ELECTRIC OVEN & GRILL SGBR 1500 A2
ELECTRIC OVEN & GRILL
Operating instructionss
GRILL- UND BACKAUTOMAT
Bedienungsanleitung
IAN 113370
GRILL- EN BAKAUTOMAAT
Gebruiksaanwijzing
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Vouw vóór het lezen de pagina met de afbeeldingen open en maak u vertrouwd met alle functies van het
apparaat.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.
GB / IE Operating instructions Page 1
NL / BE Gebruiksaanwijzing Pagina 21
DE / AT / CH Bedienungsanleitung Seite 41
A
9
1
2
B
8
7
6
3
4
5
0
q
w
z
e
tr
Contents
Introduction ............................................................2
Proper use .............................................................2
Package contents .......................................................2
GB
IE
Appliance descr
Technical data ..........................................................2
Safety instructions ......................................................3
Se
tting up .............................................................
Using t
he appliance .....................................................
Glass door
Inserting the crumb tray
Using the rotisserie ...................................................................7
Using the baking tray/rack ............................................................8
Before first use .........................................................8
Operating the appliance .................................................9
Function switch ......................................................................9
Temperature control ..................................................................9
Timer
Grilling and baking .....................................................9
Gr
Cleaning and care ......................................................12
Storage ..............................................................12
.........................................................................6
.............................................................................9
illing with the rotisserie ...............................................
iption ....................................................
...............................................................6
10
2
6
6
Troubleshooting .......................................................13
W
arranty and service ..................................................
Disposal ..............................................................14
Importer .............................................................14
R
ecipes ...............................................................
SGBR 1500 A2
14
15
1
Introduction
GB
Congratulations on the purchase of your new
IE
appliance.
You have selected a high-quality product.
The operating instructions are part of this product.
They contain important information on safety, usage
and disposal. Before using the product, familiarise
yourself with all handling and safety guidelines.
Use the product only as described and for the
range of applications specified. Please also pass
these operating instructions on to any future
owner(s).
Proper use
The automatic oven and grill is intended for the
heating, cooking and grilling of food.
This appliance is intended solely for use in private
homes. Do not use it for commercial applications.
All other uses are deemed to be improper and may
result in property damage or even in personal injury.
Package contents
♦ Electric Oven & Grill
♦ 1 baking tray
♦ 1 rack
♦ 2 tongs
♦ Rotisserie with 2 clamps
♦ 1 crumb tray
♦ Operating instructions
Appliance description
Figure A:
Drive
Temperature control
Function switch
Timer
Control lamp
Glass door
Crumb tray
Lower heating element
Spit fitting
Figure B:
Tongs (baking tray or rack)
- Baking tray
3 Tongs (for spit)
! rack
. Restrainer
0 Skewer clamps
6 Rotisserie
Technical data
Rated voltage: 220 - 240 V ~,
50/60 Hz
Max. power consumption: 1500 W
NOTE
Check contents for completeness and damage
immediately after unpacking. Contact Customer
Services if necessary.
2
SGBR 1500 A2
Safety instructions
DANGER – RISK OF ELECTRIC SHOCK!
► Do not open the housing of the appliance or attempt to repair it.
Doing so can lead to risks and also invalidates the warranty.
Defective appliances should be repaired by the retailer or
authorized personnel only.
► Arrange for defective power plugs and/or cables to be replaced
as soon as possible by a qualified technician or by our Customer
Service Department to avoid the risk of injury.
► Do not allow any liquids to penetrate the housing. Do not expose
the appliance to moisture and do not use it outdoors. Additionally,
do not place fluid-filled receptacles such as flower vases on the
appliance. This increases the risk of fire and of receiving an electric
shock! If liquids permeate into the housing, unplug the appliance
immediately and arrange for it to be repaired by a qualified
technician.
► Never touch the appliance, power cable or power plug with wet
hands. There is a risk of electric shock!
GB
IE
NEVER immerse the appliance in water or other liquids!
Risk of electrocution if residual liquids come into contact with
live components during operation.
SGBR 1500 A2
3
GB
IE
WARNING – RISK OF INJURY!
