Page 1

Operating Instructions Display Operations

Interactive Plasma Display

Model No.

TH-50PB2U TH-65PB2U

English

Before connecting, operating or adjusting this product, please read these instructions completely. Please keep this manual for future reference.

Page 2

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

WARNING: To reduce the risk of electric shock, do not remove cover or back. No user-serviceable parts inside. Refer servicing to qualiﬁ ed service personnel.

The lightning flash with arrowhead within a triangle is in tend ed to tell the user that parts inside the product are a risk of electric shock to per sons.

The exclamation point within a triangle is intended to tell the user that important operating and servicing instructions are in the papers with the ap pli ance.

WARNING : To prevent damage which may result in ﬁ re or shock hazard, do not expose this apparatus to rain

or mois ture. Do not place containers with water (ﬂ ower vase, cups, cosmetics, etc.) above the set. (including on shelves above, etc.)

WARNING : 1) To prevent electric shock, do not remove cover. No user serviceable parts inside. Refer servicing to

qualiﬁ ed service personnel.

2) Do not remove the grounding pin on the power plug. This apparatus is equipped with a three pin grounding-type power plug. This plug will only ﬁ t a grounding-type power outlet. This is a safety fea ture. If you are unable to insert the plug into the outlet, contact an electrician.

Do not defeat the purpose of the grounding plug.

Page 3

Important Safety Instructions

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliﬁ ers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not ﬁ t into your outlet, consult an electrician for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11) Only use attachments / accessories speciﬁ ed by the manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table speciﬁ ed by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart / apparatus combination to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualiﬁ ed service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

15) To prevent electric shock, ensure the grounding pin on the AC cord power plug is securely connected.

Page 4

Dear Panasonic Customer

Welcome to the Panasonic family of customers. We hope that you will have many years of enjoyment

from your new Plasma Display.

To obtain maximum benefit from your set, please read these Instructions before making any adjustments,

and retain them for future reference.

Retain your purchase receipt as well, and record the model number and serial number of your set in the

space provided on the rear cover of these instructions.

Visit our Panasonic Web Site http://panasonic.net

Table of Contents

Important Safety Instructions .................................. 3

FCC STATEMENT ...................................................... 5

Safety Precautions ................................................... 6

Maintenance .............................................................. 7

Accessories .............................................................. 8

Accessories Supplied .............................................. 8

Remote Control Batteries ........................................ 8

Connections .............................................................. 9

AC cord connection and ﬁ xing, cable ﬁ xing ............. 9

Speaker connection ............................................... 10

Video equipment connection ................................. 10

VIDEO and COMPONENT / RGB IN connection ...11

HDMI connection ................................................... 12

DVI-D IN connection .............................................. 12

PC Input Terminals connection .............................. 13

SERIAL Terminals connection ............................... 14

Power ON / OFF ...................................................... 15

Selecting the input signal ...................................... 17

Basic Controls ........................................................ 18

ASPECT Controls ................................................... 20

Digital Zoom ............................................................ 21

MULTI PIP ................................................................ 22

On-Screen Menu Displays ..................................... 23

Adjusting POS./SIZE .............................................. 24

PICTURE Adjustments ........................................... 27

ADVANCED SETTINGS ........................................ 28

Picture Proﬁ les ....................................................... 29

Saving proﬁ les ....................................................... 30

Loading proﬁ les ..................................................... 31

Editing proﬁ les ....................................................... 31

SOUND Adjustment ................................................ 32

SDI SOUND OUTPUT ........................................... 33

SETUP menu ........................................................... 34

DAY/TIME SETUP / ON/OFF TIMER SETUP .......... 35

DAY/TIME SETUP ................................................. 35

ON/OFF TIMER SETUP ........................................ 35

TOUCH-PEN SETTINGS ......................................... 36

MULTI PIP SETTINGS ............................................. 38

SCREENSAVER (For preventing image

retention) ................................................................. 39

Setup of SCREENSAVER Time ............................ 40

Reduces screen image retention .......................... 41

EXTENDED LIFE SETTINGS ............................... 41

ECO MODE SETTINGS ........................................... 44

Customizing the Input labels ................................. 45

FUNCTION BUTTON SETTINGS ............................ 46

NO ACTIVITY POWER OFF .................................... 47

MENU DISPLAY DURATION / OSD

BRIGHTNESS .......................................................... 47

OSD LANGUAGE .................................................... 47

DISPLAY ORIENTATION ......................................... 47

SETUP for Input Signals ........................................ 48

COMPONENT / RGB IN SELECT ......................... 48

YUV / RGB IN SELECT ......................................... 48

SIGNAL menu ....................................................... 49

Options Adjustments ............................................. 52

Weekly Command Timer ....................................... 55

Audio input select .................................................. 57

Touch Panel settings (Settings when using

Touch Panel) ......................................................... 58

Input Search .......................................................... 59

Troubleshooting ..................................................... 60

List of Aspect Modes ............................................. 61

Applicable Input Signals ........................................ 62

Shipping condition ................................................. 63

Command list of Weekly Command Timer ........... 64

Speciﬁ cations ......................................................... 65

Page 5

FCC STATEMENT

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced technician for help.

This device complies with Part15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC CAUTION: To assure continued compliance, follow the attached installation instructions and use only shielded interface cables when connecting to computer or peripheral devices. Some recommended user provided interface cables may require usage of the attached ferrite core kit(s), refer to interface cable connection instructions for details. Any changes or modiﬁ cations not expressly approved by Panasonic Corp. of North America could void the user's authority to operate this device.

FCC Declaration of Conformity

Model No. TH-50PB2U, TH-65PB2U

Responsible Party: Panasonic Corporation of North America Three Panasonic Way 2F-5, Secaucus, NJ 07094 Contact Source: Panasonic System Communications Company of North America 1-800-973-4390

CANADIAN NOTICE:

This Class B digital apparatus complies with Canadian ICES-003.

Note:

Do not allow a still picture to be displayed for an extended period, as this can cause a permanent image retention to remain on the Plasma Display. Examples of still pictures include logos, video games, computer images, teletext and images displayed in 4:3 mode.

Trademark Credits

• VGA is a trademark of International Business Machines Corporation.

• Macintosh is a registered trademark of Apple Inc., USA.

• SVGA, XGA, SXGA and UXGA are registered trademarks of the Video Electronics Standard Association. Even if no special notation has been made of company or product trademarks, these trademarks have been fully

respected.

• HDMI, the HDMI Logo, and High-Deﬁ nition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

Page 6

Safety Precautions

CAUTION

This Plasma Display is for use only with the following optional accessories. Use with any other type of optional accessories may cause instability which could result in the possibility of injury.

• Pedestal .................................................................... TY-ST42P50 (for TH-50PB2U),

• Mobile Stand for Display ........................................... TY-ST50PB2 (for TH-50PB2U), TY-ST65PF1 (for TH-65PB2U),

• Mobile stand .............................................................. TY-ST58PF20 (for TH-50PB2U)

• Wall-hanging bracket (vertical) .................................. TY-WK42PV20 (for TH-50PB2U)

• Wall-hanging bracket (angled) .................................. TY-WK42PR20 (for TH-50PB2U),

• Ceiling-hanging bracket ............................................ TY-CE42PS20 (for TH-50PB2U)

• Touch Panel ..............................................................

• BNC Dual Video Terminal Board ............................... TY-FB9BD

• HD-SDI Terminal Board ............................................. TY-FB9HD

• HD-SDI Terminal Board with audio ........................... TY-FB10HD

• Dual Link HD-SDI Terminal Board ............................. TY-FB11DHD

• Dual HDMI Terminal Board ....................................... TY-FB10HMD

• DVI-D Terminal Board ............................................... TY-FB11DD

• AV Terminal Box ....................................................... TY-TB10AV

• Mate-IF Board ........................................................... TY-FB11HB

• Electronic Pen for Interactive Plasma Display

•

Electronic Pen Adapter for Interactive Plasma Display

•

Electronic Pen Charger for Interactive Plasma Display

• Wireless Module........................................................ ET-WM200U

(All of the following accessories are manufactured by Panasonic Corporation.)

TY-ST65P20 (for TH-65PB2U)

TY-ST65PB2 (for TH-65PB2U)

TY-WK65PR20 (for TH-65PB2U)

TY-TP50P30K (for TH-50PB2U), TY-TP65P30K (for TH-65PB2U)

.............

TY-TPEN2

... TY-TAD20

... TY-TCG20

Always be sure to ask a qualiﬁ ed technician to carry out set-up.

Small parts can present choking hazard if accidentally swallowed. Keep small parts away from young children. Discard unneeded small parts and other objects, including packaging materials and plastic bags/sheets to prevent them from being played with by young children, creating the potential risk of suffocation.

When using the Plasma Display

Do not bring your hands, face or objects close to the ventilation holes of the Plasma Display.

Top of the Plasma Display is usually very hot due to the

• high temperature of exhaust air being released through the ventilation holes. Burns or personal injuries can happen if any body parts are brought too close. Placing any object near the top of the display could also result in heat damages to the object as well as to the Display if its ventilation holes are blocked.

Be sure to disconnect all cables before moving the Plasma Display.

•

Moving the Display with its cables attached might damage the cables which, in turn, can cause ﬁ re or electric shock.

Disconnect the power plug from the wall outlet as a safety precaution before carrying out any cleaning.

• Electric shocks can result if this is not done.

Clean the power cable regularly to prevent it from becoming dusty.

• Built-up dust on the power cord plug can increase humidity which might damage the insulation and cause ﬁ re. Unplug the cord from the wall outlet and clean it with a dry cloth.

This Plasma Display radiates infrared rays, therefore it may affect other infrared communication equipment. Install your infrared sensor in a place away from direct or reﬂ ected light from your Plasma Display.

Note:

Page 7

Safety Precautions

WARNING

Setup

Do not place the Plasma Display on sloped or unstable surfaces, and ensure that the Plasma Display does not hang over the edge of the base.

• The Plasma Display may fall off or tip over.

Do not place any objects on top of the Plasma Display.

•

If water spills onto the Plasma Display or foreign objects get inside it, a short-circuit may occur which could result in ﬁ re or electric shock. If any foreign objects get inside the Plasma Display, please consult an Authorized Service Center.

Do not cover the ventilation holes.

• Doing so may cause the Plasma Display to overheat, which can cause ﬁ re or damage to the Plasma Display.

Transport only in upright position!

• Transporting the unit with its display panel facing upright or downward may cause damage to the internal circuitry.

If using the pedestal (optional accessory), leave a space of 3 15/16” (10 cm) or more at the top, left and right, and 2 3/4” (7 cm) or more at the rear, and also keep the space between the bottom of the display and the ﬂ oor surface. If using some other setting-up method, follow the manual of it. (If there is no speciﬁ c indication of installation dimension in the installation manual, leave a space of 3 15/16” (10 cm) or more at the top, bottom, left and right, and 2 3/4” (7 cm) or more at the rear.)

When installing the Plasma Display vertically;

Turn up the power switch for the upward direction when you install the Plasma Display vertically. And set “DISPLAY ORIENTATION” to “PORTRAIT” in SETUP menu. (see page 47)

An apparatus with CLASS I construction shall be connected to a mains socket outlet with a protective earthing connection.

AC Power Supply Cord

The Plasma Display is designed to operate on 110 - 127 V AC, 50/60 Hz.

Ensure that the mains plug is easily accessible.

Do not use any power supply cord other than that provided with this unit.

• Doing so may cause ﬁ re or electric shocks.

Securely insert the power cord plug as far as it will go.

• If the plug is not fully inserted, heat may be generated which could cause ﬁ re. If the plug is damaged or the wall socket plate is loose, they should not be used.

Do not handle the power cord plug with wet hands.

• Doing so may cause electric shocks.

Do not do anything that might damage the power cable. When disconnecting the power cable, hold the plug, not the cable.

• Do not make any modiﬁ cations, place heavy objects on, place near hot objects, heat, bend, twist or forcefully pull the power cable. Doing so may cause damage to the power cable which can cause ﬁ re or electric shock. If damage to the cable is suspected, have it repaired at an Authorized Service Center.

If the Plasma Display will not be used for a long period of time, unplug the power cord from the wall outlet.

If problems occur during use

If a problem occurs (such as no picture or no sound), or if smoke or an abnormal odor is detected from the Plasma Display, unplug the power cord immediately.

• Continuous use of the Display under these conditions might cause ﬁ re or permanent damage to the unit. Have the Display evaluated at an Authorized Service Center. Services to the Display by any unauthorized personnel are strongly discouraged due to its high voltage dangerous nature.

If water or foreign objects get inside the Plasma Display, if the Plasma Display is dropped, or if the cabinet becomes damaged, disconnect the power cord plug immediately.

• A short may occur, which could cause ﬁ re. Contact an Authorized Service Center for any repairs that need to be made.

Maintenance

The front of the display panel has been specially treated. Wipe the panel surface gently using only a cleaning cloth or a soft, lint-free cloth.

• If the surface is particularly dirty, wipe with a soft, lint-free cloth which has been soaked in pure water or water in which neutral detergent has been diluted 100 times, and then wipe it evenly with a dry cloth of the same type until the surface is dry.

• Do not scratch or hit the surface of the panel with ﬁ ngernails or other hard objects, otherwise the surface may become damaged. Furthermore, avoid contact with volatile substances such as insect sprays, solvents and thinner, otherwise the quality of the surface may be adversely affected.

If the cabinet becomes dirty, wipe it with a soft, dry cloth.

• If the cabinet is particularly dirty, soak the cloth in water to which a small amount of neutral detergent has been added and then wring the cloth dry. Use this cloth to wipe the cabinet, and then wipe it dry with a dry cloth.

• Do not allow any detergent to come into direct contact with the surface of the Plasma Display. If water droplets get inside the unit, operating problems may result.

• Avoid contact with volatile substances such as insect sprays, solvents and thinner, otherwise the quality of the cabinet surface may be adversely affected or the coating may peel off. Furthermore, do not leave it for long periods in contact with articles made from rubber or PVC.

Page 8

Accessories

Accessories Supplied

Check that you have the Accessories and items shown

Operating Instruction book

TMME289 J0KG00000014

Software CD-ROM × 1

• Panasonic WhiteBoard Software

• Operating Instructions Display Operations Network Operations Electronic Pen Operations

• Software license statements GNU GENERAL PUBLIC LICENSE GNU LESSER GENERAL PUBLIC LICENSE

AC cordClamper × 1

Ferrite core × 2

Use the Ferrite cores to comply with the EMC standard. (refer to “Operating Instructions, Network Operations”)

Remote Control Batteries

Requires two AA batteries.

1. Pull and hold the hook, then open the battery cover.

2. Insert batteries - note correct polarity (+ and -).

Remote Control Transmitter N2QAYB000691

Electronic Pen set

Refer to “Operating Instructions, Electronic Pen Operations”.

3. Replace the cover.

Batteries for the Remote Control Transmitter (AA Size × 2)

“AA” size

Helpful Hint:

For frequent remote control users, replace old batteries with Alkaline batteries for longer life.

Precaution on battery use

Incorrect installation can cause battery leakage and corrosion that will damage the remote control transmitter. Disposal of batteries should be in an environment-friendly manner.

Observe the following precautions:

1. Batteries should always be replaced as a pair. Always use new batteries when replacing the old set.

2. Do not combine a used battery with a new one.

3. Do not mix battery types (example: “Zinc Carbon” with “Alkaline”).

4. Do not attempt to charge, short-circuit, disassemble, heat or burn used batteries.

5. Battery replacement is necessary when the remote control acts sporadically or stops operating the Plasma Display.

6. Do not burn or breakup batteries.

7. Batteries must not be exposed to excessive heat such as sunshine, ﬁ re or the like.

Page 9

Connections

AC cord connection and ﬁ xing, cable ﬁ xing

AC cord ﬁ xing

Unplug the AC cord

Unplug the AC cord pressing the

Plug the AC cord into the display unit.

Plug the AC cord until it clicks.

Note:

Make sure that the AC cord is locked on both the left and right sides.

When using the Wall-hanging bracket (vertical) (for TH-50PB2U) Note:

When using the Wall-hanging bracket (vertical) (TY-WK42PV20), use the holes used on the hole

TH-50PB2U TH-65PB2U

, the cables may be caught by the wall-hanging bracket.

and to secure the cables. If the clamper is

two knobs.

Note:

When disconnecting the AC cord, be absolutely sure to disconnect the AC cord plug at the socket outlet ﬁ rst.

Using the clamper

Secure any excess cables with clamper as required.

Note:

One clamper is supplied with this unit. In case of securing cables at three positions, please purchase it separately.

Attach the clamper

Insert the clamper in a hole.

hole

To remove from the unit:

snaps

Keep pushing both side snaps

Bundle the cables

hooks

Set the tip in the hooks

To loosen:

knob

Keep pushing the knob

Page 10

Connections

Speaker connection

For TH-50PB2U

Please use 6 Ω/8 W speaker.

For TH-65PB2U

Please use 8 Ω/10 W speaker.

Video equipment connection

Ex. TH-65PB2U

SLOT: Terminal board (optional

accessories) insert slot (see page 6)

Note:

The right side slot is for terminal board with 2-slot width. The terminal board with 1-slot width does not function when installed in the right side slot.

AUDIO 1 IN: Audio input terminal shared with VIDEO and COMPONENT/RGB IN. (see page 11)

PEN ADAPTER, MEMORY/(CHARGE), CHARGE:

Refer to “Operating Instructions, Electronic Pen Operations”.

(L)

(R)

While pressing the lever, insert the core wire.

Red

Black

AUDIO 2 IN: Audio input terminal shared with DVI-D IN and PC IN. (see page 12, 13)

(R)

Return the lever.

