAM Frequency Ratio [DDR 400 MHz]
Real CPU FSB:DRAM = 532(133*4): 400(200*2) MHz

DRAM CAS# Latency [By SPD]

Primary Graphics Adapter [PCI Express]

Allows selection of the graphics controller to use as a primary boot

device. Configuration options: [PCI] [PCI Express]

CPU FSB Set To Chipset Timing [FSB: 533MHz]

Displays auto-detected CPU FSB information.

Auto Detect DRAM Frequency [Enabled]

When set to [Enabled], this allows the BIOS to detect the DRAM
frequency automatically. Configuration options: [Disabled] [Enabled]

CPU:DRAM Frequency Ratio [DDR 400 MHz]

Displays auto-detected CPU and DRAM frequency ratio information.

Real CPU FSB:DRAM = 532(133*4): 400(200*2) MHz

Displays auto-detected CPU FSB and DRAM frequency information.

DRAM CAS# Latency [By SPD]

Controls the latency between the SDRAM read command and the time
the data actually becomes available. Configuration options: [By SPD]
[2T] [2.5T] [3T]

ASUS P5SD1-FM2 2-17

SouthBridge SiS965 Chipset Configuration

Onboard AC97 Audio Device [Enabled]
Onboard SiS191 LAN Device [Enabled]

Onboard LAN Boot ROM [Disabled]

Onboard AC97 Audio Device [Enabled]

Enables or disables the onboard AC `97 audio CODEC.
Configuration options: [Disabled] [Enabled]

Onboard SiS191 LAN Device [Enabled]

Enables or disables the onboard SiS191 LAN controller.
Configuration options: [Disabled] [Enabled]

Onboard LAN Boot ROM [Disabled]

Enables or disables the onboard LAN boot ROM feature.
Configuration options: [Disabled] [Enabled]

2-18 Chapter 2: BIOS setup

2.4.3 Onboard Devices Configuration

Configure ITE8712 Super IO Chipset

Serial Port1 Address [3F8/IRQ4]

Serial Port1 Mode [Normal]
Parallel Port Address [378]
Parallel Port Mode [ECP]

ECP Mode DMA Channel [DMA3]

Parallel Port IRQ [IRQ7]

Onboard 1394 Controller [Enabled]

Allows BIOS to enable
or disable the floppy
controller.

Serial Port1 Address [3F8/IRQ4]

Allows you to select the Serial Port1 base address.
Configuration options: [Disabled] [3F8/IRQ4] [3E8/IRQ4] [2E8/IRQ3]

Serial Port1 Mode [Normal]

Allows you to select the Serial Port1 mode.
Configuration options: [Normal] [IrDA] [ASK IR]

COMA Duplex Mode [Half Duplex]

Allows the BIOS to select Full or Half Duplex for Serial Port. This
appears only when the Serial Port1 Mode item is set to [IrDA] or
[ASK IR] Configuration options: [Full Duplex] [Half Duplex]

Parallel Port Address [378]

Allows you to select the Parallel Port base addresses.
Configuration options: [Disabled] [378] [278]

Parallel Port Mode [ECP]

Allows you to select the Parallel Port mode.
Configuration options: [Normal] [EPP] [ECP] [EPP+ECP]

EPP Version [1.9]

Allows selection of the Parallel Port EPP version. This item appears
only when the Parallel Port Mode is set to [EPP] or [EPP+ECP].
Configuration options: [1.9] [1.7]

ECP Mode DMA Channel [DMA3]

Allows you to set the Parallel Port ECP DMA. This item appears only
when the Parallel Port Mode is set to [ECP] or [EPP+ECP].
Configuration options: [DMA0] [DMA1] [DMA3]

Parallel Port IRQ [IRQ7]

Allows selection of the Parallel Port IRQ.
Configuration options: [IRQ5] [IRQ7]

ASUS P5SD1-FM2 2-19

Onboard 1394 Controller [Enabled]

Allows you to enable or disable the onboard IEEE 1394a controller.
Configuration options: [Disabled] [Enabled]

2.4.4 PCI PnP

The PCI PnP menu items allow you to change the advanced settings for
PCI/PnP devices. The menu includes setting IRQ and DMA channel resources
for either PCI/PnP or legacy ISA devices, and setting the memory size block
for legacy ISA devices.