► This appliance may be used by children of the age of 8 years or
more and by persons with reduced physical, sensory or mental
capabilities or lack of experience and/or knowledge if they are
being supervised or have been instructed with regard to the safe
use of the appliance and have understood the potential risks.
► Children must not use the appliance as a plaything.
► Cleaning and user maintenance must not be performed by children
unless they are older than 8 years of age and are supervised.
► Children younger than 8 years of age must be kept away from
the appliance and the power cable.
► Route the power cable in such a way that no one can tread on it
or trip over it.
► Never touch the glass door or the housing during use, these can
get very hot. Use oven gloves or something similar to open the
glass door to avoid being burnt!
► Never touch the heating elements or the viewing window when
the appliance is in use, or before it has cooled down completely.
Do not reach into the cooking chamber when the appliance is in
use. Wait until the appliance has cooled down. Otherwise, you
could be burnt.
► Allow the appliance to cool down after use before transporting it.
► Always use oven gloves or a pot holder if you need to take hold
of the appliance.
Caution! Hot surface!
4
SGBR 1500 A2
CAUTION – PROPERTY DAMAGE!
► Do not use an external timer switch or a separate remote control
system to operate the appliance.
► Never leave the appliance unattended during operation.
► Ensure that the appliance, the power cable and the plug do not
come into contact with heat sources such as hotplates or naked
flames.
► Only operate the appliance with the original accessories supplied.
► Do not kink or crush the mains cable.
► To disconnect, always remove the plug itself from the mains
power socket, do not pull on the power cable.
► When the appliance is in use, ensure that there are no easily
inflammable materials in the immediate vicinity (e.g. dishcloths,
oven cloths, etc.).
► Never dry textiles or other objects on or above the appliance.
This increases the risk of fire!
GB
IE
SGBR 1500 A2
5
GB
IE
Setting up
WARNING! RISK OF FIRE!
► Never place the appliance beneath wall cup-
boards or next to curtains, cupboard walls or
other flammable objects.
► Always ensure a minimum distance between
the appliance and hanging cupboards, ceilings,
walls or similar of at least 10 cm above the
appliance and 5 cm at the sides. For this
reason the appliance may not be used, for
example, in cupboards or similar. Otherwise
there is likely to be insufficient ventilation for
the appliance, which could cause a fire or
damage.
► Always place the appliance on a heat-resistant
surface. Failure to do so increases the risk of
fire or of it being damaged. The area under
the bottom can discolour and be damaged.
Additionally, if placed on a soft upper surface,
the appliance could cause permanent damage
to it due to pressure indentations.
DANGER – ELECTRIC SHOCK!
► Do not place the appliance immediately ad-
jacent to sources of water, e.g. sinks or basins,
or in damp cellar areas. Otherwise, there is
a risk of receiving an electric shock.
■ Place the appliance on a solid, level and heat-
resistant surface (e.g. stainless steel worktops
or natural stone worktops such as granite).
Ensure there is sufficient ventilation around the
appliance.
■ Clean all components as described in the
section “Cleaning and care”.
Using the appliance
Glass door
ATTENTION! DAMAGE TO PROPERTY!
►
Do not lean on the glass door . Do not
place any objects on the glass door .
This can cause damage to the hinges.
■ If you are cooking especially fatty foodstuffs, this
can result in increased smoke production. In this
case, do not close the glass door completely;
instead, leave it slightly open:
The glass door has a latching position so that
it remains open a little: if you carefully push the
glass door closed, it clicks into this position
shortly before closing completely.
■ When drying fruit (to make dried fruit), the glass
door should remain in the latching position
to ensure that moisture can escape and that the
fruit dries better.
Inserting the crumb tray
■ Push the crumb tray under the lower heating
element so that it rests flat on the bottom of
the appliance.
6
SGBR 1500 A2
Using the rotisserie
WARNING! RISK OF INJURY!
► Always use the tongs 3to insert the hot rotis-
serie 6 into the appliance or to remove it.
■ You can use the two skewer clamps 0 to fix the
food onto the rotisserie 6. Loosen the restrainer
. on the skewer clamps 0, push them so that
the food is fixed firmly in between the clamps
and then screw the restrainer . tight again.
