Silvercrest SLG 1.0 A1 User Manual
USB Charger SLG 1.0 A1
Operating and Safety Instructions
V 1.5
IAN 70999
Before you use this device for the first time
please read and follow these instructions, even if
you are familiar with handling electronic devices!
Keep the instructions and pass them on with the
device if applicable.
In the following, this symbol indicates risks which
could result in personal injury or damage.
Package Contents
USB Charger SilverCrest SLG 1.0 A1
User's Manual
Safety Instructions
Intended Use
The SLG 1.0 A1 USB charger adapter is intended to be
used exclusively to charge devices with a USB charger
receptacle using a 110/240 V AC socket. Any use other
than that mentioned above does not correspond to the
intended use.
The manufacturer accepts no liability if:
the USB charger adapter is not used in accordance
with the intended use;
the USB charger adapter is damaged or operated
when incomplete or modified;
devices are connected which cannot be charged via
USB. Check the documentation for the device you
wish to connect.
This is an information technology device. It may only be
used for private purposes, not for industrial or
commercial purposes.
General safety instructions
Electrical devices should not be operated by children
or people with mental or physical disabilities. Do not
allow these people to use electrical devices when not
under supervision. They may not understand that
they can be dangerous.
Small parts can represent choking hazards. Please
also note that there is a risk of suffocation if airways
are blocked by the packaging film.
If you notice any smoke, unusual noises or strange
smells, immediately unplug the USB charger adapter
from the mains socket. If this occurs the device
should no longer be used and should be inspected
by authorized service personnel.
Operational safety
Do not connect devices which contain batteries to
the USB charger adapter, as these can explode
during the charging process.
The automatic power-off feature of the USB charger
adapter does not fully disconnect the device from the
mains. Unplug it from the power outlet to fully
disconnect it from the mains.
Never open the housing of the device. Opening the
housing exposes you to lethal electric shocks.
Only use the USB charger adapter in a power socket
which is easy to access so that it can be quickly
disconnected in the event of a problem (smoke,
burning smell).
Before stormy weather and/or when there is the
danger of lightning, disconnect the USB charger from
the mains. This will protect your USB charger and the
connected device from damage due to lightning
strike.
A damaged or incorrectly installed power outlet can
cause a fire or electric shock. The USB charger
adapter should therefore only be connected to power
sockets which are undamaged, fully assembled and
properly installed.
There is also a risk of fire if the USB charger adapter
is not fully inserted into the power socket, resulting in
a loose connection.
Do not use an adapter plug or extension cable which
is damaged or that does not meet the required safety
standards.
Please also remember that children may be able to
unplug the USB charger from the power socket and
gain access to an exposed power socket.
To disconnect a cable, pull on the plug of the USB
charger adapter, not the cable. Make sure that the
cable is not kinked and is not in anyone's way.
If the USB charger adapter is exposed to broad
temperature fluctuations condensation can form and
cause moisture which can produce a short circuit. If
this occurs, use the USB charger adapter only after it
has reached the ambient temperature.
Operating Environment/Environmental
Conditions
Keep the USB charger adapter away from moisture.
Do not place any recipients containing liquids
(beverages, vases, etc.) next to the device. Avoid
vibrations, dust, heat and direct sunlight. These can
damage the charger.
Controls and Display Elements
Pos. Function, controls
POWER button: keep this button pressed for at least 1
1
second to start the charging process for the connected
device. The charging LED [3] will flash for a few
seconds whilst charging is being prepared. During
charging, the charging LED [3] will light continuously.
The USB charger adapter powers off automatically as
soon as the connected device is fully charged.
Cable holder. Wind the USB cable (max. 1.2m) of the
2
device you wish to charge here.
Charging LED (visible when illuminated only).
3
Device connector. Connect the USB cable of the device
4
you wish to charge here.
Power plug. Plug it into a properly installed power
5
socket that is easy to access.
Cleaning
Disconnect the USB charger adapter from the
power socket and remove all connected devices
prior to cleaning otherwise your life is in danger
due to electric shock.
Furthermore, there is a risk of a short circuit causing
damage to the USB charger adapter and the
connected device.
If dirty, clean with a dry cloth or a slightly damp cloth for
stubborn dirt. Do not use any solvents, irritants or
gaseous cleaners. No moisture must penetrate into the
adapter.
Disposal of Old Devices
The product bears the symbol of a rubbish bin
crossed out. The European Directive
2002/96/EC therefore applies.
All electrical and electronic devices must be disposed
of separately from household waste at official disposal
centres. For further information, contact your local
government, disposal bodies or the shop where you
bought the device.
Legal Requirements
The USB charger adapter fulfils all relevant norms
and standards relating to conformity. Any
modifications to the USB charger adapter may result
in these directives no longer being met.
If you are not using the charger adapter within the
Republic of Germany, you must observe the
regulations and laws in the country of use.
Manufacturer: TARGA GmbH, Postfach 2244,
D-59482 Soest, Germany
Conformity Notice
This USB charger adapter complies with the basic and
other relevant requirements of EMC Directive
2004/108/EC and the Low-Voltage Directive
2006/95/EC.
Technical data
Model USB charger adapter SLG 1.0
Dimensions (diameter x H) 54 x 72 mm
Weight 45 g
Connection input UK plug
Connection output USB-A socket
Input voltage 100 – 240 V ~
Input current 0.15A
Output voltage 5 V
Output current 1A
Standby power
consumption
Compatibility USB 2.0, USB 1.1
Temperature 10 - 35 °C
Air humidity (rel. humidity) Max. 85 %
A1
50Hz / 60 Hz
0 W
charging cable which you can buy
The USB charger
adapter does not
power off after the
battery has been
charged.
separately. This is not a
malfunction of the charger.
The connected device is faulty or
cannot be charged via USB.
The standby current of the
connected device is too high. If
necessary, power off the device
after the battery has been charged.
Warranty Information
Troubleshooting
Problem Cause, action
Device is not charged
Press and hold the POWER button
Power socket defective or fuse
No USB connection to device:
The charging current is lower than
Some devices, especially mobile
[1] for at least 1 second to start the
charging process.
blown: check the power socket by
connecting a different device.
check the USB connection.
40 mA. It is not possible to charge
devices with a charging current
lower than 40 mA.
telephones, require a special USB
