Overview
This User Guide provides instructions for setting up your Game
Point!. It also includes details about WEP security, advanced
settings, and specific information for Windows, Macintosh, and
Linux users.
If we update information about the Game Point!, we provide the
updated information at this Zoom Web site:
http://www.zoom.com/techsupport/index.html
The Game Point! package includes the following items:
• Game Point!
Device
• Ethernet Cable
• Power Cube
• CD for Windows,
Macintosh, and Linux
If anything is missing or damaged, please contact Zoom Customer
Support or whoever sold you the Game Point!.
: Sony PlayStation® devices do not typically have an Ethernet port. To
Note
wirelessly enable a Sony PlayStation®2 using the Game Point!, you must purchase
an Ethernet adapter from Sony. The Game Point! can plug into this adapter.
Overview 5
1
Installing the Game Point!
This chapter provides simple instructions for installing the Zoom
Game Point! in a home that has wireless networking. First, you
plug the Game Point! device into a computer to do a quick
setup, and then you plug the device into the Ethernet port of
your Xbox Live® or PlayStation®2. It’s fast and easy!
Directly connect the Game Point! device to an Ethernet-
1111
equipped computer that has a Web browser.
If your computer is connected to your network, change the
connection. To do this, plug one end of the Ethernet cable
into the
plug the other end into the Ethernet port on the computer. If
the connection is via wireless, disable the wireless connection
using your wireless application software.
Ethernet
2222 Plug the included power cube into a “live” power strip or wall
outlet and then plug its other end into the
back of the Game Point!. Confirm that the Game Point!
light goes on.
port on the back of the Game Point! and
jack on the
Power
PWR
Important!
power cubes may damage the device.
3333 Change the
static IP addressing, and the IP address and subnet mask
shown on the next page. Be sure to make note of what the
Chapter 1: Installing the Game Po int! 7
Only use the power cube shipped with the G am e Point!. Other
TCP/IP
Settings on the computer so that it uses
settings are prior to changing them as you will need to restore
these settings later.
IP Address
Subnet Mask
Setting up Static IP Addressing for Game Point!
Windows XP, 2000: If you’re running Windows XP or 2000, open up the
and then double-click
Panel
Connection
Use the following IP address
mask of
255.255.255.0
Windows Me or 98: If you’re running Windows Me or 98, open up the
and then double-click
Panel
you’re using for Game Point! and then click
IP address
subnet mask of
opened.
Macintosh, Linux and other computers: See
Settings
on page 33.
4444 Open a Web browser, type
then press
5555 When the
the
Login
: 10.0.0.100
: 255.255.255.0
Network Connections
. Highlight
or
Specify an IP Address
Internet Protocol (TCP/IP
and click OK. Then close the windows you’ve opened.
Network
255.255.255.0
. (This is the IP address of the Game Point!.)
Enter
Login Screen
button to access the
. Double-click
) and click
. Enter an IP address of
. Highlight the TCP/IP Ethernet port
Properties
. Enter an IP address of
and click OK. Then close the windows you’ve
Appendix B: Setting Up TCP/IP
10.0.0.200
10.0.0.100
. Select
in the address bar, and
Local Area
Properties
and a subnet
Control
Use the following
10.0.0.100
opens, do not enter a password. Click
Web Management Interface
for the Game Point!.
Control
. Select
and a
Click
6666
System
Operation Mode
7777 From the
Bridge (Infrastructure)
Client Bridge AdHoc, please see
AdHoc Network
8888 Click the
8 Zoom Game Point! User Guide
in the left navigational menu, then click
to open the
Operating Mode
Operating Mode
drop-down list, select
. (For information about setting up
Appendix C: Setting Up an
on page 41.)
Save Changes
button.
page.
Client
9999 When a confirmation message appears, click
operating mode. Another message will appear letting you know
that it may take a few moments while the unit resets itself and
changes its mode. Click OK. (Once the Game Point! reboots
itself, you will be prompted to log into the
Interface
10
10 Click
1010
again.)
Wireless
Site Survey
networks detected by the Game Point!. Click the
the network you want to be part of, then click OK when
asked to confirm this choice.
in the left navigational menu, then click
. The page that opens lists the wireless
to change the
OK
Web Management
SSID
of
11
11
1111
12
12 Click the
1212
13
13 Reset the computer’s
1313
14
14 Test that your Game Point! is set up properly. Shut down
1414
Game Point! works well with networks that have WEP
security or no security, and does not work with networks
that have WPA security turned on. If the wireless network
you just selected has no security enabled, continue at step
12. If the wireless network you just selected has WEP
security, click
menu. Specify the same WEP security settings as the
network, then click the
allow your Game Point! to access the wireless network. (If
you need more detailed information about setting security,
see
Chapter 2: Setting Security
close your Web browser.
before you changed them.
your PC and power it off. Power it back on. Open your
Web browser and go to a familiar site. If the Game Point!
is set up properly, you should be able to browse the Web.
WEP Configuration
Save Changes
Logout
icon at the top right of the screen, then
TCP/IP
in the left navigational
button. This will
on page 11).
settings to what they were
Chapter 1: Installing the Game Po int! 9
15
15 Connect the Game Point! to your Xbox or PlayStation®2.
1515
First unplug the Game Point’s power cube from the power
strip or wall outlet and disconnect the Game Point’s
Ethernet cable from the Ethernet port of the computer
you used to configure it. Then connect the Game Point! to
the Ethernet port of the gaming device and plug the Game
Point’s power cube into a “live” power strip or wall outlet
near this gaming device. Confirm that the Game Point!
light goes on.
