Table of Contents
Introduction
Proper use ............................................................................................................................................ Page 6
Description of parts ............................................................................................................................. Page 7
Included items .....................................................................................................................................Page 7
Technical Data ....................................................................................................................................Page 7
Important safety instructions ......................................................................................... Page 7
Safety system .............................................................................................................................. Page 9
Preparing the product for use
Switching on / off / Selecting the temperature...................................................................................Page 9
Temperature levels .............................................................................................................................. Page 9
Automatic switch-off ............................................................................................................................ Page 10
Cleaning and Care ................................................................................................................... Page 10
Storage .............................................................................................................................................Page 10
Disposal ............................................................................................................................................ Page 10
Warranty / Service centre .................................................................................................Page 11
Declaration of conformity ................................................................................................. Page 11
5 GB/IE
Introduction
The following pictograms are used in these operating instructions /
on the equipment:
Read the instructions!
Do not use the foot warmer when
folded or bunched up!
V∼
Hz
W
Volt (AC) Do not stick needles into it!
Hertz (mains frequency)
Watts (effective power) Do not wash.
Safety class II Do not use bleach.
Observe caution and safety notes! Do not dry in a tumbler dryer.
Keep children away from the foot
warmer!
Risk of loss of life by electric shock from
damaged mains power cable or mains
plug!
The textiles used in this foot warmer
meet the strict human ecological requirements of Öko-Tex Standard 100,
as verified by the German Hohenstein
Research Institute.
Caution – electric shock!
Danger to life!
Do not iron.
Do not dry clean.
Dispose of the packaging and the
foot warmer in an environmentally
friendly manner!
Foot Warmer
Introduction
We congratulate you on the purchase of
your new device. You have chosen a
high quality product. Please make yourself familiar with the foot warmer before preparing
it for use or using it for the first time. Please read
the following operating instructions and the important safety instructions carefully. Always use the
foot warmer only as described and for the stated
areas of use. Keep these instructions in a safe
place. If you pass the foot warmer on to anyone
6 GB/IE
else, please ensure that you also pass on all the
documentation.
Proper use
This foot warmer is intended for applying heat to
the human body. Do not use the foot warmer wearing shoes, as this would reduce your sensitivity to
heat and also soil the foot warmer. This foot
warmer is not intended for use in hospitals or for
commercial use. In particular it must not be used
for babies or infants, persons who are insensitive to
heat, helpless persons, or animals. Any use other
than that described here or modification to the foot
Introduction / Important safety instructions
warmer is not permitted and could lead to injury
and/or damage to the product. The manufacturer
accepts no liability for any damage caused by
improper use.
Description of parts
1
Teddy lining, removable
2
Control unit
3
Function indicator
Included items
Immediately after unpacking, check that all the
items are present and that the product is in perfect
condition.
1 Foot warmer with removable teddy lining and
control unit
1 Set of operating instructions
Technical Data
Model: SFW 100 A2
Type: FW 10
Power supply:
Power input : 100 W
Dimensions: approx. 26 x 26 x
Protection class: II /
Protection class
(water protection): Foot warmer: IPX 1,
Control unit: IPX0, no
Electric field strength: max. 5000 V / m
Magnetic field strength: max. 80 A / m
Magnetic flux density: Max. 0.1 milli-Tesla
Material:
Surface of foot warmer: 100 % polyester
Inside: teddy lining: 100 %
Manufacturer:
MGG Elektro GmbH
Königsbrückerstr. 61
01099 Dresden, Germany
220–240 V∼ /
50–60 Hz
30 cm (W x H x D)
drip-resistant
moisture protection
polyester
IMPORTANT ADVICE – KEEP
THIS SAFE FOR FUTURE USE!
Important safety
instructions
Failure to comply with the following instructions can
cause personal injury or material damage (electric
shock, skin burns, fire).
The following advice on safety and hazards is intended to protect your health and that of other people as well as to protect the foot warmer. Please
observe these safety instructions and make sure
that you pass on this manual together with the foot
warmer.
DANGER TO
LIFE AND RISK OF ACCIDENTS
FOR INFANTS AND CHILDREN!
leave children unsupervised with the packaging materials. Danger of suffocation.
DANGER OF
ELECTRIC SHOCK! Do not use the
mains power cable for purposes for
7 GB/IE
Important safety instructions
which it was not intended, e.g. for hanging up
the foot warmer, carrying it or to pull the plug
out of the mains socket. Keep the mains power
cable away from heat, oil and sharp edges. If
the mains power cable is damaged or severed,
do not touch the mains power cable, but pull
the mains plug out of the mains socket immediately. Damaged or tangled mains power
cables increase the risk of electric shock.
