HAIR STRAIGHTENERS SHGD 52 A1
HAIR STRAIGHTENERS
Operating instructions
HAARGLÄTTER
Bedienungsanleitung
IAN 277700
ΙΣΙΩΤΙΚΗ ΣΥΣΚΕΥΗ ΜΑΛΛΙΩΝ
Οδηүίες χρήσης
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τη σελίδα με τις εικόνες και εξοικειωθείτε με όλες τις λειτουργίες
της συσκευής.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.
GB / CY Operating instructions Page 1
GR / CY Οδηүίες χρήσης Σελίδα 15
DE / AT / CH Bedienungsanleitung Seite 29
A
B
Contents
Introduction ...................................................2
Copyright ............................................................... 2
Intended use ..................................................2
Safety information .............................................3
Package contents ..............................................5
Disposal of the packaging .................................................. 5
Technical data .................................................6
Appliance description ...........................................6
Why use steam for straightening? ................................6
Before straightening ............................................6
Automatic switch-off ............................................7
Use ..........................................................7
Filling the water tank ...................................................... 7
Switching on/off ......................................................... 8
Straightening hair ........................................................ 9
Cleaning .....................................................10
Storage .....................................................10
Troubleshooting ..............................................11
Disposal of the appliance .......................................11
Kompernass Handels GmbH warranty ............................12
Service ................................................................ 13
Importer ............................................................... 13
SHGD 52 A1
GB│CY │ 1 ■
Introduction
Congratulations on the purchase of your new appliance.
You have selected a high-quality product. The operating instructions are part of
this product. They contain important information about safety, use and disposal.
Before using the product, please familiarise yourself with all operating and safety
instructions. Use the product only as described and for the range of applications
specified. Please also pass these operating instructions on to any future owner.
Copyright
This documentation is protected by copyright.
Any copying or reproduction, including in the form of extracts, or any reproduction
of images (even in a modified state), is permitted only with the written authorisation of
the legal owner.
Intended use
This hair straightener is intended for straightening human hair only. Under no
circumstances is it to be used for wigs or hairpieces made of synthetic material.
This appliance is intended exclusively for private use. Pay heed to all of the information in this operating manual, especially the safety instructions. This appliance
is not intended for commercial applications.
The appliance is not intended for any other purpose, nor for use beyond the
scope described. No claims of any kind will be accepted for damage arising
as a result of incorrect use. The risk shall be borne solely by the user.
■ 2 │ GB
│
CY
SHGD 52 A1
Safety information
RISK OF ELECTRIC SHOCK
► Connect the appliance only to mains power sockets supplying
a mains power voltage of 220–240 V ~, 50/60 Hz.
► Remove the plug from the mains power socket in case of
operating malfunctions and before you clean the appliance.
► Always pull on the plug to disconnect the appliance from the
mains; never pull on the power cable itself.
► Ensure that the power cable does not become wet or damp
during use. Route the cable in such a way that it cannot be
crushed or damaged.
► If the appliance, the power cable or the plug are damaged,
arrange for them to be repaired by Customer Services to
avoid hazardous situations.
► Do not use the appliance outdoors.
► Do not use extension cables – they will make it difficult to
disconnect the appliance quickly in an emergency.
► Never touch the appliance, the power cable or the power
plug with wet hands.
► Do not kink or crush the power cable, and route the cable
so that it cannot be stepped on or tripped over.
► Do not wrap the power cable around the appliance, and
protect it from being damaged. Under no circumstances
should the appliance be submersed in liquids or liquids be
allowed to penetrate the housing. Do not expose the appliance to humidity and do not use it outdoors. If any liquid
gets into the housing, disconnect the appliance from the
mains power socket immediately and have it repaired by a
qualified technician.
SHGD 52 A1
GB│CY │ 3 ■
RISK OF ELECTRIC SHOCK
► Unplug the appliance immediately after use. The appliance
is completely free of electrical power only when unplugged.
Never use the appliance near water, and keep it away
from sinks, baths and other similar containers.
The proximity of water is hazardous, even if the appliance
is switched off. Always disconnect the plug from the
mains power socket after use. For additional protection,
we recommend that you install a residual current circuit
breaker with an activation power rating of no more than
30 mA for the power circuit in the bathroom. Ask your
electrician for advice.
WARNING! RISK OF INJURY!
► Never leave a switched-on appliance unsupervised.
► Never place the appliance close to sources of heat, and
always protect the power cable from damage.
