Model No.
Número de modelo
TC-P60ST30
TC-P65ST30
Owner’s Manual
60”/65” Class 1080p Plasma HDTV
(60.1/64.7 inches measured diagonally)
Manual de usuario
Televisión de alta definición de 1080p y clase 60”/65” de Plasma
(60,1/64,7 pulgadas medidas diagonalmente)
For assistance (U.S.A./Puerto Rico), please call:
1-877-95-VIERA (958-4372) www.panasonic.com/help
For assistance (Canada), please call:
1-866-330-0014 www.vieraconcierge.ca
Para solicitar ayuda (EE.UU./Puerto Rico), llame al:
1-877-95-VIERA (958-4372) www.panasonic.com/help
English
Español
Thank you for purchasing this Panasonic product.
Please read these instructions before operating your set and retain them for future reference. The images shown in this manual are for illustrative purposes only.
Gracias por su decisión de comprar este producto marca Panasonic. |
|
Lea estas instrucciones antes de utilizar su televisor y guárdelas para consultarlas en |
|
el futuro. Las imágenes mostradas en este manual tienen solamente fines ilustrativos. |
TQB2AA0609-2 |
Experience an amazing level of multimedia excitement
Enjoy rich multimedia
SD memory card
USB device
Camcorder
VCR
Cable box
Amplifier with
Speaker system
DVD player/
Blu-ray Disc player
DVD recorder/
Blu-ray Disc recorder
■Do not display a still picture for a long time
This causes the image to remain on the plasma screen
(“Image retention”). This is not considered a malfunction and is not covered by the warranty.
12
4 : 3
To prevent the “Image retention”, the screen saver is automatically activated after a few minutes if no signals are sent or no operations are performed.
Typical still images
●Channel number and other logos |
|
|
●Image displayed in 4:3 mode |
●Computer image |
|
●SD Card photo |
●Video game |
■Set up
●Do not place the unit where it’s exposed to sunlight or other bright light (including reflections).
●Use of some types of fluorescent lighting may reduce the remote control’s transmission range.
2
VIERA Link™ is a trademark of
Panasonic Corporation.
HDMI, the HDMI logo and HighDefinition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
SDXC Logo is a trademark of SD3C, LLC.
“AVCHD” and the “AVCHD” logo are trademarks of Panasonic Corporation and Sony Corporation.
“RealD 3D” is a trademark of RealD. This product is covered by U.S. Patent 5,193,000 until August 28, 2011.
DLNA®, the DLNA Logo and DLNA CERTIFIED™ are trademarks, service marks, or certification marks of the Digital Living Network Alliance.
QuickTime and the QuickTime logo are trademarks or registered trademarks of Apple Inc., used under license therefrom.
Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.
HDAVI Control™ is a trademark of Panasonic Corporation.
Skype™ is a trademark of Skype limited.
TM
This product is licensed under the AVC patent portfolio license for the personal and non-commercial use of a consumer to (i) encode video in compliance with the AVC Standard (“AVC Video”) and/or (ii) decode AVC Video that was encoded by a consumer engaged in a personal and non-commercial activity and/or was obtained from a video provider licensed to provide AVC Video. No license is granted or shall be implied for any other use. Additional information may be obtained from MPEG LA, LLC.
See http://www.mpegla.com.
●See page 63 for more information.
Contents
Please read before using the unit |
|
||
• Safety Precautions··········································4 |
|
||
Getting started |
Getting |
||
• |
Accessories/Optional Accessories··················8 |
||
• |
Connections·················································· 11 |
started |
|
• |
Identifying Controls·······································13 |
||
• |
First Time Setup············································14 |
|
|
|
|
||
Basic Features |
|
||
|
|||
• |
Watching TV ·················································19 |
|
|
• |
Using VIERA TOOLS····································22 |
Basic |
|
• |
Watching content from external devices·······23 |
||
• |
Viewing 3D images on TV ····························24 |
||
• |
Using Media player·······································26 |
|
|
Advanced Features |
|
||
|
|||
|
|||
• |
VIERA LinkTM “HDAVI ControlTM”····················32 |
|
|
|
Using Network services ································38 |
|
|
•• Network Connections··································39 |
|
||
|
• Network settings ·········································40 |
Advanced |
|
|
• VIERA Connect (Enjoy Internet Service) ····43 |
||
|
• Using DLNA feature ····································44 |
||
• |
• Network Camera·········································45 |
||
Editing and Setting Channels ·······················46 |
|||
|
How to Use Menu Functions·························48 |
||
•• Picture settings ···········································49 |
|||
|
• Audio settings ·············································51 |
|
|
|
• Timer settings ·············································51 |
|
|
|
• Lock ····························································52 |
|
|
|
• Closed caption ············································52 |
|
|
|
• Setup ··························································53 |
|
|
Support Information |
|
||
Support |
|||
• |
Ratings List for parental control····················54 |
||
• |
Technical Information····································55 |
||
• |
Care and Cleaning········································58 |
||
• |
Frequently Asked Questions (FAQ) ··············59 |
Information |
|
• |
Customer Services Directory |
||
• |
Specifications················································62 |
|
|
• |
Index·····························································64 |
|
|
• |
Limited Warranty |
|
|
|
(for U.S.A. and Puerto Rico only) ·················65 |
|
|
• |
(for U.S.A. and Puerto Rico)·························66 |
|
|
Limited Warranty (for Canada) ·····················67 |
|
||
|
3
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: To reduce the risk of electric shock, do not remove cover or back. No user-serviceable parts inside. Refer servicing to qualified service personnel.
The lightning flash with arrowhead within a triangle is intended to tell the user that parts inside the product are a risk of electric shock to persons.
The exclamation point within a triangle is intended to tell the user that important operating and servicing instructions are in the papers with the appliance.
WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. Do not place liquid containers (flower vase, cups, cosmetics, etc.) above the set
(including on shelves above, etc.).
Important Safety Instructions
1)Read these instructions.
2)Keep these instructions.
3)Heed all warnings.
4)Follow all instructions.
5)Do not use this apparatus near water.
6)Clean only with dry cloth.
7)Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8)Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
9)Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10)Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
11)Only use attachments / accessories specified by the manufacturer.
12)Use only with the cart, stand, tripod,
bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart / apparatus combination to avoid injury from tip-over.
13)Unplug this apparatus during lightning storms or when unused for long periods of time.