■ First push the end of the rotisserie 6 without the
notch into the drive (Figure 1):
NOTE
► Always slide the baking tray - into the lower
rail when you use the rotisserie 6.
This will collect any drips.
■ To remove the hot rotisserie 6, grip with
the hooks at the end of the tongs 3 into the
recesses on the rotisserie 6 (Figure 3):
GB
IE
Fig. 1: Push the rotisserie 6 into the drive .
■ Then insert the other end of the rotisserie 6 with
the deep groove in the spit fitting (Figure 2):
Fig. 2: Insert the rotisserie 6 in the spit fitting .
SGBR 1500 A2
Fig. 3: Hooking the tongs 3 onto the rotisserie 6
■ First lift the left-hand side of the rotisserie 6 out
of the spit fitting and then pull the rotisserie 6
from the drive .
7
Using the baking tray/rack
GB
IE
WARNING! RISK OF INJURY!
► Always use the tongs to insert the hot
baking tray -/the hot rack ! into the appliance or to remove it.
■ Push the baking tray -/the rack ! into one of
the 3 rails in the cooking chamber of the appliance.
ATTENTION! DAMAGE TO PROPERTY!
► Never place the baking tray -/the rack !
directly onto the heating elements .
■ To remove the hot baking tray - or the rack !,
hook the tongs onto them as follows:
Fig. 4: Hooking the tongs onto the rack !
Before first use
1) Insert the plug into a mains power socket.
2) Turn the temperature control clockwise to
the maximum temperature (to the stop).
3) Turn the function switch to “upper and
lower heat”
4) Open the glass door leave this open for this
operation.
5) Remove any installed accessories from the
cooking chamber.
6) Turn the timer to 20 minutes.
NOTE
► The first time the appliance heats up, a
small amount of smoke and odour may be
generated due to production-related residue.
This is normal and is completely harmless.
Provide sufficient ventilation by opening a
window, for example.
The appliance switches off automatically
after 20 minutes.
If you want to interrupt the heating process
prematurely, turn the temperature control
counter-clockwise to the stop and set the
timer to “OFF - 0”.
7) Allow the appliance to cool down, then clean
the appliance as described in the chapter
“Cleaning and care”.
The appliance is now ready for use.
.
Fig. 5: Hooking the tongs onto the baking
tray -
8
SGBR 1500 A2
Operating the appliance
Function switch
You can switch on the appliance with the function
switch , and also set 5 different functions:
Symbol Meaning
"Upper heat"
e.g. to gratinate
"Lower heat"
e.g. for baking
"Upper & lower heat"
e.g. for baking a pizza
"Upper heat/hot air/
rotisserie"
e.g. to roast poultry
"Upper & lower heat/hot air"
e.g. to reheat rolls
OFF
Temperature control
Use the temperature control to set the desired
temperature.
■ If you set the temperature for the functions
“Upper heat”
lower heat”
■ If you set the temperature for the functions
“Upper heat/hot air/rotisserie”
“Upper & lower heat/hot air”
marked with “ ”.
"OFF" the appliance is
switched off.
, “Lower heat” or “Upper &
use the scale marked with “ ”.
or
use the scale
Timer
User the timer to set the cooking time.
■
Set the timer to the desired cooking time.
After expiry of the set time a signal tone sounds
and the appliance stops heating.
If the function “Upper heat/hot air/rotisserie”
is selected, the rotisserie 6 will also stop
turning.
Grilling and baking
1) Put the crumb tray into the appliance.
2) Remove the rack ! and baking tray - from
the appliance. If required, cover these with
baking paper or lightly grease the baking tray with suitable baking fat.
NOTE
► Depending on the meal, the oven must be
preheated. Refer to the guidelines in the
respective recipe. Preheating is useful for:
– very short baking times,
– crisp crusts,
– sensitive meals that require a constant
temperature, such as soufflés.
► If no preheating is required, skip step 3).
3) Allow the appliance to heat up for approx.
10 minutes (depending on the temperature
setting) to the required temperature:
– Select the required temperature using the
temperature control . Ensure that you use
the correct scale (see chapter “Temperature
control”).
– Select the required function with the function
switch .
GB
IE
SGBR 1500 A2
9
NOTE
GB
IE
► As a general rule, if you are baking or grilling
with hot air you can dispense with a preheating
of the grilling/cooking space.