► Do not operate the appliance if it has been dropped or is
damaged in any way. Have the appliance checked and/or
repaired by qualified technicians if necessary.
► This appliance may be used by children of the age of 8 years
or more and by persons with reduced physical, sensory or
mental capabilities or lack of experience and/or knowledge
if they are being supervised or have been instructed with regard to the safe use of the appliance and have understood
the potential risks.
► Do not allow children to play with the appliance.
► Cleaning and user maintenance should not be carried out
by children, unless they are under supervision.
■ 4 │ GB
│
CY
SHGD 52 A1
WARNING! RISK OF INJURY!
► Do not open the housing or attempt to repair the appliance
yourself. This can lead to hazards and also invalidates the
warranty. Defective appliances should be repaired by
authorized specialists only.
► The appliance heats up during use.
Always hold the appliance by its handle when it is hot.
Package contents
The appliance is supplied with the following components as standard:
▯ Hair Straighteners
▯ Fill bottle
▯ Operating instructions
1) Remove all parts of the appliance and the operating instructions from the
carton.
2) Remove all packaging material.
3) Clean all parts of the appliance as described in the section entitled “Cleaning”.
NOTE
► Check the package for completeness and signs of visible damage.
► If any items are missing or damaged as a result of defective packaging
or transportation, contact the service hotline (see section "Service").
Disposal of the packaging
The packaging protects the appliance from damage during transport.
The packaging materials have been selected for their environmental friendliness
and ease of disposal, and are therefore recyclable.
Returning the packaging to the material cycle conserves raw materials and
reduces the amount of waste that is generated. Dispose of packaging materials
that are no longer needed in accordance with applicable local regulations.
NOTE
► If possible, keep the original packaging during the warranty period so
that the appliance can be properly packed for returning in the event of
a warranty claim.
SHGD 52 A1
GB│CY │ 5 ■
Technical data
Mains voltage 220–240 V ~, 50/60 Hz
Rated power 52 W
max. temperature 230°C (+/− 10°C)
Protection class
II
Appliance description
Rubber closure
Steam activation
Water tank
Hanger
Catch
Temperature control
ON/OFF switch
Indicator lamp
Lower hotplate
Upper hotplate (with integrated steam nozzles)
- Fill bottle
Why use steam for straightening?
The added steam ensures that the hair is straightened gently. Depending on the
hair structure, the hair looks silkier and shinier because of the gentle straightening.
Before straightening
■ The hair should be clean, dry and free of styling products. The only exceptions
to this are special products that promote the straightening of the hair.
■ Comb the hair thoroughly before straightening so that there are no knots in it.
■ 6 │ GB
│
CY
SHGD 52 A1
Automatic switch-off
This appliance is fitted with an automatic switch-off system. After 60 minutes
(+/− 6 minutes), the appliance will switch itself off automatically. If you want to
continue using the appliance, switch it off for a moment and then back on again.
NOTE
► The automatic switch-off is a safety function only and is not intended as a
replacement for switching the appliance off properly using the ON/OFF
switch !
Use
Filling the water tank
NOTE
► Fill the water tank only when you want to generate steam for straightening.
1) Unscrew the top of the fill bottle - and fill it with water. Screw the top back
on the fill bottle -.
2) Pull the water tank backwards and out of the appliance.
3) Open the black rubber closure on the water tank . When doing so, be
careful that you do not tear the rubber tab to which the rubber closure is
attached completely off the water tank . Pull out the rubber tab only far
enough out of the water tank so that the rubber closure opens and the
filling hole is free.
4) Twist the top off the fill bottle - and guide the tip into the large filler opening
on the water tank . Hold the water tank at a slight tilt when filling it, so
that the water runs downwards.
5) Squeeze the fill bottle - a little so that the water runs into the water tank .
6) When the water tank is filled up to the small opening next to the filler
opening, hold the water tank straight again and remove the fill bottle from the filler opening.
7) Close the rubber closure .
8) Push the water tank back onto the appliance so that it clicks audibly back
into place.
SHGD 52 A1
GB│CY │ 7 ■
Switching on/off
NOTE
► The hotplates must be free of dirt. Clean them before use if required
(see section "Cleaning")
The appliance is secur
Press the hotplates together and pull the catch out.
Now you can open the hair straightener all the way.
1) Insert the plug into a mains socket.
2) Push the ON/OFF switch forwards into the “I” (ON) position.
The indicator light starts to flash red and the appliance heats up.
NOTE
► Steam generation requires a temperature of at least 170°C. At lower tempe-
ratures it is possible that hot water will come out of the upper hotplate .