14)Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
15)To prevent electric shock, ensure the grounding pin on the AC cord power plug is securely connected.
WARNING/CAUTION (TV set)
WARNING
Small parts can present choking hazard if accidentally swallowed.
Keep small parts away from young children. Discard unneeded small parts and other objects,
including packaging materials and plastic bags/sheets to prevent them from being played with by young children, creating the potential risk of suffocation.
■Set up
This Plasma TV may fall and can cause personal injury or even death if not installed correctly. To prevent personal injury or death, follow these warnings:
●Install the Plasma TV in accordance with the manufacturer’s recommended pedestal or stand, corresponding hardware and installation instructions.
This Plasma TV is for use only with the following optional accessories. Use with any other type of optional
accessories may cause instability. The following accessories are manufactured by Panasonic Corporation.
•Wall-hanging bracket (Angled)
TY-WK5P1RW (TC-P60ST30)
TY-WK6P1RW (TC-P65ST30)
●Be sure to ask a qualified technician to carry out the installation and set-up.
Two or more people are required to install or remove the television.
●Some wall mounts (wall-hanging brackets) are not designed to be mounted to walls with steel studs or old cinder block constructions.
Ask your dealer or licensed contractor to properly secure the wall-hanging bracket.
●Do not route the TV’s power cord inside the wall.
The power cord was not designed for in-wall mounting. Doing so can lead to fire hazard.
●Do not place the Plasma TV or its stand on a sloped or unstable surface.
The Plasma TV may fall or tip over.
●Do not support the Plasma TV on a non-specified pedestal.
●Do not place the Plasma TV on furniture that can easily be used as steps, such as a chest of drawers.
●Do not climb or allow children to climb on the Plasma TV
●Place or install the Plasma TV where it cannot be pushed, pulled over or knocked down.
●Route all cords and cables such that they cannot be tripped over or pulled by curious children.
4
●Do not place any objects on top of the Plasma TV.
If water spills onto the Plasma TV or foreign objects get inside it, a short-circuit may occur which could result in fire or electric shock. If any foreign objects get inside the Plasma TV, please consult an Authorized Service Center. In the unlikely event that you receive a shock from this product it is possible that your household outlet may be wired improperly. Have an electrician verify that the TV’s outlet is properly wired. If the symptom persists, have the TV serviced by a qualified authorized technician.
●To prevent the spread of fire, keep candles or other open flames away from this product at all times
■AC Power Supply Cord
To prevent fire or electric shock:
●The Plasma TV is designed to operate on a 120 V AC, 60 Hz service. Insert the power cord plug as far as it will go into the wall socket.
If the plug is not fully inserted, heat may generate, which could cause a fire.
●The included power cord is for use with this unit only.
●Do not use any power cord other than that provided with this TV.
●Do not handle the power cord plug with wet hands.
●Do not do anything that might damage the power supply cord.
●When disconnecting the power supply cord, hold the plug, not the cord.
●Do not use the power supply cord if the plug or cord is damaged.
Replace the cord or contact your Authorized Service Center.
●Do not use a 3-prong to 2-prong AC plug adapters to connect your TV’s plug to the wall outlet.
Doing so will defeat the TV plug’s safety feature, which can lead to a shock hazard. If the wall outlet does not accommodate a 3-prong plug, have a qualified electrician replace your outlet and check the associated wiring.
■Handling the power supply cord
●Insert the power plug fully into the socket outlet. (If the power plug is loose, it could generate heat and cause fire.)
●Ensure that the power plug is easily accessible.
●Ensure the earth pin on the power plug is securely connected to prevent electrical shock.
•An apparatus with CLASS I construction shall be connected to a power socket outlet with a protective earthing connection.
●Do not touch the power plug with a wet hand. (This may cause electrical shock.)
●Do not use any power cord other than that provided with this TV. (This may cause fire or electrical shock.)
●Do not damage the power cord. (A damaged cord may cause fire or electrical shock.)
•Do not move the TV with the cord plugged in the socket outlet.
•Do not place a heavy object on the cord or place the cord near a high-temperature object.
•Do not twist the cord, bend it excessively, or stretch it.
•Do not pull on the cord. Hold onto the power plug body when disconnecting cord.
•Do not use a damaged power plug or socket outlet.
●If a problem occurs (such as no picture or no sound), or if smoke or an abnormal odor is detected from the Plasma TV, unplug the power supply cord immediately.
Continued use of the TV under these conditions might cause a fire or permanent damage to the TV. Have the TV evaluated by an Authorized Service Center. Servicing of the TV by unauthorized personnel is strongly discouraged due to its high voltage.
●If water or an object gets inside the Plasma TV, if the Plasma TV is dropped, or if the enclosure becomes damaged, unplug the power supply cord immediately.
A short-circuit may occur, which could cause a fire. Contact an Authorized Service Center for an evaluation.
CAUTION
●Do not cover the ventilation holes.
Doing so may cause the Plasma TV to overheat, which can cause a fire or damage to the Plasma TV.
●Leave a space of 3 15/16” (10 cm) or more at the top, left and right, and 2 3/4” (7 cm) or more at the rear.
●When using the pedestal, keep the space between the bottom of the TV and the pedestal or stand surface clear from objects that may obstruct ventilation.
■When Moving the Plasma TV
●Be sure to disconnect all cables before moving the Plasma TV.
Moving the TV with its cables attached might damage the cables which, in turn, can cause fire or electric shock.
●To prevent an electric shock, disconnect the power plug from the wall outlet as a safety precaution before carrying out any cleaning.
●Transport only in upright position.
Transporting the unit with its display panel facing upright or downward may cause damage to the internal circuitry.
●Using a dry cloth, clean any dust from the power supply cord and plug regularly.
Build-up of dust on the power cord plug can increase humidity, which might damage the insulation and cause a fire.
This Plasma TV radiates infrared rays;
therefore, it may affect other infrared communication equipment. Install your infrared sensor in a place away from direct or reflected light from your Plasma TV.
The TV will still consume some power as long as the power supply cord is connected to the wall outlet.
●Display panel is made of glass. Do not apply strong force or impact to the display panel.
This may cause damage resulting in injury.
●The TV is heavy. TV should be handled by 2 or more people. Support as shown to avoid injury by the TV tipping or falling.
