www.silverlinetools.com
228541
|
Clamp |
Meter |
Digital |
AC & DC |
|
|
|
Digital Clamp Meter
Pince ampèremétrique numérique
Digitales Zangenmessgerät
Pinza amperimétrica digital
Pinza amperometrica digitale
Digitale ampèretang
www.silverlinetools.com
2 |
3 |
1 |
4 |
5 |
10 |
9 |
8 |
7 |
6 |
2
®
Digital |
Clamp |
|
AC & DC
English................... |
4 |
Français................. |
8 |
Deutsch.................. |
12 |
Español.................. |
16 |
Italiano................... |
20 |
Nederlands............ |
24 |
www.silverlinetools.com 3
GB
Description of Symbols
The rating plate on your tool may show symbols. These represent important information about the product or instructions on its use.
Wear hearing protection
Wear eye protection
Wear breathing protection
Wear head protection
Wear hand protection
Read instruction manual
Conforms to relevant legislation and safety standards
Environmental Protection
Waste electrical products should not be disposed of with
household waste. Please recycle where facilities exist. Check with
your local authority or retailer for recycling advice
Specification
The following specifications assume a 1-year calibration cycle and an operating temperature of 18°C to 28°C (64°F to 82°F) at relative humidity up to 80% unless otherwise noted.
AC Current
(Average sensing, calibrated to rms of sine wave)
Range |
Resolution |
Accuracy (50Hz - 60Hz) |
|
200A |
100mA |
±(2.5% of reading ±10 digits) |
|
1000A |
1A |
±(2% of reading ±5 digits |
|
|
|
for 800A and below |
|
|
|
± (3% of reading ±5 digits) |
|
|
|
for other current |
|
Overload Protection: |
|
1000A within 60 seconds |
|
Jaw Opening: |
|
2" (5cm) |
AC Voltage
(Average sensing, calibrated to rms of sine wave)
Range |
Resolution |
Accuracy (50Hz - 500Hz) |
600V |
1V |
±(1.2% of reading ±5 digits) |
Input Impendance: |
|
9MΩ |
Overload Protection: |
|
600V AC/DC on all ranges |
DC Voltage |
|
|
Range |
Resolution |
Accuracy (50Hz - 500Hz) |
600V |
1V |
±(1% of reading ±2 digits) |
Overload Protection: |
|
600V DC/peak AC on all |
|
|
ranges |
Input Impendance: |
|
9MΩ |
Resistance |
|
|
|
Range |
Resolution |
Accuracy (50Hz - 500Hz) |
|
200Ω |
0.1Ω |
±(1% of reading ±3 digits) |
|
20KΩ |
10Ω |
±(1% of reading ±1 digits) |
|
Overload Protection: |
|
500V DC/rms AC on all ranges |
|
Continuity Test |
|
|
|
Range: |
200Ω |
|
|
Buzzer Sound: |
30+ 20Ω |
|
|
Overload Protection: |
500V DC/rms AC |
|
|
Environment |
|
|
|
Temperature: |
18˚C-28˚C |
(64˚F-82˚F) |
|
Normal Operation: |
|||
Usable Condition: |
0˚C-50˚C |
(32˚F-122˚F) |
|
Storage: |
-20˚C-+60˚C |
(-30˚F-140F) |
|
|
battery removed and<80% RH |
||
Relative Humidity: |
Max. 80% |
|
|
Measurement Method: |
Dual slope integration technical |
||
Reading Rate: |
3 reading/sce |
|
|
Polarity: |
Automatic, indicated minus, |
||
|
assumed plus |
|
|
Overload Indication: |
Blanking of all digits, except |
||
|
MSD,decimal point and sign |
||
|
appropiate |
|
|
Power Requirements: |
9V Battery |
|
|
Battery Life: |
Up to 200 hours typical with |
||
|
Alkaline |
|
|
|
Up to150 hours typical with Zinc |
||
Battery Indication: |
Display indicates LO BAT when |
||
|
approximately 20% of battery |
||
|
life remains |
|
|
Display: |
LCD 31⁄2 digit (1999 count) |
||
|
0.5" high |
|
|
Data Hold: |
All function and ranges with this |
||
|
feature |
|
|
Weight: |
Approx 11 ounces (310 grams) |
||
AC Current: |
0.1A to 1000A |
|
|
AC Voltage: |
1V to 600V |
|
|
DC Voltage: |
1V to 600V |
|
|
Resistance: |
200Ω to 2000MΩ |
|
|
Continuity Test: |
30+ 20Ω with audio tone |
As part of our ongoing product development, specifications of Silverline products may alter without notice.
