FIUS1401G131
CHOO CHOO express train
NOTE: because this manual contains 3 languages, the Assembly illustrations are separate from the Assembly verbal instructions (Assembly verbal instructions are several pages deeper into the manual)
NOTA: este manual contiene 3 idiomas, por lo tanto las ilustraciónes para ensamblaje estan aparte de las instrucciónes de ensamblaje escritas (Las instrucciónes de ensamblaje escritas estan varias paginas adelante en el manual).
NOTE: puisque ce manuel est traduit en 3 langues, les illustrations d'assemblage ne se trouvent pas sur la même page que les instructions verbales d'assemblage (les instructions verbales d'assemblage sont quelques pages plus loin dans le manuel).
USE AND CARE |
EN |
EMPLEO Y MANUTENCION |
ES |
UTILISATION ET ENTRETIEN |
FR |
See separate insert sheet for more information
Vea la hoja separada del separador de millares para másinformación
Voir ls feuille séparée d’insertion pour plus d’information
6 VOLT
Model Number IGED1116
MADE IN U.S.A.
SEE VERBAL INSTRUCTIONS |
INITIAL BATTERY CHARGE |
AFTER THE PICTURES |
|
VER LAS INSTRUCCIONES |
PRIMERA CARGA DE LA |
DESPUÉS DE LOS DISEÑOS |
BATERÍA |
VOIR LES INSTRUCTIONS |
PREMIÈRE CHARGE DE |
APRÈS LES DESSINS |
BATTERIE |
!
|
ASSEMBLY |
|
|
MONTAJE |
|
|
MONTAGE |
|
|
1 |
2 |
|
2 |
|
|
|
A |
|
1 |
|
|
|
B |
3 |
4 |
5 |
1
2
6 |
7 |
8 |
OPEN
LOCKED
A
9 |
10 |
FEATURES AND
INSTRUCTIONS FOR USE
CARACTERÍSTICAS Y USO
CARACTERÍSTIQUES ET
UTILISATION
A
B
11
b
13 |
A |
C |
16 |
BATTERY RECHARGE
CARGA DE LA BATERÍA
CHARGE DE LA BATTERIE
B |
C |
21 |
12 |
A |
C |
14 |
a |
b |
17 |
B |
A |
19 |
B |
A |
22 |
BATTERY REPLACEMENT
CAMBIO DE LA BATERÍA
REPLACEMENT DE LA BATTERIE
2
1
3
15
18
B
C
20
1
2
23
REPLACEMENT PARTS |
PIEZAS DE RECAMBIO |
PIÈCES DE RECHANGE |
CHOO CHOO express train IGED1116 |
|
|
|
|
1SPST9168YY
2SPST9111GR 3dx SPST8532KDYY 3sx SPST8532KSYY
4MMRP0990
5SPST8588JGP
6SPST9071R
7SPST8512GR
8SPST8513R
9SPST8514GP
10SPST9128GL
11SPST8517YY
12IAKB0022
13SPST8516GR
14SPST8515GR
15SPST8521GP
16SPST8541N
17SAGI9963JKTBN
18SPST8511JR 19dx SPST8518DGR 19sx SPST8518SGR
20SPST8644GP
21SPST8538YY
22SPST8521GP
23ASGI0169GP
24SPST9072GR
25SPST8535J
26MMEV0622
27IKCB...
28SOFF0214Z
29SOFF0214Z
30SOFF0215Z
31SPST8537JGP
32SPST8519YY
33 |
SPST8536YY |
25 |
|
34 |
SPST8589N |
|
|
35 |
SOFF0214Z |
24 |
|
36 |
SOFF0214Z |
||
|
|||
37 |
SPST8520YY |
|
|
38 |
SPST8519YY |
|
|
39 |
SPST8519YY |
|
|
40 |
MEVA0061 + MEIE0041 electrical diagram |
||
41 |
SAGI9992 |
|
|
42 |
SAGI3635WJKB |
|
|
43 |
ASGI0170GPR |
|
|
44dx |
SPST9196N |
|
|
44sx |
SPST9196R |
|
|
27
21
41
|
|
|
|
8 |
|
|
MEDI0005 |
LAMP |
LOUDSPEAKER |
|
|
|
MEVA0061 |
|
|
b |
b |
|
|
|
r |
|
SOUND |
|
|
|
BOARD |
|
|
|
|
|
|
|
|
|
MEIE0041 |
|
|
w |
bk |
|
|
7 |
|
|
r |
bk |
|
|
|
MEPU0036 |
|
|
|
|
r |
bk |
|
|
|
b |
y |
|
|
|
MEPU0033 |
|
26 |
|
|
b |
y |
|
|
SAGI9992 |
|
|
|
|
|
|
|
40 |
9
|
|
|
|
|
10 |
|
|
|
|
44 dx |
|
4 |
|
|
11 |
2 |
3 dx |
|
44 sx |
|
|
||
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
3 sx |
|
12 |
|
|
1 |
|
|
|
5 |
|
|
14 |
|
|
|
34 |
6 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
18 |
13 |
|
|
|
|
|
|
|
|
|
|
|
|
43 |
|
|
|
|
|
|
|
|
31 |
36 |
38 |
|
|
|
|
|
|
17 |
|
|
|
|
|
|
|
35 |
|
15 |
|
|
|
|
|
|
|
|
|
|
|
|
30 |
37 |
|
|
|
|
|
|
|
|
|
|
21 |
|
|
29 |
|
33 |
16 |
|
|
28 |
|
|
|
|
39 |
15 |
|
|
|
|
|
|
|
|
42 |
|
|
32 |
|
20 |
|
|
23 |
|
|
|
22 |
|
|
|
|
|
|
|
|
19 sx |
|
|
ENGLISH
PEG PEREGO® thanks you for choosing this product.For almost 60 years,PEG PEREGO have been taking children for an outing:first with its famous baby carriages and strollers, later with its pedal and battery operated toy vehicles.