5
WARNING/CAUTION (3D Eyewear)
WARNING
■About Prevention of Accidental Ingestion
●Do not store batteries, the band accessory or nose pads in places where small children can reach.
There is a danger small children could swallow such parts by mistake.
•If a child accidentally swallows such parts, seek immediate medical attention.
■About Prohibition of Disassembly
●Do not disassemble or modify the 3D Eyewear.
■About lithium battery
●Batteries must not be exposed to excessive heat such as sunshine, fire or the like.
CAUTION
■About 3D Eyewear
●Do not drop, exert pressure on, or step on the 3D Eyewear.
Doing so may damage the glass section, which may result in injury.
•Always store the 3D Eyewear in the case provided when not in use.
●Be careful of the tips of the frame when putting on the 3D Eyewear.
Accidentally inserting the tip of the frame into the eye may cause injury.
●Be careful not to trap a finger in the hinge section of the 3D Eyewear.
Doing so may result in injury.
•Pay special attention when children are using this product.
■About Use of 3D Eyewear
●Parents/guardians should monitor children’s viewing habits to avoid their prolonged use without rest periods.
●Use only the 3D Eyewear recommended for this TV.
●Only use the 3D Eyewear for the specified purpose.
●Do not move around while wearing the 3D Eyewear.
The surrounding area appears dark, which may result in falling or other accidents that may cause injury.
■About Viewing of 3D Images
●In the event that you experience dizziness, nausea, or other discomfort while viewing 3D images, discontinue use and rest your eyes.
•When you set the effect by using “3D adjustment”, take into account that the vision of 3D images varies among different individuals.
●Do not use if the 3D Eyewear is cracked or broken.
■About lithium battery
●Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type.
CEA CHILD SAFETY NOTICES
WARNING
Flat panel displays are not always supported on the proper stands or installed according to the manufacturer’s
recommendations. Flat panel displays that are inappropriately situated on dressers, bookcases, shelves, desks, speakers, chests or carts may fall over and may cause personal injury or even death.
The consumer electronics industry (of which Panasonic is a member) is committed to making home entertainment enjoyable and safe. To prevent personal injury or death, be sure to follow the following safety guidelines:
TUNE INTO SAFETY:
•One size does NOT fit all. Follow the manufacturer’s recommendations for the safe installation and use of your flat panel display.
•Carefully read and understand all enclosed instructions for proper use of this product.
•Don’t allow children to climb on or play with furniture and television sets.
•Don’t place flat panel displays on furniture that can easily be used as steps, such as a chest of drawers.
•Remember that children can become excited while watching a program, especially on “larger than life” flat panel displays. Care should be taken to install the display where it cannot be pushed, pulled over, or knocked down.
•Care should be taken to route all cords and cables connected to the flat panel display so that they cannot be pulled or grabbed by curious children.
WALL MOUNTING: IF YOU DECIDE TO WALL MOUNT YOUR FLAT PANEL DISPLAY, ALWAYS:
•Use a mount that has been recommended by the display manufacturer and/or listed by an independent laboratory (such as UL, CSA, ETL).
•Follow all instructions supplied by the display and wall mount manufacturers.
•If you have any doubts about your ability to safely install your flat panel display, contact your retailer about professional installation.
•Make sure the wall where you are mounting the display is appropriate. Some wall mounts are not designed to be mounted to walls with steel studs or old cinder block construction. If you are unsure, contact a professional installer.
•A minimum of two people are required for installation. Flat panel displays can be heavy.
Panasonic recommends that a qualified installer perform the wall-mount installation. See page 4.
The American Academy of Pediatrics discourages television viewing for children younger than two years of age.
6
FCC STATEMENT
This equipment has been tested and found to comply with the limits for an Other Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the Panasonic Service Center or an experienced radio/TV technician for help.
FCC Caution:
To assure continued compliance, follow the attached installation instructions and use only shielded interface cables when connecting to peripheral devices. Any changes or modifications not expressly approved by Panasonic Corp. of North America could void the user’s authority to operate this device.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
Responsible Party: |
Panasonic Corporation of North America |
|
One Panasonic Way, Secaucus, NJ 07094 |
Contact Source: |
Panasonic Consumer Electronics Company |
|
1-877-95-VIERA (958-4372) |
email: |
consumerproducts@panasonic.com |
This device complies with Part 15 of FCC Rules and RSS-Gen of IC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation of this device.
This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter. This product is restricted to indoor use due to its operation in the 5.15 to 5.25 GHz frequency range.
FCC and IC require this product to be used indoors for the frequency range 5.15 to 5.25 GHz to reduce the potential for harmful interference to co-channel Mobile Satellite systems. High power radars are allocated as primary users of the 5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. These radar stations can cause interference with and/or damage this product.
The available scientific evidence does not show that any health problems are associated with using low power wireless devices. There is no proof, however, that these low power wireless devices are absolutely safe.
Low power Wireless devices emit low levels of radio frequency energy (RF) in the microwave range while being used. Whereas high levels of RF can produce health effects (by heating tissue), exposure to low-level RF that does not produce heating effects causes no known adverse health effects.
Many studies of low-level RF exposures have not found any biological effects. Some studies have suggested that some biological effects might occur, but such findings have not been confirmed by additional research.
Product Identification Marking is located on the bottom of the Wireless LAN Adapter.
CANADIAN NOTICE:
For Model TC-P60ST30, TC-P65ST30
This Class B digital apparatus complies with Canadian ICES-003.
7
Accessories
Check you have all the items shown.
Accessories
Remote Control |
Batteries for the |
AC cord |
Transmitter |
Remote Control |
|
N2QAYB000571 |
Transmitter (2) |
|
|
AA Battery |
|
|
|
Wireless LAN Adapter (p. 39) |
|
|
N5HBZ0000055 K2KYYYY00150 |
|
Pedestal |
|
|
TBL5ZX0042 (TC-P60ST30) |
TBL5ZX0170 (TC-P65ST30) |
Owner’s Manual |
|
|
Quick start guide |
|
|
Child safety |
How to assemble |
|
Product Registration Card (U.S.A.) |
(p. 9) |
|
Optional Accessories Please contact your nearest Panasonic dealer to purchase the recommended Optional accessories. For additional details, please refer to the Optional
accessories installation manual.