PWR
16
16 You may want to try to position the unit’s antennas to
1616
improve wireless speed and coverage. Typically the
antennas should not be parallel. For example, try making
one vertical and one horizontal.
17
17 Restore the network connection for the computer you
1717
used to set up Game Point!:
• If the connection is via Ethernet, plug the Ethernet
cable back in to your computer.
• If the connection is via wireless, enable the wireless
connection using your wireless application software.
Congratulations!
client, and your gaming device should be able to wirelessly connect
to the wireless network you specified.
10 Zoom Game Point! User Guide
Your Game Point! is installed as an Ethernet
2
Setting Security
This chapter explains how to enable security for the Game Point!
using WEP.
When you first set up your Zoom Game Point!, security is turned
off by default. If you are joining a network that has WEP security
enabled, you need to set the same security on the Game Point! so
you can connect to the network.
Setting Up Security Using WEP
If you are already logged into the
begin with step 2. If you have not logged into the Web
Management Interface begin with step 1.
Web Management Interface
,
1111 Access the Game Point!’s
logging into the device, as explained below.
Directly connect the Game Point! to an Ethernet-equipped
aaaa
computer that has a Web browser. To do this, plug one
end of the included Ethernet cable into the
on the back of the Game Point! and plug the other end
into the Ethernet port on the computer.
Chapter 2: Setting Security 11
Web Management Interface
Ethernet
by
port
Plug the included power cube into a power strip or wall
bbbb
outlet and then plug its other end into the
Power
the back of the Game Point!.
jack on
Important!
Other power cubes may damage the device.
Change the TCP/IP Settings on your computer so that it
cccc
Only use the power cube shipped with the Game Point!.
uses static IP addressing and the IP address and subnet
mask below. Be sure to make note of what the settings are
prior to changing them, since you will need to restore
these settings later.
IP Address:
Subnet Mask:
If you do not know how to access and specify TCP/ IP settings on
Tip!
your computer, see
page 33.
Open a Web browser, type
dddd
then press
10.0.0.100
255.255.255.0
Appendix B: Specifying TCP/IP Settings
10.0.0.200
. (This is the IP address of the Game
Enter
in the address bar,
Point!.)
When the
eeee
Click the
Interface
Login Screen
button to access the
Login
for the Game Point!.
opens, do not enter a password.
Web Management
on
12 Zoom Game Point! User Guide
2222 From the Game Point!
Wireless
Configuration
in the left navigational menu, then click
to open the
Web Management Interface
WEP
WEP Configuration
page.
, click
3333 Use the
want to use
manually or automatically
that is on your network. If you choose the
you will have to enter hexadecimal keys. If you choose
automatically
generates hexadecimal keys based on the passphrase.
!
WEP Mode
64-bit manually
64-bit manually
are joining uses 64-bit security and four hexadecimal WEP
keys. When you select this option, the screen changes so
you can enter up to four WEP keys manually. Select the
option button for the key you want to enter (for example,
), then enter five hexadecimal pairs in the boxes
Key1
provided. The range for hexadecimal characters is 0-9, a-f
and A-F. Once you have entered the keys you want, click
the
Save Changes
drop-town list to specify whether you
or
automatically
. You must use the same security
manually
, you can enter a passphrase which automatically
– Choose this option if the network you
button
, or
128-bit
option,
Chapter 2: Setting Security 13
!
64-bit automatically
– Choose this option if the network
you are joining uses 64-bit security and a passphrase
(password) to define the hexadecimal keys. When you
select this option, the screen changes so you can specify
the passphrase. The passphrase can be 1-32 alphanumeric
characters, for example,
Save Changes
button. All four hexadecimal keys are
. When complete, click the
zoom
generated automatically and appear on the screen. (Write
down the hexadecimal keys—you may need them later.)
!
128-bit manually
– Choose this option if the network you
are joining uses 128-bit security and one hexadecimal WEP
key. When you select this option, the screen changes so
you can enter the WEP key manually. Enter 13
hexadecimal pairs in the boxes provided. The range for
hexadecimal characters is 0-9, a-f, and A-F. Once you have
entered the key, click
14 Zoom Game Point! User Guide
Save Changes
.
!
128-bit automatically
you are joining uses 128-bit security and a passphrase
(password) to represent the 13 hexadecimal pairs in the
key. When you select this option, the screen changes so
you can enter the passphrase. The passphrase can be 1-31
characters. Enter the passphrase in the
then click the
generated by the passphrase appears on the screen. (Write
down the hexadecimal key—you may need it later.)
Save Changes
– Choose this option if the network
PassPhrase
button. The hexadecimal key
box,
Click the
4444
then close your Web browser.
Reset the computer’s
5555
before you changed them.
Logout
icon at the top right corner of the screen,
TCP/IP
settings to what they were
6666 Connect the Game Point! to your Xbox or PlayStation®2.
First unplug the Game Point’s power cube from the power
strip or wall outlet and disconnect the Game Point’s Ethernet
cable from the Ethernet port of the computer you used to
configure it. Then connect the Game Point! to the Ethernet
port of the gaming device and plug the Game Point’s power
cube into a “live” power strip or wall outlet near this gaming
device. Confirm that the Game Point!
Congratulations!
wireless network. Your Game Point! installation should be
complete.
You have specified WEP security for your
light goes on.
