Silvercrest SFS 150 A2 Operating instructions
KITCHEN TOOLS
Vacuum Sealer SFS 150 A2
KOMPERNASS GMBH
BURGSTRASSE 21 · D-44867 BOCHUM
www.kompernass.com
ID-Nr.: SFS150A2-09/10-V2
IAN: 61777
Vacuum Sealer
Operating instructions
Foliesvets
Bruksanvisning
Vakuumilaite
Käyttöohje
Lamineringsapparat
Betjeningsvejledning
SFS 150 A2
q
w
e
y
r
ut
i
Content Page
Intended Use 2
Important safety instructions 2
Items supplied 3
Technical Data 3
Description of the appliance 3
Commissioning 3
Inserting the film................................................................................................................................3
Utilisation 4
Sealing the film .................................................................................................................................4
Vacuuming films................................................................................................................................5
Storing the appliance.......................................................................................................................6
Cleaning 6
Cleaning the collector receptacle...................................................................................................6
Cleaning the appliance ...................................................................................................................6
Maintenance 6
Disposal 7
Importer 7
Warranty and Service 7
Read the operating instructions carefully before using the appliance for the first time and preserve this
booklet for later reference. Pass the manual on to whomsoever might acquire the appliance at a later date.
- 1 -
Vacuum Sealer
Intended Use
This plastic film sealer is intended for the occasional
vacuum-packing of food in typical household quantities and only for private household use.
This product is not intended for commercial or industrial applications or for continuous operation.
Important safety instructions
To avoid potentially fatal electric
shocks:
• Protect the appliance against moisture. Only use
the device in dry rooms, not outdoors. Ensure
that fluids can never permeate into the appliance,
whether during cleaning or from the leaking of
fluids during the sealing process. Also, do not
use the appliance if you have wet hands.
• Ensure that the power plug is at all times freely
accessible, so that in a case of emergency it can
be quickly removed from the power source.
• Ensure that when the appliance is in use the power
cable cannot become jammed or damaged in
any way. Place it such that no one can trip or
stumble over it.
• In order to avoid potentially fatal risks, should the
power cable and/or the plug become damaged,
arrange for it/them to be replaced by Customer
Services before continuing to use the appliance.
• Should the appliance become damaged, immediately remove the power plug. Then arrange
for the device to be checked by Customer Services.
• After use or during extended absences, ALWAYS
remove the plug from the power socket. Never
leave the appliance unsupervised when it is
connected to mains power. The appliance is
electrically "live" for as long as the plug is inserted into the wall socket.
To avoid the risk of fire:
• Use only the special plastic films that are suitable
for a plastic film sealer.
• Allow the appliance to cool down after every sealing process before continuing to use it.
• NEVER position the appliance below inflammable
objects, especially not below curtains or drapes.
• Do not use an external timing switch or a separate
remote control system to operate this appliance.
To avoid the risks of accidents and
personal injuries:
• During operation, both the sealing wire and the
cutting wire heat up. NEVER touch them directly
after a sealing process.
• This appliance is not intended for use by individuals (including children) with restricted physical,
physiological or intellectual abilities or deficiences
in experience and/or knowledge unless they are
supervised by a person responsible for their safety or receive from this person instruction in how
the appliance is to be used. Children should be
supervised to ensure that they do not play with
the device.
- 2 -
Items supplied
Description of the appliance
1 Plastic Film Sealer
1 Tube film made of PE-HD
(Polyethylene of high density)
Operating Instructions
DVD with Product Video
Check to ensure that the appliance is undamaged
and that all parts and remnants of the packaging
are removed from it.
Technical Data
Mains voltage: 230-240 V ~50Hz
Power consumption: 150 W
Protection class: II /
Recommended operating times:
Vacuuming + Sealing: 20 Seconds
After vacuuming and sealing allow a break of
80 seconds before continuing to seal further bags.
Collector receptacle
q
Extraction supports
w
Cutting wire
e
Sealing wire
r
Film compartment cover
t
Seal/Cut button
y
Appliance cover
u
Control lamp
i
Commissioning
Place the appliance on a non-slip and stable
surface.
Insert the power plug into a wall power socket.