SERIAL:

Control the Plasma Display by connecting to PC. (see page 14)

(L)

Red

Black

AV IN (VIDEO): Composite Video Input Terminal

(see page 11)

COMPONENT/RGB IN: Component/RGB

Video Input Terminal (see page 11)

Terminals are on the bottom side of the Plasma Display.

DVI-D IN: DVI-D Input Terminal (see page 12) PC IN: PC Input Terminal Connect to video

terminal of PC or equipment with Y, PB(CB) and PR(CR) output. (see page 13)

AV IN (HDMI):

HDMI Input Terminal (see page 12) Connect to video equipment such as VCR or DVD player.

WIRELESS MODULE, LAN:

Refer to “Operating Instructions, Network Operations”.

Page 11

VIDEO and COMPONENT / RGB IN connection

Note:

Additional equipment, cables and adapter plugs shown are not supplied with this set.

RCA-BNC Adapter plug

Stereo mini plug (M3)

AUDIO 1 IN: Shared with VIDEO and

COMPONENT/RGB IN

Notes:

•

Change the “COMPONENT/RGB-IN SELECT” setting in the “SETUP” menu to “COMPONENT” (when COMPONENT signal connection) or “RGB” (when RGB signal connection). (see page 48)

• Signals input to COMPONENT/RGB IN terminals correspond to SYNC ON G or SYNC ON Y.

VIDEO

OUT

AUDIO

OUT

VCR

Connections

RCA-BNC Adapter plug

AUDIO

OUT

DVD Player

Computer RGB Camcorder

, Y , P B , P R

Page 12

Connections

HDMI connection

[Pin assignments and signal names]

Pin No.

Note:

Additional equipment and HDMI cable shown are not supplied with this set.

Signal Name

T.M.D.S Data2+

T.M.D.S Data2

Shield

T.M.D.S Data2-

T.M.D.S Data1+ T.M.D.S Data1

Shield

T.M.D.S Data1-

T.M.D.S Data0+ T.M.D.S Data0

Shield

T.M.D.S Data0-

T.M.D.S Clock+

Pin No.

15 16

18 19

Signal Name

T.M.D.S Clock Shield

T.M.D.S Clock-

CEC

Reserved (N.C. on device)

SCL SDA DDC/CEC

Ground +5V Power Hot Plug Detect

HDMI

AV OUT

DVD player

HDMI cable

DVI-D IN connection

Shared with PC IN.

PC with DVI-D video out

Stereo mini plug (M3)

DVI-video cable (Within 5 m)

DVI-D Input Connector Pin Layouts

Connection port view

Notes:

• Additional equipment and cables shown are not supplied with this set.

• Use the DVI-D cable complying with the DVI standard. Image deterioration may occur depending on the length or the quality of the cable.

Pin No.

Signal Name

T.M.D.S. data 2-

T.M.D.S. data 2+

T.M.D.S. data 2 shield

3 4 5

DDC clock

DDC data

7 8

T.M.D.S. data 1-

T.M.D.S. data 1+

T.M.D.S. data 1 shield

11 12 24

Pin No.

13 14 15 16 17 18 19 20 21 22 23

Signal Name

+5 V DC Ground Hot plug detect T.M.D.S. data 0T.M.D.S. data 0+ T.M.D.S. data 0 shield

T.M.D.S. clock shield T.M.D.S. clock+ T.M.D.S. clock-

Page 13

PC Input Terminals connection

COMPUTER

Connections

Shared with DVI-D IN.

Conversion adapter (if necessary)

RGB

PC cable

Audio

Connect a cable which matches the audio output terminal on the computer.

(Female)

Mini D-sub 15p

(Male)

Stereo mini plug (M3)

Notes:

• With regard to the typical PC input signals that are described in the applicable input signals list (see page 62), adjustment values such as for the standard picture positions and sizes have already been stored in this unit. You can add up to eight PC input signal types that are not included in the list.

• Computer signals which can be input are those with a horizontal scanning frequency of 15 to 110 kHz and vertical scanning frequency of 48 to 120 Hz. (However, the image will not be displayed properly if the signals exceed 1,200 lines.)

• The display resolution is a maximum of 1,440 × 1,080 dots when the aspect mode is set to “4:3”, and 1,920 × 1,080 dots when the aspect mode is set to “FULL”. If the display resolution exceeds these maximums, it may not be possible to show ﬁ ne detail with sufﬁ cient clarity.

• The PC input terminals are DDC2B-compatible. If the computer being connected is not DDC2B-compatible, you will need to make setting changes to the computer at the time of connection.

• Some PC models cannot be connected to the set.

• There is no need to use an adapter for computers with DOS/V compatible Mini D-sub 15P terminal.

• The computer shown in the illustration is for example purposes only.

• Additional equipment and cables shown are not supplied with this set.

• Do not set the horizontal and vertical scanning frequencies for PC signals which are above or below the speciﬁ ed frequency range.

• Component Input is possible with the pin 1, 2, 3 of the Mini D-sub 15P Connector.

• Change the “COMPONENT/RGB-IN SELECT” setting in the “SETUP” menu to “COMPONENT”

(when COMPONENT signal connection) or “RGB” (when RGB signal connection). (see page 48)

Signal Names for Mini D-sub 15P Connector

Pin No.

15 14 13 12 11

Pin Layout for PC Input Terminal

67839

NC (not connected)

Signal Name

R (PR/CR)

G (Y)

B (PB/CB)

GND (Ground)

Pin No.

Signal Name

GND (Ground)

+5 V DC

GND (Ground)

Pin No.

Signal Name

NC (not connected)

SDA

HD/SYNC

SCL

Page 14

Connections

SERIAL Terminals connection

The SERIAL terminal is used when the Plasma Display is controlled by a computer. Note: To use serial control for this unit, make sure to set the “CONTROL I/F SELECT” in the “NETWORK SETUP” menu

to “RS-232C”. (refer to “Operating Instructions, Network Operations”)

COMPUTER

(Male)

6789

13452

RS-232C Straight cable

D-sub 9p

(Female)

Notes:

• Use the RS-232C straight cable to connect the computer to the Plasma Display.

• The computer shown is for example purposes only.

• Additional equipment and cables shown are not supplied with this set.

The SERIAL terminal conforms to the RS-232C interface speciﬁ cation, so that the Plasma Display can be controlled by a computer which is connected to this terminal. The computer will require software which allows the sending and receiving of control data which satisﬁ es the conditions given below. Use a computer application such as programming language software. Refer to the documentation for the computer application for details.

Communication parameters

Signal level RS-232C compliant

Synchronization method Asynchronous

Baud rate 9600 bps

Parity None

Character length 8 bits

Stop bit 1 bit

Flow control

None

Basic format for control data

The transmission of control data from the computer starts with a STX signal, followed by the command, the parameters, and lastly an ETX signal in that order. If there are no parameters, then the parameter signal does not need to be sent.

STX C1 C2 C3 P1 P2 P3 P4: P5 ETX

Start (02h)

Colon Parameter(s) 3-character command (3 bytes)

(1 - 5 bytes)

End (03h)

Notes:

• If multiple commands are transmitted, be sure to wait for the response for the ﬁ rst command to come from this unit before sending the next command.

• If an incorrect command is sent by mistake, this unit will send an “ER401” command back to the computer.

• S1A and S1B of Command IMS are available only when a dual input terminal board is attached.

• Consult an Authorized Service Center for detail instructions on command usage.

Signal names for D-sub 9P connector

Pin No.

2 3

•

7 8

•

These signal names are those of computer speciﬁ cations.

Command

Command Parameter Control details PON None Power ON POF None Power OFF AVL ** Volume 00 - 63 AMT 0 Audio MUTE OFF

1 Audio MUTE ON

IMS None

SL1 S1A S1B VD1 YP1

HM1 DV1 PC1 NW1 WB1

DAM None

ZOOM FULL JUST NORM SJST SNOM SFUL ZOM2

With the power off, this display responds to PON command only.

Pin layout for SERIAL Terminal

Details

R X D T X D

GND

Non use

(Shorted in this set)

Input select (toggle) SLOT input (SLOT INPUT) SLOT input (SLOT INPUT A) SLOT input (SLOT INPUT B) VIDEO input (VIDEO) COMPONENT/RGB IN input (COMPONENT) HDMI input (HDMI) DVI-D IN input (DVI) PC IN input (PC) Network input (NETWORK) WhiteBoard input (WHITEBOARD)

Screen mode select (toggle) ZOOM (For Video/SD/PC signal) FULL JUST (For Video/SD signal) 4:3 (For Video/SD/PC signal) JUST (For HD signal) 4:3 (For HD signal) H-FILL (For HD signal) ZOOM (For HD signal)

Page 15

Power ON / OFF

Connecting the AC cord plug to the Plasma Display.

Connecting the plug to the Wall Outlet.

Note:

When disconnecting the AC cord, be absolutely sure to disconnect the AC cord plug at the socket outlet ﬁ rst.

Press the Power switch on the Plasma Display to turn the set on: Power-On.

Power Indicator: Green

[Starting up the network]

It takes some time for the network to start up just after the power is turned on. During that time, “NETWORK SETUP” in the “SETUP” menu is grayed out and cannot be set.

Press the button on the remote control to turn the Plasma Display off.

Power Indicator: Red (standby)

Press the button on the remote control to turn the Plasma Display on.

Power Indicator: Green

Turn the power to the Plasma Display off by pressing the switch on the unit, when the Plasma Display is on or in standby mode.

Note:

During operation of the power management function, the power indicator turns orange in the power off state.

INPUT MENU ENTER/+/VOL-/

Power Indicator

Remote Control Sensor

Page 16

Power ON / OFF

When ﬁ rst switching on the unit

Following screen will be displayed when the unit is turned on for the ﬁ rst time. Select the items with the remote control. Unit buttons are invalid.

OSD LANGUAGE DAY/TIME SETUP

OSD LANGUAGE

English (UK)

Deutsch Français

Italiano

Español

ENGLISH (US)

Русский

SET SELECT

Select the

language.

Set.

DISPLAY ORIENTATION

VIEWING ENVIRONMENT

PUBLIC SPACE

HOME

Select viewing mode.

Set.

PUBLIC SPACE:

Suitable for commercial applications.

HOME:

Suitable for home environment.

DAY/TIME SETUP

SET DAY TIME

TIME MON 99:99

MON

99:99

Select “DAY” or “TIME”.

Setup “DAY” or “TIME”.

Select “SET”.

Set.

DISPLAY ORIENTATION

LANDSCAPE

PORTRAIT

For vertical installation,

select “PORTRAIT”.

Set.

Notes:

• Once the items are set, the screens won't be displayed when switching on the unit next time.

• After the setting, the items can be changed in the following menus. OSD LANGUAGE (see page 47) DAY/TIME SETUP (see page 35) DISPLAY ORIENTATION (see page 47)

Power ON message

The following message may be displayed when turning the unit power ON:

Easy WhiteBoard Startup screen

Easy WhiteBoard

NOW LOADING…

When the power is turned ON with the Input switch of the WHITEBOARD, the built-in WhiteBoard software “Easy WhiteBoard” starts up.

No activity power off Precautions

’NO ACTIVITY POWER OFF’ IS ENABLED.

If “NO ACTIVITY POWER OFF” in SETUP menu is set to “ENABLE”, a warning message is displayed every time the power is turned ON. (see page 47)

Power Management Information

LAST TURN OFF DUE TO 'POWER MANAGEMENT'.

If “PC POWER MANAGEMENT” or “DVI-D POWER MANAGEMENT” is functioned, an information message is displayed every time the power is turned ON. (see page 44) These message displays can be set with the following menu: Options menu Power On Message (No activity power off) (see page 54) Power On Message (Power Management) (see page 54)

Page 17

INPUT MENU ENTER/+/VOL-/

Selecting the input signal

Press to select the input signal to be played back from the equipment which has been connected to the Plasma Display.

Input signals will change as follows:

PC COMPONENT* DVINETWORK WHITEBOARD HDMIVIDEO

PC: PC input terminal in PC IN. NETWORK: Network input terminal in LAN or WIRELESS MODULE. WHITEBOARD: WhiteBoard mode.

This mode can be selected when the “WHITEBOARD

FUNCTION” is “ON”. (see page 36) VIDEO: Video input terminal in AV IN (VIDEO). COMPONENT*: Component or RGB input terminal in COMPONENT/RGB IN. HDMI: HDMI input terminal in AV IN (HDMI). DVI: DVI input terminal in DVI-D IN. * “COMPONENT” may be displayed as “RGB” depending on the setting of

“COMPONENT/RGB-IN SELECT”. (see page 48)

When an optional Terminal Board is installed:

PC VIDEO HDMI DVINETWORK WHITEBOARD COMPONENTSLOT INPUT

INPUT MENU ENTER/+/VOL-/

SLOT INPUT: Input terminal in Terminal Board

Note:

When a Terminal Board incompatible with the Plasma Display is installed, “NON-COMPATIBLE FUNCTION BOARD” is displayed.

When a Terminal Board with dual input terminals is installed:

WHITEBOARD

SLOT INPUT A, SLOT INPUT B: Dual input terminal in Terminal Board.

Notes:

• Selecting is also possible by pressing the INPUT button on the unit.

• Outputs the sound as set in “Audio input select” in the Options menu.(see page 57)

• Select to match the signals from the source connected to the component/RGB input terminals. (see page 48)

• Image retention (image lag) may occur on the plasma display panel when a still picture is kept on the panel for an extended period. The function that darkens the screen slightly is activated to prevent image retention (see page 61), but this function is not the perfect solution to image retention.

VIDEO HDMI DVINETWORK COMPONENTSLOT INPUT A SLOT INPUT BPC

Page 18

Basic Controls

INPUT MENU ENTER/

/VOL

Main Unit

Brightness Sensor

Detects the brightness in the viewing environment

Remote control sensor

Main Power On / Off Switch

Power Indicator

The Power Indicator will light.

• Power-OFF ....Indicator not illuminated (The unit will

still consume some power as long as the power cord is still inserted into the wall outlet.)

• Standby ......... Red

Orange (When “Slot power” is set to

“On” and Terminal Board is installed. See page 54) Orange (Depending on the type of the function board installed, when the power is supplied to the slot) Orange (When “CONTROL I/F SELECT” is set to “LAN” or “WEB CONTROL” is set to “ON”. Refer to “Operating Instructions, Network Operations”.) Orange (When “QUICK WHITEBOARD LAUNCH” is set to “ON”. See page 36) Orange (When “STANDBY PEN CHARGING MODE” is set to “ON” or “ON[4hrs]”. See page 37)

• Power-ON ...... Green

• PC POWER MANAGEMENT (DPMS)

........................ Orange (With PC input signal.

See page 44)

• DVI-D POWER MANAGEMENT

........................Orange (With DVI input signal. See page 44)

Volume Adjustment

Volume Up “+” Down “–” When the menu screen is displayed: “+” :

press to move the cursor up

“–” :

press to move the cursor down

(see page 23)

Enter / Aspect button

(see page 20, 23)

MENU Screen ON / OFF

Each time the MENU button is pressed, the menu screen will switch. (see page 23)

Normal Viewing PICTURE SETUP

SOUND POS./SIZE

INPUT button (Input signal selection)

(see page 17)

Page 19

Remote Control Transmitter

ACTION button

Press to make selections.

ASPECT button

Press to adjust the aspect. (see page 20)

Standby (ON / OFF) button

The Plasma Display must ﬁ rst be plugged into the wall outlet and turned on at the power switch (see page 15). Press this button to turn the Plasma Display On, from Standby mode. Press it again to turn the Plasma Display Off to Standby mode.

POS. /SIZE button

(see page 24)

Basic Controls

OFF TIMER button

The Plasma Display can be preset to switch to standby after a ﬁ xed period. The setting changes to 30 minutes, 60 minutes, 90 minutes and 0 minutes (off timer cancelled) each time the button is pressed.

30 MIN 60 MIN

0 MIN(Cancel)

When three minutes remain, “OFF TIMER 3 MIN” will ﬂ ash. The off timer is cancelled if a power interruption occurs.

AUTO SETUP button

Automatically adjusts the position/ size of the screen. (see page 24)

SETUP button (see page 34)

90 MIN

PICTURE button (see page 27)

Sound mute On / Off Press this button to mute the sound. Press again to reactivate sound. Sound is also reactivated when power is turned off or volume level is changed.

N button (see page 26, 27, 28, 32)

POSITION buttons

INPUT button

Press to select input signal sequentially. (see page 17)

ECO MODE (ECO)

Press to change the ECO MODE setup status. (see page 44)

FUNCTION buttons (FUNCTION)

(see page 46)

SOUND button (see page 32)

Volume Adjustment

Press the Volume Up “+” or Down “–” button to increase or decrease the sound volume level.

R button (see page 23) Press the R button to return to previous menu screen.

RECALL button

Press the “RECALL” button to display the current system status.

Input label

1 2

Aspect mode (see page 20)

Audio input (see page 57)

Proﬁ le name (see page 30) NANODRIFT SAVER operating (see page 42)

Touch Pen mode ON/OFF

(see page 36)

Off timer

The off timer indicator is

displayed only when the off

timer has been set.

Clock display (see page 54)

4:3

♪ COMPONENT

MEMORY NAME: MEMORY2

NANODRIFT

TOUCH-PEN

10:00

OFF TIMER

90MIN

Digital Zoom (see page 21)

Page 20

ASPECT Controls

INPUT MENU ENTER/ +/ VOL -/

The Plasma Display will allow you to enjoy viewing the picture at its maximum size, including wide screen cinema format picture.

Note:

Be aware that if you put the display in a public place for commercial purposes or a public showing and then use the aspect mode select function to shrink or expand the picture, you may be violating the copyright under copyright law. It is prohibited to show or alter the copyrighted materials of other people for commercial purposes without the prior permission of the copyright holder.