Take caution when changing the settings of the PCI PnP menu items.
Incorrect field values can cause the system to malfunction.

Advanced PCI/PnP Settings

WARNING: Setting wrong values in below sections

may cause system to malfunction.

Plug And Play O/S [No]
Allocate IRQ to PCI VGA [Yes]
OffBoard PCI/ISA IDE Card [Auto]

IRQ-3 assigned to [PCI Device]
IRQ-4 assigned to [PCI Device]
IRQ-5 assigned to [PCI Device]
IRQ-7 assigned to [PCI Device]
IRQ-9 assigned to [PCI Device]
IRQ-10 assigned to [PCI Device]
IRQ-11 assigned to [PCI Device]
IRQ-14 assigned to [PCI Device]
IRQ-15 assigned to [PCI Device]

DMA Channel 0 [PCI Device]
DMA Channel 1 [PCI Device]
DMA Channel 3 [PCI Device]
DMA Channel 5 [PCI Device]
DMA Channel 6 [PCI Device]
DMA Channel 7 [PCI Device]

No: Lets the BIOS
configure all the
devices in the system.
Yes: Lets the operating
system configure Plug
and Play (PnP) devices
not required for boot
if your system has a
Plug and Play operating
system.

Plug and Play O/S [No]

When set to [No], BIOS configures all the devices in the system. When set
to [Yes] and if you install a Plug and Play operating system, the operating
system configures the Plug and Play devices not required for boot.
Configuration options: [No] [Yes]

2-20 Chapter 2: BIOS setup

Allocate IRQ to PCI VGA [Yes]

When set to [Yes], BIOS assigns an IRQ to PCI VGA card if the card
requests for an IRQ. When set to [No], BIOS does not assign an IRQ to the
PCI VGA card even if requested. Configuration options: [Yes] [No]

OffBoard PCI/ISA IDE Card [Auto]

Allows you to set the PCI slot number that is holding the PCI IDE card.
Configuration options: [Auto] [PCI Slot1] [PCI Slot2] [PCI Slot3] [PCI Slot4]
[PCI Slot5] [PCI Slot6 ]

IRQ-xx assigned to [PCI Device]

When set to [PCI Device], the specific IRQ is free for the use of PCI/PnP
devices. When set to [Reserved], the IRQ is reserved for legacy ISA
devices. Configuration options: [PCI Device] [Reserved]

DMA Channel x [PCI Device]

When set to [PCI Device], the specific DMA channel is free for the use of
PCI/PnP devices. When set to [Reserved], the IRQ is reserved for legacy ISA
devices. Configuration options: [PCI Device] [Reserved]

ASUS P5SD1-FM2 2-21

2.4.5 USB Configuration

The items in this menu allow you to change the USB-related features.
Select an item then press <Enter> to display the configuration options.

USB Configuration

Module Version - 2.23.2-9.4

USB Devices Enabled: None

USB Function [Enabled]
Legacy USB Support [Enabled]
USB 2.0 Controller Mode [HiSpeed]
Stop EHCI HC in OHCI handover [Enabled]

The Module Version and USB Devices Enabled items show the
auto-detected values. If no USB device is detected, the item shows

None.

USB Function [Enabled]

Allows you to enable or disable the USB function.
Configuration options: [Disabled] [Enabled]

Legacy USB Support [Enabled]

Allows you to enable or disable support for USB devices on legacy
operating systems (OS). Setting to [Auto] allows the system to detect the
presence of USB devices at startup. If detected, the USB controller legacy
mode is enabled. If no USB device is detected, the legacy USB support is
disabled. Configuration options: [Disabled] [Enabled] [Auto]

USB 2.0 Controller Mode [HiSpeed]

Allows you to set the USB 2.0 controller mode to HiSpeed (480 Mbps) or
FullSpeed (12 Mbps). Configuration options: [FullSpeed] [HiSpeed ]

Stop EHCI HC in OHCI handover [Enabled]

When this item is set to [Enabled], the BIOS stops the EHCI host controller
during OHCI OS handover cal. This is needed for installing operating
systems that do not support EHCI host controllers.
Configuration options: [Disabled] [Enabled]

2-22 Chapter 2: BIOS setup

2.5 Power menu

The Power menu items allow you to change the settings for the ACPI and
Advanced Power Management (APM). Select an item then press <Enter> to
display the configuration options.