4
228541 |
Digital Clamp Meter |
|
|
General Safety
Carefully read and understand this manual and any label attached to the tool before use. Keep these instructions with the product for future reference. Ensure all persons who use this product are fully acquainted with this manual.
Even when used as prescribed it is not possible to eliminate all residual risk factors. Use with caution. If you are at all unsure of the correct and safe manner in which to use this tool, do not attempt to use it.
Keep guards in position
•Where guards exist keep them in position, in good working order, correctly adjusted and aligned. Never attempt to use a tool if any of the supplied guards are missing. If any guards are damaged, replace before use
Remove adjusting keys
•Where adjusting keys exist, ensure they are removed prior to using the tool. Always check to see that keys and adjusting devices are removed from the tool before use
Clean the work area
•Accidents can occur where benches and work areas are cluttered or dirty. Keep floors clear and avoid working where the floor is slippery. If working outdoors, be aware of all potential slip and trip hazards before using this tool
Trained, competent persons
•This tool should be used by trained, competent persons only
Children and pets
•Keep children and pets at a safe distance from the work area. Lock tools away where children cannot gain access
Use the correct tool
•Do not force or attempt to use a tool for a purpose for which it was not designed. This tool is not intended for industrial use
Wear suitable clothing and footwear
•Do not wear loose fitting clothing, neckties, jewellery, or other items which may become caught. Wear non-slip footwear or, where appropriate, footwear with protective toe caps. Long hair should be covered or tied back
Keep your balance
•Do not over-reach. Keep proper footing at all times and do not use tools when standing on an unstable surface
Accessories
•The use of any attachment or accessory, other than those mentioned in this manual, could be dangerous and result in damage or injury, and may invalidate your warranty
Never stand on your tool
•Standing on your tool or its stand could cause serious injury if the tool is tipped or collapses. Do not store materials above or close to the tool in such a way that a person might stand on the tool to reach the stored items
Secure work
•Where possible, always secure work. If appropriate, use a clamp or vice so that both hands are free to operate the tool
Check for damaged or missing parts
•Before each use, check if any part of the tool is damaged or missing. Carefully check that it will operate properly and perform its intended function. Check alignment of moving parts for binding. Any guard or other part that is damaged should be immediately repaired or replaced by an authorised service centre. DO NOT USE IF DEFECTIVE
Safety Instructions For Clamp
Meter
•Before using this instrument, inspect the test leads for damage, such as cracks or breaks in the insulation. Do this before every use. If leads are found to be defective, have them replaced by a qualified technician
Product Familiarisation
1Lever
2Transformer Jaws
3Data Hold Switch
4Rotary Switch
5Display
6Wrist Strap
7EXT Input Connector
8COM Input Connector
9V, Ω Input Connector 10 Test Leads
Unpacking Your Tool
•Carefully unpack and inspect your tool. Fully familiarise yourself with all its features and functions
•Ensure that all parts of the tool are present and in good condition. If any parts are missing or damaged, have such parts replaced before attempting to use this tool
www.silverlinetools.com 5
GB
Operating Instructions
Insert Battery
1.In the back of the unit, undo the retaining screw and remove the battery compartment cover – use a sliding motion to disengage the cover.
2.Connect 9V battery to the correct terminals.
3.Insert connected battery into the compartment.
4.Replace the cover and secure with the retaining screw.
AC Current Measurement
IMPORTANT: Make sure that all test leads are disconnected from instrument terminals
1.Make sure the Data Hold Switch (3) is not pressed.
2.If the display indicates one or more leading zeros, shift to the 200A range to improve the resolution of the measurement.
3.Press the lever to open the transformer jaws and clamp one conductor ONLY. It is impossible to make measurements when two or three conductors are clamped at the same time.
AC Voltage Measurement
1.Set Rotary Switch (4) to the V~600 position.
2.Insert the red lead into the V,Ω Input Connector (9) and the black lead to the COM Input Connector (8).
3.Connect the probes to the circuit under test and take the reading.
DC Voltage Measurement
1.Set Rotary Switch (4) to the V600 position.
2.Insert the red lead into the V,Ω Input Connector (9) and the black lead to the COM Input Connector (8).
3.Connect the probes to the circuit under test and take the reading.
Resistance Measurement & Continuity Check
WARNING: Make sure there is no residual voltage in the circuit of components being measured
1.Set Rotary Switch (4) to the Ω position.
2.Insert the red lead into the V,Ω Input Connector (9) and the black lead to the COM input connector (8).
