STEAM IRON SDB 2200 D2
STEAM IRON
Operating instructions
DAMPFBÜGELEISEN
Bedienungsanleitung
IAN 273029
ŻELAZKO PAROWE
Instrukcja obsługi
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Przed przeczytaniem proszę rozłożyć stronę z ilustracjami, a następnie proszę zapoznać się z wszystkimi
funkcjami urządzenia.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.
GB Operating instructions Page 1
PL Instrukcja obsługi Strona 11
DE / AT / CH Bedienungsanleitung Seite 21
A
B
CONTENT PAGE
DIN A5 148 mm 210 mm
Introduction 2
Intended use 2
Scope of delivery 2
Operating elements 2
Technical data 2
Safety instructions 3
Before initial use 5
Filling the water tank 5
Plugging in and ironing 6
Steam ironing 6
Ironing with steam blast 6
Temporarily setting the steam iron aside 6
Turning off the steam iron 7
Drip-stop function 7
Automatic switch-off 7
Cleaning 7
Self-cleaning function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Housing and sole of the iron . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Storage 8
Troubleshooting 8
Disposal 8
Warranty and service 9
Importer 9
- 1 -
STEAM IRON
DIN A5 148 mm 210 mm
Introduction
Congratulations on the purchase of your new appliance.
You have clearly decided in favour of a quality
product. These operating instructions are a constituent of this product. They contain important information with regard to safety, use and disposal.
Before using the product, familiarise yourself with all
of these operating and safety instructions. Use the
product only as described and only for the specified
areas of application. Please also pass these documents on to any future owner, together with the product.
Intended use
Operating elements
Figure A:
1 Water jet
2 Filler opening for the water tank
3 Steam regulator
4 Button for steam blast
5 Button for fine water spray
6 Automatic switch-off indicator lamp
7 Temperature control lamp
8 Thermostat
9 Power cable with anti-kink protection
0 Appliance base
q Ironing sole
w Self-clean button
Figure B:
e Measuring beaker
The steam iron is exclusively intended for ironing
textiles. The iron may only be used indoors and in
private households. Any other use is deemed
improper. The apparatus is not intended for commercial use!
Scope of delivery
Steam Iron
Measuring beaker
Operating instructions
Technical data
Power supply voltage: 220 - 240 V
50/60 Hz
max. power consumption: 2200 W
- 2 -
~
Safety instructions
DIN A5 148 mm 210 mm
Risk of Burns!
•Always hold the steam iron by the handle when it is hot.
•Children should be supervised to ensure that they do not play with the
appliance.
•Never hold your hand over the steam spray or touch hot metal parts.
•The filler opening of the water reservoir must not be opened while the iron is in
use. First allow the steam iron to cool down and remove the plug from the power socket.
•The iron and its connecting cable must be kept out of the reach of children
younger than 8 years old when it is switched on or cooling down.
Risk of Injury! Risk of fire!
•Never leave a steam iron that is hot, switched on or connected to the mains power supply unattended.
•Do not put the steam iron into storage until it has cooled down completely.
•This steam iron must be used and placed on a stable surface.
•When ironing, only use the temperatures detailed in the garment care instructions, or those suitable for the material. Otherwise, you could damage the textiles. Should care instructions not be given or known, start with the lowest temperature setting.
•Always put the iron on a level, heat-resistant surface.
The iron must be in a stable position.
•Should you wish to put the steam iron down, always put it on the appliance
base.
Risk of electric shock!
• The rating of the local power supply must correspond with the details given on
the rating plate of the appliance.
•To avoid potential risks, arrange for defective appliances to be checked and
possibly repaired by a qualified specialist workshop, or contact our Customer
Service Department.
•Arrange for defective power plugs and/or cables to be replaced immediately
by qualified technicians or our Customer Service Department.
•To disconnect from the power source, only pull the plug itself, not the cable.
- 3 -
•Never bend (kink) or crush the power cable. Arrange it in such a way that it
DIN A5 148 mm 210 mm
cannot come into contact with hot surfaces and so that no-one can step on it or
trip over it.
•Remove the plug from the power socket after every use, and before cleaning or
filling with tap water.
•Always unwind the power cable fully before switching on, and do not use an
extension cable.
•Never touch the power cable or the plug with wet hands.