Press repeatedly to move through the aspect options: For details about the aspect mode, please see “List of Aspect Modes” (page 61).

[from the unit]

The aspect mode changes each time the ENTER button is pressed.

For VIDEO (S VIDEO) signal input:

4:3 ZOOM JUSTFULL

For PC signal input:

4:3 ZOOM FULL 4:3 ZOOM JUSTFULL

For HD signal input [1125 (1080) / 60i • 50i • 60p • 50p • 24p • 25p • 30p • 24sF, 1250 (1080) / 50i, 750 (720) / 60p • 50p]:

4:3 H-FILL ZOOM FULL JUST

[For Touch Pen mode]

The aspect is ﬁ xed as “FULL” and you cannot switch.

Notes:

• The aspect mode is memorized separately for each input terminal.

• Do not allow the picture to be displayed in 4:3 mode for an extended period, as this can cause a permanent image retention to remain on the Plasma Display Panel.

All Aspect mode

Set “All Aspect” to “On” in Options menu to enable the extended aspect mode (page 54). When All Aspect mode, the aspect mode of pictures is switched as follows. For details about the aspect mode, please see “List of Aspect Modes” (page 61).

For VIDEO (S VIDEO) signal input:

4:3 Zoom1 16:9 JustZoom2 Zoom3 14:9

For PC signal input:

4:3 Zoom 16:9

For SD signal input (525 (480) / 60i • 60p, 625 (575) / 50i • 50p):

For SD signal input (525 (480) / 60i

For HD signal input [1125 (1080) / 60i • 50i • 60p • 50p • 24p • 25p • 30p • 24sF, 1250 (1080) / 50i, 750 (720) / 60p • 50p]:

•

60p, 625 (575) / 50i

4:3 Zoom1 16:9 JustZoom2 Zoom3 14:9

4:3 Full Zoom1 16:9 Just1Zoom2 Zoom3 14:9 Just2 4:3 (1) 4:3 (2)

•

50p):

Page 21

Digital Zoom

INPUT MENU ENTER/ +/ VOL -/

This displays an enlargement of the designated part of the displayed image.

Display the operation guide.

Press to access Digital Zoom. The operation guide will be displayed.

During Digital Zoom, only the following buttons can be operated.

[Remote control]

Select the area of the image to be enlarged.

Press on the enlargement location to select.

OFF TIMER button

VOL button

MUTE button

POSITION / ACTION button

The cursor will move.

EXIT

[Unit]

VOL button

Notes:

• When power goes OFF (including “Off Timer” operation), Digital Zoom terminates.

• The Digital Zoom function cannot be selected while in the following operation state: When WHITEBOARD input. When two screen display. When SCREENSAVER (except for NEGATIVE IMAGE) is running. (see page 39)

• While Digital Zoom is in operation, “Adjusting POS./SIZE” cannot be used.

Select the magniﬁ cation required for the enlarged display.

Each time this is pressed, the magniﬁ cation factor changes. This is shown in the image being displayed.

Return to normal display (quit Digital Zoom).

Touch Pen mode during Digital Zoom

Press to exit from the Digital Zoom.

The electronic pen cannot be used while the image is enlarged with Digital Zoom during Touch Pen mode.

The electronic pen can be used when Digital Zoom is cancelled.

s1

s2

s3

EXIT

s4

Page 22

MULTI PIP

You can display two pictures, such as a video image and computer image, in a two-screen display.

Notes:

• If “Input lock” in Options menu is set to other than “Off”, two screen display isn’t available (see page 53).

• 2k1k signals that are received with the Dual Link HD-SDI Terminal Board (TY-FB11DHD) cannot be displayed in twoscreen display.

MULTI PIP SETTINGS

Set the functions and mode for two-screen display in “MULTI PIP SETTINGS” in the SETUP menu. (see page 38)

PIP MODE

There are two modes for two screen display:

PIC IN PIC

Displays two input images combined.

SLOT INPUT

PIC IN WHITEBOARD

Displays the built-in WhiteBoard with the other input image combined.

WHITEBOARD

Note:

SD signal is displayed in 4:3 mode on the sub screen.

Main screen input Sub screen input

Main screen is ﬁ xed to WHITEBOARD. Inputs supported for the sub screen: HDMI/DVI/COMPONENT/PC/VIDEO

Note:

SLOT INPUT and NETWORK cannot be displayed on the sub screen.

The following three system inputs are combined:

A SLOT INPUT/NETWORK B HDMI/DVI/COMPONENT/PC C VIDEO Note:

Two screen display cannot be displayed with the same system inputs such as HDMI―DVI combined.

Using Two Screen Display

Set “MULTI PIP” in “MULTI PIP SETTINGS” to “ON” (see page 38).

Two screen display appears.

Using the FUNCTION button

ON/OFF of “MULTI PIP” switches.

“MULTI PIP SETTINGS” menu appears.

Note:

Please use the "FUNCTION BUTTON SETTINGS" to set the FUNCTION button (see page 46).

Switching Sub Screen Position Changing the Size of Sub Screen

Press to switch the sub screen position. Press to change the size of the sub screen.

Note:

Alternatively, “SUB SCREEN SIZE” and “SUB SCREEN POSITION” in “MULTI PIP SETTINGS” can be used for the same operation (see page 38).

Page 23

On-Screen Menu Displays

Remote Control Unit

Display the menu screen.

Select the item.


NORMALIZE

PICTURE MENU PICTURE BRIGHTNESS COLOR TINT SHARPNESS COLOR TEMP

ADVANCED SETTINGS

MEMORY SAVE MEMORY LOAD

MEMORY EDIT

Set.

NORMAL

STANDARD

0 0 0 5

NORMAL

( Example:

PICTURE menu)

Press to select. (Example: PICTURE menu)

Select.

Set.

Press several times.

Each time the MENU button is pressed, the menu screen will switch.

Normal Viewing PICTURE

SOUND POS./SIZE

SETUP

Select.

Press.

Set.

Press.

Exit the menu.

Press several times.

Press.

Press

to return to the previous menu.

Menu display list

Note: Menu that cannot be adjusted is grayout. Adjustable menu changes depending on signal, input and menu setting.

PICTURE menu SETUP menu POS./SIZE menu SOUND menu


NORMALIZE

PICTURE MENU PICTURE BRIGHTNESS COLOR TINT SHARPNESS COLOR TEMP

ADVANCED SETTINGS

NORMAL

MEMORY SAVE

MEMORY LOAD

MEMORY EDIT

see page 27-31

STANDARD

0 0 0 5

NORMAL

SETUP

TOUCH-PEN SETTINGS

MULTI PIP SETTINGS

SIGNAL

SCREENSAVER

EXTENDED LIFE SETTINGS

ECO MODE SETTINGS

INPUT LABEL FUNCTION BUTTON SETTINGS COMPONENT/RGB-IN SELECT

NO ACTIVITY POWER OFF MENU DISPLAY DURATION OSD BRIGHTNESS OSD LANGUAGE ENGLISH (US

ON/OFF TIMER SETUP

DAY/TIME SETUP

NETWORK SETUP

DISPLAY ORIENTATION

RGB

DISABLE

30 S

LANDSCAPE

1/2

2/2SETUP

POS./SIZE

H-POS H-SIZE V-POS V-SIZE

NORMAL

0 0 0 0 0 0 0

OFF

NORMALIZE

AUTO SETUP

DOT CLOCK CLOCK PHASE CLAMP POSITION 1:1 PIXEL MODE

see page 24-26

)

SOUND

NORMALIZE

SPEAKER AUDIO MENU BASS MID TREBLE BALANCE SURROUND AUDIO OUT (PIP)

LEFT CHANNEL RIGHT CHANNEL SOUND OUT LEVEL METER

NORMAL

SDI SOUND OUTPUT

see page 32-33

INTERNAL STANDARD 0 0 0 0 0

OFF

MAIN

CHANNEL 1 CHANNEL 1

OFF OFF

1/2

2/2

see page 34-51

Page 24

Adjusting POS./SIZE

Press to display the POS./SIZE menu.

Press to select the menu to adjust.

Press to adjust the menu.

POS./SIZE

NORMALIZE

AUTO SETUP

DOT CLOCK CLOCK PHASE CLAMP POSITION 1:1 PIXEL MODE

NORMAL

H-POS H-SIZE V-POS V-SIZE

0 0 0 0 0 0 0

OFF

Note:

Unadjustable items are

Press to exit from adjust mode.

grayed out. Adjustable items differ depending on the input signal and the display mode.

Notes:

• POS./SIZE cannot be adjusted with two screen display.

• Adjustment details are memorized separately for different input signal formats. (Adjustments for component signals are memorized for 525 (480) / 60i · 60p, 625 (575) / 50i · 50p, 1125 (1080) / 60i · 50i · 60p · 50p · 24p · 25p · 30p · 24sF, 1250 (1080) / 50i, 750 (720) / 60p · 50p each, and RGB/PC/Digital signals are memorized for each frequency.)

• If a “Cue” or “Rew” signal from a VCR or DVD player is received, the picture position will shift up or down. This picture position movement cannot be controlled by the POS./SIZE function.

AUTO SETUP

When inputting a PC signal as an example, “H-POS/V-POS”, “H-SIZE/V-SIZE”, “DOT CLOCK” and “CLOCK PHASE” are automatically corrected. This setting is enabled under the following conditions:

• When inputting an analog signal (Component/PC): This setting is enabled if “COMPONENT/RGB-IN SELECT” (see page 48) in SETUP menu is “RGB”.

• When inputting a digital signal (HDMI/DVI): A PC format signal enables this setting. When the signal is not PC format, this setting is enabled only if “OVER SCAN” (see page 25) is “OFF” or “1:1 PIXEL MODE” (see page 26) is “ON.” H-SIZE/V-SIZE is not automatically adjusted.

This setting will be invalid and will not work under the following conditions:

• When NETWORK input is selected.

• When VIDEO signal input

• During two screen or Digital Zoom.

• Aspect is set to “JUST”

• “Display size” in the Options menu (see page 53) is set to “On”

Using Remote Control

When on the remote control is pressed, “AUTO SETUP” will be executed.

When AUTO SETUP does not work, “INVALID” is displayed.

Auto mode

When the “Auto Setup“ is set to “Auto” in the Options menu (see page 54), automatic position adjustment starts

• When the display power is turned ON.

• When the input signal is switched.

Page 25

Adjusting POS./SIZE

Notes:

• If the dot clock frequency of an analog signal is 162 MHz or higher, “DOT CLOCK” and “CLOCK PHASE” cannot be automatically corrected.

• When digital signal input, DOT CLOCK and CLOCK PHASE cannot be made.

• AUTO SETUP may not work when a cropped or dark image is input. In such case, switch to a bright image with borders and other objects are clearly shown, and then try auto setup again.

• Depending on the signal, out of alignment may occur after AUTO SETUP. Carry out ﬁ ne tuning for the position/size as required.

• If AUTO SETUP cannot set properly for vertical frequency 60Hz XGA signal (1024×768@60Hz, 1280×768@60Hz, and 1366×768@60Hz), pre-selecting the individual signal in “XGA MODE” (see page

49) may results in correct AUTO SETUP.

• AUTO SETUP does not work well when a signal such as additional information is superimposed out of valid image period or intervals between synchronizing and image signals are short, or for image signal with tri-level synchronizing signal added.

• If AUTO SETUP cannot adjust correctly, select “NORMALIZE” once and press ACTION ( POS./SIZE manually.

H-POS Adjust the horizontal position. V-POS Adjust the vertical position.

) then adjust

H-SIZE Adjust the horizontal size. V-SIZE Adjust the vertical size.

DOT CLOCK

CLOCK PHASE

OVER SCAN

(During Component/PC input signal)

Periodic striped pattern interference (noise) may occur when a striped pattern is displayed. If this happens, adjust so that any such noise is minimized.

(During Component/PC input signal)

Eliminate the ﬂ ickering and distortion.

Turn image over scan ON/OFF. Conﬁ gurable signals are as follows: 525i, 525p, 625i, 625p, 750/60p, 750/50p (Component Video, RGB, DVI, SDI, HDMI)

ON OFF

Notes:

• When “OFF” is set, “H-SIZE” and “V-SIZE” cannot be adjusted.

• When the “Display size” is set to “On” in the Options menu, this setting will be invalid. (see page 53)

Page 26

Adjusting POS./SIZE

CLAMP POSITION

1:1 PIXEL MODE Adjusts the display size when 1125i, 1125p or 1250i signal is input.

1:1 PIXEL MODE (2k1k)

(For 2k1k signals)

(During Component/PC input signal)

Adjusts the clamp position when black parts of the image have no detail due to underexposure or are tinged with green.

Optimum value for Clamp Position adjustment

When black parts have no detail due to underexposure (blackout) →Value that causes least blackout is the optimum. When black parts are tinged with green →Value that cancels the greenishness without causing blackout is the optimum.

Notes:

• Select ON when you would like to replay 1920 × 1080 input signal.

• Applicable input signal; 1125 (1080) / 50i · 60i · 24sF · 24p · 25p · 30p · 50p · 60p, 1250 (1080) / 50i

• Select OFF when ﬂ ickering is shown around the image.

• H-SIZE and V-SIZE cannot be adjusted when ON is selected.

OFF ON

When the input signal is a 2k1k signal (2048×1080 / 24p, 2048×1080 / 24sF), the display size is adjusted as follows.

OFF ON (LEFT) ON (CENTER) ON (RIGHT)

Note:

2k1k signals can only be received when the Dual Link HD-SDI Terminal Board (TY-FB11DHD) is installed.

Helpful Hint ( /

NORMALIZE

Normalization)

While the POS./SIZE display is active, if either the N button on the remote control is pressed at any time or the ACTION ( ) button is pressed during “NORMALIZE”, then all adjustment values are returned to the factory settings.

Page 27

PICTURE Adjustments

Select to adjust each item.

Press to display the PICTURE menu.

Press to select the menu to adjust.

Select the desired level by looking at the picture behind the menu.

Note:

Menu that cannot be adjusted is grayout. Adjustable menu changes depending on signal, input and menu setting.


NORMALIZE

PICTURE MENU PICTURE BRIGHTNESS COLOR TINT SHARPNESS COLOR TEMP

ADVANCED SETTINGS

NORMAL

STANDARD

0 0 0 5

NORMAL

Press to enter Advanced Settings.

ADVANCED SETTINGS Enables ﬁ ne picture adjustment at a professional level (see next page).

ADVANCED SETTINGS

NORMALIZE

BLACK EXTENSION INPUT LEVEL

GAMMA W/B HIGH R W/B HIGH G W/B HIGH B W/B LOW R W/B LOW G W/B LOW B

NORMAL

0 0

2.2 0 0 0 0 0 0

Press the left or right button to switch between modes.

DYNAMIC CINEMA

STANDARD

MONITOR

STANDARD

For viewing in standard (evening lighting) environments. This menu selects the normal levels of BRIGHTNESS and PICTURE.

DYNAMIC

For viewing in brighter environments. This menu selects higher than normal levels of BRIGHTNESS and PICTURE.

CINEMA

For use in viewing tone-focused pictures with brightness reduced.

MONITOR

For use when creating broadcast or movie content. With this picture, even if the overall average picture level (APL) changes, the brightness of areas with the same signal level does not change.

PICTURE MENU during Touch Pen mode

Only “STANDARD” or “DYNAMIC” can be selected in PICTURE MENU during Touch Pen mode.

Notes:

● When “MONITOR” is selected in PICTURE MENU, the following menu items cannot be set.

EXTENDED LIFE SETTINGS: PEAK LIMIT (see page 42)

● If you would like to change the picture and color of the selected PICTURE menu to something else, adjust using the items in the PICTURE menu. (see next page)

Press the left or right button to switch between modes.

NORMAL (9300K) COOL (11500K) WARM (6500K)

Helpful Hint ( /

NORMALIZE

Normalization)

While the “PICTURE” menu is displayed, if either the N button on the remote control is pressed at any time or the ACTION ( ) button is pressed during “NORMALIZE”, then all adjustment values are returned to the factory settings.

Page 28

PICTURE Adjustments

Item Effect Adjustments


BRIGHTNESS

COLOR

TINT

SHARPNESS

Less More

Darker Brighter

Less More

Reddish Greenish

Less More

Adjusts the proper picture contrast.

Adjusts for easier viewing of dark pictures such as night scenes and black hair.

Adjusts color saturation.

Adjusts for natural ﬂ esh tones.

Adjusts picture sharpness.

ADVANCED SETTINGS

Item Effect Details

BLACK

EXTENSION

INPUT

LEVEL

GAMMA

Less More

Down Up

Adjusts the dark shades of the image in gradation.

Adjustment of parts which are extremely bright and hard to see.

S CURVE 2.0 2.2 2.4 2.6

Notes:

•

You can change the level of each function (PICTURE, BRIGHTNESS, COLOR, TINT, SHARPNESS) for each PICTURE MENU.

•

The setting details for STANDARD, DYNAMIC, CINEMA and MONITOR respectively are memorized separately for each input terminal.

•

In PICTURE, there is not a noticeable change even when contrast is increased with a bright picture or reduced with a dark picture.

W/B HIGH R

W/B HIGH G

W/B HIGH B

W/B LOW R

W/B LOW G

W/B LOW B

Notes:

• ADVANCED SETTINGS cannot be adjusted with two screen display.

• Carry out “W/B” adjustment as follows.

Adjust the white balance of the bright sections using the “W/B HIGH R” , “W/B HIGH G” and “W/B HIGH B” settings.

2. Adjust the white balance of the dark sections using the “W/B LOW R” , “W/B LOW G” and “W/B LOW B” settings.

3. Repeat steps 1 and 2 to adjust.

Steps 1 and 2 affect each other’s settings, so repeat each step in turn to make the adjustment.