3D Eyewear
(Rechargeable type) |
• Product information (Model No. and release date etc.) is subject to change without notice. |
|
●TY-EW3D2S |
●TY-EW3D2M |
• For more product information |
●TY-EW3D2L |
|
(USA) http://www.panasonic.com (Canada) http://panasonic.ca |
(Global reference) http://panasonic.net/avc/viera/3d/
Communication Camera
●TY-CC10W
•This camera can be used on VIERA Connect.
•For details, read the manual of the Communication Camera.
Wall-hanging bracket |
|
|
●TY-WK5P1RW (for 60”) |
●TY-WK6P1RW (for 65”) |
Rear of the TV |
|
|
a |
|
|
b |
a: 19.7” (500 mm) |
a: 26.9” (684 mm) |
Holes for wall-hanging |
b: 11.8” (300 mm) |
b: 11.8” (300 mm) |
|
|
|
bracket installation |
Screw for fixing the TV onto the wall-hanging bracket (not supplied with the TV)
Depth of screw: minimum 0.67” (17.0 mm),
maximum 0.87” (22.0 mm) M8
(View from the side)
Warning
●In order to maintain the TV’s performance and safety, be absolutely sure to ask your dealer or a licensed contractor to secure the wall-hanging brackets.
●Carefully read the instructions accompanying optional accessories, and be absolutely sure to take steps to prevent the TV from tipping over.
●Handle the TV carefully during installation since subjecting it to impact or other forces may cause product damage.
●Take care when fixing wall brackets to the wall. Always ensure that there are no electrical cables or pipes in the wall before hanging bracket.
●When using the angled-type wall hanging bracket, please ensure that there is sufficient space for the connecting cables not to press against the wall when the TV is tilted forward.
●For safety reasons, remove units no longer being used from their wall-mounted locations.
8
■Assembling the pedestal |
Attaching the pedestal to TV |
|
|
[TC-P60ST30] |
[TC-P65ST30] |
Fix securely with assembly screws A |
Fix securely with assembly screws A |
(Total 4 screws). |
(Total 6 screws). |
Tighten screws firmly. |
Tighten screws firmly using Allen |
|
wrench C . |
A |
A |
|
|
|
C |
Front |
Front |
■Set-up
Carry out work on a horizontal and level surface.
Tighten assembly screws B (total 4 screws) loosely at first, then tighten them firmly to fix securely.
Bottom view
B
Rear side
Arrow mark
Arrow mark
Hole for pedestal installation
Pole
Base
(Image: TC-P60ST30)
Removing the pedestal from the TV
Be sure to remove the pedestal in the following way when using the wall hanging bracket or repacking the TV.
Remove the assembly screws B from the TV.
Pull out the TV from the pedestal.
Remove the assembly screws A from the pole.
Accessories
Assembly screws
A
THEL090N (for 60”)
size (M5 x 25) (Black) (4)
THEL093J (for 65”)
size (M5 x 30) (Black) (6)
B
THEL090N (for 60”)
size (M5 x 25) (Black) (4)
XYN6+F25FJK (for 65”) size (M6 x 25) (Black) (4)
Poles (2) (for 60”)
L
R
● L or R is printed at the front of the poles.
(for 65”)
Base (1) (for 60”)
(for 65”)
Allen wrench
(included tool only for 65”)
C
Accessories Accessories/Optional started Getting
9
Warning
Do not disassemble or modify the pedestal.
Otherwise the TV may fall over and become damaged, and personal injury may result.
Caution
Do not use any pedestal other than that provided with this TV.
Otherwise the TV may fall over and become damaged, and personal injury may result.
Do not use the pedestal if it becomes warped or physically damaged.
If you use the pedestal when it is physically damaged, personal injury may result. Contact your nearest Panasonic Dealer immediately.
During set-up, make sure that all screws are securely tightened.
If sufficient care is not taken to ensure screws are properly tightened during assembly, the pedestal will not be strong enough to support the TV, and it might fall over and become damaged, and personal injury may result.
When removing the pedestal, do not remove the pedestal by any methods other than the specified procedure. (p. 9)
Otherwise the TV and/or pedestal may fall over and become damaged, and personal injury may result.
Installing the remote’s batteries
|
Close |
Caution |
|
Incorrect installation may cause |
|
Pull open |
|
|
|
battery leakage and corrosion, |
|
|
|
|
|
|
resulting in damage to the remote |
|
|
control. |
Hook |
|
• Do not mix old and new batteries. |
|
Do not mix different battery types (such |
|
Note the correct |
|
• as alkaline and manganese batteries). |
polarity (+ or -). |
|
Do not use rechargeable (Ni-Cd) |
|
|
• batteries. |
Do not burn or break batteries.
Power cord connection
To attach |
To remove |
Insert it firmly until the tabs on both sides click into place.
Keep pushing both sides until they snap and pull.
10
Connection Panels
|
Front of the TV |
LAN connector DIGITAL AUDIO OUT |
SD card |
|
A |
slot (p.26) |
|
|
|
|
B |
USB1/2 |
|
C |
connector |
|
|
|
|
|
HDMI 3 |
Back of the TV |
|
terminal |
|
|
|
Antenna or Cable connection |
|
* See page 10 |
Back of the TV |
VHF/UHF Antenna |
|
(Power cord |
|
|
|
connection) |
|
|
|
|
|
|
Cable TV or |
Power Cord |
|
VHF/UHF Antenna |
|
(Connect after all the |
|
||
other connections have |
• NTSC (National Television System Committee): |
|
|
been made.) |
|
ATSC (Advanced Television Systems Committee): |
|
|
|
Digital TV Standards include digital high-definition television (HDTV), standard-definition television |
(SDTV), data broadcasting, multichannel surround-sound audio and interactive television.
Cable
●You need to subscribe to a cable TV service to enjoy viewing their programming.
●You may need to subscribe to a high-definition (HD) cable service to enjoy HD programming.
The connection for high-definition can be done with the use of an HDMI or Component Video cable. (p. 12)
Note
●When using a Cable box, external equipment and video cables shown in this manual are not supplied with the TV.
●When disconnecting the power cord, be absolutely sure to disconnect the power cord plug from the wall outlet first.
●For additional assistance, visit us at: www.panasonic.com/help
www.panasonic.ca
started Getting |
|
|
|
Accessories/Optional |
Connections |
Accessories |
|
Connection references |
|
■Antenna terminal |
■Pin terminals |
|
red blue green |
|
green |
●Firmly tighten by hand. |
●Match colors of plugs and terminals. |
|
●Insert firmly. |
■HDMI terminal
●Insert firmly.