Inserting the film
Open up the cover to the film compartment
and insert a roll of tube film.
Fold the appliance cover
of tube film through between the appliance
lid
and the appliance.
u
Close the appliance cover
the film compartment
up and pull a piece
u
and the cover of
u
.
t
t
- 3 -
Utilisation
Sealing the film
Attention
For sealing use only films rated HDPE (High Density
PolyEthylene) or LDPE (Low Density PolyEthylene).
The film thickness must be 30 - 50 μ (0.03 - 0.05
mm). Otherwise, the sealing seam will not be tight
and the appliance could be damaged. You will
recognise films of this type by the information on the
packaging.
The quality of the seal joint varies depending on the
type and strength of the film..
:
Firmly press the appliance cover
u
down.
Note:
The bag opening must sit smoothly on the sealing
wire
and on the cutting wire e. Otherwise, the
r
sealing and cutting will not function properly.
Attention
Do not heat the supplied film, for example in a waterbath or similar. It is construed for temperatures of
a maximum of 60°C.
Fold the appliance cover
:
up.
u
Pull out as much film as is required for the task
at hand.
Then close the appliance cover
u
.
Press and hold the Seal/Cut button
both hands until the control lamp
Hold the Seal/Cut button
until the control lamp down
pressed down
y
i
y
lights up.
i
goes out.
with
Note:
To achieve the best results, press the Seal/Cut button
down continuously, applying an even pres-
y
sure and using both hands.
- 4 -
Warning:
If the control lamp idoes not go out after 10
seconds at the latest, the appliance is defective!
Immediately remove the plug from the wall socket.
Do not attempt to repair the appliance yourself. In
this case, contact Customer Services.
Place the open end of the bag around the
extraction supports
them lightly. Thereby, the bag must project to
the markings in the appliance.
. For this you can lift
w
Open the appliance cover
the film. This is sealed at one end and, at the
same time, separated from the roll of tube film.
Seal the remaining open sides, except for one,
in the same manner.
again and remove
u
Fill the bag. You must leave at least 6 cm of the
bag free, measured up to the edge that is to be
sealed.
Warning:
Fill the bags in such a way that, under no circumstances, food remnants or fluids can run out of the
bag when sealing it and permeate into the appliance.
If you do not want to extract the air from the
bag, you should now seal the last open side.
Vacuuming films
When sealing, you can at the same time extract the
air from the bag (vacuuming):
Warning:
Do NOT vacuum bags in which there are liquids.
They will permeate into the appliance and damage
it.
Note:
The bag opening must sit smoothly on the extraction
supports
. Otherwise, the vacuuming, sealing and cutting
e
will not function properly.
Close the appliance cover
, the sealing wire rand the cutting wire
w
and firmly press
u
it down on both sides. Be sure
the Seal/Cut button
the bag.
y
nnoott
. Air is now sucked from
to press on
- 5 -
As soon as the air has been sucked from the
bag, press and hold the Seal/Cut button
with both hands, as already described, and
seal the bag.
Storing the appliance
y
Do not wrap the power cable around the appli-
ance, use the guides provided on the bottom of
the appliance.
Store the appliance where it will be dry and free
from dust and particles, so that nothing
can lodge in the suction device.
Cleaning
Attention!
First remove the power plug from the wall socket
and allow the appliance to cool down completely
before cleaning it or placing it into storage. NEVER
submerse the appliance in fluids of any kind. Do not
permit liquids to permeate into the appliance.
If you do, you risk receiving a potentially fatal electric shock.
Fold up the extraction supports
Carefully pull the collector receptacle
of the appliance using the lateral grips.
w
.
out
q
Clean it in a lukewarm washing-up solution and
the allow then collector receptacle
well.
Replace the collector receptacle
the extraction supports
Cleaning the appliance
w
down.
q
and fold
q
to dry
Clean the appliance only with a dry or lightly
moistened cloth. Do not use abrasives or detergents, these could damage the plastic surfaces.
Do not remove stubborn glue remnants from
the sealing wire
at the very most carefully use a fingernail.