– Use the timer to set the preheat time
(approx. 10 minutes).
– Close the glass door .
4) Once the warm-up period is finished, place
the foodstuffs on the rack ! or the baking
tray - and slide it in on one of the rails.
Ensure that there is sufficient space between
the foodstuffs and the inner walls/heating
elements of the appliance.
NOTE
► If you wish to prepare food on the rack !
that drips excessively, then slide the baking
tray - onto the bottom rail. By doing this,
dripping fat for example will be caught and
the appliance is then easier to clean.
5) Close the glass door before starting the
grilling or baking process.
6) Use the timer to set the required grilling or
baking time. The maximum grilling or baking
time is 120 minutes.
NOTE
► If the cooking time for the food is less than
20 minutes, first set the timer to 40 minutes
and then turn it back to the required grilling
or baking time.
The appliance switches off automatically after the
set period, there is a beep and the control lamp
switches off.
NOTE
If you want to interrupt the heating process
prematurely, turn the temperature control
counter-clockwise to the stop and set the timer
to "OFF - 0".
7) After cooking, remove the rack ! or the baking
tray - using the tongs .
8) Set the function switch to “OFF”.
Grilling with the rotisserie
1) Put the crumb tray into the appliance.
2) If inserted, remove the rotisserie 6 from the
appliance.
3) Push the baking tray - onto the lower rail.
4) Fix the food to be grilled with the skewer
clamps 0. Ensure that the food in the cooking
chamber can turn freely without touching the
sides. The rotisserie 6may change its direction
of rotation if the food strikes against a resistance.
The two depressions on the rotisserie 6 must remain freely accessible, otherwise you will not be
able to grasp the rotisserie 6 with the tongs 3.
5) Fit the rotisserie 6 in the cooking chamber
(see chapter “Using the rotisserie”)
6) Close the glass door .
The control lamp indicates that the appliance is
now switched on. The switch of the timer now
rotates itself anti-clockwise to “OFF - 0”.
10
SGBR 1500 A2
NOTE
If you want to interrupt the heating process prematurely, turn the temperature control counterclockwise to the stop and set the timer to
"OFF - 0".
7) Adjust the temperature control to the desired
temperature.
8) Set the function switch to “Upper heat/hot
air/rotisserie”
desired grill time.
The appliance starts the grilling process and
the rotisserie 6 starts turning.
The control lamp indicates that the appliance is
now switched on. The switch of the timer now
rotates itself anti-clockwise to “OFF - 0”.
The appliance switches off automatically after the
set period, there is a beep and the control lamp
switches off.
NOTE
If you want to interrupt the heating process
prematurely, turn the temperature control
counter-clockwise to the stop and set the timer
to "OFF - 0".
9) After the grilling process is completed remove
the rotisserie 6 with the help of the tongs 3.
10) Set the function switch to “OFF”.
. Set the timer to the
EXAMPLE: GRILLED CHICKEN
Ingredients
♦ Grilling chicken (approx. 1.3 kg,
guts removed)
♦ Spices (salt, paprika)
♦ Cooking oil
1) Season the chicken on the inside and outside
with salt and paprika powder. Brush it from
the outside with heat resistant cooking oil.
2) Push the chicken onto the spit and fix it in
place with the skewer clamps 0. Ensure that
the notches on the rotisserie 6 remain free
so that you can remove the rotisserie 6with
the help of the tongs 3. Depending on the
shape of the chicken, it may be necessary
to fasten the wings and legs with a fireproof
string to stop them impacting the sides when
turning.
3) Push the baking tray - onto the lower rail.
4) Preheat the appliance for about 10 minutes
using the function "Upper & lower heat/hot
air"
to 210°C.
5) Put the chicken on the rotisserie into the
appliance using the tongs 3.
6) Set the function switch to “Upper heat/hot
air/rotisserie”
7) Set the timer approx. 80 minutes. The
cooking time can vary depending on the
size and nature of the chicken.
8) Brush the chicken every now and again with
some cooking oil. This will make it crispy.
9) Once the set time is up, carefully remove the
rotisserie with the chicken using the tongs 3.