PWR
Chapter 2: Setting Security 15
3
Advanced Options
Once your Game Point! is installed and running, you may want
to specify some advanced settings for the device. These
advanced options are not required and many users may not
need or want to use them. However, for those advanced users
that do, this chapter provides details about these options and
how to apply them.
To specify advanced options, you must log into the Game Point!’s
Web Management Interface
1111 Directly connect the Game Point! to an Ethernet-equipped
computer that has a Web browser. To do this, plug one end of
the included Ethernet cable into the
back of the Game Point! and plug the other end into the
Ethernet port on the computer. (If your Game Point! is already
connected to another device, such as a router or gaming
device, do not worry; simply plug it back in after you have used
an Ethernet-equipped computer to specify the settings you
need.)
, as explained below.
Ethernet
port on the
2222 Plug the included power cube into a power strip or wall outlet
and then plug its other end into the
the Game Point!.
Important!
Other power cubes may damage the device.
Chapter 3: Advanced Options 17
Only use the power cube shipped with the Game Point!.
jack on the back of
Power
3333 Change the TCP/IP Settings on your computer so that it uses
static IP addressing and the IP address and subnet mask below.
Be sure to make note of what the settings are prior to changing
them, since you will need to restore these settings later.
IP Address:
Subnet Mask:
If you do not know how to access and specify TCP/ IP settings on your
Tip!
computer, see
10.0.0.100
255.255.255.0
Appendix B: Specifying TCP/IP Settings
4444 Open a Web browser, type
press
5555 When the
the
Login
for the Game Point!.
. (This is the IP address of the Game Point!.)
Enter
Login Screen
button to access the
opens, do not enter a password. Click
on page 33.
10.0.0.200
in the address bar, then
Web Management Interface
One you are logged in, a navigational menu appears on the left side
of the
Web Management Interface
menu, a list of pages on which settings can be specified appears.
18 Zoom Game Point! User Guide
. If you click an item in the
The following table lists each page that you can access from the
Web Management Interface
. Each page is described in detail
later in this chapter.
Menu Item Page Use this Page to...
System
Password
Setting
Specify a password to restrict access to the
Game Point!’s
Interface
Web Management
.
Operation
Mode
LAN LAN Settings Specify a new name for the Game Point!
Wireless
Tools
Settings Specify wireless settings, such as SSID
WEP
Configuration
Site Survey Have the Game Point! search for and
Configuration
Tool
Firmware
Upgrade
Reset Reset the Game Point!, but retain the
Status View the current status of the Game Point!,
Specify whether to use the Game Point! as
client bridge infrastructure or client bridge
ad hoc. (Infrastructure is the default.)
device. By default, the name is set to
Game Point!. You can also specify static IP
addresses and a subnet mask if you are
using multiple Game Points!.
and channel information. The settings you
can specify on this page depend on the
operation mode of the Game Point!.
Specify WEP encryption settings for the
Game Point! to protect the wireless
network from unauthorized use. By default,
no security is applied.
display available wireless access points.
This page is only accessible when the
Operating Mode
(Infrastructure)
Backup the Game Point!’s current
configuration, restore the unit to a saved
configuration, or reset it to its factory
defaults.
If Zoom releases updated software for the
Game Point!, upgrade the firmware.
current configuration.
the wireless network, or the local area
network.
is set to
.
Client Bridge
Chapter 3: Advanced Options
19
Viewing the System Status Page
The
System Status
Management Interface
in the left navigational menu, then clicking
The status page shows you
Wireless Status
page opens when you first log into the
. (You can also access it by clicking
.)
Status
System Status, LAN Status
.
Web
Tools
, and
System Status
Provides version information about the Game Point!, including the
version of firmware currently installed on it.
Wireless Status
Shows the current wireless settings for the Game Point!, including
the SSID of the wireless network to which it is connected, the
Game Point! name, the channel on which it is broadcasting, its
mode (Client Bridge Infrastructure or AdHoc), and the type of
encryption (if any) applied for security (WEP).
20 Zoom Game Point! User Guide
LAN Status
Shows the current settings for your local area network, including
the IP address of the Game Point!, subnet mask, configuration, and
MAC address of the Game Point!.
Using the Password Settings Page
Use the
to access the
if you want to prohibit other users from logging in to the Game
Point!’s interface.
You can also use this page to specify how long the interface can
remain idle before it times out. (If it times out, a user will have to
log in again to continue using the interface.)
Password Settings
Web Management Interface
page to change the password needed
. This is typically done
Chapter 3: Advanced Options
21
To open the
navigational menu, then click
To change the password
Password Settings
Password Settings
page, click
System
.
in the left
1111 Enter the current password in the
default, there is not password, so if you are adding a password
for the first time, leave this box blank.)
Current Password
2222 Type the password that you now want to use in the
Password
characters and is not case sensitive.
3333 Type the new password again in the
Verification
4444 Click the
To change the idle time out
1111 In the
which the
current computer will time out (if the connection is idle for
that period of time). You can enter a value between 1 and 99.
2222 Click the
box. The password can be up to 12 alphanumeric
Re-Enter Password for
box.
Save Changes
Idle Time Out
Web Management Interface
Save Changes
button.
box, enter the number of minutes after
connection with the
button.
box. (By
New
22 Zoom Game Point! User Guide
Using the Operating Mode Page
Use the
the Zoom Game Point! as
Bridge AdHoc
By default, the Game Point! is set up as
Infrastructure
using the Game Point! in
on page 41 to set up a network with multiple Game Points! and
gaming devices in
To open the
left-navigational menu, then click
Operating Mode
.