11
AV cable connection
Best |
To use HDMI terminals |
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
HDMI-DVI
Conversion cable
Connect to Audio input terminal
HDMI connection (p. 57)
●VIERA Link connection, please refer to p. 33
●The HDMI connection is required for a 1080p signal.
HDMI |
AV Equipment |
|
|
AV OUT |
e.g. Blu-ray Disc |
|
|
|
player |
DVI OUT |
AV Equipment |
L |
|
AUDIO OUT |
e.g. Blu-ray Disc |
R |
|
|
player |
To use COMPONENT terminals
Good
|
|
Y |
|
|
red |
green |
green |
|
|
|
|
|
||
|
|
PB |
COMPONENT |
|
blue |
blue |
blue |
VIDEO OUT |
AV Equipment |
|
|
PR |
|
|
green |
red |
red |
|
e.g. Blu-ray Disc |
|
|
L |
|
|
white |
white |
white |
AUDIO |
player |
|
||||
|
|
R |
OUT |
|
red |
red |
red |
|
|
|
|
|
|
To use COMPOSITE terminals
Basic
(Not HD)
|
|
|
|
AV Equipment |
yellow |
yellow |
yellow |
|
|
|
|
L |
COMPOSITE |
e.g. DVD Recorder |
white |
white |
|
||
white |
OUT |
or |
||
|
|
R |
|
|
red |
red |
red |
|
e.g. VCR |
|
|
|
||
|
|
|
|
Audio connection
|
Audio equipment |
|
DIGITAL |
Optical cable |
AUDIO IN |
|
|
●For HDMI-ARC (Audio Return Channel) connection, see p. 32 |
e.g. Amplifier |
12
TV controls/indicators
Front of the TV
POWER button
Back of the TV
3D Eyewear
transmitter
Selects channels in sequence
Volume up/down
Displays the Main Menu Changes the input mode Chooses Menu and Submenu entries
Power indicator
(on: red, off: no light)
C.A.T.S. sensor
Plasma C.A.T.S. (Contrast Automatic
Tracking System) (p. 49)
Note
●The TV consumes a small amount of electric energy even when turned off.
●Do not place any objects between the TV remote control sensor and remote control.
Remote control
Switches TV On or Off (Standby)
Displays 3D settings. (p. 25)
Lights the buttons for 5 seconds Press again to turn off the button lights
Select source to watch (p. 23)
Switches to input terminal that has “GAME” label (p. 23)
Displays Main Menu (p. 48)
Displays Sub Menu for special functions (when available) (p. 20)
Colored buttons
(used for various functions)
Volume up/down
Sound Mute On/Off
Changes aspect ratio and zoom (p. 20, 55)
Switches to previously viewed channel or input
External equipment operations (p. 37)
Closed caption On/Off (p. 19)
Selects Secondary Audio Programming (p. 19)
Exits from Menu screen
VIERA Link menu (p. 36-37)
Displays VIERA Connect (includes VIERA
CAST) Home screen (p. 43)
Displays VIERA TOOLS menu (p. 22)
Selects/OK/Change
Go back to previous menu
Channel up/down, when viewing from ANT/ Cable source
Displays or removes the channel banner (p. 19)
Operates the Favorite channel list function (p. 20)
Numeric keypad to select any channel or
press to enter alphanumeric input in menus Use for digital channels (p. 19)
Controls Identifying started Getting
Connections
13
The first time setup screen is displayed only when the TV is turned on for the first time after the power cord is inserted into a wall outlet and when “Auto power on” (p. 53) is set to “No”.
Turn the TV On with the POWER button
(TV) (Remote)
or
or
Configure your viewing mode
Select your language
Language / Idioma / Langue |
Step 1 of 7 / Paso 1 de 7 / Étape 1 de 7 |
|||
Select your language |
|
|
|
|
Seleccione su idioma |
|
|
|
|
Sélection de la langue |
|
|
|
|
English |
|
|
|
|
Español |
Français |
|||
|
|
|
|
|
Select OK
Selección
Sélection
select
OK
Select your country
Country |
Step 2 of 7 |
Select the country where this TV is being used.
U.S.A. |
Canada |
|
Other |
OK
Select RETURN
select
OK
Select your viewing mode (Be sure to select “Home use”)
Set viewing mode |
|
Step 3 of 7 |
|
|
Select your viewing environment |
select |
|
|
Home use |
Store Demonstration |
|
|
|
||
|
|
|
OK |
Select |
OK |
|
|
RETURN |
|
|
|
|
|
|
●Please confirm your selection (Home Use) before pressing OK button.
■If you select “Store Demonstration” by mistake in , confirmation screen will be displayed.
You are selecting the store demonstration mode.
Yes |
|
No |
If you select “Yes”, the picture mode will regularly reset
to “Vivid” and a Picture Refresh message will be displayed on the screen.
select
OK
●Select “No” and return to previous screen .
●If you select “Yes”, Screen enters the store demonstration mode.
To display the “Set viewing mode” screen again as shown above and select “Home Use”, do one of the following:
• Press and hold down the front POWER button for at least five seconds.
• Unplug power cord for 30 seconds and plug it again.
|
Note |
|
●If you use any other step other than then turn the TV off, or if you used |
|
the EXIT button to quit before completing the settings, the next time you turn |
|
the TV on, “First time setup” will not be automatically displayed. |
|
• The settings up to that point are saved. |
|
• You can start “First time setup”. (p. 53) |
|
●Language, ANT/Cable setup, Input labels and Clock can also be changed in |
14 |
the Settings Menu. (p. 53) |
|
Press to exit from a menu screen
Press to go back to the previous screen
Note
About broadcasting systems
Analog (NTSC):
Conventional broadcasting
Digital (ATSC):
New programming that allows you
to view more channels featuring high-quality video and sound
ANT/Cable setup
Do you use a Cable, Satellite or Fiber Optic box with this TV?
ANT/Cable setup |
Step 4 of 7 |
Do you use a Cable, Satellite or Fiber Optic box with this TV?
Yes |
No |
OK
Select Return
No
a Select signal type
(Cable/Antenna)
ANT/Cable setup |
Step 4 of 7 |
How does the TV receive its programming content?