• The adjustment values are memorized separately for each input terminal.

• The adjustment range values should be used as an adjustment reference.

Less More

Adjusts the white balance for light red areas.

Adjusts the white balance for light green areas.

Adjusts the white balance for light blue areas.

Adjusts the white balance for dark red areas.

Adjusts the white balance for dark green areas.

Adjusts the white balance for dark blue areas.

Helpful Hint ( /

On the remote control unit, while the “ADVANCED SETTINGS” menu is displayed, if either the N button is pressed at any time or the ACTION ( ) button is pressed during “NORMALIZE”, then all adjustment values are returned to the factory settings.

NORMALIZE

Normalization)

Page 29

Picture Proﬁ les

Up to 8 combinations of picture adjustment values (in the PICTURE menu and ADVANCED SETTINGS) can be stored in the display memory as proﬁ les and applied as needed, for a convenient way to enjoy your preferred picture settings.


NORMALIZE

PICTURE MENU PICTURE BRIGHTNESS COLOR TINT SHARPNESS COLOR TEMP

ADVANCED SETTINGS

NORMAL

CINEMA

0 0 0 3

NORMAL

MEMORY SAVE MEMORY LOAD

MEMORY EDIT

Save proﬁ les (page 30)

Load proﬁ les (page 31)

Edit proﬁ les (page 31)

Edit the proﬁ le

Delete or rename the proﬁ le

MY PICTURE MEMORY2 MEMORY3 MEMORY4

MEMORY8

Load the proﬁ le


NORMALIZE

PICTURE MENU PICTURE BRIGHTNESS COLOR TINT SHARPNESS COLOR TEMP

ADVANCED SETTINGS

Save proﬁ les

MEMORY1

MEMORY2 MEMORY3 MEMORY4

MEMORY8

Custom picture Original picture

NORMAL

CINEMA

0 0 0 5

NORMAL

Save the picture adjustment values in the MEMORY1 proﬁ le

Apply the MEMORY1 proﬁ le


NORMALIZE

PICTURE MENU PICTURE BRIGHTNESS COLOR TINT SHARPNESS COLOR TEMP

ADVANCED SETTINGS

NORMAL

STANDARD 0 0 0 0 0

NORMAL


NORMALIZE

PICTURE MENU PICTURE BRIGHTNESS COLOR TINT SHARPNESS COLOR TEMP

ADVANCED SETTINGS

NORMAL

CINEMA

0 0 0 5

NORMAL

Page 30

Picture Proﬁ les

Saving proﬁ les

Follow these steps to save picture adjustment values as proﬁ les.

Note:

When the settings are locked in “EXTENDED LIFE SETTINGS”, proﬁ les cannot be saved.

Specify the picture quality in the PICTURE menu and

ADVANCED SETTINGS. (see page 27, 28)

In the PICTURE menu, select “MEMORY SAVE”.

MEMORY SAVE

MEMORY LOAD

MEMORY EDIT

Select a proﬁ le name for saving the picture adjustment

values.

MEMORY SAVE

[

]

MEMORY1

[

]

MEMORY2

[

]

MEMORY3

[

]

MEMORY4

“∗” appears for a proﬁ le in which the picture adjustments have already been saved.

Select “OK”.

MEMORY SAVE

SAVE THE ADJUSTED VALUE IN ”MEMORY1”

CANCEL

select

access

select

set

select

set

Enter a name for the proﬁ le.

[Entering proﬁ le names]

Proﬁ le names can be up to 40 characters. To enter text, select characters in the on-screen keyboard. Edit the default profile name in the text box as desired.

MEMORY NAME INPUT

BCDEFGH I JKLMALL DELETE

A N O P Q R S T U V W X Y Z DELETE abcde fgh i j k lm nopq rs tuvwxyz 0123456789 !”#$%&’ +–/=? _` |~<>() [ ]{ } ,

MEMORY1

█

SPACE

@\ ˆ

.;:

CANCEL

Example: Specifying “MY PICTURE”

Select “ALL DELETE”.

MEMORY1

█

All text is deleted. To delete individual characters, select “DELETE”.

Select “M”.

█

Repeat this process to enter the next character.

Select “Y”.

█

Select “SPACE”.

█

select

set

When you ﬁ nished entering the proﬁ le name, select

“OK”. To cancel saving the proﬁ le, select “CANCEL”.

MEMORY NAME INPUT

B C D E F G H I J K L M ALL DELETE

A N O P Q R S T U V W X Y Z DELETE abcde fgh i j k lm nopq rs tuvwxyz 0123456789 !”#$%&’ +–/=? _` |~<>() [ ]{ } ,

MY PICTURE

█

SPACE

@\ ˆ

.;:

CANCEL

select

set

Page 31

Picture Proﬁ les

Loading proﬁ les

Load proﬁ les and apply the picture adjustment values to the display as follows.

Notes:

• Loaded proﬁ les are stored in memory according to the selected input interface. (see page 17)

• When the settings are locked in “EXTENDED LIFE SETTINGS”, proﬁ les cannot be loaded.

In the PICTURE menu, select “MEMORY LOAD”.

MEMORY SAVE MEMORY LOAD

MEMORY EDIT

When

proﬁ le

is being loaded,

proﬁ le

name is displayed.

select

access

FULL

MEMORY NAME: MEMORY2

NANODRIFT

Select the proﬁ le to load.

MEMORY LOAD

[

]

MEMORY1

[

]

MEMORY2

[

]

MEMORY3

[

]

MEMORY4

While in Touch Pen mode, a proﬁ le(s), whose “PICTURE MENU” is set to “CINEMA” or “MONITOR”, is grayed out and cannot be selected.

Editing proﬁ les

Delete or rename proﬁ les as follows.

In the PICTURE menu, select “MEMORY EDIT”.

MEMORY SAVE MEMORY LOAD

MEMORY EDIT

select

access

In the PICTURE menu, select “MEMORY EDIT”.

MEMORY SAVE MEMORY LOAD

MEMORY EDIT

select

set

select

access

Select “MEMORY DELETE”.

MEMORY EDIT

MEMORY DELETE

MEMORY NAME CHANGE

Select the proﬁ le to delete.

To delete all proﬁ les, select “ALL DELETE”.

MEMORY DELETE

[

]

MEMORY1

[

]

MEMORY2

[

]

MEMORY3

[

]

MEMORY4 ALL DELETE

Select “OK”.

MEMORY DELETE

DELETE THE ”MEMORY1” DATA.

CANCEL

select

set

select

set

select

set

Select “MEMORY NAME CHANGE”.

MEMORY EDIT

MEMORY DELETE

MEMORY NAME CHANGE

Select the proﬁ le to rename.

MEMORY NAME CHANGE

[

]

MEMORY1

[

]

MEMORY2

[

]

MEMORY3

[

]

MEMORY4

Enter a name for the proﬁ le.

Entering proﬁ le names

MEMORY NAME INPUT

█

EMORY1M ABCDEFGH I J KLMALL DELETE N O P Q R S T U V W X Y Z DELETE abcde fgh i j k lm nopq rs tuvwxyz 0123456789 !”#$%&’ +–/=? _` |~<>() [ ]{ } ,

page 30

SPACE

CANCEL

@\ ˆ

.;:

When you ﬁ nished entering the proﬁ le name, select

“OK”. To cancel renaming the proﬁ le, select “CANCEL”.

CANCEL

select

set

select

set

select

set

select

set

Page 32

SOUND Adjustment

Select to adjust each item.

Press to display the SOUND menu.

Press to select the menu to adjust.

Select the desired level by listening to the sound.

Press to exit from adjust mode.

Item Details

Select the audio output.

SPEAKER

AUDIO MENU

BASS

MID Adjusts normal sounds.

TREBLE

BALANCE

SURROUND Select ON or OFF.

AUDIO OUT (PIP)

INTERNAL: Internal speakers EXTERNAL: External speakers

STANDARD: Emits the original sound. DYNAMIC: Accentuates sharp sound. CLEAR: Attenuates human voice.

Adjusts low pitch sounds.

Adjusts high pitch sound.

Adjusts left and right volumes.

MAIN: Selects main picture sound. SUB: Selects PIP frame sound.

VIDEO

SOUND

NORMALIZE

SPEAKER AUDIO MENU BASS MID TREBLE BALANCE SURROUND AUDIO OUT (PIP)

VIDEO PC

NORMAL

1/2

INTERNAL STANDARD 0 0 0 0 0

OFF

MAIN

Musical note ♪ is displayed on right side of the audio output screen label.

Note: BASS, MID, TREBLE and SURROUND settings are memorized separately for each AUDIO MENU.

Helpful Hint ( /

NORMALIZE

Normalization)

While the “SOUND” menu is displayed, if either the N button on the remote control is pressed at any time or the ACTION (

) button is pressed during “NORMALIZE”, then all adjustment values are returned to the factory settings.

Page 33

SOUND Adjustment

SDI SOUND OUTPUT

This menu is available only when selecting a slot that any of the following terminal boards is installed: HD-SDI Terminal Board with audio (TY-FB10HD) or Dual Link HD-SDI Terminal Board (TY-FB11DHD)

SDI SOUND OUTPUT

LEFT CHANNEL RIGHT CHANNEL SOUND OUT LEVEL METER

CHANNEL 1 CHANNEL 1

2/2

OFF OFF

Note:

This menu is unavailable when two screen display mode is active.

Item Details

LEFT CHANNEL

RIGHT CHANNEL

SOUND OUT

LEVEL METER

CHANNEL 1 to CHANNEL 16

Selects left audio channel.

CHANNEL 1 to CHANNEL 16

Selects right audio channel.

ON ON: Enables audio output. OFF: Disables audio output.

OFF

Sets audio channels to show in the audio level meter. 8 channels are displayed in the audio level meter; 4 channels each on both right and left sides of the display.

OFF: Hides the audio level meter. 1-8CH: Displays the audio level meter (1-8ch) 9-16CH

OFF

1-8CH 9-16CH

: Displays the audio level meter (9-16ch)

Page 34

SETUP menu

Press to display the SETUP menu.

Press to select the menu to adjust.

Press to adjust the menu.

Press to return to the previous menu.

SETUP menu screen

SETUP

TOUCH-PEN SETTINGS

MULTI PIP SETTINGS

SIGNAL

SCREENSAVER

EXTENDED LIFE SETTINGS

ECO MODE SETTINGS

INPUT LABEL

FUNCTION BUTTON SETTINGS

COMPONENT/RGB-IN SELECT

NO ACTIVITY POWER OFF MENU DISPLAY DURATION OSD BRIGHTNESS OSD LANGUAGE ENGLISH (US

Press to exit from adjust mode.

1/2

Page 36 Page 38 Page 49 Page 39 Page 41 Page 44 Page 45 Page 46

RGB

DISABLE

30 S

Page 48 Page 47 Page 47 Page 47

)

Page 47

SETUP

TOUCH-PEN SETTINGS

MULTI PIP SETTINGS

SIGNAL

SCREENSAVER

EXTENDED LIFE SETTINGS

ECO MODE SETTINGS

INPUT LABEL

FUNCTION BUTTON SETTINGS

COMPONENT/RGB-IN SELECT

NO ACTIVITY POWER OFF MENU DISPLAY DURATION OSD BRIGHTNESS OSD LANGUAGE ENGLISH (US

RGB

DISABLE

30 S

1/2

)

ON/OFF TIMER SETUP

DAY/TIME SETUP

NETWORK SETUP

DISPLAY ORIENTATION

2/2SETUP

LANDSCAPE

Page 35 Page 35

Page 47

NETWORK SETUP

Set this to connect the Display to a computer via a network. For details of PJLink and Network, refer to “Operating Instructions, Network Operations”.

Page 35

DAY/TIME SETUP / ON/OFF TIMER SETUP

The timer can switch the Plasma Display ON or OFF.

Before attempting Timer Set, conﬁ rm the TIME and adjust if necessary. Then set POWER ON TIME / POWER OFF TIME.

Press to display the SETUP menu.

Press to select ON/OFF TIMER SETUP or DAY/TIME SETUP.

Press to display the ON/OFF TIMER SETUP screen or DAY/TIME SETUP screen.

DAY/TIME SETUP

Press to select DAY or TIME.

Press to set up DAY or TIME.

button: Forward button: Back

Notes:

• Pressing “ ” or “ ” button once changes TIME 1 minute.

• Pressing “ ” or “ ” button continuously changes TIME by 15 minutes.

Press to select SET.

Press to store DAY/TIME SETUP.

Notes:

• SET cannot be selected unless TIME is set.

• Unless setting the present time other than “99:99”, “DAY” and “TIME” cannot be set.

• The settings of “DAY” and “TIME” are reset when leaving the display turned off for about 7 days for the following reasons:

Pressing Disconnecting the AC cord. Interruption of power supply.

switch of the unit to turn off the display.

ON/OFF TIMER SETUP

DAY/TIME SETUP

NETWORK SETUP

DISPLAY ORIENTATION

DAY/TIME SETUP

SET DAY TIME

2/2SETUP

LANDSCAPE

TIME MON 99:99

MON 99:99

ON/OFF TIMER SETUP

Press to select POWER ON TIME / POWER OFF TIME.

Press to set up POWER ON TIME / POWER OFF TIME.

button: Forward button: Back

Notes:

• Pressing “ ” or “ ” button once changes POWER ON TIME / POWER OFF TIME 1 minute.

• Pressing “ ” or “ ” button continuously changes POWER ON TIME / POWER OFF TIME by 15 minutes.

Press to select POWER ON FUNCTION / POWER OFF FUNCTION.

Press to select ON.

Note:

Timer function will not work unless “TIME” is set.

ON/OFF TIMER SETUP

POWER ON FUNCTION POWER ON TIME POWER OFF FUNCTION POWER OFF TIME

TIME 99:99

OFF 0:00 OFF 0:00

Page 36

TOUCH-PEN SETTINGS

Set Touch Pen mode.

Select “TOUCH-PEN SETTINGS” in “SETUP” menu and press

TOUCH-PEN SETTINGS

TOUCH-PEN MODE

WHITEBOARD FUNCTION

QUICK WHITEBOARD LAUNCH

SLOT INPUT VIDEO COMPONENT HDMI DVI PC NETWORK

STANDBY PEN CHARGING MODE

PAIRING

PEN ADAPTER STATUS

TOUCH ONLY

OFF OFF

OFF OFF OFF OFF OFF OFF OFF

OFF

DETECTED

When a Terminal Board with dual input terminals is installed, “SLOT INPUT” is displayed as “SLOT INPUT A” and “SLOT INPUT B”.

button.

TOUCH-PEN MODE

Select an appropriate setting for the function of the electronic pen used. TOUCH ONLY: Contact-type Touch Pen TOUCH & REMOTE: Contact-type Touch Pen and remote pointer

WHITEBOARD FUNCTION

Sets the built-in WhiteBoard (WhiteBoard mode) function. When this is set to “ON”, the built-in WhiteBoard function is enabled and the WHITEBOARD input can be selected.

QUICK WHITEBOARD LAUNCH

When this is set to “ON”, the built-in WhiteBoard will be in the standby mode when the plasma display is in the standby mode (power OFF with remote control) and the start up is quicker.

Note:

This setting is automatically turned “ON” and cannot be changed in the following cases.

When the power is supplied to the slot When “CONTROL I/F SELECT” is set to “LAN” When “WEB CONTROL” is set to “ON” When “STANDBY PEN CHARGING MODE” is set to “ON”

SLOT INPUT ― NETWORK

Set “ON” or “OFF” for each input terminal. If you switch to the input terminal that is set to “ON”, the mode becomes Touch Pen mode.

TOUCH-PEN

“TOUCH-PEN: ON” is displayed in Touch Pen mode.

Notes:

• The picture quality changes according to the settings of “TOUCH-PEN MODE” and ON/OFF state of each input terminal.

• The electronic pen cannot be used during Digital Zoom. (see page 21)

• When using the electronic pen, adjust “POS./SIZE” so that the screen of the computer can be correctly displayed. (see page 24)

Setting the Remote Control

You can also turn Touch Pen mode ON/OFF with the FUNCTION buttons on the remote control. (see page 46)

In Touch Pen mode, the menus and functions are restricted as follows.

POS./SIZE menu

PICTURE menu

SETUP menu

Options menu

EXTENDED LIFE SETTINGS

1:1 PIXEL MODE: ON OVER SCAN: OFF PICTURE MENU: “STANDARD” or “DYNAMIC” only. (see page 27) PICTURE MENU: “STANDARD” or “DYNAMIC” only. (see page 41) Display size: Unavailable Rotate: Unavailable

ASPECT Controls FULL

Page 37

TOUCH-PEN SETTINGS

STANDBY PEN CHARGING MODE

Sets the power supply for the electronic pen charging terminal (CHARGE, MEMORY/(CHARGE)) in the standby mode (power OFF with remote control). OFF: Turns off the charging terminal power in the standby mode. ON[4hrs]: Turns ON the charging terminal power for 4 hours after entering standby mode. ON: Leaves the charging terminal power ON in standby mode so that the pen can be charged.

PAIRING

Registers an electronic pen to electronic pen adapter. Up to four electronic pens can be registered for an electronic pen adapter. For the details of the pairing, please refer to “Operating Instructions, Electronic Pen Operations”.

Note:

Make sure the electronic pen adapter is connected to the display.

If no electronic pen has been registered, the screen of procedure the screen to register an electronic pen.

Select “PAIRING” in “TOUCH PEN SETTINGS” and press button.

Select “Pairing” and press button.

Pairing Tool

Pairing

Unpairing All

While pressing both the remote drawing and the remote clearing buttons of the electronic pen, press the Power switch. To cancel the paring, select “Cancel”.