. You only need to change this setting if you are
AdHoc
Operating Mode
page to specify whether you want to use
Client Bridge Infrastructure
Client Bridge
AdHoc
mode.)
mode. (Please see
page, click
Operation Mode
System
or
Appendix C
in the
.
Client
To specify the operation mode for the Game
Point!
From the
1111
plan to use the unit:
!
!
2222 Click the
Chapter 3: Advanced Options
Operating Mode
Client Bridge (Infrastructure).
want to connect to an existing wireless network through a
wireless access point or wireless router. If you know you
are unsure of which option to choose, select
Infrastructure
Client Bridge (AdHoc).
connect wirelessly without an access point to another
gaming device in a “peer-to-peer” setup.
Save Changes
.
drop-down list, select how you
Select this option if you
Select this option if you want to
button.
23
3333 When a confirmation message appears, click
operating mode. Another message will appear letting you know
that it may take a few moments while the unit resets itself and
changes mode. Click OK. (Once the unit reboots itself, you
will be prompted to log into the
again.)
Web Management Interface
to change the
OK
Using the LAN Settings Page
Use the
Point! device. By default, the Game Point! is set up to use a static
IP address (
(
Note to AdHoc Users
for your Game Point! devices in an AdHoc network.)
To open the
left-navigational menu, then click
LAN Settings
10.0.0.200
LAN Settings
page if you want to rename the Game
) to access its
-- You can also use the page to specify the LAN settings
page, click
Web Management Interface
in the
LAN
LAN Settings
.
To rename the Game Point! device
1111 [Optional] Enter a name for the Game Point!. By default, it is
named
Game Point!
.
.
2222 If you selected
Web Management Interface
AdHoc
3333 Keep the default subnet mask of the unit
4444 Click the
24 Zoom Game Point! User Guide
Save Changes
mode, specify the IP address for the
of the Game Point!.
255.255.255.0
button.
.
Using the Wireless Settings Page
Use the
Point!. If you need to select a channel for AdHoc mode, you can
do so on this page.
To open the
left-navigational menu, then click
Wireless Settings
Wireless Settings
page to specify the
page, click
Settings
Wireless
.
for the Game
SSID
in the
To specify wireless settings
The following steps assume that you want to set up a wireless
network.
Click the
1111
you clear this, wireless networking will be disabled).
Enable Wireless Network
check box. (Note that if
Channel displays only
for AdHoc mode
2222 In the
to join. This is the name of the wireless network that will
appear to other devices on your network. By default, this is set
to
zoom
and is case sensitive.
3333 (For AdHoc mode only. Select a
4444 Click the
Chapter 3: Advanced Options
box, enter the
SSID
. The SSID can be up to 32 alphanumeric characters
Save Changes
button.
of the network that you want
SSID
channel
.)
25
Accessing the WEP Configuration Pages
Use these two pages to specify security for your Game Point!.
To open these pages, click
then click
are covered in
WEP Configuration
Chapter 2: Setting Security
Wireless
in the left-navigational menu,
. Details about specifying security
on page 11.
Using the Site Survey Page
This page is only accessible when the Game Point!’s
is set to
Mode
Use the
available wireless networks in the area.
To open the
left-navigational menu, then click
Client Bridge (Infrastructure)
Site Survey
Site Survey
page to have the Game Point! detect the
page, click
Wireless
Site Survey
Operating
.
in the
.
To perform a Site Survey
1111 Click the
available wireless networks. Each one detected appears in a list
showing its
(802.11g or 802.11b), and signal strength (
2222 Click the
26 Zoom Game Point! User Guide
Refresh
SSID
button to have the Game Point! search for
, MAC address (
SSID
of the network you want.
BSSID
),
Channel, Type
Signal %
).
Using the Configuration Tools Page
Use the
current configuration to a backup file, to restore the unit to a saved
backup file, or to restore it to its factory defaults.
To open the
left-navigational menu, then click
Configuration Tools
Configuration Tools
page to save the Game Point!’s
page, click
Configuration Tools
Tools
in the
.
To backup the current settings
1111 Click the
Backup
button.
2222 When asked if you really want to save this file, click
3333 On the
computer where you want to save this file. By default, the file
is named
need it should you ever want to restore the Game Point! to this
configuration.
4444 Click
Chapter 3: Advanced Options
Save As
Save
dialog box, navigate to the location on your
backup.bin
.
. Be sure to note this location, you will
Save
.
27
To restore to a saved configuration
1111 Click the
backup file. Select the file, then click
is automatically entered in the
2222 Click the
that the Game Point! is being reset, click OK.
Browse
Restore
button and navigate to the location of the
. The path to the file
Save
Restore Settings
button. A message appears to let you know
box.
3333 Wait while the unit is reset using the saved configuration. You
will be prompted to log in to the
Interface
after the process is complete.
To restore to factory defaults
Click the
1111
that the Game Point! is being reset to factory defaults, click
OK
Default
.
button. A message appears to let you know
Web Management
2222 Wait while the unit is reset to its factory defaults. You will be
prompted to log in to the
the process is complete.
Web Management Interface
after
An alternative
If you do not want to log into the Game Point! to restore the
factory defaults, you can do the following. Unplug the Game Point!
from the wall outlet or power strip, insert a paper clip into the
Reload
While the button is depressed, plug the unit back in and continue
depressing the button for five seconds. All of the LEDs on the
Game Point! will go out and then turn back on. (If you do not keep
the button depressed for at least five seconds, the Game Point! will
be reset to its current configuration, NOT the factory defaults.)