Discover our complete range of products, news and other information about the Peg Perego world on our web site www.pegperego.com
IMPORTANT INFORMATION
•Read this instruction manual carefully to learn the use of the toy and to teach your child safe and enjoyable driving. Please keep this manual (with your original sales receipt) for use as a reference in the future.
•DO NOT RETURN YOUR TOY TO THE STORE.This product cannot be returned for a refund after it has been used. If you have ANY questions, need replacement parts or need assistance, call us toll-free; U.S.A. , call 1-800-728-2108 / CANADA, call 1-800-661-5050
•This product meets and/or exceeds all ASTM (American Society for Testing and Materials) TOY SAFETY STANDARDS, including F 963, Consumer Toy Safety Specifications as well as C.R.C, c.931, the Canadian Hazardous Products (Toys)Regulations.
•Tools needed for assembly: small and medium phillips screwdrivers.
•Your new toy is partially pre-assembled. It will require adult assembly. Please set aside at 15-20 minutes for assembly.
•Before the toy is used for the first time, charge the battery for 18 hours to initiate them. Failure to do this can result in permanent battery damage.
•Use only with the included Peg Perego 6 Volt lead-acid, rechargeable battery and a Peg Perego 6 Volt Charger (both included).
•Year 1-3
•Weight capacity 40 lbs
•Do not exceed the maximum total weight capacity of 40 lbs (18,1Kg).
Contents:
•1 Choo Choo Express Train riding toy -- partially assembled •1 Rechargeable 6V 3,3Ah sealed lead-acid battery
•1 Charger 6V
•one 60 W motor -- pre installed •assembly hardware
•parts to be assembled •decals
•Speed: 1,5 mph
•Peg Perego reserves the right to modify or change its products. Price, literature, manufacturing processes or locations or any combination of the above mentioned entities may change at any time for any reason without notice with impunity.
CAUTION:
ELECTRIC TOY NOT RECOMMENDED FOR CHILDREN UNDER 1 YEAR OF AGE.AS WITH ALL ELECTRIC PRODUCTS, PRECAUTIONS SHOULD BE OBSERVED DURING HANDLING AND USE TO PREVENT ELECTRIC SHOCK. RECHARGER INCLUDED. 120 VOLTS, 60Hz, 15W INPUT, 6 VOLTS (DC) OUTPUT.
BATTERY MAINTENANCE AND SAFETY
CAUTION:
Only adults should recharge batteries never children. Never allow children to handle batteries.
Only use the batteries specified by the manufacturer. Only use the charger specified by the manufacturer. Do not mix old and new batteries.
Do not mix alkaline, standard (carbon-zinc), or rechargeable (nickel-cadmium) batteries.
CHARGING THE BATTERY
• Charge the batteries no longer than 24 hours, following the instructions enclosed with the battery charger.
• Charge the battery, as the toy shows low power, in this way you will avoid damage to the battery.
•If you don’t use your toy for a long period of time unplug the battery from the main wire harness of the toy. Remember to charge the battery at least every three months.
•Never charge the battery upside down.
•Do not forget batteries during charging! Check them periodically.
•Never use a replacement recharger or batteries unless they are approved by PEG PEREGO.
•Batteries are sealed and maintenance free.
•Battery polarity must be observed when connecting battery to wiring.
WARNING:
•BATTERIES CONTAIN TOXIC AND CORROSIVE SUBSTANCES. DO NOT TAMPER WITH THEM.
•Batteries contain an acid-based electrolyte.
• Do not make direct contact between battery terminals, as this can cause an explosion or fire.
•Charging produces explosive gases. Charge batteries in a well ventilated area away from sources of heat and flammable materials.
•Exhausted batteries are to be removed from the toy.
•Do not place the batteries near clothing to avoid damage.
IF A LEAK DEVELOPS
Shield your eyes.Avoid direct contact with the electrolyte, protect your hands.
Place battery in a plastic bag and follow directions listed below.
IF ELECTROLYTE COMES IN CONTACT WITH SKIN OR CLOTHING
Flush with cool water for at least 15 minutes.
See a physician at once.
IF ELECTROLYTE IS INJESTED
Give tap water, milk of magnesia or egg whites at once.
Do not induce vomiting.
See a physician at once.
DISPOSAL OF BATTERIES Help protect the environment!
Do not throw used batteries in your regular, household trash.
Dispose of the old batteries in an approved dumping station; contact your local environmental protection agency office for further information.