Pairing in progress

Set the electronic pen that you want to pair as pair-enabled and then move it closer to the electronic pen adapter. For details, refer to the procedure for registering electronic pens in the operating instructions for the electronic pen.

Cancel

appears ﬁ rst. Follow the instructions on

When the electronic pen paring is completed, select “Return” and press button.

Pairing Tool

Pairing was successful.

Return

Select “Close” and press

Pairing Tool

Pairing

Unpairing All

button.

[Unpairing]

Unpairs all paired electronic pens.

1 2

PEN ADAPTER STATUS

NOT DETECTED: Electronic pen adapter is not connected. CONFIRMING...: Immediately after connecting an electronic pen adapter and the built-in WhiteBoard “Easy WhiteBoard”

DETECTED: Electronic pen adapter is connected.

Select “Unpairing All” in “Pairing Tool” and press button.

Select “Yes” and press button.

Pairing Tool

Do you want to cancel all pairings?

Yes

is starting up.

Page 38

MULTI PIP SETTINGS

Set the two screen display function. Two screen display function MULTI PIP (page 22)

Select “MULTI PIP SETTINGS” in “SETUP” menu and press

MULTI PIP SETTINGS

MULTI PIP PIP MODE MAIN INPUT SUB INPUT SUB SCREEN SIZE SUB SCREEN POSITION

SWAP

PIC IN PIC

COMPONENT

VIDEO

LOWER RIGHT

button.

MULTI PIP

Set this “ON” to have two screen display. Various settings such as “PIP MODE” can be set.

PIP MODE

Sets the two screen display mode. PIC IN PIC: Displays two input images combined. PIC IN WHITEBOARD: Displays the built-in WhiteBoard with the other input image combined. Main screen is ﬁ xed to WHITEBOARD.

MAIN INPUT

Sets the input image for the main screen.

SUB INPUT

Sets the input image for the sub screen.

SUB SCREEN SIZE

1 (small) - 4 (large): Sets the size of the sub screen.

SUB SCREEN POSITION

Sets the display position of the sub screen.

SWAP

Swap the main and sub screens.

Note:

When “PIC IN WHITEBOARD” is selected, “SWAP” cannot be used.

Page 39

SCREENSAVER (For preventing image retention)

Do not display a still picture, especially in 4:3 mode, for any length of time. If the display must remain on, a SCREENSAVER should be used.

Select “SCREENSAVER” in “SETUP” menu and press button.

FUNCTION selection

MODE selection

Press to select the FUNCTION.

Press to select the desired function.

NEGATIVE IMAGE

WHITE SCREEN

NEGATIVE IMAGE : A negative image will be displayed on the screen. SCROLLING BAR ONLY : OVERLAY SCROLLING BAR

WHITE SCREEN : The whole screen will be white.

Note: OVERLAY SCROLLING BAR is not effective during two screen display.

Press to select the MODE. Press to select each mode items.

SCROLLING BAR ONLY

OVERLAY SCROLLING BAR

A white bar will scroll from left to right. The image won't be displayed.

: The brightness of the image will be decreased and a white bar

will scroll on it.

STANDBY AFTER SCR SAVER : Operates while SCREENSAVER DURATION,

and display enters standby mode.

OFF

INTERVAL

TIME OF DAY : Operates when START TIME and FINISH TIME

: Operates when START is selected and the

ACTION ( ) button is pressed.

: Operates when SHOW DURATION and SAVER

DURATION are set up and those times arrive.

are set up and those times arrive.

SCREENSAVER

START FUNCTION MODE

TIME 99:99

SCROLLING BAR ONLY STANDBY AFTER SCR SAVER

START setting

When the MODE is set to ON, press to select START.

Press to start SCREENSAVER. The menu screen will disappear and the SCREENSAVER will be activated. To stop the

SCREENSAVER under ON, press the R button or any buttons on the main unit. Note: When the display is turned off, the SCREENSAVER will be deactivated.

Page 40

SCREENSAVER (For preventing image retention)

Setup of SCREENSAVER Time

After selecting TIME OF DAY, INTERVAL or STANDBY AFTER SCR SAVER, the relevant Time Setup will become available for selection and the Operating Time may be set. (Time cannot be set when “MODE” is “ON” or “OFF”.)

Press to select START TIME / FINISH TIME (when TIME OF DAY is selected). Press to select SHOW DURATION / SAVER DURATION (when INTERVAL is selected). Press to select SCREENSAVER DURATION (when STANDBY AFTER SCR SAVER is selected).

Press to setup. button: Forward

button: Back

Notes:

• Pressing “ [However, switching occurs every 15 minutes when Periodic Time is selected.]

” or “ ” button once changes the Time 1 minute.

• Pressing “ ” or “ ” button continuously changes the Time by 15 minutes.

• “SCREENSAVER DURATION” of the “STANDBY AFTER SCR SAVER” can be set from 0:00 to 23:59. When this is set to “0:00”, “STANDBY AFTER SCR SAVER” will not be activated.

Note: Timer function will not work unless “TIME” is set.

SCREENSAVER

START FUNCTION MODE START TIME FINISH TIME

SCREENSAVER

START FUNCTION MODE SHOW DURATION SAVER DURATION

SCREENSAVER

START FUNCTION MODE SCREENSAVER DURATION

SCROLLING BAR ONLY

SCROLLING BAR ONLY STANDBY AFTER SCR SAVER

TIME 15:00

TIME OF DAY

6:15

12:30

TIME 15:00

INTERVAL

12:00

3:00

TIME 15:00

6:15

Page 41

Reduces screen image retention

EXTENDED LIFE SETTINGS

The following settings are setup to reduce image retention:

Select “EXTENDED LIFE SETTINGS” in “SETUP” menu and press button.

EXTENDED LIFE SETTINGS

EXPRESS SETTINGS

CUSTOM SETTINGS

RESET

EXTENDED LIFE SETTINGS

RECOMMENDED SETTINGS

PICTURE MENU PICTURE SIDE BAR ADJUST NANODRIFT SAVER NANODRIFT MODE PEAK LIMIT LOCK SETTINGS

APPLY TO CURRENT INPUT

APPLY TO ALL INPUTS

DYNAMIC

HIGH MID SMOOTH

UNLOCK

BRIGHT

OFF

Set to the recommended value Set individually Reset to the factory settings

Image Retention Reduction Menu

“EXTENDED LIFE SETTINGS” enables you to set the following 5 menus (Image Retention Reduction Menu) as recommended values or set them individually.

PICTURE MENU PICTURE

“PICTURE MENU” and “PICTURE” are same as “PICTURE” menu items (see page 27). The settings of this menu will be reﬂ ected to the “PICTURE” menu.

SIDE BAR ADJUST

Do not display a picture in 4:3 mode for an extended period, as this can cause an image retention to remain on the side bars on either side of the display ﬁ eld. To reduce the risk of such an image retention, illuminate the side bars.

This function may be applicable to the non-picture area.

OFF: Darken both ends. DARK: Make it dark gray. MID: Make it gray. BRIGHT: Make it light gray.

Notes:

• To reduce the occurrence of image retention, set the SIDE BAR ADJUST to BRIGHT.

• The side bar may ﬂ ash (alternate black/white) depending on the picture being shown on the screen. Using Cinema mode will reduce such ﬂ ashing.

side bars

4:3 mode


retention

Page 42

Reduces screen image retention

NANODRIFT SAVER

Moves the display position of the screen slightly to reduce image retention on the display panel. MIN–MAX: NANODRIFT SAVER operates. The display position of the screen moves at set time intervals. You can set

the screen movement range. Some of the screen may appear to be missing as a result of this operation. If you change the value, a mask is displayed in the range where the picture is missing as a result of position movement.

When “NANODRIFT” Image Retention Reduction is operating, “NANODRIFT”

is displayed.

Note:

This function does not work in the following cases. When in digital zoom mode

NANODRIFT MODE

Sets the operation mode of NANODRIFT SAVER. SMOOTH: Moves by 1/16 dot PIXEL: Moves by 1 dot

PEAK LIMIT ON: Suppresses image contrast (peak brightness).

Note: When a still picture is viewed for an extended time, the screen may become slightly darker. (see page 60)

EXPRESS SETTINGS

Set the “Image Retention Reduction” menu to the recommended settings. All menus will be locked. PICTURE MENU: STANDARD PICTURE: Recommended setting for each model SIDE BAR ADJUST: BRIGHT NANODRIFT SAVER: HIGH MID NANODRIFT MODE: SMOOTH (“PIXEL” when Touch Pen or Touch Panel mode) PEAK LIMIT: ON

FULL

NANODRIFT

Select “EXPRESS SETTINGS”.

EXTENDED LIFE SETTINGS

EXPRESS SETTINGS CUSTOM SETTINGS

RESET

Select the input to apply the settings.

EXTENDED LIFE SETTINGS

APPLY TO CURRENT INPUT

APPLY TO ALL INPUTS

Select “YES”.

EXTENDED LIFE SETTINGS

APPLY TO CURRENT INPUT

NOYES

select

access

select

set

select

set

Page 43

CUSTOM SETTINGS

Set the individual “Image Retention Reduction” menu.

Reduces screen image retention

Select “CUSTOM SETTINGS”.

EXTENDED LIFE SETTINGS

EXPRESS SETTINGS

CUSTOM SETTINGS

RESET

To set each menu to the recommended setting:

Select “RECOMMENDED SETTINGS”.

EXTENDED LIFE SETTINGS

RECOMMENDED SETTINGS

PICTURE MENU PICTURE SIDE BAR ADJUST NANODRIFT SAVER NANODRIFT MODE PEAK LIMIT LOCK SETTINGS

APPLY TO CURRENT INPUT

APPLY TO ALL INPUTS

DYNAMIC

BRIGHT

HIGH MID

SMOOTH

OFF

UNLOCK

Each menu will be set as same as the “EXPRESS SETTINGS”.

Set each menu.

EXTENDED LIFE SETTINGS

RECOMMENDED SETTINGS

PICTURE MENU PICTURE SIDE BAR ADJUST NANODRIFT SAVER NANODRIFT MODE PEAK LIMIT LOCK SETTINGS

APPLY TO CURRENT INPUT

APPLY TO ALL INPUTS

To lock each menu setting:

Set the “LOCK SETTINGS” to “LOCK”.

EXTENDED LIFE SETTINGS

RECOMMENDED SETTINGS

PICTURE MENU PICTURE SIDE BAR ADJUST NANODRIFT SAVER NANODRIFT MODE PEAK LIMIT LOCK SETTINGS

APPLY TO CURRENT INPUT

APPLY TO ALL INPUTS

DYNAMIC

BRIGHT

HIGH MID

SMOOTH

OFF

UNLOCK

DYNAMIC

BRIGHT

HIGH MID

SMOOTH

OFF

UNLOCK

select

access

select

set

select

adjust

select

adjust

When a menu is locked, it is grayed out and cannot be set. “PICTURE MENU” and “PICTURE” will no longer be able to set in the “PICTURE” menu, and they are labeled with icon to indicate their locked status. Also, “NORMALIZE”, “MEMORY SAVE” and “MEMORY LOAD” are not available.


NORMALIZE

PICTURE MENU PICTURE

BRIGHTNESS COLOR TINT SHARPNESS COLOR TEMP

ADVANCED SETTINGS

NORMAL

MEMORY SAVE MEMORY LOAD

MEMORY EDIT

DYNAMIC

0 0 0 5

NORMAL

EXTENDED LIFE SETTINGS

Touch Pen mode when a menu is locked

When a menu is locked, “TOUCH-PEN SETTINGS” are disabled and Touch Pen mode cannot be set.

Select the input to apply the settings.

EXTENDED LIFE SETTINGS

RECOMMENDED SETTINGS

PICTURE MENU PICTURE SIDE BAR ADJUST NANODRIFT SAVER NANODRIFT MODE PEAK LIMIT

LOCK SETTINGS

APPLY TO CURRENT INPUT

APPLY TO ALL INPUTS

Select “YES”.

EXTENDED LIFE SETTINGS

APPLY TO CURRENT INPUT

DYNAMIC

BRIGHT HIGH MID SMOOTH

NOYES

OFF

LOCK

select

set

select

set

RESET

Reset the “Image Retention Reduction” menu to the factory settings. Each menu will be unlocked.

Select “RESET”.

EXTENDED LIFE SETTINGS

EXPRESS SETTINGS

CUSTOM SETTINGS

RESET

Select the input to reset the settings.

EXTENDED LIFE SETTINGS

RESET CURRENT INPUT

RESET ALL INPUTS

select

access

select

set

Select “YES”.

EXTENDED LIFE SETTINGS

RESET CURRENT INPUT

NOYES

select

set

Page 44

ECO MODE SETTINGS

Select “ECO MODE SETTINGS” in “SETUP” menu and press button.

ECO MODE SETTINGS

select

CUSTOMECO MODE

POWER SAVE PC POWER MANAGEMENT DVI-D POWER MANAGEMENT NO SIGNAL POWER OFF

OFF

DISABLE

ECO MODE

CUSTOM: The menu of power consumption reduction is individually set. ON: The following ﬁ xed values are set to the menu of power consumption reduction. Individual setting is not available.

POWER SAVE: ON PC POWER MANAGEMENT: ON

Using Remote Control

When is pressed, the “ECO MODE” setting changes.

Custom settings

The menu of the power consumption reduction is individually set. This setting is enabled when “ECO MODE” is set to “CUSTOM”.

POWER SAVE

When this function is turned ON, luminous level of the Plasma Display is suppressed, so power consumption is reduced.

SENSOR: The luminous level of the Plasma Display is automatically adjusted according to the viewing environment.

Note: In Touch Pen mode, the sensor function is disabled.

PC POWER MANAGEMENT

When this function is set to ON, it operates under the following conditions to turn the power on or off automatically. When no pictures (HD/VD sync signals) are detected for 60 or so seconds during PC signal input:

→ Power is turned off (standby); the power indicator lights up orange.

When pictures (HD/VD sync signals) are subsequently detected:

→ Power is turned on; the power indicator lights up green.

Notes:

• This function operates only during PC signal input.

• This function is effective when “SYNC” is set to “AUTO”, “COMPONENT / RGB-IN SELECT” is set to “RGB” and during normal viewing.

DVI-D POWER MANAGEMENT

When this function is set to ON, it operates under the following conditions to turn the power on or off automatically. When no picture

→ Power is turned off (standby); the power indicator lights up orange.

When pictures (sync signal) are subsequently detected: → Power is turned on; the power indicator lights up green. Notes:

• This function operates only during DVI signal input.

• This function is invalid during input from DVI-D Terminal Board (TY-FB11DD).

• Depending on the type of terminal board equipped, this function may be invalid.

NO SIGNAL POWER OFF

Equipment power supply is turned OFF when there is no signal.

When this is set to “ENABLE”, the power supply of the unit goes Off 10 minutes after the input signals stop.

s (sync signal) are detected for 60 or so seconds during DVI signal input:

adjust

DVI-D POWER MANAGEMENT: ON NO SIGNAL POWER OFF: ENABLE

ECO MODE ON

Page 45

Customizing the Input labels

This function can change the label of the Input signal to be displayed. (see page 17)

Select “INPUT LABEL” in “SETUP” menu and press

INPUT LABEL

SLOT INPUT VIDEO COMPONENT HDMI DVI PC NETWORK WHITEBOARD

SLOT INPUT

VIDEO

COMPONENT

HDMI

DVI

NETWORK

WHITEBOARD

button.

Image input Input label [SLOT INPUT]*1 SLOT INPUT / DVD1 / DVD2 / DVD3 / DVD4 / Blu-ray1 / Blu-ray2 / Blu-ray3 / Blu-ray4 / CATV /

VCR / STB / (SKIP)

[VIDEO] VIDEO / DVD1 / DVD2 / DVD3 / DVD4 / Blu-ray1 / Blu-ray2 / Blu-ray3 / Blu-ray4 / CATV / VCR /

STB / (SKIP)

[COMPONENT]*2 COMPONENT / DVD1 / DVD2 / DVD3 / DVD4 / Blu-ray1 / Blu-ray2 / Blu-ray3 / Blu-ray4 / CATV /

VCR / STB / (SKIP)

[HDMI] HDMI / DVD1 / DVD2 / DVD3 / DVD4 / Blu-ray1 / Blu-ray2 / Blu-ray3 / Blu-ray4 / CATV / VCR /

STB / (SKIP)

[DVI] DVI / DVD1 / DVD2 / DVD3 / DVD4 / Blu-ray1 / Blu-ray2 / Blu-ray3 / Blu-ray4 / CATV / VCR / STB /

(SKIP)

[PC] PC / DVD1 / DVD2 / DVD3 / DVD4 / Blu-ray1 / Blu-ray2 / Blu-ray3 / Blu-ray4 / CATV / VCR / STB /

(SKIP) [NETWORK] NETWORK / (SKIP) [WHITEBOARD] WHITEBOARD / (SKIP)

(SKIP) : The INPUT button press will skip its input.

*1 “SLOT INPUT” is displayed when a Terminal Board is installed.

*2 “COMPONENT” may be displayed as “RGB” depending on the setting of “COMPONENT/RGB-IN SELECT”.

(see page 48)

When a Terminal Board with dual input terminals is installed

“SLOT INPUT” is displayed as “SLOT INPUT A” and “SLOT INPUT B” and independent settings are available.

[SLOT INPUT A] SLOT INPUT A / DVD1 / DVD2 / DVD3 / DVD4 / Blu-ray1 / Blu-ray2 / Blu-ray3 / Blu-ray4 / CATV / VCR /

STB / (SKIP) [SLOT INPUT B] SLOT INPUT B / DVD1 / DVD2 / DVD3 / DVD4 / Blu-ray1 / Blu-ray2 / Blu-ray3 / Blu-ray4 / CATV /

VCR / STB / (SKIP)

When a Terminal Board with ﬁ xed display (such as Tuner Board) is installed

Only ﬁ xed display and (SKIP) are available as Input label of “SLOT INPUT”.