Cable service |
Over-the-Air Antenna |
|
(No box) |
||
|
Antenna
Cable In
OK
Select Return
Yes
b Select connection type for Cable or Satellite box and go to (Input labels)
|
ANT/Cable setup |
Step 4 of 7 |
|
select |
Which wiring method is used to connect your box to the TV? |
||
VIDEO IN |
Antenna/Cable in |
||
|
HDMI |
|
|
OK |
Component |
Antenna |
|
Cable In |
|||
|
|||
|
Composite |
|
OK
Select Return
started Getting
Select scan type
Auto program |
Step 4 of 7 |
Start scanning for available channels in your area?
Yes No
OK
Select Return
Yes
Start scanning
Auto program
Progress |
|
|
1% |
|
Number of analog channels |
|
|
|
|
||
|
Number of digital channels |
0 |
This may take some time to complete. Press RETURN to quit
RETURN
Complete scanning
Auto program completed.
Press OK to continue.
Number of analog channels |
10 |
Number of digital channels |
|
20 |
OK
RETURN
select
OK
Setup Time First
15
Press to exit from a menu screen
■Press to go back to the previous screen
Label the inputs for easy identification (Label inputs)
To name each input, follow the instructions on screen.
When done, select NEXT and press OK to go to the next step.
|
|
|
|
|
|
select |
|
|
|
|
|
|
|
|
|
|
Label inputs |
Step 5 of 7 |
|
|
|
Video |
|
GAME |
|
|
|
|
|
||||
What is connected to HDMI 1 ? |
|
|
or |
|
Next |
|
|
|
|
|
|
|
||||
For your convenience, you may name each input for easy identification. |
|
|
|
|
|
|
|
|
|
|
|
|||||
The labels will be shown in the “Input select” menu. |
|
set |
|
|
OK |
|
|
|
|
|
||||||
|
HDMI 1 |
|
|
|
|
|
|
Select |
4 GHI |
5 JKL |
6MNO |
|
|
|||
|
|
|
|
|
|
|
RETURN |
7PQRS |
8 TUV |
9WXYZ |
|
|
||||
|
HDMI 2 |
|
|
|
|
|
|
|
|
LAST |
0 - , |
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
ABC abc |
|||||
|
HDMI 3 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Component |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Video |
|
|
|
|
|
|
Follow the instructions on |
||||||||
|
Next |
|
|
|
HDMI |
|
|
|||||||||
|
|
|
|
|
|
|
|
screen to complete the |
||||||||
|
|
OK |
|
|
|
|||||||||||
|
Customize label |
|
|
|
following operations. |
|||||||||||
Select |
Return |
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
--> To edit the labels to match your connected devices.
Label: [BLANK] Blu-ray/CABLE/SATELLITE/DVD/DVD REC/DVR/GAME/HOME THTR/RECEIVER/COMPUTER/MEDIA CTR/MEDIA EXT/VCR/CAMERA/ MONITOR/AUX/OTHER/Not used
•Select “Not used” for any back-panel input that has no device connected to it. Afterward, the input will be skipped when pressing INPUT, for your convenience.
•The input labels can be changed at any time from the TV’s setup menu
Configure Network settings
Select the Network type
Network settings |
|
|
Step 6 of 7 |
Set later: |
Go to |
|
Select Ethernet cable of wireless network. |
|
|
|
You can set in “Setup” menu later. |
||
Ethernet cable |
Wireless(Wifi) |
Set later |
|
|
||
|
|
|
|
|
Wireless (WiFi): Start “Wireless network” (p. 18) |
|
Select |
OK |
|
|
|
|
|
Return |
|
|
|
|
|
|
|
|
|
|
|
|
Select the setting mode
Network settings Step 6 of 7
Checks for proper network connection, settings and communication to the Internet and server automatically.
Automatic Manual
OK
Select RETURN
Automatic
Start connection test
Automatic: Press OK to start setup automatically. Error screen is displayed when Network connection has failed.
Manual: Go to Manual setting.
Manual
■Manual setting
Network settings |
Step 6 of 7 |
|
Connection test |
|
||
|
|
|
|
|
||
|
Connection test |
|
|
|||
|
Check Ethernet cable connection |
|
|
|
|
|
|
Validate IP address |
|
|
|
|
|
|
Check for IP address duplication |
|
|
|
|
|
|
Check connection to the Internet |
|
|
|
|
|
|
Check communication with VIERA Connect server. |
|
|
|
|
|
|
Test in progress... |
|
|
|
|
|
|
|
|
|
|
Connection |
|
|
|
|
|
|||
|
RETURN |
|
|
|
error |
|
Complete “Network settings”
Helpful information is displayed when you successfully complete “Network settings”.
Network settings |
Step 6 of 7 |
Network settings are complete. You can use VIERA Connect.
VIERA Connect lets you enjoy Internet contents on your VIERA TV.
OK
Return
Network settings |
|
Step 6 of 7 |
||
Configure settings of the network connection. |
||||
|
IP setting mode |
Automatic |
|
|
|
IP address |
192.168.0.4 |
|
|
|
Subnet mask |
255.255.255.0 |
|
|
|
Default gateway |
192.168.0.1 |
|
|
|
DNS setting mode |
Automatic |
|
|
|
DNS |
192.168.0.1 |
|
|
|
Proxy address |
|
|
|
|
Proxy port |
|
|
|
|
Connect test |
|
|
|
|
Mac address |
00-00-aa-cc-33-ab |
|
|
Select |
|
|
|
|
Change |
|
RETURN |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Manual |
|
|
|
|
||
■Error screen |
|
|
|
|
|||||
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
Network settings |
|
|
|
Step 6 of 7 |
||||
|
|
|
|
|
|
|
|
|
|
|
|
Connection test |
|
|
|
|
|
|
|
|
|
Check Ethernet cable connection |
|
|
|
|
|||
|
|
Validate IP address |
|
|
|
|
|
|
|
|
|
Check for IP address duplication |
|
|
|
|
|||
|
|
Check connection to the Internet |
|
|
|
|
|||
|
|
Check communication with VIERA Connect server. |
|
||||||
|
|
Connection to local network (router) failed. |
|
||||||
|
|
Ensure wireless network availability |
|
|
|
|
|||
|
|
Retry |
Manual |
|
Set later |
|
|
||
|
Select |
OK |
|
|
|
|
|
|
|
|
RETURN |
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
Retry: Go to “Start connection test” Set later: Go to
16
Press to exit from a menu screen
■Press to go back to the previous screen
Adjust the Clock (Set clock)
When done, select NEXT and press OK to go to the next step.