28 Zoom Game Point! User Guide
pinhole on the bottom of the unit and depress the button.
Using the Firmware Upgrade Page
From time to time, Zoom may release updated software for your
Game Point!. Use the
software onto the unit. To see if there is a firmware update,
periodically visit the Zoom Web site (www.zoom.com).
Firmware Upgrade
page to install the new
To open the
left-navigational menu, then click
Firmware Upgrade
page, click
Firmware Update
Tools
in the
.
To update the firmware
Enter the path and name of the upgrade file, or click
1111
and navigate to the file. (Typically, you would have
downloaded the file to your computer from the
site.)
2222 Click the
upgrade.
You can verify whether the upgrade was successful by checking the
System Status
then click
Upload
Status
button. You will be prompted to confirm the
page (click
).
in the left navigational menu,
Tools
Browse
Zoom Web
Chapter 3: Advanced Options
29
Using the Reset Page
Use the
current settings.
To open the
then click
To reset the Game Point!
1111 Click the
2222 When prompted to confirm the reset click
page to reset the Game Point!, but maintain the
Reset
Reset
Reset
Reset
page, click
.
button.
in the left-navigational menu,
Tools
OK
.
3333 When a message appears to let you know that the unit is being
reset, click OK. You will be prompted to log into the Game
Point! again once the reset is complete.
30 Zoom Game Point! User Guide
Appendix A
Troubleshooting
Problem
I installed my Game Point!, but cannot connect my gaming device
to a wireless network.
Solution
Here are some things you can try:
1111 Power off your computer and power it on. Then open your
Web browser and try to browse the Web.
2222 Check the following: (
Management Interfa c e
page 17 for login information.)
• If you want to belong to a wireless network that is
connected by a wireless access point or wireless router,
check your
Bridge (Infrastructure)
information about the
• The Game Point! should have a fixed IP Address. Check
the
LAN Settings
Game Point!. Please see page 24 for information about
LAN Settings
• Go to the
there. If it is there, click on it to connect. Please see page
26 for information about using
• Go to the
security settings. Reenter them if necessary. Please see page
26 for information about accessing the
Configuration
Site Survey
WEP Configuration
Note: You need to log into the
to check the settings described below. Please see
Operating Mode
page to verify the IP Address of the
.
page and verify that your network is
page.
. It should be set to
. Please see page 23 for
Operating Mode
Site Survey
page and verify your
Web
.
.
WEP
Client
Appendix A: Troubleshooting 31
3333 Try using the
console.
network repair
function on your gaming
32 Zoom Game Point! User Guide
Appendix B
Specifying TCP/IP Settings
Accessing the Game Point!’s
requires that you plug the unit directly into the Ethernet port of a
computer. It also requires that the computer’s TCP/IP settings be
set for static IP addressing and the following IP address and subnet
mask:
IP Address:
Subnet Mask:
This Appendix details how to access and set the TCP/IP settings
for Windows, Macintosh, and Linux operating systems. Depending
on your operating system, follow the steps in the appropriate
section to ensure your TCP/IP settings are correct.
• If you are using Windows, see
• If you are using Macintosh, see
• If you are using Linux, see
10.0.0.100
255.255.255.0
Settings
Settings
page 39.
on page 34.
on page 37.
Web Management Interface
Windows TCP/IP
Macintosh TCP/IP
Linux TCP/IP Settings
on
Appendix B: Specifying TCP/IP Setting s 33
Windows TCP/IP Settings
How you configure your Windows computer’s network settings
differs, depending on your operating system.
Windows XP
Open the
1111
box.
aaaa
bbbb
cccc
Select
2222
255.255.255.0
respectively.
Click OK, then click
3333
Internet Protocol (TCP/IP) Propert ies
From the desktop, click the
, and then double-click
Panel
Double-click the
Select the
include “TCP/IP” in it, but not “AOL,” “Dial-up,” or
“Adapter”) and click the
Use the following IP address
button, open
Start
Network Connections
Local Area Connection
Internet Protocol (TCP/IP)
button.
and enter
Subnet mask
as the
Properties
IP address
.
Close
and
dialog
Control
.
icon.
entry (it should
10.0.0.100
and
,
34 Zoom Game Point! User Guide
Windows 2000
Open the
1111
box:
aaaa
bbbb
cccc
Ensure that
2222
enter
Subnet mask
3333 Click
Internet Protocol (TCP/IP) Propert ies
From the desktop, open the
click
Network Connections
Double-click the
Select the
include “TCP/IP” in it, but not “AOL,” “Dial-up,” or
“Adapter”) and click the
10.0.0.100
OK
Internet Protocol (TCP/IP)
Use the following IP address
, respectively.
, then click OK again.
Local Area Connection
and
255.255.255.0
Control Panel
.
Properties
as the
entry (it should
button.
is selected and
IP address
dialog
, then double-
icon.
and
Appendix B: Specifying TCP/IP Setting s
35
Windows 98/Me
Open the
1111
box.
aaaa
bbbb
cccc
Internet Protocol (TCP/IP) Propert ies
From the desktop, click the
Settings
Double-click the
dialog box.
Select the Ethernet card’s
“TCP/IP” in it, but not “AOL,” “Dial-up,” or “Adapter”)
and click the
, then
Control Panel
Properties
Network
Start
icon to display the
TCP/IP
button and then click
2222 On the IP Address tab, ensure that
selected and enter
Address
3333 Click
OK
10.0.0.100
and
Subnet Mask
, then click OK again.
and
, respectively.
dialog
button, point to
.