[SLOT INPUT]

ﬁ xed display

/ (SKIP)

Page 46

FUNCTION BUTTON SETTINGS

Set the functions that operates when is pressed.

Select “FUNCTION BUTTON SETTINGS” in “SETUP” menu and

press

button.

FUNCTION BUTTON SETTINGS

FUNCTION BUTTON 2 FUNCTION BUTTON GUIDE

SCROLLING BAR

TOUCH-PENFUNCTION BUTTON 1

• FUNCTION BUTTON 1, FUNCTION BUTTON 2

The following functions are set to the FUNCTION button.

ECO MODE SETTINGS / SIGNAL / ON/OFF TIMER SETUP /

Note:

Factory settings are as follows. FUNCTION1 button: TOUCH-PEN FUNCTION2 button: SCROLLING BAR

MULTI PIP SETTINGS

Menu is displayed. (Example: ECO MODE SETTINGS)

ECO MODE SETTINGS

CUSTOMECO MODE

POWER SAVE PC POWER MANAGEMENT DVI-D POWER MANAGEMENT NO SIGNAL POWER OFF

OFF

DISABLE

Pressing the FUNCTION button clears the menu.

SCROLLING BAR

Activates the SCROLLING BAR ONLY screensaver.

After 15 minutes, the display enters standby mode.

To exit this mode, press button.

INPUT (SLOT)* – INPUT (WHITEBOARD)

Simply press to select the input.

* “INPUT (SLOT)” is displayed when an optional Terminal Board is installed.

When a Terminal Board with dual input terminals is installed, “INPUT (SLOT A)” and “INPUT (SLOT B)” are displayed.

TOUCH-PEN

Press

and turn Touch Pen mode ON/OFF.

TOUCH-PEN ON

NETWORK SETUP

“NETWORK SETUP” menu is displayed.

MULTI-LIVE

Switch to the MULTI-LIVE mode when using the “Wireless Manager”.

COMPUTER SEARCH

The list of connectable computers on the network is displayed.

Note:

For the network function, refer to “Operating Instructions, Network Operations” and the instruction manual of “Wireless Manager” in use.

AV MUTE

Mutes the audio and video. To exit this mode, press any

MULTI PIP ON/OFF

Press

to turn MULTI PIP ON/OFF.

button.

• FUNCTION BUTTON GUIDE

The function display setting for the FUNCTION button is conﬁ gured.

ON: Press the FUNCTION button to display the function list of the button.

OFF: The function list is not displayed.

The operation starts.

FUNCTION 1:TOUCH-PEN 2:SCROLLING BAR

Page 47

NO ACTIVITY POWER OFF

DISABLE ENABLE

When this function is set to “ENABLE”, the power is turned off (standby) automatically when there is no operation of the Plasma Display for 4 hours. Starting from 3 minutes before the turn off, the remaining time will be displayed.

PRESS ANY KEY TO ABORT.

NO ACTIVITY POWER OFF

When the power is turned off due to this function, a message “LAST TURN OFF DUE TO ’NO ACTIVITY POWER OFF’.” is displayed next time the power is turned on.

Note:

During the screensaver is running, this function is disabled.

3MIN

MENU DISPLAY DURATION / OSD BRIGHTNESS

Set the display time and brightness of the on-screen menu display.

MENU DISPLAY DURATION: 5 S – 30 S

OSD BRIGHTNESS: 1 – 5

OSD LANGUAGE

Select your preferred language.

Selectable languages

English(UK) Deutsch Français Italiano Español ENGLISH(US)

(Chinese)

(Japanese)

Русский (Russian)

DISPLAY ORIENTATION

Sets the fan control, panel drive control, and the display style of on-screen menu for vertical installation.

LANDSCAPE PORTRAIT

Fan control and panel drive control for horizontal installation.

Notes:

• Turn up the power switch for the upward direction when you set Display vertically.

• When you change this setting, fan control and panel drive control will be switched as the power is turned on next time.

Fan control and panel drive control for vertical installation. On-screen menu will be rotated 90 degrees counterclockwise to be suitable for the setting.

Page 48

SETUP for Input Signals

COMPONENT / RGB IN SELECT

COMPONENT RGB

Select to match the signals from the source connected to the Component / RGB or PC input terminals. Y, PB, PR signals “COMPONENT” RGB signals “RGB”

Note:

Make setting of the selected input terminal (COMPONENT/RGB IN or PC IN).

YUV / RGB IN SELECT

YUV RGB

Select to match the signals from the source connected to the DVI input terminals. YUV signals “YUV” RGB signals

“RGB”

Notes:

• Selection may not be possible, depending on which optional board is installed.

• Make setting of the selected input terminal (SLOT or DVI-D IN).

Page 49

SETUP for Input Signals

SIGNAL menu

Notes:

• “SIGNAL” setup menu displays a different setting condition for each input signal.

• Depending on the input signal type, an optional Terminal Board may be required.

Select “SIGNAL” in “SETUP” menu and press

button.

For VIDEO (S VIDEO) For RGB

[

AUTO

OFF

AUTO

OFF

[

OFF

AUTO

OFF

RGB

Digital

]

SIGNAL

3D Y/C FILTER (NTSC) COLOR SYSTEM 3 : 2 PULLDOWN NOISE REDUCTION

For COMPONENT

SIGNAL

SYNC 3 : 2 PULLDOWN XGA MODE NOISE REDUCTION

H-FREQ. V-FR EQ.

SIGNAL FORMAT 1280×1024/60i

[

63.98

60.02

COMPONENT

kHz Hz

[

VIDEO

AUTO

OFF OFF

AUTO

OFF

AUTO

OFF

]

SIGNAL

SYNC 3 : 2 PULLDOWN XGA MODE NOISE REDUCTION

H-FREQ. V-FR EQ.

SIGNAL FORMAT 1280×1024/60i

For Digital

]

SIGNAL

3 : 2 PULLDOWN HDMI RANGE NOISE REDUCTION

H-FREQ.

V-FR EQ.

SIGNAL FORMAT 1280×1024/60i

63.98

60.02

63.98

60.02

kHz Hz

kHz

• 3D Y/C FILTER (NTSC)

This menu is displayed when BNC Dual Video Terminal Board (TY-FB9BD) is installed to the unit. Set this menu when the moving image looks unnatural during Video (S Video) input signal.

ON OFF Note:

When ON, this setting only affects NTSC input signals.

• COLOR SYSTEM

AUTO SECAM M.NTSC NTSCPAL

Set the color system to match the input signal. When “AUTO” is set, COLOR SYSTEM will be automatically selected from NTSC/PAL/SECAM/M.NTSC. To display PAL60 signal, select “AUTO” or “PAL”.

If the image becomes unstable:

With the system set on Auto, under conditions of low level or noisy input signals the image may in rare cases become unstable. Should this occur, set the system to match the format of the input signal.

• 3:2 PULLDOWN

When “ON”, the display attempts to reproduce a more natural interpretation of sources such as movie pictures, which are recorded at 24 frames per second. If the picture is not stable, turn the setting to “OFF”.

ON OFF Note:

When ON, this setting only affects the following signal input:

• NTSC / PAL signal input during Video (S Video) input signal.

• 525i(480i), 625i(575i), 1125(1080)/60i signal input during “COMPONENT” input signal.

• XGA MODE

This menu is displayed when the input signal is analog (Component/PC). This unit supports three types of XGA signals with 60Hz vertical frequency having different aspect ratios and sampling rates (1,024 × 768 @ 60Hz, 1,280 × 768 @ 60Hz and 1,366 × 768 @ 60Hz).

AUTO 1024×768 1280×768 1366×768 AUTO: Automatically selected from 1024×768/1280×768/1366×768.

Switch the setting to suit the input signal for better display depends on the angle of view or display resolution condition.

Note:

After making this setting, be sure to make each adjustment (such as “AUTO SETUP”) on the “POS./SIZE” menu as necessary. (see page 24)

Page 50

SETUP for Input Signals

• SYNC

This function operates only during input from PC IN terminal.

Setting RGB sync signal

Conﬁ rm that the input is set to RGB input (this setting is valid only for RGB input signal).

AUTO:

ON G:

Setting Component sync signal

Conﬁ rm that the input is set to Component input (this setting is valid only for Component input signal). AUTO:

ON Y: Uses a synchronized signal on the Video Y signal, which is input from the Y connector.

Note:

Signals input to COMPONENT/RGB IN terminals correspond to SYNC ON G or SYNC ON Y.

• SDI THROUGH

Set the active through function of the Dual Link HD-SDI Terminal Board (TY-FB11DHD).

OFF ON: Enables active through. OFF: Disables active through. Note:

Settings can only be performed for this menu when a slot mounted with a Dual Link HD-SDI Terminal Board (TY-FB11DHD) is selected.

The H and V sync or synchronized signal is automatically selected. If both input, it is selected the H and V sync.

Uses a synchronized signal on the Video G signal, which is input from the G connector.

The H and V sync or synchronized signal is automatically selected. If both input, it is selected the H and V sync.

• HDMI RANGE

Switches the dynamic range according to the input signal from HDMI terminal.

VIDEO(16-235) FULL(0-255) AUTO VIDEO(16-235): If the input signal is the video range, Example: HDMI terminal output for DVD player FULL(0-255): If the input signal is full range, Example: HDMI terminal output for personal computer AUTO: Note:

This function can be set only for HDMI signal input.

Switches the dynamic range automatically between “VIDEO(16-235)” and “FULL(0-255)” according to the input signal.

Page 51

()

• NOISE REDUCTION

Sets the following three NR (Noise Reduction) functions together. VIDEO NR, MOSQUITO NR, BLOCK NR

SETUP for Input Signals

Press to select “NOISE REDUCTION”.

Press to select “OFF”, “MIN”, “MID”, “MAX”, “ADVANCED”.

Advanced NR

Sets the three NR functions separately.

Press to select “ADVANCED”.

Press to enter ADVANCED NR.

Press to select VIDEO NR, MOSQUITO NR or BLOCK NR. Press to select “OFF”, “MIN”, “MID”, “MAX”.

ADVANCED NR

VIDEO NR MOSQUITO NR BLOCK NR

ADVANCED NR

VIDEO NR MOSQUITO NR BLOCK NR

[

VIDEO

OFF OFF OFF

[

COMPONENT

OFF OFF OFF

NOISE REDUCTION

]

ADVANCED NR

VIDEO NR MOSQUITO NR BLOCK NR

]

ADVANCED NR

VIDEO NR MOSQUITO NR BLOCK NR

OFF

ADVANCED

[

RGB

OFF OFF OFF

[

Digital

OFF OFF OFF

▼

]

VIDEO NR: Automatically reduces unwanted picture noise. MOSQUITO NR

: Reduces mosquito noise around subtitles on MPEG videos.

BLOCK NR: Reduces block noise when playing MPEG videos.

Note:

NOISE REDUCTION cannot be adjusted while a PC signal is being applied.

• Input signal display

Displays the frequency and the type of the current input signal.

This display is valid only for COMPONENT/RGB/PC and Digital input signal. Display range:

Horizontal 15 - 110 kHz Vertical 48 - 120 Hz

The dot clock frequency is displayed during DVI signal input.

H-FREQ. V-FREQ .

SIGNAL FORMAT 1280×1024/60i

H-FREQ.

V-FREQ . DOT CLOCK FREQ. SIGNAL FORMAT 1280×1024/60i

63.98

60.02

63.98

60.02

kHz Hz

kHz Hz MHz108.0

Page 52

Options Adjustments

Press to display the SETUP menu.

Press to select “OSD LANGUAGE”.

Press for more than 3 seconds.

Press to select “Options”.

Press to display the Options menu.

Press to select your preferred menu.

Press to adjust the menu.

Press to exit from Options menu.

Options

Shipping

Options

Weekly Command Timer

Audio input select

Touch Panel settings

Input Search

Onscreen display Initial input Initial VOL level Maximum VOL level Input lock Button lock Remocon User level

Options

Off-timer function

Initial Power Mode ID select Serial ID Display size Studio W/B Studio Gain

Options

Slot power Power On Screen Delay Clock Display All Aspect Auto Setup Rotate

Power On Message (No activity power off)

Power On Message (Power Management)

On Off

Off00 Off

Off

Enable

Normal

Off

O f f Off Off Off

Manual

Off

1/3

2/3

3/3

Item Adjustments

Weekly Command Timer

Audio input select

Touch Panel settings

Input Search Set auto input switching for when there is no signal. (see page 59)

Onscreen display

Initial input

Initial VOL level

Maximum VOL level

Sets Weekly Command Timer. (see page 55) Set up the sound when an image input is selected. (see page 57) Set while using Touch Panel (available as an option). (see page 58)

On: Displays all the following on screen.

• Power on display

• Input signal switch display

• No signal display

• Mute and the remaining time of off-timer after

was pressed.

Off: Hides all the items above from view. Adjusts the input signal when the unit is turned on.

Off SLOT INPUT*1 VIDEO COMPONENT*2 HDMI DVI PC NETWORK WHITEBOARD

*1 “SLOT INPUT” is displayed when an optional Terminal Board is installed.

When a Terminal Board with dual input terminals is installed, “SLOT INPUT A” and “SLOT INPUT B” are displayed.

“COMPONENT” may be displayed as “RGB” depending on the setting of “COMPONENT/RGB-IN SELECT”. (see page 48)

Notes:

• Only the adjusted signal is displayed. (see page 17)

• This menu is available only when “Input lock” is “Off”.

Press

Off

button to adjust the volume when the unit is turned on.

Off: Sets normal volume. On: Sets your preferred volume. Notes:

When “Maximum VOL level” is “On”, the volume can only be adjusted between 0 and your maximum range.

•

• You can hear the changed volume regardless of your volume setting before opening the options menu if you adjust the volume when “Initial VOL level” is “On” and cursor is on the menu.

Press

Off

button to adjust the maximum volume.

Off: Sets auto maximum volume. On: Sets your preferred maximum volume. Notes:

• If the “Maximum VOL level” is set lower than the “Initial VOL level”, the “Initial VOL level” automatically becomes the same as the “Maximum VOL level”.

• The volume display can go up to 63 regardless of the settings.

• You can hear the changed volume regardless of your volume setting before opening the options menu if you adjust the volume when “Maximum VOL level” is “On” and cursor is on the menu.

Page 53

Item Adjustments

Locks the input switch operation.

Off SLOT INPUT*1 VIDEO COMPONENT*2 HDMI DVI PC NETWORK WHITEBOARD

*1 “SLOT INPUT” is displayed when an optional Terminal Board is installed.

When a Terminal Board with dual input terminals is installed, “SLOT INPUT A” and “SLOT INPUT B” are displayed.

*2 “COMPONENT” may be displayed as “RGB” depending on the setting of “COMPONENT/RGB-IN SELECT”.

Input lock

(see page 48)

Notes:

• Only the adjusted signal is displayed (see page 17).

• Input switch can be used when this is set to “Off”. Two screen display cannot be selected.

• In two screen display mode, if anything other than “Off” is set, the value will be ﬁ xed as the value input in the single screen display mode.

Options Adjustments

Button lock

Remocon User level

Off-timer function

Initial Power Mode

ID select

Serial ID

Off

MENU&ENTER On

Off: All the buttons on main unit can be used. MENU&ENTER: Locks On: Locks all the button on main unit.

and

buttons on main unit.

ENTER/

Sets Button lock with the unit buttons in the following procedure.

Off: Press MENU&ENTER: Press On: Press four times→Press

Off

four times→Press

four times→Press four times→Press

ENTER/

four times→Press four times→Press

INPUT

four times→Press four times→Press

ENTER/

User1 User2 User3

ENTER/

four times→Press

INPUT

ENTER/

Off: You can use all of the buttons on the remote control. User1:

You can only use , , , , buttons on the remote control.

User2: You can only use User3:

Locks all the buttons on remote control.

button on the remote control.

Enable: Enables the “Off-timer function”. Disable: Disables the “Off-timer function”. Note: When “Disable” is set, the Off-timer is cancelled.

Normal

Standby On

Sets the power mode of the unit for when the power recovers from failure or after plugging off and in again.

Normal: Power returns in as the same state as before the power interruption. Standby: Power returns in standby mode. (Power Indicator : red/orange) On: Power returns in power On. (Power Indicator : green) Note: When using multiple displays, “Standby” is preferred to be set in order to reduce a power load.

Sets panel ID number when panel is used in “Serial ID”. Set value range: 0 - 100 (Standard value: 0)

Sets the panel ID Control.

Off: Disables external control by the ID. On: Enables the external control by the ID.

Adjusts the image display size on screen.

Off: Sets the normal image display size on screen. On: Sets the image display size approximately 95 % of the normal image display. Off On

Display size

Notes:

• This setting is valid only when the input signals are as follows;

NTSC, PAL, SECAM, M.NTSC, PAL60, PAL-M, PAL-N (Video)

525i, 525p, 625i, 625p, 750/60p, 750/50p, 1125/60i, 1125/50i, 1125/24sF, 1125/25p, 1125/24p, 1125/30p, 1125/60p, 1125/50p, 1250/50i (Component Video, RGB, DVI, SDI, HDMI)

• This setting is invalid when digital zoom is selected.

• When “Display size” is set to “On”, “H-POS” and “V-POS” in “POS./SIZE” can be adjusted.

• Refer to each board’s operating instruction for DVI, SDI, HDMI’s corresponding signals.

Page 54

Options Adjustments

Item Adjustments

Studio W/B

Studio Gain

Off: Nullify all the settings adjusted. On: Sets the color temperature for TV studio. Note: Valid only when the “WARM” is set as “COLOR TEMP” in PICTURE menu.