Otherwise, the sealing wire
or the insulation underneath could be da-
e
maged.
with hard or sharp objects,
r
, the cutting wire
r
Maintenance
Warning:
NEVER open the housing! There is potentially fatal
high voltage in the appliance. Arrange for the appliance to be repaired by specialists only.
The appliance is maintenance-free. No form of
maintenance, either on or in the appliance, is intended for execution by the user. In the event of malfunction or apparent damage, make contact with
Customer Services.
Cleaning the collector receptacle
Should food remnants unintentionally be sucked in
when vacuuming, the collector receptacle
tects the appliance from damages. Clean the collector receptacle
Open the appliance cover
as soon as soiling is visible:
q
.
u
q
pro-
- 6 -
Disposal
Warranty and Service
Do not dispose of the appliance with
your normal domestic waste. This
product is subject to the provisions of
European Directive 2002/96/EC.
Dispose of the appliance through an approved
waste disposal centre or at your community waste
facility.
Observe the currently applicable regulations.
In case of doubt, please contact your waste disposal
centre.
Dispose of all packaging materials in an
environmentally friendly manner.
Importer
KOMPERNASS GMBH
BURGSTRASSE 21
44867 BOCHUM, GERMANY
www.kompernass.com
The warranty for this appliance is for 3 years from
the date of purchase. The appliance has been manufactured with care and meticulously examined before delivery. Please retain your receipt as proof of
purchase. In the event of a warranty claim, please
make contact by telephone with our Service Department. Only in this way can a post-free despatch for
your goods be assured.
The warranty covers only claims for material and
maufacturing defects, but not for transport damage,
for wearing parts or for damage to fragile components, e.g. buttons or batteries. This product is for
private use only and is not intended for commercial
use. The warranty is void in the case of abusive and
improper handling, use of force and internal tampering not carried out by our authorized service
branch. Your statutory rights are not restricted in
any way by this warranty.
The warranty period will not be extended by repairs
made under warranty. This applies also to replaced
and repaired parts. Any damage and defects extant
on purchase must be reported immediately after unpacking the appliance, at the latest, two days after
the purchase date. Repairs made after the expiration of the warranty period are subject to payment.
DES UK LTD
Tel.: 0871 5000 700
e-mail: support.uk@kompernass.com
Kompernass Service Ireland
Tel.: 1850 930 412 (0,082 EUR/Min.)
Standard call rates apply. Mobile operators may vary.
e-mail: support.ie@kompernass.com
CY
Kompernass Service Cyprus
Tel.: 800 9 44 01
e-mail: support.cy@kompernass.com
- 7 -
(£ 0.10 / minute)
- 8 -
www.kompernass.com
£
Add. £ 7 p&p.
£ 5,50 £
Name of article Cost p. Unit Total sum
(max. 3 sets per order)
Quantity ordered
Order card SFS 150 A2
(each roll 10 m long)
Triple-pack of tube foil
for Plastic Film Sealer SFS 150 A2
Payment method
(Signature)
Bank Transfer
(Location, Date)
Sort Code: 60-50-06
Account No: 37758829
Account Name: Domestic Electrical
Solutions UK Limited
Natwest Bank Plc
Hammersmith Branch
1.
2
.
(for possible queries) in block capitals.
Bank Transfer (BACS): Please transfer
the complete amount to our account
below:
Please tick y
Enter under “Sender/or
our pr
efer
r
ed payment met
der
er” y
our name, addr
Or
der Card -
Ho
w t
(Telephone)
• Write your name as the sender on the
envelope.
(Post code, town)
hod on t
o
or
On your transfer, please provide the
article(s) you ordered as well as your complete name
and address. Then post your completed order card to
our postal address below.
Our postal address:
DES UK LTD
Unit B7
Oxford Street Industrial Park
Vulcan Road
Bilston/ West Midlands
WV14 7LF
Important:
• Please affix sufficient postage to the letter.
(Street)
(Surname, first name)
Sender
(please complete in block captals)
/
O
r
der
he or
der car
d. Y
ou hav
e
got t
h
r
ee options:
der
ess and telephone number
:
www.kompernass.com
er
www.kompernass.com
€
Add. 12,50 € p&p.