■Manual setting
Adjust the TV's date and time |
Step 7 of 7 |
select |
|
Minutes |
10 |
|
|||
Set clock |
|
|
|
|
|
|
|
||
|
Year |
|
- - - |
|
set |
or |
|
|
|
|
Mode |
|
Manual |
|
|
|
|
|
|
|
Month |
|
- - - |
|
|
|
OK |
0 |
9 |
|
Day |
|
- - - |
|
|
|
|
|
|
|
Hour |
|
- - - |
|
|
|
RETURN |
|
|
|
Time zone |
|
- - - |
|
|
|
|
|
|
|
Minute |
|
|
|
|
|
|
|
|
|
DST |
|
|
|
|
|
|
|
|
|
Next |
|
|
|
|
|
Follow the instructions on |
|
|
Select |
Edit |
0 |
- 9 |
|
|
|
|
||
Change |
RETURN |
|
|
|
|
|
screen to complete the |
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
following operations. |
|
■Auto setting
Set clock |
Step 7 of 7 |
|
Adjust the TV's date and time |
||
|
2011/4/5 |
6:00 AM |
|
Mode |
Auto |
|
Year |
|
|
Month |
|
|
Day |
|
|
Hour |
|
|
Minute |
|
|
Time zone |
EST |
|
DST |
Off |
|
Next |
|
Select |
|
|
Change |
RETURN |
|
|
|
|
|
Manual: Adjust the clock manually (Year/Month/Day/Hour/Minute) |
|
Mode |
|
||
|
Auto: The clock is adjusted automatically via Internet service. Only |
||
|
|
||
|
|
available when the TV is on a network. -->Set “Network settings” first. |
|
|
|
Select your time zone. (EST/CST/MST/PST/AKST/HST/NST/AST) |
|
Time zone |
|||
|
|||
|
|
Set DST (Daylight Saving Time) setting. (On/Off) |
|
DST |
|
||
|
On: Advances the clock one hour from the time it is set according to the |
||
|
|
||
|
|
time zone. |
Complete First time setup
Congratulations! You are done.
The First time setup can be repeated at any time.
Press MENU and select SETUP; then “First time setup”.
Congratulations!
Setup is complete.
Enjoy your Panasonic VIERA TV.
OK
RETURN
To watch TV via a Cable box, Satellite receiver, or any other source (DVD, DVR, gaming device, etc.), press the INPUT button and select the appropriate input.
Setup Time First started Getting
17
■About wireless LAN
●To use the Wireless LAN Adapter, an access point needs to be obtained.
For the additional information for Wireless LAN Adapters, check the following website: http://Panasonic.com/NetConnect
●It is recommended to use the Wireless LAN Adapter with the supplied extension cable.
●Do not use the Wireless LAN Adapter to connect to any wireless network (SSID*) for which you do not have usage rights. Such networks may be listed as a result of searches. However, using them may be regarded as illegal access.
* SSID is a name for identifying a particular wireless network for transmission.
●Do not subject the Wireless LAN Adapter to high temperatures, direct sunlight or moisture.
●Do not bend, or subject the Wireless LAN Adapter to strong impacts.
●Do not disassemble or alter the Wireless LAN Adapter in any way.
●Do not attempt to install the Wireless LAN Adapter in any incompatible device.
●When VIERA Connect, Network camera, DLNA, or other device is using the network, do not disconnect the Wireless LAN Adapter.
●Check that the Access point supports WPS*.
(If it does not support WPS, the encryption key of the Access point is required when configuring settings.)
●Follow the instructions on the Access point setup screen and configure the appropriate security settings. For more details on setting of Access point, please refer to operating manual for the Access point.
●We recommend using 11n (5 GHz) for the wireless system between the Wireless LAN Adapter and Access point. Communication is also possible with 11a, 11b, and 11g (2.4 GHz), but the communication speed may be slower.
●If the wireless system of the Access point is changed, devices that could connect by wireless LAN may no longer be able to connect.
●Data transmitted and received over radio waves may be intercepted and monitored.
●Keep the TV away from the following devices as much as possible:
Wireless LAN, microwaves, and other devices that use 2.4 GHz and 5 GHz signals. Otherwise, the TV failures such as malfunction may occur due to the radio wave interference.
●When noises occur due to the static electricity, etc., the TV might stop operating for the protection of the devices. In this case, turn the TV Off with power On / Off switch, then turn it On again.
* WPS: Wi-Fi Protected Setup
■Wireless network (First time setup) in
Display “Wireless network”
Select the connection method
select
Wireless network
Please choose connection method: |
|
Search for wireless networks |
OK |
WPS (Wi-Fi Protected Setup using push button) |
|
●Follow the directions on screen to complete the setting.
●See page 41 for more information.
18
Turn power on
(Remote) |
(TV) |
Note |
Please select correct input --> (p. 23)
or
■VIERA Connect Banner appears
Press OK/INTERNET (or VIERA CAST) button to enter VIERA Connect. (p. 43)
●To hide the banner Press any button except OK/INTERNET (or VIERA CAST) button (Time-out period of this banner is 5 sec.)
●You can also set the banner display status (on/off) in the Setup menu. (p. 53)
Menu > Setup > Advanced setup > VIERA Connect Banner
Select a channel number
up
or down
• Also available side CH button on the unit.
[For Cable/Satellite box connection]
- Use your connected box’s remote control.
Note
To directly enter the digital channel
number
When tuning to a digital channel,
press the button to enter the minor number in a compound channel number.
example: CH15-1:
Reselect “Cable” or “Antenna” in “ANT in” of “ANT/Cable setup” to switch the signal reception between cable TV and antenna. (p. 15, 46)
The channel number and volume level remain the same even after the TV is turned off.
■Other Useful Functions
Listen with SAP (Secondary Audio Programming)
■Select the Audio mode for watching TV
Digital mode
Press SAP to select next Audio track (if available) when receiving a digital channel.
Audio track 1 of 2 (English)
Analog mode
Press SAP to select the desired Audio mode.