Network
entry (it should include
OK
Specify an IP address
255.255.255.0
as the
is
IP
36 Zoom Game Point! User Guide
Macintosh TCP/IP Settings
How you configure your Macintosh computer’s network settings
differs, depending on your Mac OS. For OS X, follow the
instructions below. Otherwise, go to page 38.
Mac OS X
From the
1111
Network
have to click the
Ensure that
2222
3333 Under the
4444 Under the
addressing and enter
address
5555 Click
Network
Dock
to display the
Show
TCP/IP
and
Apply Now
pane.
, choose
Configure
Automatic
drop-down tab, choose
Subnet mask
System Preferences
Network
button.)
is selected from the
tab, specify that you want to use static IP
10.0.0.100
respectively.
(or
if prompted) and close the
Save
and then
pane. (For OS X 3, you also
list box.
as the
and
255.255.255.0
Location
Built-in Ethernet
.
IP
Appendix B: Specifying TCP/IP Setting s
37
Mac OS 7.6.1 - 9.2.2
From the
1111
TCP/IP
Under
2222
3333 Under
addressing and enter
address
4444 Close the
save the changes. Click
Apple
to display the
Connect via:
Configure:
and
TCP/IP
menu, choose
TCP/IP
, select
, specify that you want to use static IP
10.0.0.100
Subnet mask
Window. You will be asked if you want to
Save
Control Panels
Window.
Ethernet built-in
and
255.255.255.0
, respectively.
.
.
and then
as the
IP
38 Zoom Game Point! User Guide
Linux TCP/IP Settings
The instructions for setting up static IP addressing vary
dramatically by distribution, so you may want to refer to your
particular version’s documentation.
If you have more than one network card installed, you will need to pick
Note:
distinct Ethernet identifiers for each (eth0, eth1, eth2, and so forth). If you select
an identifier other than eth0 for your Game Point!, u se that identifier throughout.
RedHat
Edit or create
/etc/sysconfig/network-scripts/ifcfg-eth0
that it contains the following lines:
DEVICE=eth0
BOOTPROTO=static
ONBOOT=yes
IPADDR=10.0.0.100
NETMASK=255.255.255.0
USERCTL=no
PEERDNS=no
GATEWAY=10.0.0.200
TYPE=ethernet
NETWORK=10.0.0.0
BROADCAST=10.0.0.255
so
Once you have modified this file and saved the changes, issue the
following commands to have the changes applied:
ifdown eth0
ifup eth0
Appendix B: Specifying TCP/IP Setting s
39
SuSE
Edit the file
10.0.0.100. The settings you need to specify will be similar to the
Red Hat example above.
/etc/rc.config
and specify a static IP address of
Reboot with this command:
/sbin/shutdown -r now
.
Debian
Locate
of 10.0.0.100. The settings you need to specify will be similar to the
Red Hat example above.
Reboot with this command:
/etc/network/interfaces
and specify a static IP address
/sbin/shutdown -r now
.
40 Zoom Game Point! User Guide
Appendix C
Setting Up an AdHoc Network
The Game Point! supports AdHoc networks. This network type is
also known as a peer-to-peer network. Within an AdHoc network,
the Game Point! connects your gaming device directly to other
gaming devices that are using a Game Point!. The network does
not include a wireless access point or wireless router. To set up a
peer-to-peer or AdHoc gaming network, complete these steps:
Installing the Game Point!
1111 Directly connect the Game Point! device to an Ethernet-
equipped computer that has a Web browser. To do this, plug
one end of the Ethernet cable into the
back of the Game Point! and plug the other end into the
Ethernet port on the computer.
Ethernet
2222 Plug the included power cube into a “live” power strip or wall
outlet and then plug its other end into the
back of the Game Point!. Confirm that the Game Point!
light goes on.
Power
port on the
jack on the
PWR
Important!
power cubes may damage the device.
3333 Change the
static IP addressing, and the IP address and subnet mask
shown on the next page. Be sure to make note of what the
settings are prior to changing them as you will need to restore
these settings later.
IP Address
Subnet Mask
Appendix C: Setting Up an AdHoc Network 41
Only use the power cube shipped with the G am e Point!. Other
TCP/IP
: 10.0.0.100
Settings on the computer so that it uses
: 255.255.255.0
Setting up Static IP Addressing for Game Point!
Windows XP, 2000: If you’re running Windows XP or 2000, open up the
and then double-click
Panel
Connection
Use the following IP address
mask of
Windows Me or 98: If you’re running Windows Me or 98, open up the
Panel
you’re using for Game Point! and then click
IP address
subnet mask of
opened.
Macintosh, Linux and other computers: See
Settings
. Highlight
255.255.255.0
and then double-click
or
Specify an IP Address
255.255.255.0
on page 33.
Network Connections
Internet Protocol (TCP/IP
. Enter an IP address of
and click OK. Then close the windows you’ve opened.
Network
. Highlight the TCP/IP Ethernet port
Properties
. Enter an IP address of
and click OK. Then close the windows you’ve
Appendix B: Setting Up TCP/IP
. Double-click
) and click
. Select
Properties
10.0.0.100
Use the following
10.0.0.100
Local Area
and a subnet
Control
Control
. Select
and a
4444 Open a Web browser, type
then press
5555 When the
the
Login
for the Game Point!.
Click
6666
System
Operation Mode
7777 From the
Bridge (AdHoc)
8888 Click the
Save Changes
. (This is the IP address of the Game Point!.)