Use the foot warmer only for the purpose
described in these operating instructions.
This foot warmer is not intended for use in
hospitals or for commercial use.
Children or persons who lack
the knowledge or experience to use the foot
warner or whose physical, sensory or intellectual capacities are limited must never be
allowed to use the foot warmer without supervision or instruction by a person responsible for
their safety. Risk of injury.
RISK OF INJURY! Do not use this
device on helpless people, on chil-
dren, or people who are insensitive
to heat (e.g. diabetics, people whose skin is
affected by illness or who have scarred skin in
the area where the heat will be applied, or
who have taken painkilling medication or
alcohol). Risk of injury.
The textiles used in this
foot warner fufil the
high human ecological
requirements of Öko-
Tex Standard 100, as
verified by the German Hohenstein Research
Institute.
Do not use the foot warmer on
any part of the body that is inflamed, injured or
swollen. Seek medical advice before using the
foot warmer if in doubt. Risk of injury.
RISK OF INJURY FROM BURNS!
Excessively long use can cause skin
burns.
ATTENTION! Do not fall asleep under any
circumstances while the foot warner is in operation. There is a risk of receiving skin burns.
Under certain circumstances, the
electrical and magnetic fields emitted from the foot warmer could
interfere with the proper functioning of your
heart pacemaker. However, the levels are far
below the permissible limits: electric field
strength: max. 5000 V / m, magnetic field
strength: max. 80 A / m magnetic flux density:
max. 0.1 milli-Tesla. Ask your doctor and, if
relevant, the manufacturer of your heart pacemaker before you use this foot warmer.
Avoid damage to the foot
warmer
Only connect this foot warmer
– to the voltage indicated on the device (label),
– do not operate the foot warmer without
supervision,
–
do not switch the foot warmer on
if it is folded or bunched up,
– do not squeeze,
– do not cause any sharp creases in the foot
warmer,
– do not use on animals,
– do not use the foot warmer if it is damp.
The foot warmer It may otherwise be damaged.
The electronic components in the control unit 2
of the foot warmer cause the control unit to
heat up slightly during operation. For this reason, the control unit
2
may not be covered or
be lying on the foot warmer during operation.
Do not pull, twist or crease the cables.
DANGER OF ELECTRIC SHOCK!
Do not insert needles or pointed objects into the foot warmer. There is a
risk of electric shock.
RISK OF INJURY! This foot
warmer pad must not be used by
children unless the control unit
2
has been preset by a parent or other responsi-
ble person, or unless the child has been in-
structed sufficiently in how to use this foot
warmer safely. Risk of injury.
Children should be supervised in order to en-
sure that they do not play with the foot warmer.
Risk of injury.
DANGER OF ELECTRIC SHOCK
AND INJURY! Check the foot
warmer regularly for signs of wear
8 GB/IE
Important safety instructions / Safety system / Preparing the product for use
or damage. If you find such signs of damage,
if the cables are damaged or if the foot
warmer has not been used properly, it must be
returned to the manufacturer or to the service
department before it is used again. There is a
danger of electric shock and injury.
Repairs must only be carried out by specially
trained personnel or at a repair shop authorised by the manufacturer, since special tools
are necessary. Unsatisfactory repairs can lead
to considerable danger for the user.
Only have the foot warmer repaired by qualified specialist personnel using
OEM spare parts. This will ensure your foot
warmer remains safe to use.
If the mains power cable of the
foot warmer is damaged, it has to be replaced
by the manufacturer or its service department
or a similarly qualified person in order to avoid
hazards.
Safety system
Note: This foot warmer is equipped with a safety
system. The electronic sensor technology prevents
the entire surface of the foot warmer from overheating by automatically switching off in the event of a
fault. If the safety system switches the foot warmer
off automatically due to a fault, then the function
3
display
minated, even if the heating pad is switched on.
Please note that, for safety reasons, the foot
on the control unit 2 is no longer illu-
warmer must not be used after a fault and must
be returned to the service address indicated.
Switching on / off / Selecting
the temperature
Insert the mains plug into the mains socket.
Switching on:
Set Level 1, 2, 3, 4, 5 or 6 on the control
2
unit
to switch the foot warmer on.
Note: The function display
after the foot warmer is switched on.
Note: This foot warmer features rapid heating,
which allows it to heat up within the first 15
minutes of operation.
Switching off:
Set Level 0 on the control unit 2 to switch the
foot warmer off.
Note: the function display
Selecting the temperature:
Just before using the heating pad, set it to the
highest temperature setting (setting 6). This will
cause the heating pad to warm up quickly.
If you are going to use the foot warmer for a
number of hours, set it to the lowest temperature setting (setting 1).