3) Select the temperature suitable for your hair by turning the temperature
control :
– 150–170°C, low heat level, for fine hair,
not suitable for steam generation.
– 170–190°C, medium heat level, for normal hair,
suitable for steam generation.
– 190–210°C, high heat level, for thick hair,
suitable for steam generation.
– 210–230°C, highest heat level, for thick hair that is hard to style,
suitable for steam generation.
NOTE
► Select a high temperature for thick and strong hair.
► Select a lower temperature for fine and thin hair.
► If you are unsure, start with a lower temperature and increase the temperature
until you find the ideal temperature for you.
.
ed with the catch .
■ 8 │ GB
4) As soon as the hair straightener has reached the set temperature, the indicator
lamp will light up permanently red.
5) When you have finished styling your hair, push the ON/OFF switch backwards into the “0” (OFF) position. The indicator light goes out.
Pull out the plug and allow the appliance to cool down completely.
│
CY
SHGD 52 A1
Straightening hair
1) Prepare the hair as described in “Before straightening”.
NOTE
►
After the hotplates have been pushed together about 5 times, steam
will be generated automatically because the steam activation is engaged
by each press
want to work with steam from the start, then press the hotplates
together as often as required until steam is dispensed
2) S
tart with the lower sections of hair at the back of your head. Work around
the sides to the front:
Take a strand with a width of approximately 2cm and hold its end tightly
between your index and middle finger of the hand that is not holding the
hair straightener.
WARNING! RISK OF INJURY!
► Ensure that the hotplates do not touch your scalp. Risk of burns!
Never touch the hotplates or the upper part of the hair straightener
during operation! Risk of burns!
► You need to press the hotplates together approx. 5 times only before
the first time steam is dispensed. After this, steam is then dispensed every
time you press the hotplates together. If you press the hotplates
together too often without straightening your hair, drops of very hot water
will form. Risk of scalding!
3) Clamp the strand near the root between the hotplates and press them
together.
4) Pull the entire strand through the hotplates by pulling the hair straight-
ener quickly downwards from the root to the tips.
5) Proceed in the same way for every strand.
6) Once you have straightened all the strands, switch the appliance off and pull
the power plug from the mains power socket.
7) Allow the appliance to cool down completely.
. Steam is now dispensed from the upper hotplate . If you
.
SHGD 52 A1
Press the hotplates together and push the catch back in.
GB│CY │ 9 ■
Cleaning
WARNING – RISK OF INJURY!
CAUTION – PROPERTY DAMAGE!
1) Empty the water tank after each use and wipe it off with a damp cloth.
2) Wipe the housing and the hotplates with a damp cloth.
3) For stubborn soiling, add a mild detergent to the cloth. Wipe off any detergent
4) Allow the appliance to dry fully before using it again.
Storage
RISK OF ELECTRIC SHOCK
► Always remove the plug from the mains power socket before cleaning the
appliance.
► Never immerse the appliance in water or other liquids during cleaning!
► Allow the appliance to cool sufficiently before cleaning it.
► Do not use any aggressive cleaning liquids or solvents. They could damage
the surface.
residue using a cloth moistened with clean water only.
■ Place the appliance on a heat-resistant surface to cool down.
■ You can hang the appliance up by the hanger .
■ 10 │ GB
If you do not intend using the appliance for an extended period:
■ clean the appliance as described in the section “Cleaning”.
■ Store the appliance in a clean and dry location.
│
CY
SHGD 52 A1
Troubleshooting
Problem Cause Solution
The plug is not in-
serted into a mains
power socket.
Plug in the appliance.
The appliance is not working.
The hair does not straighten.
The hair is singed.
Disposal of the appliance
Never dispose of the appliance in your normal domestic waste.
This product is subject to the provisions of European Directive
2012/19/EU.
Dispose of the appliance through an approved disposal facility or your municipal
waste facility. Please comply with all applicable regulations. Please contact your
waste disposal centre if you are in any doubt.
The mains power
socket is defective.
The appliance is
defective.
The appliance is
not yet heated up.
The set heat level is
too low.
The hair was
between the
hotplates for
too long.
The set heat level is
too high.
Try a different wall
socket.
Contact the Customer
Service department.
Wait until the appliance
has heated up.
Select a higher heat level.
Always pull the hair
straightener through
the hair.
Never stay in one
place on the hair for
any length of time.
Select a lower heat
level.
SHGD 52 A1
GB│CY │ 11 ■
Loading...