Enter
Login Screen
opens, do not enter a password. Click
button to access the
in the left navigational menu, then click
to open the
Operating Mode
.
button.
10.0.0.200
in the address bar, and
Web Management Interface
Operating Mode
drop-down list, select
page.
Client
42 Zoom Game Point! User Guide
9999 When a confirmation message appears, click
operating mode. Another message will appear letting you know
that it may take a few moments while the unit resets itself and
changes its mode. Click OK. (Once the Game Point! reboots
itself, you will be prompted to log into the
Interface
10
10 Click
1010
again.)
Wireless
Settings
enter a
choice. (For information about using the
Settings
channel
in the left navigational menu, then click
. Enter an
. Click OK when asked to confirm this
page, see page 25.)
for the AdHoc network. Then
SSID
to change the
OK
Web Management
Wireless
11
11
1111
12
12 Click the
1212
13
13 Unplug the Game Point! Device 1 from your computer.
1313
14
14
1414
15
15 Repeat steps 5-9 then continue with step 16.
1515
16
16 Click
1616
Click
Settings
is now the IP Address of the Game Point! Device 1. Keep
the default
close your Web browser.
Plug in Game Point! Device 2.
Open a Web browser, type
and then press
Game Point! Device 2.)
Settings
for the Game Point! Device 1. Then enter the same
channel
in the left navigational menu, then click
LAN
. Enter
Wireless
. Enter the
. Click OK when asked to confirm this choice.
10.0.0.201
Subnet Mask 255.255.255.0
Logout
icon at the top right of the screen, then
Enter
in the left navigational menu, then click
in the
. (This is the default IP address of the
of the network that you entered
SSID
IP Address
10.0.0.200
in the address bar,
boxes. This
.
LAN
17
17 Click
1717
Settings
Appendix C: Setting Up an AdHoc Network 43
in the left navigational menu, then click
LAN
. Enter
10.0.0.202
in the
IP Address
LAN
boxes. This
is now the IP Address of the Game Point! Device 2. Keep
the default
18
18 Click the
1818
close your Web browser.
Subnet Mask 255.255.255.0
Logout
icon at the top right of the screen, then
.
19
19
1919
20
20
2020
21
21
2121
Congratulations!
network.
Reset the computer’s
before you changed them.
Configure each gaming device. Set the IP Address of
Gaming Device 1 to
Gaming Device 2 to
of
255.255.255.0
Connect the Game Point! Device 1 to Gaming Device 1
and Game Point! Device 2 to Gaming Device 2.
TCP/IP
100.0.0.211
100.0.0.212
for each gaming device.
Your Game Point! is installed in an AdHoc
settings to what they were
. Set the IP Address of
. Enter the Subnet Mask
44 Zoom Game Point! User Guide
Appendix D
LED Description
The following table describes each of the LEDs on the top of the
Game Point! and what each light means when it is flashing and/or
steady.
LED What it does Flashing/Steady Status
TX/RX Shows the
status of the
Game Point!’s
wireless link
LINK/ACT Shows the
status of the
Game Point!’s
Ethernet LAN
connection
When flashing green, the Game
Point! is sending or receiving data
wirelessly.
•
If it flashes green and then
becomes steady green, the Game
Point! has established a valid 100
Mbps Ethernet connection.
•
If it flashes orange and then
becomes steady orange, the
Game Point! has established a
valid 10 Mbps Ethernet
connection.
•
When flashing ( regardless of
color), the Game Point! is sending
or receiving data over the
Ethernet LAN.
PWR Shows whether
the Game Point!
is powered on.
Appendix D: LED Description 45
When steady green, the Game
Point! is powered on.
Appendix E
If You Need Help
If you are unable to get the Game Point! to operate and need
assistance, contact whoever sold you the Game Point!. You can
also use a variety of technical support services available to Zoom
customers. Please see the Customer Support information that is
available on the CD or go to www.zoom.com and select Technical
Support to find the support that’s right for you.
Appendix E: If You Need Help 47
Appendix F
Regulatory Information
U.S. FCC Part 15 Emissi on s Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These lim its are designed to
provide reasonable protection ag ainst harmful interference in a residential
installation. This equipm ent generates, uses and can radiate radio frequency and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determ ined by
turning the equipment off and on, the user is encour aged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This d evice may not cause harmful interferenc e, and
(2) this device must accept any interference received , inclu ding interference that
may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this
equipment.
IMPORTANT NOTE:
IEEE 802.11b or 802.11g operation of this product in the U.S.A. is firmwarelimited to channels 1 through 11.
Industry Canada Emissions Statement
This Class B digital apparatus meets all requirements of the Canadian
Interference-Causing Equipment Regulations. Cet appareil numérique de la classe
B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada.
Operation is subject to the following t w o conditions:
1) this device may not cause interference and
2) this device must accept any interference, inclu ding interference that may cause
undesired operation of the device.
Appendix F: Regulatory Information 49
European Declaration of Conformit y
The manufacturer declares under sole responsibility that this equipment is
compliant to Directive 1999/5/EC (R&TTE Directive) via the following. This
product is CE Marked.