3.With the test leads open, Display (5) should indicate an over range condition.
4.Hold the test probes together to make sure that the display reads zero and that the buzzer will sound.
5.Connect test leads to the circuit to be tested and take the resistance reading.
6.If the resistance measured is less than 40Ω the buzzer will sound, indicating continuity check.
Disposal
•Do not dispose of power tools, or other waste electrical and electronic equipment, with household waste
•Contact your local waste disposal authority for information on the proper way to dispose of tools
6
228541 |
Digital Clamp Meter |
|
|
Silverline Tools Guarantee
This Silverline product comes with a 3 year guarantee
Register this product at www.silverlinetools.com within 30 days of purchase in order to qualify for the 3 year guarantee. Guarantee period begins according to the date of purchase on your sales receipt.
Registering your purchase
Registration is made at silverlinetools.com by selecting the Guarantee Registration button. You will need to enter:-
•Your personal details
•Details of the product and purchase information
Once this information is entered your guarantee certificate will be created in PDF format for you to print out and keep with your purchase.
Terms & Conditions
Guarantee period becomes effective from the date of retail purchase as detailed on your sales receipt.
PLEASE KEEP YOUR SALES RECEIPT
If this product develops a fault within 30 days of purchase, return it to the stockist where it was purchased, with your receipt, stating details of the fault. You will receive a replacement or refund.
If this product develops a fault after the 30 day period, return it to:
Silverline Tools Service Centre PO Box 2988
Yeovil
BA21 1WU, UK
The guarantee claim must be submitted during the guarantee period.
You must provide the original sales receipt indicating the purchase date, your name, address and place of purchase before any work can be carried out.
You must provide precise details of the fault requiring correction.
Claims made within the guarantee period will be verified by Silverline Tools to establish if the deficiencies are related to material or manufacturing of the product.
Carriage will not be refunded. Items for return must be in a suitably clean and safe state for repair, and should be packaged carefully to prevent damage or injury during transportation. We may reject unsuitable or unsafe deliveries.
All work will be carried out by Silverline Tools or its authorized repair agents.
The repair or replacement of the product will not extend the period of guarantee
Defects recognised by us as being covered by the guarantee shall be corrected by means of repair of the tool, free of charge (excluding carriage charges) or by replacement with a tool in perfect working order.
Retained tools, or parts, for which a replacement has been issued, will become the property of Silverline Tools.
The repair or replacement of your product under guarantee provides benefits which are additional to and do not affect your statutory rights as a consumer.
What is covered:
The repair of the product, if it can be verified to the satisfaction of Silverline Tools that the deficiencies were due to faulty materials or workmanship within the guarantee period.
If any part is no longer available or out of manufacture, Silverline Tools will replace it with a functional replacement part.
Use of this product in the EU.
What is not covered:
Silverline Tools does not guarantee repairs required as a result of:
Normal wear and tear caused by use in accordance with the operating instructions eg blades, brushes, belts, bulbs, batteries etc.
The replacement of any provided accessories drill bits, blades, sanding sheets, cutting discs and other related items.
Accidental damage, faults caused by negligent use or care, misuse, neglect, careless operation or handling of the product.
Use of the product for anything other than normal domestic purposes. Change or modification of the product in any way.
Use of parts and accessories which are not genuine Silverline Tools components.
Faulty installation (except installed by Silverline Tools).
Repairs or alterations carried out by parties other than Silverline Tools or its authorized repair agents.
Claims other than the right to correction of faults on the tool named in these guarantee conditions are not covered by the guarantee.
EC Declaration of Conformity
The technical documentation is kept by: Silverline Tools
The undersigned: Mr Darrell Morris as authorised by: Silverline Tools Declares that the
Name/ model: Digital Clamp Meter
Type/ serial no: 228541
Conforms to the following Directives:
•EMC Directive 2004/108/EC
•Low voltage directive 2006/95/EC
•ROHS Directive 2002/95/EC
•EN61010-2:2010; EN61010-031:2002+A1:2008
•EN61326-1:2006
Notified body: VOP
Place of declaration: Vyskov, Czechoslovakia
Date: 07/09/11
Signed by:
Director
Name and address of Manufacturer or Authorised representative:
Silverline Tools, Boundary Way, Lufton Trading Estate, Yeovil, Somerset,
BA22 8HZ United Kingdom
www.silverlinetools.com 7
F
Description des symboles
La plaque signalétique figurant sur votre outil peut présenter des symboles. Ces symboles constituent des informations importantes relatives au produit ou des instructions concernant son utilisation.