Loosen the skewer clamps 0 and pull the
chicken off the rotisserie 6.
and close the door.
GB
IE
SGBR 1500 A2
11
Cleaning and care
GB
IE
DANGER – ELECTRIC SHOCK!
►
Before cleaning the appliance, disconnect the
plug from the mains power socket!
Risk of electric shock!
NEVER immerse the appliance in water or
any other liquid!
WARNING! RISK OF INJURY!
► Always allow the appliance to cool down
before cleaning it. Otherwise there is a risk
of burns!
■ It is best to clean the appliance and accessories
as soon as they have cooled down. This makes
food residues easier to remove.
ATTENTION! DAMAGE TO PROPERTY!
► Do not use abrasive or aggressive cleaning
materials. These could damage the surface of
the appliance!
► Do not clean the components of the appliance
in a dishwasher!
► Do not clean the cooking chamber with an
oven spray as this may make residues on the
heating elements impossible to remove.
■ Wipe the appliance with a damp cloth. If neces-
sary, put a little mild detergent on the cloth and
wipe this off afterwards with a cloth dampened
with clean water. Dry everything properly.
■ Clean the cooking chamber and the glass door
with a moist cloth
detergent on the cloth and wipe this off afterwards with a cloth dampened with clean water.
Dry everything properly.
■ Clean the tongs /3, the rotisserie 6, the
skewer clamps 0, the restrainer ., the baking
tray -, the rack ! and the crumb tray in
warm soapy water. Dry all parts properly after
cleaning.
. If necessary, put a little mild
Storage
■ Store the cleaned appliance and its accessories
in a clean, dust-free and dry location.
12
SGBR 1500 A2
Troubleshooting
Fault Cause Solution
GB
IE
The mains plug is not connected to the
mains power.
The appliance is not
working.
The control lamp
comes on and but the
appliance does not
heat up.
The cooking time of
the food seems very
long
Smoke and smells
develop during use.
If the malfunction cannot be corrected with the above suggestions, or if you have found some other
kind of malfunction, please contact our Customer Service.
The mains power socket is defective.
The appliance is defective. Contact Customer Services.
The function switch is set to OFF.
The glass door has been opened often
to check the cooking progress.
The wrong temperature level has been set. Check the temperature settings.
There is detergent or food residue on the
heating elements.
Insert the plug into a mains power
socket.
Use a different mains power
socket.
Turn the function switch to the
desired function.
Do not open the glass door
any more often than is absolutely
necessary.
Remove the food from the appliance and continue cooking
process with the glass door
open until the smoke stops.
SGBR 1500 A2
13
Warranty and service
GB
The warranty provided for this appliance is
IE
3 years from the date of purchase. This appliance
has been manufactured with care and inspected
meticulously prior to delivery. Please retain your
receipt as proof of purchase. In the event of a
warranty claim, please contact your Customer
Service unit by telephone. This is the only way to
guarantee free return of your goods.
The warranty only covers claims for material and
manufacturing defects, not for transport damage,
wearing parts or for damage to fragile components
such as switches or batteries. This appliance is
intended solely for private use and not for commercial purposes.
The warranty shall be deemed void in the case
of misuse or improper handling, use of force and
interventions which have not been carried out by
one of our authorised Service centres.
Your statutory rights are not restricted by this warranty.
The warranty period is not prolonged by repairs
effected under the warranty. This also applies to
replaced and repaired components. Any damage
and defects present at the time of purchase must
be reported immediately after unpacking, but no
later than two days after the date of purchase.
Repairs made after expiry of the warranty period
are chargeable.
Service Great Britain
Tel.: 0871 5000 720 (£ 0.10/Min.)
E-Mail: kompernass@lidl.co.uk
IAN 113370
Service Ireland
Tel.: 1890 930 034
(0,08 EUR/Min., (peak))
(0,06 EUR/Min., (off peak))
E-Mail: kompernass@lidl.ie
IAN 113370
Hotline availability:
Monday to Friday 08:00 - 20:00 (CET)
Disposal
Under no circumstance should
the appliance be disposed of
as standard domestic waste.
This product is subject to the
provisions of European Directive 2012/19/EU.
Dispose of the appliance via an approved waste
disposal company or your municipal waste disposal facility. Please observe applicable regulations.