•Never use the steam iron near a bath, shower, wash basin or other vessel containing water. The proximity of moisture presents a danger, even when the appliance is switched off.
•Under no circumstances should you submerge the steam iron in liquid or permit
liquids to penetrate the casing of the steam iron. Do not expose the appliance
to humidity and do not use outdoors. Should liquids enter the casing, unplug the
appliance from the socket immediately and arrange for it to be repaired by a
qualified technician.
•You may not open the casing of the steam iron. Should repairs be necessary,
only allow authorised technicians to repair a defective appliance.
•Under NO circumstance should you use the appliance if it shows visible signs
of damage, has fallen, or is leaking.
Arrange for it to be repaired by qualified specialists.
•Do not use the appliance if the anti-kink protection on the power cable is
damaged!
•This appliance may be used by children aged 8 years or over and by individuals with reduced physical, sensory or mental capabilities, or lack of experience
and/or knowledge if they are supervised or have been instructed in the safe use
of the appliance and have understood the potential risks. Children may not
play with the appliance.
Cleaning and user maintenance should not be carried out by children without
supervision.
- 4 -
Attention! Property Damage!
DIN A5 148 mm 210 mm
• Should the clothing care instructions forbid iro-
ning, (symbol ), the clothing item may not be
ironed. If you do so, the clothing item could be
permanently damaged.
• The water tank is to be filled exclusively with tap
water or distilled water. Otherwise, you will damage the steam iron.
• Do not clean the steam iron with solvents, alcohol
or abrasive cleaning agents, since these could
cause damage.
Before initial use
• Remove the steam iron from the packaging.
• Remove all stickers and protective film from the
steam iron and the ironing sole q.
Filling the water tank
• Hold the iron at an angle.
• Open the cover of the filler opening for the
water tank 2.
• Using the measuring beaker e, fill the water
tank to the "MAX" marking.
• Slide the cover of the filler opening for the water
tank 2 back to close it.
Note:
Should the tap water in your area be rated as hard,
it is recommended that you mix tap water with some
distilled water. Otherwise, the jets for the steam
blast function could calcify (become blocked) prematurely.
To extend the optimal steam blast function, mix tap
water with distilled water as follows.
Risk of asphyxiation!
Plastic bags can be dangerous. To avoid the risk of
asphyxiation, keep plastic bags out of the reach of
toddlers and small children.
• Pour water into the water tank (see chapter
"Filling the water tank").
• Insert the plug into a wall power socket supplying an electrical current as detailed on the rating
plate.
• Move the thermostat 8 to the "MAX" position.
• Heat the steam iron up for several minutes at the
highest setting.
• Press the button for the steam blast 4 a few
times until steam exits from the ironing sole q.
• Then iron a scrap piece of material to remove
possible contamination from the ironing sole q.
Ratios - distilled
Water hardness
very soft / soft 0
medium 1 : 1
hard 2 : 1
very hard 3 : 1
The water hardness level can be queried at your
local water works.
water to
tap water
- 5 -
Plugging in and ironing
DIN A5 148 mm 210 mm
Dry ironing is possible at all temperatures, steam ironing is possible by adjusting to on the
thermostat 8.
• Insert the plug into a power socket.
Attention! Property Damage!
Should the clothing care instructions forbid ironing,
(symbol ), the clothing item may not be ironed.
If you do so, the clothing item could be permanently
damaged.
• Check the care instructions on the labels in the
garment to see whether it is suitable for being
ironed, and at which temperature setting.
Symbol thermostat 8
Type of material
Acrylic, rayon
Silk, wool, polyester
blended fabrics
• Wait until the temperature control lamp 7
switches off.
• To moisten the laundry, press the button for fine
water spray 5.
This function is suitable for extremely dry and extremely
crumpled garments.
Steam ironing
• Set the steam regulator 3 to the desired steam
setting.
• The thermostat 8 must be moved to at least
adjustment range . Otherwise it cannot
produce any steam.
Ironing with steam blast
The steam blast is especially suitable for smoothing
parts of a garment that are difficult to reach.
• Slightly raise the steam iron.
• For a steam blast, press the steam blast
button 4.
Cotton, linen, viscose
• Select the best suitable temperature setting with
the thermostat 8.
Note:
While it is heating up, always place the iron on the
base 0.
