Zoom iHiFi 4353 User Manual [en, es]
ZOOM BLUETOOTH
IPOD TRANSMITTER
Quick Start
English............................................... 3
Español............................................. 12
2
Using the Zoom® Bluetooth iPod Transmitter
® ®
Thank you for choosing this Zoom product. Your package
includes:
• Bluetooth
®
iPod® Transmitter
• USB charging cable that lets you charge your iPod when
the iPod Transmitter is plugged in
Mini USB port
for charging
the iPod
Charging cable
To pair the iPod Transmitter with Bluetooth-enabled
headphones, see page
To pair the iPod Transmitter with a stereo system
connected to an iHiFi Receiver, see page
To charge your iPod through the Transmitter, see page
4.
5.
7.
3
Pairing the iPod Transmitter with Bluetooth Headphones
Pairing is the procedure that establishes a wireless link
between two Bluetooth devices.
To pair your iPod Transmitter with Bluetooth-enabled
headphones such as the Zoom iHiFi™ Stereo Headphones:
1 Make sure the headphones are within a few meters of the
iPod.
2 Plug the Transmitter into your iPod.
3 Turn on the headphones.
While the Transmitter searches for another Bluetooth
device to pair with, its LEDs flash red and blue. The
Transmitter and the headphones should pair quickly.
The iPod Transmitter's blue LED flashes on and off during
the time the Transmitter is paired with the headphones.
4 If pairing doesn't occur, see the Notes on Pairing on page
6.
Note: If you want to turn off the Transmitter and/or the iPod,
unplug the Transmitter.
Caution from The American Speech-Language-Hearing
Association (ASHA)
To avoid hearing damage, ASHA counsels headphone
users to turn down the volume, take frequent listening
breaks, and wear headphones like Zoom's that fit over the
ears to block background noise.
4
Pairing the iPod Transmitter with a Zoom iHiFi Receiver
1 Install the Receiver and turn it on.
2 Plug the iPod Transmitter into your iPod.
The LEDs on both the Transmitter and the Receiver flash
red and blue, indicating that they are searching for another
Bluetooth device. The Transmitter and the Receiver should
pair quickly.
(The blue LEDs on both the iPod Transmitter and the
Receiver flash on and off during the time the two devices
are paired.)
3 Turn on your audio system, select your songs on the iPod,
and enjoy!
5
Use the right button or the left button on the iPod
Transmitter to control the iPod's volume.
Volume Up
Volume Down
Note: If you want to turn off the iPod transmitter and/or the
iPod, unplug the transmitter.
Notes on Pairing
Pairing usually takes only about 10 seconds. However, it
•
can take up to three minutes if there are other Bluetoothenabled devices nearby that you don't want to pair with.
Move those devices out of range or switch them off.
• Headphones will stop working if they get too far away from
the iPod Transmitter – for example, if you move outside
the Transmitter's range without taking the headphones off.
• If the iPod Transmitter loses pairing, it automatically tries
for 10 seconds to reconnect. The LEDs continue flashing
during this interval. If it is unable to reconnect, the
Transmitter goes into Idle mode for 45 seconds and then
turns off, so that the iPod battery isn't depleted. To restart
the Transmitter, unplug it from the iPod and then plug it in
again.
6