The foot warmer can of course be used at any
time if it is switched off. Its teddy plush lining
will warm your feet even if an electric socket is
nowhere near.
3
illuminates
3
ceases to illuminate.
Temperature levels
Set the required temperature level on the
2
control
.
Preparing the product for use
Note: When the foot warmer is used for the first
time, you may notice a smell of plastic; however,
this will disappear after a short time.
Level 0: Off
Level 1: minimum heat
Level 2 - 5: Customised heat
Level 6: maximum heat
9 GB/IE
Preparing the product for use / Cleaning and Care / Storage / Disposal
Automatic switch-off
Note: The foot warmer switches itself off automati-
cally after about 90 minutes. The function display
then starts to flash.
Then select the setting 0 and after about
5 seconds, reset the foot warmer to the desired
temperature setting to switch it on again.
Switch the foot warmer off (setting 0) and pull
the mains plug out of the mains socket if the
heating pad is not to be used after it has
switched itself off automatically.
Cleaning and Care
The foot warmer should be kept clean as it
may not be washed.
DANGER TO
LIFE BY ELECTRIC SHOCK! Re-
move the mains plug from the socket
before you clean the foot warmer. There is
otherwise a risk of an electric shock.
Small stains can be removed with a cloth or
moist sponge and if necessary with a little mild
detergent. The foot warmer may not become
saturated. There is otherwise a risk of an electric shock.
RISK OF DAMAGE TO THE
PRODUCT OR PROPERTY!
Please note that the foot warmer
must not be washed in a machine, spin-dried or
tumbler-dried, dry-cleaned, wrung out, mangled or ironed. The foot warmer It may otherwise be damaged.
The removable teddy lining 1 can be washed
by hand.
DANGER OF ELECTRIC
SHOCK! DANGER OF MATE-
RIAL DAMAGE! Do not use the
foot warmer again until the foot warmer and
the teddy lining
is otherwise a risk of an electric shock.
Note: Non-observance of the following warn-
ings may damage the foot warmer.
1
are completely dry. There
Do not wash.
3
Do not use bleach. Do not use any
cleaning agents containing bleach
(such as heavy duty detergents).
Do not dry in a tumbler dryer.
Do not iron.
Do not dry clean.
Storage
RISK OF DAMAGE TO THE
PRODUCT OR PROPERTY! Let
the foot warmer cool before putting
it away. Otherwise material damage could
occur.
RISK OF DAMAGE TO THE
PRODUCT OR PROPERTY! To
prevent the foot warmer from becoming sharply creased, do not store other
objects on top of the foot warmer. Otherwise
material damage could occur.
If you do not intend to use the foot warmer for
any length of time, store it in the original packaging in a dry environment and without weighing it down.
Disposal
The packaging and packaging material
consist of environmentally friendly materials. They can be disposed of at your
local recycling facility.
Do not dispose of electrical
devices with the household
rubbish!
10 GB/IE
Disposal / Warranty / Service centre / Declaration of conformity
In accordance with European Directive
2002 / 96 / EC relating to old electrical and electronic appliances and its translation into national
law, used electrical equipment must be collected
separately and recycled in an ecologically compatible way.
Contact your local refuse disposal authority for
more details of how to dispose of your worn out
foot warmer.
Warranty / Ser vice centre
We provide a 3-year warranty covering faults in
materials or manufacture of the product from the
purchase date.
The warranty does not cover:
• Damage resulting from improper use.
• Wear parts.
• Defects that were known to the customer at the
time of purchase.
• Damage for which the customer was responsible.
This warranty does not affect the customer‘s legal
rights.
The customer must provide proof of purchase in
order for any warranty claims within the warranty
period to be honoured. Claims under the warranty
are honoured by
Please contact our Service Hotline in the first instance,
before you return the device to the manufacturer.
IAN 75923
02030 249 050
0152 451 32
Declaration of conformity
This foot warmer complies with the requirements of
the relevant European and national guidelines.
This is confirmed by the CE mark.
The relevant declarations are held by the manufacturer.
MGG Elektro GmbH-Service
c / o Dachser GmbH & Co. KG
Thomas-Dachser-Str. 1
89129 Langenau, Germany
for a period of 3 years after the date of purchase.
In the event of a warranty claim, the customer has
the right to have the goods repaired by our own
workshop or a workshop authorised by us. The foot
warmer must not be opened for any reason. Opening or modifying the device invalidates the warranty.
This warranty does not grant any additional rights
to the customer. Complaints are often initiated by
difficulties encountered during use. Many of these
complaints can be resolved by telephone or email.
11 GB/IE
12
Loading...