If you place the iron on the ironing sole q and do
not move it, the automatic switch-off will be activated after 30 seconds (see chapter “Automatic
switch-off”) and the appliance stops heating.
The temperature control lamp 7 glows. When the
set temperature has been reached, the temperature
control lamp 7 goes out.
You can also use the steam blast function to smooth hanging textiles.
Hold the iron vertically and press the steam blast
button 4.
Temporarily setting the steam
iron aside
Risk of fire!
NEVER leave the hot, mains-connected or switched-on
steam iron unattended.
• Set the thermostat 8 to the "MIN" position.
• Always put the steam iron on the appliance
base 0.
- 6 -
Turning off the steam iron
DIN A5 148 mm 210 mm
• Remove the plug from the wall socket.
• Empty the water tank and clean the ironing
sole q.
• Put the steam iron on the appliance base 0
after it has cooled down.
Note:
The automatic switch-off is not a substitute for unplugging the apparatus from the power supply! It is
only intended for reducing the risk of fire if the iron
is accidentally left on!
Cleaning
Drip-stop function
With conventional steam irons it can occur that water
drips from the ironing sole q at low temperatures.
However, this iron possesses a new equipment characteristic, the DRIP-STOP function. At low temperatures the iron automatically switches off the steamblast function. When this happens, a "CLICK" is
heard. You must then select a suitable temperature
using the thermostat 8. As soon as this is reached,
steam production continues.
Automatic switch-off
The iron is equipped with an automatic switch-off.
This stops the iron from heating up.
If the iron is standing on its ironing sole q and has
not been moved for approx. 30 seconds, acoustic
warning signals are heard and the automatic switchoff indicator lamp 6 flashes. The iron will no longer
be heated. To deactivate the automatic switch-off,
pick up the iron and move it around a little. The
automatic switch-off indicator lamp 6 will go off
and the iron will heat up again.
If the iron is standing on its base 0 and has not
been moved for approx. 8 minutes, acoustic warning
signals are heard and the automatic switch-off indicator lamp 6 flashes. The iron is no longer heated.
To deactivate the automatic switch-off, pick up the
iron and move it around a little. The automatic
switch-off indicator lamp 6 will go off and the iron
will heat up again.
Self-cleaning function
• Fill the water tank to the "MAX" marking.
• Insert the plug into a wall socket.
• Move the thermostat 8 to the "MAX" position.
• Adjust the steam regulator 3 to maximum steam
power.
• Allow the steam iron to heat up until the temperature control lamp 7 switches off and once
again glows.
• Hold the steam iron horizontally over a catchment
receptacle.
• Press and hold down the self-clean button w.
Move the steam iron back and forth a little.
Steam and boiling water flows from the steam
exit holes in the ironing sole q.
Impurities that may be present are washed out.
• Release the self-clean button w as soon as all
of the water has exited.
• Thoroughly dry the ironing sole q. For this, slide
the ironing sole q back and forth over a hand
towel or an old piece of material several times.
• Allow the steam iron to cool down before placing
it in storage.
- 7 -
Housing and sole of the iron
DIN A5 148 mm 210 mm
Disposal
Potentially fatal danger!
Remove the plug before cleaning the device.
There is a risk of electric shock!
Risk of physical injury!
Allow the appliance to cool down before cleaning
it. Otherwise, there is a risk of burns!
Attention! Property Damage!
Do not use abrasive, aggressive or chemical cleaning agents.
They can damage the surface and also lead to irreparable damage to the appliance.
• Clean the housing with a soft, dry cloth only.
• Clean the ironing sole q using a damp cloth
and a mild, non-scouring detergent.
Storage
Store the appliance in a clean, dust-free, and dry
location after it has cooled down.
Do not dispose of the appliance in your
normal domestic waste. This appliance
is subject to the provisions of European
Directive 2012/19/EU.
Dispose of the appliance through an approved disposal centre or at your community waste facility.
Observe the currently applicable regulations.
In case of doubt, please contact your waste disposal
centre.
Dispose of all packaging materials in an
environmentally friendly manner.
Troubleshooting
Steam iron producing little or no steam:
The reserves of water in the steam iron are depleted.
Fill the water tank with tap water (See "Filling the
water tank").
The steam iron does not get hot:
• The steam iron is not plugged in or is not switched
on. Insert the plug into a wall power socket and
adjust the thermostat 8 to the desired ironing
temperature.