5,95 € €
(each roll 10 m long)
Triple-pack of tube foil
Name of article Cost p. Unit Total sum
(max. 3 sets per order)
Quantity ordered
Order card SFS 150 A2
for Plastic Film Sealer SFS 150 A2
Cheque payment
Payment method
(Signature)
(Location, Date)
• Write your name as the sender on the envelope.
letter.
• Please affix sufficient postage to the
Important:
A: By cheque: Please place a cheque made
payable to
Irish Connection
together with your completed order card
into an envelope and post to our postal
address below.
Our postal address:
Kompernass Service Ireland
c/o Irish Connection
41 Harbour view
Howth Co. Dublin
1.
Order Card -
(for possible queries) in block capitals.
Enter under “Sender/or
der
er”y
How to order:
our name, addr
ess and telephone number
(Telephone)
(Post code, town)
(Street)
(Surname, first name)
Sender
(please complete in block captals)
/
O
rderer
www.kompernass.com
Sisällysluettelo Sivu
Määräystenmukainen käyttö 14
Tärkeitä turvaohjeita 14
Toimituslaajuus 15
Tekniset tiedot 15
Laitteen kuvaus 15
Käyttöönotto 15
Muovin asettaminen.......................................................................................................................15
Käyttö 16
Muovin saumaaminen ...................................................................................................................16
Tyhjiön luominen muoviin..............................................................................................................17
Laitteen säilytys...............................................................................................................................18
Puhdistaminen 18
Keruusäiliön puhdistaminen ..........................................................................................................18
Laitteen puhdistaminen ..................................................................................................................18
Huolto 18
Hävittäminen 19
Maahantuoja 19
Takuu ja huolto 19
Säilytä käsikirja myöhempää käyttöä varten. Jos myyt laitteen, anna käsikirja uudelle omistajalle!
- 13 -
Vakuumilaite
Määräystenmukainen käyttö
Tuote on tarkoitettu kotitalouden elintarvikkeiden
ajoittaiseen tyhjiöpakkaamiseen ja pakkausten saumaamiseen tavanomaisina kotitaloudessa esiintyvinä
määrinä ja ainoastaan yksityiskäyttöön.
Tätä tuotetta ei ole tarkoitettu ammatti- tai teollisuuskäyttöön tai jatkuvaan käyttöön.
Tärkeitä turvaohjeita
• Vedä pistoke pois pistorasiasta käytön jälkeen
tai poissa ollessasi. Älä jätä laitetta ilman valvontaa sen ollessa liitettynä pistorasiaan! Tuotteessa
on verkkojännite niin kauan, kun pistoke on pistorasiassa.
Tulipalovaaran välttämiseksi:
• Käytä ainoastaan erityistä muovia, joka soveltuu
tyhjiöpakkaajassa käytettäväksi.
• Anna laitteen jäähtyä jokaisen saumauskerran
jälkeen, ennen kuin jatkat laitteen käyttöä.
• Älä aseta tuotetta palavien esineiden, erityisesti
verhojen alapuolelle.
• Älä käytä laitetta ulkoisen ajastimen tai erillisen
kaukovaikutusjärjestelmän avulla.
Hengenvaarallisen sähköiskun
välttämiseksi:
• Suojaa laitetta kosteudelta. Käytä laitetta vain
kuivissa tiloissa, ei ulkona. Varmista, ettei laitteeseen pääse koskaan nesteitä, ei puhdistettaessa
eikä saumattaessa ulos vuotavia nesteitä. Älä
myöskään käytä laitetta kostein käsin.
• Huolehdi siitä, että pistoke on aina käsillä, jotta se
voitaisiin mahdollisessa vaaratilanteessa irrottaa
nopeasti pistorasiasta.
• Varmista, ettei verkkojohto voi käytössä jäädä
puristuksiin tai vaurioitua muuten. Vedä johto
niin, ettei siihen voi kompastua.
• Mikäli virtajohto tai verkkopistoke on vioittunut,
se on annettava vaaratilanteiden estämiseksi valtuutetun huoltoliikkeen tarkistettavaksi ennen kuin
tuotetta käytetään.