Port de protection auditive
Port de lunettes de sécurité
Port de masques respiratoires
Port du casque
Port de gants
Lire le manuel d’instructions
Conforme à la réglementation et aux normes de sécurité pertinentes
Protection de l’environnement
Les produits électriques usagés ne doivent pas être jetés avec les ordures ménagères. Veuillez les recycler dans les centres prévus à cet effet. Pour de plus amples informations, veuillez contacter votre municipalité ou point de vente
Caractéristiques techniques
Les données suivantes sont fondées sur un cycle de calibration d'un an et une température de service comprise entre 18 °C et 28 °C avec une humidité relative maximum de 80 %, sauf indication contraire.
Intensité courant alternatif
(Relevé moyen, calibration suivant valeur efficace (rms) d'onde sinusoïdale)
Plage |
Résolution |
Précision (50 Hz - 60 Hz) |
200 A |
100 mA |
± (2,5 % ±10) |
1000 A |
1 A |
± (2 % du relevé ±5) |
|
|
pour 800 A et moins |
|
|
± (3 % du relevé ±5) |
Protection surcharge : |
|
pour autre intensité |
|
1000 A en moins de 60 |
|
Ouverture mâchoires : |
|
secondes |
|
5 cm |
Tension courant alternatif
(Relevé moyen, calibration suivant valeur efficace (rms) d'onde sinusoïdale)
Plage |
Résolution |
Précision (50 Hz - 500 Hz) |
600 V |
1 V |
±(1,2 % de mesure ±5) |
Impédance d’entrée : |
|
9 MΩ |
Protection surcharge : |
|
600 V CA/CC pour toutes |
|
|
plages |
Tension courant continu |
|
|
Plage |
Résolution |
Précision (50 Hz - 500 Hz) |
600 V |
1 V |
± (1,2 % du relevé ±2) |
Protection surcharge : |
|
600 V CC/max. CA pour toutes |
|
|
les plages |
Impédance entrée : |
|
9 MΩ |
Résistance |
|
|
|
Plage |
Résolution |
Précision (50 Hz - 500 Hz) |
|
200 Ω |
0,1 Ω |
± (1 % du relevé ±3) |
|
20K Ω |
10 Ω |
± (1 % du relevé ±1) |
|
Protection surcharge: |
|
500 V CC/valeur efficace CA |
|
|
|
pour toutes les plages |
|
Essai de continuité |
|
|
|
Plage : |
200 Ω |
|
|
Son avertisseur : |
30+ 20 Ω |
|
|
Protection surcharge : |
500 V CC/valeur |
|
|
|
efficace CA |
|
|
Environnement |
|
|
|
Température : |
|
|
|
Fonctionnement |
18 ˚C-28 ˚C |
|
(64 ˚F-82 ˚F) |
normal : |
|
||
Condition d'utilisation : |
0 ˚C-50 ˚C |
|
(32 ˚F-122 ˚F) |
Conservation : |
Entre -20 ˚C et +60 ˚C Sans |
||
|
la pile et sous HR < 80 % |
(-30 ˚F-140 ˚F) |
|
Humidité relative : |
Max. 80% |
|
|
Méthode de mesure : |
Intégration double pente |
|
|
Fréquence de mesure : |
3 mesures/seconde |
|
|
Polarité : |
Automatique, ‘moins’ indiqué, |
|
|
|
‘plus’ supposé |
|
|
Indication surcharge : |
Effacement de tous les |
|
|
|
chiffres, sauf du chiffre le |
|
|
|
plus significatif (MSD), point |
|
|
|
décimal et signe approprié |
|
Alimentation :
Durée utile maximum pile :
Indication pile :
Affichage :
Mémorisation données :
Poids : Intensité CA : Tension CA : Tension CC : Résistance :
Essai de continuité :
Pile 9 V
200 heures maximum pour pile alcaline
150 heures pour pile au Zinc
L'écran indique LO BAT (pile déchargée) lorsqu'il reste environ 20 % de la charge de la pile
Ecran cristaux liquides 3 chiffres ½ (compteur 1999) hauteur 0, 5 “ (12, 7 mm)
Toutes fonctions et plages avec cette mémoire
310 grammes
de 0,1 A à 1 000 A de 1 V à 600 V
de 1 V à 600 V
de 200 Ω à 2 000 kΩ
30+ 20 Ω avec tonalité audio
Du fait de l’évolution constante de notre développement produits, les spécifications des produits Silverline peuvent changer sans notification préalable.
8