• The steam iron is defective. Arrange for the steam
iron to be repaired by qualified specialists.
- 8 -
Warranty and service
DIN A5 148 mm 210 mm
Importer
The warranty for this appliance is for 3 years from
the date of purchase. The appliance has been manufactured with care and meticulously examined
before delivery.
Please retain your receipt as proof of purchase. In the
event of a warranty claim, please telephone our
Service Department. This is the only way to ensure
that your goods are dispatched free of charge.
The warranty only covers claims for material and
manufacturing defects, but not for transport damage,
wearing parts or damage to fragile components
such as buttons or batteries. This product is for private
use only and is not intended for commercial use.
The warranty is void in the case of incorrect and improper handling, use of force and internal manipulation that is not carried out by our authorised service
branch. Your statutory rights are not restricted in any
way by this warranty.
The warranty period will not be extended by repairs
made under warranty. This also applies to replaced
and repaired parts. Any damage and defects that
are discovered immediately after purchase must be
reported immediately after unpacking the appliance, no more than two days after the purchase date.
Repairs made after the expiration of the warranty
period are subject to payment.
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com
Service Great Britain
Tel.: 0871 5000 720 (£ 0.10/Min.)
E-Mail: kompernass@lidl.co.uk
IAN 273029
Hotline availability:
Monday to Friday 08:00 - 20:00 (CET)
- 9 -
DIN A5 148 mm 210 mm
- 10 -
SPIS TREŚCI STRONA
DIN A5 148 mm 210 mm
Wstęp 12
Zastosowanie zgodnez przeznaczeniem 12
Zakres dostawy 12
Elementy obsługowe 12
Dane techniczne 12
Wskazówki dotyczące bezpieczeństwa 13
Przed pierwszym użyciem 15
Napełnianie zbiornika 15
Podłączanie i prasowanie 16
Prasowanie z parą 16
Prasowanie z uderzeniem pary 16
Chwilowe odstawianie żelazka z nawilżaczem 16
Wyłączanie żelazka z nawilżaczem 17
Funkcja zapobiegająca kapaniu 17
Automatyczne wyłączanie 17
Czyszczenie 17
Funkcja samoczyszczenia . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Obudowa i stopa żelazka . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Przechowywanie 18
Usuwanie zakłóceń działania 18
Utylizacja 18
Gwarancja i obsługa posprzedażna 19
Importer 19
- 11 -
ŻELAZKO NA PARĘ
DIN A5 148 mm 210 mm
Wstęp
Gratulujemy zakupu naszego urządzenia.
Jest to produkt wysokiej jakości. Instrukcja obsługi
stanowi część tego produktu. Zawiera ona ważne
wskazówki dotyczące bezpieczeństwa, użytkowania i utylizacji urządzenia. Przed przystąpieniem do
użytkowania produktu, zapoznaj się z wszystkimi
dotyczącymi obsługi i bezpieczeństwa. Używaj
produkt zgodnie z opisem i w podanych obszarach
zastosowania. W razie przekazania produktu osobom
trzecim, nie zapomnij dołączyć również instrukcji
obsługi.
Zastosowanie zgodne
z przeznaczeniem
Żelazko z nawilżaczem jest przeznaczone wyłącznie
do prasowania ubrań. Można go używać wyłącznie
w pomieszczeniach zamkniętych w gospodarstwach
domowych. Jakiegokolwiek inne zastosowania
uważane są za niezgodne z i przemysłowych.
Wykorzystywanie do celów komercyjnych i
przemysłowych jest zabronione!
Elementy obsługowe
Rysunek A:
1 Dysza
2 Otwór do wlewania wody
3 Regulator pary
4 Przycisk uderzenia pary
5 Przycisk spryskiwacza
6 Kontrolka automatycznego wyłączania
7 Lampka kontrolna temperatury
8 Regulator temperatury
9 Przewód sieciowy
0 Podstawa
q Stopa żelazka
w Przycisk funkcji samoczyszczenia (Selfclean)
Rysunek B:
e Miarka
Dane techniczne
Napięcie zasilania: 220 - 240 V
50/60 Hz
Maksymalna moc: 2200 W
~
Zakres dostawy
Żelazko na parę
Miarka
Instrukcja obsługi
- 12 -
Loading...