ACPI Aware O/S [Yes]
Suspend Mode [S3 only]
Repost Video on S3 Resume [No]
ACPI 2.0 Support [Yes]
ACPI APIC Support [Enabled]

APM Configuration
Hardware Monitor

Enable/Disable ACPI
support for operating
system.

ENABLE: If OS supports
ACPI.

DISABLE: If OS does not
support ACPI

2.5.1 ACPI Aware O/S [Yes]

Set this item to [Yes] if the operating system supports the Advanced
Configuration and Power Interface [ACPI]. Configuration options: [No] [Yes]

2.5.2 Suspend Mode [S3 only]

Allows you to select the (ACPI) state to be used for system suspend.
Configuration options: [S1 (POS) Only] [S3 Only] [Auto]

2.5.3 Repost Video on S3 Resume [No]

Determines whether to invoke VGA BIOS POST on S3/STR resume.
Configuration options: [No] [Yes]

2.5.4 ACPI 2.0 Support [Yes]

Allows you to add more tables for Advanced Configuration and Power
Interface (ACPI) 2.0 specifications. Configuration options: [No] [Yes]

2.5.5 ACPI APIC Support [Enabled]

Allows you to enable or disable the Advanced Configuration and Power
Interface (ACPI) support in the Advanced Programmable Interrupt
Controller (APIC). When set to [Enabled], the ACPI APIC table pointer is
included in the RSDT pointer list. Configuration options: [Disabled]
[Enabled]

ASUS P5SD1-FM2 2-23

2.5.6 APM Configuration

Power Button Mode [On/Off]

AC Power Loss Restart [Previous State]
Power On By PS/2 Devices [Disabled]
Power On By PCI Devices [Disabled]
Power On By External Modems [Disabled]
Power On By RTC Alarm [Disabled]

Select Power button
functionality.

Power Button Mode [Off/On]

Allows you to select the power button function.
Configuration options: [Off/On] [Suspend]

AC Power Loss Restart [Previous State]

]

Allows you to set whether or not to reboot the system after power
interruptions. [Always Off] leaves your system off while [Always On]
reboots the system after AC power loss. [Previous State] sets the system
back to the state it was in before the power interruption. Configuration
options: [Always OFF] [Always On] [Previous State]

Power On By PS/2 Devices [Disabled]

Allows you to use PS/2 devices to turn on the system. This feature
requires an ATX power supply that provides at least 1A on the +5VSB lead.
Configuration options: [Disabled] [Enabled]

Power On By PCI Devices [Disabled]

When set to [Enabled], this parameter allows you to turn on the system
through a PCI LAN or modem card. This feature requires an ATX power
supply that provides at least 1A on the +5VSB lead.
Configuration options: [Disabled] [Enabled]

Power On By External Modems [Disabled]

This allows either settings of [Enabled] or [Disabled] for powering up the
computer when the external modem receives a call while the computer is in
Soft-off mode. Configuration options: [Disabled] [Enabled

The computer cannot receive or transmit data until the computer and
applications are fully running. Thus, connection cannot be made on the
first try. Turning an external modem off and then back on while the
computer is off causes an initialization string that turns the system on.

2-24 Chapter 2: BIOS setup

Power On By RTC Alarm [Disabled]

Allows you to enable or disable RTC to generate a wake event. When this
item is set to Enabled, the items RTC Alarm Date, RTC Alarm Hour, RTC
Alarm Minute, and RTC Alarm Second appear with set values.
Configuration options: [Disabled] [Enabled]

2.5.7 Hardware Monitor

Hardware Monitor

MB Temperature [41ºC/105.5ºF]
CPU Temperature [51ºC/122.5ºF]

CPU Fan Speed [3813 RPM]
Chassis Fan Speed [N/A]

VCORE Voltage [ 1.320V]

3.3V Voltage [ 3.345V]
5V Voltage [ 5.094V]
12V Voltage [11.880V]

Smart Q-FAN Function [Enabled]

Fan Auto Mode Start Voltage [2.0V]

Fan Auto Mode Start Speed Temp [45ºC]
Fan Auto Mode Full Speed Temp [70ºC]
Fan Auto Mode Slope PWM [2 PWM value/ºC]

MB Temperature

MB Temperature [xxxºC/xxxºF]
CPU Temperature [xxxºC/xxxºF]

The onboard hardware monitor automatically detects and displays the
motherboard and CPU temperatures. Select Disabled if you do not wish to
display the detected temperatures.