Sharpens the contrast for a better view when a part of the image is too light to see.

Off: Disables “Studio Gain”. On: Enables “Studio Gain”. Note: This setting is valid only when the input signals are as follows:

Component Video, RGB (analog), SDI, HDMI

Slot power

Power On Screen

Delay

Clock Display

All Aspect

Auto Setup

Rotate

Power On Message

(No activity power

off)

Power On Message

(Power Management)

Off Off: Power is not transmitted to the slot power. Auto: Power is transmitted to the slot power only when main power is on. On: Power is transmitted to the slot power when main power is on or in the standby state. Note: In some cases, power is transmitted to the slot power when main power is on or in the standby state

Off

You can set the power-on delay time of the displays to reduce the power load, when you press on the multiple displays that are set together. Set each display’s setting individually.

Off: The display will be turned on at the same time as 1 to 30 (sec.)

After pressing

Notes:

• During this function is working, the power indicator is blinking green.

•

This function also works when the power recovers from failure or after plugging off and in again the power cord.

After you unplug and plug the power cord in while the unit is in standby mode and also the power is being

supplied to a terminal board, the unit will start supplying the power to the board with time delay according to the setting. The power indicator lights up red ﬁ rst and it turns orange when the power starts being supplied to the board.

Off: Not display the clock. On: Display the clock.

The clock is displayed at the lower left of the screen when Note: When “DAY/TIME SETUP” is not set, the clock is not displayed even if

Sets All Aspect mode (advanced aspect setting) or default aspect mode. With each press of

Off: Default aspect mode On: All Aspect mode

Aspect mode of each setting is as follows: (Example: HD signal)

Off 4:3→H-FILL→ZOOM→FULL→JUST On 4:3 (1)→4:3 (2)→4:3 Full→Zoom1→Zoom2→Zoom3→16:9→14:9→Just1→Just2

Sets the operational mode of the automatic position adjustment in the POS./SIZE menu.

Manual: Automatic position adjustment starts when is pressed on the remote control or automatic position

Auto: Other than remote control or menu operation, automatic position adjustment starts:

When the display power is turned ON. When the input signal is switched.

Off: Does not rotate the image. On: Rotates the image 180 degrees.

Whether to show/hide No activity power off Precautions at the time of power ON is set.

On: The warning precautions are shown at the time of power ON. Off: The warning precautions are not shown at the time of power ON. Note: This setting is enabled only if “NO ACTIVITY POWER OFF” is “ENABLE” (see page 47).

Whether to show/hide an information message that tells the power has been turned off by Power Management when the power is set to ON.

On: The information is shown at the time of power ON. Off: The information is not shown at the time of power ON. Note: This setting is enabled only if “PC POWER MANAGEMENT” or “DVI-D POWER MANAGEMENT” is

Auto On

regardless of the slot power setting.

1 2 3.... 30

to turn

is pressed.

: Set the power-on delay time (second).

, the display will be powered on with time delay depending on this setting.

button is pressed.

“Clock Display” is “On” (see page 35)

10:00

button, the aspect changes in the selected mode.

adjustment is executed from the POS./SIZE menu.

“ON” (see page 44).

Page 55

Options Adjustments

Normalization

When both main unit buttons and remote control are disabled due to the “Button lock” or “Remocon User level” adjustments, set all the values “Off” so that all the buttons are enabled again.

Press the

button on main unit together with button on the remote control and hold for more than 5 seconds. The

“Shipping” menu is displayed and the lock is released when it disappears.

Weekly Command Timer

You can set 7-day timer programming by setting time and command.

Note:

Before setting Weekly Command Timer, set DAY/TIME SETUP. (see page 35)

Press to select Function.

Press to select “On”.

Note:

• When Function is set to On, ON/OFF TIMER SETUP (see page 35) is unavailable and INTERVAL / TIME OF DAY in MODE of SCREENSAVER (see page 39) cannot be selected.

Press to select a day.

Press to select a program number.

Note:

• You can set the program from 1 to 7.

--- indicates unset.

Press to select Program Edit.

Press to show the Program Edit screen.

Press to select Program.

Press to change the program numbers (1-7).

Options

Weekly Command Timer

Audio input select

Touch Panel settings

Input Search

Onscreen display

Press ACTION ( ) button

Weekly Command Timer

Function

Monday Tuesday

Wednesday Thursday Friday Saturday Sunday

Program Edit

Program number

Thursday Friday Saturday Sunday

Program Edit

Program Edit screen

Weekly Command Timer

1/3

On Program1 Program3

---

Program3

---

Program6

Program4

Program3

---

Program6

Program4

1/8

--:--

PON

IMS:SL1

---

DAM:ZOOM

AVL:10

---

Program

01 02 03 04

05 06 07 08

8:00

10:30

12:00

9:12

Page 56

Options Adjustments

Press to select a command number.

Press to show the previous / next command pages (1-8) of the selected program.

Press to show the command setting screen.

Weekly Command Timer

Program

01 02 03 04 05 06 07 08

8:00

10:30

--:--

12:00

9:12

--:--

PON

IMS:SL1

---

DAM:ZOOM

AVL:10

---

Command (--- indicates unset)

Set time of timer (--:-- indicates unset)

Command numbers

Press to select Command No.

Press to select a command number.

1/8

Weekly Command Timer

Program

57 58 59 60 61 62 63 64

20:00

20:30 22:00

--:--

AVL :00

DAM:NORM

POF

---

8/8

Command setting screen

Weekly Command Timer

Command No

Time Command

Program

IMS:SL1

10:30

Press to select Time / Command.

Press to set each item. Time: Set the time to execute a command program. Pressing “ ” or “ ” button once changes “Time” 1

minute. Pressing “ ” or “ ” button continuously changes “Time” by 15 minutes. Command: Select a command to execute at the set time. This unit has 64 commands to set.

(see page 64)

Notes:

•

Command is performed in order of execution time, regardless of the command number.

• If a command execution time overlaps with that of other commands, these commands are

performed in number order.

• Pressing , Time becomes --:-- and Command becomes ---.

Note:

Press to return to the previous screen.

Weekly Command Timer

Program

Command No Time

Command

10:30

IMS:SL1

Page 57

Audio input select

Options Adjustments

Set up the sound when an image input is selected.

Options

Weekly Command Timer

Audio input select

Touch Panel settings

Input Search

Press ACTION ( ) button

Audio input select

Press to select image input.

Press to select audio input.

Image input Audio input

SLOT INPUT VIDEO COMPONENT HDMI DVI PC NETWORK WHITEBOARD

♪ SLOT INPUT ♪

AUDIO 1

♪

AUDIO 1

♪ HDMI

♪ AUDIO 2 ♪ AUDIO 2

♪ NETWORK

NO AUDIO

[SLOT INPUT]*1 SLOT INPUT / AUDIO 1 / AUDIO 2 / NETWORK / NO AUDIO [VIDEO] SLOT INPUT / AUDIO 1 / AUDIO 2 / NETWORK / NO AUDIO [COMPONENT]*2 SLOT INPUT / AUDIO 1 / AUDIO 2 / NETWORK / NO AUDIO [HDMI] SLOT INPUT / AUDIO 1 / HDMI / AUDIO 2 / NETWORK / NO AUDIO [DVI] SLOT INPUT / AUDIO 1 / AUDIO 2 / NETWORK / NO AUDIO [PC] SLOT INPUT / AUDIO 1 / AUDIO 2 / NETWORK / NO AUDIO [NETWORK] SLOT INPUT / AUDIO 1 / AUDIO 2 / NETWORK / NO AUDIO [WHITEBOARD] SLOT INPUT / AUDIO 1 / AUDIO 2 / NETWORK / NO AUDIO NO AUDIO: No audio input (Mute) *1 “SLOT INPUT” is displayed when a Terminal Board is installed. *2 “COMPONENT” may be displayed as “RGB” depending on the setting of “COMPONENT/RGB-IN SELECT”.

(see page 48)

1/3

When a Terminal Board with dual input terminals is installed

“SLOT INPUT” is displayed as “SLOT INPUT A” and “SLOT INPUT B” and independent settings are available. To set other image inputs, you can select “SLOT INPUT A” and “SLOT INPUT B”.

Image input Audio input

[SLOT INPUT A] SLOT INPUT A / AUDIO 1 / AUDIO 2 / NETWORK / NO AUDIO [SLOT INPUT B] SLOT INPUT B / AUDIO 1 / AUDIO 2 / NETWORK / NO AUDIO [VIDEO] SLOT INPUT A / SLOT INPUT B / AUDIO 1 / AUDIO 2 / NETWORK / NO AUDIO [COMPONENT] SLOT INPUT A / SLOT INPUT B / AUDIO 1 / AUDIO 2 / NETWORK / NO AUDIO [HDMI]

SLOT INPUT A / SLOT INPUT B / AUDIO 1 / HDMI / AUDIO 2 / NETWORK / NO AUDIO [DVI] SLOT INPUT A / SLOT INPUT B / AUDIO 1 / AUDIO 2 / NETWORK / NO AUDIO [PC] SLOT INPUT A / SLOT INPUT B / AUDIO 1 / AUDIO 2 / NETWORK / NO AUDIO [NETWORK] SLOT INPUT A / SLOT INPUT B / AUDIO 1 / AUDIO 2 / NETWORK / NO AUDIO [WHITEBOARD] SLOT INPUT A / SLOT INPUT B / AUDIO 1 / AUDIO 2 / NETWORK / NO AUDIO

When Image input and Audio input differ from each other, the Audio input is displayed as below.

FULL

COMPONENT

NANODRIFT

Notes:

• HDMI Audio is selectable only for HDMI Input.

• You cannot set audio of B for SLOT INPUT A, or audio of A for SLOT INPUT B.

Page 58

Options Adjustments

Touch Panel settings (Settings when using Touch Panel)

The mode to restrict NANODRIFT SAVER (see page 42) operation when using Touch Panel (available as an option) is set up.

Options

Weekly Command Timer

Audio input select

Touch Panel settings

1/3

Press ACTION ( ) button

Touch Panel settings

Touch Panel mode Calibration mode

Set “Touch Panel mode” to “On”.

select

adjust

Calibration mode

This setting is used in calibrating a touch panel. You can conﬁ gure the setting if “Touch Panel mode” is “On”.

Select “Calibration mode” and then press .

select

Touch Panel settings

Touch Panel mode Calibration mode

set

The screen is displayed in the middle and NANODRIFT is deactivated for 180 seconds.

Calibration mode

After 180 seconds or when you have the menu displayed with a remote control, Calibration mode is cancelled.

Note:

For information on how to set up Calibration, please see Touch Panel instruction manual.

When the menu is not displayed (normal screen)

Hold down for over 3 seconds.

Page 59

Input Search

When a signal is not detected, another input with a signal is automatically selected.

Options Adjustments

Options

Weekly Command Timer

Audio input select

Touch Panel settings

Input Search

Press ACTION ( ) button

Input Search

Primary Input Secondary Input

Input Search

Off: When there is no signal, the input is not switched automatically. All Inputs: Searches all inputs and switches to an input with a signal.

Priority: Searches “Primary Input” and “Secondary Input” in order and switches to an input with a signal.

SEARCHING...

1/3

select

adjust

Off

Input search is executed in the following order. (Example) When the current input is PC

PC VIDEO HDMI DVINETWORK COMPONENTSLOT INPUT

“SEARCHING...” is displayed during the input search.

Primary Input, Secondary Input

Set the input to search when “Priority” is selected.

(NONE) SLOT INPUT* VIDEO COMPONENT HDMI DVI PC NETWORK

* “SLOT INPUT” is displayed when an optional Terminal Board is installed.

When a Terminal Board with dual input terminals is installed, “SLOT INPUT A” and “SLOT INPUT B” are displayed.

Notes:

•

This menu is available only when “Input lock” is “Off”. (see page 53)

• If the input is changed by this function, the last input is selected when the power is turned on next time. If you wish to retain the original input when the power is turned on, set “Initial input” to the original input. (see page 52)

Page 60

Troubleshooting

Before you call for service, determine the symptoms and make a few simple checks as shown below.

Symptoms

Picture Sound

Interference Noisy Sound

Normal Picture No Sound

No Picture No Sound

No Picture Normal Sound

No Color Normal Sound

No remote control operations can be performed. Check whether the batteries have discharged completely and, if they have not, whether they

A cracking sound is sometimes heard from the unit. If there is nothing wrong with the picture or sound, this is the sound of the cabinet undergoing

The top or bottom of the picture on the screen is cut off when I use the zoom function.

Areas at the top and bottom of the screen where the image is missing appear when I use the zoom function.

I can hear sounds coming from inside the unit. When the power is turned on, a sound of the display panel being driven may be heard: This is

Parts of the unit become hot. Even when the temperature of parts of the front, top and rear panels has risen, these temperature

Power automatically turns off unexpectedly.

Power indicator is blinking in red. There is possibility of malfunction. Please contact an Authorized Service Center. This Plasma Display uses special image processing. Hence a slight time lag may occur between image and audio, depending on the type of input

signal. However, this is not a malfunction.

Electrical Appliances Cars / Motorcycles Fluorescent light

Volume (Check whether the mute function has been activated on the remote control.) Check if speakers are connected properly.

Not plugged into AC outlet Not switched on PICTURE and BRIGHTNESS/Volume setting (Check by pressing the power switch or stand-by button on the remote control.)

If a signal with a non-applicable color system format, or frequency is input, only the input terminal indication is displayed.

Color controls set at minimum level. (see page 27, 28) COLOR SYSTEM (see page 49)

were inserted properly. Check whether the remote control sensor is exposed to an outdoor light or a strong ﬂ uorescent light. Check whether the remote control designed speciﬁ cally for use with the unit is being used. (The unit cannot be operated by any other remote control.)

very slight contractions in response to changes in the room temperature. There are no adverse effects on the performance or other aspects.

Adjust the position of the picture on the screen.

When using a video software program (such as a cinema size program) with a screen wider than one in the 16:9 mode, blank areas separate from the images are formed at the top and bottom of the screen.

normal and not indicative of malfunctioning.

rises will not pose any problems in terms of performance or quality. Check the settings of “PC POWER MANAGEMENT”, “DVI-D POWER MANAGEMENT”, “NO

SIGNAL POWER OFF” and “NO ACTIVITY POWER OFF” in the SETUP menu. Any of them may be set to “ON (ENABLE)”. (see page 44, 47)

Checks

Plasma Display panel

Symptoms Check

The screen darkens slightly when bright pictures with minimal movements are shown.

It takes a while for the picture to appear.

The edges of the images ﬂ icker. Due to the characteristics of the system used to drive the panel, the edges may appear to ﬂ icker

The brightness on both sides of images in 4:3 mode changes.

Some parts of the screen do not light up. The plasma display panel is manufactured using an extremely high level of precision technology,

Image retention appears

Whirring sounds can be heard from the display unit. The display unit is ﬁ tted with a cooling fan to dissipate heat generated during normal use. The

The screen will darken slightly when photos, still images of a computer or other pictures with minimal movements are shown for an extended period. This is done to reduce image retention on the screen and the shortening of the screen’s service life: It is normal and not indicative of malfunctioning.

The unit digitally processes the various signals in order to reproduce esthetically pleasing images. As such, it sometimes takes a few moments for the picture to appear when the power has been turned on, when the input has been switched or when the images for the main picture and sub picture on the two screens are swapped.

in the fast-moving parts of the images: This is normal and not indicative of malfunctioning.

When viewing the side panels at the “BRIGHT” or “MID” setting, the brightness on both sides may change depending on the kind of program shown: This is normal and not indicative of malfunctioning.

however, sometimes some parts of the screen may be missing picture elements or have luminous spots. This is not a malfunction.

Note:

The permanent image retention on the Plasma Display resulting from ﬁ xed image use is not an operating defect and as such is not covered by the Warranty. This product is not designed to display ﬁ xed images for extended periods of time.

whirring sound is caused by rotation of the fan and is not a malfunction.

Page 61

List of Aspect Modes

Aspect mode

All Aspect: OnFactory setting

All Aspect: Off

16:9 FULL

14:9 –

Just

JUST

Just1

Just2 JUST

4:3

4:3 (1)


Enlarged screen

Description

The display of the pictures ﬁ lls the screen. In the case of SD signals, pictures with a 4:3 aspect ratio are enlarged horizontally, and displayed. This mode is suited to displaying anamorphic pictures with a 16:9 aspect ratio.

Letterbox pictures with a 14:9 aspect ratio are enlarged vertically and horizontally so that their display ﬁ lls the screen vertically and is slightly smaller than the screen horizontally. The top and bottom edges of the pictures are cut off. Side panels are displayed at the left and right edges of the screen.

Pictures with a 4:3 aspect ratio are enlarged horizontally so that the picture distortion is minimized. The display of the areas around the left and right edges of the screen is slightly elongated.

Pictures with a 4:3 aspect ratio are enlarged horizontally so that the picture distortion is minimized. The left and right edges of the pictures are cut off. The display of the areas around the left and right edges of the screen is slightly elongated.

Pictures with a 4:3 aspect ratio are displayed with their original aspect ratio. Side panels are displayed at the left and right edges of the screen.

4:3 (2) 4:3

4:3 Full H-FILL

Zoom

ZOOM

Zoom1

Zoom2 ZOOM

Zoom3 –

Pictures with a 4:3 aspect ratio are displayed with their original aspect ratio. The left and right edges of the pictures are masked by side panels.

Pictures with a 4:3 aspect ratio are enlarged horizontally so that their display ﬁ lls the screen. The left and right edges of the pictures are cut off.

Letterbox pictures with a 16:9 aspect ratio are enlarged vertically and horizontally so that their display ﬁ lls the screen. The top and bottom edges of the pictures are cut off.