• Jos laite on vaurioitunut, irrota verkkopistoke
välittömästi. Anna valtuutetun huoltoliikkeen
silloin ensin tarkastaa tuote.
Onnettomuus- ja loukkaantumis-vaarojen välttämiseksi:
• Käytön aikana saumauslanka ja leikkauslanka
kuumenevat. Älä koskaan koske siihen välittömästi saumauksen jälkeen.
• Tätä laitetta ei ole tarkoitettu sellaisten henkilöiden
(mukaan lukien lapset) käyttöön, joiden rajoitetut,
fyysiset, aistilliset tai henkiset kyvyt tai kokemuksen
ja/tai tiedon puute estävät käytön, lukuun ottamatta tilanteita, joissa heitä valvoo turvallisuudesta
vastaava henkilö tai joissa he ovat saaneet tältä
ohjeita laitteen käytöstä. Lapsia on valvottava,
jotta varmistettaisiin, etteivät he leiki laitteella.
- 14 -
Toimituslaajuus
Laitteen kuvaus
1 tyhjiöpakkaaja
1 pussimuovirulla suurtiheyspolyeteeniä (PE-HD)
Käyttöohje
Tuotevideon sisältävä DVD
Tarkasta, että tuote ei ole vaurioitunut ja että kaik-
ki osat ja pakkauksen jäämät on poistettu
tuotteesta.
Tekniset tiedot
Verkkojännite: 230-240 V ~50Hz
Tehontarve: 150 W
Suojausluokka: II /
Suositetut käyttöajat:
Tyhjiön luominen + saumaus: 20 sekuntia
Pidä tyhjiön luomisen ja saumauksen jälkeen 80 sekunnin tauko ennen seuraavan pussin työstämistä.
Keruusäiliö
q
Imuistukka
w
Leikkuulanka
e
Saumauslanka
r
Muovilokeron suojus
t
Saumaus-/leikkuupainike
y
Laitteen kansi
u
Merkkivalo
i
Käyttöönotto
Aseta laite pöydälle tukevasti ja vakaasti.
Työnnä verkkopistoke pistorasiaan.
Muovin asettaminen
Käännä muovilokeron suojus
pussimuovirulla paikoilleen.
Käännä laitteen kansi
pussimuovia laitteen kannen
välistä.
Sulje laitteen kansi
u
ja muovilokeron suojus t.
u
ylös ja aseta
t
auki ja vedä pala
ja laitteen
u
- 15 -
Käyttö
Muovin saumaaminen
Huomio:
Käytä saumaamiseen vain suurtiheys- (PE-HD) tai
pientiheyspolyeteenistä (PE-LD) valmistettua muovia.
Muovin paksuuden on oltava 30 - 50 μ (0,03 0,05 mm). Muutoin saumasta ei tule tiivistä ja laite
voi vaurioitua. Tällaiset muovit tunnistaa pakkauksen
merkinnöistä.
Saumauksen laatu vaihtelee aina muovin laadun ja
paksuuden mukaan.
Huomio:
Älä kuumenna mukana toimitettua muovia esim.
vesihauteessa tai vastaavassa. Se on tarkoitettu
ainoastaan korkeintaan 60 °C:n lämpötiloille.
Käännä laitteen kansi
Vedä ulos tarvitsemasi määrä muovia.
u
auki.
Paina laitteen kansi
lujaa alas.
u
Ohje:
Pussin aukon on sijaittava tasaisesti saumauslangalla
ja leikkuulangalla e. Muutoin saumaaminen
r
ja leikkaaminen ei tapahdu oikein.
Paina saumaus-/leikkuupainiketta
käsin ja pidä sitä painettuna, kunnes merkkivalo
syttyy. Pidä saumaus-/leikkuupainiketta
i
painettuna niin pitkään, kunnes merkkivalo
jälleen sammuu.
molemmin
y
y
i
Sulje sitten laitteen kansi
u
jälleen.
Ohje:
Parhaan tuloksen saat aikaiseksi asettumalla saumaus-/
leikkuupainiketta
painamalla tasaisella paineella molemmin käsin
alaspäin.
- 16 -
alas painaessasi laitteelle ja
y
Loading...