CPU Fan Speed [xxxxRPM] or [N/A]
Chassis Fan Speed [xxxxRPM] or [N/A]

The onboard hardware monitor automatically detects and displays the CPU/
Chassis fan speed in rotations per minute (RPM). If the fan is not connected
to the motherboard, the field shows N/A.

VCORE Voltage, 3.3V Voltage, 5V Voltage, 12V Voltage

The onboard hardware monitor automatically detects the voltage output
through the onboard voltage regulators.

Smart Q-Fan Function [Enabled]

Allows you to enable or disable the ASUS Q-Fan feature that smartly
adjusts the fan speeds for more efficient system operation.
Configuration options: [Disabled] [Enabled]

ASUS P5SD1-FM2 2-25

Fan Auto Mode Start Voltage [2.0V]

Allows you to select the voltage level at which the fan automatically starts.
Configuration options: [2.0V] [3.0V] [4.0V]

Fan Auto Mode Start Speed Temp [45ºC]

Allows you to select the temperature level at which the fan automatically
starts. Configuration options: [10ºC] ~ [75ºC]

Fan Auto Mode Full Speed Temp [70ºC]

Allows you to select the temperature level at which the fan automatically
runs at full speed. Configuration options: [25ºC] ~ [75ºC]

Fan Auto Mode Slope PWM [2 PWM value/ºC]

Configuration options: [0 PWM value/ºC] [1 PWM value/ºC]
[2 PWM value/ºC] [4 PWM value/ºC] [8 PWM value/ºC] [16 PWM value/ºC]
[32 PWM value/ºC] [64 PWM value/ºC]

The above items appear only when the Smart Q-Fan Function item
is set to [Enabled].

2-26 Chapter 2: BIOS setup

2.6 Boot menu

The Boot menu items allow you to change the system boot options. Select
an item then press <Enter> to display the sub-menu.

Boot Settings

Boot Settings Configuration
Security

2.6.1 Boot Settings Configuration

Boot Settings Configuration

Quick Boot [Enabled]
Full Screen Logo [Enabled]
Bootup Num-Lock [On]
Wait For ‘F1’ If Error [Disabled]
Hit ‘DEL’ Message Display [Enabled]
Interrupt 19 Capture [Disabled]

Specifies the Boot
Device Boot Priority
sequence.

Allows BIOS to skip
certain tests while
booting. This will
decrease the time
needed to boot the
system.

Quick Boot [Enabled]

Enabling this item allows the BIOS to skip some power on self tests (POST)
while booting to decrease the time needed to boot the system. When set
to [Disabled], BIOS performs all the POST items.
Configuration options: [Disabled] [Enabled]

Full Screen Logo [Enabled]

This allows you to enable or disable the full screen logo display feature.
Configuration options: [Disabled] [Enabled]

Set this item to [Enabled] to use the ASUS MyLogo™ feature.

ASUS P5SD1-FM2 2-27

Bootup Num-Lock [On]

Allows you to select the power-on state for the NumLock.
Configuration options: [Off] [On]

Wait for ‘F1’ If Error [Disabled]

When set to Enabled, the system waits for the F1 key to be pressed when
error occurs. Configuration options: [Disabled] [Enabled]

Hit ‘DEL’ Message Display [Enabled]

When set to Enabled, the system displays the message “Press DEL to run
Setup” during POST. Configuration options: [Disabled] [Enabled]

Interrupt 19 Capture [Disabled]

When set to [Enabled], this function allows the option ROMs to trap
Interrupt 19. Configuration options: [Disabled] [Enabled]

2-28 Chapter 2: BIOS setup

2.6.2 Security

The Security menu items allow you to change the system security settings.
Select an item then press <Enter> to display the configuration options.

Security Settings

Supervisor Password : Not Installed
User Password : Not Installed

Change Supervisor Password

Boot Sector Virus Protection [Disabled]

<Enter> to change
password.
<Enter> again to
disabled password.