Please contact your waste disposal facility
if you are in any doubt.
The packaging is made of environmen-
tally friendly materials which you can
dispose of at your local recycling centre.
Importer
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com
14
SGBR 1500 A2
Recipes
In this section, we provide you with various sample
recipes for preparing dishes. These examples are
recommendations. Cooking times may vary.
ecipes are provided without guarantee.
These r
All information on ingredients and preparation is
indicative only. Modify the suggested recipes to
taste. We hope you enjoy the recipes and wish
you “bon appetit”!
NOTE
Take note of the preparation guidelines provided
on the food packaging.
Muffins
Ingredients for four people:
♦ 1 cup of flour
♦ 1 teaspoon of baking powder
♦ 1 egg
♦ 1 tablespoon of melted butter
♦ 1 cup of milk
♦ 3 tablespoons of sugar
♦ 1 pinch salt
♦ f
or variations: also nuts, chopped bananas or
chocolate flakes
Preparation:
1) Gradually mix the flour, baking powder, egg,
milk, salt and sugar together in a bowl, one
by one.
2) Melt the butter in a saucepan and mix it into
the dough.
3) Subject to taste, blend in the nuts, chocolate
flakes or mashed bananas.
4) Place the prepared dough into standard muffin
moulds and place them on the baking tray -.
5) Bake the muffins at 220°C on the bottom rail
using top & bottom heat for about 15 minutes.
Hawaiian toast
Ingredients for 4 pieces of toast:
♦ 4 slices of toasting bread
♦ 1–2 tablespoons of remoulade
♦ 120 g cooked ham
♦ 1/2 tin of pineapples
♦ 4 slices of cheese for gratinating
♦ Curry
Preparation:
♦ Toast the bread slices.
♦ Spread the remoulade thinly over the pieces of
toast and lay the slices of cooked ham on top.
♦ Lay one slice of pineapple on each piece of
toast. Season with curry.
♦ Then place a slice of cheese over each of the
pineapple slices.
♦ Lay the Hawaiian toasts on the rack ! and
bake at 200°C for about 8 minutes on the
upper rail using top heat
Baking deep-frozen pizza
Preparation:
♦ Place the rack ! on the upper rail in the cooking
chamber.
♦ Place the deep-frozen pizza (without packaging)
onto the rack !.
♦ Bake the pizza, using upper and lower heat, for
about 20 minutes.
♦ Please follow the instructions on the packaging
regarding temperature.
.
GB
IE
SGBR 1500 A2
15
Spritzgebäck cookies
GB
Ingredients:
IE
♦ 125 g butter
♦ 125 g sugar
♦ 1 packet of vanilla sugar
♦ 1 pinch salt
♦ 1 egg
♦ 1 egg white
♦ 250 g flour (type 405)
♦ 1 teaspoon of baking powder
♦ Zest of half a lemon
Preparation:
1) Beat the butter until foamy.
2) Add the sugar, vanilla sugar, lemon zest and
eggs.
3) Mix the flour, baking powder and salt and stir
into the mixture using a mixing spoon.
4) Allow the dough to stand for about 10 minutes.
5) Shape the dough as desired, e.g. with the assistance of a mincer, cookie cutters or a piping
bag.
6) Line the baking tray - with baking paper and
place the cookies on this.
7) Bake the cookies on the top rail of a preheated
oven at 180°C, using top and bottom heat,
for about 10–15 minutes, until they are golden
brown.
Bread rolls
Ingredients:
♦ 300 g flour (or wholemeal flour)
♦ 2 heaped teaspoons of baking powder
♦ 200 g linseeds
♦ 1 egg
♦ 500 g quark or curd cheese
♦ 1 teaspoon of salt
♦ Subject to taste: caraway seeds, onions,
bacon ...
Preparation:
1) Knead all ingredients together well and then
shape into small rolls.
2) Line the baking tray - with baking paper and
place the rolls on this.
3) Bake on the top rail at about 200°C for
around 30 minutes.
NOTE
This quantity of dough is sufficient for several
baking trays -.
NOTE
This quantity of dough is sufficient for several
baking trays -.
16
SGBR 1500 A2
Loading...