Directive Standard Test Report
73/23/EEC-Low
Voltage
89/336/EEC-EMC EN55022 :1998+A1/2000+A2
89/336/EEC-EMC EN 301 489-1, 489-17 EMC
99/5/EC EN 300 328 V1.4.1 : 2003-04 Technical
EN 60950-1: 2001 electrical safety
:2003, Class B
EN61000-3-2 :2000, Class A
EN61000-3-3 :1995+A1:2001
EN61000-42 :1995+A1/1998+A2/2001
EN61000-43 :1996+A1/1998+A2/2001
EN61000-44 :1995+A1/2001+A2/2001
EN61000-4-5 :1995+A1/2001
EN61000-4-6 :1996+A1/2001
EN61000-411 :1994+A1/2001
EMC
Requirements
for Emissions
and Immunity
Requirements
for Radio
Equipment
Requirements
for 2.4GHz
Radio
Equipment
50 Zoom Game Point! User Guide
Countries of Operation & Conditions of Use in the European
Community
This device is intended to be operated in all countries of the European
Community.
Requirements for indoor vs. outdoor operation, license requirements and allowed
channels of operation apply in some countries as described below:
Note: The user must use the configuration utility provided with this product to
ensure the channels of operation are in conformance with the spectrum usage
rules for European Community countries as described below.
This device requires that the user or installer properly enter the current
•
country of operation in the command line interface as described in the user
guide, before operating this device.
This device will automatically limit the allowable c hannels determined by the
•
current country of operation. Incorrectly entering the cou ntry of operation
may result in illegal operation and may cause harmful interference to other
system. The user is obligated to ensure the device is operating according to
the channel limitations, indoor/outdoor restrictions and license requirements
for each European Community country as described in this document.
This device may be operated
•
European Community using the 2.4 GHz band: Channels 1 - 13, except
where noted below.
- In Italy the end-user must apply for a license from the national spectrum
authority to operate this device ou tdoors.
- In Belgium outdoor operation is only permitted using the 2.46 - 2.4835 GHz
band: Channel 13.
- In France outdoor operation is only permitted using the 2.4-2.454 GHz
band: Channels 1-7.
indoors or outdoors
in all countries of the
Electrostatic Discharge Statement
The unit may require resetting after a severe electrostatic discharge event.
Additional compliance information is located on the CD.
Appendix E: Regulatory Information 51
We, the undersigned,
Declaration of Conformity
Company
Address, City
Country
Phone number
Fax number
certify and declare under our sole responsibility that the following equipment:
Product description / Intended use
EU / EFTA member states intended for
use
Member states with restrictive use
Manufacturer
Brand
Type
is tested to and conforms with the essential requirements for protection of health and the
safety of the user and any other person and Electromagnetic Compatibility, as included in
following standa rds:
Standards Issue Date
EN60950-1
EN301 489-1 V1. 4.1
EN301 489-17 V1 .2 .1
EN55022
and is tested to and conforms wi th the essential radio test suites so that it effectively u ses
the frequency spectrum allocated to terrestrial/space radio communication and orbital
resources so to as to avoid harmful interference, as included in following standards:
Standard Issue Date
EN300 328 V1.4.1 2003-04
and therefor e complies with the essential requirements and provisi ons of the
Directive 1999/5 /EC
Radio equipment and Telecommunications Terminal Equipment and the mutual
recognition of their conformity and wit h the provisions of Ann ex II (Conformity
Assessment procedure referred to in article 10(3)).
of the European Parlia ment and of the council of March 9, 1999 on
Zoom Telephonics, Inc.
207 South Stree t , Bo ston, Massachuse t ts 02 1 11
USA
617 423 1072
617 542 8276
EU
: Austria, Belgium, Denmark,
Finland, France, Germany Greece,
Ireland, Italy, Luxembourg, The
Netherlands, Portugal, Spain, Sweden,
United Kingdom
EFTA
: Switzerland, Iceland,
Lichtenstein, Norway
None
Zoom Technologies, Inc.
Zoom Game Point!
Model 4420
2001
2002-08
2002-08
1998+A1/2000+A2/2003, Class B
The following Notified Body has been consulted in the Conformity Assessment procedure:
Notified Body number
N/A
Name and address
52 Zoom Game Point! User Guide
The technical documentation as required by the Conformity Assessment procedure is kept at
the following address:
Company
Address, City
Country
Phone number
Fax number
Zoom Telephonics, Inc.
207 South Stree t , Bo ston, Massachuse t ts 02 1 11
USA
617 423 1072
617 542 8276
TCF/TF reference nr.
Drawn up in Boston, MA USA
Date July 21, 2005
Name and position
4400/TF
Director, Hardware Engineeri ng
Andy Pollock,
Appendix E: Regulatory Information 53
NOTICE
NOTICE
NOTICENOTICE
This document contains proprietary information protected by
copyright, and this Manual and all the accompanying hardware,
software, and documentation are copyrighted. No part of this
document may be p hotocopied or reproduced by mechanical,
electronic, or other means in any form.
The manufacturer does not warrant that the hardware will work
properly in all environments and applications, and makes no
warranty or representation, either expressed or implied, with respect
to the quality, performance, merchantability, or fitness for a
particular purpose of the software or documentation. The
manufacturer reserves the right to make changes to the hardware,
software, and documentation without obligation to notify any person
or organization of the revision or change.
Playstation and Playstation2 are registered trademarks of Sony
Computer Entertainment Inc.
Sony is a registered trademark of the Sony Corporation.
©2005 Microsoft Corporation. All Rights Reserved. Xbox, Xbox Live,
the Live Logo, and the Xbox logos are registered trademarks or
trademarks of Micr osoft Corp.
All brand and product names are the trademarks of their respective
owners.
© Copyright 2005
All rights reserved.
2785-B 27388 ©2005
Loading...