Change Supervisor Password

Select this item to set or change the supervisor password. The Supervisor
Password item on top of the screen shows the default Not Installed.
After you set a password, this item shows Installed.

To set a Supervisor Password:
1 . Select the Change Supervisor Password item and press <Enter>.

2 . From the password box, type a password composed of at least six

letters and/or numbers, then press <Enter>.

3. Confirm the password when prompted.
The message “Password Installed” appears after you successfully set your

password.
To change the supervisor password, follow the same steps as in setting a

user password.
To clear the supervisor password, select the Change Supervisor Password

then press <Enter>. The message “Password Uninstalled” appears.

ASUS P5SD1-FM2 2-29

If you forget your BIOS password, you can clear it by erasing the CMOS
Real Time Clock (RTC) RAM. See section “1.6 Jumpers” for information
on how to erase the RTC RAM.

After you have set a supervisor password, the other items appear to allow
you to change other security settings.

Security Settings

Supervisor Password : Not Installed
User Password : Not Installed

Change Supervisor Password
User Access Level [Full Access]
Change User Password
Clear User Password
Password Check [Setup]

Boot Sector Virus Protection [Disabled]

<Enter> to change
password.
<Enter> again to
disabled password.

User Access Level (Full Access]

This item allows you to select the access restriction to the Setup items.
Configuration options: [No Access] [View Only] [Limited] [Full Access]

No Access prevents user access to the Setup utility.
View Only allows access but does not allow change to any field.
Limited allows changes only to selected fields, such as Date and

Time.
Full Access allows viewing and changing all the fields in the Setup

utility.

Change User Password

Select this item to set or change the user password. The User Password
item on top of the screen shows the default Not Installed. After you set
a password, this item shows Installed.

To set a User Password:
1 . Select the Change User Password item and press <Enter>.

2 . On the password box that appears, type a password composed of at

least six letters and/or numbers, then press <Enter>.

3. Confirm the password when prompted.

2-30 Chapter 2: BIOS setup

The message “Password Installed” appears after you set your password
successfully.

To change the user password, follow the same steps as in setting a user
password.

Clear User Password

Select this item to clear the user password.

Password Check [Setup]

When set to [Setup], BIOS checks for user password when accessing the
Setup utility. When set to [Always], BIOS checks for user password both
when accessing Setup and booting the system.
Configuration options: [Setup] [Always]

Boot Sector Virus Protection [Disabled]

Allows you to enable or disable the boot sector virus protection.
Configuration options: [Disabled] [Enabled]

2.7 Exit menu

The Exit menu items allow you to load the optimal or failsafe default values
for the BIOS items, and save or discard your changes to the BIOS items.

Exit Options

Exit & Save Changes
Exit & Discard Changes
Discard Changes

Load Setup Defaults

Exit system setup
after saving the
changes.
F10 key can be used
for this operation.

Pressing <Esc> does not immediately exit this menu. Select one of the
options from this menu or <F10> from the legend bar to exit.

ASUS P5SD1-FM2 2-31

Exit & Save Changes

Once you are finished making your selections, choose this option from the
Exit menu to ensure the values you selected are saved to the CMOS RAM.
An onboard backup battery sustains the CMOS RAM so it stays on even
when the PC is turned off. When you select this option, a confirmation
window appears. Select Yes to save changes and exit.

If you attempt to exit the Setup program without saving your changes,
the program prompts you with a message asking if you want to save
your changes before exiting. Press <Enter> to save the changes while
exiting.

Exit & Discard Changes

Select this option only if you do not want to save the changes that you
made to the Setup program. If you made changes to fields other than
System Date, System Time, and Password, the BIOS asks for a confirmation
before exiting.

Discard Changes

This option allows you to discard the selections you made and restore the
previously saved values. After selecting this option, a confirmation appears.
Select Yes to discard any changes and load the previously saved values.

Load Setup Defaults

This option allows you to load the default values for each of the
parameters on the Setup menus. When you select this option or if you
press <F5>, a confirmation window appears. Select Yes to load default
values. Select Exit & Save Changes or make other changes before
saving the values to the non-volatile RAM.

2-32 Chapter 2: BIOS setup

ASUS P5SD1-FM2 2-33