• Each press of SAP will change the Audio mode. (Stereo/SAP/Mono)
SAP is not available when watching TV with a Cable or Satellite box connected via HDMI.
Contact your Cable or Satellite operator for instructions on enabling SAP with their box.
Closed Caption
■Switches the Closed Caption mode On or Off
Closed caption Off |
|
Closed caption On |
|
Closed caption On mute |
|
|
|
|
|
Closed Caption is not available when watching TV with a Cable or Satellite box connected via HDMI.
Contact your Cable or Satellite operator for instructions on enabling CC with their box.
Displaying Information
■Displays and removes information. When watching programming via the Antenna/Cable input, shows the channel banner.
Channel Clock
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
THE NEWS |
|
|
|
|
|
|
|
|
|
|||||
15-2 |
|
|
|
|
|
|
12:30 |
PM |
|
|||||||
ABC-HD |
CC SAP |
TV-G |
1080i |
Standard |
4:3 |
30 |
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Station |
|
SAP |
|
|
Signal |
Picture |
|
|
Sleep |
timer |
||||||
identifier |
|
indication |
|
resolution |
mode |
|
|
remaining time |
||||||||
|
|
Closed |
caption |
Rating Level |
|
|
Aspect ratio |
Basic started Getting
TV Watching
Setup Time First
19
Change aspect ratio and Zoom the picture
■Press FORMAT to cycle through the aspect modes (p. 55)
• 480i, 480p: FULL/JUST/4:3/ZOOM
• 1080p, 1080i, 720p: FULL/H-FILL/JUST/4:3/ZOOM
Use when the picture does not fill the whole screen (bars appears on either side of the image) or portions of the picture is trimmed.
Note
1.Some content, such as film-based movies, are available in extra-wide format. Top and bottom bars are unavailable.
2.Connected devices, such as Cable/Satellite box, DVD/Blu-ray players and game consoles have their own aspect (format) settings. Adjust the device’s aspect settings.
Display the SUB MENU
■Press SUB MENU to show the Sub Menu screen
This menu consists of shortcuts to convenient functions.
Sub menu is only available when the TV is using the Antenna/Cable input, not when using Cable or Satellite box.
Setup SUB MENU |
|
Specify favorites or type of channels to view when pressing the channel up/ |
Channel surf mode |
|
|
|
||
All |
|
down button. |
Set favorite |
|
Set favorite channel (below) |
|
||
Edit CH caption |
|
Edit the channel identifier (p. 47) |
|
||
Signal meter |
|
Check the signal strength (p. 47) |
|
|
Call up a favorite channel
■FAVORITE
Channel numbers registered in Favorite are displayed on the favorite tune screen. Select the desired broadcast station with the cursor or use the number buttons. (p. 19)
Favorite channels |
1/3 |
select |
|
|
|||
1 |
26-1 |
|
|
|
|
|
|
2 |
or |
|
|
3 |
|
4 |
|
5 |
|
■Set the Favorite channel
Setup SUB MENU |
|
|
Set favorite |
1/3 |
|
select the list |
|
Channel surf mode |
|
|
|
26-1 |
|
|
number |
|
1 |
|
|
||||
|
|
|
|
|
|
||
All |
|
|
2 |
|
|
|
save the displayed |
|
|
|
|
|
|
|
|
Set favorite |
|
|
3 |
|
|
|
|
Edit CH caption |
|
|
4 |
|
|
|
channel |
Signal meter |
|
|
5 |
|
|
|
or |
|
|
|
|
||||
|
|
|
|
|
|
|
select the list number (to save the channel without pressing OK)
■Delete a favorite channel
Set favorite |
1/3 |
select |
|
1 |
26-1 |
|
|
2 |
|
|
|
3 |
|
|
delete |
4 |
|
|
|
5 |
|
|
(while holding down) |
|
|
|
■To change the page
Press repeatedly to change between pages (1/3, 2/3, 3/3 or exit)
|
Changes the page forward/backward |
20 |
●Favorite channels cannot be set when using Cable or Satellite box. |
|
■Other Useful operations
Entering characters
You can use the remote control keys to enter the alphanumeric characters.
■Switches input mode |
|
|
|
|
|
|
||||
Menu |
Proxy setting |
|
||||||||
|
|
|
Proxy address |
|
||||||
|
|
|
|
|
|
|
||||
ABC → abc → 123 |
|
|
|
1 |
4 |
8 |
|
|
||
|
|
|
|
|
|
|
||||
|
|
|
Proxy port |
0 |
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
■Press each number key |
|
OK |
|
|
|
to cycle through the |
|
4 |
GHI 5 |
JKL 6MNO |
|
alphanumeric character |
|
|
1 |
@. 2 ABC 3 DEF |
|
Select |
RETURN |
LAST 0 |
- , |
||
|
|
7PQRS 8 TUV 9WXYZ |
|||
|
|
ABC → abc |
|
|
Delete |
Navigation area
●You can also use a USB keyboard (not supplied) to enter the alphanumeric characters.
●Keyboard type (p. 53)
Password setting/entering
You need to enter the password when you access locked channel or inputs.
Input your 4-digit password
Menu Password
Enter password.
* * * -
●If it is your first time entering the password, enter the password twice in order to register it.
●Make a note of your password. Do not forget it. (If you have forgotten your password, consult your local dealer.)
●When you select a locked channel, a message will be displayed that allows you to view the channel after you input your password.
●Change password (p. 52)
Operate USB keyboard
You can operate non-character keys as remote control keys.
■Key chart
Keyboard key |
Remote key |
Keyboard key |
Remote key |
UP/DOWN/LEFT/RIGHT |
Cursor key |
F4 |
Input |
Enter |
OK |
F5 |
Channel Down(-) |
BackSpace |
Return (when you do not |
F6 |
Channel up(+) |
|
input character) |
|
|
0-9 |
0-9 |
F7 |
Volume Down(-) |
F1 |
Menu |
F8 |
Volume up(+) |
F2 |
VIERA Tools |
F9(Red)/F10(Green)/ |
Color key |
F3 |
Submenu |
F11(Blue)/F12(Yellow) |
(Red/Blue/Yellow/Green) |
●For more details on setting and operation of the USB keyboard, please also read the operating manuals for the USB keyboard.
●Some keyboards do not have these keys.
Basic
TV Watching
21