Letterbox pictures with a 16:9 aspect ratio are enlarged vertically and horizontally so that their display ﬁ lls the screen. The top and bottom edges as well as the left and right edges of the pictures are cut off.

Letterbox pictures with a 2.35:1 aspect ratio are enlarged vertically and horizontally so that their display ﬁ lls the screen vertically and is slightly larger than the screen horizontally. The top and bottom edges as well as the left and right edges of the pictures are cut off.

Page 62

Applicable Input Signals

*Mark: Applicable input signal

Signal name

1 525 (480) / 60i 15.73 59.94 * (13.5) * (27.0) * 2 525 (480) / 60p 31.47 59.94 * (27.0) 3 625 (575) / 50i 15.63 50.00 * (13.5) 4 625 (576) / 50i 15.63 50.00 * (27.0) * 5 625 (575) / 50p 31.25 50.00 * (27.0) 6 625 (576) / 50p 31.25 50.00 * (27.0) * 7 750 (720) / 60p 45.00 60.00 * (74.25) * (74.25) * 8 750 (720) / 50p 37.50 50.00 * (74.25) * (74.25) *

9 1,125 (1,080) / 60p 67.50 60.00 * (148.5) 10 1,125 (1,080) / 60i 33.75 60.00 * (74.25) 11 1,125 (1,080) / 50p 56.26 50.00 * (148.5) 12 1,125 (1,080) / 50i 28.13 50.00 * (74.25) 13 1,125 (1,080) / 24sF 27.00 48.00 * (74.25) 14 1,125 (1,080) / 30p 33.75 30.00 * (74.25) 15 1,125 (1,080) / 25p 28.13 25.00 * (74.25) 16 1,125 (1,080) / 24p 27.00 24.00 * (74.25) 17 1,250 (1,080) / 50i 31.25 50.00 * (74.25) 18 2,048 × 1,080 / 24sF 19 2,048 × 1,080 / 24p 20 640 × 400 @70 Hz 31.46 70.07 * (25.17) 21 640 × 480 @60 Hz 31.47 59.94 * (25.18) ∗6 * (25.18) * 22 640 × 480 @72 Hz 37.86 72.81 * (31.5) 23 640 × 480 @75 Hz 37.50 75.00 * (31.5) 24 640 × 480 @85 Hz 43.27 85.01 * (36.0) 25 800 × 600 @56 Hz 35.16 56.25 * (36.0) 26 800 × 600 @60 Hz 37.88 60.32 * (40.0) * (40.0) * 27 800 × 600 @72 Hz 48.08 72.19 * (50.0) 28 800 × 600 @75 Hz 46.88 75.00 * (49.5) 29 800 × 600 @85 Hz 53.67 85.06 * (56.25) 30 852 × 480 @60 Hz 31.47 59.94 * (33.54) 31 1,024 × 768 @50 Hz 39.55 50.00 * (51.89) * 32 1,024 × 768 @60 Hz 48.36 60.00 * (65.0) * (65.0) * 33 1,024 × 768 @70 Hz 56.48 70.07 * (75.0) 34 1,024 × 768 @75 Hz 60.02 75.03 * (78.75) 35 1,024 × 768 @85 Hz 68.68 85.00 * (94.5) 36 1,066 × 600 @60 Hz 37.64 59.94 * (53.0) * (53.0) * 37 1,152 × 864 @60 Hz 53.70 60.00 * (81.62) * 38 1,152 × 864 @75 Hz 67.50 75.00 * (108.0) 39 1,280 × 768 @60 Hz 47.70 60.00 * (80.14) 40 1,280 × 800 @60 Hz (1) 49.31 59.91 * (71.0) * (71.0) * 41 1,280 × 800 @60 Hz (2) 49.70 59.81 * (83.5) * (83.5) * 42 1,280 × 960 @60 Hz 60.00 60.00 * (108.0) 43 1,280 × 960 @85 Hz 85.94 85.00 * (148.5) 44 1,280 × 1,024 @60 Hz 63.98 60.02 * (108.0) * (108.0) * 45 1,280 × 1,024 @75 Hz 79.98 75.03 * (135.0) 46 1,280 × 1,024 @85 Hz 91.15 85.02 * (157.5) 47 1,366 × 768 @50 Hz 39.55 50.00 * (69.92) * 48 1,366 × 768 @60 Hz 48.36 60.00 * (86.71) * (87.44) * 49 1,400 × 1,050 @60 Hz 65.22 60.00 * (122.61) * 50 1,440 × 900 @60 Hz (1) 55.47 59.90 * (88.75) * (88.75) * 51 1,440 × 900 @60 Hz (2) 55.93 59.89 * (106.5) * (106.5) * 52 1,600 × 1,200 @60 Hz 75.00 60.00 * (162.0) * (162.0) * 53 1,600 × 1,200 @65 Hz 81.25 65.00 * (175.5) 54 1,920 × 1,080 @60 Hz 67.50 60.00 * (148.5) 55 1,920 × 1,200 @60 Hz 74.04 59.95 * (154.0) * 56 Macintosh13” (640 × 480) 35.00 66.67 * (30.24) 57 Macintosh16” (832 × 624) 49.72 74.54 * (57.28) 58 Macintosh21” (1,152 × 870) 68.68 75.06 * (100.0)

Based on SMPTE 274M standard.

∗

Based on SMPTE 295M standard.

∗

5: When selected the RGB format and 525p signal input to the PC IN terminal, it is recognized as VGA 60Hz signal.

∗

When inputted VGA 60Hz format signal from the other than

∗

Based on SMPTE 292M and 372M standards. These signals can be received when the Dual Link HD-SDI Terminal Board

∗

Horizontal frequency

7 27.00 48.00

∗

7 27.00 24.00

∗

(kHz)

Vertical frequency

(Hz)

Based on SMPTE RP211 standard.

∗

The input signal is recognized as 1,125 (1,080) / 60p.

∗

PC IN

COMPONENT / RGB IN / PC IN

(Dot clock (MHz))

5 * (27.0) *

∗

1 * (148.5) *

∗

1 * (74.25) *

∗

1 * (148.5) *

∗

1 * (74.25) *

∗

1 * (74.25)

∗

1 * (74.25)

∗

1 * (74.25) *

∗

4 * (148.5) *

∗

terminal, it is recognized as 525p signal.

(TY-FB11DHD) is installed.

Note: Signals without above speciﬁ cation may not be displayed properly.

DVI-D IN

(Dot clock (MHz))

(34.24) *

HDMI

Page 63

Video input (VIDEO)

Signal name

1 NTSC 15.73 59.94

2 PAL 15.63 50.00

3 PAL60 15.73 59.94

4 SECAM 15.63 50.00

5 Modiﬁ ed NTSC 15.73 59.94

Horizontal Vertical

frequency(kHz) frequency(Hz)

Shipping condition

This function allows you to reset the unit to the factory setting.

Applicable Input Signals

Press to display the SETUP menu.

Press to select “OSD LANGUAGE”.

Press for more than 3 seconds.

Press to select “Shipping”.

Press to display the Shipping menu.

Press to select “YES”.

Press to conﬁ rm.

Wait for 10 seconds.

Press the power switch ( ) on main unit to turn the power off.

SETUP

TOUCH-PEN SETTINGS

MULTI PIP SETTINGS

SIGNAL

SCREENSAVER

EXTENDED LIFE SETTINGS

ECO MODE SETTINGS

INPUT LABEL

FUNCTION BUTTON SETTINGS

COMPONENT/RGB-IN SELECT

NO ACTIVITY POWER OFF MENU DISPLAY DURATION OSD BRIGHTNESS OSD LANGUAGE ENGLISH (US

Options

Shipping

YES NO

RGB

DISABLE

30 S

1/2

)

[from the unit]

1 Press the MENU button till the SETUP menu is displayed. 2 Press the Volume Up “+” or Down “–” button to select “OSD LANGUAGE”. 3 Press and hold the ENTER button till the Shipping menu is displayed. 4 Press the Volume Up “+” or Down “–” button to select “YES”. 5 Press the ENTER button and wait for 10 sec. 6 Press the power switch ( ) on main unit to turn the power off.

Page 64

Command list of Weekly Command Timer

No. Command Control details

1 AAC:MENCLR Audio Menu (CLEAR) 2 AAC:MENDYN Audio Menu (DYNAMIC) 3 AAC:MENSTD Audio Menu (STANDARD) 4 AAC:SURMON Surround (ON) 5 AAC:SUROFF Surround (OFF) 6 AMT:0 Audio Mute (OFF) 7 AMT:1 Audio Mute (ON) 8

ASO:M Audio out when PIP mode (Main Picture)

9 ASO:S Audio out when PIP mode (Sub Picture)

10 AVL:00 Audio Volume (00)

11 AVL:10 Audio Volume (10) 12 AVL:20 Audio Volume (20) 13 AVL:30 Audio Volume (30) 14 AVL:40 Audio Volume (40) 15 AVL:50 Audio Volume (50) 16 AVL:60 Audio Volume (60) 17 DAM:FULL Aspect (FULL) 18 DAM:JUST Aspect (JUST) 19 DAM:NORM Aspect (4:3) 20 −− 21 DAM:ZOOM Aspect (ZOOM) 22

DWA:OFF Dual Picture mode (OFF)

ISS:SL1 Sub Picture Input Select (SLOT INPUT) 24 ISS:NW1 Sub Picture Input Select (NETWORK) 25 IMS:WB1 Input select (WHITEBOARD) (Main Picture when PIP mode) 26 −− 27 −− 28 −− 29 −− 30 −− 31

DWA:PIN0 The location of the sub picture (lower right) 32 DWA:PIN1 The location of the sub picture (lower left) 33

DWA:PIN2 The location of the sub picture (upper left) 34

DWA:PIN3 The location of the sub picture (upper right) 35

DWA:PIP Dual Picture mode (Picture in Picture) 36 −− 37

DWA:SWP Swap main picture and sub picture when PIP mode 38 −− 39

IMS:SL1 Input select (SLOT INPUT) (Main Picture when PIP mode) 40 IMS:S1A Input select (SLOT INPUT A) (Main Picture when PIP mode) 41

IMS:S1B Input select (SLOT INPUT B) (Main Picture when PIP mode) 42

IMS:VD1 Input select (VIDEO) (Main Picture when PIP mode) 43 IMS:YP1 Input select (COMPONENT) (Main Picture when PIP mode) 44 IMS:HM1 Input select (HDMI) (Main Picture when PIP mode) 45

IMS:DV1 Input select (DVI) (Main Picture when PIP mode) 46

IMS:PC1 Input select (PC) (Main Picture when PIP mode) 47 IMS:NW1 Input select (NETWORK) (Main Picture when PIP mode) 48 ISS:S1A Sub Picture Input Select (SLOT INPUT A) 49

ISS:S1B Sub Picture Input Select (SLOT INPUT B) 50

ISS:VD1 Sub Picture Input Select (VIDEO) 51 ISS:YP1 Sub Picture Input Select (COMPONENT) 52

ISS:HM1 Sub Picture Input Select (HDMI) 53

ISS:DV1 Sub Picture Input Select (DVI) 54

ISS:PC1 Sub Picture Input Select (PC)

OSP:SCR0 Screen Saver SCROLLING BAR ONLY (OFF)

OSP:SCR1 Screen Saver SCROLLING BAR ONLY (ON)

56 57 POF Power OFF 58 PON Power ON

SSC:FNC0 Screen Saver function (SCROLLING BAR ONLY)

SSC:FNC1 Screen Saver function (NEGATIVE IMAGE)

SSC:MOD0 Screen Saver (Mode (OFF))

SSC:MOD3 Screen Saver (Mode (ON))

62 63 64

Picture Mute cannot be unlocked by powering off/on with the remote control. Turn off and on again with the button on

∗

the unit or enter the command VMT:0 to unlock Picture Mute.

VMT:0

VMT:1

∗ ∗

Picture Mute (OFF) Picture Mute (ON)

Page 65

Speciﬁ cations

TH-50PB2U TH-65PB2U Power Source Power Consumption

Rated Power Consumption 400 W 550 W

Stand-by condition 0.4 W 0.4 W

Power off condition 0.2 W 0.2 W

Plasma Display panel

Screen size

(No.of pixels) 2,073,600 (1,920 (W) × 1,080 (H))

Operating condition

Temperature 32 °F - 104 °F (0 °C - 40 °C)

Humidity 20 % - 80 %

Applicable signals

Color System NTSC, PAL, PAL60, SECAM, Modiﬁ ed NTSC

Scanning format 525 (480) / 60i · 60p, 625 (575) / 50i · 50p, 750 (720) / 60p · 50p, 1125 (1080) / 60i · 60p · 50i · 50p

· 24p · 25p · 30p · 24sF, 1250 (1080) / 50i

PC signals VGA, SVGA, XGA, SXGA

Connection terminals

AV IN

COMPONENT/RGB IN

DVI-D IN

PC IN

SERIAL

PEN ADAPTER For electronic pen adapter

MEMORY/(CHARGE) For USB memory/electronic pen charging

CHARGE For electronic pen charging

WIRELESS MODULE for Wireless module (ET-WM200U)

EXT SP

Sound

Speakers

Audio Output

Dimensions (W × H × D)

Mass (weight)

main unit only

VIDEO

AUDIO 1 IN

HDMI TYPE A Connector

Y/G

B/CB/B

R/CR/R

AUDIO 1 IN

AUDIO 2 IN

LAN RJ45 10BASE-T/100BASE-TX, compatible with PJLink™

BNC Stereo mini jack (M3) × 1

BNC BNC BNC

Stereo mini jack (M3) × 1

DVI-D 24 Pin Content Protection Stereo mini jack (M3) × 1

High-Density Mini D-sub 15 Pin

Stereo mini jack (M3) × 1 External Control Terminal

D-sub 9 Pin RS-232C compatible

47.7” (1,210 mm) × 28.5” (724 mm) × 3.5” (89 mm) 61.2” (1,554 mm) × 36.5” (925 mm) × 3.9” (99 mm)

Drive method : AC type 50-inch,

16:9 aspect ratio

43.5” (1,105 mm) (W) × 24.4” (622 mm) (H) × 49.9” (1,268 mm) (diagonal)

Horizontal scanning frequency 15 - 110 kHz

6 Ω, 16 W [8 W + 8 W] (10 % THD) 8 Ω, 20 W [10 W + 10 W] (10 % THD)

approx. 75.0 lbs approx. 127.9 lbs

110 - 127 V AC, 50/60 Hz

Drive method : AC type 65-inch,

56.4” (1,434 mm) (W) × 31.7” (806 mm) (H)

[5,760 × 1,080 dots]

UXGA ···· (compressed)

Vertical scanning frequency 48 - 120 Hz

1.0 Vp-p (75 Ω)

0.5 Vrms, Shared with COMPONENT/RGB IN

with sync 1.0 Vp-p (75 Ω)

0.7 Vp-p (75 Ω)

0.5 Vrms, Shared with VIDEO Compliance with DVI Revision 1.0

Compatible with HDCP 1.1

0.5 Vrms, Shared with PC IN Y or G with sync 1.0 Vp-p (75 Ω)

Y or G without sync 0.7 Vp-p (75 Ω) P

/B: 0.7 Vp-p (75 Ω)

B/CB

PR/CR/R: 0.7 Vp-p (75 Ω) HD/VD: 1.0 - 5.0 Vp-p (high impedance)

0.5 Vrms, Shared with DVI-D IN

4.8” (120 mm) × 1.6” (40 mm) × 2 pcs

20 W [10 W + 10 W] (10 % THD)

16:9 aspect ratio

× 64.7” (1,645 mm) (diagonal)

Note:

Design and speciﬁ cations are subject to change without notice. Mass and dimensions shown are approximate.

Page 66

This product incorporates the following software:

(1) the software developed independently by or for Panasonic Corporation, (2) the software owned by third party and licensed to Panasonic Corporation, (3) the software licensed under the GNU General Public License, Version 2.0 (GPL-2.0), (4) the software licensed under the GNU LESSER General Public License, Version 2.1 (LGPL-2.1) and/or, (5) open source software licensed under the MIT License. (6) open source software other than the software licensed under the GPL and/or LGPL.

For the software categorized as (3) and (4), please refer to the terms and conditions of GPL-2.0 and LGPL-2.1, as the case may be at http://www.gnu.org/licenses/old-licenses/gpl-2.0.html and http://www.gnu.org/licenses/old-licenses/lgpl-2.1.html

The GPL/LGPL/MIT software is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY, without even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.

At least three (3) years from delivery of products, Panasonic will give to any third party who contact us at the contact information provided below, for a charge no more than our cost of physically performing source code distribution, a complete machine-readable copy of the corresponding source code and the copyright notice, covered under GPL-2.0/ LGPL-2.1. Contact Information [email protected]

For the software categorized as (6) includes as follows.

1. The software developed by the OpenSSL Project for use in the OpenSSL Toolkit. (http://www.openssl.org/)

2. The software developed by the University of California, Berkeley and its contributors.

3. FreeType code.

4. The Independent JPEG Group's JPEG software.

5. thttpd code.

USA Only:

Disposal may be regulated in your community due to environmental considerations. For disposal or recycling information, please visit Panasonic website: http://www.panasonic.com/environmental or call 1-888-769-0149.

Customer’s Record

The model number and serial number of this product can be found on its back cover. You should note this serial number in the space provided below and retain this book, plus your purchase receipt, as a permanent record of your purchase to aid in identiﬁ cation in the event of theft or loss, and for Warranty Service purposes.

Model Number Serial Number

Panasonic Corporation 2013

Panasonic System Communications Company of North America

Unit of Panasonic Corporation of North America

Executive Ofﬁ ce :

Three Panasonic Way 2F-5, Secaucus, NJ 07094

Panasonic Canada Inc.

5770 Ambler Drive Mississauga, Ontario L4W 2T3
